Plevo Up User manual

User Guide
UP

Welcome to the PLEVO family
www.plevo.co

UP
Product
01- Product external parts
Removable battery
02- Parts and features
03- Installation
04- Extraction method
Removable wheels
05- Installation
06- Dismantling
Mobile application and electronic lock
07- Components
08- Electronic lock (Morse code)
09- Electronic lock (Face ID/Touch ID)
10- Digital Scale
11- GPS
Airplane mode
12- Activation and disabling method
Communication
13-15- Lights and alerts indicators
Garment bag System
16- Components
17-19- Operation
Table of Contents

PRODUCT 1

01UP User Guide
Front cover
Side handle
Frontal logo
Front lock flaps
Secondary handle
Front light indicator
Removable wheel
Main handle
Electronic lock
Battery access cover
Dashboard
Button
Support plugs
Wheel holder
Body
Hinged
Aluminum frame
Rear logo
Outer parts of the suitcase
The images in this manual are illustrative and can vary with actual model.

REMOVABLE
BATTERY

02UP User Guide
Parts and characteristics
Our energy bank with lithium-ion battery (8,000
mah) is fully removable from PLEVO baggage.
-Dimensions: 85.5 x 84 x 21 mm
-Capacity: 8000 Mah/29.6 WH
-Input (Micro): 5v/3a 9v/2a
-Input (C-type): 5v/3a 9v/2a
-type-C output 5v/3a 9v/2a 12v/1.5 A-QC 3.0 output:
5v/3a 9v/2a 12v/1.5 A
-USB output: 5v/3a
-Total output: 18w MAX
USB 3.0 USB USB-C
Micro USB Power button
Battery
lights
Characteristics:

Picture 1
Picture 2
A
03UP User Guide
Installation
To install the energy bank, it is necessary
to access the "A" cover on the back of
the board and open it by rotating it
downwards. This cover protects internal
components from shocks, dust, and
water so it is recommended that it is
always closed while the battery is not in
use.
Open the rubber cover to the right
to access the internal compartment
of the board .
Position the battery horizontally and
press forward until the mechanism
locks and the element is anchored.

1 2 3
04UP User Guide
Extraction method
!
BATTERY BACKUP
Our system has a nickel-ion back-up battery of less than 600mAh and its
weight is 39g (2.16 Wh). This battery feeds THE WHOLE suitcase when the
removable battery is not installed on it.
Open the sticky cover to the right to access
the battery.
Press forward slightly until the ejection
mechanism is released.
Remove the battery horizontally forward,
without making any upward or lateral
pressure.

REMOVABLE
WHEELS

1
2
3
B
A
A
AA
05UP User Guide
Installation
To be able to set each of the wheels
it is necessary to get access to the
four "A" locks placed in the lower
part of the suitcase. Follow steps 1-3
to remove the latch and install the
wheels.
Hold the latch button down and
place the wheel bolt into orifice B.
Make pressure on the wheel until it
fully snaps into the orifice.
Release the safety button so that
the final adjustment is done.

1
2
3
C
A
A
A
A
06UP User Guide
Disassembly
To remove each one of the wheels, it
is necessary to access the four "A"
locks located in the lower part of the
bag. Follow steps 1-3 to remove the
safe and extract the wheels.
Hold the button back to release
the latch.
Pull the wheel backwards while
holding down the button.
The wheel is released once the
"C" Bolt is completely out from
the orifice.

MOBILE
APPLICATION AND
ELECTRONIC LOCK

Morse code
button
TSA logo
Indicator light
TSA Lock
Secondary handle
Using Travel Sentry Approved lock allows your
luggage to be unlocked and inspected by security
authorities without damage.
07UP User Guide
COMPONENTS - Electronic lock

If the Morse code has entered
correctly, the flaps "B", located
up and down the closing, will
open automatically releasing the
latch.
1 2 3
08UP User Guide
A
3
B
B
Electronic lock (Morse code)
All PLEVO bags have an alternate Morse code closure system that replaces the old padlocks. Only one-
time code configuration is required, and it will be ready for use at any time without depending on the
battery or mobile phone.
Configure the code from our
mobile application. You must
select 4 digits. Allowed numbers:
1 to 5. For example: 1234.
To open the bag, it is necessary
to press the digit button. Doing
so will turn the light (A) red on
and the action will be taken as a
number. So, if you press once, it
will be 1, if you press three
consecutive times, it is 3.

Immediately turn on the CYAN
light the flaps "B", located up and
down the closing, will open
automatically releasing the latch.
1 2 3
A
B
B
09UP User Guide
Electronic lock (Face ID/Touch ID)
It is possible to open or close the bag by means of biometrics by using our mobile application. Depending
on the smartphone model used you can choose to use facial recognition or fingerprint. In order to perform
this action, it is necessary to follow the steps 1-3
It is necessary to activate the
opening method within the
application depending on the
device used. (In some cases, the
selection is automatic)
If the input by face ID or by
Touch ID has been correct the
"A" light will light in CYAN color
for 3 seconds, otherwise it will be
in red color communicating the
error.

10UP User Guide
Digital scale
1
2
You will be able to monitor the weight of your baggage on
your mobile device through our application.
A
While holding luggage with handle A, you will be able to view the weight of the baggage using
our mobile device application.
Important: Before weighing the bag, it is necessary to start a calibration from the Application.
This lasts a few seconds -click on "START TO CALIBRATE"-. The system will then be ready, and
the exact weight of the load will be displayed.
Lift the suitcase from the floor
using the "A" handle to
activate the sensors

11UP User Guide
GPS
PLEVO INFINITE
The PLEVO UP model features a GPS tracking system that will allow you
to locate the bag anywhere by using our mobile device application. In
order to use this feature, you need to install the APP on your device,
register and link the system with your luggage PLEVO.
Select the GPS function icon in
the lower bar of our app and
slide it to activate the system.
Our system will load the map of
the site where your baggage is
located, showing you the exact
location.
!
The application for PLEVO
devices has automatic
distance alerts to warn you
immediately when baggage is
removed from the owner.
<
New York, United States
ANDROID APP ON
Available on the

AIRPLANE
MODE

12UP User Guide
How to activate/deactivate airplane mode
At the moment the suitcase is placed in horizontal
mode the sensors that work with the GPS detect the
location and go into airplane mode to completely
disable, automatically, all the suitcase functions.
When landing, these sensors contact the GPS and
in case of being at the airport, they automatically
disable the airplane mode to re-connect all the
functions of the bag. In this way a safe product is
achieved that respects all the regulations in force.
Our PLEVO bags are developed using a system of sensors that
allow to detect what is happening and adjust the condition of
the baggage according to the norms established by the FAA,
IATA, DOT & EASA.
AIRPLANE MODE
You can monitor the activation and deactivation of
your baggage on your mobile device through our
application.
