Pni Hunting 2c User manual

PNI HUNTING 2C

Hunting camera

User manual 2

English

KEYS AND FUNCTION DESCRIPTION

Light sensor

Indicator light

LCD screen

Power

Navigation

Lens

Menu/OK

13 IR LED

13 IR lED

PIR sensor

Micro USB port

DC in

Battery slot

Micro SD card slot

3User manual

English

CAMERA SCREEN DISPLAY (TEST MODE MAIN INTERFACE)

Note: camera support camera, video, camera+video three dierent working modes; screen

display will be dierent based on dierent working mode.

Photo Mode

Recorded le number

Estimated available

le number *

Video Mode

* estimated available le number based on left memory space in memory card

Photo-Video Mode

Hour/Min./Sec.

Photo Resolution

Multi Shot Number

Battery left capacity

Year/Month/Day

Video resolution-Video FPS

MENU DESCRIPTION

• Main menu

ID camera Photo Video Photo+Video Settings Delete Back

• Menu, level 2 and 3. Settings.

Video settingsPhoto settings

Size Multi Shot Exit Resolution Length

PIR

Sensitivity

Date/Time

Foto Video Timer Time Lapse Delay Stamp SD Cycle Camera Sound

GPRS ON/OFF Password Reset

FPS Frequency Sound Exit

Exit

User manual 4

English

BASIC OPERATIONS

1. Open the cover on the back of the camera and insert the micro SD card and the batteries

Power on the camera

2. Press and hold Power/Navigation button for 3 seconds; camera will enter PIR Auto

working mode after indicator ashes 5 times

3. Press once the Menu/OK button to wake up camera LCD screen to enter Test Mode

Manual Photographing/ Video Recording

4. Test Mode main Interface - press again Power/Navigation button to shoot photos,

videos, or photo+video based on camera settings; stop video recording by pressing again

Power/Navigation button

Enter Menu for setup functions

5. Test Mode main Interface - press the Menu/OK button to enter the settings menu;

now the button it is for navigation only; the button it is just to conrm the settings

made

6. Press and hold the button for 3 seconds, to return to the main interface of the Test

Mode (Camera Modes Menu) after you have made all the settings

7. Test Mode main Interface - Press and hold the button for 3 seconds, to enter Auto

PIR mode; (the led indicator will blink 3 times, the screen will fe o󰀨)

Power o󰀨 the camera

8. Press and hold the button for 5 seconds to turn o󰀨 the camera.

CAMERA OPERATION

Camera ON/OFF

(PIR Auto, Test, OFF)

PIR Auto Mode

Hold pressed Power button

for 3 seconds; the camera

will enter PIR Auto mode after

the led indicator blinks 5 times

Test Mode

PIR Auto mode, press once

the button Menu/OK to

wake up the camera’s screen

and enter Test mode

Power o󰀨 Hold pressed Power button

for 3 seconds in order to

turn o󰀨 the camera

5User manual

English

Functions setup

Conguration

In Test Mode, press the Menu/

OK button to enter the settings

menu; now the button it’s

only for navigation; the button

it’s only for saving the

made settings

Return to rst

navigation menu

Press and hold the button for

3 seconds to return to the

main menu after you have

made all the settings

Enter PIR Auto Working

Mode from Test Mode

In the main menu, press and

hold the button for 3 seconds

to enter PIR Auto Mode

Manual recording

1. Set Photo, or Video, or Photo+Video

: press Menu/OK button; the camera is now on

Photo Mode

: press Menu/OK button; the camera is now on

Video Mode

: press Menu/OK button; the camera is now on

Photo+Video Mode

2. After conguration above, press and hold button for

3 seconds, to return back to Test Mode main interface;

then press Power/Navigation button camera now is

recording photo/ video/ photo+video

3. Press again Power/Navigare button to stop video

recording

Notes:

• To ensure the correct operation of the camera, please set the correct time;

• Please do not activate the function at the same time Time Lapse and Delay

• The camera can be turned o at any time by holding down the button

ADVANCED SETTINGS

• Camera modes

Default settings:

ID camera OFF Photo+Video OFF

Photo 2MP Settings

Video VGA (640*480) Delete

If the desired icon does not appear on the LCD screen, press the button repeatedly until

it appears.

User manual 6

English

ID Camera

a. Set up

1. Press to enter conguration page, press and choose ON;

press again to return to conguration page.

2. Press to choose numbers or letters, press to conrm and go

to the next setting.

3. Press to conrm and save.

b. How does this work?

The 4 selected digits/letters will be displayed on the photo stamp.

Such a function can help the user to identify the photos: where they were

made and from which camera.


a. Set up

Press to enter Photo Mode; the OK icon will appear at the bottom

right of the screen

b. Fotograere

Hold pressed the button for 3 seconds to return to test mode interface.

Then press to take a picture.

Video

a. Set up

Press to enter Video Mode; the OK icon will appear at the bottom

right of the screen

b. Start recording

Hold pressed the button for 3 seconds to return to test mode interface

, then press to record. Press once more to stop recording.

Photo+Video

a. Set up

Press to enter Photo+Video Mode; the OK icon will appear at the

bottom right of the screen.

b. Start recording; Photo(s) rst, then recording video

Hold press for 3 seconds the button to return to test mode interface

, then press to start recording; press again to stop

recording.

Settings Press to enter advanced settings interface.

7User manual

English

Delete

1. Press to enter conguration page, press to delete one or all

saved les, or format the SD card

2. Press choose Yes/No, press again to conrm the deletion

or formatting

Notes:

• The menu will remain in the Yes/No interface when you delete each

le; please press “No” to return to the previous interface. The user

can delete more les at once without pressing more buttons.

• If all les are deleted, the camera will automatically return to the

main Test Mode interface

Exit Press to return you to the main interface of the Test mode

• Photo Mode

Default settings:

Image size 2MP

Multi-shot 1P

If the desired icon does not appear on the LCD screen, press the button repeatedly until

it appears.

Image size Press to enter conguration page, press to choose the

desired size of the photo; press to conrm the settings.

(8MP/5MP/2MP: 3264x2448, 2560x1920, 1920x1080)

Multi-shot

Press to enter conguration page, Press to choose the

desired number for burst shooting; press to save and conrm

the settings.

(Support 1~7 photos per burst/ trigger)

• Video Mode

Default settings:

Video resolution VGA

Video length 5 sec.

Frames per second 30 fps

Frequency 50 Hz

Audio recording On

If the desired icon does not appear on the LCD screen, press the button repeatedly until

it appears.

User manual 8

English

Video resolution Press to enter conguration page, press to choose the

desired resolution, press to save the settings.

(720P/VGA/CIF: 1280x720/640x480/320x240)

Video length Press to enter conguration page, press to choose the

desired length for video recordings; press to save the settings.

(Support 5~60 seconds)

Frame per second Press to enter conguration page, press to choose the

desired frame rate; press to save the settings.

(Optional 15FPS and 30FPS)

Frequency Press to enter conguration page, press to choose the

desired frequency; press to save the settings.

(Optional 50HZ and 60HZ)

Delay Press to enter conguration page, press to enable or disable

audio recording; press to save the settings.

If you select “ON”, the video recordings will also have audio.

• Camera settings

Default settings:

Timer OFF

Time lapse OFF

Delay OFF

Stamp ON

SD cycle recording OFF

Camera sound ON

PIR sensotivity High

Date/Time -

GPRS OFF

Camera password OFF

Reset NO

If the desired icon does not appear on the LCD screen, press the button repeatedly until

it appears.

9User manual

English

Timer

a. Set up

1. Press to enter conguration page, press and choose

ON; press again to set the timer

2. Press to choose the desired number, press to save and

go to the next number

3. Press again to exit.

b. How does it work?

The camera will only work within the set time frame

Time lapse

a. Set up

1. Press to enter conguration page, press and choose

ON; press again to set the time lapse

2. Press to choose the desired number, press to save and

go to the next number

3. Press again to exit.

b. How does it work?

The camera will take pictures or record periodically at preset times

Delay

a. Set up

1. Press to enter conguration page, press and choose

ON; press again to set the desired delay

2. Press to choose the desired number, press to save and

go to the next number

3. Press again to exit.

b. How does it work?

The camera will take pictures or start recording after the set time

from motion detection

Stamp

a. Set up

1. Press to enter conguration page, press to choose ON/

OFF; press again to conrm the setting

b. How does it work?

Battery level, phase of the month, temperature, date/time and

camera ID will be printed on the photo

SD Cycle

Recording

a. Set up

1. Press to enter conguration page, press to choose ON/

OFF; press again to conrm the setting

b. How does it work?

If you select “ON”, the camera will continue to record photos or

videos by deleting older recordings from the SD card.

User manual 10

English

Camera sound

a. Set up

1. Press to enter the conguration page, press to choose

ON/OFF; press again to conrm the setting

b. How does it work?

Select “OFF” to deactivate the camera speaker

PIR sensitivity

a. Set up

1. Press to enter the conguration page, press to choose

between High/Middle/Low; press again to conrm the setting

b. How does it work?

High/Middle/Low;

High sensitivity means 1) more sensitive to the movements of small

objects; 2) greater detection distance; 3) easier for the camera

to detect the di󰀨erence between body temperature and external

temperature; 4) easier to trigger the camera. In high temperature

environments, the camera detects more di󰀩cult the di󰀨erence

between body temperature and ambient temperature, which is why

we recommend setting the PIT sensitivity to the maximum level..

Date/Time

a. Set up

1. Press to enter the conguration page, press to select

the desired date and time; press again to conrm the setting

b. How does it work?

Date/Time; Date: “month/day/year”; Hour: “hour/minute”

Note: We recommend that you set the correct time and date to

ensure the correct operation of the camera.

Camera password

a. Set up

1. Press to enter the conguration page, press and choose

ON; press again to set the password

2. Press to choose the desired number, press to conrm

and go to the next number

3. Press again to exit.

b. How does it work?

Activates the password protection of the camera; the camera

supports passwords of up to 6 characters.

Reset

a. Set up

1. Press to enter the conguration page, press and select

YES/NO; press again to conrm the setting

b. How does it work?

If you choose YES, the camera will reset to factory settings.

11 User manual

English

SOFTWARE UPDATE

1. Copy the 3 les for software update on the micro SD card;

Note: We recommend using a 1 or 2GB card

2. Insert the MicroSD Card into the camera

3. Insert the battery into the camera or plug it into a power source via the USB cable

4. Press and hold the Power/Navigation button , the camera will beep

5. Release the button when you see the LED blinking

6. Then press and hold Menu/OK button

Note: The led indicator does not blink but remains lit.

7. Release the button after you see the ISP icon on the screen

8. If the update was successful, the led indicator will turn o󰀨;

9. Remove the batteries or remove the power cord;

10. Reinsert the batteries and turn on the camera. Procedure completed.

Note: Do not interrupt the power supply while updating the software; otherwise, the camera

can only be turned on after a software update via a PC

USB CONNECTION

When the camera is connected via USB, press and hold the button , the camera will beep

and the led indicator will light up; then the following interface appears

Press and choose DC in or PC connection; press to conrm the setting.

1. DC power supply

The camera enters the main interface of the Test mode

2. PC connection to read SD card

The interface below appears on the camera screen. Now you can read the contents of the

SD card on your PC.

User manual 12

English

Press again the camera will become a PC camera; press again to exit.

Remove the power cord to turn o󰀨 the camera and restart it.

MICRO SD CARD SELECTION AND BATTERY LIFE TEST

To use the camera, you need a Micro SD card. When the camera is turned on “ON” and

no card has been inserted, “No SD Card” appears on the screen. The camera supports up

to 32 GB cards. When inserting or removing the card from the camera, it must be closed.

Otherwise, the images recorded on the memory card may be lost or damaged.

The following data shows the approximate number of photos that can be recorded by the

camera depending on the capacity of the memory card.

Capacity 1GB 2 GB 4 GB 8 GB 16 GB 32 GB

Foto (images)

2 MP 1645 3195 6197 12401 23786 50146

5 MP 653 1244 2356 4453 7957 14241

8 MP 421 796 1488 2873 4864 8092

Video (hours)

720P HD 00:09:50 00:18:41 00:35:15 01:06:51 02:11:18 04:20:54

640x480 00:21:31 00:41:58 01:22:13 02:47:27 05:29:13 13:01:16

320x160 00:50:45 01:44:18 03:21:04 06:37:45 13:22:58 27:00:20

Battery life test:

Test conditions: LCD screen o󰀨. Auto PIR Mode: “ON”

Alcaline batteries 4 x AA

Photos shot per day Working

time Video clips shot per day Working

time

IR LEDs On

2MP 100 photos 26 days 320× 240 10 sec 10 clips 47 days

5MP 100 photos 24 days 640× 480 10 sec 10 clips 44 days

8MP 100 photos 21 days 1280× 720 10 sec 10 clips 41 days

IR LEDs O󰀨

2MP 100 photos 51 days 320× 240 10 sec 10 clips 185 days

5MP 100 photos 48 days 640× 480 10 sec 10 clips 170 days

8MP 100 photos 46 days 1280× 720 10 sec 10 clips 161 days

13 User manual

English

TECHNICAL SPECIFICATIONS

Recording

Video format .avi

Video resolution

720P (1280*720)

D1 (640*480)

CIF (320*240)

Frame rate 15/30 FPS; programabil

Video length 5-60sec. programabil

Image format JPEG

Image resolution

2MP (1920x1080)

5MP (2560x1920)

8MP(3264x2448)

Countinuous shooting 1~7 photos/trigger(programmable)

Photo stamp

Battery left capacity

moon phase

Temperature

Date & time

ID camera—4 digits/ alphabets combination

(Programmable by User)

Record delay 1sec.~23h 59min 59sec

Might vision

Night vision distance 15m

IR LED 26

General

Image sensor 1.3 Mega Pixels Color CMOS

Lens F=3.0; FOV=49°; Auto IR-Cut-Remove

IR ash length 8 m

Infrared cut lter Yes

White balance Automatic

Day/night mode Color during day/B&W at night

Minimum lighting 0 Lux (IR on)

PIR angle 100°

PIR sensitivity High/Normal/Low

Record audio Da

Power supply 6~12V DC (1~2A)

Battery 4 x AA

Auto shut o󰀨 Enter PIR Auto Mode in 1min without any

operations

User manual 14

English

Interface USB; slot Micro SD card

Memory type Micro SD Card, up to 32G

Screen Ecran B/W 1.0 inch B/W

Language English

Sensor type PIR (Passive Infrared)

Sensory range 12~15m; 50 feet

Sensor triger speed 0.8-1 sec

Power consumption

150mA

(+1380mA: 940nm IR LEDs on)

(+1080mA: 850nm IR LEDs on)

Battery alert downloaded Da

Operating time in stand-by 4 months (4 x AA batteries)

Working temperature (-20 ~ 60) °C

Working humidity 5%-90%

Waterproof IP54

Dimensions 100.4*70.44*51.32mm

Weight 171.2 g

Functions

Photo+Video Yes

Time Lapse Yes

Timer Yes

Time Lapse Delay) Yes

Password protection Yes, 6 digits

Cyclic recording Yes

Auto power o󰀨 in Test Mode Yes

Water/WeatherProof Yes

EN:

EU Simplied Declaration of Conformity

SC ONLINESHOP SRL declares that Hunting camera PNI Hunting 2C complies with the Directive EMC

2014/30/EU and LVD 2014/35/EU. The full text of the EU declaration of conformity is available at the following

Internet address:
