Pocketbook SURFpad 4 S User manual

User Manual
PocketBook SURFpad 4 S

2
Contents
SAFETY PRECAUTIONS 4
APPEARANCE 6
TECHNICAL SPECIFICATIONS 7
GETTING STARTED 8
Charging The Battery 8
Unlock Your Device 9
Home Screen 9
Display Views 10
Finger Gestures 11
Using the On-screen Keyboard 12
Menus 12
Establishing Wi-Fi 13
Inserting Micro SD Card 13
Mobile Networks Connection 14
SOFTWARE 16
Manage Data 16
Application Launching 17
Creating Folders on the Home Screen 18
Application Removing 19
List of Opened Applications 19
Preinstalled Applications 20
PBI Packages Support 22
Listen to the Music 23
Gallery 24
MX Player 24
Camera 25
Browser 25
Email 26
SETTINGS 27
Language & Input 28
Sound Settings 30
Display Settings 31

3
Storage 32
Connecting Devices to Your Tablet 32
Unmounting External Memory and Devices 32
Location and Security 33
Date & Time 33
Restore Your Tablet to Factory Settings 34
Battery Charge State 35
Wi-Fi Connection 36
Connecting to Wi-Fi Network with
Automatically Obtained IP-address 36
Connection to Wi-Fi Network with
Manual Conguring Network Settings 37
Advanced Options 38
Turn off Wi-Fi 38
Bluetooth 38
Transferring Data 39
Scheduled Power On and Off 39
Printing 40
Information about Apps 40
FIRMWARE UPDATE 41
COMPLIANCE WITH INTERNATIONAL STANDARDS 44
CUSTOMER SUPPORT 47

4
Safety Precautions
Before start working with the Device, please, read this section carefully. Follow-
ing these instructions will help you ensure your safety and extend service life of
the Device.
Storage, Carriage and Usage Conditions
Device operating temperature range is 0°C to +40°C, so don’t expose the Device
to excessively high or low temperatures. Never leave cables near heat sources.
Heated cables or their insulation may become deformed or damaged, which
could lead to fire or electric shock.
Try to avoid next impacts:
•direct sunlight
•direct flame or smoke (cigarette, lighter, open fire etc.)
•exposure to liquids or damp (do not use the Device in the rain, in the street
at higher humidity, near bodies of water etc.)
•penetration of liquids or moisture
•exposure to strong electromagnetic fields, electrostatic charges and artificial
sources of UV electromagnetic radiation
•excessive mechanical pressure on the screen, connectors and keys of the
Device.
Do not leave the Device for a long time in poorly ventilated environment, e.g.
in a car or in closed tight boxes/packaging.
Neither drop nor try to bend the Device. Protect the screen from objects that
may scratch or damage it. To ensure adequate protection of the screen, we
recommend storing the Device in a protective and/or hard cover.
Keep away from children.
Maintenance
Do not disassemble or modify the Device.
Do not use the Device with a damaged battery, charger (broken case, poor
contact, broken feed cable) or SD card. If the battery is damaged (cracked case,
leakage of electrolyte, off-shape etc.) it should be replaced by the authorized

SAFETY PRECAUTIONS
5
personnel. Usage of home-made or modified batteries may cause an explo-
sion and/or damage the Device. Do not use organic or inorganic solvents (e.g.
benzoyl etc.) to clean the screen/case. Use a soft cloth to remove dust from the
Device’s surface. Apply a few drops of distilled water to remove dirt.
Up to five faulty pixels are acceptable in the screen and do not constitute a
warrantable defect of the screen.
When the product guarantee term is out of expiration, please contact the near-
est authorized service to diagnose whether the Device can be used safely.
For detailed information about service centers in your region please visit the official
website of PocketBook International: http://www.pocketbook-int.com/support/.
RF Safety
The Device receives and transmits radio frequencies and may interfere with
radio communications and other electronic equipment. If you use personal
medical Devices (e.g. a pacemaker or hearing aid) please contact your doctor
or the manufacturer to learn whether or not such medical devices are protected
against external RF signals.
Do not use wireless communication in places where it is prohibited, e.g. onboard
a plane and in hospitals – this may affect airborne avionics or medical equipment.
Utilization
Incorrect disposal of this Device may have adverse impacts on the environment
and public health. To prevent such consequences follow the device-specific
disposal requirements. Recycling of these materials helps preserve natural re-
sources. For more information regarding recycling issues please contact local
municipal authorities, your domestic waste collection service, store where you
purchased the Device, or the authorized service center.
Disposal of electric and electronic components (the Directive is applicable to
the EU and other European countries where separate waste disposal systems
exist). In other countries dispose batteries accordingly to local laws.
Do not destroy the battery by burning it to avoid the danger of explosion!

6
Appearance
1. Rear camera
2. Microphone
3. Micro-USB
4. Front camera
5. Speaker
6. On/Off button
7. Volume +
8. Volume -
9. Combined Micro SIM
and Micro SD card tray
10. Headphone jack

7
Technical Specifications
Display 7” touch screen 1920 × 1200
Processor Octa-Core ARM Cortex A7, 1.7 GHz (MT8392)
RAM 2GB SDRAM
Internal Storage 16 GB *
Platform Android™ 4.4
Input/Output Ports 1×micro USB 2.0, 3.5 mm audio jack,
microphone, micro SIM card
Card reader microSD (SDXC/SDHC) up to 64GB
Communications Wi-Fi (802.11 a/b/g/n), 3G (HSPA/UMTS/GSM/
EDGE), GPS, Bluetooth, FM radio
Camera Rear — 8 Megapixels,
Front — 2 Megapixels
Audio Speaker, microphone
Accelerometer Yes
Battery Li-Polymer, 4000 mAh **
Dimensions 193.2 × 107.9 × 9.3 mm
Weight 345 g
Text Formats epub, fb2, txt, doc, rtf, html, chm, tcr, pdf,
pml
Image Formats JPEG, PNG, BMP, GIF
Audio Formats MP3, WMA, AAC
Video Formats
MKV, AVI, MP4, FLV, WEBM, 3GP, MOV,
MPG, WMV, divX, Xvid, mpeg-4 SP,
mpeg-4, ASF, VC1, H264, H263, wmv 9,
MPEG-1, MPEG-2
* The actual available internal storage size may vary depending on the software
configuration of your device
** Battery life and values mentioned above might vary depending on usage mode,
connectivity and settings

8
Getting Started
CHARGING THE BATTERY
The battery of your Device is not fully charged as you unpack it, so you
need to charge it. When charging for the first time, we recommend
charging the device for 8 to 12 hours when off. Full charging will
subsequently take 2,5 to 3 hours. It’s strongly recommended to keep
the Device off during the first charge, otherwise power consumption
could be more, than charging, especially when you charge it from PC.
Follow next steps to charge the battery:
1. Make sure the Device is off. In opposite case, press On/Off button
for a few seconds and select Power Off in menu appeared. The Device
will shut down.
2. Connect your Device to power supply or computer using the mi-
croUSB cable included in package.
• Connect a USB cable to the jack of the Device:
ATTENTION! Incorrect connection of the USB cable can seriously damage the
Device. Damages of the Device, caused by incorrect connection, aren’t covered by
warranty.
• While the USB cable is connected, the Device should be near to
PC/charger.
NOTE It’s recommended to charge the battery using the charging device. In case if
you charge the battery from PC, it’s better to keep the Device off, because power
consumption could be more, than charging.
USB cable

GETTING STARTED
9
UNLOCK YOUR DEVICE
Tap and drag the lock out of the circle to one of icons to unlock your
Device.
HOME SCREEN
Notification
area
Back - return
to the previ-
ous screen
Return to
Home Screen Last opened applications Open a list of applications
and widgets
Applications
Choose Goog-
le search or
Voice search

GETTING STARTED
10
DISPLAY VIEWS
The screen orientation is changed automatically when you hold the De-
vice horizontally to vertically, and vice versa. To enable/disable screen
auto-rotation, go to Settings > Device > Display.
Landscape view
Portrait view

GETTING STARTED
11
FINGER GESTURES
Tap
Short soft touch on an item (e.g. file, application, folder or menu
item) opens it.
Press and Hold
This gesture calls context menu with available options for an
item. While you at Home Screen, it allows to move an item.
Slide
Slide means move finger across the screen vertically or
horizontally.
Drag
To drag an item, press and hold it until you reach final position.
Flick
Flicking is similar to sliding, but you need to move your finger more
rapidly. It’s used for scrolling through lists.
Pinch
In particular applications (e.g. Maps) to scale an image, you
can ‘pinch’ the screen: move to zoom out or spread to zoom
in two fingers.

GETTING STARTED
12
USING THE ON-SCREEN KEYBOARD
To access the on-screen keyboard, touch any textbox. Enter your text by
touching the keys of the on-screen keyboard.
1.Switches to symbol mode;
2.Switches between upper and lower case;
3.Voice search;
4. Field for text typing;
5. Backspace – delete a previous sign;
6. Input text;
7. Continuous press changes input languages;
8. Changes input languages.
MENUS
Most applications have two types of menu: application/section menu
and context one. Application/section menu is brought up by pressing
Menu button . Context menu is called by continuous touch on a screen
or item, depending on application.
NOTE Application/section menu is available not for all applications. In this case
nothing happens when you press the Menu button.
1
2
4
5
6
7
38

GETTING STARTED
13
ESTABLISHING WI-FI
If you skipped Wi-Fi configuration during the initial setup, you can con-
figure it later.
1. Go to Settings > Wireless & networks. Check Wi-Fi checkbox
2.To see the list of available networks open Wi-Fi section.
3.The Device automatically detects security type, and if there’s no need
to specify additional data (e.g. pre-shared key), connection would be
established.
4. Otherwise, you need to specify password and other security settings
(if required) manually.
You can read about advanced network configuration in the Wi-Fi Con-
nection chapter of the current User Manual.
INSERTING MICRO SD CARD
The Device has 16 GB of internal storage, but you can extend it by using
micro SD card.
Back view
SD card
SIM card

GETTING STARTED
14
To pull on the tray for SIM card and SD card use included clip. Insert SD
card to the tray, like it shown on a figure, and slightly push until tray
will be fixed.
ATTENTION! Before ejecting microSD card either turn the Device off or unmount
it: go to Settings > Storage settings> Unmount SD card. Otherwise the data stored
on microSD card might be damaged.
ATTENTION! If your SD card or SIM card get stuck, do not try to eject it by your-
self, and immediately call Customer Support.
MOBILE NETWORKS CONNECTION
ATTENTION! The Device utilizes some services, which don’t ask user’s permission
for Internet access (for example, synchronization). Consult with your mobile opera-
tor about traffic rates.
The Device supports GSM and/or WCDMA mobile networks connection
for Internet access.
ATTENTION! Before inserting or ejecting SIM-card turn the Device off.
Install your network operator SIM-card, as it is shown on the figure,
and turn the Device on.
In case if the card is protected with PIN-code, the Device will ask you
to enter it from on-screen keyboard. PIN-code request settings can be
changed in Settings> Security > SIM card lock > Set up SIM card lock.
In this section you can set whether request or not PIN-code when you
are unlocking the screen, also you can change the SIM-card PIN-code.
NOTE In case when Lock SIM card parameter is on, you will be asked for PIN every
time when you’re unlocking the screen.
Usually mobile network operators pre-configure connection settings
(such as APN) on a SIM-card, so the Device will connect to the network
automatically.
ATTENTION! If the Device is connected to Wi-Fi network, it will have higher prior-
ity for data transfer.

GETTING STARTED
15
If you need to change connection configuration, go to Settings > Wireless
& networks > More > Mobile networks.
•Data connection – turn mobile network connection on or off
•Data roaming – select whether use mobile network connection or
not when you are out of your mobile operator coverage, for example,
abroad
•Preferred networks
•Network mode – select the most suitable one for your mobile network
or set to auto-detect
•Access Point Name – Internet access points configuration. If you
need to set up one more point, open the section’s menu and set the
parameters provided by your mobile operator
•Network operators – select network operator to connect to. Press
Select automatically to connect to the default network.
After pressing Select manually, the Device will search for available mo-
bile networks and you will be able to select one. For example, this fea-
ture could be useful when you are in roaming zone – you will be able
to select operator with the lowest rates.
NOTE Consult your mobile network operator about roaming rates.

16
Software
MANAGE DATA
Use File Manager to operate with files, stored in internal Device memory
and external microSD card. To open File Manager, press on its icon in
the list of applications.
1. Root folder – returns to the highest level of file hierarchy;
2. Path to folder location;
3.Search – opens search textbox;
4. Create folder;
5.Select several files/folders;
6. File Manager settings.
Context menu, evoked by continuous press on element, allows moving,
copying or deleting files.
1
345 62

SOFTWARE
17
APPLICATION LAUNCHING
The application can be launched by short press on the icon on the
Homescreen or from the list of available applications. You can create
a shortcut to an application at any desktop. Scroll Home Screen to the
desktop you need, then open the application list.
Touch and hold desired application icon until the desktop appears. After
you release a finger, an icon remains on a desktop. To launch applica-
tion tap on its icon.
Button for opening lists of applications
To place a shortcut on Homescreen, press and hold
the one, selected in the list
Applications shortcuts

SOFTWARE
18
CREATING FOLDERS ON THE HOME SCREEN
Desktop icons can be grouped into folders. To create a folder, tap and
hold the icon and drag it to the icon which you want to merge with,
and then release your finger.
You can add the icons of other programs to this
folder in a similar way. To rename a folder, touch
to its name and type the new name on the ap-
peared keyboard.
To open an application, located in a folder, touch
the icon of a folder and choose the application
in the displayed list. A list of applications
in a folder
Email

SOFTWARE
19
APPLICATION REMOVING
After continuous touch on icon or widget Sign of application removing
is activated. To delete element from the home screen or a folder,
drag-and-drop it to this sign and release after it highlights in red.
LIST OF OPENED APPLICATIONS
Opened applications are displayed in the list of opened applications
(button for invoking a list is located on the right bottom side of the
screen). You can close application:
1. Invoke the list of opened applications;
2. Press and hold the application, you need to close;
3. When the dialog window appears, press Remove from list.
Applications, launched by the system automatically, can be stopped in
the Settings >Apps > Running > Stop (see more detailed information in
“Information about Apps” section of this User Manual).
Sign of application removing

SOFTWARE
20
PREINSTALLED APPLICATIONS
Browser Supports functions for comfortable web-pages
viewing
App update Keeps your apps updated to date
Calculator Simple Android calculator
Calendar Events calendar with Google synchronizing
Camera Standard Android (photo/video) camera
application
Clock Clock with alarm and screen saving function
People List of contacts
Downloads Download tool for music, documents, video
and other files
Email Email client supporting POP3, IMAP, Exchange
File Manager Standard file manager
FM Radio More than 10 000 radio stations from all over
the world
1) Button for invoking
opened applications
2) Press and hold on the
application in the list
3) Press ‘Remove
from list’
