Point Mobile PM86 User manual

V1.0, Aug 2023
Copyright © 2023 Point Mobile Co., Ltd. All rights reserved.
Point Mobile Co., Ltd. is the designer and manufacturer of mobile handheld devices.
The Point Mobile logo is a registered trademark and symbol of Point Mobile Co., Ltd.
Features and specifications are subject to change without prior notice.
PM86
Quick Start Guide

2
Device Parts
1. Receiver
2. LED indicator
3. Audio jack
4. Power button
5. Scan button (Left)
6. Microphone
7. I/O connector for cradle
8. Speaker
9. Touch screen
10. Front camera
10
1
8
3
7
6
2
4
5
9

3
Device Parts
11. Rear I/O connector
12. Hand strap hole
13. Battery release button
14. Scanner
15. Rear camera & Flashlight
16. Volume buttons
17. Scan button (Right)
18. Battery
19. USB connector
11
16
15
14
12
13
17
18
19

4
Product Standard Accessories Battery Replacement
1. Insert the battery from the bottom side (opposite side of the
battery release buttons).
2. Push the battery down until it clicks.
Confirm that the battery release buttons are completely outward.
Battery pack
Insert Battery
Remove Battery
LCD protection filmHand strap
USB type C cable
AC Plug
5V 2A power adapter
1. Hold the battery release buttons and press in.
2. While pressing the battery release buttons in, pull the battery up.
open
close
close
open

5
Supported Cards & Card Slot Cover
PM86 provides
•1 microSD card slot
•2 Nano SIM card slots –LTE SKU only
•2 SAM card slots –LTE + SAM SKU only
Remove the battery, and open the card slot cover to find card slots.
You can use the handle on the right side of the cover to open.
Handle
Card slot layout
< Notice >
Do not throw away the cover. It affects device sealing performance against
water, dust, etc.
1. Gently slide the card holder left, and swing upwards to open the
holder.
2. Put the SD card with the contacts facing down, close the holder,
and gently slide it right to lock.
Install SD Card
1 2
3 4

6
1. Gently slide the card holder up (top slot) or down (bottom slot),
and swing upwards to open the holder.
2. Put the SAM card with the contacts facing down, close the
holder, and gently slide it opposite direction to open.
Install SAM Card
1 2
3 4
< Note >
PM86 LTE + SAM SKU includes two SAM slots, on the top and bottom.
All direction to open/close the cardholders are opposite each other. The
figures indicate the top SAM slot.
Install SIM Card
1 2
3 4
1. Gently slide the card holder left, and swing upwards to open the
holder.
2. Put the SIM card with the contacts facing down, close the
holder, and gently slide it right to lock.

7
Turning on /off
Press and hold the power button on the left side of the PM86 until
SMART BEYOND RUGGED logo displays on the screen.
Turn on
When the display is on, press and hold the power button until the
power menu is shown.
Then, tap Power > Power off.
Turn off
Charging the Device
1. Assemble the AC plug, power adapter and USB cable.
2. Connect the cable to the USB connector of PM86.
3. Provide power by plugging the power adapter to the wall socket.
PM86 can also be charged with charging cradle (sold separately).
< Caution >
1. Always use an original power supply from Point Mobile. Other
chargers and cables may damage the PM86.
The device warranty does not cover any damage caused by the usage
of non-original power supplies.
2. Make sure the charger and cable is not wet.
3. Charge in temperatures from 0 ℃ to 45℃.

8
LED Indicator
2
1
No
Indicator
Status
Indication
1
Power
LED
Solid
green
Device
is fully charged
Solid
red
Charging
the device / Battery is low
Blinking
red
Charging temperature is out of
normal range
/ Battery is very low
Alternately blinking
red
&green
Cannot
recognize the battery
2
Notification
LED
Blinking
blue
Notification
existing
Red
flash
Barcode
reading failed
Blue
flash
Barcode
reading success
Scan a Barcode
Center the cross-hair aimer or red dot aimer over the barcode. You
can tilt the aimer slightly for a comfortable angle to scan.
Scanner is disabled by default, so enable the scanner from
ScanSettings first.
Check if the scanner icon is placed on the Status bar. Then,
press a scan button on the device to scan a barcode.
