Point Mobile PM260 Service manual

HANDY TERMINAL
Quick Reference Manual
PM260
Red key
Blue key
1. Open the cover
Front Back
3. Insert the battery2. MicroSD card
Using AC/DC Power Adapter
5. Charge the battery4. Attach the plug
Getting StartedGetting StartedGetting Started
(Press Blue key first)
es
S lide the lockers upwards and remove
the cover by pulling on it with your finger.
F irst, insert the battery into the battery well
with the labels facing upward.
C lose the cover from the bottom and push
down the cover until it locks properly.
B attery cover locker
F ront scan key
S ide scan key
PM260 Terminal
S tylus pen
A C/DC power adapter
A C plugs
B attery pack
H and strap
Q uick reference manual
B elt clip
L CD screen protector
H and strap
S tylus pen
B elt clip bracket
M icro SD Card is sold separately.
P lease contact your dealer.
U SB ActiveSync cable
R egulatory sleeve
E ULA sleeve
O
P
E
N
Micro SD Card is supported up to 32GB.

Scanner beam position Software
Y ou can find the shortcut icon "CICO" of the bundle
software on the desktop of this handy terminal.
H ow to perform “Item Check-in task”
When products or goods come into your place
(office, warehouse, and so on), you can input the
physical count of the goods into your Excel sheet
by scanning through the built-in “bundle software”
of your handy terminal which may reduce the
possible human error, streamlining checking-in work.
H ow to perform “Item Check-out task”
When put out products or goods from your place
(office, warehouse, and so on), you can input the
physical count of the goods into your Excel sheet
by scanning through the built-in “bundle software”
of your handy terminal which may reduce the
possible human error, streamlining checking-out work.
H ow to perform “Physical Counting”
By easily scanning your physical inventory,
you can record the inventory counts into your
Excel sheet which allows you to find differences
between Book QTY and physically stored inventory.
Plus, physical counting program guides you to tag
items’ quality state such as defective or normal
to each item, while you’re performing this job.
Every moment of scanning the physical inventory,
you can easily notice if difference exists or not by
color change of count cell.
P lease refer to the Bundle software
(Item Check-In & Out / Physical Counting)
User’s manual for more information on how to use.
How to scanGetting Started How to scan Date and Time
About Bundle S/W (CICO)
Service and Support
Reference Documentation
I n case of system failure,
press reset button with
stylus pen.
H T-K10 will be restarted when
button is released.
S uspend mode works like
the device is turned off.
P ress Blue key + windows key
to suspend and press windows
key one more time to wake up
the device.
T ouch the scan start button
on the screen or press and
hold one of the scan keys
on device to start scanning.
Demos
Scan Demo
S elect your time zone.
Select automatically adjust
clock for daylight saving
option if needed.
N ever apply strong pressure to the touchscreen
or subject it to strong impact. If the LCD panel
glass breaks, do not touch the liquid inside -
it can cause skin inflammation.
U se only the AC/DC power adapter provided by
us or authorized dealers. The use of any other
power adapter can cause electrical problems,
fire and/or electric shock.
U nauthorized modifications and/or repairs of
HT-K10 will void the factory warranty. please
contact your dealer for support.
D epending on bar code size, position of the device
should be closer when scanning small bar code,
or keep its distance when the bar code is larger.
A im the scanning beam at the center of the
bar code so the beam is perpendicular to the
bar code.
P lease contact your dealer or distributor for
services and authorised repair center for
technical services.
F or futher information regarding the terminal
accessories, safety and regulatory, please
refer to User manual.
Suspend and restart
S ingle slot docking cradle
Optional Accessories
S ingle slot ethernet cradle
S tandard battery (2200mAh)
battery (3300mAh)
L i-ion battery pack must be recycled or disposed
properly.
Li-ion batteries are subject to disposal
and recycling regulations that vary by country
and region.
Follow your applicable regulations before
disposing of any battery.
Do not put in fire, apply heat to, disassemble
or short circuit.
T his device is rated at IP65 standard for water
and dust protection but we do not recommend
to use it in extremely rainy, dusty, and/or windy
conditions. If environmental conditions exceed
the standards for IP65, the industrial seal may
fail, voiding the factory warranty.
A lways keep the plug and outlet clean.
Prevent them from accumulating dust and dirt.
This could cause a fire and give you an electric
shock due to the heat released by electric
leakage.
M13-000765-00(Rev.A)
2012-12
