Pokini Tab K10 User manual

Tab K10
Quick Start Guide
English

2
English
Related Information ...................................................................................................................................
Conventions ....................................................................................................................................................
Safety Guidelines ...............................................................................................................................
Intended Use
Maintenance and Operation Overview
Safety
Electrical Hazards
Environmental
Radio Transmissions
Cleaning and Servicing
Regulatory and Certification
Lithium Battery Safety Statement
Introduction ...........................................................................................................................................
About This Guide
Unpacking the Device
Technical Specifications
Tab K10 Configuration Options
Parts List
Identifying the Device
Identifying the Digitizer
Dimensions
Touch Screen Features
Getting Started .....................................................................................................................................
First Time Use
Charging the Battery
Powering the Device On and Off
Installing the Micro SIM Card
Removing the Micro SIM Card
Installing the MicroSD Card
Removing the MicroSD Card
Using the Digitizer
Removing the Protective Film from the Display
Table of Contents
4
4
4
9
20

3
Operation ................................................................................................................................................
Opening the I/O Compartment Cover
Closing the I/O Compartment Cover
Connecting to External Cabling
Handstrap, Carrying Handle and Shoulder Strap
Installing the Standard Battery
Removing the Standard Battery
Connecting to a Wireless Network
Using the BIOS Setup Utility ....................................................................................................
When to Use the BIOS Setup Utility
Accessing the BIOS Setup Utility
Installation an Operating System
BIOS Passwords
EC and BIOS
Using the DashON Utility .............................................................................................................
Overview
Troubleshooting ...................................................................................................................................
Troubleshoot the Wi-Fi Connection
Troubleshoot Operating the Computer
Call Product Support
Maintenance ...........................................................................................................................................
Cleaning the Device
Returning the Device
Contacting Pokini
24
32
40
41
44

4
English
About This Manual
The Tab K10 User’s Manual provides instruction for qualified personnel to follow when
setting up a new Tab K10 device.
This document is intended for use by qualified personnel to compliment the training and
expertise, not to replace it.
Related Information
Current information and manuals are available for download at the following website:
http://www.pokini.de
Conventions
Bolded or underlined text is used to emphasize the designated information.
A Note is used to provide additional information for the device or settings.
A Caution is used to warn against potential hazards or to caution against
unsafe practices.
A Warning is used to identify immediate hazards for property damage,
injury or death
!
!
Basic Safety Guidelines
The following safety guidelines are intended to help protect the user from injury and
prevent damage to the hardware.
■ Do not place anything on the AC adapters power cable and make sure the cable is
not located where it can be tripped over or stepped on.
■ Do not cover the AC adaptor as it reduces the cooling.
■ Do not use the AC adapter while it is inside the carrying case.
■ Use only the AC adapter, power cord, and batteries that are approved for use with the
device. Use of another type of battery or AC adapter may cause risk of fire or explosion.
■ If you use an extension cable with the AC adapter, ensure that the total ampere
rating of all products plugged in to the extension cable does not exceed the ampere
rating of the extension cable.

5
■ If the device is moved between environments with very different temperature and/
or humidity ranges, condensation may form on or within the device. Avoid damaging
the device by allowing sufficient time for the moisture to evaporate before using the
device.
■ When disconnecting cables, pull on the connector or on its strain relief loop, not on
the cable itself. When pulling out or plugging in the connector, keep it evenly aligned
to prevent bending the connector pins.
Intended Use
The Tab K10 rugged tablet is equipped with multi-functional terminals for stationary
and mobile applications in industrial environments such as logistics, warehousing, fleet
management, manufacturing and the automotive industry.
Read the safety guidelines thoroughly before starting any servicing on the device. Read
the guidelines before powering up the device, and keep this document for later use.
The operator is solely responsible for any damage resulting from unauthorized modifica-
tions to the device.
Unintended Application Use
The device is not designed for use in life-support systems or critical safety/security
systems where system malfunction can lead to the direct or indirect endangerment of
human life. The operator is fully responsible for using the device in these situations.
Maintenance and Operation Overview
The Tab K10 is designed and manufactured according to strict controls and following
the stated safety regulations. The following list identifies incorrect operating uses of the
Tab K10. Incorrect use of the Tab K10 can lead to hardware damage, safety issues and
possible risk to personnel health:
■ The Tab K10 is under operation by untrained personnel;
■ The Tab K10 is not maintained as recommended;
■ The Tab K10 is not used as intended.
Safety
To prevent injury and damage, read the following safety guidelines prior to operating
the device. The manufacturer assumes no liability for any and all damages arising from
misuse or noncompliance with these guidelines.

6
English
Electrical Hazards
Cleaning/Servicing: Power Off the Tab K10
■ Disconnect the Tab K0 from power before cleaning or servicing it.
Power Adapter
Contact an authorized service personnel for repairs to the power pack. In the event of
a blown fuse after replacing the fuse, contact an authorized service personnel to avoid
electrical shock.
Use only Supplied Power Cables
Pokini power cables meet industrial requirements for low-temperature flexibility, UV
resistance, and oil resistance. Use only supplied power cables from Pokini.
If other power cables are used, the following may apply:
■ The operator is solely responsible for the resulting damage;
■ All Pokini warranties are void.
Environmental Hazards
Do not use the Tab K10 in locations near/with flammable gases or vapor. The use of elec-
trical equipment in explosive environments can be dangerous.
■ Turn off the device when near a gas station, fuel depot, chemical plant or a place
where blasting operations take place.
Environmental
Ambient Temperature
The Tab K10 operates on the basis of a passive cooling concept which internal waste
heat is released via the housing surface and requires fresh airflow in the environment.
■ Operating the Tab K10 with no fresh cooling air may cause overheating and damage
to the device.
■ The operating environment should not be enclosed to prevent the cool air being
heated by the heat waste from the device.
Connecting and Disconnecting External Devices
To prevent the considerable damage, the Tab K10 and the external device should be
disconnected from power when connecting/disconnecting excluding USB devices.
Only Use Authorized Accessories
Only use the supplied cables, power packs and other accessories that have been tested
and approved by Pokini. Contact your local distributor for further information.

7
Radio Transmissions
Permitted Transmission Power
Follow the national regulations for the maximum permitted transmission power. The
operator is solely responsible for this type of operation.
Radio Frequency Limited Locations
Considering the radio frequency limitation in hospitals and aircraft, the Tab K10 can only
be installed with permission.
Industrial computers may affect the function of implanted medical devices such as pace-
makers and may cause malfunction.
Cleaning and Servicing
■ Disconnect the Tab K10 from power before cleaning or servicing.
■ Never clean the Tab K10 with compressed air, a pressure washer or a vacuum cleaner.
■ If necessary, clean the housing of the Tab K10 with a damp cloth.
■ Clean the touch-screen with a nonabrasive cloth.
Regulatory and Certification
FCC
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference when the equipment is operated in a
commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful inter-
ference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
However, there is no guarantee that interference will not occur in a particular installa-
tion. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
■ Reorient or relocate the receiving antenna.
■ Increase the separation between the equipment and receiver.
■ Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.

8
English
■ Consult the dealer or an experienced radio / TV technician for help.
▪ Any changes or modifications not expressly approved by the grantee of this
device could void the user’s authority to operate the equipment.
▪ This device is operation in 5.15 – 5.25GHz frequency range, then restricted in
indoor use only, Outdoor operations in the 5.15 – 5.25GHz is prohibit.
▪ This device is slave equipment; the device is not radar detection and not
ad-hoc operation in the DFS band.
Labeling Requirements
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
RF Exposure Information (SAR)
This device meets the government¡s requirements for exposure to radio waves. This
device is designed and manufactured not to exceed the emission limits for exposure to
radio frequency (RF) energy set by the Federal Communications Commission of the U.S.
Government.
The exposure standard employs a unit of measurement known as the Specific Absorp-
tion Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted
using standard operating positions accepted by the FCC with the EUT transmitting at the
specified power level in different channels.
The highest SAR value for the device as reported to the FCC is 0.55 W/kg when placed
next to the body.
CE Marking
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. Please
contact your local representative for ordering information.
This product has passed the CE test for environmental specifications. Test conditions for
passing included the equipment being operated within an industrial enclosure. In order
to protect the product from being damaged by ESD (Electrostatic Discharge) and EMI
leakage, we strongly recommend the use of CE-compliant industrial enclosure products.
!

9
R&TTE
This device complies with the essential requirements of the R&TTE Directive 1999/5/EC.
This device is classified as class 2 in Article 1(2) of Decision 2000/299/EC due to its capa-
bility of operating WLAN in the band 5.15 to 5.35 GHz.
CB
This device complies with the IEC 60950-1:2005+A1.
Lithium Battery Safety Statement
Lithium battery inside. Danger of explosion if battery is incorrectly replaced.
Replace only with same or equivalent type recommended by battery manufacturer.
!
Introduction
The Tab K10 is a rugged device equipped with 802.11, Bluetooth and GNSS for wireless
data communications.
The Tab K10 is a rugged 10.1” tablet computer capable of 1920 x 1200 resolution. The Tab
K10 supports the following operating systems:
■ Windows® 10 IoT Enterprise CBB
About This Guide
The Tab K10 User Manual provides instruction for qualified personnel to use as a guide
for setup of the device. This document is not intended to replace the training and exper-
tise of the end-user.
Unpacking the Device
Before you begin the installation or configuration process make sure to inspect all
components and accessories. Contact your representative if there are any missing or
damaged items.

10
English
Technical Specifications
Item Description
Display 10.1-inch LED Backlight, 1920 (W) x 1200 (H) WUXGA
Touch screen 10-point capacitive touch screen with optional digitizer
Brightness 1000 nits (before touch)
CPU Intel Core i5-7300U 2.6 GHz
Operating System (Optional) Windows® 10 IoT Enterprise CBB
RAM DDR4@2400 MT/s 8 GB RAM
Storage M.2 SSD 128 GB (optional: 256 GB)
Battery - Standard hot swappable battery: 10.8V, 4500mAh, Li-polymer
- Extended hot swappable battery: 10.8V, 9000mAh, Li-polymer (optional)
Power Supply AC 100V ~ 240V, 50~60Hz input; [email protected], 65W
Dimensions (W x H x L) 280 mm (11”) x 23 mm (0.9”) x 195 mm (7.7”)
Weight 1.36 kg (3 lbs)
Wireless
WLAN Wi-Fi IEEE 802.11 a/b/g/n/ac
Bluetooth Bluetooth V4.2
WWAN (Optional) Option 4G LTE
Sensor
Sensor Gyroscope, G Sensor, E-compass, Light Sensor
I/O
Docking Connector 12-pin
DC-IN Jack x1
Micro SIM Card Slot x1
Audio Jack x1; headphone / microphone combo
USB 3.01 x2; type A x1, type C x1

11
Item Description
RS-232 x1
Micro HDMI x1
Ethernet x1
Security
TPM TPM 1.2
BIOS On/Off for I/Os YES
Data Collection
Camera - Front: 2.0 Mega-Pixels camera
- Rear: 8.0 Mega-Pixels camera with LED auxiliary light and Auto-focus
GNSS YES
NFC Optional
Barcode Reader Optional
Smart Card Reader Optional
Rugged Specifications
Drop 153 cm (5 feet), 26 drops on plywood
MIL-STD 810G
- Vibration (MIL-STD-810G Method 514.6 Category 4, Fig 514.6C-1,
Fig 514.6C-2, Fig 514.6C-3)
- Drop (MIL-STD-810G Method 516.6 Procedure IV)
- Mechanical shock (MIL-STD-810G Method 516.6 Procedure I, Procedure V)
- Operation and storage temperature (MIL-STD-810G Method 501.5 and 502.5)
- Humidity MIL-STD-810G Method 507.5 Humidity Procedure II
Aggravated Cycles (Fig 507.5-7)
IP rating IP65
Operating Temperature Range -20°C (-4°F) to 60°C (140°F)
Storage Temperature Range -30°C (-22°F) to 70°C (158°F)
Humidity 5-95% without condensation

12
English
Tab K10 Configuration Options
The following options are available for the K10:
■ NFC module
■ Barcode reader
■ Smart card reader
Parts List
The Tab K10 is shipped with the following items. All other accessories are sold and or-
dered separately. For help, contact your local Pokini sales representative.
■ High capacity battery
■ 4G LTE
■ Digitizer
Power Adapter
Stylus or Digitizer
Tab K10

13
Identifying the Device
Overview
1Left view See “Side View” for further information.
2Front view See “Front View” for further information.
3Rear view See “Rear View” for further information.
4Right view See “Side View” for further information.
5Rubber bumpers
Easy to grip rubber bumpers enable the rugged tablet
to withstand shocks and drop for use in demanding
environments.
6Bottom view See “Bottom View” for further information.

14
English
Product Overview
Front View
1 2
3
4
5
6
78910
11
12
13
1Front camera 2.0 Mega-Pixels camera.
2Touch screen 5-point capacitive touch.
3Barcode trigger If barcode scanner is installed, press to scan.
4Battery LED Display battery status
5Wi-Fi LED The Wi-Fi LED lights to indicate Wi-Fi is enabled.
6FN LED The FN LED lights when the function switch on.
7Home key Windows® home key.
8Volume + Volume increase.

15
9Volume - Volume decrease.
10 Power key Turns the Tab K10 on or off.
11 Power LED The power LED lights when the device is on.
12 F2 key Programmable function key.
13 F1 key Programmable function key.
14 FN key Programmable function key.
LED Status
Item Status Description
Green: On Power on
Off Power off
Battery
Green: On Fully charged
Amber: On Charging
Amber: Blinking Low power < 15%
Off Not charging / no battery
FN Blue: On FN function switch on
Blue: Off FN function switch off
Wi-Fi Blue: On Wi-Fi on
Blue: Off Wi-Fi off

16
English
Bottom View 1
2 3
1Docking connector 12 pin connector for docking onto a station.
2Kensington lock Lock the Tab K10 to a stationary object for security.
3Pass-through Dual pass-through for WLAN, GNSS and WWAN.
Left View
1
3
2
4
567
1Micro HDMI Connect HDMI devices to the Tab K10.
2USB 3.1 Type C Connect USB devices to the Tab K10.
3
Left I/O
compartment
cover
Open to access the left I/O port.
4Tether hole Digitizer or stylus can be tethered to it.
5USB 3.1 Connect USB devices to the Tab K10.
6Audio jack Connect a 3.5 mm jack for a headphone or external speakers.
7Ethernet Connect the Tab K10 to an Ethernet (RJ-45) cable.

17
Left View
1
3
2
4
1DC-IN jack Insert power connector to charge battery.
2RS-232 Connect the Tab K10 to a serial device.
3DC-IN cover Open to access the DC-IN jack.
4Right I/O compartment cover Open to access the right I/O port.

18
English
Rear View
1 2
4
67
5
1Battery To install a battery, an external battery is optional.
2Rear camera 5.0 Mega-Pixels camera with LED auxiliary light.
3Barcode reader For installing a barcode reader. (Optional)
4Fan Embedded fan for cooling.
5Securing holes Secure the bumpers and the D-rings for the handstrap
and shoulder strap.
6Expansion bay Remove the cover to find the expansion accessory
connector.
7Stylus holder Place stylus here.
3

19
Identifying the Digitizer (Optional)
You can use the optional digitizer to control your Tab K10 as with a mouse or keyboard.
Tip
Click Button
Dimensions
The following image lists the device dimensions without add-ons (mm/inches).
280 / 11
195 / 7.7
23 / 0.9
Touch Screen Features
Always use the point of the digitizer for clicking or making strokes on the touch
screen. Never use an actual pen, pencil, or sharp/abrasive object on the touch
screen.
The digitizer is used as if it were a pen or pencil. Touch the screen with the tip of the
digitizer then remove the digitizer from the screen.
After each use, replace the digitizer in the digitizer holder for proper care and to
preserve the life of the digitizer.
Using a digitizer is similar to moving the mouse pointer then left-clicking icons on a
desktop computer screen.
!

20
English
The following actions are available through the use of the digitizer:
■ Open applications
■ Choose commands in menu
■ Select options in dialog box or drop-down menu
■ Drag the scroll bar
■ Drag across the text to select content
■ Place the cursor in a text box before typing
A right click is generated by tapping the mouse icon in the system tray. After tapping,
the mouse icon highlights the right button of the icon in red. The next touch screen tap
is treated as a right click. The mouse icon returns to the left button highlighted in red so
subsequent taps are treated as left clicks.
A digitizer replacement kit is available.
To prevent damage or malfunction, always dry the touch screen when wet.
Getting Started
This section provides an outline of the steps necessary to setup a new Tab K10. A
detailed guide follows the listed items, see as follows.
For additional technical assistance, contact your Pokini representative.
It is recommended to installing or remove accessories on a clean, well-lit work
surface. To protect yourself and the device from electrostatic discharge, wear
anti- static wrist straps or place the device on an anti-static mat.
First Time Use
Tab K10 is under “Battery Ship Mode” and will not power on to preserve the battery and
prevent power loss. To enable “Regular Mode” and activate the battery, please connect
the power adapter to power on.
