Polargos EASY WAY201 User manual

DRIVE UNIT FOR SWING GATES
EASY WAY 201

2
GB
V12x V2 2x
L+30 L
I!! II
4 SETS
M8 x 85 mm*
H
A
2x B
2x
C
2x
D
2x
M8 x 40 mm
E
M6 x 40 mm
I
P
1x L
1x
G
1x
F
1x
2 SETS
8 SETS
*this lock screw is designed for gates
mounted on steel posts 70 x 70 mm;
if the gate is to be mounted on steel
posts 100 x 100 mm, 8 sets of lock sc-
rews M8 x 120 mm should be obtained.
Depending on the model purchased, a suitable connector should be added to the set.

3
GB
TABLE OF CONTENTS
Introduction.........................................................................4
Safety principles .................................................................5
Product description ............................................................6
Preparation for assembly....................................................8
Installation:
1. Automatic system installation .......................................12
2. Electrical connections...................................................17
3. Parameter setting..........................................................20
Operational use ................................................................26
Troubleshooting................................................................28
Accessories.......................................................................29
In the case of a solar energy supply ................................35

4
GB
Introduction
POLARGOS is a Polish manufacturer of residential and industrial fence systems as well as other steel
products that has been operating on the market since 1994.
Due to their many years’ experience, as well as their production and marketing facilities, POLARGOS
manufactures products for a large number of domestic and foreign customers.
Our aim is to supply products that meet the highest standards of workmanship and fulll customers’
expectations as regards aesthetics and the dominant trends in the fence market.
Thank you for placing your condence by choosing EASY WAY 201.
Please read this instruction book thoroughly before installation.
EASY WAY 201 is manufactured by Somfy for POLARGOS.

5
GB
Safety principles
Please read all the instructions in this service manual thoroughly before installation of the product. It is necessary
to follow the instructions precisely and retain this document for the whole useful life of the product.
Failure to comply with all of the recommendations concerning installation can lead to severe injury or material
damage. POLARGOS shall not bear responsibility in such cases.
This device is not designed to be used by people (including children) with limited physical, sensory or mental
abilities, or by people without any experience or knowledge unless under the supervision of the person respon-
sible for their safety or using the instructions provided as regards operation of the device. Children are not al-
lowed to play with xed control devices. Remote control transmitters must be kept out of the reach of children.
When using a switch without interlock***, check to make sure that any other people are at an appropriate dis-
tance from the gate.
Check the installation frequently to detect any abnormalities connected with the gate balance or specic signs of
wear. Do not use the drive unit if it needs to be repaired or adjusted.
Disconnect the power supply from the device before cleaning or any other maintenance work if it is controlled
automatically.
Before installation of the drive unit, check if the driven part is in good technical condition, properly balanced and
if it opens and closes well.
Do not pass between the moving part and close xed elements in view of the danger connected with the move-
ment of the driven parts during opening (crushing, cropping, jamming).
Observe the gate during its movement.
All switches without interlock*** must be in a position from where the driven part is directly visible but also at a
suitable distance from moving elements. The switches must be installed at a height of at least 1.5 m; they cannot
be generally accessible with the exception of switches requiring the use of a key.
When the gate is open completely, keep a distance of 500 mm clear behind each leaf.
After installation is completed, check the proper adjustment of the mechanism and proper operation of the pro-
tection system and any devices used to switch off the system manually.
Do not throw away unwanted devices or expired batteries together with normal household waste.
Householders are obliged to transport all unwanted electronic and electrical equipment to a special
waste collection area for their disposal and recycling.
POLARGOS hereby declares that this product conforms to the basic requirements and other relevant regula-
tions of the Directive 1999/5/CE. The Declaration of Conformity is available at www.polargos.eu. This product
is authorised for use in the European Union and Switzerland.
*** example: intercom, key switch, code panel, etc.

6
GB
Product description
This product is designed for gates used at residential properties (description below).
Technical data
Type EASY WAY 201
Supply voltage 230 V AC / Solar system
Drive type 24 V DC
Driving power 40 W
Maximum energy consumption
(including gate zone lighting) 600 W
Energy consumption in stand by mode 4,5 W
Average number of working cycles daily 20 cycles daily
Opening time* 16 s up to 90°
Automatic obstacle detection According to EN 12 453 (Attachment A)
Working temperature Between -20°C and +60°C
Thermal shield Yes
Protection level IP 55 for electronic components
IP 44 for drives
Built-in radio wave receiver Yes
Remote controls:
•Radio frequency 433,42 MHz
•Range of operational use 30 m
•Number of memory settings 16
Possible connections:
•Orange light output Flashing, 24 V, 10 W
•Zone lighting output, supplied terminals Max 500 W (at 230 V AC)
Max 24 V – 25 W (for solar power system)
•Accessory supply output 24 V DC / 200 mA
•Emergency battery input Yes (only for 230 V)
•Photocell input Yes
•Control input of dry contact type Yes
•Built in antenna Yes
* Opening time may vary depending on gate parameters.

7
GB
Product description
Leaf dimensions and maximum weight Maximum opening angle
(for standard hinges)
EASY WAY 201
P200 kg
H2,00 m
L2,00 m
Width of each leaf should be
between 1 m and ‘L’.
Maximum opening angle
(for hinges fastened to the post side)
Dimensions (in mm)
Opening limiter
The motor stops automatically using its internal limiter.
To stop the gate earlier, x a limiter (not included in the delivery) on the ground to stop
the leaves.

8
GB
Crossbar
Fastening holder
Metallic post
Preparation for assembly
Checkpoints before installation
Gate inspection
The gate is in good technical condition: it opens and closes without use of force.
The gate remains in a level position during the whole movement cycle.
It opens inwards to the garden.
Gate types – only with frames made of metal
(Subject to observance of the dimensions specied on page 7).
Inspection of posts
The posts must be at least 70 mm wide. Otherwise, reconstruction may appear necessary to
ensure proper corner embedment and fastening.

9
GB
6,57,510,5
13
10
Preparation for assembly
Necessary tools

10
GB
231
Crossbar
Electronic
module
Junction box
(not included in the delivery)
(cable 2 x 1 mm
2
between drives;
cable 2 x 0.75 mm
2
between photocells)
23
Flexible shield ICT
Power supply connection: (3 x 1.5 mm
2
) Connection of 24 V between two drive units: (2 x 1 mm
2
)
1. 2.
Preparation for assembly
Preliminary wiring system
To install the gate drive, proceed as follows:
 ● Lay down a power supply of 230 V to one of the posts and as close to the drive unit as possible.
 ● Connect the post together using a cable 2 x 1 mm2 (not included in the delivery).
Provide a shield Orange ICT Ø 25 mm for cables located underground.
If cables cannot be led underground between the posts, use a cable bush that can withstand the
weight of vehicles.
Mains supply
To ensure operation of the gate opening mechanism,
connect a power supply of 230 V – 50 Hz to it.
The electrical supply cable must be:
●Designated for the gate opening mechanism only.
Protected: - by means of a fuse or a circuit breaker 10 A,
- by means of a differential-current switch (30 mA).
●Installed in accordance with the safety standards concerning wiring systems and
effective in the country of use.
Multipole disconnection of the power supply is to be provided:
●using a supply cable with a plug
●or by means of a switch where a distance between contacts is at least 3 mm for
each pole (according to EN 60335-1).
It is recommended to install a lightning arrester (maximum residual voltage 2 kV).

11
GB
POST 100x100 POST 100x100
POST 70x70 POST 70x70
30 30
30 30
P
P
L
L
II
I
8 SETS
M8 x 120 mm
H
8 SETS
M8 x 85 mm
H
Preparation for assembly
Preparation of connectors
In case I use the lock screws M8 x 85 mm included in the delivery.
In case II where the metallic posts have dimensions 100 x 100 mm,
provide 8 sets of lock screws M8 x 120 mm.

12
GB
A
P
B
V1
V2
I!
!II
Mandrel
advanced
ultimately
POST 100x100
PP
POST 70x70
30
30
III
!
1Automatic system installation
Preparation of the gate
1 Level the gate leaves.
2Set position of the automatic system.
3 Apply the prepared set to the previously leveled and closed gate.
The automatic system cannot rub against the gate ttings.

13
GB
E
V1
Fix to the two selected
bean-shaped holes
holes in the gate
prepared for bean-shaped holes
V1
1Automatic system installation
4Hold the connectors P and L using a clamp.
Apply the automatic system to the gate
and see which holes in the gate crossbar
line up with the bean-shaped holes in the
connector V1 (use two selected
bean-shaped holes).
5Attach the connector to the gate with screws.
Do not tighten all the way. Some adjustment of the connector by gentle movement
should be possible.

14
GB
P
H
1Automatic system installation
6Next, attach the connector to the post (with the gate closed).
The post must be drilled with a drill bit 10.5 .
7Screw the connector to the post.
10,5

15
GB
A
B
V1
Choose one hole (of three)
that does not interfere with
a rail and drill the gate
crossbar M6 x 40 mm
I
1Automatic system installation
8Put the automatic system onto the suitably attached connectors.
9Check the position of the connector on the gate once again and adjust it if necessary.
10 Remove the automatic system.
Choose one hole in the connector that does not interfere with a rail.
In its position, drill the gate crossbar with a drill 6.5 . Then ream the hole with
a drill 7.5 from the street side.
Fit the locking screw M6 x 40 mm.
7,5
6,5

16
GB
C
D
1Automatic system installation
Assembly of the yoke fastening the leaf V1 or V2
11 Fasten the unlocking element Don the yoke fastening the leaf V1 or V2
using the screw C.
To use the unlocking element properly, follow the assembly direction as shown in
the diagram. Do not mount the screw from below.
12 Fix the yoke fastening the leaf V1 or V2 on the driving mandrel. Attach the unlocking
element D to the drive spindle to lock the mandrel.
13 Repeat step 1 - 12 for the second gate leaf.

17
GB
126
70
2Electrical connections
Stages:
●Location of the electrical box on the post.
●  Fastening of the electrical box on the post.
● Connection of the two servomotors.
●Connection of the antenna.
●Connection to the mains or solar system.
Location of the electric box on the post.
The box should be mounted on the same side as the source of power supply.
Fixing the electrical box on the post.
1. Place the box at the post (preferably over
one meter above the ground) and use the
template to drill installation holes.
2. Put the electronic system in the box. Press
it slightly for proper location. Fix the system
using the mounting screws included in the
delivery kit.
The box shall be mounted with the gland facing downward. The cables will be introduced from below
(as shown in the picture).

18
GB
blue cable*
brown cable*
blue cable*
brown cable*
M1
M2
2Electric connections
Connection of two servomotors.
The servomotors must be connected to the electrical box
before the box is connected to the mains.
Servomotor M1 must be mounted on the post of the leaf that opens rst and closes last.
M2 M1
The servomotor M1 moves the right leaf that opens
as the rst one and closes as the last one
Cables of servomotors:
Servomotor M1 must be always connected to terminals 11 and 12.
Servomotor M2 must be always connected to terminals 13 and 14.
* The colours of cables used may vary from these shown in the manual.
Please take this into account during installation.

19
GB
ON/OFF
AUTO
PROG
ON/OFF
AUTO
PROG
2Electric connections
Connection of the antenna.
To ensure optimum operation, it is recommended
to introduce the antenna cable through
a cable bush.
Never cut the antenna cable.
Connection to the mains or solar system
In the case of supply from a solar system, see page 35.
For safety reasons, these operations must be carried out
with the power supply disconnected.
1. Insert the cable into the gland.
2. Connect the earth wire.
The earth wire (green-yellow) will be
needed for some accessories
(lighting 230 V Class I).
3. Connect the live and the neutral.
Check if the wires are locked properly by
pulling them.
It is necessary to always follow the rules
regarding cable colours without variation.
Blue wire Neutral
Red-brown-black wire Live
Green-yellow wire Earth
4. Clamp the gland. Check if the wire is locked properly by pulling it.

20
GB
3Parameter setting
Stages:
● Explanation of symbols.
●Programming the remote control.
●Leaf path teaching.
●Automatic mode adjustment.
● Switchover from automatic mode to sequential mode.
● Approval of settings.
Explanation of symbols.
Long pressing
above 0.5 s
Indicator is ashing
Short pressing
below 0.5 s
Indicator is lit
Programming of remote controls.
Before the system parameters are entered, check if the indicators ON/OFF and PROG are lit and the
indicator DANGER is unlit. Carry out the following operations:
Operation of remote controls
The drive unit can be controlled by means of one or several remote controls.
The following operations must be repeated for each remote control to be programmed.
Two operating modes are available for the drive unit:
9Complete opening only
Complete opening of 2 leaves by short or
long pressing of the remotecontrol push-button.
9Opening for pedestrian entry or
complete opening
Opening of one leaf only by short pressing of the
remote control push-button to allow pedestrian
entry.
Complete opening of 2 leaves by longer
pressing of the remote control push-button.
