Polaris Alpha iQ+ User manual

Owner’s Manual
Manuel du propriétaire
El manual del propietario
Robotic Pool Cleaner
Models: ALPHATM iQ+, ALPHA iQ
VRXTM iQ+, VRX iQ
PHENOMTM iQ+
TYPE EC27--
WARNING
WARNING – For anything other than the routine cleaning and maintenance described in this guide, this product must be serviced by a qualified professional with sufficient experience
in pool equipment installation and maintenance so that all of the instructions in the product’s complete installation and operations manual can be followed exactly. All safety
instructions in the complete manual must be followed explicitly in order to prevent injury hazards. Improper installation and/or operation may void the warranty. Never turn the cleaner
on unless it is fully submerged in the water. Doing so may void the warranty and may cause severe damage to the cleaner motors.

Page 2
ENGLISH Polaris®Robotic Pool Cleaner | Owner’s Manual
FCC Statement
This device complies with Part 15 of the FCC Rules and IC license-exempt RSS standard. Operation is
subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception which can be
determined by turning the equipment off and on, the user is encouraged to try to correct interference by one
or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Any changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the
equipment.
NOTE: This device complies with FCC and IC RF radiation exposure limits set forth for general population. This
device must be installed to provide a separation distance of at least 20 cm from all persons and must not be
co-located or operating in conjunction with any other antenna or transmitter.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type
and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type and its gain should be so chosen that the equivalent
isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
THANK YOU FOR PURCHASING THE POLARIS CLEANER.
YOUR POLARIS ROBOTIC CLEANER HAS BEEN DESIGNED AND MANUFACTURED TO BE EASILY INSTALLED AND TO PROVIDE LOW
MAINTENANCE OPERATION. PRIOR TO INSTALLING YOUR NEW POLARIS CLEANER, PLEASE DO THE FOLLOWING:
1) Complete and return the warranty registration card.
2) Record your purchase information on the spaces provided below.
3) Attach your invoice (or a copy) to this page.
Taking these steps will help ensure prompt warranty service, should it be required. If service is required, please contact your original dealer. If
the original dealer does not perform warranty service, please visit polarispool.com to locate an independent service company near you. If you are
unable to locate a service company, please call our Technical Support department at 1.800.822.7933.
RECORD YOUR POLARIS CLEANER DATA HERE:
Date of Purchase Purchased From Serial Number:
(located on robot-head)
City State/Province Zip/Postal Code

Page 3
Polaris®Robotic Pool Cleaner | Owner’s Manual ENGLISH
Table of Contents
Section 1. Important Safety Instructions.........4
Section 2. Cleaner Specifications ....................5
Section 3. Getting Started.................................5
3.1 Contents.........................................................5
3.2 Connect to a Power Source...........................5
Section 4. General Cleaner Operation .............7
4.1 Install and Submerge the Cleaner..................7
4.2 Using the Control Box....................................8
4.3 Start / Stop Cleaning and
Adjust Cleaning Time .....................................9
4.4 Lift System ...................................................10
Section 5. Installing iAquaLink®.....................10
5.1 Download the App .......................................10
5.2 Sign Up and Log In ......................................10
5.3 Add to Mobile App System ..........................11
Section 6. iAquaLink®Control ........................11
6.1 iAquaLink Control Home Screen..................11
6.2 Start / Stop Cleaning and
Adjust Cleaning Time ...................................12
6.3 Set Cleaning Mode.......................................12
6.4 Remote Control............................................12
6.5 Lift System ...................................................12
6.6 Program or Cancel Cleaning Schedules
(not available on all models).........................13
6.7 Temperature Display
(not available on all models).........................13
6.8 LED Lights....................................................13
6.9 In-App Error Messages
and Troubleshooting.....................................13
6.10 System Settings ...........................................13
Section 7. Maintenance...................................14
7.1 Cord Tangling ...............................................14
7.2 Clean the Filter Canister...............................15
7.3 Store the Cleaner When Not in Use .............16
7.4 Replacing Worn Parts ..................................16
7.5 Spare Parts...................................................19
Section 8. Troubleshooting .............................20
8.1 Error Codes..................................................20
8.2 General Troubleshooting ..............................21
8.3 Dismissing an Error Code ............................22
8.4 iAquaLink Troubleshooting...........................22

Page 4
ENGLISH Polaris®Robotic Pool Cleaner | Owner’s Manual
Section 1. Important Safety Instructions
READ AND FOLLOW ALL INSTRUCTIONS
Please read through the entire manual before installing your new robotic pool cleaner. The cleaner must be
installed and operated as specified.
WARNING
Failure to comply with the following warnings can result in permanent injury, electrocution or death.
PREVENT ELECTRICAL SHOCK
To reduce risk of electrical shock:
• Connect unit to receptacle protected by a ground fault circuit interrupter (GFCI). Such a GFCI receptacle should be provided by a qualified
installer and should be tested on a routine basis. To test the GFCI, push the test button. The GFCI should interrupt power. Push the reset
button. Powershould be restored. If the GFCI fails to operate in this manner, the GFCI is defective. If the GFCI interrupts power to the pump
without the test button being pushed, a ground current is flowing, indicating the possibility of an electric shock. Do not use this product.
Disconnect the cleaner and have the problem corrected by a qualified service representative before using.
• Per the United States National Electrical Code® (NEC®), keep the control box at least five (5) feet from the edge of the (pool/spa) water. In
Canada, the Canadian Electrical Code (CEC) requires a minimum distance of 3 m (10 ft) to be maintained between the pool edge and the
control box. Neversubmerge the control box.
• Do not enter pool while the cleaner is in water.
• Do not bury cord. Locate cord so as to prevent it from being damaged by lawn mowers, hedge trimmers and other equipment.
• To reduce the risk of electrical shock, do not use the robotic cleaner or control box if the cord is worn or damaged. Contact Zodiac Pool
SystemsLLC. Technical Support immediately for proper servicing and replacement of the damaged cord.
• Double insulation—For continued protection against possible electric shock, use only identical replacement parts when servicing. Do not
attempt repair of the robotic cleaner, control box, power cord, or floating cable.
• NEVER OPEN CONTROL BOX.
• DO NOT USE AN EXTENSION CORD TO CONNECT THE UNIT TO ELECTRIC SUPPLY; PROVIDE A PROPERLY LOCATED GFCI RECEPTACLE.
THECONTROL BOX SHOULD BE PLUGGED INTO THE GFCI RECEPTACLE BOX.
PREVENT CHILD INJURY AND DROWNING
• To reduce the risk of injury, do not permit children to operate this product.
• Do not let anyone, especially small children, sit, step, lean, or climb on any equipment installed as part of your pool’s operational system.
CAUTION
Failure to comply with the following warnings could cause damage to pool equipment or personal injury.
• The cleaner must be installed and operated as specified.
• This product is intended for use with permanently-installed pools. Do not use with storable pools. A permanently-installed pool is constructed
in or on the ground or in a building such that it cannot be readily disassembled for storage. A storable pool is constructed so that it is capable
of being readily disassembled for storage and reassembled to its original integrity.
• Clean the filter canister in the cleaner after each use.
• Do not use the product in your pool if the water temperature is above 95° F (35° C) or below 55° F (13° C).
USE OF THE ROBOTIC CLEANER IN A VINYL LINER POOL
• Certain vinyl liner patterns are particularly susceptible to rapid surface wear of pattern removal caused by objects coming into contact with
the vinyl surface, including pool brushes, pool toys, floats, fountains, chlorine dispensers, and automatic pool cleaners. Some vinyl liner
patterns can be seriously scratched or abraded simply by rubbing the surface with a pool brush. Ink from the pattern can also rub off during
the installation process or when it comes into contact with objects in the pool. Zodiac Pool Systems LLC is not responsible for, and the Limited
Warranty does not cover, pattern removal, abrasion or markings on vinyl liners.
SAVE THESE INSTRUCTIONS

Page 5
Polaris®Robotic Pool Cleaner | Owner’s Manual ENGLISH
Section 2. Cleaner Specifications
Technical Specifications
The general specifications for the cleaner are as
follows:
Control Box Supply
Voltage 100-125 VAC, 60 Hz
Supply Voltage 30 V DC
Installed Load 150 W max
Cable Length 60 ft (18 m) or 70 ft (21 m)
depending on model
Cleaner Size (WxDxH) 16.9 x 18.9 x 10.6 in.
(43 x 48 x 27 cm)
Weight of Cleaner 21 lbs. (9.5 kg)
Packed Weight 42 lbs. (19 kg)
Filtration Single filter canister
Cycle Lengths Variable programming
The cleaner is a double-insulated product.
Adouble-insulated electrical appliance is one
which has been designed in such a way that it
does not require a safety connection to ground.
The basic requirement for double-insulation is that
no single failure can result in dangerous voltage
becoming exposed so that it might cause an
electric shock and that this is achieved without
relying on an earthed (grounded) metal casing. This
is achieved by having two (2) layers of insulating
material surrounding live parts or by using
reinforced insulation. Therefore, devices having
double-insulated construction, suchas this cleaner,
do not utilize a grounded (three-prong) cord/plug.
Section 3. Getting Started
3.1 Contents
The packaging should contain the following items:
• Robotic cleaner and floating cable
• Control box
3.2 Connect to a Power Source
WARNING
Failure to comply with the following warnings can result in permanent
injury, electrocution or drowning.
PREVENT ELECTRICAL SHOCK
U.S.: Per NEC® requirements, keep the control box at least 5 ft.
(1.5m) from the edge of the pool.
CANADA: Per CEC requirements, keep the control box at least 3 m
(10 ft) from the edge of the pool.
Only connect the control box to a receptacle protected by a ground
fault circuit interrupter (GFCI). Contact a certified electrician if you
cannot verify that the receptacle is protected by a GFCI.
Do not use an extension cord to connect the control box.
Do not allow anyone to swim while the cleaner is in the pool.
The control box is water-resistant, not waterproof. In order to prevent
electrocution, never submerge the control box or leave exposed to
inclement weather.
1. Unscrew the protective cap for the floating
cable from the side of the control box by
turning counter-clockwise.
Figure 1. Remove Protective Cap

Page 6
ENGLISH Polaris®Robotic Pool Cleaner | Owner’s Manual
2. Grip the notched end of the floating power
cable, insert into the control box, and turn
clockwise to tighten.
3. Plug the control box directly into a GFCI outlet.
DO NOT use an extension cord.
Figure 2. Connect Floating Cable
NOTE: To avoid damaging the power cable, do not try
to twist the entire cable housing.
NOTE: To avoid exposing the power cable connector
pins to water, be sure the connector is screwed
in all the way and there is no gap.

Page 7
Polaris®Robotic Pool Cleaner | Owner’s Manual ENGLISH
Section 4. General Cleaner
Operation
CAUTION
To prevent damage to the cleaner, to adhere to the following
guidelines:
• Remove the cleaner from the pool after the cleaning cycle is
completed.
• Store out of direct sunlight or inclement weather.
• Never lift the cleaner out of the pool by the floating cable.
• Take additional care when lifting the cleaner out of the pool.
Itbecomes heavier when filled with water.
• Always remove the cleaner from pool when super chlorinating
or adding acid.
• Do not handle cleaner while it is in operation.
IMPORTANT
• Always fully submerge the cleaner head before you begin
operation.
• Clean the filter canister after each cleaning cycle.
• Do not leave your cleaner in the pool on a permanent basis.
• At the end of each cycle, remove the cleaner from the pool.
• Start at the cleaner head and untangle any coils in the cable
before storing the cleaner.
The robotic cleaner includes a safety feature that
automatically stops the cleaner if a cleaning cycle
starts but it is not submerged in water. For pools
equipped with a beach area, this safety feature is
programmed to drive the cleaner in reverse and
back into the pool when the impeller is out of the
water.
WARNING
• Do not use an extension cord.
• Do not enter pool while the robotic cleaner is in water.
4.1 Install and Submerge the Cleaner
1. With the control box plugged into a GFCI
outlet, spread the floating cable across the
pool deck until you reach the middle of the
pool length.
2. At the center point, submerge the cleaner in
the pool and hold in the vertical position to
release any air trapped inside.
1
Figure 3. Submerge the Cleaner Vertically
3. Ensure the unit sinks to the bottom of the pool
and does not float.
2
Figure 4. Cleaner Sinking to the Bottom of the Pool
4. Place only enough floating cable in the water
to reach the farthest end of your pool from the
central point. Spread out the floating cable
ensuring there are no kinks or coils in the
cable.
NOTE: For optimal patterning and reduced tangling, the
floating cable should enter the water near the
middle of the pool length. Only place enough
cable in the water to reach the farthest point in
thepool.

Page 8
ENGLISH Polaris®Robotic Pool Cleaner | Owner’s Manual
Max Floating
Cable Length
Caddy /
Control Box
Recommended Entry Point
Not Recommended
Cleaner
Cleaner
WARNING
Do not use an extension cord.
Figure 5. Pool Entry Point for Optimal Patterning
4.2 Using the Control Box
The control box can be used to initiate basic cleaning features and to connect the device to home
Wi-Fi. For more information on connecting your cleaner to Wi-Fi, see section Installing iAquaLink®.
ALPHA™iQ+ / VRX™iQ+ / PHENOM™iQ+ VRX iQ / ALPHA iQ

Page 9
Polaris®Robotic Pool Cleaner | Owner’s Manual ENGLISH
Control box receiving power
Start/Stop cleaning
Select cleaning mode
*Waterline (45 min) Waterline only
Quick Clean (1 h 15 min) Floor only
SMART Cycle
(Calculate custom clean duration)
Floor, Wall, Waterline
*Deep Clean (2 h 45 min)
Floor, Walls, Waterline, High Intensity
Dirty canister indicator
Remove cleaner from the pool
+ / - 15 minute increments
Initiate connection and set up
iAquaLink®control
Bluetooth®light indicator status:
BLINKING - searching for signal
SOLID - paired with phone
Wi-Fi light indicator status:
BLINKING - connected to router
SOLID - connected to the internet
*Set recurring cleaning:
Every: Day, 2 Days, or 3 Days
* not available on all models
4.3 Start / Stop Cleaning and Adjust
Cleaning Time
The factory default cleaning mode is SMART Cycle
(Floor, Wall, Waterline).
The first use of SMART Cycle (duration: 2:30),
will automatically calculate the cleaner’s optimal
cleaning time for your pool. After the initial SMART
Cycle calculation, the optimal cleaning time is
saved for future use.
To recalculate the SMART Cycle setting, press and
hold the START/STOP button for 5 seconds.
Use to change cleaning surface setting.
Toggle between:
*Waterline (45 min) Waterline only
Quick Clean (1 h 15 min) Floor only
SMART Cycle
(Calculate custom clean duration)
Floor, Wall, Waterline
*Deep Clean (2 h 45 min)
Floor, Walls, Waterline, High Intensity
* not available on all models
1. With cleaner submerged in water, press
to begin operation.
Press again to interrupt and cancel an
in-progress cleaning cycle.
NOTE: At the beginning of each cleaning cycle,
the robot confirms your pool parameters
(approximately 10minutes). During this time, the
cleaner does not climb to the waterline.
Press +/- buttons to increase or decrease cleaning
time in 15-minute increments.
- Minimum run time is 30 minutes.
- Maximum run time is 3 hours 30 minutes.
NOTE: The control box automatically goes into standby
mode after 5 minutes and the display screen
turns off. Press any key to exit standby mode
and view remaining cycle time. Cleaner will
continue to function in standby mode.

Page 10
ENGLISH Polaris®Robotic Pool Cleaner | Owner’s Manual
4.4 Lift System
The Lift System is designed to assist in retrieving
the robot from the pool. Lift System can be
activated at any time during or after a cleaning
cycle.
1. Press to begin the automated
procedure.
The screen displays when the
LiftSystem is in operation.
NOTE: To stop the procedure at any time, press and
release the button again.
2. Next, Press and HOLD to rotate
thecleaner.
3. Once the cleaner is facing the wall of your
choice for retrieval, release the button.
4. Cleaner will drive forward and up the wall it
is facing. It will wait at the water line to be
retrieved.
5. When in reach, remove the cleaner from the
pool using the handle. The cleaner will quickly
expel water to allow for lighter, easier removal.
NOTE: Never lift the cleaner out of the pool by the
floating cable.
Section 5. Installing iAquaLink®
The iAquaLink app is available for download from
the App Store or Google Play.
With iAquaLink Control, you can connect to
your robotic cleaner from anywhere, anytime to
access functions and troubleshooting advice.
App features are dependent on model.
Before you begin installation, make sure you
have the following:
• IMPORTANT: Have your Wi-Fi network
password available
• Robotic cleaner is submerged in the pool
• Control box is connected and plugged into a
GFCIoutlet
• Smart device (phone or tablet) with Wi-Fi and
Bluetooth®enabled
• Wi-Fi router with sufficient signal strength at
the control box
5.1 Download the App
Install or update the iAquaLink app from the App
Store or Google Play.
5.2 Sign Up and Log In
Open the iAquaLink app, then Sign Up or Log In.
Complete all required fields in the Account Setup
page and agree to the Terms and Conditions.

Page 11
Polaris®Robotic Pool Cleaner | Owner’s Manual ENGLISH
5.3 Add to Mobile App System
1. On the My Systems page, click + in the upper
right-hand corner to add a system.
2. Choose “Robotic Cleaner”. Follow in app
instructions to add your cleaner and connect it
to your home router.
3. On the control box, press .
Bluetooth®light indicator status:
BLINKING - searching for signal
SOLID - paired with phone
Wi-Fi light indicator status:
BLINKING - connected to router
SOLID - connected to the internet
NOTE: Errors during connection may be the results of
insufficient Wi-Fi signal strength at the control
box location. If you are unable to move the
control or router to improve signal strength,
you may need a Wi-Fi extender to boost your
signal strength. (SeeiAquaLink®Troubleshooting
section.)
NOTE: An incorrect password may also be that cause
of a connection error. If the signal strength at the
control box is good, double check the network
name and credentials for the router you are
trying to access.
Section 6. iAquaLink®Control
Once you have downloaded the iAquaLink app and
connected the device to Wi-Fi, the iAquaLink app
allows for robotic cleaner control from anywhere,
anytime. Functions vary within the iAquaLink app
depending on which cleaner model you have.
WARNING
Do not enter pool while the robotic cleaner is in water.
6.1 iAquaLink Control Home Screen
App function and design is subject to change.
Start/Stop Cleaning
Remote
Clean Mode
Lift System
Dirty Canister Indicator
+
–Manual Time Adjustment
(current run time +/- 15 minutes)
°F / C
Water Temperature Display

Page 12
ENGLISH Polaris®Robotic Pool Cleaner | Owner’s Manual
6.2 Start / Stop Cleaning and Adjust
Cleaning Time
The factory default cleaning surface setting is
SMART Cycle (Floor, Wall, Waterline).
SMART Cycle calculates a customized cleaning
time optimized for your pool. On the first run of
SMART Cycle, the app counts up as it calculates
the optimized cleaning time.
On periodic SMART Cycle cleaning, the app will
count down from the optimized cleaning time.
NOTE: To Recalculate SMART Cycle, go to the Set
Cleaning Mode after the initial calculation.
1. From the Home screen or the control box,
press the Start button to begin cleaning.
2. The app displays the cycle time in hours and
minutes.
To increase or decrease the cycle time during
cleaning, press the (+) and (–) buttons.
—Time adjusts up or down in 15 minute
increments.
—Minimum run time is 30 minutes.
—Maximum run time is 3 hours 30 minutes.
—The control box displays the same
countdown and cycle setting as the app.
3. Press to interrupt and cancel an
in-progress cleaning cycle.
NOTE: At the beginning of each cleaning cycle,
the robot confirms your pool parameters
(approximately 10minutes). During this time, the
cleaner does not climb to the waterline.
6.3 Set Cleaning Mode
1. From the main screen, select Cleaning Mode
to view options.
2. Choose from available cleaning modes
depending on your cleaner model.*
3. In Custom mode (if applicable), select the
cleaning surface and cleaning intensity from
the on-screen icons.
*not available on all models
6.4 Remote Control
Use your mobile device as a remote control.
IMPORTANT
Only use remote control when in view of the cleaner.
1. From the main screen, select the Remote tab.
NOTE: When in remote control mode, the control box
displays .
2. You can direct the cleaner using the remote
control or use the spot clean feature to help
pick up debris.*
3. To use “Spot Clean” drive the cleaner near
where debris has collected and initiate “Spot
Clean.” The Cleaner will perform a short
cleaning pattern to remove debris in that area.
*not available on all models
NOTE: If you experience significant delays between the
app command and cleaner response, you may
have a weak Wi-Fi signal or other connectivity
challenges that interfere with the immediacy of
the remote control functions.
6.5 Lift System
The Lift System is designed to assist in retrieving
the robot from the pool. Lift System can be
activated at any time during or after a cleaning
cycle.
IMPORTANT
Only use Lift System when in view of the cleaner.
1. From the home screen, select Lift System
to enter automated procedure.
2. Use the left and right controls to rotate the
cleaner to face the wall of your choice.
3. Press the Lift System icon to drive the cleaner
up the wall it is facing. The cleaner will wait at
the water line to be retrieved.
NOTE: To stop the procedure at any time, press and
release the button again.
4. When in reach, grab the cleaner handle and
begin to pull cleaner out of the water. The
cleaner will quickly expel water to allow for
lighter, easier removal.
NOTE: Never lift the cleaner out of the pool by the
floating cable.

Page 13
Polaris®Robotic Pool Cleaner | Owner’s Manual ENGLISH
6.6 Program or Cancel Cleaning
Schedules
(not available on all models)
It is still recommended to remove and clean the
filter canister after every cleaning cycle.
1. Tap the area titled Next Cleaning or go
to System Settings and choose
Schedules.
2. To program a schedule, select the day of the
week.
3. Select a start time to begin the cleaning cycle.
4. Select a cleaning mode. Mode selected will
determine runtime.
5. Press OK to save the schedule or Delete to
remove permanently.
6. Repeat steps 2-4 to program additional days.
NOTE: Only one programmed cleaning cycle can be
scheduled per day.
7. Press BACK or DONE to leave the Edit
Schedule page and return to the main screen.
8. The next scheduled cleaning cycle will display
near the top of the main screen.
6.7 Temperature Display
(not available on all models)
On some models, the pool water temperature will
be displayed on the main app screen. Accurate
temperature may take a few minutes to display as
the sensor acclimates to the surrounding water
temperature. Temperature will only be displayed
during an in-progress cleaning cycle.
6.8 LED Lights
1. Sensor Nav System™- Indicator Light:
Located on the front of the cleaner, this light
has several functions to indicate status:
Blinking Blue: Sensing, Scanning and
Cleaning
*Solid Blue: Cleaning
Blinking Green: Lift System or Spot Cleaning
Solid Green: Remote Control
2. On some models, an LED light illuminates the
interior area of the body and canister.
*not available on all models
NOTE: LED lights may be difficult to see in sunlight.
6.9 In-App Error Messages and
Troubleshooting
If an error occurs, the status bar will show a
warning symbol and: “Cleaning Interrupted”.
1. Click on the warning symbol to view
troubleshooting advice on how to fix the issue.
2. Choose Clear Error if you believe you have
fixed the problem and want to re-try. Choose
OK if you want to suspend the cleaner in error
mode and work on the troubleshooting fix at a
later time.
6.10 System Settings
Access System Settings by pressing the gear icon
in the upper right hand corner of the app screen.

Page 14
ENGLISH Polaris®Robotic Pool Cleaner | Owner’s Manual
Section 7. Maintenance
WARNING
To avoid electric shock and other hazards which could result in
permanent injury or death, disconnect (unplug) the cleaner from the
power source before performing any cleaning and maintenance.
7.1 Cord Tangling
Tangling can occur more frequently when the
cleaner is not attended to after each cleaning
cycle. The tangle-reducing swivel, in addition to
proper installation, general maintenance and the
following troubleshooting steps can help to avoid
cable challenges.
IMPORTANT
Cleaner power cable may become tangled if correct procedure is
not followed after each cleaning cycle.
NOTE: For optimal patterning and reduced tangling, the
floating cable should enter the water near the
middle of the pool length. Only place enough
cable in the water to reach the farthest point in
thepool.
Caddy /
Control Box
Not Recommended
Cleaner
Cleaner
WARNING
Do not use an extension cord.
Max Floating
Cable Length
Recommended
Entry Point
Figure 6. Optimal Entry Point in Pool
If tangling occurs, follow these steps:
1. Remove the cleaner from the pool using the
Lift System. When the cleaner is within arm’s
reach, use the handle to remove from the
water. Never lift the cleaner out of the pool by
the floating cable or swivel.
2. Hold the cleaner vertically to drain.
Figure 7. Keep Cleaner Vertical to Drain Water
3. Unplug power to the cleaner at the control
box.
Figure 8. Unplug

Page 15
Polaris®Robotic Pool Cleaner | Owner’s Manual ENGLISH
4. Remove the cleaner from the pool and
untangle all kinks and coils in the power cable.
Start at the cleaner head. Lay the cable in the
sun to loosen any tangling memory.
Figure 9. Untangle
7.2 Clean the Filter Canister
The filter canister should be cleaned at the end of
each cycle.
1. Remove the cleaner from the water using the
Lift System and let the remaining water drain.
2. Set the unit on four wheels.
3. Push the cover lock (1) and lift the cover (2)
until it is secured in the vertical position.
2
1
Figure 10. Lift Cleaner Cover
4. Remove the filter canister assembly from the
body (3), as shown.
3
Figure 11. Remove Filter Canister Assembly
5. Push the quick release button on the canister
assembly (4) and pull open.
4
5
Figure 12. Open Filter Canister Assembly
6. Separate the filter canister from the filter
support (6), as shown.
6
Figure 13. Remove Filter Canister

Page 16
ENGLISH Polaris®Robotic Pool Cleaner | Owner’s Manual
7. Empty all debris from the filter canister, then
rinse the canister, the filter support and the
cleaner using a hose, as shown.
Figure 14. Wash Filter Canister
NOTE: Periodically, remove the filter canister and clean
thoroughly with soapy water and a soft bristle
brush.
7.3 Store the Cleaner When Not in Use
The cleaner should be cleaned regularly using
slightly soapy clean water. Do not use solvents
such as trichlorethylene or its equivalent. Rinse the
cleaner generously using clean water. Do not let
your cleaner dry in direct sunlight near the pool.
Thecleaner should be stored on its caddy so that
itdries quickly.
1. Disconnect cleaner from the power source.
2. Starting at the cleaner head, remove all coils
and tangles from the cable. Lay the cable in
the sun to loosen any tangling memory.
3. Place the rear wheels on the caddy and
position the cleaner vertically on the caddy
base.
4. Disconnect the cable from the control box.
Replace the protective cap on the control box.
Figure 15. Untangle the Floating cable
5. Loosely coil the power cable starting at the
cleaner and moving toward the connection
pointat control box. Store the cable by
wrapping it around the hook located on the
frontof the caddy.
7.4 Replacing Worn Parts
Replacing Brushes
The cleaner is fitted with PVC brushes with a
“wear’’ indicator.
raised groove becomes
partially flattened,
indicating excessive
wear
Raised groove
becomes
partially flattened,
indicating
excessive wear.
Figure 16. Worn Brush Indicator
To maintain cleaner performance at its best you
need to replace the brushes as soon as one of the
wear indicators is reached (even if the blade wear
is not even). It is recommended that you replace
the brushes when the rubber is worn down to
the top of the wear indicator (or every two years,
whichever comes first).

Page 17
Polaris®Robotic Pool Cleaner | Owner’s Manual ENGLISH
To replace a worn brush:
1. Lift the cleaner to a vertical position so that the
handle is up.
1
Figure 17. Cleaner in Upright Position
2. Separate the edges of the brush and undo the
tabs. Remove the worn brushes.
2
Figure 18. Undo the Tabs of the Brush
3. To install the new brush, position the new
brush on the roller with the cleaning blades
facing away from the roller.
3
Figure 19. Install the New Brush
4. Thread each tab into the slot provided and
gently feed it through until the heel comes out
at the other side of the slot.
4
Figure 20. Pull Tabs Through Each Slot
5. Use a pair of scissors to cut the tabs 3/4 inch
from the heel so that they are no higher than
the cleaning blade.
6. Repeat the procedure to install the second
brush.
Figure 21. Cut Tabs

Page 18
ENGLISH Polaris®Robotic Pool Cleaner | Owner’s Manual
Replacing Tires
1. Pull on the inside of the old tire to remove the
tire lip from the wheel.
1
Figure 22. Pull the Old Tire Over the Wheel
2. Remove the old tire.
2
Figure 23. Remove the Old Tire
3. To replace the tire, position the tire on the
wheel making sure to orient the tire so that the
word INSIDE is toward the body of the cleaner.
1
I
N
S
I
D
E
I
N
S
I
D
E
I
N
S
I
D
E
Word
“INSIDE”
Towards
Cleaner
Figure 24. Tire Replacement Orientation
4. Push one side of the tire on to the wheel and
fit the rib of the tire in the groove of the wheel.
2
Figure 25. Start on One Side of the Tire

Page 19
Polaris®Robotic Pool Cleaner | Owner’s Manual ENGLISH
5. Work the tire onto the wheel and verify the
rib of the tire is positioned properly within the
groove of the wheel.
3
Figure 26. Work the Tire On Around the Wheel
6. Push and position the rib of the inner side of
the tire in the groove of the wheel. If needed,
turn the wheel gently to help with installation.
4
Figure 27. Push the Tire into Place on the Wheel
7.5 Spare Parts
The complete spare parts list and exploded view is
available on the Polaris website.
• USA: www.polarispool.com
• Canada: www.polarispool.ca
Contact your local maintenance provider to
perform diagnostic tests or repairs not shown in
general maintenance.

Page 20
ENGLISH Polaris®Robotic Pool Cleaner | Owner’s Manual
Section 8. Troubleshooting
Information about the cleaner status and any relevant condition will be displayed on the control box and/or
in the iAquaLink®app.
8.1 Error Codes
Control Box
Display In-App Display Suggested Solution
1
2
3
Pump Motor
Traction Motor Right
Traction Motor Left
a. Check for corrosion or bent pins in the power cable
connection area.
b. Turn each wheel one quarter turn in one direction
repeatedly until rotation is smooth. Repeat, turning wheels
in the opposite direction until rotation is smooth.
c. If this does not resolve the problem, contact your local
retailer for a diagnostic review or call customer service.
4Pump Motor Consumption a. Check for small debris or hair in the fan impeller.
b. Thoroughly clean the filter canister.
c. If this does not resolve the problem, contact your local
retailer for a diagnostic review or call customer service.
5
6
Drive Motor Consumption Right
Drive Motor Consumption Left
a. Thoroughly clean the filter canister.
b. Turn off the cleaner and submerge. Shake to release air
bubbles. Restart cycle.
c. If this does not resolve the problem, contact your local
retailer for a diagnostic review or call customer service.
7Cleaner Floating
• Turn cleaner power off, then submerge cleaner according to
correct procedure.
8Cleaner Out of the Water
• Turn off the cleaner and submerge. Shake to release air
bubbles. Restart cycle.
9N/A
• Cleaner has completed a cleaning cycle. This is not an error.
Noaction required.
10 Communication a. Turn cleaner power off and on again to reset.
b. Check floating cable connection to the control box.
Checkfor corrosion or bent pins at the connection point.
c. If this does not resolve the problem, contact your local
retailer for a diagnostic review or call customer service.
11 Sensor Unit
• Contact approved service station for replacement.
N/A Connection Error a. Check that the control box is plugged into a GFCI outlet
and that the Wi-Fi icon is illuminated.
b. If not, go through the set-up steps to reconnect to the
home router. Check that the router is in close enough range
to the control box. Install a Wi-Fi extender if necessary.
