Fig.1 Fig.2 Fig.3 Fig.4
Fig.13
SANI SYSTEM CHECK M0S08111 Ed.2O08
T
H
Fig.6 Fig.8
Q
Q1
B
C
D
D1
D2/
D3
D4
E
D5
Fig.9 Fig.10 Fig.11 Fig.12
U
Fig.5 Fig.7
COP-SANI SYSTEM CHECK M0S08111 2O08:V_tto_1300cop.qxd 31/07/2008 10.45 Pagina 1

L
A
G
P
O
N
M
I
F
RS
Fig.1 Fig.2 Fig.3 Fig.4
Fig.13
SANI SYSTEM CHECK M0S08111 Ed.2O08
T
H
Fig.6 Fig.8
Q
Q1
B
C
D
D1
D2/
D3
D4
E
D5
Fig.9 Fig.10 Fig.11 Fig.12
U
Fig.5 Fig.7
COP-SANI SYSTEM CHECK M0S08111 2O08:V_tto_1300cop.qxd 31/07/2008 10.45 Pagina 1

E
EN
NG
GL
LI
IS
SH
H
SANI SYSTEM CHECK
42
KEY
GENERATOR
A) ON/OFF switch
B) Numerical keypad
C) Display
D) Printer
D1) Paper output
D2) Printer LED
D3) OPEN key
D4) FEED key
D5) CARD slot
E) Signalling lamp
F) Pressure indicator
G) Tank cap
H) Power cable
I) Carrier grip
L) Rod for supporting tube
M) Monotube
DELIVERY DEVICE
N) Delivery lamp
O) Delivery device grip
P) Steam delivery push-button
Q) Fitting for disposable bottle
Q1) Disposable bottle of HPMED
R) Adaptor for creating concentrated steam
jet
S) Spacer
T) Brush
U) Card
Polti S.p.A. reserves the right to change equipment or accessory specification without
prior notice.
The POLTI SANI SYSTEM delivers saturated steam at a high temperature combined with
the sanitising agent HPMED in order to lower the bacterial, fungous and viral load on the
surfaces to which it is applied. This enables the possibility of cross-infections to be re-
duced.
The POLTI SANI SYSTEM can be used wherever it is necessary to reduce microbial con-
tamination (hospitals, nursing homes, doctors’ surgeries, public places, means of tran-
sport, food-processing facilities, pharmaceutical companies, etc.).
This appliance complies with directive 93/42/EEC
TECHNICAL DATA
Voltage:........................................220-240 V~
Frequency:.......................................50/60 Hz
Max. current:.............................................11A
Max.wattage:.......................................2250W
Boiler wattage:.....................................2200W
Delivery unit wattage:..........................950W
Protection class:......................................IPX4
Fuses:.......................................................16A
Operating temperature:.........from 18 to 35°c
Operating humidity:..............from 40 to 70 %
PERFORMANCE
Steam consumption:..................... 100 g/min
*Guaranteed average consumption of
HPMED:....................................... 0.4 ml/min
Steam temperature:..............................180°C
Pressure:...............................from 4 to 6 bar
Dry saturated steam
* The operation time of the disposable bottle
strictly depends on the conditions in which
SANI SYSTEM POLTI is used and on the wi-
deness of the surfaces to be treated.
Read these instructions carefully before using the appliance.
SANI SYSTEM CHECK M0S08111 2O08:A5 31/07/2008 11.27 Pagina 42

P
PR RE EC CA AU UT TI IO ON NS S
KEEP THESE INSTRUCTIONS
• The appliance is designed and made for
use in closed areas, never outdoors.
•BEFORE STARTING TO SANITISE, IT IS
ADVISABLE TO DIRECT THE FIRST JET
OF STEAM ONTO A CLOTH OR DOWN-
WARDS FOR APPROXIMATELY 30 SEC-
ONDS WITHOUT HOOKING UP THE FIT-
TING FOR THE DISPOSABLE BOTTLE
(Q). THIS WILL ENABLE THE OPTIMUM
TEMPERATURE AND PRESSURE TO BE
REACHED.
• Before treating delicate or unusual surfaces
with the SANI SYSTEM Polti sanitising sys-
tem, consult the manufacturer’s instructions
and always carry out a test on a hidden part
or on a sample of the material. Allow the
sanitised area to dry in order to make sure
that no changes in colour or deformations
have occurred.
• Read these instructions for use carefully
before using the appliance, and make sure
that anyone using the machine is familiar
with these instructions and the warnings.
• Any use which does not comply with these
instructions will invalidate the warranty.
• The wiring system to which the appliance is
connected must always comply with the
laws in force.
• Before connecting the appliance, make
sure that the mains voltage is the same as
the voltage indicated on the data label of
the appliance and that the power outlet is
connected to earth
• Always turn off the appliance at the on/off
switch before unplugging it.
• If the appliance is left unused, always dis-
connect it from the mains. Never leave the
appliance unattended with the cable
plugged into the mains.
• Always make sure the appliance is un-
plugged before performing maintenance
work of any kind
• Do not pull the power cable out of the
socket, but grasp the plug itself to avoid
damage to the socket.
• Do not allow the power cable to be twisted,
crushed, stretched, or come into contact
with sharp or hot surfaces.
• Do not use the appliance if the power cable
or other important parts are damaged.
• Do not use electric extension leads that are
not authorized by the manufacturer, as they
may cause damage or fire.
• Never touch the appliance with wet hands
or feet with the cable plugged into the
mains.
• Do not use the appliance when barefoot.
• Do not use the appliance near a bathtub,
shower or container full of water
• Never immerse the appliance, the cable or
the plugs in water or another liquid.
• Use of the appliance in places where there
is a danger of explosions is prohibited.
• Do not use the product with toxic sub-
stances.
• Do not lay the hot appliance on surfaces
sensitive to heat.
• Do not leave the appliance exposed to wind
or rain.
• Do not place the appliance near a live ele-
ment, an electric stove or any other source
of heat.
• Do not expose the appliance to extreme
temperatures
• Never let children or people who are not fa-
miliar with how the appliance works use it.
• Do not press the buttons hard or with a
pointed object such as a pen.
• Always rest the appliance on a stable sur-
face.
• In case of accidental fall of the appliance it
is necessary to have it checked by an au-
thorized Service Centre as the internal
safety features may have been affected.
• In case of breakdown or malfunction switch
off the appliance and never attempt to dis-
assemble it, but refer to an authorized Polti
Service Centre.
• To avoid prejudicing the safety of the appli-
ance, use only original spare parts and ac-
cessories approved by the manufacturer.
• Do not wind the power cable around the ap-
pliance, especially when the appliance is
still hot.
• During refilling with water, switch off and
