Polycom Realpresence collaboration server 1500 Installation instructions

Version 8.3 |January 2014 |DOC2751A
Hardware Guide
RealPresence Collaboration Server
(RMX) 1500

© 2014 Polycom, Inc. All rights reserved.
Polycom, Inc.
6001 America Center Drive
San Jose CA 95002
USA
No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for
any purpose, without the express written permission of Polycom, Inc. Under the law, reproducing includes translating
into another language or format.
As between the parties, Polycom, Inc., retains title to and ownership of all proprietary rights with respect to the software
contained within its products. The software is protected by United States copyright laws and international treaty
provision. Therefore, you must treat the software like any other copyrighted material (e.g., a book or sound recording).
Every effort has been made to ensure that the information in this manual is accurate. Polycom, Inc., is not responsible
for printing or clerical errors. Information in this document is subject to change without notice.
2
Trademark Information
POLYCOM®and the names and marks associated with Polycom's products are trademarks and/or service marks of
Polycom, Inc., and are registered and/or common law marks in the United States and various other countries.
All other trademarks are the property of their respective owners.
Patent Information
The accompanying product may be protected by one or more U.S. and foreign patents and/or pending patent
applications held by Polycom, Inc.
This document provides the latest information for security-conscious users running Version 8.3 software.
The information in this document is not intended to imply that DoD or DISA certifies Polycom RMX systems.
End User License Agreement
Use of this software constitutes acceptance of the terms and conditions of the Polycom® RealPresence® Collaboration
Server (RMX) 1500/1800/2000/4000 system end-user license agreements (EULA).
The EULA for your version is available on the Polycom Support page for the Polycom® RealPresence® Collaboration
Server (RMX®) 1500/1800/2000/4000 system.
This software has not achieved UC APL certification.

RMX Release Notes Version 8.3
Polycom, Inc. 3
Regulatory Notices
Warning
Warning
•No user-serviceable parts inside. Do not open.
•The plug-socket combination must be accessible at all times, because it serves as the main
disconnecting device.
•This equipment must be earthed. Do not power this equipment if the integrity of themains earthing
conductor cannot be verified.
•Only trained and qualified personnel should be allowed to install, replace, service or repair this
equipment.
•To prevent system overheating do not operate in an ambient temperature
exceeding 40° C / 104° F.
•Installation of this equipment must comply with local and national electrical codes.
Environmental
This product is compliant with the requirements of the recast RoHS Directive 2011/65/EU. Information can be
obtained from Polycom Ltd, 270 Bath Road, Slough, Berkshire, SL1 4DX, UK or via:
[e-mail]
Information on recycling can be found at: www.polycom.com/WEEE
Disposal of this equipment should be carried out in accordance with local environmental guidelines and regulations
for waste. For further information please contact: [e-mail]
Batteries
Below is a listing of batteries that could be present in the product:
Description:Internal CMOS battery
Type:CR2032 Lithium Coin Cell
Weight:3.3g
Batteries used in this product are in compliance with EU Battery Directive 2006/66/EC.
Batteries in this product are not based on mercury, lead or cadmium technologies.
Batteries in this product are not intended to be replaced or removed by the user
Additional information on the safe use and recycling of batteries can be found at: www.polycom.com/batteries

RMX Release Notes Version 8.3
Polycom, Inc. 4
United States Federal Communication Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
Modifications: Any modifications made to this device that are not approved by Polycom, Inc. may void the authority
granted to the user by the FCC to operate this equipment.
Industry Canada (IC)
This Class [A] digital apparatus complies with Canadian ICES-003
Cet appareil numerique de la classe [A] est conforme a la norme NMB-003 du Canada
European Economic Area (EEA)
Česky [Czech]: Polycom (UK) Ltd tímto prohlašuje, že tento Polycom RMX je ve shoděse
základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES.
Dansk [Danish]: Undertegnede Polycom (UK) Ltd erklærer herved, at følgende udstyr Polycom
RMX overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
Deutsch [German]: Hiermit erklärt Polycom (UK) Ltd, dass sich das Gerät Polycom RMX in
Übereinstimmung mit den grundlegenden Anforderungen und den übrigen
einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.
Eesti [Estonian]: Käesolevaga kinnitab Polycom (UK) Ltd seadme Polycom RMX vastavust
direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele
asjakohastele sätetele.
English: Hereby, Polycom (UK) Ltd. Declares that this Polycom RMX is in compliance with
the essential requirements and other relevant provisions of Directive 1999/5/EC.
Español [Spanish]: Por medio de la presente Polycom (UK) Ltd declara que el Polycom RMX cumple
con los requisitos esenciales y cualesquiera otras disposiciones aplicables o
exigibles de la Directiva 1999/5/CE.
Ελληνική [Greek]: ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Polycom (UK) Ltd ∆ΗΛΩΝΕΙ ΟΤΙ Polycom RMX
ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩ∆ΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ
ΣΧΕΤΙΚΕΣ ∆ΙΑΤΑΞΕΙΣ ΤΗΣ Ο∆ΗΓΙΑΣ 1999/5/ΕΚ.
Français [French]: Par la présente Polycom (UK) Ltd déclare que l’appareil Polycom RMX est
conforme aux exigences essentielles et aux autres dispositions pertinentes de la
directive 1999/5/CE.

RMX Release Notes Version 8.3
Polycom, Inc. 5
Italiano [Italian]: Con la presente Polycom (UK) Ltd dichiara che questo Polycom RMX è conforme
ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva
1999/5/CE.
Íslenska (Icelandic): Hér með lýsir Polycom (UK) Ltd yfir því að Polycom RMX er í samræmi við
grunnkröfur og aðrar kröfur, sem gerðar eru í tilskipun 1999/5/EC.
Latviski [Latvian]: Ar šo Polycom (UK) Ltd deklarē, ka Polycom RMX atbilst Direktīvas 1999/5/EK
būtiskajām prasībām un citiem ar to saistītajiem noteikumiem.
Lietuvių[Lithuanian]: Šiuo Polycom (UK) Ltd deklaruoja, kad šis Polycom RMX atitinka esminius
reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.
Nederlands [Dutch]: Hierbij verklaart Polycom (UK) Ltd dat het toestel Polycom RMX in
overeenstemming is met de essentiële eisen en de andere relevante bepalingen
van richtlijn 1999/5/EG.
Malti [Maltese]: Hawnhekk, Polycom (UK) Ltd, jiddikjara li dan Polycom RMX jikkonforma
mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva
1999/5/EC.
Magyar [Hungarian]: Alulírott, Polycom (UK) Ltd nyilatkozom, hogy a Polycom RMX megfelel a
vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb
elõírásainak.
Norsk [Norwegian]: Polycom (UK) Ltd erklærer herved at utstyret Polycom RMX er i samsvar med de
grunnleggende krav og øvrige relevante krav i direktiv 1999/5/EF.
Polski [Polish]: Niniejszym Polycom (UK) Ltd oświadcza, że Polycom RMX jest zgodne z
zasadniczymi wymaganiami oraz innymi stosownymi postanowieniami Dyrektywy
1999/5/WE.
Português [Portuguese]: Polycom (UK) Ltd declara que este Polycom RMX está conforme com os
requisitos essenciais e outras disposições da Directiva 1999/5/CE.
Slovensko [Slovenian]: Polycom (UK) Ltd týmto vyhlasuje, že Polycom RMX spĺňa základné požiadavky a
všetky príslušné ustanovenia Smernice 1999/5/ES.
Slovensky [Slovak]: Polycom (UK) Ltd týmto vyhlasuje, že Polycom RMX spĺňa základné požiadavky a
všetky príslušné ustanovenia Smernice 1999/5/ES.
Suomi [Finnish]: Polycom (UK) Ltd vakuuttaa täten että Polycom RMX tyyppinen laite on direktiivin
1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen
mukainen.
Svenska [Swedish]: Härmed intygar Polycom (UK) Ltd att denna Polycom RMX står I
överensstämmelse med de väsentliga egenskapskrav och övriga relevanta
bestämmelser som framgår av direktiv 1999/5/EG.
A full copy of the Declaration of Conformity can be obtained from Polycom Ltd, 270 Bath Road, Slough, Berkshire,
SL1 4DX, UK.
European Economic Area (EEA)

RMX Release Notes Version 8.3
Polycom, Inc. 6
Taiwan BSMI EMC statement
Japan VCCI EMC statement
This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information
Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise.
When such trouble occurs, the user may be required to take corrective actions.
Worldwide EMC statement
This is a class A product. In a domestic environment this product may cause radio interference in which case the
user may be required to take adequate measures.
Optional ISDN interface card
If the above is fitted to the system then the following statements also apply;
United States Federal Communication Commission (FCC)
This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the ISDN
card itself is a label that contains, among other information, a product identifier in the format US:AAAEQ##TXXXX.
If requested, this number must be provided to the telephone company.
The following USOC, FIC and SOC codes are applicable to this equipment;
USOC Jacks: RJ48S
Service Order Code: 6.0N
Facility Interface Code: 04DU9.DN, 04DU9.BN, 04DU9.1KN, 04DU9.1SN
If this equipment causes harm to the telephone network, the telephone company will notify you in advance that
temporary discontinuance of service may be required. But if advance notice isn't practical, the telephone company
will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC
if you believe it is necessary.
The telephone company may make changes in its facilities, equipment, operations or procedures that could affect
the operation of the equipment. If this happens the telephone company will provide advance notice in order for you
to make necessary modifications to maintain uninterrupted service.
If trouble is experienced with this equipment, for repair or warranty information, please contact Polycom Inc in the
U.S.A. 1-888-248-8294. If the equipment is causing harm to the telephone network, the telephone company may
request that you disconnect the equipment until the problem is resolved.
Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service
commission or corporation commission for information.

Polycom, Inc. 7
Contents
Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Main Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
RealPresence Collaboration Server (RMX) 1500 Specifications . . . . . . . . . . . . . . . . . . . . . . . 10
RealPresence Collaboration Server (RMX) 1500 System Capacities . . . . . . . . . . . . . . . . . . . 11
Conferencing Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Resource Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Site Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Safety Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Rack Mount Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Installation Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Installing the RealPresence Collaboration Server (RMX) 1500 . . . . . . . . . . . . . . . . . . . . 14
Unpacking the RealPresence Collaboration Server (RMX) 1500 . . . . . . . . . . . . . . . . 14
Installing the RTM ISDN 1500 Card on the RealPresence Collaboration Server
(RMX) 1500 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Telescopic Rail Runner Assembly for RealPresence Collaboration Server
(RMX) 1500 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Assembling the Telescopic Rail Runner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Mounting the RealPresence Collaboration Server (RMX) 1500 on a Shelf . . . . . . . . 20
Connecting the RealPresence Collaboration Server (RMX) 1500 to a Power Source . . . 20
Connecting the RealPresence Collaboration Server (RMX) 1500 to AC Power . . . . . 21
Connecting Cables to the RealPresence Collaboration Server (RMX) 1500 . . . . . . . . . . 21
First-time Power-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
RealPresence Collaboration Server (RMX) 1500 Components . . . . . . . . . . . . . . . . . . . . . . . 23
RealPresence Collaboration Server (RMX) 1500 Front Panel . . . . . . . . . . . . . . . . . . . . . 23
Opening the Collaboration Server (RMX) 1500 Front Panel . . . . . . . . . . . . . . . . . . . 23
Front Panel Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
RealPresence Collaboration Server (RMX) 1500 Rear Panel . . . . . . . . . . . . . . . . . . . . . 25
RTM IP 1500 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
RTM ISDN 1500 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Polycom RealPresence Collaboration Server (RMX) 1500 Hardware Guide
Polycom, Inc. 8
ISDN/PSTN Clock Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
RealPresence Collaboration Server (RMX) 1500 Power Supply . . . . . . . . . . . . . . . . . . . 28
RealPresence Collaboration Server (RMX) 1500 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
RealPresence Collaboration Server (RMX) 1500 Front Panel LEDs . . . . . . . . . . . . . . . . 29
RealPresence Collaboration Server (RMX) 1500 Rear Panel LEDs . . . . . . . . . . . . . . . . . 29
RTM IP 1500 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
RTM ISDN 1500 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Power Supply LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Component Installation & Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Installing or Replacing the RTM ISDN 1500 Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Removing the Blank Cover or the Existing RTM ISDN 1500 Card from the
RealPresence Collaboration Server (RMX) 1500 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Installing a New or Replacement RTM ISDN 1500 Card . . . . . . . . . . . . . . . . . . . . . . . . . 33
PRI Port Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Polycom, Inc. 9
RealPresence Collaboration Server
(RMX) 1500 Hardware Description
This Hardware Guide provides information on the RealPresence Collaboration Server (RMX) 1500 and its
components. This system utilizes a modular platform, whose components are designed for high
performance, capacity, and reliance.
Main Features
The Polycom RealPresence Collaboration Server (RMX) 1500 offers the following features:
●Linux® based
●Support for standard network interfaces (H.323, SIP, ISDN, PSTN and LAN)
●New hardware technologies
●Telco grade high availability, on-line upgrading and dynamic resource allocation
●Easy integration of conference elements into external network management
●Enhanced Continuous Presence (multi-image video)
●IVR (Interactive Voice Response) module
Polycom® RealPresence® Collaboration Server 1500 and RMX® 1500 are used interchangeably
throughout this document.

RealPresence Collaboration Server (RMX) 1500 Hardware Guide
Polycom, Inc. 10
RealPresence Collaboration Server (RMX) 1500
Specifications
RMX 1500 Specifications
Physical
Height 1U (4.44 cm.)
Width 19” (48.26 cm.)
Depth 26.3” (60 cm.)
Weight Up to 12 Kg (26.5 lbs).
Media Protocols
Audio G.711a/u, G.722, G.722.1C, G.722.1, G.723.1, G.719 G.729A, Polycom
Siren™ 14, Siren 22 (in mono or stereo) and Siren LPR.
Video H.261, H.263, H.264, H.264 High Profile
Network Interfaces
IP, ISDN, PSTN and LAN H.323, SIP, ISDN, PSTN, VoIP and LAN
Power Supply
AC Input/ Range, BTU Voltage range: 100-240 VAC ±10%, 1.5-4 AMP, 50-60 Hz.
Maximum BTU output: 1195 per hour.
Power Consumption
AC Maximum Power consumption 350 Watts.
Environment
Operating temperature 0°to 40°C (32° to 104°F).
Storage temperature -40°to70°C (-40° to 158° F).
Relative humidity 15% to 90% non-condensing.
Operating altitude 360m (1200ft) below sea level and up to 4Km (13,000ft)
Transit Storage Sea level and up to 15Km (50,000ft)
Operating ESD 4 kV.

RealPresence Collaboration Server (RMX) 1500 Hardware Guide
Polycom, Inc. 11
RealPresence Collaboration Server (RMX) 1500
System Capacities
Conferencing Capacities
The following table summarizes the different system capacities.
System Functions and Capacities RMX 1500 Series
System Functions MPMx - Q MPMx -S MPMx -D
Maximum number of Video participants in a conference 25 45 90
Maximum number of PSTN participants in a conference 90 120 120
Maximum number of VOIP participants in a conference 90 180 360
Maximum number of Audio calls per second 5 5 5
Maximum number of Video calls per second 2 2 2
Maximum number of conferences 200 400 400
Maximum number of Meeting Rooms 1000 1000 1000
Maximum number of Entry Queues 40 40 40
Maximum number of Profiles 80 80 80
Maximum number of Conference Templates 100 100 100
Maximum number of SIP Factories 40 40 40
Maximum number of IP Services 2 2 2
Maximum number of ISDN Services 2 2 2
Maximum number of IVR Services 80 80 80
Maximum number of Recording Links 20 (default) 20 (default) 20 (default)
Maximum number of IVR Video Slides 150 150 150
Maximum number of Log Files (1Mb max.) 4000 4000 4000
Maximum number of CDR Files 2000 2000 4000
Maximum number of Fault Files 1000 1000 1000
Number of Participant alerts Unlimited Unlimited Unlimited
Maximum number of concurrent RealPresence Collaboration Server
Web Client connections to the MCU
20 20 20
Maximum number Address Book entries 4000 4000 4000
Maximum number of Users 100 100 100

RealPresence Collaboration Server (RMX) 1500 Hardware Guide
Polycom, Inc. 12
Resource Capacities
Maximum number of Gateway Profiles 40 40 40
Maximum number of Reservations (Internal Scheduler) 2000 2000 2000
System Resources are now reported in terms of HD720p30 CP ports. One HD video port equals 3
CIF video ports.
System Resource Capacities per Resolution in CP Mode
Resource Type/Video
Resolution MPMx - Q MPMx -S MPMx - D
CIF H.263 14 30 60
CIF 30 H.264 25 45 90
CIF 60 H.264 14 30 60
SD 30/ 4CIF H.264 14 30 60
4CIF H.263 7 15 30
HD720p30/ 4CIF 60/ SD 60 7 15 30
HD1080p30fps/HD720p60 3 7 15 (Symmetric)
VOIP 90 180 360
PSTN 90 120 120
ISDN 25 60 (at 128 Kbps) - 4
E1/T1
60 (at 128 Kbps) - 4
E1/T1
On the Collaboration Server (RMX) 1500 with a MPMx-Q media card, the use of HD resolution with
Continuous Presence requires an additional license.
System Resource Capacities per Line Rate per Card Type in VSW Mode
Resource Type/ Line Rate MPMx - Q MPMx - S MPMx -D
VSW 2Mb 20* 40* 80*
VSW 4Mb 10 20 40
System Functions and Capacities RMX 1500 Series
System Functions MPMx - Q MPMx -S MPMx -D

RealPresence Collaboration Server (RMX) 1500 Hardware Guide
Polycom, Inc. 13
Site Requirements
This section describes the requirements your site must meet for the safe installation and operation of the
system.
Safety Requirements
For your protection, please read these safety instructions completely before operating the equipment.
●Look carefully for potential hazards in your work area: moist floors, ungrounded power cables, frayed
power cords, missing safety grounds and so forth.
●Locate the main circuit breaker within the room.
●Locate the emergency power OFF switch within the room.
●Never assume that power is disconnected from a circuit.
●Use only the power cord supplied with the system.
●The power cord should only be connected to a power outlet that has a protective ground contact.
●Ensure that the power cord is easily accessible from the back of the system at all times.
●Place the equipment in a well-ventilated area where the vents are free from obstruction.
●Do not place heavy objects directly on top of the Collaboration Server (RMX) 1500 unit.
Do not use liquids around your equipment.
Rack Mount Safety Precautions
The following precautions should be followed with regards to rack mount safety:
●Keep the area around the Collaboration Server (RMX) 1500 clean and free of clutter.
●Decide on a suitable location for the equipment rack that will hold the Collaboration Server (RMX)
1500 unit. It should be situated in a clean, dust-free area that is well ventilated. Avoid areas where
heat, electrical noise and electromagnetic fields are generated. You will also need it placed near a
grounded power outlet.
●Ensure that the leveling jacks on the bottom of the rack are fully extended to the floor with the full
weight of the rack resting on them.
●In a single rack installation, stabilizers should be attached to the rack.
●In multiple rack installations, the racks should be coupled together.
●Always make sure the rack is stable before extending a component from the rack.
●You should extend only one component at a time - extending two or more simultaneously may cause
the rack to become unstable.
●Before you install the rails, determine the placement of each component in the rack.
VSW 6Mb 5 10 20
ISDN 25 (at 128 Kbps) 60 (at 128 Kbps) 60 (at 128 Kbps)
System Resource Capacities per Line Rate per Card Type in VSW Mode
Resource Type/ Line Rate MPMx - Q MPMx - S MPMx -D

RealPresence Collaboration Server (RMX) 1500 Hardware Guide
Polycom, Inc. 14
●Install the heaviest components on the bottom of the rack first, and then work up.
●Allow the power supply units to cool before touching them.
●Always keep the rack’s trays and card’s slots closed when not servicing, to maintain proper cooling.
Installation Precautions
The following precautions should be followed with regards to installation of the Collaboration Server (RMX)
1500:
●Use a regulating uninterruptable power supply (UPS) to protect the Collaboration Server (RMX) 1500
from power surges and voltage spikes, to keep your MCU operating in case of a power failure.
●Place the Collaboration Server (RMX) 1500 on a hard, flat surface such as a desktop or mount it on
19” rack.
●The airflow of the Collaboration Server (RMX) 1500 is from front to back. Be sure that the areas in
the front and rear side of the system are clear for proper ventilation.
Installing the RealPresence Collaboration Server (RMX) 1500
The following procedures have to be performed to install the Collaboration Server (RMX) 1500 in your site:
●Unpacking the RMX
●Installing the RTM ISDN card on the RMX
●Installing the RMX in a rack or as a standalone
●Connecting the RMX to the power source
●Connecting the network (LAN, IP and ISDN) cables to the RMX
Unpacking the RealPresence Collaboration Server (RMX) 1500
Observe the following procedures when unpacking theCollaboration Server (RMX) 1500.
To unpack and lift the Collaboration Server (RMX) 1500:
1When you receive the Collaboration Server (RMX) 1500 packing case, inspect the equipment for
damage and verify that the components match the packing slip.
2Open the top cover of the packing case.
Boxes are placed on the top Stratocell® and contain the following:
When handling electronic components, standard anti-static precautions must be observed:
•Wear a grounding strap
•Handle cards by their edges only and do not touch their components or connector pins
•Keep components in anti-static bags when not installed in the Collaboration Server (RMX) 1500.
Sealed System! The Collaboration Server (RMX) 1500 is a sealed system, breaking the seal and
opening the RMX chassis VOIDS the WARRANTY!

RealPresence Collaboration Server (RMX) 1500 Hardware Guide
Polycom, Inc. 15
Installation Accessories. This kit contains the power cables, 3 ethernet cables, USB key and
documentation.
Rack Installation Accessories. This kit contains the accessories for the 19” rack.
ISDN Package (Optional). Contains the ISDN card and ISDN Software License.
Make sure that boxes contain all the required parts.
Installing the RTM ISDN 1500 Card on the RealPresence Collaboration Server
(RMX) 1500
The ISDN card is shipped out of the box and must be manually installed into the rear of the Collaboration
Server (RMX) 1500. It is recommended that the ISDN card be installed before the Collaboration Server
(RMX) 1500 is placed in a rack.
A RealPresence® Collaboration Server 1500/1800/2000/4000 Getting Started Guide Software License is
included with the ISDN card and must be registered as part of the Product Registration and Product
Activation. For more information, refer to the ISDN Software Licence document you received with your
shipment.
For more information on installing the ISDN card, see Installing or Replacing the RTM ISDN 1500 Card .
Write down the RMX’s serial number that is on a sticker on the back of the unit. You will need it for
product registration later in the process.

RealPresence Collaboration Server (RMX) 1500 Hardware Guide
Polycom, Inc. 16
Telescopic Rail Runner Assembly for RealPresence Collaboration Server (RMX)
1500
Before installing the telescopic rail runners in the rack, make sure that the kit has the following parts.
Rail Runners Kit Contents
Part/Kit no. Item Item
no.
Item Sample Item
Quantity
ASY2716A-L0
Rail runner Rail Runner End Views:
Left rail runner (two types
available: item (a) with or (b)
without rail runner clip
Note: The rail runner clip is
designed to attach and clip
onto the chassis runner frame.
11
Right rail runner (two types
available: with or without rail
runner clip)
Note: The rail runner clip is
designed to attach and clip
onto the chassis runner frame.
2 See Fig.1-1 1
Rack spacer
assembly kit
Rack spacer 3 Front & Rear 4
Flat head screw - M5*10mm 4 8

RealPresence Collaboration Server (RMX) 1500 Hardware Guide
Polycom, Inc. 17
Assembling the Telescopic Rail Runner
To assemble the Telescopic Rail Runner:
1Determine the location of the RMX on the rack:
Allow for a 1U gap above and below the system for ventilation.
Use the Rack Spacer (3) to predetermine its position on the rack post, making sure that square
studs of the spacer fit into the rack post’s square/rounded mounting holes. Mark the spacer’s
location on the rack post. Repeat this process for the 3 remaining vertical posts ensuring that the
system can be horizontally seated.
Rail runner
assembly kit
Flat head screw - M3*8mm 5 4
Flat washer M3 6 4
Nut spring M3 7 4
RMX chassis
assembly kit
Pan head screw - M5*12mm 8 2
Flat washer M5 9 2
Rack Rail Runners require a minimum of 48cm and a maximum of 80cm within the rack for
installation.
Rail Runners Kit Contents
Part/Kit no. Item Item
no.
Item Sample Item
Quantity

RealPresence Collaboration Server (RMX) 1500 Hardware Guide
Polycom, Inc. 18
Front view of RMX Rail Runner Assembly
2Position the Rack Spacer (3) onto the marked rack post together with left rack rail runner (1) and
fasten the flat head screws 3*10m (4) as shown in the following figure.
Detail of Front Rack Spacer Assembly (left rail runner is shown here) for all RMX types
On the RMX1500 the center hole on the Rack Spacer must be left clear as it is required for
fixing the RMX to the rack post.

RealPresence Collaboration Server (RMX) 1500 Hardware Guide
Polycom, Inc. 19
3Adjust the telescopic rack rail runner to the rack opening and mount it onto the marked position of
the rear post as described in step 2.
Detail of Rear Collaboration Server (RMX) 1500 Rack Spacer Assembly
4Repeat steps 2 and 3 for the right rack rail runner.
5Install the flat head screw (item 5), flat washer (item 6) and nut spring (item 7) in
the middle of the telescopic rack rail runner for added stability, as shown below.
Detail of Left Rail Runner (front internal view)
6Repeat step 5 for the right rack rail runner.
The number of screws to install depends on the rack width.

RealPresence Collaboration Server (RMX) 1500 Hardware Guide
Polycom, Inc. 20
Collaboration Server (RMX) 1500 Bolt Installation
Mounting the RealPresence Collaboration Server (RMX) 1500 on a Shelf
Observe the following procedure to mount the RealPresence Collaboration Server (RMX) 1500 on a shelf.
To mount the RealPresence Collaboration Server (RMX) 1500 on a shelf:
1Install the shelf supplied by the rack manufacturer in the rack.
2Mount the RMX on the shelf.
3Fasten the RMX to the rack with screws through the four holes in the RMX’s front mounting brackets.
Connecting the RealPresence Collaboration Server (RMX) 1500 to a
Power Source
The following restrictions apply to the conductors and connectors that may be used to ground the unit when
rack mounted:
●When using bare conductors, they must be coated with an appropriate antioxidant compound before
crimp connections are made. Tinned, solder-plated or silver-plated connectors do not have to be
prepared in this manner.
●The same bolt assemblies should not secure multiple connectors.
