Polygroup TGC0M6010C00 User manual

*Electrical Rating For The Tree
(For Indoor Use Only)
4.76A 120V, 60Hz
Fig.
Top view Side view
Fig. C
SNOITCURTSNIYLBMESSA ANIHCNIEDAM
MODEL #: TGC0M6010C00 2016 TREE LETTER "S"
B - Tree and Light Assembly
3. Each tree section is numbered with a tag. Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective
cap before inserting into the assembled stand. Make sure the pole is firmly inserted and secured into
the stand.
5. Remove the protective cap from the upper section(s) and insert into the lower section(s). Continue until
the tree top is inserted.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all
wires are free of branch hinges.
7. (For pre-lit trees only) Connect the plug(s) securely to the extension cord(s) as per the color labels
indicated in Fig. B and insert the green label extension cord plug into the wall outlet. Your entire tree
should now be lit. If some bulbs do not light or flickers, search for any loose plugs and/or broken, loose
or missing bulbs. Replace bulbs promptly in order to maintain the performance and life expectancy of
your pre-lit tree.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from
the pole and fan out one to the right, one to the left and one at the center of the main stem. (See Fig. C)
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from Polytree®! Carefully follow the instructions below
on how to quickly and easily set up your new tree.
Insert Yellow Label
Plugs Into Yellow
Labeled Extension Cord
Insert Blue Label
Plugs Into Blue
Labeled Extension Cord
bel
d
nsion Cord
Insert
Green Label
Plug Into Wall
Outlet
Section 4
Section 3
Section 2
Section 1
Section 5
1. Pull apart the legs of the stand so that
they are snapped into an x-shape, place the
tree stand on a level surface.
2. When inserting the bottom section of the tree
into the assembled stand, insert and turn the
eyebolts into the stand and tighten until the
tree pole is firmly secured.
To close the stand, remove the eyebolts, press
the metal button and fold the legs together.
Fig. A - Tree Stand Assembly Eye Bolt
Click
Eye Bolt
Insert Red La
Plugs Into Re
Labeled Exte
Sku # 5064571 & 220293

ASSEMBLY INSTRUCTIONS MADE IN CHINA
1. Remove all ornaments and decorations. For pre-lit trees, first unplug extension cord from the wall
outlet and then disconnect light extension cord between each section of the tree.
2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to
remove from section below and fold all branches toward the pole.
3. In case of difficulty separating the tree pole (trunk), apply a small amount of lubricant at the joint and
rotate the upper pole in both directions. Lift up the upper pole again.
4. Continue by gently lifting straight up each section(s) from the section below and fold all branches
toward the pole until the bottom section is removed from the tree stand.
5. Carefully place all tree sections into shipping box and tape it shut.
6.When not in use, please store your tree in a cool, dry place away from sunlight. Exposing your tree to
excessive heat or humidity may damage your tree.
STORAGE INSTRUCTIONS
For Pre-lit Trees, If The Tree Does Not Illuminate
1. Please check to make sure that all plugs are properly connected according to the color labels indicated
in Fig.B and the power cord is plugged into the wall outlet. Refer to assembly guide for instructions. (If
the tree comes with a foot pedal, try stepping on the on/off button).
2. Please check for blown fuses at the light string plugs and power cord plug. Replace as needed.
Note: Please make sure to use appropriate replacement fuses as indicated on the light string plug and
power cord plug.
3. Please check for loose, broken or missing light bulbs and replace as needed.
Loose Hinge Pin
1. Extra hinge pins are included for repairing the hinges. Place the branch into the slot of the bracket.
2. Insert a new hinge pin through the hole and secure using the retainer washer. (See Fig. D)
TROUBLE SHOOTING TIPS
Each tree includes hinge pins/washers, and for pre-lit
trees spare bulbs and fuses are also included. If extra
parts are needed, please contact our customer service
center.
SPARE PARTS
CUSTOMER SERVICE FOR CHRISTMAS TREES
For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact
us at 1-888-919-0070 or visit our website at www.polygroup.com. One of our customer service
representatives will be happy to assist you.
TREE ID# IS LOCATED ON END PANEL OF BOX.TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.
Customer Name:
Address:(No P.O. Boxes)
City & State:
Zip Code:
Day Phone:
Date Purchased:
Tree ID#:
Tree UPC#:
Store Purchased:
Specify Problem:
9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform
look. Shift branches to fill any gaps.Your Christmas tree is now complete and ready to be decorated.
