PA30BI-H
POWER AMPLIFIER USER MANUAL
VERSION: PA30BI-H-AE-1.20
DATE: MARCH 2021
This manual is the publication of PONOVO POWER CO.,LTD. Any form of copy should
obtain the consent of it.
The manual represents the technology status at publication time. The product information,
directions and all technical specifications do not have contract binding. The company
subjects to changing the technical and configuration information without notice. The
company is not responsible for possible errors occurred in the manual.

PA30Bi-H Power Amplifier User Manual
2
Contents
1. Safety Precaution..................................................................................................3
2. General..................................................................................................................9
3. Main Technical Specifications .............................................................................10
3.1 Power Supply ................................................................................................10
3.2 Use Environment...........................................................................................10
3.3 Dimension and Weight .................................................................................. 11
3.4 Current Amplifier ...........................................................................................12
3.5 Voltage Amplifier............................................................................................13
3.6 Digital Display of Voltage/Current Output .....................................................14
4. Function and Features of Current Amplifier ........................................................15
4.1 Basic Principle...............................................................................................15
4.2 Function.........................................................................................................15
4.3 High Power Output........................................................................................16
5. Function and Features of Voltage Amplifier ........................................................18
5.1 Basic Principle...............................................................................................18
5.2 Function.........................................................................................................18
6. Panels..................................................................................................................20
6.1 Front Panel....................................................................................................20
6.2 Rear Panel ....................................................................................................22
6.3 Terminal Definition.........................................................................................23
7. How to Use Amplifier...........................................................................................25
7.1 Wiring ............................................................................................................25
7.2 Power On ......................................................................................................25
7.3 Simulation Current/Voltage Output ...............................................................25
7.3.1 Amplifier Output ..................................................................................25
7.3.2 High power output...............................................................................26
7.3.3 Voltage/Current Output Display ..........................................................26
7.4 Amplifier Off ...................................................................................................26
8. Amplifier Inspection.............................................................................................27
9. Cables .................................................................................................................28
10. PAP-02B Standard Chassis and Power Control Device..............................29
10.1 Standard Chassis........................................................................................29
10.2 PAP-02B Power Control Device..................................................................29
10.3 Operation.....................................................................................................30

PA30Bi-H Power Amplifier User Manual
3
1. Safety Precaution
Read User Manual before operation.
1. Check carefully all buttons are positioned correctly before startup.
1) Pause button in correct position in pressed state.
2) ON/OFF in OFF state.
3) Not press high power button (High power indicator in OFF state)
2. Main supply capacity should meet the requirement; otherwise it will affect output
power of amplifier during high current output.
3. Handle the amplifier with great care and follow the symbols on the package: fragile,
handle with care, top (an arrow pointing up), keep dry and protect from shaking.
4. Generally it’s not necessary to depress high power button (high power button light
should be off also).
5. Never operate live signal and load wires with voltage or current output to protect the
safety of equipment and personnel.
6. In case the power outlet for powering up the amplifier does not have protective ground
customer must connect the ground socket to the protective ground at the test site
7. The voltage output of over 36V is considered as dangerous and care must be taken
8. It’s not allowed to feed external voltage into the voltage/current output sockets
9. It’s not allowed to feed external current into the current/voltage output sockets
10. Disconnect the external circuit from the relay to avoid any influence to the test
11. Do not block the ventilation outlets
12. Avoid the equipment to be wet by rain

PA30Bi-H Power Amplifier User Manual
4
13. Do not switch-on and operate the equipment in the place having explosive gas or
water vapor.
14. The 500V dangerous voltage can be in the equipment and please don’t remove the
cover by yourself
15. Please contact the manufacture for any maintenance
16. The guarantee will become invalid if kit is opened by the customer.

PA30Bi-H Power Amplifier User Manual
5
For Your Safety Please Note
This symbol indicates potential hazards by electrical voltages/currents caused by, for
example, wrong connections, short-circuits, technically inadequate or faulty equipment or
by disregarding the safety notes of the following sections.
Use Proper Power Cord
Only the power cord designed for the instrument and authorized by local country could be
used.
Ground The Instrument
The instrument must be grounded safely with the supplied ground cable in testing.
Observe All Terminal Ratings
To avoid fire or shock hazard, observe all ratings and markers on the instrument and
check your manual for more information about ratings before connecting.
Do not Assemble/Disassemble the Instrument without
Authorization
The instrument should be assembled and or disassembled by professional engineers;
users are not allowed to perform related operations except for some possible
replacements in this manual.

PA30Bi-H Power Amplifier User Manual
6
Do not Move or Maintain the Instrument When it is Powered
On
To avoid personnel injuries, any position adjustment, maintenance or parts replacement
are forbidden when instrument is on.
Use Proper Fuse
Please use the specified fuses.
Do Not Operate With Suspected Failures
If you suspect damage occurs to the instrument, have it inspected by qualified service
personnel before further operations. Any maintenance, adjustment or replacement
especially to circuits or accessories must be performed by authorized personnel.
Keep Well Ventilation
Inadequate ventilation may cause increasing of temperature or damages to the device.
So please keep well ventilated and inspect the intake and fan regularly.
Do Not Operate in Wet Conditions
In order to avoid short circuiting to the interior of the device or electric shock, please do
not operate in a humid environment.
Do Not Operate in an Explosive Atmosphere
In order to avoid damages to the device or personal injuries, it is important to operate the

PA30Bi-H Power Amplifier User Manual
7
device away from an explosive atmosphere.
Keep Product Surfaces Clean and Dry
To avoid the influence of dust and/or moisture in air, please keep the surface of device
clean and dry.
Operate the Instrument in a Suitable Environment
The best condition for optimal measurement is: 5 ℃to 40℃; less than 2 ℃/hour
changing, 20% to 80% RH and the instrument should not be placed towards the air outlet.
Electrostatic Prevention
Operate in an electrostatic discharge protective area environment to avoid damages
induced by static discharges. Always ground both the internal and external conductors of
the cable to release static before connecting.
Proper Use of Solvent
Please use the solvent in compliance with instructions specified in its supplier. If
necessary, wear protective clothing, gloves and glasses to avoid any injuries.
Handling Safety
Please handle with care during transporting to avoid damages to surface, panel and parts
resulting from the falling from your hand.

PA30Bi-H Power Amplifier User Manual
8
NOTE: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.

PA30Bi-H Power Amplifier User Manual
9
2. General
Real time digital simulator technology has broad applications in power system test and
research nowadays. As the computer technology and the research of power system
simulator are improving, several different kinds of digital simulator systems are coming
out continuously, such as RTDS, EDF, TEQSIM, etc. However, power amplifier, as the
final output in simulator system, will always be the most important part of full digital
simulator or digital-analog simulator, no matter how they have changed.
The power amplifier for digital simulator in power system is required to have high linearity,
quick response, be available to all kinds of capacitive, inductive and resistive loads.
Generally power amplifier consists of two types of amplifiers: linear power amplifier and
switching power amplifier. The linear power amplifier has the strengths of high linearity,
quick response, high accuracy, good electromagnetic compatibility and the weakness of
bad performance in high current and high power cases. The switching power amplifier is
quite fit in high current, high power devices with its strength of high efficiency, but it’s weak
in linearity, small signal noise, DC offset, drift, transient response, load driving capability
aspects, which are very difficult to fix.
PA30Bi-H can produce 3-phase current, with maximum RMS phase current of 30A and
maximum output power of 450VA, and 4-phase voltage, with maximum RMS phase
voltage of 250V and maximum output power of 75VA.

PA30Bi-H Power Amplifier User Manual
10
3. Main Technical Specifications
3.1 Power Supply
Power supply 3 phase 380V AC 50/60Hz
Power capacity
1800VA
Note:
The instant current while running the amplifier is 7-10 times of the rated current, as a
result, the power supply should be more than 10 times of the total power.
It is suggested the total power supply by PAP02 should be not less than 5 times of the
total power of all the amplifiers installed on the same panel
It is suggested power on each amplifier on the same panel with interval 5 seconds.
3.2 Use Environment
Operating temperature: 25 deg±10 deg
Storage Temperature: -25 deg—+70 deg
Related humidity: 20%RH—85%RH
Pressure: 86 kPa—106kPa
EMC (Emission) IEC-61000-3-2/3
EMC (immunity) IEC-61000-4-2/3/4/5/6/11
Safety IEC/EN 61010-1:2010
UL 61010-1:2012

PA30Bi-H Power Amplifier User Manual
11
CAN/CSA-C22.2 No. 61010-1-12
Surrounding conditions: No dust, vibration or serious electromagnetic field interferes.
The equipment is not recommended to be used out of laboratory.
Avoid the equipment to be used online out of laboratory in severe environment.
3.3 Dimension and Weight
Dimension: 4U
Weight: 25kg

PA30Bi-H Power Amplifier User Manual
12
3.4 Current Amplifier
Current output 3 X 0~30A RMS
Max. output power >450VA(30A output)
Input signal-Analog, Gain
Standard: 0~7.07V RMS (±10Vpek), Gain: 4.5A/V
Option: 0~11.31V RMS (±16Vpek), Gain: 3A/V
Input signal-Digital (optional) Support Aurora protocol
Current accuracy 0.2% (0.5-30A)
Current typical accuracy <0.1%
Differential input impedance 20k
Harmonic distortion ratio ≤0.2%
Linearity ≤0.2%
Phase accuracy 0.2°
Frequency range DC-5kHz±1dB
Step response < 20us
Input/output delay < 20us

PA30Bi-H Power Amplifier User Manual
13
3.5 Voltage Amplifier
Voltage output 4 X 0~250V RMS
Max. output power >75VA(250V output)
Input signal, Gain
Standard: 0~7.07V RMS (±10Vpek), Gain: 40V/V
Option: 0~11.31V RMS (±16Vpek), Gain: 24V/V
Voltage accuracy <0.2%(5V-250V)
Voltage typical accuracy <0.1%
Differential input impedance 20k
Harmonic distortion ratio ≤0.1%
Linearity ≤0.2%
Phase accuracy 0.2°
Frequency range DC-3kHz±1dB
Step response <80us
Input/output delay <80us

PA30Bi-H Power Amplifier User Manual
14
3.6 Digital Display of Voltage/Current Output
The RMS of current or voltage output can be displayed in real-time on the panel.

PA30Bi-H Power Amplifier User Manual
15
4. Function and Features of Current
Amplifier
4.1 Basic Principle
This current amplifier is a kind of linear current power amplifier targeting at the CT
characteristic of power system, with strengths of high accuracy, high current and quick
response, which consists of below parts mainly:
1) High-speed differential input circuit for amplifier;
2) Current power amplifier module;
3) Detection and alarm circuit: each amplifier has an output distortion detection
circuit.
4) Protection circuit, by which the amplifier can be terminated when its temperature is
too high and will resume working when it is cooled down to a reasonable degree.
5) Cooling fan. When the temperature of the amplifier is quite low, the fan will work at
low speed for prolonging the service life and reducing the operation noise of the fan.
4.2 Function
1) The differential input circuit can reduce the influence of the common mode noise to
make it possible that use long wires to connect across the amplifier and signal source,
which will reduce mutual effects between all amplifiers producing high currents to
guarantee the operation safety of the simulator.

PA30Bi-H Power Amplifier User Manual
16
2) When open circuit or waveform distortion occurs in current output, the alarm light of
current open circuit on the front panel will turn on.
3) Pause control function (PAUSE). The pause button on the front panel can cut off the
signal input of the amplifier, pressing the pause button to pause the output of the amplifier.
And resume the output after pressing Pause again.
4) When the overheat protection is activated, the input of the amplifier will be terminated
and the “Overheat” alarm light on the front panel will be on.
4.3 High Power Output
With high power control button depressed, after several seconds, the high power control
button light will turn on. By then the current amplifier can improve 20% of output power.
This button can be used in case there have high current output needed and heavy load
applied.
Note:
1. Generally it’s not necessary to activate the high power output function, because it may
cause extra heat generated from amplifier.
2. High power output function must be inactivated as soon as the job was done. Never let
amplifier stay in high power output state for a long time.
3. Never apply the high power output function when output terminals are directly short
connected.

PA30Bi-H Power Amplifier User Manual
17
4. Never apply the high power output function when DC current is produced.
5. Never switch to/off the high power output function when amplifier is producing any
output.

PA30Bi-H Power Amplifier User Manual
18
5. Function and Features of Voltage
Amplifier
5.1 Basic Principle
This voltage power amplifier is a linear voltage power amplifier specially targeting at the
PT characteristics of power system with the strengths of high accuracy, high voltage and
quick response, which consists of below parts mainly:
1) High-speed differential input circuit for amplifier;
2) High-performance voltage power amplifier module;
3) Distortion detection and alarm circuit. Each amplifier has the overload or output
distortion detection circuit. When the overload or short-circuit situation disappears, the
amplifier will resume to work automatically.
4) Temperature protection circuit. It will terminate the amplifier as soon as the
temperature of the amplifier reaches dangerous degree and will let the amplifier resume
to work automatically when it has been cooled down to a reasonable level.
5) Temperature-controlled fan. Fan will work at low speed if amplifier temperature is
certain low, which is benefit for prolonging its service life and reducing working noise.
5.2 Function
1) The differential input circuit can reduce the influence of the common mode noise to
make it possible that use long wires to connect across the amplifier and signal source,

PA30Bi-H Power Amplifier User Manual
19
which will reduce mutual effects between all amplifiers during output to guarantee the
operation safety of the simulator.
2) Automatic output voltage distortion and overload detection circuit, which is quite
capable to protect voltage amplifier against output overload or short-circuit fault. When
the overload and short circuit situation disappears, the amplifier can resume to work
automatically. If overload or short-circuit occurs, the amplifier will be terminated
automatically and the overload alarm light on the front panel will turn on.
3) Pause control function (PAUSE). The pause button on the front panel can cut off the
signal input of the amplifier, pressing the pause button to pause the output of the amplifier.
And resume the output after pressing Pause again.
4) When the overheat protection is activated, the input of the amplifier will be terminated
and the “Overheat” alarm light on the front panel will be on.

PA30Bi-H Power Amplifier User Manual
20
6. Panels
6.1 Front Panel
1. Power Switch:Power on/off
2. Display: Show the current/ voltage value (The current output is showing on above
picture.)
3. Indicator: The working status will be showing.
4. Voltage/current display: The current or voltage output will be shown based on the
switch.
5. Current high power: Press it and light in red to output high power.
6. Voltage high output: Press it and light in red to output high voltage 0~250V. Normally
the output is 0~120V.
7. Pause button: Press it and light in red. The current and voltage output will be paused.
The output will be resumed after press Pause button again.
8
＊
. Current output: It is connected with the current input of the test object.
9
＊
. Voltage output: It is connected with the voltage input of the test object.
