Ponovo PAV120Bi User manual

1
PONOVO POWER CO., LTD
No. 139 Jinghai Third Road, BDA, Beijing, China, 100176
Office
TEL. [phone]
E-Mail
[e-mail]
Website
www.relaytest.com / www.ponovo.com.cn
PAV120Bi
POWER AMPLIFIER USER MANUAL
VERSION: PAV120Bi-AE-1.50
D AT E : MARCH 2021
This manual is the publication of PONOVO POWER CO.,LTD. Any form of copy should
obtain the consent of it.
The manual represents the technology status at publication time. The product information,
directions and all technical specifications do not have contract binding. The company
subjects to changing the technical and configuration information without notice. The
company is not responsible for possible errors occurred in the manual.

PAV120Bi Power Amplifier User Manual
2
Content
1. Safety Precaution...........................................................................................................................3
2. General ............................................................................................................................................9
3. Main Technical Specifications.....................................................................................................10
3.1 Power Supply .....................................................................................................................10
3.2 Use Environment ...............................................................................................................10
3.3 Dimension and Weight......................................................................................................11
3.4 Voltage Amplifier................................................................................................................11
4. Functions and Features...............................................................................................................12
4.1 Basic Principle....................................................................................................................12
4.2 Functions ............................................................................................................................13
5. Panels ............................................................................................................................................14
5.1 Front Panel .........................................................................................................................14
5.2 Rear Panel..........................................................................................................................15
5.3 Terminal definition .............................................................................................................17
6. How to Use Amplifier ...................................................................................................................18
6.1 Wiring ..................................................................................................................................18
6.2 Power On............................................................................................................................18
6.3 Simulation Voltage Output ...............................................................................................18
6.3.1 Amplifier Output ......................................................................................................18
6.3.2 Voltage Output Display ..........................................................................................19
6.4 Amplifier Off........................................................................................................................19
7. Amplifier Inspection......................................................................................................................20
8. Cables............................................................................................................................................21
9. PAP-02B Standard Chassis and Power Control Device.........................................................22
9.1 Standard Chassis ..............................................................................................................22
9.2 PAP-02B Power Control Device......................................................................................22
9.3 Operation ............................................................................................................................23

PAV120Bi Power Amplifier User Manual
3
1. Safety Precaution
Read User Manual before operation.
1. Check carefully all buttons are positioned correctly before startup.
1) Pause button in correct position in pressed state.
2) ON/OFF in OFF state.
3) Not press high power button (High power indicator in OFF state)
2. Main supply capacity should meet the requirement; otherwise it will affect output power
of amplifier during high current output.
3. Handle the amplifier with great care and follow the symbols on the package: fragile,
handle with care, top (an arrow pointing up), keep dry and protect from shaking.
4. Generally it’s not necessary to depress high power button (high power button light
should be off also).
5. Never operate live signal and load wires with voltage or current output to protect the
safety of equipment and personnel.
6. In case the power outlet for powering up the amplifier does not have protective ground
customer must connect the ground socket to the protective ground at the test site
7. The voltage output of over 36V is considered as dangerous and care must be taken
8. It’s not allowed to feed external voltage into the voltage/current output sockets
9. It’s not allowed to feed external current into the current/voltage output sockets
10. Disconnect the external circuit from the relay to avoid any influence to the test
11. Do not block the ventilation outlets
12. Avoid the equipment to be wet by rain
13. Do not switch-on and operate the equipment in the place having explosive gas or water

PAV120Bi Power Amplifier User Manual
4
vapor.
14. The 500V dangerous voltage can be in the equipment and please don’t remove the
cover by yourself
15. Please contact the manufacture for any maintenance
16. The guarantee will become invalid if kit is opened by the customer.

PAV120Bi Power Amplifier User Manual
5
For Your Safety Please Note
This symbol indicates potential hazards by electrical voltages/currents caused by, for
example, wrong connections, short-circuits, technically inadequate or faulty equipment or by
disregarding the safety notes of the following sections.
Use Proper Power Cord
Only the power cord designed for the instrument and authorized by local country could be
used.
Ground The Instrument
The instrument must be grounded safely with the supplied ground cable in testing.
Observe All Terminal Ratings
To avoid fire or shock hazard, observe all ratings and markers on the instrument and check
your manual for more information about ratings before connecting.
Do not Assemble/Disassemble the Instrument without
Authorization
The instrument should be assembled and or disassembled by professional engineers; users
are not allowed to perform related operations except for some possible replacements in this
manual.

PAV120Bi Power Amplifier User Manual
6
Do not Move or Maintain the Instrument When it is Powered On
To avoid personnel injuries, any position adjustment, maintenance or parts replacement are
forbidden when instrument is on.
Use Proper Fuse
Please use the specified fuses.
Do Not Operate With Suspected Failures
If you suspect damage occurs to the instrument, have it inspected by qualified service
personnel before further operations. Any maintenance, adjustment or replacement
especially to circuits or accessories must be performed by authorized personnel.
Keep Well Ventilation
Inadequate ventilation may cause increasing of temperature or damages to the device. So
please keep well ventilated and inspect the intake and fan regularly.
Do Not Operate in Wet Conditions
In order to avoid short circuiting to the interior of the device or electric shock, please do not
operate in a humid environment.
Do Not Operate in an Explosive Atmosphere
In order to avoid damages to the device or personal injuries, it is important to operate the
device away from an explosive atmosphere.

PAV120Bi Power Amplifier User Manual
7
Keep Product Surfaces Clean and Dry
To avoid the influence of dust and/or moisture in air, please keep the surface of device clean
and dry.
Operate the Instrument in a Suitable Environment
The best condition for optimal measurement is: 5 ℃to 40℃; less than 2 ℃/hour changing,
20% to 80% RH and the instrument should not be placed towards the air outlet.
Electrostatic Prevention
Operate in an electrostatic discharge protective area environment to avoid damages
induced by static discharges. Always ground both the internal and external conductors of the
cable to release static before connecting.
Proper Use of Solvent
Please use the solvent in compliance with instructions specified in its supplier. If necessary,
wear protective clothing, gloves and glasses to avoid any injuries.
Handling Safety
Please handle with care during transporting to avoid damages to surface, panel and parts
resulting from the falling from your hand.

PAV120Bi Power Amplifier User Manual
8
NOTE: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.

PAV120Bi Power Amplifier User Manual
9
2. General
The power amplifier for digital simulator in power system is required to have high linearity,
quick response, be available to all kinds of capacitive, inductive and resistive loads.
Generally power amplifier consists of two types of amplifiers: linear power amplifier and
switching power amplifier. The linear power amplifier has the strengths of high linearity,
quick response, high accuracy, good electromagnetic compatibility and the weakness of bad
performance in high current and high power cases. The switching power amplifier is quite fit
in high current, high power devices with its strength of high efficiency, but it’s weak in
linearity, small signal noise, DC offset, drift, transient response, load driving capability
aspects, which are very difficult to fix.
PAV120Bi is specially designed for R&D of power system simulation. It is adapt to various
capacitive and inductive load. There are 6-phase voltage outputs with max. 120VRms per
phase and max. output power 60VA..

PAV120Bi Power Amplifier User Manual
10
3. Main Technical Specifications
3.1 Power Supply
Power supply
3-phase 380V AC
50/60Hz
Power capacity
750VA
3.2 Use Environment
Operating temperature: 25 deg±10 deg
Storage Temperature: -25 deg—+70 deg
Related humidity: 20%RH—85%RH
Pressure: 86 kPa—106kPa
EMC (Emission) IEC-61000-3-2/3
EMC (immunity) IEC-61000-4-2/3/4/5/6/11
Safety IEC/EN 61010-1:2010
UL 61010-1:2012
CAN/CSA-C22.2 No. 61010-1-12
Surrounding conditions: No dust, vibration or serious electromagnetic field interferes.
The equipment is not recommended to be used out of laboratory.
Avoid the equipment to be used online out of laboratory in severe environment.

PAV120Bi Power Amplifier User Manual
11
3.3 Dimension and Weight
Dimension: 4U
Weight:20kg
3.4 Voltage Amplifier
Voltage output 6x0～120V RMS
Max. output power ＞60VA (120V output)
Input signal-Analog, Gain
Standard: 0~7.07V RMS (±10Vpek), Gain: 20V/V
Option: 0~14.14V RMS (±20Vpek), Gain: 10V/V
Input signal-Digital (optional)
Support Aurora protocol communication
Voltage accuracy
<0.1%(5V-120V)
Voltage typical accuracy <0.05%
Differential input impedance
20k
Harmonic distortion ratio
≤
0.1%
Linearity
≤
0.1%
Phase accuracy
0.2
°
Frequency range
DC-5kHz
±
1dB
Step response
<20us
Input/output delay
<20us

PAV120Bi Power Amplifier User Manual
12
4. Functions and Features
4.1 Basic Principle
PAV120Bi consists of the below parts mainly:
1) High-speed differential input circuit for amplifier;
2) High-performance voltage power amplifier module;
3) Distortion detection and alarm circuit. Each amplifier has the overload or output
distortion detection circuit. When the overload or short-circuit situation disappears, the
amplifier will resume to work automatically.
4) Temperature protection circuit. It will terminate the amplifier as soon as the
temperature of the amplifier reaches dangerous degree and will let the amplifier resume to
work automatically when it has been cooled down to a reasonable level.
5) Temperature-controlled fan. Fan will work at low speed if amplifier temperature is
certain low, which is benefit for prolonging its service life and reducing working noise.

PAV120Bi Power Amplifier User Manual
13
4.2 Functions
1) The differential input circuit can reduce the influence of the common mode noise to make
it possible that use long wires to connect across the amplifier and signal source, which will
reduce mutual effects between all amplifiers during output to guarantee the operation safety
of the simulator.
2) Automatic output voltage distortion and overload detection circuit, which is quite capable
to protect voltage amplifier against output overload or short-circuit fault. When the overload
and short circuit situation disappears, the amplifier can resume to work automatically. If
overload or short-circuit occurs, the amplifier will be terminated automatically and the
overload alarm light on the front panel will turn on.
3) Pause control function (PAUSE). The pause button on the front panel can cut off the
signal input of the amplifier, pressing the pause button to pause the output of the amplifier.
And resume the output after pressing Pause again.
4) When the overheat protection is activated, the input of the amplifier will be terminated and
the “Overheat” alarm light on the front panel will be on.

PAV120Bi Power Amplifier User Manual
14
5. Panels
5.1 Front Panel
1. Switch: Power On/Off
2. Display: Show the voltage value
3. Overload indicators: Each indicator is related to each output.
4. Pause/Overtemp indicator/button: Press it for pause the output and light on; Or
overtemperature light on.
5
＊
. Voltage Output: It is connected with the voltage input of the test object
＊:
There are voltage output in the front and rear panels. Voltage output on either panel can
be configured.

PAV120Bi Power Amplifier User Manual
15
5.2 Rear Panel
6
7
13
8
12
11
10
9
6. Power: Power supply socket
7
＊
. Voltage Output:It is connected with the voltage input of the test object
8. Gain: There are two options for choice and the related indicators for Gain will be on in
front and rear panels.
9
＊＊
. Ud out: Select the suitable Ud output way.
10
＊＊＊
. LPF: Low-pass filter
Test: It is used for calibration purpose.
11. Earth ground: It should be grounded with earth during testing.
12. Voltage Signal Input: Please refer to the terminal definition below.
13. Control signal Input: Please refer to the terminal definition below.
＊:
There are both voltage output in the front and rear panels. Either of voltage output can be
configured.

PAV120Bi Power Amplifier User Manual
16
＊＊:
Ud out:
Normal: It outputs normally based on the input signal.
3U0: It outputs zero sequence voltage based on the UA+UB+UC calculation result.
＊＊＊:
LPF: Low-pass filter. A low-pass filter (LPF) is a filter that passes signals with a
frequency lower than a selected cutoff frequency and attenuates signals with frequencies
higher than the cutoff frequency. The output response time is delayed around 200us.
Please refer to the Terminal Definition below for more details.
Test: It is used for calibration purpose. When the calibration signal is input, all the outputs
will be the same for calibration convenience.
Please refer to the Terminal Definition below for more details.

PAV120Bi Power Amplifier User Manual
17
5.3 Terminal definition
Voltage Signal Input
Channel
UA
UB
UC
NC
+
-
+
-
+
-
Function
Definition
UA signal
input +
UA signal
input -
UB signal
input +
UB signal
input -
UC signal
input +
UC signal
input -
/
/
Channel
UD
UE
UF
NC
+
-
+
-
+
-
Function
Definition
UD signal
input +
UD signal
input -
UE signal
input +
UE signal
input -
UF signal
input +
UF signal
input -
/
/
Control Signal Input
Channel
0
1
2
3
4
5
6
7-
8
9
A
B
C
Definition
Low
pass
filtering
+12V
Low
pass
filtering
-12V
NC
Te s t
signal
input
+
Te s t
signal
GND
Te s t
control
+12V
Pause
control
+12V
Pause
control
-12V
NC

PAV120Bi Power Amplifier User Manual
18
6. How to Use Amplifier
6.1 Wiring
The amplifier voltage input signal terminals should be connected with the simulation
system’s D/A output signal correctly.
Please refer to the Terminal Definition for detail.
Pay attention that the shielded layer at simulation system should be grounded.
6.2 Power On
Check the power supply is normal before energizing the amplifier and the polarity of input
signal is correct. When all things are ready, turn on the power of PAP02 first and then turn on
the power on amplifier panel. The power light will be on, the run light will flash and the
amplifier will enter into its normal working status.
6.3 Simulation Voltage Output
See the panel of terminals in paragraph Terminal Definition for details.
6.3.1 Amplifier Output
Press the pause button on the panel or operate the remote control to send the pause signal,
connect the voltage output terminals to corresponding terminals of the test object

PAV120Bi Power Amplifier User Manual
19
respectively, and then inactivate the pause function and input the simulation signal, the
amplifier will enter into simulation status.
6.3.2 Voltage Output Display
Voltage output will be display in real time on the front panel.
6.4 Amplifier Off
After all testing is finished, please terminate the simulator signal input, press Pause button
and turn off the power of the amplifier.

PAV120Bi Power Amplifier User Manual
20
7. Amplifier Inspection
All amplifiers have passed strict tests and high power output running test before delivery.
The test items include function test, linearity, load stability, total harmonic distortion,
maximum output power, amplitude and frequency characteristic, input/output delay, step
response, system phase precision tests. Refer to Factory Inspection and Acceptance Report
for detail.
Please refer to Factory Test Report for the detailed information.
