POP UP MI TOWER STAIRS User manual

ASSEMBLY GUIDE
FOR MI TOWER STAIRS
[phone] [e-mail] popupproducts.co.uk
MI TOWER
STAIRS

CONTENTS
CONTENTS
INTRODUCTION
KNOW YOUR MI TOWER STAIRS
KNOW YOUR MI TOWER STAIRS’S COMPONENTS
KNOW YOUR KIT LIST AND SPECIFICATIONS
KNOW YOUR STORAGE AND TRANSPORT PACK
REGISTRATIONS
1
2
3
4-5
6
7
8


BEFORE YOU START
GETTING STARTED



9
10
11
12
13-14
15-17
18
ASSEMBLY GUIDE
FOR MI TOWER STAIRS

INTRODUCTION
Mi TOWER STAIRS is an access tower system complying with BS 1139 Part 6, EN 1004:2004 and Work
at Height Regulations, with vertical ladder access, designed for a maximum platform loading of 150kg.
Platform heights are 2.2m to 4.7m internal and external.
Tower designation - EN1004-3-4.7/4.7-D
Our priority is to help ensure the safe operation of our products, so please pay particular attention to the
safety tips on pages 9 and 10.
We want you to enjoy the safe and responsible use of your Mi TOWER STAIRS with the minimum of fuss
and this guide is designed to get you up and running as quickly and as safely as possible.
We recommend that you read this guide prior to assembling and using Mi TOWER STAIRS.
Scan this QR code to view the Mi TOWER STAIRS on our website.
Visit PASMA for further reference.
www.pasma.co.uk/training/towers-on-stairs-course
www.popupproducts.co.uk
Page 2

KNOW YOUR Mi TOWER STAIRS
Page 3
1
2
3
4
4 RUNG FRAME
TOE BOARD SET
2 RUNG FRAME
EASY-LOCK STABILISER
PARTS LISTING
5
6
7
8


GUARDRAIL BRACE PANEL


KNOW YOUR Mi TOWER STAIRS’S COMPONENTS
Page 4
1 GUARDRAIL BRACE PANEL
Hooks are tted to the guardrail brace panels and each has an
automatic locking jaw which is released by simply moving the jaw’s
trigger. The hook must only be attached to the frame with the
opening facing outward. Attachment with the jaw’s opening
facing inward will not fully protect the user if lent upon and
may cause serious injury or death. Always ensure that each
hook is positively locked in position before using your Mi TOWER
STAIRS.

The Easy-Clip frame clip’s pin locates into a retaining hole in the
frames to lock tower sections together when placed one on top of
the other. The pin is locked in place by a red tab to ensure that it
remains in place. From the disengaged position, pivot the pin/tab
to bring the pin horizontal. Insert the pin fully through the retaining
hole with its tail pointing down. Next ip the tab vertically to lock
the pin in place.
Removal is simply a reversal of the tting sequence.

The Easy-Lock clamps are used to secure the stabilisers to Mi
TOWER STAIRS’s vertical tubing. With the clamp jaw open, oer it
to the tube. Bring the jaw around the tube and set the buckle on
to the hook, then close the black clamp arm to lock the stabiliser in
position. A similar clamp is tted to the stabiliser extension leg.

The Wind-Lock catch is a drop down jaw tted to the side of the
hatch platform’s mounting hook and prevents the platform from
lifting in windy conditions. It is attached to the horizontal tube of
the frame. To disengage, simply lift and hold the jaw as you raise
the platform clear.
