Populo PEDC-50 User manual

BY THE PEOPLE FOR THE PEOPLE
USER MANUAL
50FT. POWER-FEED
ELECTRIC DRAIN CLEANER WITH GFCI
WHAT’S IN THE BOX
PEDC-50
Arrow Cutter
x 1
Boring Bulb Cutter
x 1
C-Cutter
x 1
Spade Cutter
x 1
Retrieving Auger
x 1
Funnel Auger
x 1
Expanding Finish Cutter
x 1
Screwdriver
x 1
Spiral Saw Tooth Cutter
x 1
Spanner
x 1
Gloves
x 1
MADE IN CHINA
WARNING! To reduce the risk of injury, the user must read and understand the user manual before
operating this product. Save this manual for future reference.

ELECTRICAL SAFETY WARNINGS
WARNING! When using mains powered tools, basic safety precautions
should always be followed to reduce the risk of fire, electric shock,
personal injury and material damage.
GROUNDING WARNINGS
Volts
120V
Ampere
More
Than
Rating
Not More
Than
Total length of cord in feet
AWG
25 50 100 150
0
6
10
12
6
10
12
16
18
18
16
14
16
16
16
12
16
14
14
14
12
12
Not recommended
Using an extension lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect
the extension lead for signs of damage, wear and aging. Replace the extension lead if damaged or
defective. When using an extension lead on a reel, always unwind the lead completely. Use of an
extension lead not suitable for the power input of the tool or which is damaged or defective may result
in a risk of fire and electric shock.
Before operating the unit, carefully read the entire manual and be certain you know how to switch the unit off in case of an emergency.
Be sure to save these instructions and any other documents supplied with this unit for future reference.
The electric motor has been designed for 120V 60Hz only. Always check that the power supply corresponds to the voltage on the rating
plate.
Note: The supply of 120V 60Hz on Populo tools are interchangeable for use in the United States and Canada.
Note: The power outlet used for the power tools must be protected by a 30mA ground fault circuit interrupter or earth leakage circuit
breaker. If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The insulation system is added to
prevent against potential injury should an electrical failure occur within the tool.
1. This appliance must be grounded in the event of malfunction or breakdown, grounding provides a path of least resistance for electric
current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipmentgrounding conductor and a
grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local
codes and ordinances.
2. Danger-improper connection of the equipmentgrounding conductor can result in a risk of electric shock. The conductor with insulation
having an outer surface that is green with or without yellow stripes is the equipment-grounding conductor. If repair or replacement of the
electric cord or plug is necessary, do not connect the equipment grounding conductor to a live terminal. Check with a qualified
electrician or serviceman if the grounding instructions are not completely understood, or if in doubt as to whether the appliance is
properly grounded. Do not modify the plug provided with the appliance- if it will not fit the outlet, have a proper outlet installed by a
qualified electrician.
5. The temporary adaptor should be used only until a properly grounded outlet can be installed by a qualified electrician. The green
colored rigid ear, lug, and the like, extending from the adaptor must be connected to a permanent ground such as a properly grounded
outlet box cover. Whenever the adaptor is used, it must be held in place by the metal screw.
3. This appliance is for use on a nominal 120 v circuit, and
Has a grounding plug that looks like the plug illustrated in
figure a.
4. A temporary adaptor, which looks like the adaptor illustrated
in figures b and c, may be used to connect this plug to a
2-pole receptacle as shown in figure b if a properly grounded
outlet is not available.
Figure A: 3-prong Plug Figure B: Grounding Adapter

GROUNDING WARNINGS(CONT.)
1. Plug the GFCI Power Plug into a
grounded, 120 VAC electrical outlet.
2. Press the TEST button, The GFCI
indicator light should go out and power to
the appliance should cut off.
3. To restore power after TEST, push the
RESET button.
WARNING! If the appliance does not start, stops while running, or if you
experience an electric shock, disconnect the power cord and do not use the
appliance. Have it repaired by a qualified electrician or replace it.
Note: The Power Cord is not GFCI-protected from the GFCI to the 3-prong
plug in the electrical outlet.
The appliance is quipped with a ground fault circuit interrupter (GFCI), which reduces the risk of electric shock. Check that the receptacle
is properly grounded and test the GFCI before each use.
Ground Fault Circuit Interrupter (GFCI)
6. The adapter should not be used if a three-slot grounded receptacle is available.
7. A qualified electrician should be consulted if there is any doubt as to whether an outlet box is properly grounded.
8. A qualified electrician should be consulted if there is any doubt as to whether an outlet box is properly grounded.
Figure c: Grounding Adapter connection

GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in electric shock,
fire and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains operated (corded) power
tool or battery operated (cordless) power tool.
Work area safety
■ Keep work area clean and well lit. Cluttered or dark areas invite accidents.
■ Do not operate power tools in explosive atmosphere, such as in the presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
■ Keep children and bystanders at a safe distance while operating a power tool. Getting distracted while using the tool may lead to injury
for the operator or bystanders if not exercising proper safety.
Electrical safety
■ Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce the risk of electric shock.
■ Avoid bodily contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of
electric shock if your body is earthed or grounded.
■ Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
■ Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords increase the risk of electric shock.
■ When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces
the risk of electric shock.
■ If operating a power tool in a damp location is unavoidable, use a ground fault circuit interrupter (GFCI) protected supply with a rated
leakage current of 30 mA or less. Use of a GFCI reduces the risk of electric shock.
Personal safety
■ Always be sure to pay close attention to what you are doing when operating a power tool. Do not use a power tool when you are tired or
under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal
injury.
■ Use personal protective equipment. Always wear eye protection. Under the appropriate condition, protective equipment such as a dust
mask, non-skid safety shoes, hard hat, or hearing protection can reduce personal injuries.
■ Prevent unintentional starting. Make sure the switch is in the off-position before picking up or carrying the tool or connecting the unit to a
power source/battery pack. Carrying power tools with your finger on the switch or energizing power tools that have the switch on may lead
to accidents.
■ Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
■ Do not over reach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
■ Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving parts. Loose clothes,
jewelry or long hair, can get caught in moving parts resulting in serious injury.
■ If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
Power tool use and care
■ Do not force the power tool. Use the correct power tool for your application. The correct power tool will do a better and safer job when
used for its designed purpose.
■ Do not use the power tool if the on/off switch is malfunctioning. Any power tool that cannot be controlled with the switch is dangerous and
must be repaired.
■ Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing
accessories, or storing power tools. This helps reduce the risk of starting the power tool accidentally.
■ Store idle power tools out of the reach of children. Do not allow persons unfamiliar with the power tool to operate it without first reading
these instructions. Power tools are dangerous in the hands of untrained users.
■ Properly maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may
affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained
power tools.
■ Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to
control.
■ Use the power tool, accessories, and tool bits, etc. by following these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from those intended could create a hazardous situation.
Service
■ Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the power tool is
properly and safely maintained.
■ If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons to prevent any
potential hazard.

WARNING! This tool vibrates during use. Repeated or long term exposure
to vibration may cause temporary or permanent physical injury,
particularly to the hands, arms and shoulders. To reduce the risk of
vibration-related injury:
WARNING! Read all safety warnings and instructions listed below.
Failure to follow the warnings and instructions may result in serious
injury.

SYMBOLS AND DEFINITONS
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
Addresses practices not related to personal injury.
Double Insulated
Volts
Alternating Current
Amperes
No Load Revolutions per Minute (RPM)
WARNING marking concerning Risk of Eye Injury. Wear ANSI-approved safety goggles with side shieds.
Read the manual before set-up and/or use.
WARNING marking concerning Risk of Fire. Do not cover ventilation ducts. Keep flammable objects away.
WARNING marking concerning Risk of Electric Shock. Properly connect power cord to appropriate outlet.
SYMBOLS DEFINITONS

KNOW YOUR PRODUCT
SPECIFICATIONS
CUTTING TOOL ACCESSORIES
Electrical Rating: 120VAC 60Hz 5.3A
Motor Speed: 1716 RPM
Drum Speed: 202 RPM
Power Cord: 6 ft.
Cable Size: Ø1/2” x 50’L
Drain Pipe Capacity: 2” to 4” I.D.
Drum Dimensions: 13 x 6.3”
Wheels: 8”
1. Handle
2. Rotation Switch(FOR/REV/OFF)
3. Tool Holder
4. Power Cord With GFCI
5. Foot Switch
6. Wheel
7. Drive Belt
8. Handle locking Knob
9. Belt Guard
10. Drum
11. Cable
12. Tension Knob
13. Power-Feed Lever
Spade Cutter
Starting tool – for cutting and scraping.
Boring Bulb Cutter
Starting Tool – for removing loose objects.
C-Cutter
Finish Tool – for grease stoppages and cleaning pipe walls.
Arrow Cutter (2 pieces)
Finishing Tool – for scraping the inside edges of pipes.
Funnel Auger
Starting Tool – for use in exploring an breaking up stoppages or returning sample to surface to
determine correct tool.
Expanding Finish Cutter
Finish Tool – for final removal of material adhering to walls and certain roots of fibrous nature.
Spiral Saw Tooth Cutter
Starting Tool – for clearing any stoppage roots, rags, stick etc.
Retrieving Auger
Starting Tool – for use as second tool in line. Breaks up remains of stoppage left by straight auger.
NOTICE: if the cause of the obstruction is unknown, use the boring bulb cutter to explore the obstruction and, if possible, retrieve a piece
to inspect. Once you can see the cause of the obstruction, select the appropriate tool for the job. Run the smallest available tool through
the blockage to allow the backed up water to flow and carry away the debris as the drain is cleaned. Once the drain is flowing, more
appropriate tools can be used on the rest of the blockage. Keep in mind that the largest tool used should be no bigger than the drain’s
inside diameter, minus an inch. If properly used, the drain cleaners and assorted cutting tool accessories will not damage a drain that is in
good condition and properly designed, constructed, and maintained. However, if the drain is in poor condition or has not been properly
designed, the drain cleaning work may damage the drain. If possible, visually inspect the drain’s quality before operation.
1
2
3
4
5
6
13
12
10
9
8
7
11
***THIS APPLIANCE IS INTENDED FOR HOUSEHOLD USE ONLY!***
①
①
②
②
③
③
④
④
⑤
⑤
⑥
⑥
⑦⑦
⑧
⑧
4004713

Electrical Rating: 120VAC 60Hz 5.3A
Motor Speed: 1716 RPM
Drum Speed: 202 RPM
Power Cord: 6 ft.
Cable Size: Ø1/2” x 50’L
Drain Pipe Capacity: 2” to 4” I.D.
Drum Dimensions: 13 x 6.3”
Wheels: 8”
UNPACK AND SET-UP
WARNING! Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the
beginning of this manual including all text under subheadings therein before set
up or use of this product.
TO PREVENT SERIOUS INJURY FROM ACCIDENT OPERATION: Turn the rotation
switch of the tool to its “OFF” position and unplug the tool from its electrical
outlet before assembling or making any adjustments to the tool.
1. Once the drain cleaner is assembled, check the appliance and cutting tools for any signs of wear and damage. If necessary, replace
worn or damaged parts prior to using the drain cleaner. Dull or damaged cutting tools can lead to binding, cable breakage, and slow the
drain cleaning.
2. Verify drain cleaner is unplugged and inspect the power cord, ground fault circuit interrupter (GFCI) and plug for damage. If the plug has
been modified, is missing the grounding prong or if the cord is damaged, to avoid electrical shock, do not use the appliance until the cord
has been replaced by a qualified electrician.
3. Clean any oil, grease or dirt from all equipment handles and controls. This helps prevent the appliance or control from slipping during
use.
4. Verify foot switch is attached to drain cleaner.
5. Verify drain cleaner is properly assembled. Inspect the appliance for broken, worn, missing, misaligned or binding parts or any other
condition which may prevent safe and normal operation.
6. Make sure that switches and handles move smoothly between positions and lock in place.
7. Rotate the drum and make sure that it turns freely without binding.
8. Check that all warning labels are present, firmly attached and readable.
9. Make sure belt guard is securely fastened to the drain cleaner.
10. Check the cable for any wear and damage. If any section of the cable is worn or flattened, replace cable before use.
11. Verify cable does not have multiple or excessive kinks (greater than 15°). Kinks weaken the cable and can cause cable failure.
Replace any cables that have multiple or excessively large kinks.
12. Look for spaces between the cable coils. Kinking, stretching (pulling cable by hand) or running the cable in reverse can deform the
cable. Cables with spaces between the coils should be replaced.
13. Check for signs of excessive corrosion. Corrosion weakens the cable, making it brittle. This can be caused by storing the cable wet or
using the cable with corrosive chemicals (often found in chemical clog removers). Excessively corroded cable should be replaced.
14. Before use, fully retract the cable with no more than 2″ of cable outside of the appliance. This will the keep the cable from “whipping”
when the appliance is turned on.
15. Set the rotation switch to the off position.
16. With dry hands, plug cord into properly grounded outlet and move the rotation switch into the for position.
17. Move power-feed lever to exactly between f and r settings, otherwise cable will start moving in or out during this test.
18. Press the foot switch and note the direction of rotation of the drum. If the foot switch does not control the drain cleaner’s operation, do
not use the appliance until the foot switch has been repaired.
19. The drum should rotate clockwise when seen from the front of the drum. It will match the drum direction arrow on the drum. If the
rotation is not correct, do not use the appliance until it has been repaired.
20. After inspection, set the rotation switch to off, dry off your hands, and unplug the drain cleaner.
21. Once you’ve verified that the drain cleaner is in good working order, inspect the work area where you will be using the appliance.
TO PREVENT SERIOUS INJURY FROM ELECTRIC SHOCK, TWISTED/BROKEN CABLES, CHEMICAL BURNS, INFECTIONS AND
OTHER CAUSES AND PREVENT DRAIN CLEANER DAMAGE:
Before each use, inspect Drain cleaner and correct any problems.
Wear ANSI-approved splash-resistant safety goggles, NIOSH-approved dust mask/respirator under face shield, and heavy-duty
LEATHER gloves, and other appropriate protective equipment when setting up the Drain Cleaner. For extra protection from chemicals
and bacteria on the appliance and in the work area, wear latex, rubber or other liquid barrier gloves under the heavy-duty LEATHER work
gloves Before use, inspect gloves to be sure they are free of defects or loose sections that could be caught in the Drain Cleaner Cable.
Rubber soled, non-slip shoes can help prevent slipping and electric shock, especially on wet surfaces

WORK AREA SET-UP
UNPACK AND SET-UP(CONT.)
1. Verify that work area has adequate lighting for the job.
2. Make sure work area is free of flammable liquids, vapors or dust that may ignite. Sparks can be generated during drain cleaner
operation. Do not work in area until these sources of ignition have been identified and corrected.
3. Choose a firm, stable location for the appliance and operator that will remain relatively dry. Do not use the appliance while standing in
water. If needed, remove the water from the work area.
4. Verify the electrical outlet is properly grounded. A three-prong or gfci outlet may not be properly grounded. If in doubt, have outlet
inspected by a licensed electrician.
5. Make sure there is a clear, unobstructed path from the drain cleaner to the electrical outlet. 6. Inspect the drain to be cleaned. If
possible, determine the best access point(s) to the drain, the size(s) and length(s) of the drain, distance to tanks or mainlines, the nature
of the blockage, presence of drain cleaning chemicals or other chemicals, etc.
7. If there are chemicals present in the drain, read and adhere to the specific safety measures required to work around those chemicals.
Contact the chemical manufacturer for required safety instructions and information.
8. If necessary, remove fixture (toilet, sink, etc.) to allow access to the drain. Do not feed the cable through a fixture. This could damage
the drain cleaner and the fixture.
9. Determine the correct drain cleaning cable size for the drain cleaning job. See cable/pipe size chart below.
10. If needed, place protective covers over the work area floor. Cleaning the clogged drain can be a messy operation.
11. Make sure that the drain cleaner handle is locked into the upright position for transport. If the drain cleaner needs to be lifted, use
proper lifting techniques or seek assistance if needed. Use caution when moving equipment up and down stairs. Wear appropriate
footwear to help prevent slipping on floor.
12. To prevent cable from whipping, place drain cleaner within 2 feet of drain line or thread cable through guide (not included). The greater
the distance from the drain access, the higher the risk of the cable twisting or kinking.
13. If the drain cleaner cannot be placed within 2 feet of the drain access, use appropriate-sized pipes and fittings to extend the drain
access back to within 2 feet of the drum opening. Improper cable support can allow the cable to kink and twist and can damage the cable
or injure the operator.
14. If needed, set up barriers to keep bystanders away from the drain cleaner and work area during operation.
15. Select proper cutting tool.
16. Install the cutting tool to the end of the cable. Slide the base of the cutting tool into the slot at the end of the cable. Fasten together
using a screwdriver.
17. Position the foot switch for easy accessibility. You must be able to hold and control the cable, control the foot switch, and reach the
rotation switch.
18. Confirm that the rotation switch is in the off position.
19. Run the cord along the clear path. With dry hands, plug the drain cleaner into a properly grounded outlet. Keep all connections dry and
off the ground.
20. If the power cord is not long enough, use an extension cord that is in good condition and has a three prong plug similar to the
One supplied on the drain cleaner. Keep the connection off the ground to prevent it from accidentally getting wet.
21. Also verify that the extension cord is rated for outdoor use and contains a w or w-a in the cord designation (i.E. Sow).
22. Verify the extension cord has sufficient wire size (16 awg for 50′ or less, 14 awg for 50′ – 100′ long). Undersized wires can overheat,
Melting the insulation or causing a fire or other damage.
23. When using an extension cord, the gfci on the drain cleaner does not protect the extension cord. If the outlet is not gfci protected,
Use a plug-in type gfci between the outlet and the extension cord. This will reduce the risk of shock if there is a fault in the extension cord.
Cable Size Pipe Size Typical Applications
Roof stacks and small floor drains (no roots)
Roof stacks, laundry lines and small drains (no roots)
1/2” (included)
3/8” (not included)
2” to 4”
1-1/2” to 3”

ASSEMBLY
UNPACK AND SET-UP(CONT.)
WARNING! TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Rotation Swich of the tool to its “OFF” position and unplug the tool from
its electrical outlet before assembling or making any adjustments to the tool.
STEP 2: Lock handles into place using handle locking knobs
STEP 1: Slide handles into slots
STEP 3: Screw the tension knob in place.
STEP 4: Install the cutting tool accessory.
Follow the below steps to quickly assembly the machine.

OPERATION
POWER-FEED OPERATION
WARNING! To prevent serious injury from twisted or broken cables, cable ends
whipping around, appliance tipping, chemical burns, infections, electric shock and
other causes:
WARNING! Only one person should operate the cable feed and the foot switch. Do
not operate the drain cleaner with one person controlling the cable and another
person controlling the foot switch. This can cause the cable to kink, twist, and
break, which can also lead to serious personal injury.
Follow operating instructions for your model explicitly.
Since drains likely contain hazardous chemicals or bacteria, wear appropriate protective equipment, such as:
• ANSI-approved splash-resistant safety goggles and NIOSH-approved dust mask/respirator under face shield.
• Latex, rubber or other liquid barrier gloves under heavy-duty LEATHER work gloves. Do not use a glove you are not currently wearing or
a rag to hold the rotating cable. cloth materials can tangle in the rotating cable, leading to serious personal injury. Before use, inspect
gloves to be sure they are free of defects or loose sections that could get caught in drain cleaner.
• Rubber soled, non-slip shoes to help prevent slipping and electric shock.
1. To prevent cable from whipping, place drain cleaner within 2 feet of drain line or thread cable through guide (not included).
2. Position the drain cleaner so that you can operate foot switch while having one hand on cable at all times. This will keep cable from
hazardously “whipping” when activating the drain cleaner. Also, make sure rotation switch on top of drain cleaner and power-feed lever are
within reach.
4. After making sure the rotation switch is in the FOR position, tension knob has been tightened, and the power-feed lever is in the F
position, press the foot switch to start feeding the cable further into the drain.
5. If the cable becomes lodged (for example: in a narrow part of the drain, in a drain trap, etc.), move power-feed lever to exactly between
F and R settings, otherwise cable will start moving, and allow the cable to try and work itself past the obstruction.
6. If cable still won’t pass obstruction, release the foot switch and use sharp downward thrusts to try and pass obstruction. Once cable is
past, put the power-feed lever in the F position, press the foot switch, and continue feeding.
NOTICE: Rotation switch controls rotation of drum only. DO NOT USE ROTATION SWITCH IN REV POSITION WHILE REMOVING
CABLE FROM PIPE. Use reverse direction only momentarily for relieving pressure or untangling cable from a blockage. Warranty void if
cable damaged from allowing motor to twist excessively against blockage, or if drum is run in reverse long enough to unwind cable.
3. Loosen the tension knob, then grab the cable with both gloved
hands and push the cable into the drain until at least one foot of
cable is in the drain. Tighten tension knob.
Tension
Power-Feed
Lever
Knob OFF
FOR REV

RETRIEVING DRAIN CLEANER CABLE
OPERATION(CONT.)
WARNING! Do not retrieve cable with rotation switch set in Reverse
position.
WARNING! Do not pull cable from drain while cable is still rotating. The
cable can whip around, causing serious injury.
1. Once drain is clear, turn on faucet or use a hose to flush debris out
2. To retrieve cable, set power feed lever in reverse position but make sure rotation switch is still in Forward position.
3. Keep one hand on cable. The cable can get caught while being retrieved.
4. Continue retrieving cable until you can pull cable by hand. Release foot from foot switch.
5. Place rotation switch in OFF position, dry your hands, unplug machine.
6. Release tension knob tension and pull remaining cable from drain by hand and feed into drain cleaner. If needed, change cutting tool
and continue cleaning.
NOTICE: Rotation switch controls rotation of drum only. DO NOT USE ROTATION SWITCH IN REV POSITION WHILE REMOVING
CABLE FROM PIPE. Use reverse direction only momentarily for relieving pressure or untangling cable from a blockage. Warranty void if
cable damaged from allowing motor to twist excessively against blockage, or if drum is run in reverse long enough to unwind cable.
CAUTION: While working through the blockage, tool and cable can get clogged with debris from blockage, preventing further cleaning.
The cable and tool will then need to be retrieved from drain and debris removed.
NOTE: If water flow slows or stops, resume using the drain cleaner to locate and clear blockage further down the drain.
WORKING THROUGH A BLOCKAGE
WARNING! Do not let cable build up outside drain.
WARNING! Do not remove gloved hand from cable until all the tension is released.
1. If cutting tool becomes lodged in a blockage and drain cleaner is still operating, cable will start to wind up or twist. If so, release
pressure from foot switch and drain cleaner motor will stop.
2. The cable and drum will turn backwards until the tension in the cable is released.
3. Put power-feed lever in R position to pull cable back and free cutting tool from blockage.
4. If motor can’t pull cable out, release pressure from foot switch and allow cable to stop spinning. Once cable has stopped spinning,
Grab cable with both gloved hands and pull cable free.
5. Once tool is free of blockage and is turning again, slowly feed rotating cutting tool back into blockage. Do not force tool through blockage.
Allow cutting tool to break up and work through blockage.

Cleaning Drain Cleaner Cable
Cleaning/Lubrication
WARNING! Do not attempt to remove a rotating cable.
WARNING! Risk of shock! Do not allow water to get into the motor or
any other electrical components.
WARNING! Do not operate the drain cleaner without the belt guard in
place
WARNING! If the supply cord of this appliance is damaged, it must be
replaced only by a qualified service technician.
Procedures not specifically explained in this manual must be performed only by a
qualified technician
WARNING! TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn
the Rotation Switch of the tool to its “OFF” position and unplug the tool from its
electrical outlet before performing any inspection, maintenance, or cleaning
procedures.
WARNING! TO PREVENT SERIOUS INJURY FROM TOOL FAILURE: Do not use
damaged equipment. If abnormal noise or vibration occurs, have the problem
corrected before further use.
TROUBLESHOOTING
MAINTENANCE
1. Thoroughly flush drain cleaner cable with clean water after every use. Doing so will help prevent the build-up of sediment and any drain
cleaning chemicals still in the cable.
2. Once cable has been flushed, carefully tip the drain cleaner forward to empty out any remaining debris.
3. Once the cable is clean and dry, pull the cable from the drum.
4. Lubricate with oily rag as you feed cable back into drum.
1. The drain cleaner should be cleaned as needed with hot, soapy water and/or disinfectants.
2. Dry drain cleaner before storing or using again.
3. Once dry, thoroughly lubricate with a lightweight machine oil.
4. If drain cleaner drum is removed or changed, grease bearings with good general purpose grease.
Removing and Installing Belt
General Cleaning, Maintenance, and Lubrication
Installing Replacement Cable
1. Loosen belt guard retaining knob and slide belt guard off.
2. Use screwdriver to slide belt off back of drain cleaner drum.
3. Slide new belt onto belt pulley above drum.
4. Slide new belt onto rear of drum until securely in place.
5. Slide belt guard pack into place. Tighten belt guard retaining knob to lock belt guard back into place.
1. Remove old cable by pulling cable completely out of drum. Separate cable from drum-connecting cable.
2. Connect new cable to drum-connecting cable and feed cable back into drum.
1. Before each use, inspect the general condition of the tool. Check for:
• loose hardware,
• misalignment or binding of moving parts,
• cracked or broken parts,
• damaged electrical wiring,
• any other condition that may affect its safe operation.
2. After use, wipe external surfaces of the tool with clean cloth. Store indoors out of the reach of children.

TROUBLESHOOTING
TROUBLE SHOOTING
CARING FOR THE ENVIRONMENT
Power tools that are no longer usable should not be disposed of with household waste but in an environmentallyfriendly way.
Please recycle where facilities exist. Check with your local council authority for recycling advice.
Recycling packaging reduces the need for landfill and raw materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist. Check with your local council authority for recycling advice.
Use the table below to troubleshoot problem may get your problem solved in an effective way before contacting our customer service, if
the problem continues after troubleshooting, please always contact with our Customer Service.
Problem Possible Cause Remedy
Motor shuts off during use. 1. The motor may have been shut off
by its internal thermal protection
switch, or auto reset breaker.
2. GFCI breaker tripped.
1. Too much force on the cable.
2. Too much slack between drain
cleaner and drain pipe inlet.
3. Cable used is wrong size for drain
pipe.
4. Cable exposed to acid.
5. Cable worn out.
1. Do not force cable. Let cutting tool
do the work.
2. Move drain cleaner to within 2 feet
of drain pipe inlet.
3. Change cable size.
4. Clean and oil cable regularly.
5. Replace cable.
1. Repair or replace motor rotation
switch.
2. Have power cord replaced by a
qualified technician.
3. Have motor repaired or replaced
by a qualified technician.
4. Dry cord and unit.
5. Electrician must replace power
cord with GFCI.
Check for leaks in air line leading
from foot switch.
Check for tears and holes in foot
switch.
Replaced if needed.
Move the rotation switch to the OFF
position and allow the motor to stop
before changing from Forward to
Reverse or vice versa.
1. Do not force cable. Let cutting tool
do the work.
2. Retract cable with rotation switch
in the forward.
3. Technician should lubricate
distributor tube bearings.
1. Turn rotation switch to OFF. Allow
motor to cool off completely before
restarting and stay clear of cable
when turning motor back on.
2. Make sure all electrical components
are dry and all insulation is in good
repair. Press reset button. If GFCI
trips again, have appliance serviced
by qualified electrician before further
use.
Cable kinks, twists or breaks.
Cable tangles in drum.
Power cord GFCI trips when unit is
plugged in or when foot switch is
pressed
Motor does not operate or the foot
switch sticks
The rotation switch does not work
1. Too much force on the cable
2. Motor running in reverse.
3. Distributor tube frozen.
1. Motor rotation switch defective.
2. Frayed power cord.
3. Short circuit in motor.
4. Excess moisture touching power
cord or drain cleaner.
5. Faulty GFCI unit.
Pneumatic foot switch may have a
leak.
The centrifugal switch requires the
motor to come to a complete stop
before it will allow the direction of the
motor to be changed.

WARRANTY
YOUR PRODUCT IS GUARANTEED FOR A MAXIMUM PERIOD OF 12 MONTHS FROM THE ORIGINAL DATE OF PURCHASE AND IS
INTENDED FOR DIY (DO IT YOURSELF) USE ONLY.
Warranty excludes consumable parts (For example, bearings and O-rings, etc.).
30-DAY MONEY BACK GUARANTY
Within the first 30 days of purchase, you are allowed to return your product for a full refund.
30 DAYS TO 90 DAYS (3 MONTHS)
A defective unit will be replaced with a new one in accordance with the terms of this warranty, due to manufacturing fault.
90 DAYS TO 12 MONTHS
Up to 12 months after purchase, we will provide speedy and effective online service.
WARNING！
The following actions will result in the warranty becoming void.
● If the tool has been operated on a supply voltage other than that specified on the tool.
● If the tool shows signs of damage or defects caused by or resulting from abuse, accidents or
alterations.
● Failure to perform maintenance as set out within the user manual.
● If the product is disassembled or tampered with in any way.
● Professional, industrial or high frequency use.
ANY QUESTIONS, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER:
[email protected]
TO ENSURE THE QUICKEST RESPONSE POSSIBLE, PLEASE HAVE THE PRODUCT CODE AND ORDER NUMBER, DATE OF
PURCHASE AVAIABLE SO OUR CUSTOMER SERVICE REPRESENTATIVE CAN ANSWER ANY QUESTIONS YOU MAY HAVE
RELATING TO THE WARRANTY POLICY OR PROCEDURE.
www.facebook.com/populotools
Instagram: populousa
[email protected]
