Porter-Cable PXCMF226VW User manual

PXCMF226VW
www.portercable.com
OPERATING INSTRUCTIONS, SERVICE
CENTERS AND WARRANTY POLICY.
READ THESE INSTRUCTIONS
BEFORE USING THE PRODUCT.
Air Compressor
Instruction manual

2- ENG
GENERAL SAFETY RULES
This manual contains information that is important for you to know and understand.
This information relates to protecting YOUR SAFETY and PREVENTING
EQUIPMENT PROBLEMS. To help you recognize this information, we use the
symbols below. Please read the manual and pay attention to these symbols.
Indicates an imminently
hazardous situation which, if not
avoided, will result in death or serious
injury.
Indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury.
Indicates a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.
Indicates a practice
not related to personal injury which,
if not avoided, may result in property
damage.
IMPORTANT SAFETY INSTRUCTIONS
This product contains chemicals known to the State of California
to cause cancer, and birth defects or other reproductive harm. Wash hands after
handling.
Some dust contains chemicals known to the State of California
to cause cancer, birth defects or other reproductive harm such as asbestos and
lead in lead based paint.
To reduce the risk of injury, read the instruction manual.
SAVE THESE INSTRUCTIONS
HAZARD
RISK OF EXPLOSION OR FIRE
WHAT CAN HAPPEN HOW TO PREVENT IT
• Itisnormalforelectrical
contacts within the motor and
pressure switch to spark.
• Alwaysoperatethecompressor
in a well ventilated area free
of combustible materials,
gasoline, or solvent vapors.
• Ifelectricalsparksfrom
compressor come into contact
with flammable vapors, they may
ignite, causing fire or explosion.
• Ifsprayingflammablematerials,
locate compressor at least
20' (6.1 m) away from spray
area. An additional length of
air hose may be required.
• Storeflammablematerials
in a secure location away
from compressor.

3- ENG
• Restrictinganyofthecom-
pressor ventilation openings
will cause serious overheat-
ing and could cause fire.
• Neverplaceobjectsagainst
or on top of compressor.
• Operatecompressorinanopen
area at least 12" (30.5 cm) away
from any wall or obstruction that
would restrict the flow of fresh
air to the ventilation openings.
• Operatecompressorina
clean, dry well ventilated area.
Do not operate unit in any
confined area. Store indoors.
• Unattendedoperationofthisprod-
uct could result in personal injury
or property damage. To reduce the
risk of fire, do not allow the com-
pressor to operate unattended.
• Alwaysremaininattendancewith
the product when it is operating.
• Alwaysturnoffandunplug
unit when not in use.
HAZARD
RISK TO BREATHING (ASPHYXIATION)
WHAT CAN HAPPEN HOW TO PREVENT IT
• Thecompressedairdirectlyfrom
your compressor is not safe for
breathing. The air stream may
contain carbon monoxide, toxic
vapors, or solid particles from the air
tank. Breathing these contaminants
can cause serious injury or death.
• Neveruseairobtaineddirectly
from the compressor to supply
air for human consumption. The
compressor is not equipped with
suitable filters and in-line safety
equipment for human consumption.
• Exposuretochemicalsindust
created by power sanding,
sawing, grinding, drilling,
and other construction
activities may be harmful.
• Sprayedmaterialssuchaspaint,
paint solvents, paint remover,
insecticides, weed killers, may
contain harmful vapors and poisons.
• Workinanareawithgoodcross
ventilation. Read and follow
the safety instructions provided
on the label or safety data
sheets for the materials you are
spraying. Always use certified
safety equipment: NIOSH/OSHA
respiratory protection or properly
fitting face mask designed for use
with your specific application.

4- ENG
HAZARD
RISK OF BURSTING
Air Tank: On February 26, 2002, the U.S. Consumer Product Safety Commission
published Release # 02-108 concerning air compressor tank safety:
Air compressor receiver tanks do not have an infinite life. Tank life is dependent
upon several factors, some of which include operating conditions, ambient condi-
tions, proper installations, field modifications, and the level of maintenance. The
exact effect of these factors on air receiver life is difficult to predict.
If proper maintenance procedures are not followed, internal corrosion to the
inner wall of the air receiver tank can cause the air tank to unexpectedly rupture
allowing pressurized air to suddenly and forcefully escape, posing risk of injury to
consumers.
Your compressor air tank must be removed from service by the end of the year
shown on your tank warning label.
The following conditions could lead to a weakening of the air tank, and result in a
violent air tank explosion:
WHAT CAN HAPPEN HOW TO PREVENT IT
• Failuretoproperlydraincondensed
water from air tank, causing rust
and thinning of the steel air tank.
• Drainairtankdailyoraftereachuse.
If air tank develops a leak, replace
it immediately with a new air tank
or replace the entire compressor.
• Modificationsorattempted
repairs to the air tank. • Neverdrillinto,weld,ormakeany modifications to the air tank or its
attachments. Never attempt to
repair a damaged or leaking air
tank. Replace with a new air tank.
• Unauthorizedmodifications
to the safety valve or any
other components which
control air tank pressure.
• Theairtankisdesignedtowithstand
specific operating pressures.
Never make adjustments or
parts substitutions to alter the
factory set operating pressures.
Attachments & accessories:
• Exceedingthepressurerat-
ing of air tools, spray guns, air
operated accessories, tires,
and other inflatables can cause
them to explode or fly apart, and
could result in serious injury.
• Followtheequipmentmanufacturers
recommendation and never exceed
the maximum allowable pressure
rating of attachments. Never use
compressor to inflate small low
pressure objects such as children’s
toys, footballs, basketballs, etc.

5- ENG
Tires:
• Over inflation of tires could result in
serious injury and property damage. • Useatirepressuregaugetocheck the tires pressure before each use
and while inflating tires; see the tire
sidewall for the correct tire pressure.
NOTE: Air tanks, compressors and
similar equipment used to inflate
tires can fill small tires very rapidly.
Adjust pressure regulator on air
supply to no more than the rating
of the tire pressure. Add air in small
increments and frequently use the
tire gauge to prevent over inflation.
HAZARD
RISK OF ELECTRICAL SHOCK
WHAT CAN HAPPEN HOW TO PREVENT IT
• Yourcompressorispoweredby
electricity. Like any other electrically
powered device, if it is not used
properly it may cause electric shock.
• Neveroperatethecompressor
outdoors when it is raining
or in wet conditions.
• Neveroperatecompressor
with protective covers
removed or damaged.
• Repairsattemptedbyunqualified
personnel can result in serious
injury or death by electrocution.
• Anyelectricalwiringorrepairs
required on this product should be
performed by authorized service
center personnel in accordance with
national and local electrical codes.
• Electrical Grounding: Failure to
provide adequate grounding to this
product could result in serious injury
or death from electrocution. Refer to
Grounding Instructions paragraph
in the Installation section.
• Makecertainthattheelectrical
circuit to which the compressor
is connected provides proper
electrical grounding, correct voltage
and adequate fuse protection.

6- ENG
HAZARD
RISK FROM FLYING OBJECTS
WHAT CAN HAPPEN HOW TO PREVENT IT
• Thecompressedairstreamcan
cause soft tissue damage to
exposed skin and can propel dirt,
chips, loose particles, and small
objects at high speed, resulting in
property damage or personal injury.
• Alwayswearcertifiedsafety
equipment: ANSI Z87.1 eye
protection (CAN/CSA Z94.3)
with side shields when
using the compressor.
• Neverpointanynozzleorsprayer
toward any part of the body or
at other people or animals.
• Alwaysturnthecompressor
off and bleed pressure from
the air hose and air tank before
attempting maintenance,
attaching tools or accessories.
HAZARD
RISK OF HOT SURFACES
WHAT CAN HAPPEN HOW TO PREVENT IT
• Touchingexposedmetalsuch
as the compressor head, engine
head, engine exhaust or outlet
tubes, can result in serious burns.
• Nevertouchanyexposedmetal
parts on compressor during or
immediately after operation.
Compressor will remain hot for
several minutes after operation.
• Donotreacharoundprotective
shrouds or attempt maintenance
until unit has been allowed to cool.
HAZARD
RISK FROM MOVING PARTS
WHAT CAN HAPPEN HOW TO PREVENT IT
• Movingpartssuchasthepulley,
flywheel, and belt can cause
serious injury if they come into
contact with you or your clothing.
• Neveroperatethecompressor
with guards or covers which
are damaged or removed.
• Keepyourhair,clothing,and
gloves away from moving parts.
Loose clothes, jewelry, or long hair
can be caught in moving parts.
• Airventsmaycovermovingparts
and should be avoided as well.
• Attemptingtooperatecompressor
with damaged or missing parts or
attempting to repair compressor
with protective shrouds removed
can expose you to moving parts
and can result in serious injury.
• Anyrepairsrequiredonthisproduct
should be performed by authorized
service center personnel.

7- ENG
HAZARD
RISK OF UNSAFE OPERATION
WHAT CAN HAPPEN HOW TO PREVENT IT
• Unsafeoperationofyour
compressor could lead to serious
injury or death to you or others.
• Reviewandunderstandall
instructions and warnings
in this manual.
• Becomefamiliarwiththeoperation
and controls of the air compressor.
• Keepoperatingareaclearofall
persons, pets, and obstacles.
• Keepchildrenawayfromthe
air compressor at all times.
• Donotoperatetheproduct
when fatigued or under the
influence of alcohol or drugs.
Stay alert at all times.
• Neverdefeatthesafetyfea
tures of this product.
• Equipareaofoperation
with a fire extinguisher.
• Donotoperatemachine
with missing, broken, or
unauthorized parts.
HAZARD
RISK OF FALLING
WHAT CAN HAPPEN HOW TO PREVENT IT
• Aportablecompressorcanfall
from a table, workbench, or roof
causing damage to the compressor
and could result in serious injury
or death to the operator.
• Alwaysoperatecompressorina
stable secure position to prevent
accidental movement of the unit.
Never operate compressor on a
roof or other elevated position. Use
additional air hose to reach high
locations.
HAZARD
RISK OF SERIOUS INJURY OR PROPERTY DAMAGE
WHEN TRANSPORTING COMPRESSOR
WHAT CAN HAPPEN HOW TO PREVENT IT
• Oilcanleakorspillandcouldresult
in fire or a breathing hazard. Spilled
oil may cause a slip and fall. Oil
leaks will damage carpet, paint or
other surfaces in vehicles or trailers.
• Alwaysplacecompressorona
protective mat when transporting to
protect against damage to vehicle
from leaks. Remove compressor
from vehicle immediately upon
arrival at your destination.

8- ENG
HAZARD
RISK OF INJURY FROM LIFTING
WHAT CAN HAPPEN HOW TO PREVENT IT
• Seriousinjurycanresult
from attempting to lift
too heavy an object.
• Thecompressoristooheavytobe
lifted by one person. Obtain assis-
tance from others before lifting.
RISK FROM NOISE
WHAT CAN HAPPEN HOW TO PREVENT IT
• Undersomeconditionsandduration
of use, noise from this product
may contribute to hearing loss.
• Alwayswearcertifiedsafety
equipment: ANSI S12.6
(S3.19) hearing protection.
SAVE THESE INSTRUCTIONS
FOR FUTURE USE
SPECIFICATION CHART
Model No. PXCMF226VW
Running Horsepower 1.5 *
Bore 2.48" (63.0 mm)
Stroke 0.87" (22.0 mm)
Voltage 120
Hz-Single Phase 60
Minimum Branch Circuit Requirement 15 amps
Fuse Type Time Delay
Air Tank Capacity (Gallon) 26 (98.4 liters)
Maximum Air Pressure 150 PSI
Approximate Cut-in Pressure 120 PSIG
Approximate Cut-out Pressure 150 PSIG
SCFM @ 40 PSIG 5.0 *
SCFM @ 90 PSIG 4.0 *
* Tested per ISO 1217
Refer to Glossary for abbreviations.
GLOSSARY
Air Filter
Porous element contained within a
metal or plastic housing attached to
the compressor cylinder head which
removes impurities from the intake air of
the compressor.
Air Tank
Cylindrical component which contains
the compressed air.
Check Valve
Device that prevents compressed air
from flowing back from the air tank to
the compressor pump.
Cut-In Pressure
The low pressure at which the motor will
automatically restart.
Cut-Off Pressure
The high pressure at which the motor
will automatically shut off.
Electric Motor
Device which provides the rotational
force necessary to operate the

9- ENG
DUTY CYCLE
This air compressor pump is capable of running continuously. However, to prolong
the life of your air compressor, it is recommended that a 50%-75% average duty
cycle be maintained; that is, the air compressor pump should not run more than 30-
45 minutes in any given hour.
ACCESSORIES
Accessories for this unit are available at the store the unit was purchased.
The use of any other accessory not recommended for use with this tool could
be hazardous. Use only accessories rated equal to or higher than the rating of
the air compressor.
compressor pump.
NPT (National Pipe Thread)
A seal thread tape must be used to
provide a leak-free seal on pipe threaded
connections.
Pressure Regulator Knob
Regulates the outgoing pressure from
the air outlet to the tool. It is possible to
increase or decrease the pressure at the
outlet by adjusting this control knob.
Pressure Switch
Automatically controls the on/off
cycling of the compressor. It stops the
compressor when the cut-off pressure
in the tank is reached and starts the
compressor when the air pressure drops
below the cut-in pressure.The pressure
switch will not automatically start and
control the compressor unless the
manual AUTO/Off Switch is in the
AUTO position.
PSI (Pounds Per Square Inch)
Measurement of the pressure exerted
by the force of the air. The actual PSI is
measured by a pressure gauge on the
compressor.
Pump
Produces the compressed air with a
reciprocating piston contained within the
cylinder.
Regulator Pressure Gauge
Displays the current line pressure. Line
pressure is adjusted by rotating the
pressure regulator knob.
Pressure Relief Valve
Prevents air pressure in the air tank from
rising over a predetermined limit.
SCFM (Standard Cubic Feet Per Minute)
A unit of measure of air delivery.
Tank Pressure Gauge
Indicates the pressure in the air tank.
Thermal Overload Switch
Automatically shuts off the compressor
if the temperature of the electric motor
exceeds a predetermined limit.

10- ENG
OVERVIEW
Oilless air compressors are factory lubricated for life and do not require any oil.
The basic components of the air compressor are the electric motor, pump,
pressure switch, and tank. (Figure 1)
The electric motor (A) powers the pump. The electric motor is equipped with an
overload protector and an automatic reset. If the motor becomes overheated,
the overload protector will shut it down to prevent damage to the motor.
The motor must be allowed to cool down before restarting. To reset the motor
overload toggle turn the pressure switch AUTO/OFF lever to the OFF position
and unplug the unit from the power outlet. Allow 10 minutes (minimum) for motor
overload cut-out to cool and reset. Unit can then be plugged in and re-started.
The pump (B) compresses the air and discharges it into the tank.
The tank (C) stores the compressed air.
The pressure switch (D) shuts down
the motor when the air pressure in the
tank reaches the cut–out pressure.
As compressed air is used and the
pressure level in the tank drops to the
cut–in pressure, the pressure switch
restarts the motor automatically,
without warning, and the pump
resumes compressing air.
C
A
B
Figure 1
D

11- ENG
ASSEMBLY
ASSEMBLING THE COMPRESSOR (Figure 2)
1. Unpack the air compressor. Inspect the unit for damage. If the unit has been
damaged in transit, contact the carrier and complete a damage claim.
Do this immediately because there are time limitations to damage claims.
2. Check the compressor’s serial label to ensure that you have received the model
ordered, and that it has the required pressure rating for its intended use.
3. Locate the compressor according to the following guidelines:
a. Position the compressor near a grounded electrical outlet.
b. The compressor must be at least 12 inches (31 cm) from any wall or
obstruction, in a clean, well-ventilated area, to ensure sufficient air flow and
cooling.
c. In cold climates, store portable compressors in a heated building when
not in use. This will reduce problems with motor starting and freezing of
water condensation.
d. Remove the compressor from the carton and place it on the floor or a hard,
level surface. The compressor must be level to ensure proper drainage of
the moisture in the tank.
4. Connect an air hose to the quick connector (E).
Figure 2
E

12- ENG
ELECTRICAL POWER REQUIREMENTS
ELECTRICAL WIRING
Refer to the air compressor’s serial label for the unit’s voltage and amperage
requirements.
EXTENSION CORDS
NOTE: Avoid use of extension cords.
For optimum performance, plug the compressor power cord directly into a
grounded wall socket. Do not use an extension cord unless absolutely necessary.
Instead, use a longer air hose to reach the area where the air is needed.
If use of an extension cord cannot be avoided, the cord should be no longer than
50feetandbeaminimumwiresizeof12gauge(AWG).Donotusea16or14
gauge extension cord.
Use only a 3-wire extension cord that has a 3-blade grounding plug, and a 3-slot
receptacle that will accept the plug on the product. Make sure your extension
cord is in good condition. An undersized cord will cause a drop in line voltage,
resulting in loss of power and overheating. The smaller the gauge number, the
heavier the cord.
GROUNDING INSTRUCTIONS
This product must be grounded. In the event of an electrical short circuit,
grounding reduces the risk of electric shock by providing an escape wire for the
electric current.
This product is equipped with a cord having a grounding wire with an appropriate
grounding plug. The plug must be plugged into an outlet that is properly installed
and grounded in accordance with all local codes and ordinance is needed.
Improper installation of the grounding plug can result in
a risk of electric shock. If repair or replacement of the
cord or plug is necessary, do not connect the grounding wire to either
flat blade terminal. The wire insulation having an outer surface that is
green with or without yellow stripes is the grounding wire.
This product is for use on a nominal 120 volt circuit. A cord with a grounding
plug, as shown here, shall be used.
Make sure that the product is connected
to an outlet having the same configuration
as the plug (Figure 3). No adapter should
be used with this product.
Check with a licensed electrician if the
grounding instructions are not completely
understood, or if in doubt as to whether
the product is properly grounded. Do not
modify the plug provided; if it will not fit
the outlet, have the proper outlet installed
by a licensed electrician.
Figure 3
Grounded Outlet
Box
Grounded Outlet
Plug Grounding Pin
120 VOLTS

13- ENG
OPERATING INSTRUCTIONS
COMPRESSOR CONTROLS (Figure 4)
Pressure Switch (A): This switch turns on the compressor. It is operated manually,
but when in the AUTO position, it allows the compressor to start up or shut down
automatically,withoutwarning,uponairdemand.ALWAYSsetthisswitchtoOFF
when the compressor is not being used, and before unplugging the compressor.
Pressure Relief Valve (B): If the pressure switch does not shut down the motor
when pressure reaches the preset level, this valve will pop open automatically to
prevent over pressurization. To operate manually, pull the ring on the valve to relieve
air pressure in the tank.
Tank Pressure Gauge (C): This gauge measures the pressure level of the air stored
in the tank. It is not adjustable by the operator, and does not indicate line pressure.
Air Pressure Regulator (D): This air pressure regulator enables you to adjust line
pressure to the tool you are using.
Never exceed the maximum working pressure of the tool. Turn the knob clockwise
to increase pressure, and counterclockwise to decrease pressure.
Regulated pressure gauge (E): This gauge measures the regulated outlet
pressure.
Quick connector (F): Connect air hose to this outlet.
C
D
E
A
F
B
Figure 4

14- ENG
DAILY STARTUP (Figure 5)
1. Turn the pressure switch to the OFF position (A).
2. Close the tank drain valve (B).
3. Plug in the power cord (C).
High temperatures are generated by the electric motor
and the pump. To prevent burns or other injuries, DO NOT
touch the compressor while it is running. Allow it to cool
before handling or servicing.
Keepchildrenawayfromthecompressoratalltimes.
4. Turn the pressure switch to the AUTO position (D).
Whenadjustingfromahighertoalowerpressure,turn
the knob counterclockwise past the desired setting,
then turn clockwise to reach the desired pressure.
Do not exceed operating pressure of the tool or accessory being used.
5. Adjust the air pressure regulator to the working pressure of the tool being used.
SHUTDOWN (Figure 5)
1. Turn the pressure switch to the OFF position (A).
2. Unplug the power cord (C).
3. Reduce pressure in the tank through the outlet hose. You can also pull the
relief valve ring (E) and keep it open to relieve pressure in the tank.
4. Drain water from air tank by opening drain valve (counterclockwise) on bottom
of tank (B).
Escaping air and moisture can propel debris that may
causeeyeinjury.Wearsafetygoggleswhenopeningdrain
valve.
Figure 5
E
D
AOPEN
CLOSE
B
C

15- ENG
MAINTENANCE
To avoid personal injury, always shut off and unplug the compressor and relieve all
air pressure from the system before performing any service on the air compressor.
Regular maintenance will ensure trouble free operation. Your electric powered air
compressor represents high quality engineering and construction; however, even
high quality machinery requires periodic maintenance. The items listed below
should be inspected on a regular basis.
DRAINING THE TANK
Condensation will accumulate in the tank. To prevent
corrosion of the tank from the inside, this moisture must
be drained at the end of every workday. Be sure to wear
protective eyewear. Relieve the air pressure in the system and open the
drain valve on the bottom of the tank and tilt tank to drain.
NOTE: In cold climates, drain the tank after each use to reduce problems
with freezing of water condensation.
CHECKING THE RELIEF VALVE
Pull the relief valve daily to ensure that it is operating properly and to clear the valve
of any possible obstructions.
Check that all connections are tight. A small leak in any of the hoses, transfer
tubes, or pipe connections will substantially reduce the performance of your air
compressor.
TESTING FOR LEAKS
If you suspect a leak, spray a small amount of soapy water around the area of the
suspected leak with a spray bottle. If bubbles appear, repair or replace the faulty
component. Do not overtighten any connections.
STORAGE
Before storing the compressor for a prolonged period, use an air blow gun to clean
all dust and debris from the compressor. Disconnect the power cord and coil it up
on handle. Pull the pressure relief valve to release all pressure from the tank. Drain
all moisture from the tank. Cover the entire unit to protect it from moisture and
dust.
Perform the following maintenance at the intervals indicated
below.
Operate the pressure relief valve..........Daily
Drain tank.............................Daily
SERVICE INTERVAL

16- ENG
TROUBLESHOOTING
Risk of Unsafe Operation. Unit cycles automatically when
power is on. When servicing, you may be exposed to voltage sources, com-
pressed air, or moving parts. Before servicing unit unplug or disconnect elec-
trical supply to the air compressor, bleed tank of pressure, and allow the air
compressor to cool.
PROBLEM CAUSE CORRECTION
Low pressure or
not enough air
or Compressor
does not stop
Tank drain valve is open Close drain valve
Fittings leak Check fittings with soapy water.
Tighten or reseal leaking fittings.
DO NOT OVERTIGHTEN.
Restricted air intake Clean or replace intake filter element.
Prolonged excessive
use of air Decrease amount of air used.
Compressor not
large enough Check air requirement of accessory. If it is higher than CFM and
pressure supplied by compressor,
you need a larger compressor.
Most accessories are rated at 25% of
actual CFM while running continuously.
Hole in air hose Check and replace if necessary.
Tank leaks Immediately replace
tank. DO NOT attempt to repair.
Blown seals Replace seals.
Valve leaks Replace seals.
Leaking or worn piston Replace piston.
Air leaks from
regulator, or
regulator does
not regulate
pressure
Dirty or damaged
regulator internal parts. Replace regulator or internal parts.
Regulated
pressure
gauge reading
drops when
air accessory
is being used
This is normal If pressure drops too low, adjust
regulator while accessory is used.
Compressor not
large enough Check air requirement of accessory. If it is higher than CFM and pressure
supplied by compressor, you need a
larger compressor. Most accessories
are rated at 25% of actual CFM
while running continuously.
Pressure relief
valve opens Tank pressure exceeded normal
operating pressure
Replace pressure switch
Pressure switch stuck Replace pressure switch

17- ENG
PROBLEM CAUSE CORRECTION
Motor will
not run Tank pressure exceeds preset pressure switch
limit
Motor will start automatically when
tank pressure drops below cut- in
pressure of pressure tank.
Make sure the Thermal
Overload Switch has not
tripped. The motor has
a built in thermal cut out
that trips when necessary
to protect the motor
from damage when
overheated.
Fuse blown or circuit
breaker tripped
To reset the motor overload toggle turn
the pressure switch AUTO/OFF lever
to the OFF position and unplug the
unit from the power outlet. Allow 10
minutes (minimum) for motor overload
cut-out to cool and reset. Unit can
then be plugged in and re-started.
•Replaceblownfuseorresetcircuit
breaker. Do not use fuse or circuit
breaker with higher rating than
specified for your branch circuit.
•Checkforproperfuse;“Fusetron”
type T is acceptable.
•Checkforlowvoltageand
proper extension cord size.
•Disconnectotherapplications
from circuit. Operate compressor
on a dedicated circuit.
Check valve stuck open Remove and clean or replace.
Wrongwiregaugeincord
or excessive extension
cord length
Check for proper gauge and extension
cord length.
Loose electrical
connections Contact authorized service center.
Paint spray on internal
motor parts Have checked at service center. Do not operate compressor in the paint
spray area
Possible defective motor Have checked at service center.

18- ENG
PARTS DRAWING
PUMP/MOTOR ASSEMBLY
1
2
3
8
4
6
7
9
11
12
4
10
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
5
29
30
55

19- ENG
PARTS DRAWING
PXCMF226VW
34
35
36
37
40
41
39
38
43
44
45
46
47
48
49
50 51
52
53
54
55
56
57
58
59
60
61
28
2
27
62
55
63
54
64
65
66
67
70
69
68
71
72
63
54
52
42

20- ENG
REF. NO PART NO. KIT NO. DESCRIPTION QTY
1
7 Screw, SHCS M6 X 1 X 35mm
4
2
7Washer,LockM6
6
3
E100284 7 Head, Cylinder
1
4
1 & 7 Screw, HFHS M3 X 0.4 X 5mm
2
5
1 & 7 Washer,LockM3
1
6
1 & 7 Retainer, Outlet Valve
1
7
1 & 7 Valve, Outlet
1
8
1 & 7 Gasket, O-ring, Head
1
9
1 & 7 Valve Plate
1
10
1 & 7 Gasket, O-ring, Cylinder
1
11
1 & 7 Valve, Inlet
1
12
1 & 7 Retainer, Inlet Valve
1
13
2 & 7 Cylinder
1
14
7 Screw, Pan Head M6 x 1.0 x 10mm
4
15
E104779 7 Shroud, Motor End Cap
1
16
7 Motor/Pump F2
1
17
3 & 7 Assy, Eccentric, Pump & Bearing 6203ZC3
1
18
3 & 7 Screw, SHCS M6 X 1 X 35mm
1
19
2 & 7 Nut, M5 X 0.8
1
20
2 & 7 Screw, SHCS M5 X 0.8 X 25mm
1
21
2 & 7 Rod, Connector
1
22
2 & 7 Ring, Piston
1
23
2 & 7 Cap, Piston
1
24
2 & 7 Screw, M5 X 0.8 X 15mm
1
25
4 Fan, Cooling
1
26
4Washer,FlatM6
1
27
4Washer,LockM6
1
28
4 Screw, SHC M6 x 1.0 x 16mm
1
29
E104273 7 Capacitor, Running (Motor-50μF/250VAC) Bkt Mt
1
30
E104272 7 Capacitor, Starting (Motor-250μF/125VAC) Bkt Mt
1
31
N/A
32
N/A
33
N/A
34
E100300 Shroud, Full Rear
1
35
E103967 Handle
1
36
E103686 Gauge,Pressure1.5"(BlkHsn/WhiteFace)
2
37
E102822 Quick Connect, Steel
1
38
E101073 Cord,Power,14/3AWG,Length6'TypeST
1
39
E101800 Restraint, Power Cord - 14/3 ST
1
40
E100971 Regulator, 3-Port, 1/4" npt
1
41
Nipple, 1/4" mnpt x 35mm
2
42 E100594
Restraint, Motor Cord - 14/3 SJT
1
43
E105176 Switch, Pressure Assy 150 psig 4 X 1/4" NPT Base
1
44
E102612 Valve, Safety
1
45
Weldment,AssemblyTank26 Gallon Vertical,
1
46 5
Nut, Hex Lock Nylon inserted M10 x 1.5 (bright Zinc)
2
47 5
Washer,Flat10mm
2
48 5
Wheel,7"x1.5"DiamondTread
2
49 5
Bolt, Shoulder M10 x 1.5 x 55 (shoulder to 39mm)
2
50
E101717 Valve, Drain, 1/4 Turn
1
51
Screw, HH M8 X 1.25 X 30mm
2
52
Washer,FlatM8X22mm
4
53
E100240 Isolator, Foot (Sears, 60mmDia X 28mm Tall)
2
54
Washer,LockM8
10
55
Nut, M8 x 1.25
8
56 6
Ferrule, 3/8"
1
57 6
Nut, Comp, 3/8"
1
58 6
Tube, Outlet Finned
1
59
E100296 Shroud, F2, Full, Front
1
PARTS LIST
