Portfolio TL05BZ User manual

Français p. 9
Español p. 17
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday,
8 a.m. - 5 p.m., EST, Friday.
ATTACH YOUR RECEIPT HERE
Purchase Date
ITEM #0805600
MODEL #TL05BZ
EB1692 1
E358409
PORTFOLIO®and PORTFOLIO & DesignTM are trademarks
or registered trademarks of LF, LLC. All rights reserved.
MAGAZINE RACK LAMP

2
PACKAGE CONTENTS
A
PART DESCRIPTION QUANTITY
B
C
L
MN
O
A Shade 1
C Harp 1
B Finial 1
(preassembled)
D Socket Assembly 1
E Tube
1
(preassembled)
F Decorative Cover 1
(preassembled)
L Top 1
M Leg 2
N Side Rack 2
O Bottom Rack 1
G Cap 2
(preassembled)
H Large Washer 1
(preassembled)
I Plate
(preassembled)
J Small Washer 1
(preassembled)
K Wing Nut 1
(preassembled)
1
D
G
H
I
E
F
K
J
G

HARDWARE CONTENTS (shown actual size)
G
PREPARATION
G
Before beginning installation of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not attempt
to install, operate or assemble the product.
Estimated Assembly Time: 30 minutes
No Tools Required forAssembly
READ AND SAVE THESE INSTRUCTIONS.
WARNING
• This portable lamp has a polarized plug (one blade is wider than the other) as a safety feature to
reduce the risk of electric shock. The plug will fit in a polarized outlet only one way. If it does not fit fully
in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. NEVER use with an
extension cord unless the plug can be fully inserted. DO NOT alter the plug.
• To reduce the risk of electric shock, DO NOT use the product if power cord is frayed or broken.
• DO NOT use bulbs having a wattage greater than the maximum value stated on the fixture. The use of
bulbs with higher wattage than specified will increase temperatures and risk of fire.
SAFETY INFORMATION
3
AA
CC
Small
Screw
Qty. 4
BB
Large
Screw
Qty. 12
Allen Wrench
Qty. 1

4
ASSEMBLY INSTRUCTIONS
2. Align holes at end of side rack (N) with holes
on legs (M). Attach side rack (N) to leg (M)
with large screw (CC). Insert large screw (CC)
with fingers first and then tighten screw with 3 in.
Allen wrench (AA). Before securing large screws (CC)
permanently, repeat procedure for remaining end
of side rack (N). Secure all large screws (CC).
Repeat procedure for other side rack (N).
TABLE AND MAGAZINE RACK ASSEMBLY:
1. Place top (L), with smooth side down on carpet
or on foam to avoid damage to finish.
Align holes at top of leg (M) with two of the holes
on underside of top (L).
Insert two small screws (BB) with fingers first and
then tighten screws securely with the Allen
wrench (AA). Repeat procedure for other leg (M).
Small
Screw x 4
Hardware Used
AA Allen Wrench x 1
BB
Hardware Used
Large
Screw x 12
AA Allen Wrench x 1
CC
1
AA AA
BB BB
L
M
2
AA CC
CC CC
CC
M
N
M

5
ASSEMBLY INSTRUCTIONS
1.
TABLE LAMP ASSEMBLY:
1
Push power cord, wing nut (K), small washer (J)
and plate (I) down through hole in the top (L).
Adjust power cord length by pulling power cord
from bottom of table until taut.
Power Cord
Hole
J
K
I
L
Large Holes
3
3. Align the two holes at bottom of both side racks (N)
with large holes on each end of bottom rack (O).
Hold bottom rack (O) in place.
Insert large screw (CC) with fingers first and then
tighten screw with Allen wrench (AA). Before
securing screws (CC) permanently, repeat procedure
for other side of bottom rack (O). Secure all large
screws (CC).
Hardware Used
Large
Screw x 12
AA Allen Wrench x 1
CC
AA
CC CC
CC
CC
N
O

4
G
K
I
L
E
J
F
6
ASSEMBLY INSTRUCTIONS
3. Place the threaded portion of the tube (E) through
the hole in the top (L) until large washer (H), bottom
cap (G), decorative cover (F) and tube (E) are flush
against the top (L).
Screw wing nut (K) completely onto threaded portion
of tube (E) until plate (I) and small washer (J) are
flush against the underside of the top (L).
NOTE: Continue to hold the tube (E) with the
decorative cover (F) upright on top of cap (G) until
wing nut (K) is completely tightened.
4.
E F
D
Attach socket assembly (D) to the tube (E). Slide
tube (E) through decorative cover (F).
2. 2
3F
E
H
G
L

7
6. Remove preassembled finial (B) from harp (C).
Place harp (C) into saddle preassembled on
socket assembly (D). Attach shade (A) and secure
with finial (B).
Install one standard-base bulb (not included). Use
a 3-way 100-watt max. incandescent bulb or
halogen/CFL/LED equivalent.
CAUTION: When replacing bulb, please
allow bulb to cool down before touching.
Remove preassembled cap from end of power
cord and plug power cord into wall outlet.
NOTE: Use preassembled switch on socket
assembly (D) to turn lamp ON/OFF.
If light does not function, please refer to
TROUBLESHOOTING on next page.
ASSEMBLY INSTRUCTIONS
6
Switch
A
B
C
D
7.
5. Lift one side of shade (A). Slide shade support away
from the center while supporting shade (A) from the
opposite side.
Repeat for other shade support.
5Shade Support
Shade Frame A
7

Printed in China
The distributor warrants all of its lighting fixtures against defects in materials and workmanship for
one (1) year from the date of purchase. If within this period the product is found to be defective, take
a copy of the bill of sale as a proof of purchase and the product in its original carton to the place of
purchase. The distributor will, at its option, repair, replace or refund the purchase price to the
consumer. All costs of installation and removal of the fixture is the responsibility of the consumer. This
warranty does not cover fixtures becoming defective due to misuse, accidental damage or improper
handling and/or installation and specifically excludes liability for direct, incidental or consequential
damages. As some states do not allow exclusions of limitations on an implied warranty, the above
exclusion and limitation may not apply. This warranty gives you specific rights and you may also have
other rights which may vary from state to state.
WARRANTY
8
JMLI1607
CARE AND MAINTENANCE
•Clean only with soft, damp cloth. Do not use an abrasive cleaner on table.
TROUBLESHOOTING
WARNING: Before beginning work, shut off the power supply to avoid electrical shock.
Light does not come
on initially or no longer
comes on.
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
1. Bulb is burned out.
2. Power is OFF.
3. Lamp is not plugged in.
1. Replace light bulb.
2. Make sure power supply is ON.
3. Plug lamp into outlet.
