1
Packing List1.
Standard Accessories
1-1.
System (with stand)a.
Driver bankb.
Power adapterc.
Power cordd.
RJ45-DB9 cable (x3)e.
a
b
c
d
e

2
Optional Accessories
1-2.
MSR Modulea.
VFD Module (with RJ-45 cable)b.
Second Display (with VGA cable)c.
Wall Mount Kitd.
Cable Covere.
a
b
c
d
e

3
System View2.
Front & Side View
2-1.
Item No. Description
1 Touch screen
2 MSR module (optional)
3 Rugged footprint
4 Ventilation
5 HDD door
Rear View with stand
2-2.
Item No. Description
6 VFD dummy cover
7 MSR dummy cover
1
2
4
3
5
6
4
2
6
7

4
I/O Ports View
2-3.
Item No. Description
a Power Button
b 2nd VGA
c Parallel
d USB x 4
e COM 1, 2, 3, 4 (from right to left)
f Line-out
g Mic-in
h Cash Drawer
i LAN
j Power Switch
k DC-IN
abcdefghi j k
System Dimension
2-4.
248mm
361mm
337mm

5
System Assembly & Disassembly3.
Stand Disassembly
3-1.
Loosen the thumb screw (x1) and1.
slide the stand towards the IO
panel to release it from the system.
Reverse the steps above to attach2.
stand to the system.
Power Adapter Replacement
3-2.
Lay the PC on its back to access1.
the bottom of the system stand.
Place the adapter into the cavity2.
(shown in the picture) and secure
it with the holding bracket and
screws (x2).
Power adapter is secured into the system stand by a holding bracket and screws.
To attach power adapter, please follow the steps below.
Route the cable as shown in the3.
picture.
Connect the cable to the DC-IN4.
port on system IO panel.

6
Romove the HDD from the System
Power the system down.1.
Remove the screw(x1) from the HDD door.2.
Open the HDD door.3.
While pinching the HDD bracket4.
tabs pull the HDD from the
system. For easier removal pull
the plastic puller (see picture) at
the same time.
For replacement, please remove the current HDD rst.
Disassemble HDD
To release the HDD from the bracket gently pull it open until the four pins5.
are removed.
HDD Replacement
3-3.

7
Open the System
3-4.
Place the system face down.1.
Making sure not to scratch the
screen.
Remove the screws (x4) on system2.
rear cover to open the system.
note: If the system is equipped
with a MSR. The MSR must be
removed first.(refer to Chapter
4-1 and reverse the steps to
remove the MSR)
To install a new HDD. Attach the6.
HDD to the bracket until it clicks in
place. Make sure to press the edges
of the drive not the center to avoid
damaging the drive.
Finally slide the HDD into the slot till7.
it clicks.

8
Removing a RAM module
To remove the module pull the3.
ejector clips out of the side of the
module.
Slide the memory out of the slot.4.
RAM Replacement
3-5.
Follow the steps in Chapter 3-4 to1.
open the system.
The RAM is located on the right2.
side of the system (see picture).
Installing a RAM module
Slide the memory module into the3.
memory slot and press down until
it locks in place.

9
Peripheral Installation4.
MSR Installation
4-1.
Remove the screws (x2) to1.
release the MSR dummy cover.
MSR module can be installed to either side of the system. Choose one side and
follow the steps below.
Connect MSR cable to the2.
connector on system side.
Insert MSR module in place and3.
fasten the screws (x2) on the back
to secure the module.

10
VFD Installation
4-2.
Follow steps in Chapter 3-1 to disassemble the system stand.1.
Attach the VFD module to system by fastening the screws (x2).2.
Route the cable through cable mangement on the system stand.3.
Connect the RJ-45 cable to COM 4 on the systems IO panel. Make sure the4.
system is powered off.

11
Second Display Installation
4-3.
Follow steps in Chapter 3-1 to disassemble the system stand.1.
Connect one end of the VGA cable to 2nd Display. Route the cable through2.
cable mangement on the system stand.
Attach the 2nd Display to system by fastening the screws (x2).3.
Connect the other end of the VGA cable to 2nd VGA port on system IO panel.4.

12
Wall Mount Kit Installation
4-4.
Secure the wall plate to the wall by1.
fastening screws (x4).
The Wall Mount Kit includes a wall plate, a metal bracket, and one screw. (refer
to Chapter 1-2 item e) Please follow the steps below for installation.
2. Attach the metal bracket to the
back side of the sytem by fastening
the screw (x1) as picture shown.
3. Align the large end of
the teardrop mounting
holes (x4) on the wall
plate with the screws
(x4) on the systems
rear cover. Slide the
wall plate until the
screws are even with
the narrow end.
