POSEIDON PRSH1196 User manual

1
Form –PMPRSH1196 - 001
–Leaders in Aviation and Maritime Life Support Products
Poseidon Wireman &
Rescue Swimmers Harness
PRSH1196 &
PRSH1196(LP)
User's Manual

2
Form –PMPRSH1196 - 001
–Leaders in Aviation and Maritime Life Support Products
Copyright and Trademark notic
e
This owner’s manual is copyrighted & Trademarked with all rights reserved. It may not,
in whole or in part, be copied, photocopied, reproduced, translated, or reduced to any
electronic medium or machine-readable form with-out prior consent in writing from
Poseidon NZ.
Poseidon®(registered Trademark)
Poseidon Wireman/Rescue Swimmers Harness PRSH1196 & PRSH1196(LP)
Owner’s Manual Part No. PMPRSH1196-1
Contents Section Page
Copyright & Trademark Notice 2
Product Warning 2
Levels of Caution 3
Product Description 3
General Precautions & Warnings 4,5,6
Sizing 1.0 7
Donning of the PRSH1196 2.0 7,8
Adjusting of Harness 3.0 9,10
Drawing / Part Identification 4.0 11,12,13
Maintenance & Care of Poseidon Products 5.0 14,15
Service Life 6.0 15
Work Area 7.0 15
Storage 8.0 16
Visual Inspection 9.0 16
Repairs 10.0 16
OEM Certified Inspection and Maintenance Requirements 11.0 17
Product Warning –Read Manual prior to use:

3
Form –PMPRSH1196 - 001
–Leaders in Aviation and Maritime Life Support Products
Three Levels of Caution
Notices
Product D escription
The PRSH1196 and PRSH1196(LP) Wireman/Rescue Swimmers Harness is a unique
ANZS1891.1 approved harness, incorporating dynamic movement, with a controlled snug
fit to the body.
The PRSH1196 is designed to be integrated to the Poseidon Life Jacket system via the
modular design and weeing attachment points, where once integrated the design becomes
the PRSH1196(LP) {Life Preserver}.
The PRSH1196(LP) has been approved to both TSO-C13f and ISO12402 (SOLAS) to be
fully compliant in Aviation and Maritime use.
The PRSH1196(LP) is also ANZS1891.1 Approved with the Life Jacket integrated during
the testing and approval phase of the Drop Tests.
The PRSH1196 & PRSH1196(LP) are made entirely of FR materials with areas of hi-
luminance colouring for ease of visual identification, and Stainless Steel 316 fittings.
The design allows for use with of Users of 40kg –through to 150kg via the two size
options, in a design which ensures the User at all times are held securely and comfortably
within the harness, at the correct angle for stability, as stipulated within ANZS1891.1
With correct adjustment of the two Shoulder, two Waist points and two Crotch adjustment
points, the Users are offered a snug, comfortable and correct angle during the winching
process
The PRSH1196 & PRSH1196(LP) offers the Wireman/Rescue Swimmer comfort in long
durations of use, with the fit remaining snug to the person throughout all ranges of body
movement.
The WARNING indicates a procedure or
situation that, if not avoided, could result in
serious injury or death to the User
The CAUTION indicates any situation or
technique that could cause damage to the
product and could subsequently result in injury
to the user.
The NOTE is used to emphasize important
aspect, tips, and reminders.

4
Form –PMPRSH1196 - 001
–Leaders in Aviation and Maritime Life Support Products
General Pre-Cautions and Warnings.
Poseidon recommends that these instructions are read in
conjunction with AS/NZS 1891.4:2009 “Industrial fall-
arrest systems and devices”.
The PRSH1196 & PRSH1196(LP) is an Integrated
harness design and is not allowed to be altered,
amended or added to in any form, unless agreed to
by manufacturer in writing and counter signed by the
Aviation Authority
Users must be certified and competent in the use of
this equipment
All equipmentmustbe checkedby the end-user before and
after each use. If there is any doubt about the condition
of the equipment or its abilitytoperform itshouldberemoved
from service and marked clearly with “Non-Serviceable” and
isolated.
All equipment must be checked by the end-user before
each use to ensure the item is in service and has received
a 6 month Inspection with the appropriate Release To
Service (RTS) inspection tag/card for that current period

5
Form –PMPRSH1196 - 001
–Leaders in Aviation and Maritime Life Support Products
Intended Use:
The Wireman/Rescue Swimmers Harness may be used for:
Hoisting of Front Rings joined together, or Rear Dorsal attachment limitations:
The harness is only permitted to be used where the
maximum allowable free fall distance is less than 2
meters
All fall arrest connection points are labeled. Front fall
arrest “D” rings or webbing loops are to be connected
together using a karabiner or similar device.
Only the attachment points marked for fall arrest shall
be used for the attachment of lanyards or other
equipment provided to arrest a free fall
Only the attachment points marked for fall arrest shall
be used for the attachment of lanyards or other
equipment provided to arrest a free fall
All other attachments are for pole straps, limited fall or
retrieval only and are not suitable for fall arrest.
Confined Space Attachment Points are for victim
evacuation only and should be used in conjunction with
a two-point spreader frame.
The spreader frame must be attached to the loops on
the shoulder straps of the harness.
(Refer to AS 2865 for confined space procedures and
practices.)

6
Form –PMPRSH1196 - 001
–Leaders in Aviation and Maritime Life Support Products
.
Only competent users who have received training
should use this equipment. (Refer to the AS/NZS
1891-4: 2009 recommendations concerning
selection, use and maintenance.)
Personal energy absorbers that absorb energy by
permanent deformation or destructive action must
be discarded if that process has commenced.
No modifications or alterations are to be made
to the equipment, this will make the Standard
compliance and warranty null and void
Ensure that the harness or webbing does not
come into contact with high temperature surfaces,
welding, heat sources, electrical hazards or
moving machinery. Specially designed harnesses
with high heat webbing is available for specialized
heat applications
If the equipment is used in areas, or comes into
contact with hazardous chemicals, e.g. cleaning
materials or atmospheres that may cause damage
to the product, contact the manufacturer to see if
it is still suitable for use.
All equipment that has been involved in
preventing a fall or significant loading must be
withdrawn from service and destroyed

7
Form –PMPRSH1196 - 001
–Leaders in Aviation and Maritime Life Support Products
Donning of the PRSH1196 & PRSH1196(LP):
1.0 Sizing the Harness:
1.1 Sizing is determined by body shape, rather than physical size and length of the torso
1.2 Two sizes are offered to cover this body shape ranging of:
1.2.1 Small/Medium, and
1.2.2 Large/XLarge
2.0 Donning the PRSH1196 & PRSH1196(LP)
PRSH1196 & PRSH1196(LP) Rescue Swimmers Harness/Life Preserver Donning Process
2.1 The device is donned like a typical Fall Arrest/Restraint Harness. The device is secured by 3
side-release buckles: one at the waist and one at each thigh. After these buckles have been fastened,
there are 5 adjustment points on the harness system to assure proper fit, both right and left for each:
waist adjustment, chest adjustment, and thigh adjustment.
2.2 The waist adjustment is made on the lateral sides of waist belt, and is adjusted first. The
second adjustment is in each thigh loop. The third and fourth adjustment is to the front chest adjustment,
respectively. All adjustments should be made so that the harness and Life Preserver is snug on the body,
but allows user flexibility and mobility.
2.2.1 Elastic retainers are fitted onto each adjustment webbing to secure excess strapping after
the harness has been adjusted. The excess strapping can be flaked into the elastic retainers where
significant lengths are left after adjustment.
2.2.2 The harness should be fitted snug and secure to the body, but not to the extent that all the
elastised portion of the harness has that the “Stretch” in the Shoulder Straps is removed. The Harness
should remain snug to the body, rump and thighs with minimal movement/sagging in a crouch
position
The following instructions for the use of the
PRSH1196 & PRSH1196(LP) from this point
forward are based on the User being certified
for the Operations, that the item and its use,
and has been stored correctly and packed in
accordance with the manual for use
CAUTION: The Rescue Swimmer Harness/Life
Preserver(PRSH1196(LP) should not be worn on the
inside of a ballistic vest to avoid secondary impact
injuries. The device is designed to take damage
and perform as required and should be configured
on the outside of any tactical ensemble

8
Form –PMPRSH1196 - 001
–Leaders in Aviation and Maritime Life Support Products
Figure 33a - 33h Step a. –Step i. Donning Process
a. Remove harness from packaging and read instructions.
Pick up harness by the back “D” ring and shake it so all the
straps fall into place.
b. If any of the leg or chest straps are buckled up, un- buckle
them to release the straps.
c. Once all buckles and leg straps are hanging loose and in
the correct position, put the harness on like a jacket with
the back “D” ring facing outwards.
d. The “D” ring must be positioned between the centre of
the shoulder blades. All padded areas must sit at the
lower back. Adjust the shoulder straps to ensure the back
pad is on the lower back.
e. Fasten the waist belt via the side release buckle and adjust
to ensure the harness is fitting correctly. Ensure all excess
webbing is fed through the locking buckle. It may take
some time to get the correct length of waist belt, it is
critical to ensure a good fit with no slippage.
f. Pass the right leg strap between the legs coming from the front
of the body to the back and fasten to side release buckle on right
hand side. Make sure the webbing is not twisted and the
adjustment tag is facing out- wards.
g. Repeat procedure on left leg, do not cross the webbing. Ensure
the seat of the harness is fitting snug.
h. Leg straps must be tight but not restrictive, leg straps that are
too loose could cause injury to the wearer during a fall.
i. Once the harness is on and adjust shoulder straps to fit correctly,
run your hands along all the straps to ensure they are not
twisted. If they are twisted re- move the harness and refit.
1.1.2.Ask a colleague to check your harness is laying on you correctly, and all lanyards are attached
and closed.
33a
33b
33c
33d
33e
33f
33g
33h

9
Form –PMPRSH1196 - 001
–Leaders in Aviation and Maritime Life Support Products
3.0 Adjustment of Harness
Figure i Step a. Fasten Buckles
a. To fasten buckles such as leg straps and waist belts, snap the Male and Female 3 release buckles
together. Make sure the webbing is not twisted and the two buckles are flush against each other
when closed.
Figure i Step b. Tighten Buckles
b. Feed the webbing through the buckle and then secure it with the keeper, if the keeper is right up
against the buckle it may make it more difficult to adjust.
Figure i Step c Shoulder Straps - Pulling on the Webbing Tag
c. Tilt the buckle by pulling on the webbing tag, this will release some of the tension on the webbing,
pull the webbing while the buckle is tilted to the required length.

10
Form –PMPRSH1196 - 001
–Leaders in Aviation and Maritime Life Support Products
Figure i Step d. Buckle Keeper
d. Slide the keeper away from the buckle to give some slack in the webbing, tilt the buckle and pull the
webbing through.
Figure i Webbing Flat Must Lay Flat
e. Be careful not to twist the webbing or cross the chest or leg straps.

11
–Leaders in Aviation and Maritime Life Support Products
4.0 Drawing –Part Identification:
Shoulder Adjustments
Adjustment Buckles for
Girth
Left Loop Hoist fitting
Right Loop Hoist fitting
Chest Strap - Adjustable
Dorsal rear Hoisting/Fall Arrest D Ring
Adjustment Buckles for
Girth
Accessory Kit attachment
webbings
Instruction –Inspection
Record
Right Side
Release Buckle
Right Side
Release Buckle

12
–Leaders in Aviation and Maritime Life Support Products
Left Ring for
Line
attachment
–not Fall
Arrest
Left Ring for
Line
attachment
–not Fall
Arrest
Comfort Pads
- adjustable
Hydration
Pak Tube
retainer
Hydration
Pak
attachment
webbings
Hydration
Pak
attachment
webbings

13
–Leaders in Aviation and Maritime Life Support Products
Life Jacket
attachment
webbing
Life Jacket
attachment
webbing

14
–Leaders in Aviation and Maritime Life Support Products
5.0 Maintenance and Care of Poseidon Products
General Maintenance
5.1 After immersion in water (other than fresh clean water), the POSEIDON Harness should
be rinsed thoroughly. To increase the life of the device, it is recommended to wash the
components of the POSEIDON Harness only when required.
Cleaning
5.2 Laundering Procedures
NOTE: Do not dry clean.
Do not use bleach or other chlorine products.
Do not use fabric softeners.
Do not tumble dry.
Do not iron.
Do not dry in front of a radiator or other source of direct heat.
Do not store in a wet condition.
i. Hand wash or sponge down an area of the Harness System in warm (100°F) soapy (using
mild laundry detergent) fresh water, then rinse with clean water. Do not machine wash
any part of Poseidon.
ii. Hang to dry the Harness in a well-ventilated area, which is free from direct sunlight.
iii. To avoid mildew, hang dry the POSEIDON Harness after every use, and be sure not to
stow the product away while damp.
Treatment After Immersion
5.3 Whenever a POSEIDON Harness has been immersed in water, it must be treated as
specified below and then inspected in accordance with the current authorized servicing
schedule.
Fresh Water Immersion
5.3.1 Allow the POSEIDON Harness to dry naturally, preferably in the open air.
NOTE: Ensure that the Component is completely dry before re-packing.

15
–Leaders in Aviation and Maritime Life Support Products
Salt Water Immersion
5.3.2 Rinse thoroughly with clean, fresh water. Allow the POSEIDON Harness to dry
naturally, preferably in the open air.
5.3.3 Ensure adequate fresh water is rinsed between the webbings where the Stainless
Steel and Aluminum fittings are applied, such as the Attachment Points and
Buckles
5.3.4 Using a lightly soiled cloth with CRC66 or other equivalent product, wipe the
Buckles thoroughly to ensure the fittings are adequately protected from the
environment
Chlorinated Water Immersion
5.3.5 Immersion of the POSEIDON Harness in chlorinated water is not recommended.
If the POSEIDON Harness is immersed in chlorinated water, use the same
washing procedure as for salt water (10.5 above) immediately following
immersion.
6Service Life
6.1 The POSEIDON Harness service life is determined “On Condition”rather than age.
POSEIDON Harness may remain in service if properly maintained and all test and inspection
results are satisfactory.
6.2 Poseidon Harnesses must be inspected before each use by the user and regularly inspected by a
competent person and recorded on a register. If the equipment has been involved in a free fall
or fails any of the general inspection criteria it must be removed from service and destroyed.
6.3 Although the Harnesses have a recommended withdraw from service date marked on them, this
is only for storage purposes and will be reviewed and updated byregular inspections undertaken
by a competent person at 6 monthly intervals.
6.4 Refer to AS/NZS 1891.4:2009 for inspection on entry or re-entry into service (RTS).
NOTE: Harness must be inspected every 6 months to comply with meeting the service
life of 10 years plus from date of manufacture in accordance with AS/NZS 1891.1:2007
standards.
7.0 Work Area
7.1 The work area where inspection and maintenance of the POSEIDON Harness is performed
should be smooth and flat, where the POSEIDON Harness will not snag, tear or otherwise be
damaged and should also be cleared of all non-essential equipment and materials.
7.2 The working surface should be free of harmful contaminants such as oil, grease, acids or solvents.
Work areas, subject to wide temperature variations, should be avoided.

16
–Leaders in Aviation and Maritime Life Support Products
8.0 Storage
8.1.1 The Life Preservers should be stored in the following manner:
i. They are to be stored in a cool, dry area where an even temperature can be maintained.
ii. They are not to be exposed to sunlight, ozone gas, or ultra violet rays, and must be kept free
from petroleum products, acids or other damaging contaminants.
9.0 Visual Inspection
9.1.1 Harness at all stitching points, buckles, adjusters and webbings for any signs of
damage, including broken threads, webbing abrasion, buckles not functioning as required.
10.0 Repairs
10.1 General
10.1.1 It is extremely important that damaged POSEIDON Harness is handled in
accordance with the following repair requirements.
Qualified repair personnel can perform some repairs, with adequate OEM Approved facilities.
The manufacturer should do all major repairs, unless otherwise authorized by Poseidon NZ.
This section provides some information to assist with minor or emergency repairs to the
POSEIDON Harness and related components.
10.1.2 Identification of Defects
Defects should be identified in accordance with the inspection and testing procedures detailed
11.0 OEM Certified Inspection and Maintenance Requirements
11.1 Approved Technicians
11.1.1 Poseidon NZ OEM Certified and Qualified Approved Technicians who hold a
current Poseidon NZ OEM Approved Certification, with proper equipment, or Poseidon NZ
only may Inspect and Maintain Poseidon NZ products.
Personnel and Inspection Plant approvals require 3 yearly written Certification approved by
Poseidon NZ.

17
–Leaders in Aviation and Maritime Life Support Products
MAINTENANCE CARRIED OUT ON POSEIDON VICTIM HARNESS
NAME : David Manzi Signature : DATE :
REFERENCE DATA : MAINTENANCE:
ANNUAL 06 MONTH HARNESS
INSPECTION
LICENCE No.
PART No. BATCH No. QUANTITY
Pass Fail
DATE
CLIENT ORDER NUMBER
WORK ORDER
L/P FLOW CHART No.
FORM TWO LABEL REFENCE No.
GARMENT SERIAL No.
MODEL NUMBER
PART No.
AIR TEMPERATURE
ACCOUNTS INVOICE No.
Front Left Waist Adjustment Buckle
Shoulder/Neck Comfort Pad
Front Right Horizontal Waist Webbing
Rear Waist (Black) Adjustment Webbing
Front Right Vertical Webbing
Front Left Shoulder Adjustment Buckle
Front Right Shoulder Adjustment Buckle
Front Left Horizontal Waist Webbing
Outer Nappy Fabric
Seat Horizontal Webbing
Front Right Waist Adjustment Buckle
Instructions - horizontal Under Grab Handle
The maintenance recorded has been carried out in accordance with the requirements of Aviation Rule Part 43 and in respect of that maintenance the component is released to service:
Note: "Component" being Poseidon NZ made Victim Harness.
ANNUAL 06 MONTH VISUAL HARNESS INSPECTION
Left Thigh Comfort Pad
Front Left Vertical Webbing
Inner Nappy Fabric
Lower Back Horizontal Webbing
Left Rear Diagon Webbing
Grab Handle
Right Thigh Comfort Pad
Right Rear Diagonal Webbing
PVH2365
Front Left Diagonal Waist/Thigh Webbing To Crotch
Karabiner for correct locaking/Unlocking Action
Left Shoulder/Waist Attachment to Attachment Ring
Right Shoulder/Waist Attachment to Attachment Ring
Front Right Diagonal Waist/Thigh Webbing To Crotch
ITEM E
Component Level Inspection
ITEM D
ITEM C
ITEM B
DESCRIPTION OF REPAIRS/REPLACEMENT CARRIED OUT :
EXPIRY DATE
ITEM A
ITEM 4
ITEM 5
Poseidon NZ
FORM ONE MAINTENANCE RECORD
Inspection Facility :
SIGNED DIGITALLY - D MANZI
ITEM 3
POSEIDON VICTIM HARNESS
73807
DESCRIPTION OF WORK CARRIED OUT :
ITEM 1
ITEM 2
