Positron G1001-MP User manual

Document 180-0197-001 R01
G1001-MP
Self-installation Guide
WWW.POSITRONACCESS.COM
5101 Buchan Street, Suite 220,
Montreal, QC H4P 2R9 Canada
[email protected]
© Positron Access Solutions
Troubleshooting
The G1001-MP has three (3) Status LEDs:
• PWR: it will be ON when connected to
a local power source. If it is OFF, please
verify you have connected the 12V wall
adapter to a working power jack.
• STA: it will be yellow while the G1001-MP
is booting and then will be OFF.
• G.hn: it will be ON (green) to indicate
that the link to the Internet is UP. It will
be OFF in the link is DOWN. It will blink
ON and OFF to indicate a bad link. You
can restart the G1001-MP if you see a
blinking G.hn LED. If this does not solve
the problem, please reach out to your
Operator for assistance.
G1001-MP Port and LED Definition

Step 5. Connect the port labeled as GE (on the opposite end of the G1001-MP) to your
Residential Gateway using a standard Ethernet cable (usually provided with your
Residential Gateway).
Step 3. Connect the 12V wall adapter to a nearby power plug and connect it to the
G1001-MP 12V connector.
Step 4. Connect the port labeled as POTS to your standard telephone. This port does not
support IP telephones, use your home Gateway for this.
Unpacking the G1001-MP
Connecting the G1001-MP to
your Residential Gateway
Step 1. Find a location close to where you
will install your Residential Gateway.
This location should also be close
to the telephone jack where you will
connect the G1001-MP and to a
power outlet.
Step 2. Connect the port labeled as LINE to
your telephone jack.
Power Up
The G1001-MP takes less than one (1) minute to power up and establish the connection to the
Internet. The STA LED will turn solid green to indicate that the G1001-MP boot sequence is
completed. The G.hn LED will turn green solid to indicate that the link is UP.
Your Residential Gateway will now be able to obtain its conguration and IP address and begin
providing access to the Internet for your in-home devices. Refer to the installation document for
your Residential Gateway if needed.
12V wall adapter
Step 5
Ethernet Cable
Residential Gateway
G1001-MP
Telephone jack
Telephone
Step 3 Step 2
12V wall adapter
Power plug
Step 4
G1001-MP
