Positron TeleLite 720920 Series User manual

TeleLite Quad Ethernet
POE and PSE Optical Plug-in Cards
Model #s: 720920xxx / 720930xxx

Copyright 2017 Positron, Inc.
1
1.1 Publication Information
© 2017 Positron Inc.
TeleLite Ethernet Interface Card,
Description and Installation Guide
Part number: 925W720113-04E
Publication date: December 2017
Published By
Positron Inc.
5101 Buchan Street, Suite 220
Montreal, Québec, Canada
H4P 2R9
Telephone: [phone]
International: 514-345-2220
Trademarks
TeleLite is a trademark of Positron Inc.
Product names, other than Positron’s, mentioned herein may be trademarks and/or registered trademarks of
their respective companies
Confidentiality Notice
The information contained in this document is the property of Positron Inc. Except as specifically authorized in writing
by Positron Inc., the holder of this document: 1) shall keep all information contained herein confidential and shall
protect same in whole or in part from the disclosure and dissemination to all third parties, and 2) shall use same for
operating and maintenance purposes only.
Disclaimer Notice
Although Positron Inc. has made every effort to ensure the accuracy of the information contained herein, this
document is subject to change without notice.

Table of Contents
Copyright 2017 Positron, Inc.
2
1.0 TeleLite Quad Ethernet POE and PSE Optical Plug-in Cards.............................................. 3
1.1 TeleLite Shelves....................................................................................................................... 3
1.2 Overview ................................................................................................................................... 3
1.3 General Technical Notes......................................................................................................... 4
1.3.1 POE................................................................................................................................ 4
1.3.2 PSE ................................................................................................................................ 4
1.3.3 Ethernet Modem Interface Card Features: ................................................................ 4
2.0 Type 1 and Type 2 TeleLite Ethernet Configurations........................................................... 5
2.1 Type 1a and Type 1b, General ................................................................................................ 5
2.1.1 Type 1a Detail ............................................................................................................... 5
2.1.2 Type 1b Detail............................................................................................................... 5
2.2 Type 2, General ........................................................................................................................ 6
2.2.1 Type 2a Detail ............................................................................................................... 6
2.2.2 Type 2b Detail............................................................................................................... 7
2.3 DIP Switch Settings on POE and PSE TeleLite Ethernet Cards.......................................... 7
2.3.1 Type 1a: 720930xxx TeleLite POE Ethernet Card ..................................................... 8
2.3.2 Type 1b: 720930xxx TeleLite POE Ethernet Card ..................................................... 9
2.3.3 OEI for Type 1a or Type 1b........................................................................................ 10
2.3.4 Type 2a and Type 2b TeleLite “Campus” Configuration ....................................... 11
2.3.5 Type 2a and Type 2b, POE ........................................................................................ 12
2.3.6 Type 2a and Type 2b, PSE......................................................................................... 13
2.4 RJ-45 Pin-outs........................................................................................................................ 14
2.5 Optical Connectors................................................................................................................ 15
2.5.1 Available Varieties ..................................................................................................... 15
2.5.2 Types of Connectors ................................................................................................. 16
2.6 Faceplate Read-out LEDs (Both POE and PSE Ethernet Cards)....................................... 16
3.0 Specifications......................................................................................................................... 17
4.0 Important Information............................................................................................................ 18
4.1 Service and Support .............................................................................................................. 18
4.2 Technical Customer Support................................................................................................ 18
4.3 Repair Service ........................................................................................................................ 18
4.4 Warranty.................................................................................................................................. 19
4.5 Limitation of Liability............................................................................................................. 19
4.6 Disclaimer Notice................................................................................................................... 20
4.7 Cancellation and Rescheduling Charges ............................................................................ 20

Copyright 2017 Positron, Inc.
3
1.0 TeleLite Quad Ethernet POE and PSE Optical Plug-in Cards
List of TeleLite 10 Base-T / 100 Base-TX Quad Ethernet Model Numbers:
720920MST 4 Port Ethernet PSE Modem Unmanaged Switch, Multi-mode ST Connector
720920SSC 4 Port Ethernet PSE Modem Unmanaged Switch, Single-mode SC Connector
720920XSC 4 Port Ethernet PSE Modem Unmanaged Switch, Single-mode SC Connector
(Extended Reach)
720930MST 4 Port Ethernet POE Modem Unmanaged Switch, Multi-mode ST Connector
720930SSC 4 Port Ethernet POE Modem Unmanaged Switch, Single-mode SC Connector
720930XSC 4 Port Ethernet POE Modem Unmanaged Switch, Single-mode SC Connector
(Extended Reach)
1.1 TeleLite Shelves
TeleLite 10 Base-T / 100 Base-TX Quad Ethernet Optical modules can be plugged into any of the
following TeleLite shelves:
720000 7-slot wall mount shelf (6 slots for optical modules, one slot reserved for power
provisioning, if needed)
720002 2-slot rack or wall mount shelf (3 shelves can be daisy chained together
Power can be provisioned using a card slot or -48Vdc can be fed in an external
power port, if needed)
720013 3-slot wall mount swing-out shelf
Power can be provisioned using a card slot or -48Vdc can be fed in an external
power port, if needed.
1.2 Overview
The TeleLite Ethernet cards are modems with unmanaged switch interface card providing copper
(10 Base-T and/or 100 Base-TX) to optical media conversion, combining four Ethernet ports to a
single fiber port with an unmanaged four-port switch.
Several Ethernet provisioning configurations are possible with these card sets, each requiring two
cards with one at either end of the fiber span for conversion back to copper. In each configuration,
a CAT 5 Ethernet cable is required to interface with the RJ receptacles on the faceplate of the
TeleLite Ethernet cards. Power and Switch settings are common to all versions above. As such,
the model numbers herein are referred to with the suffix “xxx” rather than MST, SSC, or SXC.

Copyright 2017 Positron, Inc.
4
1.3 General Technical Notes
1.3.1 POE
Can be powered locally (local power provided by the backplane of the TeleLite shelf)
Can be powered by -48Vdc in the appropriate polarity from the Ethernet Network Edge
Device via the first (top) Ethernet port as per POE specifications (in the appropriate
polarity). Its interface supports the two standard modes of powering using
superimposed 48 Vdc on the data pair or using the spare pin on the RJ45 in any
polarity
Has DIP switches to set:
Master/Slave
Types 1 or 2
MDIX enabling or disabling (Disabled is default). Check modems if they are
MDIX enabled. If they are not, this feature should be enabled to avoid cross-
over issues.
PSE enabling or disabling (Used only on 720920xxx. On 720930xxx, this switch
(#4) is always to be set to “Disabled”)
1.3.2 PSE
Can only be powered locally (local power provided by the backplane of the TeleLite
shelf)
Has DIP switches to set:
Master/Slave
Types 1 or 2
MDIX enabling or disabling (“Disabled”is default). Check modems if they are
MDIX enabled. If they are not, this feature should be enabled to avoid cross-
over issues.
PSE enabling or disabling depending on if the terminating modem is locally
powered or not. If modem is not locally powered, set this DIP switch (#4) to the
“Enabled”
1.3.3 Ethernet Modem Interface Card Features:
Support of single- and multi-mode ST/SC connector type.
POE CFJ card can be either remote or locally powered through a jumper setting.
The modem/switch ports are auto-sensing with the hardware automatically detecting
and setting the speed for any 10 Base-T/100 Base-TX device connected to the
interface.
Auto-negotiation for half/full duplex operation on every port automatically.
Auto Uplink takes care of the MDI/MDI-X connection and eliminates the need for toggle
switches or special crossover cables on all 10/100 ports. This results in automatic
polarity correction that helps find and fix common cabling problems.
Flow control ensures reliable communications during full-duplex operation.
Unmanaged switch function provides plug-and-play simplicity.
Comprehensive LED display with per-port indicators allows status monitoring and
activity of every port at a glance.
Switch design delivers dedicated bandwidth to each port.
100mbps of Ethernet through-put is shared equally among the RJ-48 receptacles used

Copyright 2017 Positron, Inc.
5
2.0 Type 1 and Type 2 TeleLite Ethernet Configurations
An Ethernet configuration requires two cards; usually a Power Over Ethernet (POE) and Power
Serving Ethernet (PSE), however the same TeleLite Ethernet card can be used at each end of the
fiber span between the CFJ (Copper Fiber Junction) and Optical Electrical Interface depending on
local power arrangements, Network Ethernet Edge Devices and the terminating Ethernet modems.
2.1 Type 1a and Type 1b, General
In a Type 1a configuration, the TeleLite Ethernet card at the Central Office (C.O.) as the CFJ
(Copper Fiber Junction) and interfaces with the network Edge Devices, providing the Ethernet
service.
In a Type 1b configuration, the TeleLite Ethernet card as the CFJ (Copper Fiber Junction) is
located at the 300v Point of the GPR contour of the electric supply location and interfaces with the
network Edge Devices, providing the Ethernet service. See Figures 1 & 2.
2.1.1 Type 1a Detail
Locating the CFJ at the Central Office
2.1.2 Type 1b Detail
Locating the CFJ at the 300V point of the GPR contour of an electric supply location.
Model #720920xxx as OEI in
front of Ethernet modem
Model #720930xxx as CFJ at edge of
substation ZOI & Network Edge Device
Packet
Switched
Network
C.O.
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
Figure 2: Type 1b
10 Base-T / 100 Base-TX
Modem
CPE
CPE
CPE
CPE
10 Base-T / 100 Base-TX
300V
Point
Packet
Switched
Network
C.O.
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
Figure 1: Type 1a
10 Base-T / 100 Base-TX
Modem
CPE
CPE
CPE
CPE
10 Base-T / 100 Base-TX
300V
Point
Model #720920xxx as OEI in
front of Ethernet modem
Model #720930xxx as CFJ at edge of
substation ZOI & Network Edge Device

Copyright 2017 Positron, Inc.
6
2.2 Type 2, General
In a Type 2 configuration, the TeleLite CFJ Ethernet card acts as a modem converting the copper-
based Ethernet service to fiber across the span. The TeleLite OEI Ethernet card serves as a 4-port
Ethernet modem.
2.2.1 Type 2a Detail
Type 2a describes a 10 Base-T / 100 Base-TX multi-port router modem feeding a TeleLite
Ethernet card to distribute network connectivity to remote devices. See Figures 3 and 4.
HVI
300V
Point
Figure 3: Type 2a, Copper-fed
Modem
Base-T / 100 Base-TX
Network
Packet
Switched
Network
C.O.
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
Cu Network
Base-T / 100 Base-TX
TeleLite Model #720930xxx Ethernet CFJ
card as single port or multi-port Modem
Interface
TeleLite Model #720920xxx
Ethernet OEI card as 4-port
Ethernet Modem
300V
Point
Modem
Figure 4: Type 2a, Fiber-fed
CPE
CPE
CPE
CPE
10 Base-T / 100 Base-TX
Packet
Switched
Network
C.O.
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
10 Base-T/100 Base-TX
TeleLite Model #720930xxx Ethernet CFJ card
as single port or multi-port Modem Interface
TeleLite Model #720920xxx Ethernet
OEI card as 4-port Ethernet Modem
Optical
Network
*
*= Fiber to copper conversion

Copyright 2017 Positron, Inc.
7
2.2.2 Type 2b Detail
Type 2b describes multiple 10 Base-T / 100 Base-TX single port networked modems feeding a
TeleLite Ethernet card to distribute network connectivity to remote devices. See Figures 5 and 6.
2.3 DIP Switch Settings on POE and PSE TeleLite Ethernet Cards
The setting of the on-board DIP switches is dependent on the application. In general, there are
several things to take into account:
Is it a Type 1a, Type 1b, Type 2a, or Type 2b scenario?
Which of the two cards is to be set to master and which to slave
Is the modem feeding, or being fed by, the TeleLite Ethernet MDIX enabled?
What POE and PSE settings best suit the application of the cards?
*= Fiber to Copper Conversion
M = Modem
300V
Point
Figure 5: Type 2b, Copper-fed
CPE
CPE
CPE
CPE
10 Base-T / 100 Base-TX
Packet
Switche
d
Network
C.O.
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
Cu
Network
10 Base-T / 100 Base-TX
TeleLite Model #720930xxx Ethernet CFJ
card as single-port or multi-modem single
port transport as Interface
TeleLite Model #720920xxx
Ethernet OEI card as 4-port
Ethernet Modem
M
o
d
e
m
M
o
d
e
m
M
o
d
e
m
M
o
d
e
m
HVI
300V
Point
Figure 6: Type 2b, Fiber fed
CPE
CPE
CPE
CPE
10 Base-T / 100 Base-TX
Packet
Switche
d
Network
C.O.
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
Optical Network
10 Base-T / 100 Base-TX
TeleLite Model #720930xxx Ethernet CFJ
card as single-port or multi-modem single
port transport as Interface
TeleLite Model #720920xxx
Ethernet OEI card as 4-port
Ethernet Modem
M
o
d
e
m
M
o
d
e
m
M
o
d
e
m
M
o
d
e
m
*

Copyright 2017 Positron, Inc.
8
2.3.1 Type 1a: 720930xxx TeleLite POE Ethernet Card
Located at the Central Office (CFJ)
(Note: Default DIP Switch Settings are shown in Figure 8)
A. If the 720930xxx POE Ethernet card is to be powered by C.O. battery (-48Vdc) then the two on-
board Power Option Jumpers should be set in the LOCAL PWR position. (Figure 7)
B. If the 720930xxx card was to be powered by POE at the C.O. (or CFJ) the Power Option Jumpers
are to be set to the remote power (RMT PWR) positions. (Figure 7)
C. If the 720930xxx TeleLite POE card is placed in the Central Office (C.O.) and is feeding Ethernet to
a remote, unmanned site, such as a solar farm, the Master and Slave switches should be set so
that the 720930xxx card is set as Master, and the companion 720920xxx card located at the OEI
(Optical Electrical Interface) is set as Slave. Alarms will be reported to the manned 720930xxx
located at the Central Office. (Figure 9)
D. If this is a Type 1 Ethernet deployment as described in Section 1.3.1, the 2nd DIP switch should be
set to the left. (Figure 9)
E. If the Ethernet modem that is feeding the TeleLite modem, or is being fed by the TeleLite Ethernet
cards is MDIX enabled(1), then the MDIX feature of the TeleLite Ethernet card should be disabled. If
the associated modems are NOT MDIX enabled, then this DIP switch should be enabled to remove
any need for crossover cables. With this feature enabled or disabled appropriately, there is never a
need with TeleLite Ethernet cards to provision the site with anything but a straight CAT 5 cable. In
this example the Ethernet Modem is MDIX enabled and the feature on the TeleLite Ethernet card is
disabled. (Figure 9)
F. Since the 720930xxx is a POE Ethernet card, the PSE DIP Switch (4th) on this card should always
be in the PSE Disabled position. (Figure 9)
1Ethernet over twisted pair defines a medium dependent interface crossover (MDI-X) interface. Auto MDI-X ports on newer
network interfaces detect if the connection would require a crossover, and automatically chooses the MDI or MDI-X configuration
to properly match the other end of the link.
Figure 9: Meeting conditions C, D, E & F
Figure 8: Default DIP Switch Positions
720930SSC POE
TeleLite Card (CFJ)
Figure 7: Power Setting,
Meeting Condition A

Copyright 2017 Positron, Inc.
9
2.3.2 Type 1b: 720930xxx TeleLite POE Ethernet Card
Located at CFJ, placed at the 300V point of the Substation’s GPR Contour
(Note: Default DIP Switch Settings are shown in Figure 11)
A. If the 720930xxx POE Ethernet card is to be powered by a local supply of -48Vdc, then the
two on-board Power Option Jumpers should be set in the LOCAL PWR position. (Figure 10)
B. If the CFJ is located as mentioned above, it is highly likely that the TeleLite 720930xxx
Ethernet card will be powered using POE and the Power Option Jumpers should be set to the
remote power (RMT PWR) positions unless local a -48Vdc source is used instead. (Figure 10)
C. If the 720930xxx TeleLite POE card is placed as a CFJ at the 300V point of the Substation’s
GPR Contour, and then is feeding Ethernet via fiber to an OEI located at a generation or
distribution substation, such as at a solar farm, the Master and Slave switches should be set
so that the 720930xxx card is set as Slave, and the companion 720920xxx card located at the
OEI (Optical Electrical Interface) is set as Master. If the OEI at the solar farm is the manned
location and set as Master, the alarms will report to the 720920xxx at the OEI from the
720930xxx at the CFJ. (Figure 12)
D. If this is a Type 1 Ethernet deployment as described in Section 1.2.1, the 2nd DIP switch
should be set to the left. (Figure 12)
E. If the Ethernet modem that is feeding the TeleLite modem, or is being fed by the TeleLite
Ethernet cards is MDIX enabled(2), then the MDIX feature of the TeleLite Ethernet card should
be disabled. If the associated modems are NOT MDIX enabled, then this DIP switch should be
enabled to remove any need for crossover cables. With this feature enabled or disabled
appropriately, there is never a need with TeleLite Ethernet cards to provision the site with
anything but a straight CAT 5 cable. In this example the Ethernet Modem is MDIX enabled and
the feature on the TeleLite Ethernet card is disabled. (Figure 12)
F. Since the 720930xxx is a POE Ethernet card, the PSE DIP Switch (4th) on this card should
always be in the PSE Disabled position. (Figure 12)
2Ethernet over twisted pair defines a medium dependent interface crossover (MDI-X) interface. Auto MDI-
Xports on newer network interfaces detect if the connection would require a crossover, and automatically chooses
the MDI or MDI-X configuration to properly match the other end of the link.
Figure 11: Default DIP Switch Positions
Figure 12: Meeting conditions C, D, E & F
720930SSC POE
TeleLite Card (CFJ)
Figure 10: Power
Setting, Meeting
Condition B

Copyright 2017 Positron, Inc.
10
2.3.3 OEI for Type 1a or Type 1b
720920xxx TeleLite PSE Ethernet Card Located at the Substation OEI
(Note: Default DIP Switch Settings are shown in Figure 13)
A. The 720920xxx POE Ethernet card can only be locally powered by a source of -48Vdc. As such
there are no power jumpers to set on this card.
B. The 720920xxx TeleLite PSE card is placed at the Substation’s OEI. If this location is likely to
be manned, the Master and Slave switches should be set so that the 720930xxx card is set as
Slave (See Type 1b, 720930xxx), and the companion 720920xxx card located at the OEI
(Optical Electrical Interface) is set as Master. Alarms will be reported to the attended 720920xxx
located at the OEI at the substation OEI. (Figure 14)
C. If this is a Type 1a or Type 1b Ethernet deployment as described in Section 1.2.1, the 2nd DIP
switch should be set to the left. (Figure 14)
D. If the Ethernet modem fed by the 720920xxx PSE TeleLite Ethernet cards is MDIX enabled(3),
then the MDIX feature of the TeleLite Ethernet card should be disabled. If the associated
modems are NOT MDIX enabled, then this DIP switch should be enabled to remove any need
for crossover cables. With this feature enabled or disabled appropriately, there is never a need
with TeleLite Ethernet cards to provision the site with anything but a straight CAT 5 cable. In this
example the Ethernet Modem is MDIX enabled and the feature on the TeleLite Ethernet card is
disabled. (Figure 14)
E. If the 720920xxx card is to provide PSE to a terminating modem, the 4th DIP Switch is set to the
left. If the Ethernet modem at the OEI is locally powered by a source of -48Vdc, then the 4th DIP
switch is set to the right. (Figure 14)
In this example, the Ethernet modem at the OEI location is powered via the PSE output from the 4
ports on the faceplate of the 720920xxx TeleLite Ethernet card. (Figure 15)
3Ethernet over twisted pair defines a medium dependent interface crossover (MDI-X) interface. Auto MDI-
Xports on newer network interfaces detect if the connection would require a crossover, and automatically chooses
the MDI or MDI-X configuration to properly match the other end of the link.
Figure 13: Default DIP Switch Positions
Figure 14: Meeting conditions B, C, D, & E
720920SSC PSE
TeleLite Card (OEI)
Figure 15: 4 ports of
720920xxx provide
PSE, if enable (DIP
Switch 4)

Copyright 2017 Positron, Inc.
11
2.3.4 Type 2a and Type 2b TeleLite “Campus” Configuration
In a “Campus” Deployment of Ethernet, the TeleLite Ethernet cards are used to transport and
distribute on-site Ethernet services to other buildings or facilities were it is desired to use fiber
instead of copper to carry the Ethernet traffic, either because of the distance limitation on copper or
electrical potential differences. A single multi-port modem or several individual modems can feed
the TeleLite Ethernet card. The actual location may be fed from a network by copper or fiber. See
Figure 16.
Figure 16
Type 2a, Copper-fed
CPE
CPE
CPE
CPE
Modem
‡
10 Base-T / 100 Base-TX
Packet
Switched
Network
C.O.
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
10 Base-T / 100 Base-TX
TeleLite Model #720930xxx Ethernet
CFJ card as single port or multi-port
Modem Interface
TeleLite Model #720920xxx
Ethernet OEI card as 4-port
Ethernet Modem
H
VI
Type 2a, Fiber-fed
CPE
CPE
CPE
CPE
10 Base-T / 100 Base-TX10
Packet
Switched
C.O.
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
10 Base-T/100 Base-TX
TeleLite Model #720930xxx Ethernet CFJ
card as single port or multi-port Modem
Interface
TeleLite Model #720920xxx
Ethernet OEI card as 4-port
Ethernet Modem
Optical
Network
300V Point
300V
Point
Modem‡
‡
Cu Network
300V
Point
Type 2b, Fiber fed
CPE
CPE
CPE
CPE
10 Base-T / 100 Base-TX
Packet
Switched
Network
C.O
.
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
Optical Network
10 Base-T / 100 Base-TX
TeleLite Model #720930xxx Ethernet CFJ
card as single-port or multi-modem single
port transport as Interface
TeleLite Model #720920xxx
Ethernet OEI card as 4-port
Ethernet Modem
M
o
d
e
m
M
o
d
e
m
M
o
d
e
m
M
o
d
e
m
*
*= Fiber to Copper Conversion
‡= Individual Ethernet Modem(s)
*
‡
‡
300V
Point
Type 2b, Copper-fed
CPE
CPE
CPE
CPE
10 Base-T / 100 Base-TX
Packet
Switched
Network
C.O
.
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
NTWK
EDGE
DEVICE
Cu Network
10 Base-T / 100 Base-TX
TeleLite Model #720930xxx Ethernet CFJ
card as single-port or multi-modem single
port transport as Interface
TeleLite Model #720920xxx
Ethernet OEI card as 4-port
Ethernet Modem
M
o
d
e
m
M
o
d
e
m
M
o
d
e
m
M
o
d
e
m
H
VI

Copyright 2017 Positron, Inc.
12
2.3.5 Type 2a and Type 2b, POE
720930xxx TeleLite POE (CFJ) Ethernet Card Fed by On-Site Modem
A. If the 720930xxx POE Ethernet card is to be powered by a local source of -48Vdc then the
two on-board Power Option Jumpers should be set in the LOCAL PWR position. (Figure
17)
B. If the 720930xxx card was to be powered by POE from the feeding modem (or CFJ) the
Power Option Jumpers should be set to the remote power (RMT PWR) positions. (Figure
17)
C. In a “Campus” Ethernet transport configuration, either the OEI (720920xxx) or CFJ
(720930xxx) can be set to Master or Slave since both ends of the transport can be
assumed to be attended for alarming purposes. The only criterion is that one card must be
set to Slave and the other to Master. (Figure 19) In this example, the CFJ (720930xxx)
TeleLite Ethernet card has been set as Master.
D. This is a Type 2 (a or b) deployment so the 2nd DIP switch should be set to the right,
accordingly. (Figure 19)
E. If the Ethernet modem that is feeding the TeleLite Ethernet card or that is being fed by the
TeleLite Ethernet cards is MDIX enabled(4), then the MDIX feature of the TeleLite Ethernet
card should be disabled. If the associated modems are NOT MDIX enabled, then this DIP
switch should be enabled to remove any need for crossover cables. With this feature
enabled or disabled appropriately, there is never a need with TeleLite Ethernet cards to
provision the site with anything but a straight CAT 5 cable. In this example the Ethernet
Modem is MDIX enabled and the feature on the TeleLite Ethernet card is disabled. (Figure
19)
F. Since the 720930xxx is a POE Ethernet card, the PSE DIP Switch (4th) on this card should
always be in the PSE Disabled position. (Figure 19)
4Ethernet over twisted pair defines a medium dependent interface crossover (MDI-X) interface. Auto MDI-
Xports on newer network interfaces detect if the connection would require a crossover, and automatically chooses
the MDI or MDI-X configuration to properly match the other end of the link.
Figure 18: Default DIP Switch Positions
720930SSC POE
TeleLite Card (CFJ)
Figure 17: Power Setting,
Meeting Condition A
Figure 19: Meeting conditions C, D, E & F

Copyright 2017 Positron, Inc.
13
2.3.6 Type 2a and Type 2b, PSE
720920xxx TeleLite PSE (OEI) Ethernet Card Feeding On-Site Modem(s)
A. The 720920xxx POE Ethernet card can only be locally powered by a source of -48Vdc. As
such there are no power jumpers to set on this card.
B. In a “Campus” Ethernet transport configuration, either the OEI (720920xxx) or CFJ
(720930xxx) can be set to Master or Slave since both ends of the transport can be
assumed to be attended for alarming purposes. The only criterion is that one card must be
set to Slave and the other to Master. In this example, the CFJ (720930xxx) TeleLite
Ethernet card has been set as Master. (See 1.5.4.1) This 720920xxx OEI Ethernet card
has been set as Slave. (Figure 23)
C. If this is a Type 2a or Type 2b Ethernet deployment as described in Section 1.5.4, the 2nd
DIP switch should be set to the left. (Figure 23)
D. If the Ethernet modem fed by the 720920xxx PSE TeleLite Ethernet cards is MDIX
enabled(5), then the MDIX feature of the TeleLite Ethernet card should be disabled. If the
associated modems are NOT MDIX enabled, then this DIP switch should be enabled to
remove any need for crossover cables. With this feature enabled or disabled appropriately,
there is never a need with TeleLite Ethernet cards to provision the site with anything but a
straight CAT 5 cable. In this example the Ethernet Modem is MDIX enabled and the feature
on the TeleLite Ethernet card is disabled. (Figure 23)
E. If the 720920xxx card is to provide PSE to a terminating modem, the 4th DIP Switch is set
to the left. If the Ethernet modem at the OEI is locally powered by a source of -48Vdc, then
the 4th DIP switch is set to the right. In this example, PSE is enabled. (Figure 23)
5Ethernet over twisted pair defines a medium dependent interface crossover (MDI-X) interface. Auto MDI-
Xports on newer network interfaces detect if the connection would require a crossover, and automatically chooses
the MDI or MDI-X configuration to properly match the other end of the link.
Figure 22: Default DIP Switch Positions
Figure 23: Meeting conditions B, C, D, & E
720920SSC PSE
TeleLite Card (OEI)
Figure 21: 4 ports of
720920xxx provide
PSE, if enable (DIP
Switch 4)

Copyright 2017 Positron, Inc.
14
2.4 RJ-45 Pin-outs
The RJ-45 Receptacles are NOT polarity sensitive.

Copyright 2017 Positron, Inc.
15
2.5 Optical Connectors
The optical connectors are dependent on the model number of the TeleLite Ethernet card.
2.5.1 Available Varieties
There are three varieties of TeleLite Ethernet cards:
MST
Multi-mode fiber with ST fiber connector (850 ηm wavelength LED)
Range: ≈1.2 miles (2km)
SSC
Single-mode fiber with SC fiber connector (1310 ηm wavelength laser)
Range: ≈30 miles (50km)
XSC
Single-mode fiber with SC fiber connector (1550 ηm wavelength laser)
Range: ≈50 miles (80.5km)
•The foremost optical connector is the TX port to the companion TeleLite Ethernet card
•The rearmost optical connector is the RX port to the companion TeleLite Ethernet card

Copyright 2017 Positron, Inc.
16
2.5.2 Types of Connectors
The ST-type connectors are round in nature. Connection is done by inserting and making a ¼ turn
to the right to lock in place.
The SC-type connectors are square and simply snap into place.
2.6 Faceplate Read-out LEDs (Both POE and PSE Ethernet Cards)
POWER
GREEN indicates that the card has power
RED indicates a reset condition
OFF indicates no power present
LOS (Loss of Signal)
GREEN indicates synchronizer locked to incoming signal
RED indicates a loss of fiber receive rest condition
ALARM
RED indicates a major alarm
OFF indicates no alarm
REM ALM / SLAVE (DUAL Purpose)
GREEN indicates this card is set to Slave Mode (DIP Switch 1)
On the SLAVE unit, there is no other alarm condition reported.
This LED will remain GREEN.
RED indicates that this card has been set as Master (DIP Switch
1), and an alarm condition exists at the companion Slave card
OFF indicates this card is set as MASTER AND THAT THERE
ARE NO ALARMS
RJ-45 Receptacle LEDs
Upper AMBER LED:
ON = Link
OFF = No Link
Flashing = Activity
RJ-45 Receptacle LEDs
RJ-45 Receptacle LEDs
Lower GREEN LED:
ON = 100 Base-TX
OFF = 10 Base-T

Copyright 2017 Positron, Inc.
17
3.0 Specifications
Parameter
Specification
Card Power Consumption
3W max for POE
5W max for PSE
Ethernet Copper Max Distance
As per IEEE 802.3
Ethernet Powering
As per IEEE 802.3af
Fiber Optic Interface
ST/SC type connectors
Transceiver Wavelength
850 ηm (MST-type cards);
1310 ηm (SSC type cards);
1550 ηm (XSC type cards)
MST TeleLite Fiber Loss Budget
21dB
SSC TeleLite Fiber Loss Budget
28dB
XSC TeleLite Fiber Loss Budget
35dB
Maximum Fiber Span
Multi-mode (MST Cards): 2km (1.2 miles)
Single Mode (SSC Cards): 16km (9.9 miles)
Single Mode (XSC Cards): 80km (50 miles)
Transceiver Wavelength
850 ηm (MST-type cards);
1310 ηm (SSC type cards);
1550 ηm (XSC type cards)
Fiber Optic Type
Multi-mode fiber: 62.5/125 μm (MST type cards)
Single-mode fiber: 9/125 μm (SSC and XSC type cards)
Operating Temperature
-40°C to 65°C (-40°F to 149°F)
Storage Temperature
-40°C to 85°C (-40°F to 185°F)
Humidity (non-condensing)
20% to 80%
Altitude
-60m to 3,050m (-200 ft to 10,000 ft) relative to sea level

Copyright 2017 Positron, Inc.
18
4.0 Important Information
4.1 Service and Support
Positron Contact Information
General information
Positron Inc.
591 Buchan Street
Montreal, Québec, Canada
H4P 2R9
US and Canada: 1-888-577-5254
International: 1-514-345-2214
Fax: [phone]
E-mail: [e-mail]
Web site : www.positronpower.com
Repairs
US and Canada: 1-888-577-5254, Option 1
International: 001-514-345-2220, Option 1
4.2 Technical Customer Support
Positron is committed to providing excellent ongoing technical support to its customers. A team of
specialists is always available for telephone consultations, or for on-site visits to assist in
maintenance and troubleshooting.
For pricing information or assistance in the planning, configuration, use and interpretation of data of
the equipment, contact Technical Customer Support (TCS) at 1-888-577-5254, Option 1, Option 3
(US and Canada) or [phone] Option 1, Option 3 (International).
4.3 Repair Service
All warranty repairs are performed at no cost. Positron reserves the right to repair or replace any
equipment that has been found to be defective.
For information about out-of-warranty repairs, contact Positron’s Repair department at 1-888-577-
5254 (US and Canada) or 001-514-345-2220 (International).
Due to the varied nature of repairs, no specific turnaround can be guaranteed, but average
turnaround time is two weeks from date of receipt. In emergency situations, special arrangements
can be made. All repaired items are warranted for a period of 180 days.
Before returning any items to Positron for repair, warranty repair or replacement, call the Repair
Department to obtain a Return Material Authorization (RMA) number. Parts returned without RMA
numbers cannot be accepted. The RMA number must always be clearly marked on all boxes and
crates and on all shipping documents. Bulk repairs (more than five items) will require additional
processing time, so please take this into consideration when requesting an RMA.
To accelerate the repair process, whenever possible, include a report detailing the reason for
return with the unit(s). Also, please include the name and phone number of a contact person
should our Repair department need further information.
When packing items being returned for repair, please ensure they are properly packed and shipped
in their carrying cases to avoid further damage.

Copyright 2017 Positron, Inc.
19
4.4 Warranty
Subject to the provisions of this paragraph, Positron warrants that the equipment shall perform in
accordance with Positron's specifications. The warranty remains valid for one (1) year from the
date of shipment. The warranty fully covers workmanship, materials and labor. Positron shall, at its
sole discretion, repair or replace the problem unit.
During the warranty period, freight costs to ship defective equipment to Positron are borne by the
Customer, while the return of replaced or repaired equipment is at Positron's expense.
4.5 Limitation of Liability
Subject to anything to the contrary contained herein, Positron's sole obligation and liability and the
customer's sole remedy for Positron's negligence, breach of warranty, breach of contract or for any
other liability in any way connected with or arising out of, the equipment or any services performed
by Positron shall be as follows:
In all situations involving performance or non-performance of the equipment or any component
thereof, the customer's sole remedy shall be, at Positron's option, the repair or replacement of the
equipment or said component.
For any other claim in any other way related to the subject matter of any order under, the customer
shall be entitled to recover actual and direct damages; provided that Positron's liability for damages
for any cause whatsoever, and regardless of the form of the action, whether in contract or in tort
(including negligence), shall be limited to the value of the order.
Positron shall not be obligated to repair or replace any item of the equipment which has been
repaired by others, abused or improperly handled, improperly stored, altered or used with third
party material or equipment, which material, or equipment may be defective, of poor quality or
incompatible with the equipment supplied by Positron, and Positron shall not be obligated to repair
or replace any component of the equipment which has not been installed according to Positron
specifications.
IN NO EVENT SHALL POSITRON BE LIABLE FOR ANY INDIRECT, INCIDENTAL, SPECIAL,
CONSEQUENTIAL, PUNITIVE, EXEMPLARY OR SIMILAR OR ADDITIONAL DAMAGES
INCURRED OR SUFFERED INCLUDING LOSS OF PROFITS, LOSS OF REVENUES, LOSS OF
DATA, LOSS OF BUSINESS INFORMATION, LOSS OF GOODWILL, LOSS OF LIFE, STAFF
INJURY, LOSS OF EXPECTED SAVINGS OR BUSINESS INTERRUPTION ARISING OUT OF
OR IN CONNECTION WITH THE EQUIPMENT, A PURCHASE ORDER SUPPLIES,
MAINTENANCE SERVICES OR OTHER SERVICES FURNISHED HEREUNDER, EVEN IF
POSITRON HAS BEEN ADVISED OR IS AWARE OF THE POSSIBILITY OF SUCH DAMAGES.
EXCEPT AS EXPRESSLY SET FORTH IN THIS AGREEMENT, POSITRON DISCLAIMS ANY
FURTHER CONDITIONS, REPRESENTATIONS OR WARRANTIES, WHETHER WRITTEN OR
ORAL, EXPRESSED OR IMPLIED, INCLUDING THE CONDITIONS AND WARRANTIES OF
MERCHANTABILITY, MERCHANTABLE QUALITY, FITNESS FOR A PARTICULAR PURPOSE,
TITLE, PERFORMANCE AND THOSE ARISING FROM STATUE, TO THE EXTENT PERMITTED
BY LAW. POSITRON DOES NOT WARRANT THAT THE SYSTEM WILL OPERATE WITHOUT
INTERRUPTION OR THAT IT WILL BE ERROR FREE.
