Power Drive 100D User manual

powerdriveinverters.com
100D
100 Watt
DC to AC
Power Inverter
Owner’s Guide
Please Save for Future Reference

Thank you for purchasing the POWERDRIVE100D power inverter, a high
performance solution to using household power while on the road. Please read
and understand all of the information provided in this manual before operating or
installing. If properly used, the inverter will give you years of reliable service
providing AC power for TVs, computers and stereos. For safe and optimum
performance, the inverter must be installed and used properly. Carefully read and
follow the guidelines in this manual giving special attention to the CAUTION and
WARNING statements. Keep this manual for reference should troubleshooting be
necessary.
CAUTION statements provide information that could damage your inverter or
equipment connected to it.
WARNING statements provide information on conditions that could result in
personal injury or loss of life.
WARNING: Incorrect installation or misuse of the RPPD100D could result in
personal injury or damage to the inverter and/or attached equipment. Read
and follow the directions in the owner’s manual. The ROADPRO RPPD100D
produces the same potentially lethal AC power as normal household outlets.
It is suggested that you treat it with the same respect that you would any AC
outlet.
WARNING: SHOCK HAZARD, KEEP AWAY FROM CHILDREN.
DO NOT insert any foreign objects into the RPPD100D’s outlets, vents or fan
openings.
DO NOT expose the RPPD100D to rain, water or any other liquids.
DO NOT connect the RPPD100D to utility power distribution systems or
branch circuits.
WARNING: HEATED CASE AND SURFACE.
The case to the RPPD100D may become very warm under high power
operation reaching 140°F. Be sure that there is at least 4 inches of
unobstructed air space around the entire surface of the inverter at all times.
During use, DO NOT place materials that could be damaged by heat on or
near the RPPD100D.
WARNING: EXPLOSION HAZARD.
DO NOT operate the RPPD100D near flammable fumes or gases such as the
bilge of a gasoline power boat or near propane tanks.
DO NOT operate the RPPD100D in an enclosed area that contains automotive
type lead-acid batteries. This type of battery emits explosive hydrogen gas
which can be ignited by sparks.

CAUTION:
DO NOT connect any AC device which has its neutral conductor connected
to ground.
DO NOT expose the RPPD100D to air temperatures in excess of 104°F.
DO NOT use the RPPD100D on the following items:
1. Small battery-operated appliances such as flashlights, razors and
nightlights that can be plugged directly into an AC outlet to recharge.
2. Certain battery chargers for battery packs used in hand power tools. These
chargers will have a “Warning Label” indicating that dangerous voltages
are present at the battery terminals.
RPPD100D Waveform Output:
The output waveform of your RPPD100D is referred to as “square wave” or
“modified sine wave.” Some very sensitive electronic equipment and some
medical equipment (listed below) may not operate satisfactorily on “square
wave” or “modified sine wave.” It is a stepped waveform designed to have
characteristics similar to the pure sine wave shape of utility power. A
waveform of this nature is suitable for most AC loads (including linear and
switching power suppliers used in electronic equipment, transformers and
motors).
The problems described above, do not occur with most battery-operated
equipment. The vast majority of these items use a separate charger or
transformer that plugs into the AC outlet and produces a low voltage output.
If the label on your adapter states that it produces a low voltage (AC or DC)
output (30 volts or less) then the RPPD100D will operate the item safely.
Some of the following items may not operate properly on a “square wave”
inverter. If you have any questions, contact the device’s manufacturer.
• Laser printers, photocopiers, magneto-optical hard drives.
• Certain laptop computers.
• Some battery chargers for cordless tools and razors.
• Digital clocks with radios.
INSTALLATION:
Insert plug into your vehicle’s cigarette lighter socket or accessory power port.
NOTE: Make sure the cigarette lighter, or power port socket is clean and provides
a tight fit for the plug. For safety, unplug the RPPD100D when not in use.

Operating Indicators:
Green LED Indicator on top of your inverter will light to indicate power to your
inverter.
Current Overload Protection:
If the inverter is overloaded, it will shut down to protect itself. To restore
normal operation, disconnect the excessive load and turn the unit Off and
disconnect the plug.
Low Voltage Protection:
If the input voltage drops to 10.5V or less, the inverter will shut down to
protect the battery. To restore normal operation, return the DC input voltage
to at least 12V. The inverter will automatically return to normal operation.
High Voltage Protection:
If the DC input voltage rises above 15 volts, the inverter will shut down to
protect itself. To restore normal operation, return the DC input voltage to less
than 15 volts. The inverter will automatically return to normal operation.
CAUTION: Although the inverter has protection against over-voltage, it may
still be damaged if the input voltage were to exceed 16 volts.
Over Temperature Protection:
If the inverters internal temperature rises to 104ºF, the inverter will shut down
to protect itself.
NOTE: Internal inverter temperature can rise due to being operated in a high
heat environment or due to the fan or vents being blocked during operation
(even in relatively cool outside air). To restore normal operation, turn the unit
off and allow it to cool. The inverter will automatically return to normal
operation after it has cooled.
USB Outlet; The USB outlet will supply 5 volts at 500ma to charge and power
cell phones, iPods®and other small electronics.
Operating Limits
Power Output:
The inverter can deliver 100 watts for about 60 minutes. The inverter must
cool for 15 minutes before it can resume operation at 100 watts.

NOTE: Operating time will vary depending upon the type, capacity charge
level of the battery, and the power draw of the AC products you are using.
With a normal vehicle battery and a 100 watt load (such as a small television)
you can expect an operating time of 2 to 3 hours. It is recommended that you
start your vehicle once an hour when using the RPPD100D for extended
periods of time to prevent draining the battery.
WARNING: To prevent personal injury or loss of life, never start or leave your
engine running in a poorly ventilated area such as a garage.
Helpful Formulas:
To Convert AMPS to WATTS: AMPS X VOLTS = WATTS
To Convert WATTS to AMPS: WATTS ÷ VOLTS = AMPS
These formulas yield a close approximation of the continuous loads of a product.
EEssttiimmaatteeddWWaattttssUUsseeddbbyyCCoommmmoonnAApppplliiaanncceessaannddTToooollss
Appliance Approx. Watts
Cell phone 10
VCR 40-60
CD or DVD player 40
Xbox Console 100
7" to 10" LCD television 50 » 150
Laptop computer (recharge battery) 150
Specifications:
Operating AC Voltage (Normal) . . . . . . . . . . . . . . . . . . . . . . 105~125-Volts AC
DC Input Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10~15-Volts DC
Continuous AC Power Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 Watts
USB Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Volts DC
Maximum AC Power Output (Surge) . . . . . . . . . . . . . . . . . . . . . . . . . 175 Watts
AC Output Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60Hz ±2Hz
AC Output Waveform . . . . . . . . . . . . . . . . . . . . . . . . . . . . Modified Sine Wave
Battery Drain with No AC Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.50 Amps
Efficiency (Maximum). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87%
Ambient Operating Temperature Range. . . . . . . . 14°F (-10°C) ~ 104°F (40°C)
Low Battery Shut Down Point . . . . . . . . . . . . . . . . . . . . . . 10.5 ±0.3-Volts DC
High Voltage Shut Down Point . . . . . . . . . . . . . . . . . . . . . . 15.5 ±0.5-Volts DC
Specifications Subject to Change without Notice

Problem/Symptom Possible Causes Solution
Low output voltage Overloaded Reduce the load.
No output voltage Low input Voltage Let battery recharge.
No power when operating at full 100 watts Thermal Shutdown Allow inverter to cool down.
Reduce load.

This Limited One Year Warranty from POWERDRIVE, a DAS brand, applies to all
electronic products and devices manufactured by DAS Distributors and sold under the
brand name POWERDRIVE.
Terms of the Warranty:
POWERDRIVE warrants that the product you have purchased from a DAS authorized
retailer is free from defects in materials and workmanship under normal use during the
warranty period. The warranty period begins on the day of retail sale. This warranty
extends only to the original purchaser. It is not transferable to anyone who subsequently
receives the product. It excludes all expendable parts (fuses, etc). During the warranty
period POWERDRIVE will repair your defective product, replace it with an identical item,
or at our option exchange it for an equivalent product of value and performance. This
Limited Warranty does not extend to any product that has been damaged or rendered
defective as a result of: an accident, misuse or abuse, as a result of an act of God, by
operation outside the usage parameters stated in this manual, by modification of the
product, attempted repair, or as a result of war or terrorist attack. Other limitations of this
warranty exclude; payment for your lost time, loss of use of your product, or property
damage caused by the product or its failure to work, or any other incidental or
consequential damages including personal injury. Except as expressly set forth in this
warranty statement, POWERDRIVE makes no other warranties expressed or implied.
Defective products must be returned to the dealer within 30 days, after 30 days, the
product may be returned to POWERDRIVE.
When returning products to POWERDRIVE: Shipping to POWERDRIVE shall be prepaid,
your replacement will be mailed back to you at no additional charge. Carefully pack
product and all included accessories into a suitable box, along with original dated
register receipt or invoice, a letter stating the defect, daytime phone number, and a
physical return address. (UPS will not deliver to a PO Box.)
• Any package with a PO Box address will not be processed, and will be held until
further notification from you.
• Make sure you can track your shipment to us. POWERDRIVE will not be responsible
for lost packages.
• POWERDRIVE will not be responsible for damage incurred during shipment to us.
• Failure to provide a dated proof of purchase will invalidate warranty.
Ship to:
POWERDRIVE Returns
1875 Zeager Road, Elizabethtown, PA 17022
For customer assistance and technical support call 1-866-622-7979 Monday through
Friday 8:00am to 5:00pm Eastern Time. Or write to: [email protected]

1875 Zeager Road, Elizabethtown, PA 17022
© POWERDRIVE
