Power Tec BF800 User manual

Owner’s Manual
Model No. BF800
21_0309
You will need this manual for safety instructions, operating procedures, and warranty.
Put it and the original sales invoice in a safe, dry place for future reference.
Visit us on the web at powertecproducts.com
QUESTION...
1•847•780•6120
8" Heavy Duty Bench Buffer

Electrical Rating ............ 1/2 HP, 120V, 60 Hz, 2.5A
Motor No Load Speed.....................1750 RPM
Max. Accessory Diameter.................8" (203 mm)
Arbor Size ..........................5/8" (15.88 mm)
Recommended Run Time..................30 Minutes
Rotation (when viewed from left side)..........Clockwise
PRODUCT
SPECIFICATIONS
TABLE OF CONTENTS
SAFETY RULES 1
Work Preparation
Work Area Preparation
Tool Maintenance
Tool Operation
ASSEMBLY 3
OPERATION 5
MAINTENANCE 6
TROUBLESHOOTING 7
PARTS ILLUSTRATION
& LIST 8
WARRANTY 10
SECTION PAGE
Unpacking
Tools Needed
Set Up
Permanent Mounting
Power Source
Grounding Instructions
Extension Cords
On/Off Switch
Basic Operation
General Maintenance
Cleaning
SPECIFIC SAFETY RULES 2

SAFETY RULES 1
WARNING
For your own safety, read and understand all warnings and
operating instructions before using any tool or equipment.
WARNING
Some dust created by operation of power tool contains
chemicals known to the State of California to cause cancer, birth
defects or other reproductive harm. To reduce your exposure
to these chemicals, work in a well ventilated area and work
with approved safety equipment. Always wear OSHA/NIOSH
approved, properly fitting face mask or respirator when using
such tools.
WARNING
Failure to follow these rules may result in serious personal injury.
Remember that being careless for even a fraction of a second
can result in severe personal injury.
WORK PREPARATION
• Wear proper apparel. Do not wear loose clothing,
gloves, neckties, rings, bracelets or other jewelry which
may get caught in moving parts of the tool.
• Nonslip protective footwear is recommended. Wear
protective hair covering to contain long hair.
• Wear eye and hearing protection. Always use safety
glasses. Eye protection equipment should comply with
ANSI Z87.1 standards. Hearing equipment should
comply with ANSI S3.19 standards.
• Wear face mask or dust mask if operation is dusty.
• Be alert and think clearly. Never operate power tools
when tired, intoxicated or when taking medications that
cause drowsiness.
WORK AREA PREPARATION
• Keep work area clean. Cluttered work areas and
benches invite accidents.
• Work area should be properly lit.
• Do not use the machine in a dangerous environment.
The use of power tools in damp or wet locations or in
rain can cause shock or electrocution.
• Three‑prong plug should be plugged directly into
properly grounded, three‑prong receptacle.
• Use the proper extension cord. Make sure your
extension cord is in good condition. It should have
grounding prong and should be of the correct gauge.
• Keep children and visitors away. Your shop is a
potentially dangerous environment. Children and visitors
can be injured.
• Make your workshop childproof with padlocks, master
switches or remove switch keys to prevent any
unintentional use of power tools.
WARNING TOOL MAINTENANCE
• Turn the machine "OFF", and disconnect the machine
from the power source prior to inspection.
• Maintain all tools and machines in peak condition. Keep
tools sharp and clean for best and safest performance.
• Follow instructions for lubricating and changing
accessories.
• Check for damaged parts. Check for alignment of
moving parts, binding, breakage, mounting and any
other condition that may affect tool's operation.
• Poorly maintained tools and machines can further
damage the tool or machine and/or cause injury.
• A guard or any other part that is damaged should be
repaired or replaced. Do not perform makeshift repairs.
TOOL OPERATION
• Avoid accidental start‑up. Make sure that the tool is in
the “OFF” position before plugging in.
• Use the right tool for your job. Do not force your tool or
attachment to do a job for which it was not designed.
• Disconnect tool when changing parts.
• Don't force the workpiece on the machine. Damage to
the machine and/or injury may result.
• Never leave tool running unattended. Turn the power off
and do not leave tool until it comes to a complete stop.
• Do not overreach. Loss of balance can make you fall
into a working machine, causing injury.
• Never stand on tool. Injury could occur if the tool tips, or
if you accidentally contact the cutting tool.
• Know your tool. Learn the tool’s operation, application
and specific limitations before using it.
• Use a proper extension cord of the correct gauge. Your
extension cord should have a grounding prong, and
should be in good condition.
• Handle workpiece correctly. Keep hands away from
moving parts.
• Turn tool off if it jams.
• Always feed workpiece against the direction of the
sanding rotation. To maintain control, properly support
long or wide workpieces.
CAUTION
Think safety! Safety is a combination of operator common sense
and alertness at all times when tool is being used.
WARNING
Do not attempt to operate tool until it is completely assembled
according to the instructions.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
1
SAFETY RULES

SPECIFIC SAFETY RULES FOR BENCH BUFFER
2
2
SPECIFIC SAFETY RULES
Be aware of general power tool safety. Make sure all the safety
rules are understood.
• Wear eye protection.
• Use buffing wheel suitable for speed of bench buffer.
• Do not buff with side of wheel.
• DO NOT use grinding wheels or other unintended accessories
on this bench buffer.
• DO NOT operate with any guard disabled, damaged
or removed.
• The use of accessories or attachments not recommended by
the manufacturer may result in a risk of injury to persons.
• When servicing use only identical replacement parts.
• Only use safety equipment that has been approved by an
appropriate standards agency. Unapproved safety equipment
may not provide adequate protection. Eye protection
must be ANSI‑approved and breathing protection must be
NIOSH‑approved for the specific hazards in the work area.
• Stay alert, watch what you are doing and use common sense
when operating a power tool.
• Do not use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious
personal injury.
• Industrial applications must follow OSHA guidelines
• Maintain labels and nameplates on the tool. These carry
important safety information.
• Avoid unintentional starting. Prepare to begin work before
turning on the tool.
• People with pacemakers should consult their physician(s)
before use. Electromagnetic fields in close proximity to
heart pacemaker could cause pacemaker interference or
pacemaker failure.
WARNING
Handling the cord on this product will expose you to
lead, a chemical known to the State of California to
cause cancer, and birth defects or other reproductive
harm. Wash hands after handling. (California Health &
Safety Code § 25249.5, et seq.)
• The warnings, precautions, and instructions discussed in this
instruction manual cannot cover all possible conditions and
situations that may occur.
• It must be understood by the operator that common sense and
caution are factors which cannot be built into this product, but
must be supplied by the operator.
Vibration Safety
This tool vibrates during use. Repeated or long‑term exposure
to vibration may cause temporary or permanent physical injury,
particularly to the hands, arms and shoulders. To reduce the risk
of vibration‑related injury:
• Anyone using vibrating tools regularly or for an extended
period should first be examined by a doctor and then have
regular medical check‑ups to ensure medical problems are
not being caused or worsened from use. Pregnant women
or people who have impaired blood circulation to the hand,
past hand injuries, nervous system disorders, diabetes, or
Raynaud’s Disease should not use this tool. If you feel any
medical or physical symptoms related to vibration (such as
tingling, numbness, and white or blue fingers), seek medical
advice as soon as possible
• Do not smoke during use. Nicotine reduces the blood
supply to the hands and fingers, increasing the risk of
vibration‑related injury.
• Use tools with the lowest vibration when there is a choice
between different processes.
• Include vibration‑free periods each day of work.
• Let the tool do the work.
• To reduce vibration, maintain the tool as explained in
this manual. If any abnormal vibration occurs, stop use
immediately.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE

UNPACKING
Refer to Figure 1
• Check for shipping damage. Check immediately whether all
parts and accessories are included. The bench buffer itself
comes assembled as one unit. Additional parts (listed below)
which need to be fastened to bench buffer, should be located
and accounted for before assembling.
• The following items are included with your bench buffer:
Item Description Qty.
ABuffer 1
BFlanges 4
CSpacers 2
DArbor Nuts (left M16LH and right M16RH) 2
EBuffer Wheels 2
Figure 1
A
BC D
E
LEFT RIGHT
E
• Carefully remove the tool and any accessories from the box.
• Make sure that all items listed in the packing list are included.
• Inspect the tool carefully to make sure no breakage or damage
occurred during shipping. Do not discard the packing material
until you have carefully inspected and satisfactorily operated
the tool.
CAUTION
Do not attempt assembly if parts are missing. Call the Customer
service line to obtain replacement parts.
WARNING
Do not operate bench buffer, until completely assembled.
Do not operate this tool until you have completely read
and understood this manual.
WARNING
To avoid injury, make sure all parts are assembled and
adjusted properly before plugging the bench buffer into a
power outlet and turning it ON.
ASSEMBLY 3
TOOLS NEEDED
You will need the following tools to assemble and adjust the
machine. (The tools are not included.)
• 15/16 open end or adjustable wrench
• 1/2" wrench
SET UP
WARNING
Always place the ON/OFF switch in the OFF position
and unplug the power cord from its power source before
performing any assembly or adjustment. Failure to do so
could result in accidental starting resulting in possible serious
personal injury.
WARNING
To prevent serious injury from accessory failure. Do not use
grinding wheels or other unintended accessories with this
bench buffer.
NOTE: "LEFT" and "RIGHT" are as seen from in front of the
bench buffer, facing the switch.
TO ASSEMBLE THE BUFFER WHEELS
1. Remove the packaging sleeves (if equipped) from
the shafts.
2. Slide the spacer onto the shaft. NOTE: The spacers are
not always needed, for example when using thicker wheels.
The purpose of the spacers is to set the flanges and wheels
away from the step in the shaft, allowing the arbor nuts to be
threaded onto the shafts to secure the wheels in place.
Figure 2
Spacer
Arbor Nut
Flange
(cupped side to
buffing wheel)
Flange
(cupped side to
buffing wheel)
3. Slide the inner flange onto the shaft with the cupped side
facing the threaded end of the shaft. The cupped side will be
against the buffing wheel when assembled.
4. Slide the buffing wheel onto the shaft and up against the
inner flange.
5. Slide the outer flange onto the shaft and up against the
buffing wheel. The cupped side should be facing towards
the buffing wheel.
3
ASSEMBLY

6. Thread the arbor nut onto the shaft to secure the
buffing wheel in place. NOTE: The left hand arbor hex
nut is left hand threaded and is installed by rotating it
counterclockwise onto the threaded shaft. The right hand
arbor hex nut is right hand threaded and is installed by
rotating it clockwise onto the shaft.
7. Repeat the steps to assemble the second buffing wheel.
PERMANENT MOUNTING
Refer to Figure 3
Mounting hardware or stand are sold separately
CAUTION
To avoid serious injury, the buffer MUST be permanently
mounted to a work surface or temporarily clamped to a table,
stand or board/plywood. If clamps are used, make sure the
clamps do not interfere with the buffing wheels, the movement of
the user or the material during use.
Use the mounting holes in the base of the machine to firmly
attach the buffer to a solid work surface or stand. The two
mounting holes are 7/16" in diameter and 7‑3/4" apart.
Figure 3
POWER SOURCE
WARNING
Do not connect to the power source until the machine is
completely assembled.
The machine is wired for 120 volts, 60 HZ alternating current.
Before connecting the machine to the power source, make sure
the switch is in the “OFF” position. Running the unit on voltages
which are not within range may cause overheating and motor
burn‑out. Heavy loads require that voltage at motor terminals be
no less than the voltage specified on nameplate.
GROUNDING INSTRUCTIONS
WARNING
Improper connection of equipment grounding conductor can
result in the risk of electrical shock.
• The machine should be grounded while in use to protect
operator from electrical shock.
• In the event of an electrical short circuit, grounding reduces
the risk of electrical shock by providing an escape wire for the
electric current.
• This machine is equipped with an approved 3‑conductor cord
rated at 120V and a 3‑prong grounding type plug for your
protection against shock hazards.
• Grounding plug should be plugged directly into a properly
installed and grounded 3‑prong grounding‑type receptacle, as
shown (Figure 4).
Figure 4
Properly Ground Outlet Box
3‑Prong Plug
Grounding Prong
• The plug must be plugged into an outlet that is properly
installed and grounded in accordance with all local codes
and ordinances.
• Check with a qualified electrician or service personnel if these
instructions are not completely understood or if in doubt as to
whether the tool is properly grounded.
• Do not modify plug provided. If it will not fit in outlet, have
a proper outlet installed by a qualified electrician. Use only
3‑wire extension cords, that have 3‑prong grounding type
plugs and matching 3‑conductor receptacles that accept the
machine’s plug, as show in Figure 4.
WARNING
Do not permit fingers to touch the terminals of plug when
installing or removing from outlet.
Inspect tool cords periodically, and if damaged, have it
repaired by an authorized service facility.
• The conductor with insulation having an outer surface
that is green with or without yellow stripes is the
equipment‑grounding conductor. If repair or replacement of
the electric cord or plug is necessary, do not connect the
green (or green and yellow) wire to a live terminal.
• A temporary 3‑prong to 2‑prong grounding adapter may be
used to connect this plug to a matching 2‑conductor receptacle
as shown in Figure 5. The temporary adapter should be used
only until a properly grounded outlet can be installed by a
qualified electrician.
Grounded Lug
Adapter
3‑Prong Plug
Make Sure This
is Connected to a
Known Ground
2‑Prong Receptacle
Figure 5
In Canada, the use of temporary adapter is not permitted by the
Canadian Electric Code. Where permitted, the rigid green tab or
terminal on the side of the adapter must be securely connected
to a permanent electrical ground such as a properly grounded
water pipe, a properly grounded outlet box or a properly
grounded wire system.
4
ASSEMBLY

5
ASSEMBLY
• Many cover plate screws, water pipes and outlet boxes are not
properly grounded. To ensure proper grounding means that it
must be tested by a qualified electrician.
EXTENSION CORDS
Use proper extension cords. Make sure the extension cord is
in good condition. Use only 3‑wire extension cords that have
3‑prong grounding type plugs and 3‑pole receptacles which
accept the tool plug. When using an extension cord, make sure
to use one heavy enough to carry the current of the machine.
An undersized cord will cause a drop in the voltage, resulting in
loss of power and overheating. Use the table to determine the
minimum wire size (A.W.G.) Extension cord.
Extension Cord Length
Wire Size…………….. A.W.G.
Up to 25 ft…………… 18 gauge
NOTE: Using extension cords over 25 ft. long is
not recommended.
The following section is designed to give instructions on the
basic operations of this buffer.
ON/OFF SWITCH
Refer to Figure 6
The buffer is equipped with a keyed switch to prevent
unauthorized use.
CAUTION
Remove the safety key whenever the buffer is not in use. Place
the safety key in a safe place and out of the reach of children.
1. To turn buffer ON, insert the safety key into the key slot in
the center of the switch.
2. Push safety key firmly into the slot and then place the ON/
OFF switch in the ON position to start the buffer.
3. To turn the buffer OFF, place the ON/OFF switch in the
OFF position.
4. When the buffer comes to a complete stop gently pull the
safety key forward and out. Place the key in a safe place out
of the reach of children.
Safety Key
Key Slot
Figure 6
BASIC OPERATION
Refer to Figure 7‑8
WARNING
To avoid kickback and other hazards, never buff on the sides,
top or rear of the cotton buffing wheels.
WARNING
To prevent serious injury from tool failure, do not use damaged
equipment. If abnormal noise or vibration occurs, have the
problem corrected before further use.
OPERATION 5
5. Stand to the side of the buffer, make sure the ON/OFF
switch is in the OFF position and plug in the tool.
6. Remain standing to the side of the buffer and place the ON/
OFF switch in the ON position to turn on the unit.
Figure 7
On/Off
Switch
7. Allow the buffing wheels to come up to a steady speed and
run for at least one minute before any buffing. NOTE: If
needed, apply buffing compound to the rim of the rotating
buffer wheel. DO NOT jam or force the compound bar into
the buffer wheel, cover the buffer wheel rim completely with
the compound material. Buffing compound is not needed for
the final polishing, use an clean cotton buffing wheel for the
final polishing.
8. Using two hands, firmly hold the workpiece and gently move
it into contact with the buffing wheel. Move the workpiece
back and forth across the lower front surface of the wheel to
buff the workpiece to the desired finish.
NOTE: The correct pressure must be applied to the workpiece
to provide the best finish. Too little pressure will result in no
significant change in the workpiece. Too much pressure may
slow down the action of the buffing wheel and cause uneven
marks on the workpiece and overheat the motor.
Figure 8
Wheel
Rotation
WORK
AREA ON
WHEEL
View is from the Right Side
OPERATION
5

MAINTENANCE
6
MAINTENANCE
6
OPERATION
6
OPERATION
9. Every few minutes, check the condition and wear of the
buffing wheels and buffing compound coating.
• If the wheel is worn or damaged, remove and
replace immediately.
• If the rim surface is glazed over from material residue or
new/different grade (color) of compound is needed, use a
buffing rake to remove the old compound from the wheel.
10. When buffing is finished, remove the workpiece from the
buffing wheel before turning bench buffer OFF.
11. After completing the buffing and polishing operations,
turn the buffer OFF. NOTE: It will take a few minutes for
the buffing wheels to come to a complete stop. NEVER
STOP THE BUFFER BY FORCING MATERIAL INTO THE
WHEEL. Let the buffer stop rotating on its own.
12. Unplug the buffer from the power source. IMPORTANT: To
prevent unauthorized use of the machine, the power switch
has a removable locking key. With the power switch in the
OFF position, pull the locking key out. The Buffer can not be
turned ON with the key removed.
13. To resume buffing, insert the locking key into the ON/
OFF switch.
WARNING
Always place the ON/OFF switch in the OFF position
and unplug the power cord from its power source before
performing any assembly or adjustment. Failure to do so
could result in accidental starting resulting in possible serious
personal injury.
6
GENERAL MAINTENANCE
WARNING
Repairs to the bench buffer should be performed by trained
personnel only. Unauthorized repairs or replacement with
non‑factory parts could cause serious injury to the operator and
damage to the bench buffer.
WARNING
If the supply cord of this power tool is damaged, have it replaced
by a qualified service technician.
Before each use, inspect the general condition of the tool.
Check for:
• loose hardware,
• misalignment or binding of moving parts,
• cracked or broken parts,
• damaged electrical wiring, and
• any other condition that may affect its safe operation
CLEANING
After each use, wipe external surfaces of the tool with a
clean cloth.
Hand wash the buffing wheels using mild detergents, air dry. If
a buffing wheel has become too hard, use a stiff wire brush (not
included) to fluff it up.
Do not immerse any part of the tool in liquid.
WARNING
Periodically blow dirt and dust out of all air vents with clean,
dry air. To minimize the risk of eye injury, always wear ANSI
approved eye protection and NIOSH approve breathing
protection when performing this.

TROUBLESHOOTING
SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION
Motor does not run. 1. Machine not plugged in. 1. Plug power cord into electrical receptacle.
2. Power switch in OFF position. 2. Place ON/OFF switch to ON position.
3. Power cord is faulty. 3. Replace power cord.
4. Fuses or circuit breaker is open. 4. Overloaded electrical circuit.
Motor stalls or runs slow. Undersized or excessive length of
extension cord.
Use correct size.
Decreased performance Accessory is dull or damaged Replace accessory, always use sharp accessories.
Motor runs hot 1. Motor is overloaded. 1. Reduce pressure on workpiece.
2. Poor air circulation around motor. 2. Remove any blockage around motor.
3. Accessory is dull or damaged 3. Replace accessory, always use
sharp accessories.
4. Undersized or excessive length of
extension cord.
4. Use correct size.
Fuse blows or circuit
breaker trips.
1. Motor is overloaded. 1. Reduce pressure on workpiece.
2. Overloaded electrical circuit breaker. 2. Reduce the amount of items on circuit
3. Wrong fuse or circuit breaker 3. Replace with correct fuse or circuit breaker.
4. Defective cord, plug or switch creating a
short circuit.
4. Replace with new parts
5. Undersized or excessive length of
extension cord.
5. Use correct size.
7
TROUBLESHOOTING
7

8" HEAVY DUTY BENCH BUFFER PARTS ILLUSTRATION
8
PARTS LIST
8

8" HEAVY DUTY BENCH BUFFER PARTS LIST 9
PARTS LIST
9
Key# Part# Description Spec. Qty
1 BF800001 Type I hex nut (left) M16 LH 1
2 BF800002 Flange 4
3 BF800003 Spiral sewn cotton
buffing wheel
8" diameter x
1/2" width, with
a 5/8" bore
2
4 BF800004 Spacer 2
5 BF800005 Hex flange nut M5 2
6 BF800006 End cap 2
7 BF800007 Wave washer D40 1
8 BF800008 Bearing 6203 2
9 BF800009 Power cord 1
10 BF800010 Clip plate 1
11 BF800011 Rotor 1
12 BF800012 Type I hex nut (right) M16 RH 1
13 BF800013 Stator 1
14 BF800014 Philips pan screw
and flat washer
assembly
M5x200 2
15 BF800015 Outer locking
washer
D4 1
Key# Part# Description Spec. Qty
16 BF800016 Philips pan screw
and spring washer
and flat washer
assemly
M4x8 2
17 BF800017 Cord bushing 1
18 BF800018 Switch 1
19 BF800019 Philips screw M5x8 4
20 BF800020 Switch plate 1
21 BF800021 base 1
22 BF800022 Hex nut, I type M8 1
23 BF800023 Capacitor support 1
24 BF800024 Capacitor 1
25 BF800025 Philips pan screw
and spring washer
assmebly
M6x20 2
26 BF800026 Base plate 1
27 BF800027 Rubber foot 4
28 BF800028 Philips pan screw
and flat washer
assembly
M4x12 4
29 BF800029 Cord clip 1

WARRANTY
10
WARRANTY
10
Thank you for investing in a POWERTEC power tool. This product has been designed and manufactured to meet
high quality standards and is guaranteed for domestic use against defects in workmanship or material for a period of
12 months from the date of purchase. This guarantee does not affect your statutory rights.
SOUTHERN TECHNOLOGIES LLC. BENCH TOP AND STATIONARY POWER TOOL
LIMITED 1 YEAR WARRANTY AND 30‑DAY SATISFACTION GUARANTEE POLICY
POWERTEC products are designed and manufactured by Southern Technologies LLC. All warranty communications
should be directed to Southern Technologies LLC by calling 847‑780‑6120, 9 AM to 5 PM, Monday through Friday,
US Central Time.
30‑ DAY SATISFACTION GUARANTEE POLICY
During the first 30 days after the date of purchase, if you are dissatisfied with the performance of this POWERTEC tool
for any reason, you may return the tool to the retailer from which it was purchased for a full refund or exchange. You
must present proof of purchase and return all original equipment packaged with the original product. The replacement
tool will be covered by the limited warranty for the balance of the one year warranty period.
LIMITED ONE YEAR WARRANTY
This warranty covers all defects in workmanship or materials in this POWERTEC tool for a one year period from the
date of purchase. This warranty is specific to this tool. Southern Technologies, LLC reserves the right to repair or
replace the defective tool, at its discretion.
HOW TO OBTAIN SERVICE
To obtain service for this POWERTEC tool you must return it, freight prepaid, to POWERTEC. You may call
847‑780‑6120 for more information. When requesting warranty service, you must present the proof of purchase
documentation, which includes a date of purchase. POWERTEC will either repair or replace any defective part, at
our option at no cost to you. The repaired or replacement unit will be covered by the same limited warranty for the
remainder of the one year warranty period.
WHAT IS NOT COVERED
This warranty applies to the original purchaser at retail and may not be transferred.
This warranty does not cover consumable items such as saw blades, knives, belts, discs, cooling blocks and sleeves.
This warranty does not cover required service and part replacement resulting from normal wear and tear, including
accessory wear.
This warranty does not cover any malfunction, failure or defect resulting from:
1) misuse, abuse, neglect and mishandling not in accordance with the owner’s manual.
2) damage due to accidents, natural disasters, power outage, or power overload.
3) commercial or rental use.
4) alteration, modification or repair performed by persons not recommended by POWERTEC.
DISCLAIMER
To the extent permitted by applicable law, all implied warranties, including warranties of MERCHANTABILITY or
FITNESS FOR A PARTICULAR PURPOSE, are disclaimed. Any implied warranties, that cannot be disclaimed under
state law are limited to one year from the date of purchase. Southern Technologies LLC. is not responsible for direct,
indirect, incidental or consequential damages. Some states do not allow limitations on how long an implied warranty
lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations may
not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state
to state. Southern Technologies LLC., makes no warranties, representations, or promises as to the quality or perfor‑
mance of its power tools other than those specifically stated in this warranty.

NOTE

NOTE

NOTE

Southern Technologies, LLC
Waukegan, IL 60087
