PowerOak EB20-P1 User manual

145
210
技术要求
成品尺寸：A5(145*210mm).
材质：封面封底内页80G双铜版纸,装钉。
颜色：黑白印刷。
封底
封底
P/N:16 .06 1.0 015 0- 02A 1
封面
说明书示图（共12P）
此页不印刷
封面
目录
无特殊说明，长度单位：mm
未标注尺寸公差按:
x. (没有小数位) ±0.2
x.x (一位小数位) ±0.1
x.xx (两位小数位) ±0.05
x° ( 角度 ) ±0.5°
* --重要尺寸 ()--参照尺寸
Eb 2 0
郭窑元
180817
深圳市 德兰明 海科技 有限公 司
Sh e nz h en P o we r Oa k N ew e ne r C o. , lt d
郭窑元 1 80 8 17
郭窑元 1 81 1 23A1 P4页增加optional accessory
说明书
16 . 0 6 1 . 0 0 1 5 0 - 02
OP S 0 1 0 - 7 2 0 A 1

ATTENTION:
Strictly follow this user manual and pay close attention to all warnings.
Please DO NOT operate before reading this USER MANUAL.
EB20
USER MANUAL

• Our products are protected by patent law.
• We reserve the right to modify or change parts of or all the
specifications and pricing policies at company’s sole decision.
• We shall not be liable for losses caused by either incidental or
consequential use in connection with the furnishing, use or performance
of this manual as well as any information contained therein.
• Any part of this document is forbidden to be copied or edited without our
prior written approval.
• Information in this publication replaces all previously corresponding
material.
NOTICES
We guarantee this product conforms to the national and industrial
standards or that the standard conformance certification is in progress.
Publication Number: EB20
The information provided in this documentation contains general
descriptions and/or technical characteristics of the performance of the
products contain herein. This documentation is not intended as a substitute
for and is not to be used for determining suitability or reliability of the
products for specific user applications. It is the duty of any such user or
integrator to perform the appropriate and complete risk analysis, evaluation
andtesting of the products with respect to the relevant specific application
or use thereof. Neither our company nor any of its affiliates or subsidiaries
shall be responsible or liable for misuse of the information contained herein.
PRODUCT CERTIFICATION

TABLE OF CONTENTS
Introduction ················································01
Foreword ···················································01
Applicable···················································01
Product Description·······································01
Legend······················································01
Safety Precaution·········································02
Usage and Maintenance································02
Work Diagram of the Generator······················03
Unpacking···················································04
Unpack Checking·········································04
Operation Instruction···································04
Power on and Power off································04
Display······················································05
Trouble Shooting··········································06
System Failure Diagnosing····························06
Specification ···············································07
Contact us····················································08

Introduction
■Foreword
This Manual provides a detailed introduction regarding the use of the generator.
Please read the user instructions thoroughly in order to benefit from all the possibilities
your generator can offer.
■Applicable
By reading this manual, the user can understand the usage and operation of the generator.
Should any questions arise during installation, please contact your installer or customer
support (see page 8).
■Product Description
This portable solar generator is a smart, portable, home and camping, solar generator
battery. It has an integrated MPPT solar charge controller, inverter, system controller,
lithium battery, DC 12V, USB QC3.0,USB-C PD2.0 and BMS. Store green solar energy in
the battery for later use. This item isperfect for when the homes main power fails, the
generator can be used for powering computers, mobile phones and small appliances. This
product is safe, reliable, and easy to use.
■Legend
A
C
D
F
G
H
E
J
I
LCD B POWER C DC ON D AC ON
USB-A QC3.0 GDC 12V H USB-C PD2.0
E USB-A
JAC 120WI PV/ADAPTER
01
B
A
F

■Safety Precaution
1. Please read the “Safety Precautions” before use to ensure safe and proper operation of
EB20. Keep this manual in a safe and secure place. Warranty will be null and void if the
user fails to follow all warning and cautions in this manual.
2. Please follow all warnings when operating this unit.
3. Keep the generator away from direct sun, rain, and humid conditions.
4. Keep the generator away from heat sources like, electric heaters,ovens, furnaces, etc.
5. Keep a safe distance, approximately 4-6 inches, for ventilation and follow the manual
when installing.
6. Please power off and use dry cloths when cleaning.
7. In the event of electrical fire, only use dry powder fire extinguisher.There is a danger of
electric shock if a liquid fire extinguisher is used.
8. DO NOT open the case or touch any internal parts or wiring. Only connect cables to the
provided external ports.
9. Please contact us or a certified electrician for any maintenance needs.
■Usage and Maintenance
1. Working and storage conditions will affect the batteries overall life and reliability, please
follow the environmental conditions stated below:
• Only operate when temperatures are between 0°C~40°C with relative humidity between
5%~90%.
• Avoid places with constant vibrations or shocks.
• Avoid environments with metal dust, corrosive substances, salt, or flammable gases are
present.
2. Please place the generator in an area where there is good ventilation, away from water,
flammable gases, corrosive materials,and other dangerous goods.
3. For extended storage, place unit in dry environment, with temperatures between
0°C~+35°C.
02

■Work Diagram of the Generator
Battery
System
DC source or Solar
panel Car electric products
12V/10A
USB output port
Phone and Tablet device
Charge controller
Small power appliance
Inverter AC output
03

Unpacking
■Unpack Checking
Please check if the box has been damaged before opening. After unpacking, please
check if product appearance is damaged, or if there are any missing parts. If so, please
contact us.
Operation Instruction
■Power On and Power Off
Main functions of POWER ON/OFF button
1.POWER ON: Press the POWER button. The LED lights up. Screen turns on.
2.POWER OFF: Press the POWER button for 2 seconds. The screen turns off. LED lights
off.
Main functions of DC ON/OFF button
1.Turn on the DC power: Press the DC ON/OFF button for 2 seconds. LED lights up, and
screen shows “DC ON”.
2.Turn off the DC power: Press the DC ON/OFF button for 2 seconds. LED lights off, and
the screen shows “DC OFF”.
Main functions of AC ON/OFF button
1.Turn on the AC power: Press the AC ON/OFF button for 2 seconds. LED lights up,
and screen shows “AC ON”.
2.Turn off the AC power: Press the AC ON/OFF button for 2 seconds. LED lights off,
and the screen shows “AC OFF”.
NOTICE: Before turning on the POWER ON/OFF BUTTON, both DC ON/OFF button and
AC ON/OFF button don’t work. After turning on the POWER ON/OFF BUTTON, both DC
ON/OFF button and AC ON/OFF button are in OFF status.
No.
QuantityItem.
A
1EB20
AC wall charger（with AC charging cable）
solar charging cable（7909 to MC4）
Type-C cable
cigarette lighter adapter （6530 to cigaratte lighter）
F manual，warranty card，certificate of inspection
B
1
C
1(optional accessory)
D
1
E
1
F
1
04

Trouble Shooting
This generator has been fully tested prior to shipping. Contact our customer service
if any failure occurs. During a call, please provide us with the following information.
Failure Decription
● Serial No.
● Model No.
● Information shows on screen
● Describe in detail what error is happening.
● Is it possible to repeat the problem, if so what are the steps?
● Did it happen before?Why did it happen?
NOTICE:
1.When a function fails, the error code will show on “Charging power”, “DC output power”,
“AC output power”.
2.Screen backlight will turn off after a while with no operation, and it will turn on again when
pressing any button.
■Display
05
INPUT
W
886
W
868
DC ON/OFF
W
868
AC ON/OFF
DC AC
Battery level
POWER LED
POWER ON/OFF button AC ON/OFF button
DC ON/OFF button
Charging power
DC ON/OFF
DC output power
AC ON/OFF
Ac output power
AC LED
DC LED

■System Failure Diagnosing
Solar panel used to charge the generator
● Manufacturer name and model
● Output power of PV
● Output voltage of PV
● Output voltage of MPPT
● Output current of MPPT
● How many solar panels are hooked up?
06
Failure
code Cause Solution
E01 Over Temperature Protection Check that the ambient temperature is not
higher than 45℃.
E02 Battery pack Over Voltage
Protection Disconnect the charger and restart the unit.
E03 Battery Damage Protection Contact Poweroak.
E10 Too low temperature when
discharging
The temperature of the battery is too low.
Increase battery temperature.
E11 Battery Low Voltage
Protection
Please charge immediately. Fully charge unit
then restart.
E12 Inverter Over Current
Protection
Check if the AC output overloaded or
shortcircuited.
E13 Inverter Over Load
Protection
Check if the AC output overload, please refer to
the technical spec for overload ability.
E14 Inverter Short - Circuit
Protection
Check if the AC output overloaded or short-
circuited.
E16 Charging Over Voltage
Protection
Check if the input voltage exceed the maximum
value.
E17 Too low temperature when
charging
The temperature of the battery is too low.
Increase battery temperature to charge.
E21 12V 10A Output Over
Current Protection
Check if the output overloaded or short-
circuited.
E22 12V 10A Output Over Load
Protection Check if the output overload.

■Specification
07
E27 Total output power
overloaded Reduce the load power.
E28 Over temperature when
charging
The unit is too hot. Continue
charging once the temperature
gets lower.
E29 Over temperature when
discharging
The unit is too hot. Continue
discharging once the temperature
gets lower.
Model EB20-P1 EB20-P2
Battery capacity 200Wh 200Wh
Output Spec
AC output
Rated Output Power 120W 120W
Max. Output Power 200W(1s) 200W(1s)
Rated Output Voltage 110Vac 230Vac
Rated Frequency 50/60Hz 50/60Hz
Power Factor 1 1
THDV <3% <3%
Overload ability
125W< Load <150W@10s
150W< Load <180@5s
180W< Load <200W@1s
No-load consumption <8W <15W
>70% load power)Max. 90% 90%
DC12V output
Output Voltage Range 10-12.6V 10-12.6V
Rated Output Current 10A 10A
Overload Current >11A >11A
USB-A1 output
Fast charge support
devices BC1.2,Apple,Samsung BC1.2,Apple,Samsung
Output Voltage Range 5±0.25V 5±0.25V
Rated Output Current 2.4A 2.4A
Overload Current 2.6-3.5A 2.6-3.5A
USB-A2 output
Fast charge devices QC3.0 QC3.0
Output Voltage Range 5-12V (Default 5v) 5-12V (Default 5v)
Rated Output Current 5V/2.5A、9V/2A、12V/1.5A 5V/2.5A、9V/2A、12V/1.5A
Overload Current 2.6-3.5A 2.6-3.5A
USB-C output
Fast charge Support PD protocol PD protocol
Output Voltage Range (Default 5v) 5-20V (Default 5v)
Rated Output 5-20V/2.25A 5-20V/2.25A
Overload Current 2.25-3.5A 2.25-3.5A
PV Input
Max Input Power 60W 60W
Input voltage range 14-40Vdc 14-40Vdc
MPPT Input Voltage 15-40Vdc 15-40Vdc
Max. Input voltage 40Vdc 40Vdc
99.50% 99.50%
>90% >90%
Solar Charging Mode MPPT MPPT
Battery
Rated Voltage 11.1 Vdc 11.1 Vdc
Rated capacity (Wh) 200Wh 200Wh
Cell type Li-ion Li-ion
3S8P 3S8P

Contact us
Should you have any technical or other questions, Please contact us with following
information
1.System model
2.System serial No.
3.System failure Code
4.Displaying information
08
Max Voltage 12.6V 12.6V
Min.Voltage 10.0V 10.0V
The max. working temperature 40℃40℃
The min. working temperature 0℃0℃
General
IP IP 21
Working condition Relative Humidity: 5%-90%
Temperature: 0-40℃
Warranty One year
Dimension 196*65*255mm
Weight 2.7Kg(Net Weight)

P/N:16.061.00150-02A1
