PowerOak PS1 User manual

PS 1 USER MANUAL
ATTENTION:
Strictly follow this user manual and pay close attention to all warnings. Please DO NOT
operate before reading this USER MANUAL.

Page 2of 13
PS 1 USER MANUAL
Kanaaldijk Noord 111 | 5642 JA | Eindhoven | Nederland
©2018 PowerOak B.V. Netherlands
NOTICES
•PowerOak™ products are protected by patent law.
•PowerOak reserves the right to modify or change parts of or all the
specifications and pricing policies at company’s sole decision.
•PowerOak shall not be liable for losses caused by either incidental or
consequential use in connection with the furnishing, use or
performance of this manual as well as any information contained
therein.
•Any part of this document is forbidden to be copied or edited
without prior written approval of PowerOak.
•Information in this publication replaces all previously corresponding
material.
PRODUCT CERTIFICATION
PowerOak guarantees this product conforms to the national and industrial
standards or that the standard conformance certification is in progress.
©2018 PowerOak B.V. Netherlands All Rights Reserved
Publication Number: PS ONE
The information provided in this documentation contains general
descriptions and/or technical characteristics of the performance of the
products contain herein. This documentation is not intended as a substitute
for and is not to be used for determining suitability or reliability of the
products for specific user applications. It is the duty of any such user or
integrator to perform the appropriate and complete risk analysis, evaluation
and testing of the products with respect to the relevant specific application
or use thereof. Neither PowerOak nor any of its affiliates or subsidiaries shall
be responsible or liable for misuse of the information contained herein.

Page 3of 13
PS 1 USER MANUAL
Kanaaldijk Noord 111 | 5642 JA | Eindhoven | Nederland
©2018 PowerOak B.V. Netherlands
TABLE OF CONTENTS
NOTICES ......................................................................................................... 2
PRODUCT CERTIFICATION.............................................................................. 2
TABLE OF CONTENTS...................................................................................... 3
Introduction ................................................................................................... 4
➢Foreword............................................................................................ 4
➢Applicable........................................................................................... 4
➢Product Description ........................................................................... 4
Safety Precaution........................................................................................... 5
Usage and Maintenance ................................................................................ 5
Work Diagram of the Generator.................................................................... 6
Unpacking ...................................................................................................... 7
➢Unpack Checking................................................................................ 7
Operation Instruction .................................................................................... 7
➢Power on and Power Off.................................................................... 7
➢Display................................................................................................ 8
Trouble Shooting............................................................................................ 9
➢System Failure Diagnosing ............................................................... 10
Specification................................................................................................. 12
Contact us .................................................................................................... 13

Page 4of 13
PS 1 USER MANUAL
Kanaaldijk Noord 111 | 5642 JA | Eindhoven | Nederland
©2018 PowerOak B.V. Netherlands
Introduction
➢Foreword
This Manual provides a detailed introduction regarding the use of the
generator. Please read the user instructions thoroughly in order to benefit
from all the possibilities your generator can offer.
➢Applicable
By reading this manual, the user can understand the usage and operation of
the generator. Should any questions arise during installation, please contact
your installer or customer support (see page 8).
➢Product Description
This portable solar generator is developed by PowerOak, it’s a smart,
portable, home and camping, solar generator battery. This PowerOak
generator has an integrated MPPT solar charge controller, inverter, system
controller, lithium battery, DC 12V, USB QC3.0, USB-C PD2.0 and BMS. Store
green solar energy in the battery for later use. This item is perfect for when
the homes main power fails, the generator can be used for powering
computers, mobile phones and small appliances. This product is safe,
reliable, and easy to use.
ALCD
BPOWER
CDC ON
DAC ON
EUSB PORT
FUSB 3.0
GDC OUT
HTYPE C PORT
IAC IN
JAC OUT

Page 5of 13
PS 1 USER MANUAL
Kanaaldijk Noord 111 | 5642 JA | Eindhoven | Nederland
©2018 PowerOak B.V. Netherlands
Safety Precaution
1. Please read the “Safety Precautions” before use to ensure safe and
proper operation of PS ONE. Keep this manual in a safe and secure
place. Warranty will be null and void if the user fails to follow all
warning and cautions in this manual.
2. Please follow all warnings when operating this unit.
3. Keep the generator away from direct sun, rain, and humid
conditions.
4. Keep the generator away from heat sources like, electric heaters,
ovens, furnaces, etc.
5. Keep a safe distance, approximately 4-6 inches, for ventilation and
follow the manual when installing.
6. Please power off and use dry cloths when cleaning.
7. In the event of electrical fire, only use dry powder fire extinguisher.
There is a danger of electric shock if a liquid fire extinguisher is used.
8. DO NOT open the case or touch any internal parts or wiring. Only
connect cables to the provided external ports.
9. Please contact PowerOak or a certified electrician for any
maintenance needs. (See page 8 for contact information)
Usage and Maintenance
1. Working and storage conditions will affect the batteries overall life
and reliability, please follow the environmental conditions stated
below:
•Only operate when temperatures are between 0°C~40°C with
relative humidity between 5%~90%.
•Avoid places with constant vibrations or shocks.
•Avoid environments with metal dust, corrosive substances, salt, or
flammable gases are present.
2. Please place the generator in an area where there is good
ventilation, away from water, flammable gases, corrosive materials,
and other dangerous goods.
3. For extended storage, place unit in dry environment, with
temperatures between 0°C~+35°C.

Page 6of 13
PS 1 USER MANUAL
Kanaaldijk Noord 111 | 5642 JA | Eindhoven | Nederland
©2018 PowerOak B.V. Netherlands
Work Diagram of the Generator

Page 7of 13
PS 1 USER MANUAL
Kanaaldijk Noord 111 | 5642 JA | Eindhoven | Nederland
©2018 PowerOak B.V. Netherlands
Unpacking
➢Unpack Checking
Please check if the box has been damaged before opening. After unpacking,
please check if product appearance is damaged, or if there are any missing
parts. If so, please contact PowerOak. (See Page 13)
NO.
ITEM.
QUANTITY
A
PowerOak PS ONE
1
B
AC wall charger (with AC charging cable)
1
C
solar charging cable (7909 to MC4)
1
D
Type-C cable
1
E
cigarette lighter adapter (6530 to
cigarette lighter)
1
F
F manual, warranty card, certificate of
inspection
1
Operation Instruction
➢Power on and Power Off
Main functions of POWER ON/OFF button
1. POWER ON: Press the POWER button. The LED lights up. Screen
turns on.
2. POWER OFF: Press the POWER button for 2 seconds. The screen
turns off. LED lights off.
Main functions of DC ON/OFF button
1. Turn on the DC power: Press the DC ON/OFF button for 2 seconds. LED
lights up, and screen shows “DC ON”.
2.Turn off the DC power: Press the DC ON/OFF button for 2 seconds. LED
lights off, and the screen shows “DC OFF”.
Main functions of AC ON/OFF button
1. Turn on the AC power: Press the AC ON/OFF button for 2 seconds. Back
LED lights up, and screen shows “AC ON”.
2.Turn off the AC power: Press the AC ON/OFF button for 2 seconds. Back
LED lights off, and the screen shows “AC OFF”.

Page 8of 13
PS 1 USER MANUAL
Kanaaldijk Noord 111 | 5642 JA | Eindhoven | Nederland
©2018 PowerOak B.V. Netherlands
NOTICE: Before turning on the POWER ON/OFF BUTTON, both DC ON/OFF
button and AC ON/OFF button don’t work. After turning on the POWER
ON/OFF BUTTON, both DC ON/OFF button and AC ON/OFF button are in
OFF status.
➢Display
DC ON/OFF button

Page 9of 13
PS 1 USER MANUAL
Kanaaldijk Noord 111 | 5642 JA | Eindhoven | Nederland
©2018 PowerOak B.V. Netherlands
NOTICE:
1. When a function fails, the error code will show on “Charging power”, “DC
output power”, “AC output power”.
2.Screen backlight will turn off after a while with no operation, and it will
turn on again when pressing any button.
Trouble Shooting
This generator has been fully tested prior to shipping. Contact PowerOak
customer service if any failure occurs. During a call, please provide us with
the following information.
Failure Description
•Serial No.
•Model No.
•Information shows on screen
•Describe in detail what error is happening.
•Is it possible to repeat the problem, if so, what are the steps?
•Did it happen before? Why did it happen?
Solar panel used to charge the generator
•Manufacturer name and model
•Output power of PV
•Output voltage of PV
•Output voltage of MPPT
•Output current of MPPT
•How many solar panels are hooked up?

Page 10 of 13
PS 1 USER MANUAL
Kanaaldijk Noord 111 | 5642 JA | Eindhoven | Nederland
©2018 PowerOak B.V. Netherlands
➢System Failure Diagnosing
Failure
code
Cause
Solution
E01
Over Temperature
Protection
Check that the ambient temperature is not
higher than 45°C.
E02
Battery pack Over Voltage
Protection
Disconnect the charger and restart the
unit.
E03
Battery Damage Protection
Contact PowerOak.
E10
Too low temperature when
discharging
The temperature of the battery is too low.
Increase battery temperature.
E11
Battery Low Voltage
Protection
Please charge immediately. Fully charge
unit then restart.
E12
Inverter Over Current
Protection
Check if the AC output overloaded or short-
circuited.
E13
Inverter Over Load
Protection
Check if the AC output overload, please
refer to the technical spec for overload
ability.
E14
Inverter Short - Circuit
Protection
Check if the AC output overloaded or short-
circuited.
E16
Charging Over Voltage
Protection
Check if the input voltage exceeds the
maximum value.
E17
Too low temperature when
charging
The temperature of the battery is too low.
Increase battery temperature to charge.
E21
12V 10A Output Over
Current Protection
Check if the output overloaded or short-
circuited.
E22
12V 10A Output Over Load
Protection
Check if the output overload.

Page 11 of 13
PS 1 USER MANUAL
Kanaaldijk Noord 111 | 5642 JA | Eindhoven | Nederland
©2018 PowerOak B.V. Netherlands
E27
Total output power
overloaded
Reduce the load power.
E28
Over temperature when
charging
The unit is too hot. Continue charging
once the temperature gets lower.
E29
Over temperature when
discharging
The unit is too hot. Continue
discharging once the temperature gets
lower.

Page 12 of 13
PS 1 USER MANUAL
Kanaaldijk Noord 111 | 5642 JA | Eindhoven | Nederland
©2018 PowerOak B.V. Netherlands
Specification
Model
PSONE-P1
PSONE-P2
Battery capacity
200Wh
200Wh
Output Spec
AC output
Rated Output Power
120W
120W
Max. Output Power
200W(1s)
200W(1s)
Rated Output Voltage
110Vac
230Vac
Rated Frequency
50/60HZ
50/60HZ
Power Factor
1
1
THDV
<3%
<3%
Overload ability
125W< Load <150W@10s 150W< Load <180@5s 180W< Load <200W@1s
No-load consumption
<8W
<15W
>70% load power) Max.
efficiency
90%
90%
DC12V output
Output Voltage Range
10-12.6V
10-12.6V
Rated Output Current
10A
10A
Overload Current
>11A
>11A
USB-A1 output
Fast charge support devices
BC1.2, Apple, Samsung
BC1.2, Apple, Samsung
Output Voltage Range
510.25V
510.25V
Rated Output Current
2.4A
2.4A
Overload Current
2.6-3.5A
2.6-3.5A
USB-A2 output
Fast charge devices
QC3.0
QC3.0
Output Voltage Range
5-12V (Default 5v)
5-12V (Default 5v)
Rated Output Current
5V/2.5A, 9V/2A. 12V/1.5A
5V/2.5A, 9V/2A, 12V/1.5A
Overload Current
2.6-3.5A
2.6-3.5A
USB-C output
Fast charge Support
PD protocol
PD protocol
Output Voltage Range
(Default 5v)
5-20V (Default 5v)
Rated Output
5-20V/2.25A
5-20V/2.25A
Overload Current
2.25-3.5A
2.25-3.5A
PV Input
Max Input Power
60W
60W
Input voltage range
14-40Vdc
14-40Vdc
MPPT Input Voltage
15-40Vdc
15-40Vdc
Max. Input voltage
40Vdc
40Vdc
MPPT Efficiency
99.50%
99.50%
Max Efficiency
>90%
>90%
Solar Charging Mode
MPPT
MPPT
Battery
Rated Voltage
11.1 Vdc
11.1 Vdc
Rated capacity (Wh)
200Wh
200Wh
Cell type
Li-ion
Li-ion
Configuration
3S8P
3S8P
Max Voltage
12.6V
12.6V
Min. Voltage
10.0V
10.0V
The max. working temperature
40r
40 r
The min. working temperature
or
or
General
IP
IP 21
Working condition
Relative Humidity: 5%-90%
Temperature: 0-40*C
Warranty
One year
Dimension
196*65*255mm
Weight
2.7Kg (Net Weight)

Page 13 of 13
PS 1 USER MANUAL
Kanaaldijk Noord 111 | 5642 JA | Eindhoven | Nederland
©2018 PowerOak B.V. Netherlands
Contact us
Should you have any technical or other questions, please contact PowerOak with
following information
1.System model
2.System serial No.
3.System failure Code
4.Displaying information
Kanaaldijk Noord 111 | 5642 JA | Eindhoven | Nederland
M+31 (0) 40 240 5888 | [e-mail] | Wwww.poweroak.nl
Volg ons op:
KvK: 65077687
BTW: NL.8559.71.289.B.01
