PowerPac IF3255 User manual

Model: IF3255

PARTS & DESCRIPTION
LIST OF COMPONENTS
1.
2.
3.
4.
5.
6.
7.
8.
Rotary Switch
Air Outlet
Air Inlet (left)
Air Inlet (right)
Decorative Fixture
Front Panel
Removable Base
Composite Filter
Rotary Switch
OFF
Speed 1 – Whisper Clean
Speed 2 – Med
Speed 3 – Quick Clean
Air Inlet
Removable Base
Front Panel
Composite Filter
Decorative Fixture
Air Outlet
1

ATTENTION :
Read this booklet carefully it contains important instructions for a safe installation,
use and maintenance.
Important instructions to be kept for future reference.
The following basic precautions should always be followed when using electrical
appliances:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Read all instructions before using the appliance.
This appliance must be used only for the purpose it was expressly designed; any
use not complying with the instructions contained in the manual is considered
inappropriate and dangerous. The manufacturer is not responsible for possible
damages caused by the inappropriate and/or unreasonable use.
This appliance is NOT suitable to be used or stored near heat sources (open flame,
ovens, heaters, stoves, etc.) and/or in an explosive environment (in the presence of
flammable substances such as gas, vapour, mist or dust, in atmospheric conditions
when, after ignition, the combustion is spread in the air). Items containing these
substances should never be placed in the appliance, and never be used to clean the
appliance in order to avert the risk of fire or explosion.
The packing materials (plastic bags, expanded polystyrene, etc.) must be kept out
of the reach of children or disabled persons since they represent potential sources
of danger.
The installation/assembly of the appliance will be made in accordance with the
indications of the manufacturer. A wrong procedure may cause damages to persons,
animals or objects, for which the manufacturer cannot be considered responsible.
Before use, check the integrity of the appliance and power cable. In case you are not
sure, contact a qualified person. If the power cable is damaged, it must be replaced
by the manufacturer or its service agent or a qualified technician in order to avoid a
shock hazard.
Before powering the appliance make sure the rating (voltage and frequency)
corresponding to the grid and the socket is suitable for the plug of the appliance,
and that the wall socket is properly grounded.
DO NOT power the appliance using multiple sockets. If possible, avoid the use of
adapters and/or extension cables; if their use is absolutely necessary, use only
materials in compliance with the current safety regulations and according to the
electrical parameters of the adapters.
The appliance must NOT be switched on using external timers and/or other remote
control appliances which are not specified in this manual.
Only use original components & accessories provided by the manufacturer. Any
non-original components & accessories (e.g. Composite Filter) not recommended
by the manufacturer may cause injuries to persons or damage to the appliance.
WARNINGS
2

11.
12.
13.
If you are using the appliance for the first time, you should:
a.
b.
c.
d.
e.
f.
g.
h.
Make sure to remove any label or protective sheet which may prevent its proper
functioning.
DO NOT:
•
•
•
•
•
•
•
•
•
•
•
•
Plug and unplug the power cable firmly holding it with dry hands. Always unplug
the power cable to avoid overheating and avoid stretching it (DO NOT pull it, tug it
or use it to drag the appliance to which is connected). Before unplugging the
appliance, switch it off, using the Rotary Switch.
During operation, DO NOT touch the appliance with wet body parts, and it is
recommended to have between you and the standing surface, an isolating element
(for example, wearing shoes with rubber soles).
Clean the exterior parts of the appliance thoroughly with warm water & detergent
with a non-abrasive sponge.
DO NOT use metal scouring pads.
Ensure that the appliance is completely dry before use and standing at an upright
position or tilted 90 with the Air Inlet (left) on top before switching on the
appliance.
Operate the appliance with the Composite inserted and the Front Panel closed.
Place and use the appliance on a horizontal, stable and heat-resistant surface.
Damage may occur if the appliance is placed on an incline or decline.
Ensure that the Rotary Switch is turned counterclockwise to“OFF”. Insert the plug
directly into a standard AC socket. Be sure that the plug fits tightly into the socket.
Turn the Rotary Switch clockwise for the fan speed (Low –“Whisper Clean”, “Med”,
“Quick Clean”– High) you desire.
To stop the appliance, turn the Rotary Switch counterclockwise to “OFF”.
Switch off the appliance and unplug the socket from the electric mains if it is NOT
used for a long period, before storing, cleaning or performing any maintenance
operation.
operate the appliance in a room (or location) with high air humidity, such as a
bathroom, shower or swimming pool, as moisture can accumulate in the
appliance and cause an electric shock;
cover the appliance during functioning and allow free air access;
obstruct totally nor partially the Air Inlet & Outlet;
place the appliance on a soft surface such as a mattress, pillow, cushion or sofa, as
this could cause the appliance to tip over, blocking the Air Inlet & Outlet;
move the appliance while the appliance is switched on and connected to the
electric mains;
insert objects or body parts inside the protection cover of the appliance;
turn the Rotary Switch too forcefully;
use the appliance near curtains, textiles, or any object will can be ignited or burnt;
spray any volatile liquid or gas towards the Air Inlet of the appliance or on the
Filter;
use any of the following agents as a cleaner: gasoline, thinners, benzene, acidic or
abrasive detergents;
operate the appliance at temperatures lower than 0°C or higher than 40°C, and
operate the appliance for more than 6 hours without turning it off for at least 30
minutes to let the appliance cool down for a total usage of 12 hours a day –
failure to heed this warning may result in motor failure;
leave the appliance unsupervised during operation.
3

Clean the exterior parts of the appliance thoroughly with warm water & detergent
with a non-abrasive sponge.
DO NOT use metal scouring pads.
Ensure that the appliance is completely dry before use and standing at an upright
position or tilted 90 with the Air Inlet (left) on top before switching on the
appliance.
Operate the appliance with the Composite inserted and the Front Panel closed.
Place and use the appliance on a horizontal, stable and heat-resistant surface.
Damage may occur if the appliance is placed on an incline or decline.
Ensure that the Rotary Switch is turned counterclockwise to“OFF”. Insert the plug
directly into a standard AC socket. Be sure that the plug fits tightly into the socket.
Turn the Rotary Switch clockwise for the fan speed (Low –“Whisper Clean”, “Med”,
“Quick Clean”– High) you desire.
To stop the appliance, turn the Rotary Switch counterclockwise to “OFF”.
Switch off the appliance and unplug the socket from the electric mains if it is NOT
used for a long period, before storing, cleaning or performing any maintenance
operation.
operate the appliance in a room (or location) with high air humidity, such as a
bathroom, shower or swimming pool, as moisture can accumulate in the
appliance and cause an electric shock;
cover the appliance during functioning and allow free air access;
obstruct totally nor partially the Air Inlet & Outlet;
place the appliance on a soft surface such as a mattress, pillow, cushion or sofa, as
this could cause the appliance to tip over, blocking the Air Inlet & Outlet;
move the appliance while the appliance is switched on and connected to the
electric mains;
insert objects or body parts inside the protection cover of the appliance;
turn the Rotary Switch too forcefully;
use the appliance near curtains, textiles, or any object will can be ignited or burnt;
spray any volatile liquid or gas towards the Air Inlet of the appliance or on the
Filter;
use any of the following agents as a cleaner: gasoline, thinners, benzene, acidic or
abrasive detergents;
operate the appliance at temperatures lower than 0°C or higher than 40°C, and
operate the appliance for more than 6 hours without turning it off for at least 30
minutes to let the appliance cool down for a total usage of 12 hours a day –
failure to heed this warning may result in motor failure;
leave the appliance unsupervised during operation.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
DO NOT soak the appliance in water or other liquids, wash it under the tap, or let
any liquid flow into the internal casing of the appliance to prevent electric shock. In
case of accidental fall in water, DO NOT try to take it out, but first of all, switch off
the electric mains and unplug immediately the Power Cable from the electric mains.
DO NOT operate the appliance next to an open window while it is raining.
Rainwater splashing onto the appliance may cause an electric shock.
Place the appliance at a proper distance from objects or surrounding walls making
sure that its functioning will not cause accidental damages. There should be at least
20 cm of free space from the back, left & right sides, and the top of the appliance.
DO NOT place anything on top of the appliance.
The appliance shall NOT be placed on a surface, or in the vicinity of, objects which
can be damaged by heat such as wood, carpets or plastics. DO NOT locate multiple
portable socket outlets or power supplies at the bottom or rear of the appliance. If
the appliance is operated on wooden furniture, use a protective pad to prevent
damage to delicate finishes.
Avoid placing the power cable on abrasive or sharp surfaces or in positions where it
can be damaged easily. The cable must NOT be placed under carpets, or covered
with throw rugs, runners or similar. Arrange the cable away from the high traffic
area, and where it will NOT be tripped over.
Avoid carrying out operations which are not specified in this manual (such as
disassembling and/or altering).
In case of malfunction or anomaly during the functioning, switch off the appliance
immediately, turn off the power and check the cause of the anomaly, if possible,
with the support of a qualified person.
DO NOT touch the inside of the appliance while it is operating. The blades are
rotating at very high speeds, which may lead to injury to your fingers and hands.
If smoke is observed coming out of the appliance, unplug the power cable
immediately.
This appliance is NOT intended for commercial use but to be used in households
and similar applications, such as:
• Staff kitchen areas in shops, offices and other working environments;
• Dormitories;
• By clients in hotels, motels and other residential environments;
• Bed and breakfast type environment
DO NOT use or store the appliance outdoors. Store and use the appliance only
indoors, or in any case, protected from weathering such as rain, direct radiation of
the sun and dust.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall NOT
play with the appliance. Cleaning and user maintenance shall NOT be made by
children unless they are older than 8 and supervised. Keep the appliance and its
cable out of reach of children less than 8 years old.
Save these instructions.
4

Clean the exterior parts of the appliance thoroughly with warm water & detergent
with a non-abrasive sponge.
DO NOT use metal scouring pads.
Ensure that the appliance is completely dry before use and standing at an upright
position or tilted 90 with the Air Inlet (left) on top before switching on the
appliance.
Operate the appliance with the Composite inserted and the Front Panel closed.
Place and use the appliance on a horizontal, stable and heat-resistant surface.
Damage may occur if the appliance is placed on an incline or decline.
Ensure that the Rotary Switch is turned counterclockwise to“OFF”. Insert the plug
directly into a standard AC socket. Be sure that the plug fits tightly into the socket.
Turn the Rotary Switch clockwise for the fan speed (Low –“Whisper Clean”, “Med”,
“Quick Clean”– High) you desire.
To stop the appliance, turn the Rotary Switch counterclockwise to “OFF”.
Switch off the appliance and unplug the socket from the electric mains if it is NOT
used for a long period, before storing, cleaning or performing any maintenance
operation.
operate the appliance in a room (or location) with high air humidity, such as a
bathroom, shower or swimming pool, as moisture can accumulate in the
appliance and cause an electric shock;
cover the appliance during functioning and allow free air access;
obstruct totally nor partially the Air Inlet & Outlet;
place the appliance on a soft surface such as a mattress, pillow, cushion or sofa, as
this could cause the appliance to tip over, blocking the Air Inlet & Outlet;
move the appliance while the appliance is switched on and connected to the
electric mains;
insert objects or body parts inside the protection cover of the appliance;
turn the Rotary Switch too forcefully;
use the appliance near curtains, textiles, or any object will can be ignited or burnt;
spray any volatile liquid or gas towards the Air Inlet of the appliance or on the
Filter;
use any of the following agents as a cleaner: gasoline, thinners, benzene, acidic or
abrasive detergents;
operate the appliance at temperatures lower than 0°C or higher than 40°C, and
operate the appliance for more than 6 hours without turning it off for at least 30
minutes to let the appliance cool down for a total usage of 12 hours a day –
failure to heed this warning may result in motor failure;
leave the appliance unsupervised during operation.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
The Composite Filter consists of 3 Filters: Preliminary Filter, Charcoal Filter, and HEPA
Filter.
Filter replacement differs according to the pollution levels of the actual
environment. Replacement of Filter can be estimated according to the sound and
smell of the appliance. If bad odours are released from the Air Outlet, it means that
the Filter’s filtration and adsorption volume is saturated.
In households with a large number of smokers, or adjacent to construction sites,
industrial factories, etc., the Filter replacement cycle may be shortened to once in
every 6 months.
To replace the Composite Filter, turn the Rotary Switch counterclockwise to“OFF”.
Switch off the appliance and unplug the socket of the Power Cable from the electric
mains.
Wait for the appliance to cool down completely.
Hold the Front Panel with both hands and remove the Front Panel.
Take out the Composite Filter and wrap the Composite Filter in a garbage bag to
prevent pollutants on the Composite Filter from falling onto the floor.
Use a vacuum cleaner to suck up dirt from the Air Inlet and Air Outlet, and also to
clean the surface dust.
Adjust the direction of the new Composite Filter corresponding to the Filter slot on
the appliance and insert the new Filter.
Clean the exterior parts of the appliance thoroughly with warm water &
dish-washing agent and a damp cloth, and immediately wipe dry.
DO NOT use a scrubbing brush.
DO NOT use any of the following agents as a cleaner: gasoline, thinners, or benzene.
Never run water over the appliance as malfunctions may occur if water seeps
inside the appliance.
HOW TO CLEAN
cloth
5

PROBLEM SOLVING
If your air purifier is not working properly, please check the following before sending it
for repairs.
Problem Possible Causes How to Solve
The appliance
does not work
The plug is not properly
inserted in the power socket.
Insert the plug into the
power socket. Do not use
adaptors or extensions.
Bad odours are released
from the Air Outlet of the
appliance
The Composite Filter’s
filtration and adsorption
volume is saturated.
Remove the Front Panel
and remove the used
Composite Filter. Install a
new Composite Filter.
Close the Front Panel.
The odour concentration of
the indoor air is too high
Open nearby windows for
ventilation, and check if the
bad odour is emanating
from the appliance itself.
The switch at the electric
mains is not switched on
and/or the ON/OFF Button
is not pressed.
Turn on the electric mains
and/or the Switch Button
on the appliance to“ON”.
Disconnect the appliance
from the electric mains and
leave the motor to cool.
The motor has overheated.
Have the power cable
replaced at the authorised
Service Centre.
The power cable is defective.
Check that the house main
breaker is on.
Lack of power.
Have the appliance
checked at the authorised
Service Centre.
Motor or PCBA breakdown
Remove the Front Panel
and check the alignment of
the Composite Filter.
If needed, re-install the
Composite Filter.
Close the Front Panel.
The Composite Filter had
not been installed correctly
in position, and is preventing
the Front Panel from closing.
Close the Front Panel. The Front Panel is open.
6

Problem Possible Causes How to Solve
The purification effect is
not significant, and the
air quality is not
significantly improved
The Composite Filter had
NOT been installed.
Remove the Front Panel and
install a Composite Filter.
Close the Front Panel.
The Composite Filter
cannot fit into the
appliance
The appliance has been
situated on uneven ground.
Place the appliance on a
flat, stable surface.
The appliance is tucked
within narrow confines or
near obstacles that affect
the ability of the appliance
to draw in air.
Place the appliance on a
flat, stable surface away
from obstacles in its vicinity
or remove the obstacles.
Remove the Front Panel and
remove the used Composite
Filter. Install a new
Composite Filter.
Close the Front Panel.
The Composite Filter is too
dirty.
Remove the Front Panel
and check the alignment of
the Composite Filter.
If needed, re-install the
Composite Filter.
Close the Front Panel
The Composite Filter is
being installed upside down.
The appliance is too noisy Check to see whether there
is any blockage, and if so,
attempt to remove them.
If the foreign object(s) is
wedged too deeply, bring
the appliance to the
authorised Service Centre.
Foreign objects have fallen
into the appliance.
The parts may have been
incorrectly assembled.
Check to see whether the
Filter or parts around it had
been incorrectly
re-positioned during the
last replacement or
cleaning.
The Composite Filter is too
dirty.
Remove the Front Panel
and remove the used
Composite Filter. Install a
new Composite Filter.
Close the Front Panel.
The Wind speed set is too
high.
Set a lower speed.
7

The manufacturer provides warranty in accordance with the legislation of the
customer’s own country of residence, with a minimum of 1 year, starting from the date
on which the appliance is sold to the end user.
The warranty covers defects in material and workmanship.
The repairs under warranty may only be carried out by an authorised service centre.
When making a claim under the warranty, the original bill of purchase (with purchase
date clearly indicated) must be submitted.
The warranty will not apply in cases of:
•
•
•
•
•
•
normal wear and tear
if the steps (as laid out in the section regarding Warnings) have not been observed
e.g. overloading of the appliance, use of non-approved accessories
if the appliance has not been properly maintained, if force has been used against it
or if it has been damaged in any other way
damage caused by non-observance of the user manual or non-compliance with the
installation instructions
errors or faults owing to defects in the distribution system
if the appliance has been repaired or modified or changed in any way or by any
person not properly authorised
WARRANTY
This device, along with all other electronic devices, should, when it is no longer
capable of functioning, be disposed with the least possible environmental damage
according to the local regulations in your area. In most cases you can discard the
device at your local recycling center.
DISPOSAL: Do not dispose this device as unsorted municipal waste.
Collection of such waste separately for special treatment is necessary.
ENVIRONMENTAL TIP
8

IF3255
MODEL
10m2to 15m2
COVERAGE AREA
230V
POWER
70m3/h
CLEAN AIR DELIVERY RATE
SPECIFICATION
9
