PowerPac PPQ2020 User manual

ELECTRIC BARBECUE GRILL
PPQ2020
Model No.: PPQ2020

Parts & Description s
LIST OF COMPONENTS
1.
Control Seat
2.
Body
3.
Handle (2 pcs)
4.
Left Feet (2 pcs)
5.
Right Feet (2 pcs)
6.
Zinc Plate
7.
ST2.9 Screw (4 pcs)
8.
M4 Nut
9.
Straight Metal Pipe
10.
M4 Screw
11.
Windshield
12.
Heating Element & Control Box
13.
Grill Rack
14.
Upper Grill
Upper Grill Windshield Heating Element Zinc Plate Grill Rack
Handle Left Feet Control Seat Control Box Right Feet Handle

LIST OF COMPONENTS
A1.
Short Pipe
A2.
Long Pipe
A3.
Short Metal Shelf
A4.
Long Metal Shelf
A5.
Butterfly Nut
A6.
M5 Screw
A7.
Pipe Cap (8 pcs)
A8.
Small Grill
Small Grill
Short Pipe
Pipe Cap into
Right Feet
Long Pipe
Short
Metal
Shelf
Long Metal Shelf
Pipe Cap
M5 Screw
Butterfly Nut
Pipe Cap
Pipe Cap
Pipe Cap
Long Pipe
Long Pipe
Pipe Cap
into Left Feet

HOW TO ASSEMBLE s
1. Unpack all parts from the package and place them on the floor.
THE GRILL RACK ASSEMBLY
2. Clean the Grill Rack and its accessories.
3. Insert the two Left Feet and the two Right Feet into their allotted slots in each of
the plastic Handles.
Handle Left Feet (2 pieces) (2 pieces) Right Feet Handle
Control Seat Body

4. There are two holes on each plastic Handle and also on each side of the metal
Body. Join each plastic Handle onto the metal Body at each end by threading
four ST2.9 screws into each of the four holes (two at each end). The two
Handles are now attached to the Body.
5. Place the Zinc Plate onto the Body. Insert the straight metal pipe through 2 holes
of Zinc Plate and body on two sides.
Also, align the bottom holes in the Zinc Plate and the Body, and thread the M4
Screw though the holes. Use the M4 Nut to fasten the Zinc Plate to the Body.
Hole (M4 Screw + M4 Nut) Straight Metal Pipe Zinc Plate Body
Handle ST2.9 Screw ST2.9 Screw Handle

6. Fix up the Windshield according to the diagram shown below.
M4 Nut
Zinc Plate
M4 Screw
Body
Windshield

7. Slide the Heating Element onto the Straight Metal Pipe, with the attached Control
Box onto the Control Seat.
Heating Element
Control Box
Heating Element
Control Box
When in operation, fill the body
with water up to the ‘0.9 L’ mark.

8. Fix the Grill Rack on top of the Heating Element, alongside the Control Box and
Handles. Fix the Upper Grill onto the Windshield.
The Grill Rack Assembly is completed.
Upper Grill
Grill Rack
Upper Grill Windshield Heating Element Zinc Plate Grill Rack
Handle Left Feet Control Seat Control Box Right Feet Handle

THE GRILL STAND ASSEMBLY
9. Join A1 Short Pipe to A2 Long Pipe to produce one of four legs of the Grill
Stand Assembly. Repeat the process another 3 times to produce the other three
legs.
10. Join A3 Short Metal Shelf to A4 Long Metal Shelf using A5 Butterfly Nut and
A6 M5 Screw. Repeat the process until all four legs are locked together.
Short Pipe
Long Pipe
Short Pipe
Long Pipe Long Pipe
Long Pipe
Short Metal
Shelf
M5 Screw
Butterfly Nut
Long Metal
Shelf
Short Metal
Shelf
Short Metal
Shelf
Long Metal Shelf

11. Attach one A7 Pipe Cap to each end of the four legs (8 in total).
12. Place the A8 Small Grill on top of the metal shelf (made up of the A3 Short
Metal Shelf & A4 Long Metal Shelf).
Insert each leg of the Grill Stand Assembly into the openings of the Left Feet
and Right Feet of the Grill Rack Assembly.
Small Grill
Short Pipe
Long Pipe
Short Metal Shelf
Long Metal Shelf
Pipe Cap
Short Pipe
Short Metal Shelf
Long
Metal
Shelf
Pipe Cap

Warnings s
ATTENTION :
Read this booklet carefully as it contains important instructions for a safe installation,
use and maintenance.
Important instructions to be kept for future reference.
The following basic precautions should always be followed when using electrical
appliances:
1. Read all instructions before using the appliance.
The Appliance
2. This appliance must be used only for the purpose it was expressly designed; any
use NOT complying with the instructions contained in the manual is considered
inappropriate and dangerous. The manufacturer is NOT responsible for possible
damages caused by the inappropriate and/or unreasonable use.
3. The installation/assembly of the appliance will be made in accordance with the
indications of the manufacturer. A wrong procedure may cause damages to
persons, animals or objects, for which the manufacturer cannot be considered
responsible.
4. Before use, check the integrity of the appliance and power cable. DO NOT
operate the appliance when its housing is damaged. In case you are not sure,
contact a qualified person. If the power cable is damaged, it must be replaced by
the manufacturer or its service agent or a qualified technician in order to avoid a
shock hazard.
5. Before powering the appliance make sure the rating (voltage and frequency)
corresponding to the grid and the socket is suitable for the plug of the appliance,
and that the wall socket is properly grounded.
6. DO NOT power the appliance using multiple sockets. If possible, avoid the use
of adapters and/or extension cables; if their use is absolutely necessary, use
only materials in compliance with the current safety regulations and according to
the electrical parameters of the adapters.
7. The appliance must NOT be switched on using external timers and/or other
remote control appliances which are not specified in this manual.
8. Only use original components & accessories (e.g. Control Box, Control Seat,
Heating Element, Zinc Plate, Windshield, Grills, Handles, Shelves, Pipes, Feet,
etc.) provided by the manufacturer. Any non-original component or accessory
NOT recommended by the manufacturer (including, but not limited to, Control
Box, Control Seat, Heating Element, Zinc Plate, Windshield, Grills, Handles,
Shelves, Pipes, Feet, etc. made by other manufacturers or by the same
manufacturer but for other models of the same capacity or otherwise) may cause

injuries to persons or damage to the appliance.
9. The packing materials (plastic bags, expanded polystyrene, etc.) must be kept
out of the reach of children or disabled persons since they represent potential
sources of danger.
Location
10. This appliance is NOT suitable to be used or stored near heat sources (open
flame, ovens, heaters, stoves, etc.) and/or in an explosive environment (in the
presence of flammable substances such as gas, vapour, mist or dust, in
atmospheric conditions when, after ignition, the combustion is spread in the air).
Items containing these substances should never be placed in the appliance, and
never be used to clean the appliance in order to avert the risk of fire or
explosion. Firefighting equipment should always be made available and placed
in an easily assessable area next to the appliance before operating the
appliance.
11. This appliance should be used in an outside, well-ventilated area, NOT next to a
wall or corner. Place the appliance at a proper distance from objects or
surrounding walls making sure that its functioning will not cause accidental
damages. There should be at least 100 cm of free space from the back, left &
right sides, and the top of the appliance. Never put things on top of the
appliance.
12. Place and use the appliance on a horizontal, stable and heat-resistant surface,
impervious to splashes and stains. The appliance should NOT be placed on a
surface or in the vicinity of objects which can be damaged by heat, such as
carpets or plastics. DO NOT locate multiple portable socket outlets or power
supplies at the bottom or rear of the appliance. When using the appliance, the
surface that the appliance is placed upon as well the surface immediately above
may become very hot. If the appliance is operated on wooden furniture, use a
protective pad to prevent damage to delicate finishes.
13. Avoid placing the power cable on abrasive or sharp surfaces or in positions
where it can be damaged easily. The cable must NOT be placed under carpets,
or covered with throw rugs, runners or similar. Arrange the cable away from the
high traffic area, and where it will NOT be tripped over.
14. DO NOT store the appliance outdoors. Store and use the appliance only indoors,
or in any case, protected from weathering such as rain, direct radiation of the
sun and dust.
Operation
15. If you are using the appliance for the first time, you should:
a. Clean the inside surfaces of the appliance, Grill Rack, Upper Grill, Zinc Plate
& Windshield with water & detergent with a non-abrasive sponge.
DO NOT use metal scouring pads. Notice: you may use a dishwasher to
clean the Grill Rack and Upper Grill.

b. Ensure that the appliance is completely dry before use.
c. The following items should NOT be placed in the appliance during heating as
they may create a fire or risk of electric shock:
oversized foods or metal utensils must NOT be inserted into the appliance;
containers constructed of any materials (including but not limited to:
cardboard, plastic, paper, glass, rubber, silicone, metal, etc.) other than
aluminium foil, and ensure that the containers used are approved for use
at the set temperature;
any solid material such as an aluminum foil or tray, barbecue dishes or
other items that wraps around or cover entirely or almost entirely, the Grill
Rack or Upper Grill, as the resulting build-up of heat could cause
irreparable damage to the appliance.
d. Put oil or grease on the Grill Rack or Upper Grill before placing food to
prevent food from sticking onto the Grill Rack or Upper Grill at the end of
heating.
e. Always wear protective, insulated appliance gloves when placing or removing
items from the Grill Rack or Upper Grill.
f. Extreme caution must be used when moving the appliance containing water
in the Body, especially during, and immediately after, operation.
g. Make sure to remove any label or protective sheet which may prevent its
proper functioning.
DO NOT:
cover the appliance during functioning;
obstruct totally nor partially the Grill Rack & upper Grill with any solid material
such as an aluminum foil or tray, barbecue dishes or other items;
insert objects or body parts inside the protection cover of the appliance;
use the appliance near curtains or textiles;
heat foods without removing the wrappers (including plastic, paper or metal)
first;
switch the Heating Element on when it is NOT placed onto the appliance;
connect the appliance to the electric mains until the Body has been filled with
water;
pour water onto the Heating Element to prevent the possibility of electric
shock;
under any circumstances, use charcoal or any other solid or liquid fuel
to operate the grill;
leave the appliance unsupervised during operation.
16. During operation, DO NOT touch the appliance with wet body parts, and it is
recommended to have between you and the standing surface, an isolating
element (for example, wearing shoes with rubber soles).

17. During the period of heating, foods containing a high level of moisture may lead
to high temperature steam being emitted. To avoid scalding:
ensure that the appliance is correctly positioned before heating;
DO NOT touch any part of the appliance except the Handles and the
Thermostat Control Knob when the appliance is hot. The bottom of the
appliance becomes exceedingly hot as the appliance operates;
one’s hands and face should be angled away from the Grill Rack & Upper
Grill.
18. DO NOT soak the appliance in water or other liquids, wash it under the tap, or let
any liquid flow into the internal casing of the appliance to prevent electric shock.
In case of accidental fall in water, DO NOT try to take it out, but first of all unplug
immediately the power cable from the socket.
19. Plug and unplug the power cable firmly holding it with dry hands. Always unplug
the power cable to avoid overheating and avoid stretching it (DO NOT pull it, tug
it or use it to drag the appliance to which is connected). Before unplugging the
appliance, switch it off, using the proper command on the Control Box.
20. Switch the appliance off when not in use and before filling or emptying the
appliance. Before storing, cleaning or performing any maintenance operation,
leave to cool for at least 1 hour.
21. In case of malfunction or anomaly during the functioning, switch off the appliance
immediately, turn off the power and check the cause of the anomaly, if possible,
with the support of a qualified person.
22. If smoke is observed coming out of the appliance, unplug the power cable
immediately.
23. This appliance is NOT intended for commercial use but to be used in households
and similar applications. It should NOT be used in interior environments like
dining rooms of shops, office, dormitories or other working environments, hotels,
motels, guest houses or breakfast rooms, or other accommodation
environments.
24. This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall NOT play with the appliance. Cleaning and user
maintenance shall NOT be made by children unless they are older than 8 and
supervised. Keep the appliance and its cable out of reach of children less than 8
years old.
25. Should the barbecue fail to operate or should it be damaged, please contact the
nearest authorised service centre as special tools are needed for its repair.
Never attempt to repair the barbecue yourself.
26. Save these instructions.

How to use s
Warning: DO NOT operate the appliance with any of its parts unassembled. The
entire assembled unit works as a single appliance. The appliance must only operate
in the upright position. Any other position will be hazardous.
1. Choose a location to operate the appliance that is out in the open, NOT next to a
wall or corner. Ensure that no flammable materials are placed around it, under it
or above it.
2. Place the assembled appliance on a horizontal, stable and heat-resistant
surface, impervious to splashes and stains. When grilling food with a high fat or
moisture content, splashes are unavoidable. Food with a high fat or moisture
content may also tend to ignite.
3. Always fill the Body with water between the minimum 0.4 L (400 mL) & maximum
0.9 L (900 mL) before you switch on the appliance, and ensure that the water
level is kept between these volumes at all times during use. The water helps to
cool down the Grill, reduces the build-up of smoke, and also facilitates cleaning.
DO NOT connect the appliance to the electric mains until the Body has been
filled with water. DO NOT pour water onto the Heating Element to prevent the
possibility of electric shock
4. Check that the heating element is correctly fitted to the Body and safely locked.
5. Plug the power cable into the wall socket and switch it ON. Heating will
commence immediately.
DO NOT, under any circumstances, use charcoal or any other solid or
liquid fuel to operate the grill.
6. Set the Thermostat Control Knob to its ‘Max’ position. The indicator light turns
on, and the heating element is permanently switched on. Never switch the
Heating Element on when it is NOT placed onto the appliance.
7. When it is first switched on, the grill may emit a new smell. A small amount of
smoke may also be noticeable. We therefore recommend that the grill be
allowed to heat up for a moment without any food on the Grill Rack. Ensure
sufficient ventilation for the smell and smoke to disperse.
8. After approximately 5 – 10 minutes, the Heating Element reaches the right
temperature for grilling. Food may be placed on the Grill Rack. Turn the
Thermostat Control Knob to a lower position to avoid overheating the food.
Never, under any circumstances, cover the Grill Rack with any solid
material such as an aluminum foil or tray, barbecue dishes or other items,
as the resulting build-up of heat could cause irreparable damage to the
appliance.
9. The grill can also be used to keep food warm: turn the Thermostat Control Knob
to a lower position. The Heating Element will be switched on and off alternately,
and thus the food can be kept warm.

10. When grilling is finished, turn the Thermostat Control Knob to ‘0’ (OFF), switch
the wall socket off and unplug the power cable.
11. Always bear in mind that the Heating Element, Grill Racks and Upper Grill, as
well as the other parts of the appliance become very hot during operation. Even
after the Heating Element is switched off, it must NOT be touched until it has
sufficiently cooled down – there is otherwise a severe danger of burns. Before
carrying, transporting or storing the grill, ensure that it has sufficiently cooled
down. Pour out any remaining water after use.

How to clean s
1. Turn the Thermostat Control Knob to ‘0’ (OFF), switch the wall socket off and
unplug the power cable when not in use. Wait until the appliance has completely
cooled before cleaning or performing any maintenance operation.
2. Through away water in the Body.
3. Wipe the exterior of the appliance using a soft, damp cloth or sponge. Remove
stubborn spots with a cloth moistened with mild liquid detergent. DO NOT use
abrasive scouring pads or powders.
4. Never immerse the appliance in water or other liquids, especially the Control Box
and Heating Element. Clean the Heating Element with a clean and dry cloth only.
5. Clean the Grill Rack, Upper Grill, Zinc Plate & Body, and Windshield with warm
soapy water and dry afterwards. DO NOT use abrasive scouring pads or
powders.
6. After cleaning, the grill should be stored indoors in a dry location.

ENVIRONMENTAL TIP s
This appliance, along with all other electronic appliances, should, when it is no
longer capable of functioning, be disposed with the least possible environmental
damage according to the local regulations in your area. In most cases you can
discard the appliance at your local recycling center.
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of
such waste separately for special treatment is necessary.
SPECIFICATIONS s
MODEL
PPQ2020
VOLTAGE
220 –240V ~50 –60Hz
POWER
2000W
DIMENSIONS
565 (L) X 370 (W) mm
adjustable Height

WARRANTY s
Warranty Conditions
1. This warranty provides against defective materials and manufacturing faults
throughout for two years from the date of purchase of the appliance. The
warranty on the Compressor is 10 years subject to the same conditions as
above.
2. This warranty also does not cover normal wear and tear, replacement of
consumable materials and accessories, and the cost of maintenance of the
appliance.
3. This warranty does not cover the repair or replacement of part/s damaged by
misuse, accidents, negligence, alterations, or modifications in any way, or repairs
done by any repair organisation without the prior consent of PowerPac Electrical
Pte Ltd.
4. Repair and service are to be performed at: 5 Changi South Lane #03-01
Singapore 486045. A transport fee will be charged for personal doorstep
service.
5. The original purchaser of the appliance must furnish proof of purchase to our
Service Centre with the email or number as registered during submission of
warranty when this appliance is sent for repair/service. Failure to do so may
delay the receipt of said repair/service by the customer.
6. Under no circumstances whatsoever shall the serial number be erased, defaced
or altered by the customer and/or his representatives, or the dealer and/or his
agents. Failure to ensure this shall invalidate the warranty.
7. This warranty is deemed to be void if the defect is cause by the attack of
household pests, fire, lightning, natural disasters, pollution, abnormal voltage or
the usage of generators.
8. This warranty is valid in Singapore only.
9. This warranty will be honoured subject to the customer’s registration of the
warranty inclusive of original invoice or valid purchase receipt. Failure to present
these documents will result in denial of service. However, if the customer still
requests that the defective appliance be repaired, PowerPac Electrical Pte Ltd
may, at its discretion, repair the appliance but impose a labour charge, as well as
the costs of the replacement parts, to be borne solely by the customer.
10. Please refer to the attached picture for the location of
one of our appliance’s serial number, as an example.
