HOIST 1050W 300/600KG
POWX902
1 APPLICATION
This cable hoist is used to hoist and lower loads. It is the ideal tool for interior design hoisting,
construction site loading, repair shop loading and so on.
WARNING! For your own safety, read this manual and general safety
instructions carefully before using the appliance. Your power tool should
only be passed on together with these instructions.
2 DESCRIPTION (FIG. A)
1. Installation brackets
2. Washer
3. Mounting Case
4. Motor Housing
5. Hook Bracket
6. Cable spool
7. Steel cable
8. Lift limit bracket
9. Down limit bracket
10. Stopper
11. Spring buffer unit
12. Load Hook
13. Load hook with pulley
14. Remote control
15. Emergency switch
16. Operating switch: Up / Down
17. Power cord
3 PACKAGE CONTENT LIST
▪Remove all packaging materials.
▪Remove remaining packing and package inserts (if included).
▪Check that the package contents are complete.
▪Check the appliance, the power cord, the power plug and all accessories for transportation
damage.
▪Keep the packing materials as long as possible till the end of the warranty period. Dispose
it into your local waste disposal system afterwards.
WARNING: Packaging materials are not toys! Children must not play with
plastic bags! Danger of suffocation!
2 Installation brackets
1 Load pulley hook
4 Hexagon head screws
4 Washers
4 Spring lock washers
If any parts are missing or damaged, please contact your dealer.
4 SYMBOLS
The following symbols are used in this manual and/or on the machine:
Denotes risk of personal
injury or damage to the tool.
Read manual before use.
In accordance with essential
safety standards of applicable
European directives.
Handschuhe tragen

POWX902 EN
Copyright © 2021 VARO NV P a g e | 3www.varo.com
5 GENERAL POWER TOOL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to heed warnings and follow instructions
may result in electric shock, fire and/or serious injury. Keep safety warnings and instructions
for future reference. The term "power tool" in the safety warnings refers to your mains-
operated (corded) power tool or battery- operated (cordless) power tool.
5.1 Working area
▪Keep working area clean and well lit. Untidy and dark areas can lead to accidents.
▪Do not operate power tools in potentially explosive surroundings, for example, in the
presence of inflammable liquids, gases or dust. Power tools create sparks which may
ignite the dust or fumes.
▪Keep children and bystanders at a distance when operating a power tool. Distractions can
cause you to lose control of it.
5.2 Electrical safety
Always check that the power supply corresponds to the voltage on the
rating plate.
▪Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
adapter plugs with earthed power tools. Unmodified plugs and matching outlets will reduce
the risk of an electric shock.
▪Avoid body contact with earthed surfaces such as pipes, radiators, kitchen ranges and
refrigerators. There is an increased risk of an electric shock if your body is earthed.
▪Do not expose power tools to rain or wet conditions. If water gets inside a power tool, it will
increase the risk of an electric shock.
▪Do not damage the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep the cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of an electric shock.
▪When operating a power tool outdoors, use an extension cable suitable for outdoor use.
Using a cord suitable for outdoor use reduces the risk of an electric shock.
▪If operating a power tool in a damp location is unavoidable, use a power supply protected
by a residual current device (RCD). Using an RCD reduces the risk of an electric shock.
5.3 Personal safety
▪Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool when you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention when operating a power tool may result in serious
personal injury.
▪Use safety equipment. Always wear eye protection. Using safety equipment such as a
dust mask, non-skid safety shoes, a hard hat, or hearing protection whenever it is needed
will reduce the risk of personal injury.
▪Avoid accidental starts. Ensure the switch is in the off position before inserting the plug.
Carrying power tools with your finger on the switch or plugging in power tools when the
switch is in the on position makes accidents more likely.
▪Remove any adjusting keys or spanners before turning on the power tool. A spanner or
key left attached to a rotating part of the power tool may result in personal injury.
▪Do not reach out too far. Keep your feet firmly on the ground at all times. This will enable
you retain control over the power tool in unexpected situations.
▪Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from the power tool. Loose clothes, jewellery or long hair can become
entangled in the moving parts.

POWX902 EN
Copyright © 2021 VARO NV P a g e | 4www.varo.com
▪If there are devices for connecting dust extraction and collection facilities, please ensure
that they are attached and used correctly. Using such devices can reduce dust-related
hazards.
5.4 Power tool use and care
▪Do not expect the power tool to do more than it can. Use the correct power tool for what
you want to do. A power tool will achieve better results and be safer if used in the context
for which it was designed.
▪Do not use the power tool if the switch cannot turn it on and off. A power tool with a broken
switch is dangerous and must be repaired.
▪Disconnect the plug from the power source before making adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
▪Store power tools, when not in use, out of the reach of children and do not allow people
who are not familiar with the power tool or these instructions to operate it. Power tools are
potentially dangerous in the hands of untrained users.
▪Maintain power tools. Check for misalignment or jammed moving parts, breakages or any
other feature that might affect the operation of the power tool. If it is damaged, the power
tool must be repaired. Many accidents are caused by using poorly maintained power tools.
▪Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to jam and are easier to control.
▪Use the power tool, accessories and cutting tools, etc., in accordance with these
instructions and in the manner intended for the particular type of power tool, taking into
account the working conditions and the work which needs to be done. Using a power tool
in ways for which it was not intended can lead to potentially hazardous situations.
5.5 Service
▪Your power tool should be serviced by a qualified specialist using only standard spare
parts. This will ensure that it meets the required safety standards.
6 EXTRA SAFTY INFORMATION
ATTENTION! Never use the machine to transport persons or animals!
Never stand or work under a hoisted load.
▪Keep the immediate working environment clean.
▪Please consider environmental influences. Ensure good illumination for your workspace.
Do not use the device in potential fire hazard, easily flammable fluids or explosive
surroundings, do not expose it to unnecessary weather influences, such as rain, damp,
sun exposure, dust or cold.
▪Protect yourself from electrical shock.
▪Keep this device away from unauthorized persons.
▪Store the cable hoist in a proper manner when it is not in use. Store the machine at a dry,
high or lockable place, out of the reach of children.
▪Do not overload the cable hoist, in any case! Please do not exceed the maximum load
capacity (see data plate, not load hook!). Do not use 2 or more machines to load same
object.
▪Forbid to lift an attached/fixed object.
▪Don't use the machine in aggressive environments or under low temperatures.
▪Wear safety clothes. Never wear loose clothing or jewellery; this could be caught by
movable parts of the machine. Safety equipment (such as rubber gloves, non-slip
footwear, hearing and hair protection and etc.) is recommended when working.

POWX902 EN
Copyright © 2021 VARO NV P a g e | 5www.varo.com
▪Only use the power cord (17) for its intended use. Never carry the tool or pull on the power
cord (17) and never pull on the cord to disconnect the power plug from the power outlet.
Keep the power cord (17) away from heat, oil and sharp edges. Check the power cord (17)
before every use for damages. Never use the cable hoist, if the cord is worn out, knotted
itself, or has a kink. Allow the cord to be replaced by a qualified professional.
▪Please be sure to maintain upright body position. Ensure a safe position and always
maintain your balance, and not at an extreme angle.
▪Disconnect the cable hoist from the power network when not in use and prior to
performing any maintenance.
▪Always work carefully and with a due amount of caution.
▪Use only the manufacturer recommended accessories.
▪Have your cable hoist repaired only by a qualified electrician. This power tool complies
with applicable safety regulations.
▪Be sure to hoist the loads with lowest speed from the ground. And the cable should be
tense but not unwound when start loading from the ground.
▪The micro switch is not allowed to be used as an off-switch or be dismantled. The micro
switch is a safety device to prevent that the weight is lifted over the boundary.
▪If the brakes stop functioning and the load lowers quickly, one should press the off-switch
immediately and then the On-switch. After unloading, please send the machine in for
repairs to a qualified professional.
▪Do not leave the load hanging in the air long-term, to prevent the deformation of the
pieces. While the machine is in operation do not carry out any repairs or inspections.
▪It is prohibited to change any part of the pulley or to disassemble it.
▪Depending on the frequency of use, after 20 hours of total operation or at least once a
year, the machine must be taken in for a thorough maintenance.
▪Make sure to operate the emergency switch (15) to stop the machine in case of dangerous
and emergent situation. Reset the emergency switch (15) head to operation status in the
direction of the arrow (clockwise) until the danger has passed.
7 BEFORE EVERY USE
Attention! The cable hoist is designed only for domestic use! It is not
intended for professional applications. This device can be operated without
hazards only if you read this user manual and safety instructions and
closely follow all instructions.
Prior to start-up operation, please be sure to make some preparations:
▪Make sure the voltage of your power network complies with the voltage listed on the data
plate and that the device is equipped with the correct power plug.
▪Please make no-loading test before start-up operation at first, and please check:
−a, The flexibility of the operating switch (16) to insure the controlling of the hoisting and
lowering of the load hook (12).
−b, The flexibility of lift limit bracket (8) to make sure the cut-off of circuit.
−c. The flexibility of down limit bracket (9) to make sure the cut-off circuit when the steel
cable (7) is nearly used up.
−d, Any abnormal sounds when start-up operation.
−e, The steel cable (7) is possible damaged (split or bent), change the cable immediately.
▪Please check the brake before operating after load.
▪Please inspect the load hook (12) before operation is possible damaged or distortional,
replace it in time.
▪Operation using a residual current protective device (Emergency Switch, 15) offers
additional protection.

POWX902 EN
Copyright © 2021 VARO NV P a g e | 6www.varo.com
▪Please be sure to the enough lubricant on parts. Daub the lubricant on the load hook (12),
cable drum shaft, slow down box, and bearing every half a year.
▪Please daub the lubricant on the nesting of cable drum shaft when replace the steel cable
(7) every time. Immediately replace the cable if damaged.
▪Please perform any rework and maintenance tasks only if the power plug is disconnected.
▪Please inspect the device for transportation damages. Immediately report any possible
damages to your seller.
8 INSTALLATION
▪Install the cable hoist on a steel beam (Fig 2). Use only the enclosed installation brackets
(1) which can be attached to the top of the mounting casing (3) using the screws, washers
and spring lock washers. The steel beam must be able to withstand at least double the
rated weight of the machine. Contact a professional installer for best results.
▪The steel beam must have the following dimension: 46 x 46 mm, a wall thickness of at
least 2.3 mm and a length of at least 450 mm (Fig 1).
▪The steel beam must be securely anchored in a wall. The anchor must be installed
correspondingly sturdy in order to be able to withstand the load.
▪Please be sure that the machine is installed level and not slanted.
▪The remote control (14) must be easily accessible at all times and must therefore be
installed at a distance to the floor of between 0.8 m and 1.5 m (Fig 3).
▪Insert the load hook (12) into the hook bracket (5) of the mounting casing (3) when using
the load hook with pulley (13).
▪The electric pulley will be attached at the top. Attach the pulley with bearer frame on the
crossbar. The girder is then attached to the support columns. The support columns must
be, in accordance with the requirements of the customer, properly secured on the working
area. The support columns must be installed to be sturdy and stable. Also be able to
withstand a nominal load long-term.
9 OPERATION
▪Prior to starting work, please be sure that the steel cable (7) is wound up exactly, layer
next to layer on the cable spool (6). Never unwind the cable completely!
▪Unwind the cable only to the point that at least 3 more layers are located on the drum.
▪If the red indicator mark is visible, please stop the cable hoist immediately and do not
continue to unwind the cable!
▪Always wind the cable as shown in Fig. 4.
Note: When replace the wire rope, be sure to pull rope into the square hole
of rope drum, and then pull it out from the round hole. With that wind the
rope two circles and then pull it to the edge which is side of rope drum and
fix it.
▪The cable hoist is operated using the remote control (14). When operating the upper
position of the switch, the load is hoisted up. When operating the lower position, the load
is lowered. Never switch directly from hoisting to lowering or vice versa. Always stop the
cable hoist prior to changing directions.
▪Operate the Emergency switch (15) to immediately stop the cable hoist in case of an
emergency and to secure against restart. To reset the device to operational status, first
turn the Emergency switch (15) clockwise, which will unlock the Emergency switch (15).
The cable hoist is now operational.

POWX902 EN
Copyright © 2021 VARO NV P a g e | 7www.varo.com
▪The cable hoist is designed with limit configuration to limit stop. When load hook (12) is
hoisting up to topmost position, the stopper (10) touch the lift limit bracket (8), the micro
switch of lift limit bracket (8) can cut off the circuit and make the motor stop to insure the
safety of operations. When load hook (12) is lowering down nearly to use up the cable (7),
the micro switch of down limit bracket (9) start work and cut off the circuit and make the
motor stop.
Attention! If the cable has been unwound to the point where the red micro
switch is visible, the cable hoist must be stopped. Under no circumstances
should the cable be unwound past this point'
▪If the cable hoist cannot hoist a load immediately, switch it off immediately to prevent
damages and accidents.
▪Please be sure that the load is securely fastened to the load hook (12-13). Maintain the
largest possible distance to the load and steel cable (7) during operation.
▪Upon lowering a load, please remember that the cable hoist may still unwind a few more
centimetres after it was stopped. Therefore, please stop in sufficient time.
▪Please be sure that the steel cable (7) cannot be moved more than 15° to the side.
▪The cable hoist can be operated with a single or double cables, therefore the permissible
rated load, see Technical Specifications, can vary.
▪After unpacking the items, check to make sure that all pieces and accessories correspond
with the directions. Check to see if the cable hoist has any dents or damage, if the cable
connections have any defects and if the motor shows any signs of rain or water damage.
▪The cable hoist uses a single-phase energy power supply. The nominal voltage is 230V +
20%, the nominal frequency is 50Hz + 1%. The motor must be safely grounded. In the
circuitry of the power supply an over-current protection must be installed.
▪After connecting the power supply, the pulley can then be raised and lowered in Jog-
mode. One can raise and lower start-up during a dry-run. First when the up and down
movement is stable and the brakes work flawlessly, once can test the pulley with a dummy
load.
9.1 Intermittent rating
This machine is designed for operating type S3 20% - 10 min (periodic intermittent operation).
The relative duty cycle is 20%, which means that the device can be operated at rated load for
2.0 minutes during each operating cycle and must then be switched off for 8. 0 minutes to cool
off. The device can therefore be continuously used for a duration of 20% of the total operating
cycle of 10 minutes at rated load.
9.2 Overload (Only for POWX901-POWX902-POWX903)
▪The cable hoist is not suitable for continuous operation. The motor is protected from
overload and overheating by a temperature switch.
▪If the permissible operating time is exceeded, the motor temperature will increase and the
temperature switch will shut the cable hoist off. The temperature switch will automatically
switch back on after a cooling phase.
▪In case of a strain on the cable hoist with a lesser load, the operating time will increase
and the cooling time will decrease.
Attention! In case of direct exposure to sunlight, the temperature of the
casing will increase significantly, which will also decrease the permissible
operating time. It is therefore possible that the temperature switch will
switch off after a short time period and the cable hoist will shut down.
Please wait until the device is cooled off.

POWX902 EN
Copyright © 2021 VARO NV P a g e | 8www.varo.com
9.3 Operation with double cable (Fig 5)
▪Loosen the nuts of the 3 screws located on the load hook with pulley (13) and remove the
cover plate located on the side. Place the steel cable (7) around the deviating shaft and
reattach the cover plate and nuts. Please be sure that the load hook with pulley (13) is
installed properly and that the nuts are securely tightened.
▪Please insert the load hook (12) attached to the cable into the hook bracket (5) of the
mounting casing (3).
10 CLEANING AND MAINTENANCE
▪Disconnect the power plug prior to performing any work on the device.
▪Clean the device using a damp cloth and some liquid soap. Never use cleaning agents or
solvents, these could damage the device's plastic parts.
▪Regularly inspect the total length of the steel cable (7) for damages as well as the
functionality of the limit bracket (Wind cable hoist until the stopper (10) activates the limit
bracket of the micro switch).
▪If the steel cable (7) is damaged (split or bent, fig 6), a professional must replace it using
original replacement parts.
▪During assembly of the cable, it is imperative to remember the stopper in order to ensure a
secure limit stop.
▪Inspect the free movement of all mechanical components after the power plug has been
disconnected.
▪Replace lost parts only with original parts.
▪Return the device to your seller to ensure professional recycling.
11 TECHNICAL DATA
Rated voltage
230v~
Rated frequency
50 Hz
Power rating:
1050W
Rated current
4.6 A
Max. loading capacity
-for single cable
-for double cable
300 kg
600 kg
Cable speed
-for single cable
-For double cable
8m/min
4m/min
Hoisting height
-for single cable
-For double cable
12 m
6 m
Cable diameter
4.5 mm
Protection rating
IP54
Motor category
A1
Work duty
ED: 20%
Protection rating
I
Weight
18 kg
12 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic power level LwA
71 dB(A)

POWX902 EN
Copyright © 2021 VARO NV P a g e | 9www.varo.com
13 PROBLEM-SOLVING
Common
Malfunction
Cause
Solution
The opeating switch is
used but the motor
does not turn
1. It is not plugged into the power
supply.
2. The wires are broken or
ripped.
3. Switch Malfunction
4. The capacitor is burned
through.
5. End-switch has not been reset
or a micro switch error
6. The thermal switch has
suffered a wire break.
1. Connect the item to the
power supply.
2. Check the wires and plug
it in again to the outlet.
3. Repair switch or change it
4. Change your capacitor
5. Check the end-switch and
replace the limit switch.
6. Wait until the item cools
down, or replace the thermal
switch.
The operation switch
switch has been
activated. The motor
is very loud, can
however not pick-up
the load.
1. The voltage offered is too
small.
2. The capacitor has become
damaged.
3. The brake is not completely
open.
1. Adjust the work,
depending on the power
supply
2. Change power supply.
3. Allow the machine to be
repaired from a qualified
repair service
After a power loss the
brakes do not hold or
the machine slips
down
▪The air between the brakes
is too large
▪The brake spring is ripped.
▪The brake disk is locked
▪The brake disk is at the start
already dirty.
▪Allow the machine to be
repaired from a qualified
repair service.
The noise of the
machine becomes
louder
1. Badly oiled
2. After a long use, the cogwheel
and bearings are damaged.
3. Badly installed or dent
1. Oil/Grease machine
officially.
2. Change the cogwheel or
bearings.
3. Check installed parts or let
a qualified person check this
The cable hoist has
too much voltage.
1. Earthed error or is not possible
2. The internal connectors are
touching the housing
1. Checked earthed wires
and properly connect them.
2. Check all internal
connections
End-switch is not
functioning.
1. The end-switch is defect
2. End-switch is blocked
1. Switch off or change
2. Check, repair, and change
End switch

POWX902 EN
Copyright © 2021 VARO NV P a g e | 10 www.varo.com
14 WARRANTY
▪This product is warranted for a 36-month period effective from the date of purchase by the
first user.
▪This warranty covers all material or production flaws excluding : batteries, chargers,
defective parts subject to normal wear & tear such as bearings, brushes, cables, and
plugs, or accessories such as drills, drill bits, saw blades, etc. ; damage or defects
resulting from maltreatment, accidents or alterations; nor the cost of transportation.
▪Damage and/or defects resulting from inappropriate use also do not fall under the
warranty provisions.
▪We also disclaim all liability for any bodily injury resulting from inappropriate use of the
tool.
▪Repairs may only be carried out by an authorised customer service centre for Powerplus
tools.
▪You can always obtain more information at the number 00 32 3 292 92 90.
▪Any transportation costs shall always be borne by the customer, unless agreed otherwise
in writing.
▪At the same time, no claim can be made on the warranty if the damage of the device is the
result of negligent maintenance or overload.
▪Definitely excluded from the warranty is damage resulting from fluid permeation, excessive
dust penetration, intentional damage (on purpose or by gross carelessness), inappropriate
usage (use for purposes for which the device is not suitable), incompetent usage (e.g. not
following the instructions given in the manual), inexpert assembly, lightning strike,
erroneous net voltage. This list is not exhaustive.
▪Acceptance of claims under warranty can never lead to the prolongation of the warranty
period nor commencement of a new warranty period in case of a device replacement.
▪Devices or parts which are replaced under the warranty therefore remain the property of
Varo NV.
▪We reserve the right to reject a claim whenever the purchase cannot be verified or when it
is clear that the product has not been properly maintained. (Clean ventilation slots, carbon
brushes serviced regularly, etc.).
▪Your purchase receipt must be kept as proof of date of purchase.
▪Your appliance must be returned undismantled to your dealer in an acceptably clean state,
(in its original blow-moulded case if applicable to the unit), accompanied by proof of
purchase.
15 ENVIRONMENT
Should your appliance need replacement after extended use, do not discard it
with the household rubbish but dispose of it in an environmentally safe way.
Waste produced by electrical machine items should not be handled like normal
household rubbish. Please recycle where recycle facilities exist. Check with your
Local Authority or retailer for recycling advice.

POWX902 EN
Copyright © 2021 VARO NV P a g e | 11 www.varo.com
16 DECLARATION OF CONFORMITY
VARO N.V. -Vic. Van Rompuy N.V. Joseph Van Instraat 9 - BE2500 Lier - BELGIUM,
declares that,
product: Hoist
trade mark: POWERplus
model: POWX902
is in conformity with the essential requirements and other relevant provisions of the applicable
European Directives, based on the application of European harmonized standards. Any
unauthorized modification of the apparatus voids this declaration.
European Directives (including, if applicable, their amendments up to the date of signature);
2011/65/EU
2006/42/EC
2014/30/EU
European harmonized standards (including, if applicable, their amendments up to the date of
signature);
EN14492-2 : 2019
EN60204-32 : 2008
EN55014-1 : 2017
EN55014-2 : 2015
EN IEC61000-3-2 : 2019
EN61000-3-3 : 2013
Keeper of the Technical Documentation : Philippe Vankerkhove, VARO –Vic. Van Rompuy
N.V.
The undersigned acts on behalf of the company CEO,
Ludo Mertens
Regulatory Affairs –Compliance Manager
03/12/2020, Lier - Belgium
