GSi PNEG-222 User manual

PNEG-222
48' Diameter Bin
Cor-Lok and Cut-Lok Flooring
and Grandstand Layout
Installation Manual
PNEG-222
Version: 3.0
Date: 09-30-15

2PNEG-22248' Diameter Bin Cor-Lok and Cut-Lok Flooring
All information, illustrations, photos, and specifications in this manual are based on the latest
information available at the time of publication. The right is reserved to make changes at any
time without notice.

Table of Contents
PNEG-222 48' Diameter Bin Cor-Lok and Cut-Lok Flooring 3
Contents
Chapter 1 Introduction ..........................................................................................................................................4
Chapter 2 Safety .....................................................................................................................................................5
Safety Guidelines for Bins ..................................................................................................................... 5
Cautionary Symbols Definitions ............................................................................................................ 6
Safety Cautions ..................................................................................................................................... 7
Safety Sign-Off Sheet ........................................................................................................................... 9
Chapter 3 Decals ..................................................................................................................................................10
Chapter 4 Important Note ....................................................................................................................................12
Guidelines for Proper Storage of Grain Bin Materials Prior to Construction ....................................... 12
Chapter 5 Recommended Method for Full Floor Installation ...........................................................................13
Fan Placement Diagram ..................................................................................................................... 13
Grain Systems Recommended Method for Full Floor Installation ....................................................... 14
Undersplice Specifications .................................................................................................................. 17
Installing the Undersplices and Oversplice for Small Grain Floor Planks ........................................... 19
Chapter 6 Grandstand Identification ..................................................................................................................20
20 Gauge Grandstand Identification ................................................................................................... 20
Chapter 7 Flashing Installation ...........................................................................................................................21
Grain Systems Formed Flashing Installation ...................................................................................... 21
Chapter 8 Grandstand Layout at Center Well for Recirculating System ........................................................22
Chapter 9 Well Installation Cut Detail ................................................................................................................23
Well Installation Plank Cut Detail for 42', 48' and 60' Split Floor ......................................................... 23
Chapter 10 48' Cor-Lok/Cut-Lok Plank Order ....................................................................................................24
Chapter 11 Plank Lengths ...................................................................................................................................25
Optional 48' 3' Offset Splice Plank Length ........................................................................................ 26
Chapter 12 48' Grandstand Layout for Recirculating System .........................................................................27
48' 20 Gauge Grandstand Layout for Recirculating System Cut-Lok or 18 Gauge Cor-Lok Floors .. 27
Chapter 13 48' Grandstand Layouts, 33' Maximum Wall Height ......................................................................28
48' Cor-Lok/Cut-Lok and 20 Gauge Grandstand Layout 2.66'' Corrugated Bins
5 Rings and 4.00" Corrugated Bins 4 Rings ...................................................................................... 28
48' Cor-Lok/Cut-Lok and 20 Gauge Grandstand Layout 2.66" Corrugated Bins 6 Rings .................. 29
48' Cor-Lok/Cut-Lok and 20 Gauge Grandstand Layout 2.66" Corrugated Bins
7 Rings and 4.00" Corrugated Bins 5 Rings ...................................................................................... 30
48' Cor-Lok/Cut-Lok and 20 Gauge Grandstand Layout 2.66" Corrugated Bins
8 Rings and 4.00" Corrugated Bins 6 Rings ...................................................................................... 31
48' Cor-Lok/Cut-Lok and 20 Gauge Grandstand Layout 2.66" Corrugated Bins 9 Rings .................. 32
48' Cor-Lok/Cut-Lok and 20 Gauge Grandstand Layout 4.00" Corrugated Bins 7 Rings .................. 33
48' Cor-Lok/Cut-Lok and 20 Gauge Grandstand Layout 2.66" Corrugated Bins 10 Rings ................ 34
48' Cor-Lok/Cut-Lok and 20 Gauge Grandstand Layout 2.66" Corrugated Bins
11 Rings and 4.00" Corrugated Bins 8 Rings .................................................................................... 35
48' Cor-Lok/Cut-Lok and 20 Gauge Grandstand Layout 2.66" Corrugated Bins 12 Rings ................ 36
48' Cor-Lok/Cut-Lok and 20 Gauge Grandstand Layout 4.00" Corrugated Bins 9 Rings .................. 37
Chapter 14 20 Gauge Floor Support Requirements .........................................................................................38
20 Gauge Grandstand Chart - 2.66" Corrugation .............................................................................. 38
20 Gauge Grandstand Chart - 4.00" Corrugation .............................................................................. 39
Chapter 15 Flashing Support at Stiffeners ........................................................................................................40
Stiffener Flashing Support Instructions for Internal Universal Stiffeners ........................................... 40
Chapter 16 Air Flow Support Instructions .........................................................................................................41
Installation of Air Flow Supports ........................................................................................................ 41
Chapter 17 Warranty ............................................................................................................................................47
SEE PAGE 38 AND PAGE 39 FOR 20 GAUGE
FLOOR SUPPORT REQUIREMENTS.

4PNEG-22248' Diameter Bin Cor-Lok and Cut-Lok Flooring
1. Introduction
READ THIS MANUAL carefully to learn how to properly use and install equipment. Failure to do so could
result in personal injury or equipment damage.
INSPECT the shipment immediately upon arrival. The customer is responsible for ensuring that all
quantities are correct. The customer should report and note any damage or shortage on the bill of
lading to justify their claim to the transport company.
THIS MANUAL SHOULD BE CONSIDERED a permanent part of your equipment and should be easily
accessible when needed.
This warranty provides you the assurance that the company will back its products when defects appear
within the warranty period. In some circumstances, the company also provides field improvements, often
without charge to the customer, even if the product is out of warranty. Should the equipment be abused,
or modified to change its performance beyond the factory specifications, the warranty will become void
and field improvements may be denied.

PNEG-222 48' Diameter Bin Cor-Lok and Cut-Lok Flooring 5
1. Safety
Safety Guidelines for Bins
Safety guidelines must be followed at all times. This manual is written to help you understand safe
operating procedures and problems that can be encountered by the operator and other personnel when
using this equipment. Save these safety guidelines for future reference.
As owner or operator, you are responsible for understanding the requirements, hazards, and precautions
that exist and to inform others as required. Unqualified persons must stay out of the work area at all times.
Alterations must not be made to the equipment. Alterations can produce dangerous situations resulting in
SERIOUS INJURY or DEATH.
This equipment must be installed in accordance with the current installation codes and applicable
regulations, which should be carefully followed in all cases. Authorities having jurisdiction must be
consulted before installations are made.
When necessary, you must consider the installation location relative to electrical, fuel and water utilities.
Personnel operating or working around equipment must read this manual. This manual must be delivered
with equipment to its owner. Failure to read this manual and its safety instructions is a misuse of
the equipment.
This product is intended for the use of grain storage only. Any other use is a misuse of the product.
Sidewall bundles or sheets must be stored in a safe manner. The safest method of storing sidewall
bundles is by laying them horizontally with the arch of the sheet upward, like a dome. Sidewall sheets
stored on edge must be secured so that they cannot fall over and cause injury. Use care when handling
and moving sidewall bundles.
ST-0035

1. Safety
6PNEG-22248' Diameter Bin Cor-Lok and Cut-Lok Flooring
Cautionary Symbols Definitions
Cautionary symbols appear in this manual and on product decals. The symbols alert the user of potential
safety hazards, prohibited activities and mandatory actions. To help you recognize this information, we
use the symbols that are defined below.
DANGER
WARNING
CAUTION
NOTICE
This symbol indicates an imminently hazardous situation
which, if not avoided, will result in serious injury or death.
This symbol indicates a potentially hazardous situation
which, if not avoided, may result in serious injury or death.
This symbol indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate injury.
This symbol is used to address practices not related to
personal injury.
This symbol indicates a general hazard.
This symbol indicates a prohibited activity.
This symbol indicates a mandatory action.
ST-0005

1. Safety
PNEG-222 48' Diameter Bin Cor-Lok and Cut-Lok Flooring 7
Safety Cautions
Use Personal Protective Equipment
Eye
Protection
Hearing
Protection
Hand
Protection
Head
Protection
Respiratory
Protection Foot
Protection
Fall
Protection
• Use appropriate personal protective equipment:
• Wear clothing appropriate to the job.
• Remove all jewelry.
• Tie long hair up and back.
ST-0004-1
Follow Safety Instructions
• Carefully read all safety messages in this manual and
safety signs on your machine. Keep signs in good
condition. Replace missing or damaged safety signs.
Be sure new equipment components and repair parts
include the current safety signs. Replacement safety
signs are available from the manufacturer.
• Learn how to operate the machine and how to use
controls properly. Do not let anyone operate without
instruction.
• If you do not understand any part of this manual or
need assistance, contact your dealer.
ST-0002-1

1. Safety
8PNEG-22248' Diameter Bin Cor-Lok and Cut-Lok Flooring
Maintain Equipment and Work Area
• Understand service procedures before doing work. Keep area
clean and dry.
• Never service equipment while it is operating. Keep hands, feet,
and clothing away from moving parts
• Keep your equipment in proper working condition. Replace worn
or broken parts immediately.
ST-0003-1
Prevent Roof Damage Due to Vacuum Pressure
• Roof damage can result from excessive vacuum or internal
pressure from fans or other air moving systems. The manufacturer
does not warrant this type of roof damage.
• Adequate ventilation or “makeup air” devices should be provided
for all powered air handling systems.
• The manufacturer does not recommend the use of downward flow
systems (suction).
• Severe roof damage can result from any blockage of air
passages.
• Running fans during high humidity or cold weather conditions can
cause air exhaust or intake ports to freeze.
ST-0028-1
Sharp Edge Hazard
• This product has sharp edges, which may cause serious injury.
• To avoid injury, handle sharp edges with caution and always use
proper protective clothing and equipment.
ST-0036-1

1. Safety
PNEG-222 48' Diameter Bin Cor-Lok and Cut-Lok Flooring 9
Safety Sign-Off Sheet
Below is a sign-off sheet that canbeused to verify that all personnel have read and understoodthesafety
instructions. This sign-off sheet is provided for your convenience and personal record keeping.
Date Employee Name Supervisor Name
ST-0007

10 PNEG-222 48' Diameter Bin Cor-Lok and Cut-Lok Flooring
2. Decals
The safety decals on your equipment are safety indicators which must be carefully read and understood
by all personnel involved in the installation, operation, service and maintenance of the equipment.
To replace a damaged of missing decal, contact us to receive a free replacement.
GSI Decals
1004 E. Illinois St.
Assumption, IL. 62510
Phone: [phone]
Location Decal # Decals Description
Located next to
aeration system. DC-995 Caution Vacuum Pressure
Excessive vacuum (or pressure) may
damage roof. Use positive aeration
system. Make sure all roof vents are
open and unobstructed. Start roof
fans when supply fans are started.
Do not operate when conditions exist
that may cause roof vent icing.
DC-969
CAUTION
GSI Group, Inc. 217-226-4421

2. Decals
PNEG-222 48' Diameter Bin Cor-Lok and Cut-Lok Flooring 11
On bin door
covers DC-GBC-1A Danger Keep Clear of Augers
On bin door
covers DC-GBC-2A Warning Unload
Instructions
Location Decal # Decals Description
Rotating flighting will
kill or dismember.
Flowing material will
trap and suffocate.
Crusted material will
collapse and suffocate.
DANGER
Keep clear of all augers.
DO NOT ENTER this bin!
If you must enter the bin:
1. Shut off and lock out all power.
2. Use a safety harness and safety line.
3. Station another person outside the bin.
4. Avoid the center of the bin.
5. Wear proper breathing equipment or respirator.
Failure to heed these
warnings will result in
serious injury or death.
DC-GBC-1A
GSI GROUP, INC. 217-226-4421
WARNING
GSI GROUP, INC. 217-226-4421
1. Use CENTER FLOOR OUTLET ONLY until NO grain
remains above this outlet.
2. Side floor outlets to be used ONLY when above
condition is satisfied.
3. Lock all side floor outlets to avoid accidental
premature use.
4. See manufacturers instructions for proper use of
factory supplied sidedraw (wall) discharge systems.
UNLOADING INSTRUCTIONS:
Failure to heed these warnings
could result in serious injury, death,
structural damage or collapse of tank.
DC-GBC-2A

12 PNEG-222 48' Diameter Bin Cor-Lok and Cut-Lok Flooring
3. Important Note
Guidelines for Proper Storage of Grain Bin Materials Prior to
Construction
Storage of the build materials prior to construction is important. Do not to allow moisture to remain
between sheets or panels.
Wetstoragestain(rust)willdevelopwhenclosely packed bundles of galvanized material, such as sidewall
and roof sheets, have moisture present. Inspect roof and sidewall bundles on arrival for any moisture. If
moisture is present, it must not be allowed to remain between the sheets. Separate the sheets or panels
immediately and wipe them down. Spray with a light oil or diesel fuel.
If possible, sidewall bundles, roof sheets and other closely packed galvanized materials should be stored
in a dry, climate controlled building. If outdoor storage is unavoidable, the materials should be stored so
that they are raised above the ground and vegetation. Any stacking and spacing materials should not be
corrosive or wet. Be sure to protect materials from the weather, but permit air movement around the
bundles if possible.
Storing roof bundles and sidewall sheets at a slight incline can also help minimize the presence of
moisture. Storing the bundles with the center of the dome up (like an arch) is one option for minimizing
moisture during storage. Sidewall bundles can also be stored on edge but must be secured so that they
do not fall over and cause injury.
If “white rust” or “wet storage stain” occurs, contact the manufacturer immediately about ways to minimize
the adverse effect upon the galvanized coating.

PNEG-222 48' Diameter Bin Cor-Lok and Cut-Lok Flooring 13
4. Recommended Method for Full Floor Installation
Fan Placement Diagram
For uniform air flow, place the fans in relation to the unloading tube as shown in Figure 4A. Floor planks
should be perpendicular to the unloading tube.
Figure 4A
Ref # Description
APlacement with Two (2) Fans
B Placement with One Fan
CFlooring Planks
D Auger/Unload Equipment

4. Recommended Method for Full Floor Installation
14 PNEG-222 48' Diameter Bin Cor-Lok and Cut-Lok Flooring
Grain Systems Recommended Method for Full Floor Installation
Using the GSI recommended method for full floor installation should save construction time and eliminate
the problem of improper installation which could invalidate your warranty. Note the following dimensions
as shown in Figure 4B.
• Dimension “A” is the leg-to-leg spacing along the centerline of a given plank.
• Dimension “B” is the amount of stagger between supports under adjacent planks and is half
of Dimension “A”.
• Dimension “C” is the distance from the center of the unload auger to the nearest rows of
supports and is half of Dimension “B”.
Dimensions “A”, “B” and “C” are shown on the appropriate grandstand layout for wall heights under
32 feet. For taller bins, grandstand quantity as well as dimensions “A” and “B” are given on Page 38 and
Page 39 for 20 gauge.
1. Layout centerlines of tank. Make sure one centerline is in line with the direction of the flooring planks
while the other centerline is perpendicular with the flooring planks. (See Figure 4B.)
2. From the centerline that is perpendicular to the flooring planks, measure the distance of “C”
Dimension and mark a chalk line. (See Figure 4B.)
3. From the line chalked in the previous step, measure over the distance of “B” Dimension and chalk
another line. Repeat this procedure across the bin until reaching the wall in both directions. When
completed, there should be a set of parallel lines (perpendicular to the floor planks) with “B”
Dimension distance between each line. (See Figure 4B.)
Figure 4B
Ref # Description
AChalked Lines Referred to Step 2.
B Centerline
C1/2 of “B” Dimension
D Auger/Unload Equipment
A
B
C
B
B
B
B
BBBB

4. Recommended Method for Full Floor Installation
PNEG-222 48' Diameter Bin Cor-Lok and Cut-Lok Flooring 15
IMPORTANT: First piece of flooring must start at the proper distance from centerline of bin. Refer to floor
layoutonPage24.Firstpiecemayneedtobetrimmedforlengthtofitattheproperlocation.
(See Figure 4C.)
Figure 4C
4. Install flooring starting at the bin wall on the opposite side of the unload auger. Floor planks should be
placed perpendicular to the unload auger with the outside edge the correct distance from the center
of the bin.
(See Figure 9A on Page 24.) Be sure the flat edge of the floor plank is facing the bin wall
and the open channel edge (E) is facing towards the center of the bin.
(See Figure 4C.) Position the
supports for the first/shortest floor plank according to the number of bin rings and corrugation as
shown in the illustrations
on Pages 27-37 or stated in the charts on Pages 38-39 . Attach the flashing
to flooring and bin wall to hold plank in place. (
See Page 21 for flashing installation.)
Ref # Description Ref # Description
EOpen Channel Edge IInside Hook
F Flat Edge J Straight Tab
GBin Wall KOutside Hook
H Correct Assembly Method L The Grandstand
Attach flashing to ends of first plank here, just to
hold it in place. NOTE: These two (2) pieces of
flashing will need to be removed and repositioned
when installing the rest of the flashing.

4. Recommended Method for Full Floor Installation
16 PNEG-222 48' Diameter Bin Cor-Lok and Cut-Lok Flooring
5. POSITION THE NEXT ROW OF SUPPORTS ACCORDING TO THE CHALK LINES and support
layout. The straight tab should “snap” under the first (previous) floor piece. After the supports in the
row are correctly positioned, install the next floor piece by hooking the open channel edge (E) under
the outside hooks (K) of the floor supports. Push down sharply on the edge of the floor piece until it
snaps into the previous floor piece. (See Figure 4C on Page 15.) Continue this process for the rest
of the floor cutting planks for center and intermediate wells as needed. See Figure 7A on Page 22
for center well support locations.
NOTE: Whenever there is more than Dimension “B” divided by three inches (B/3") of plank
unsupportedbesidethebinwall,thereshouldbeasupportonthatplankorasupportoneach
of the planks adjacent to it such that no more than Dimension “B” divided by three inches
(B/3") is unsupported. For example: 2.66" bin with 8 rings has a “B” dimension of 22". Take
22"/3" = 7.33" (Round to 7"). Therefore, there should be no more than 7" of unsupported
floor plank.
6. Some floor planks will need to be spliced together. (See Figure 8A on Page 23, Figure 9A on
Page 24 and Plank Lengths Charts on Pages 25-26.) Install plank length A first, then install the
corresponding plank length B by butting plank B up against plank A. Make sure the planks are
supported by a grandstand on each side of the splice. Continue until floor is complete.
Figure 4D Oversplice Bolt Pattern for Small Grain Floors
Ref # Description
MFloor Oversplice Plate
N Floor Planks
OSelf-Drilling Screws
P Splice Seam
QNOTE: Dashed lines indicate items under the oversplice.

4. Recommended Method for Full Floor Installation
PNEG-222 48' Diameter Bin Cor-Lok and Cut-Lok Flooring 17
Undersplice Specifications
The undersplice should be installed underneath the planks at the split after both plank lengths have been
butted together. Each splice has to be installed as each row of planks are installed. Figure 4E shows the
layout of the undersplice plates (A) and the screw pattern used to secure them.
Figure 4E Specifications for installing the Undersplice to Floor Planks
Ref # Part # Description
APCL-7049 Undersplice Plate
B S-280 Self-Tapping Screws
CDenotes Split Plank
D Cut-Lok/Cor-Lok Floor Planks

4. Recommended Method for Full Floor Installation
18 PNEG-222 48' Diameter Bin Cor-Lok and Cut-Lok Flooring
Installing the Undersplice
1. Place plank ends together.
2. Place the undersplice under the planks. Make sure the undersplice extends 3" across each plank.
The splice should extend 3" under each plank. The splice should be screwed in place as shown in
Figure 4E on Page 17.
3. Repeat for all plank locations requiring a splice.
NOTE: Small grain perforated floors include an oversplice that is installed at the same time as
the undersplices.
Figure 4F
Plank A Plank B

4. Recommended Method for Full Floor Installation
PNEG-222 48' Diameter Bin Cor-Lok and Cut-Lok Flooring 19
Installing the Undersplices and Oversplice for Small Grain
Floor Planks
1. Place plank ends together.
2. Place the undersplice (B) under the planks. Make sure the undersplice extends 3" across each plank.
3. Install the undersplice (B) to the planks using two (2) self-tapping screws (C) per splice to hold it in
place. (See Figure 4G.)
4. Place the oversplice (A) over the length of the plank splice seams.
5. Install the oversplice (A) to the planks and undersplices (B) using three self-tapping screws (C)
per each undersplice.
Figure 4G
Ref # Descritpion Ref # Descritpion
AFloor Oversplice (CLF-1763SG) EFloor Planks
B Undersplice (PCL-7049) F Splice Seam
CSelf-Tapping Screw GNOTE: Dashed lines indicate items under the oversplice.
D Side View HIsometricView

20 PNEG-222 48' Diameter Bin Cor-Lok and Cut-Lok Flooring
5. Grandstand Identification
20 Gauge Grandstand Identification
Figure 5A
20 Gauge
Plenum Clearance Grandstand Color Code
11-7/8" Blue
14-3/8" White
17-3/16" Yellow
