Powrmatic VPC Series User guide

www.powrmatic.co.uk [phone]
[email protected]
Doc Ref: M202 Issue 5.5 Aug 2018
Industrial & Commercial Heating Systems
VPC Gas Cabinet Heater Range
User, Installation
& Servicing Manual

page no. 2 of 40 VPC Range Users, Installation & Servicing Instructions Doc Ref M202 issue 5.5 Aug 2018.
Installer
Date:________________Signed: _____________________________________Installer
Commissioned
Date:________________Signed:_______________________Commissioning Engineer
Important: This certicate
must be kept with the appliance
Failure to provide a copy of the commissioning sheet invalidates the heater warranty
----------------------------------------------------
Powrmatic Ltd, Hort Bridge, Ilminster, Somerset, TA19 9PS
Tel: [phone] Fax: [phone]
Web: www.powrmatic.co.uk e-mail: [e-mail]
Certificate of Guarantee
Dear Customer
This is to certify that this heater is guaranteed for two years parts and one year labour from the date
of original commissioning. The heater must be commissioned within 4 weeks of installation.
To make a claim
In the first instance you must contact your appliance supplier, or installer and provide:-
1. The appliance type and serial number.
2. The original commissioning documentation. As much detail as possible on the fault.
3. Your supplier, or installer, will then contact Powrmatic to make a guarantee claim on your behalf.
Conditions of Guarantee
1. The heater must have been installed by a competent recognised installer, and in
accordance with the manufacturer’s instructions, building regulations and local regulations.
2. The heater has been professionally commissioned, within 4 weeks of installation, and a copy of
the commissioning sheet returned to Powrmatic.
3. The heater has been maintained on a yearly basis by a competent servicing company.
4. The heater has been used in accordance with the manufacturer’s instructions.
5. The correct specification fuel has been used.
6. No unauthorised repairs of modifications have been made. Powrmatic‘General Conditions of
Sales’have been observed.
7. Except for the obligation of Powrmatic Ltd to perform warranty repairs during the guarantee
period Powrmatic will not be liable in respect of any claim for direct or indirect consequential
losses, including loss of profits or increased cost arising from loss of use of the heater, or any
event arising there from.
Exclusions
Consumables such as gaskets, ignition electrodes, flame rectification electrodes, drive belts, fusible
links, control batteries are all excluded from guarantee.

page no. 3 of 40
VPC Range Users, Installation & Servicing Instructions Doc Ref M202 issue 5.5 Aug 2018.
Dear Customer - thank you for choosing Powrmatic.
We appreciate you buying one of our high quality products and know that you have made the best
choice. By choosing Powrmatic, you are investing in UK manufacturing & its workforce. We pride
ourselves by manufacturing products that provide clean, comfortable and safe working environments
worldwide together with the personal & professional service and back-up you deserve. If you have
any questions or concerns regarding this product, please contact our Technical Support Team by
calling 01460 53535.
Title Section Contents Page
User Instructions 4
Pre Installation
1.1 Introduction 5
Duties 6
Dimensions 7
Accessories 8
1.2 Technical data 9
1.3 General Requirements 11
1.4 Ventilation Air Requirements 13
Installation
2.1 Fitting the unit 14
2.2 Flue/Combustion Air Duct System 16
2.3 General Identification of Electrical Items 18
2.4 Electrical Cable Installation 19
2.5 Wiring Diagrams 20
2.6 Commissioning and Testing 26
2.7 Servicing 30
Additional Documents
3.1 Fault Finding Flow Chart 33
3.2 Short List of Parts 34
3.3 Gas Conversion 36
Appendices
Information required for ecodesign (ErP) Directive 2009/125 38
Users, Installation and Servicing Instructions
CONTENTS

page no. 4 of 40 VPC Range Users, Installation & Servicing Instructions Doc Ref M202 issue 5.5 Aug 2018.
D) Description of Operation
Important: The heater must NOT be
controlled by switching ON and OFF the
main electrical supply to it.
1) Standard Units
The ignition sequence commences each time the external
controls e.g. Time clock, room thermostat etc. call for
heat. The internal exhaust fan will run and, when sufficient
combustion airflow is proved by the air pressure switch, the
ignition spark will be generated, the main gas valve opens
and the burners light. The heater fan will automatically
start approximately 2 minutes after the burners light.
When the external controls are satisfied the burners will be
turned off and approximately 2 - 3 minutes later the heater
fan will be automatically stopped. If the burners fail to light
the control box will make another four attempts at ignition.
2) High / Lo & Modulating Units
When the burners are alight, the heat output will be
controlled either to high fire or low fire or, in the case of
modulating units, to any point between high and low fire;
depending on the requirements of the space being heated
and the controls system.
3) Summer / Winter Modes
Certain types of external controls will provide for two
modes of operation i.e.
Summer: The heater fan alone will run at the dictate of the
external controls to provide air movement.
Winter: The heater will operate normally.
4) Fan and Limit Control
The fan and limit controls are mounted towards the top of
the air heater inner bulkhead and are accessed via the front
door.
i) Main Air Fan MAN / Auto
When the white button is pushed in the fan will run
continuously i.e. not controlled by any external controls
e.g. Time clock. When the white button is pulled out the
fan will start and stop automatically in conjunction with
the burner.
ii) Limit Thermostat
This operates if high temperatures within the heater are
detected, the burners are turned off and a red indicator
light inside the heater is illuminated. The fault condition
must be identified and rectified and the thermostat
manually reset.
When the unit has cooled push the reset switch on the
front of the heater to reset the limit thermostat interlock
relay, the red indicator light will go out and the unit is
operational again.
If the heater has not been left operational
proceed as follows.
A) Checks before lighting the Air Heater
The following preliminary checks should be made before
lighting the heater(s)
a) Ensure that the ELECTRICAL supply to the heater is
switched OFF.
b) Check that all warm air delivery outlets are open.
c) Check that the thermostat is set at MAX.
d) Check that the clock control is set to an ON period.
e) Check that any other controls are calling for heat.
B) Lighting the Air Heater
1. Switch on the electrical supply at the isolator
2. If the Limit indicator light comes on press the limit
interlock reset switch inside the heater.
3. The startup sequence will commence. After a short
delay the burners will light.
4. If the burners fail to light the control box will
automatically restart the ignition sequence. If after 5
attempts at ignition the burners have still failed to light the
control box will go to lockout and the amber lockout light
inside the heater (or on the low level remote reset, MC200
or Powrtrol RR if fitted) will be illuminated. To restart the
ignition sequence depress the reset button on the low
level reset for about 1-2 seconds.
WARNING: If it is not possible to light the
heater after several attempts, contact the
installer or local service company.
C) To Shut Down the Air Heater
1) For Short Periods:
Turn the room thermostat to the OFF, or set to it’s lowest
setting.
2) For Long Periods:
Complete step 1 above. Wait for 5 minutes and then turn
OFF the electrical supply at the isolator.
User Instructions

page no. 5 of 40
VPC Range Users, Installation & Servicing Instructions Doc Ref M202 issue 5.5 Aug 2018.
Note: The limit thermostat(s) can only be reset
once the unit has cooled down.
Unless the cause of the fault condition is
readily obvious, for example a power cut whilst
the heater was operating, a service engineer should be
contacted.
E) Maintenance
To maintain efficient, reliable and safe operation of the
heater it must serviced by a qualified person at least
annually and preferably at the end of the heating season.
IMPORTANT
Free access must be maintained to and around
the heater for servicing purposes and the air
supply to the heater must not be restricted
in any way. Combustible materials must not be stored
adjacent to the heater.
If at any time a gas leak is suspected, turn OFF the gas
supply at the meter and contact the local gas undertaking
immediately.
All Powrmatic heaters use gas and electricity
to power them, they may also contain moving
parts such as pulleys and belts. It would be
hazardous to tamper with or attempt to
service unless you are a competent person in the field of
Gas and Electrical work.
If you have any safety questions reference the servicing
and installation of any of our heaters please do not hesitate
to contact our head office for expert advice. Your safety is
paramount to us.
Gas Safety (Installation & Use) (Amendment)
Regulations
It is law that all gas appliances are
installed, adjusted and, if necessary,
converted by qualied persons* in
accordance with the current issue of the
above regulations. Failure to install appliances
correctly can lead to prosecution. It is in your own
interests and that of safety to ensure that the law is
complied with.
* An approved class of person listed on the gas safe
register.
The VPC range are highly efficient gas fired, fanned
circulation floor standing air heaters that cover heat
outputs of 30kW to 130kW. The units have a single closed
flue system that can be either vertical or horizontal and
feature a single burner assembly which as standard is ON/
OFF but can also be supplied in High/Low or Modulating
formats. High/Low or Modulating formats give a turn down
facility of approximately 2:1. The heaters are certified for
use on Natural Gas, Group H - G20, and Propane - G31 only.
Appliance Categories are Cat II2H3P (GB, IE).
The heaters intended primarily for heating commercial
or industrial premises. They must not be used where the
atmosphere inside the premises could be contaminated
e.g. Dust, oil mist etc. or in areas classified as hazardous as
defined in BS 5345: Part 2. They are not suitable for siting
externally.
VPC heaters feature a closed combustion circuit and have
an internal exhaust fan, mounted downstream of the
heat exchanger, to evacuate the products of combustion
and draw in air for combustion. The air heater must be
connected to a flue system that is approved by Powrmatic
Ltd.
They may be used where the atmosphere inside the
premises could be contaminated e.g. Dust, oil mist etc. but
the heaters are not airtight and therefore may not be used
in areas classified as hazardous as defined in BS 5345: Part 2
or areas subjected to significant negative pressures due to
extract systems.
VPC heaters have a centrifugal fan assembly fitted at the
base of the heater to circulate the air being heated past the
formed tube heat exchanger.
Heaters are fitted as standard with inshot burners, a fully
automatic control for ignition, flame sensing, gas supply
control and safety functions, an internal exhaust fan, main
air fan and fan/limit thermostat.
Options include High/Low or Modulating burner controls,
inlet duct connection, outlet duct connection, 90° outlet
bend and a full range of modular duct components.
IMPORTANT
Service and Maintenance Engineers shall
ensure that replacement items are tted,
adjusted and set in accordance with the
data and detail set out in these instructions. If in doubt
consult Powrmatic Technical Department.
Gas Safety (Installation & Use) Regulations 1998
It is law that all gas appliances are
installed, adjusted and, if necessary,
converted by qualied persons* in
accordance with the current issue of the
above regulations. Failure to install appliances
correctly can lead to prosecution. It is in your own
interests and that of safety to ensure that the law is
complied with.
* An approved class of person listed on the gas safe
register.
1.1 Introduction

page no. 6 of 40 VPC Range Users, Installation & Servicing Instructions Doc Ref M202 issue 5.5 Aug 2018.
Model 30 52 80 110 130
Output kW 30 52 80 110 130
Input (nett CV) kW 32.6 56.5 87.0 119.5 141.3
Volume m3/s 0.87 1.59 2.34 2.96 3.63
Airflow
Heads m 3 3 4 4 4
Throw m 12.0 22.0 21.0 26.0 27.0
Fan
Static
Standard Pa 150 200 225 150 200
Uprated (Refer to Powrmatic)
Electrics
Supply Standard V/ph/Hz 230/1/50
Optional V/ph/Hz n/a 400/3/50
Std
Fan
Motor kW 0.55 1.1 1.4 1 x 1.5 1 x 2.2
Start amp 6.5 8.3 19 28 40
Run amp 4.2 4.2 9.5 9.3 10.7
Fuel
Connection BSP/Rc ¾”
Minimum Inlet
Pressure
Nat Gas mbar 17.5
LPG mbar 37.0
Consumption Nat Gas m3/h 3.45 5.98 9.19 12.64 14.94
LPG m3/h 1.33 2.31 3.55 4.89 5.78
Overall
Dims
UF Upright
Freeblow
Height mm 2272 2713 2804 2715 2998
Width mm 750 750 750 750 750
Depth mm 1108 1108 1412 1767 1767
Install
Clearance
UF Upright
Freeblow
Front mm 1000
Blank mm 150
Louvred mm 500
Read mm 500
Flue
Diameter mm Ø 100 130
Max
Length
Flue Only m 12
Room Sealed m 6
Combustion Air Spigot mm Ø 100 130
Noise Levels dB(A) 60 68 76 72 74
Nett Weight kg 178 248 305 362 410
Notes -
• Fuel consumption and output figures based upon nett calorific values as follows
-Natural gas (G20) nett CV 34.02 MJ/m³
-Propane (G31) nett CV 88.00 MJ/m³
• Heaters have efficiency levels which meet with the minimum heater efficiency requirements of UK Part L Building Regulations
• Air handling data is assessed at room ambient conditions
• Throw figures provide the distance to the point where the terminal velocity degrades to 0.25 m/s
• Overall vertical heater height include heads or extended heads where appropriate
• Standard height heads can be specified where site height is restricted
• Blank and louvred lower side panels are interchangeable
• Noise levels are applicable to standard UF models and are measured 5m from appliance and in free field conditions
• Motor kW, run and start amps apply to standard electrical supply as stated. For optional data contact sales office
• Connection of combustion air duct is not required for ‘flue only’ applications
• It is the responsibility of the installing contractor to ensure that ductwork is correctly sized and balanced when installing ducted units
VPC UF / VPC UD
Duties

page no. 7 of 40
VPC Range Users, Installation & Servicing Instructions Doc Ref M202 issue 5.5 Aug 2018.
Model A B C D E F G H J J1 K L M Head
Plan
30 1108 750 1676 100 265 1378 142 237 255 596 207 657 650 2
52 1108 750 2132 100 265 1832 142 237 286 581 256 657 650 2
80 1412 750 2132 130 265 1756 220 237 340 672 308 960 650 3
110 1767 750 2043 130 265 1667 220 237 340 672 308 1315 650 4
130 1767 750 2209 130 265 1835 220 237 400 788 358 1315 650 3
G
H
50
G
H
Ø D
GAS ENTRY
COMBUSTION
AIR INLET
EXHAUST
AIR OUTLET
ALTERNATIVE FLUE
& COMBUSTION AIR
POSITIONS
J 1
JJ
J 1
K
BAB
C
M
E
L
L
M
M
F
Dimensions

page no. 8 of 40 VPC Range Users, Installation & Servicing Instructions Doc Ref M202 issue 5.5 Aug 2018.
650
750
760
660 760
660
136 SIDE REAR
N
L
136
185 SIDE REAR
760
660
N
L
185
760
660
650
750
660
650
L
660
50
50
SIDE REAR
Side/Rear Inlet Spigot Side/Rear Filters
Model 30 52 80 110 130
L 657 960 1315
N 757 1060 1415
Side/Rear Dampers
Head Plan 2 Head Plan 3Head Plan 1
Notes -
• All dimensions are outside dimensions
• Vertical units shown.
• Standard filter specification is 10ppi
• Higher specification filters available on request - contact our sales team for more information
• Standard dampers are manual operation - motorised options available
Head Plans
Accessories

page no. 9 of 40
VPC Range Users, Installation & Servicing Instructions Doc Ref M202 issue 5.5 Aug 2018.
High Fire Low Fire
Injectors Burner
Pressure Gas Rate Nominal
CO
Nett Flue
Temp Burner
Pressure Gas Rate Nominal
CO
Nett Flue
Temp
MODEL No. Size (mm) Marked mbar m/h %°C mbar m/h %°C
VPC30 61.94 194 13.8 3.45 8.6 171 4.6 1.90 3.7 125
VPC52 12 1.94 194 10.4 5.98 8.2 172 3.0 3.22 3.1 117
VPC80 12 2.54 254 8.1 9.19 8.0 146 2.1 4.44 2.7 91
VPC110 10 3.00 300 10.2 12.64 9.0 180 3.2 6.50 3.2 114
VPC130 12 3.00 300 10.0 14.94 7.2 180 3.6 8.26 3.4 113
Injector Sizes & Burner Pressures - Natural Gas - Group H - G20 Net CV (Hi = 34.02MJ/m³).
Minimum Inlet Pressure = 17.5mbar
High Fire Low Fire
Injectors Burner
Pressure Gas Rate Nominal
CO
Nett Flue
Temp Burner
Pressure Gas Rate Nominal
CO
Nett Flue
Temp
MODEL No. Size (mm) Marked mbar m/h %°C mbar m/h %°C
VPC30 61.36 136 21.7 1.33 11.0 170 7.0 0.74 4.6 125
VPC52 12 1.25 125 27.0 2.31 8.9 170 8.0 1.24 4.0 118
VPC80 12 1.55 155 24.1 3.55 9.4 151 6.0 1.72 3.4 99
VPC110 10 1.94 194 26.5 4.89 10.4 192 7.0 2.51 4.0 121
VPC130 12 1.94 194 25.0 5.78 9.0 181 7.9 3.19 3.6 114
Injector Sizes & Burner Pressures - Propane G31 Net CV (Hi = 88.00MJ/m³).
Minimum Inlet Pressure = 37mbar
MODEL Electrical
Supply Motor kW Nominal Motor R.P.M. Max Fan Amps (A) Start Amps (A) Run Amps (A) Fuse Rating (A)
VPC30 230V 1N 0.55 940 4.3 6.5 4.4 7
VPC52 230V 1N 1.1 940 4.2 8.3 4.5 7
VPC80 230V 1N 1.4 940 10.0 19.0 9.4 15
VPC110 230V 1N 1.5 1500 6.7 28.0 9.3 15
VPC130 230V 1N 2.2 1500 9.4 40.0 10.7 15
VPC110 400V 3N 1.5 1500 3.5 17. 5 3.4 5
VPC130 400V 3N 2.2 1500 4.8 25.1 4.5 7
High Fire Low Fire
Air Volume Maximum Duct
Resistance
Fan
Motor Noise Level Weight
Input
(Nett) Output Input (Nett) Output
MODEL kW kW m/s m/h Pa kW dB(A) kg
VPC30 32.6 30 18.0 15.7 0.8664 3119 150 0.55 68 178
VPC52 56.5 52 30.4 26.1 1.5884 5718 200 1.10 68 248
VPC80 87.0 80 42.0 36.8 2.3372 8414 225 1.40 76 305
VPC110 119. 5 110 61.5 53.3 2.9568 10645 150 1.50 72 362
VPC130 141.3 130 78.1 69.0 3.6288 13064 200 2.20 74 410
Electrical Loadings - 1Pha
Heater Specications
1.2 Technical Data

page no. 10 of 40 VPC Range Users, Installation & Servicing Instructions Doc Ref M202 issue 5.5 Aug 2018.
Motor (a) Motor Pulley (b) Motor Pulley
TaperLock (c) Centrifugal Fan (d)
kW Pha RPM Pt no. Size Pt no. Size Pt no.
type
Size Pt no.
VPC30 0.55 1940 n/a n/a n/a n/a n/a 1321 x 321 1402CFAN280/T/15
VPC52 1.1 1940 n/a n/a n/a n/a n/a 1321 x 321 1402CFAN210/T/15
VPC80 1.4 1940 n/a n/a n/a n/a n/a 1381 x 381 1402CFAN580/T/15
VPC110 1.5 11500 140001908 95x1SPA 142000602 1210-24 142003350 2321 x 321 1402CFAN240/T/2DECK
VPC130 2.2 11500 140001998 100x1SPA 142000601 1610-28 142161028 2321 x 321 1402CFAN240/T/2DECK
VPC110 1.5 31500 140001915 95x1SPA 142000602 1210-24 142003350 2321 x 321 1402CFAN240/T/2DECK
VPC130 2.2 31500 140002000 100x1SPA 142000601 1610-28 142161028 2321 x 321 1402CFAN240/T/2DECK
Drive Data - Standard Motor
Fan Pulley (e) Fan Pulley
TaperLock (f) Belt(s) (g) Contactor/Relay Overload
Size Pt no. Size Pt no. Size Pt no. Type Pt no. Type Pt no.
n/a n/a n/a n/a n/a n/a 5.5kW AC3 143000601 7-11A 143000801 VPC30
n/a n/a n/a n/a n/a n/a 5.5kW AC3 143000601 7-11A 143000801 VPC52
n/a n/a n/a n/a n/a n/a 7.5kW AC3 143000600 7-11A 143000801 VPC80
170x1SPA 142001689 1610-25 142003370 A990/38 142109801 7.5kW AC3 143000600 7-11A 143000801 VPC110
180x1SPA 142001675 1610-25 142003370 A1050/40 142110507 7.5kW AC3 143000600 12-18A 142000800 VPC130
160x1SPA 142001619 1610-25 142003370 A990/38 142109801 7.5kW AC3 143000600 7-11A 143000801 VPC110
180x1SPA 142001675 1610-25 142003370 A1050/40 142110507 7.5kW AC3 143000600 5-8A 142000802 VPC130
a
b
c
d
e
f
g
Fan type 2Fan type 1
