The following items aresupplied with theprojector andplease check:
Name
Quantity
Unit
Remark
Safetycord
1
Pc
Clamp
2
Pc
Foldableclamp
2
Pc
Optional
User manual
0
Pc
QRcode
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change
without notice. Whilst every care is taken in the preparation of the manual we reserve the right to change specifications in the
course of product improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any
consequence arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in
good condition before installation and use. Should there be any damage caused by transportation, consult your dealer and do not
use the unit. Any damage caused by improper use will not be assumed by the manufacturer and / or dealer.
Any future technical change in the user manual won’t be with any notice.
Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the
delivery date but the light source is not within the warranty

3
1. SAFETYANDWARNINGS
NOTE
Before a projector’s installation, power-on, operation and maintenance, please carefully read
thesafety informationhereinafter!
Thefollowingsafetysignsareusedintheusermanual.
Warning
User
Manual
Electrical
shock
Goggles
Protective
Gloves
Flames
High
Temperature
● When unpacking , check if there is transportation damage before using the projector. Should there be any
damage caused by transportation,consult your dealeranddonot useit.
●The manufacture is not responsible for loss caused by the user not following the manual or changing the
projectorashe/shelikes
●Pleasebenotedthatthedamagecausedbychangingtheprojectoratwill isnotwarranted.
● Do not hesitate to contact thedealeror the manufacturer if anyquestions or advice.
●Ifalampisdamagedordeformsbecauseofheat,itshouldbe replaced.
● Theprojectorisforindoor useonly,IP20.
● Use onlyin drylocations. Keep this unit awayfromrainand moisture, excessive heat, humidity anddust. Do not
allowcontactwithwater oranyother liquids.
●The projector should be kept away from hightemperature, fire, electrical surge, vibration and strong light while
beingoperated
●The projector is only intended for installation, operation and maintenance by qualified personnel. And the
operationmuststrictlyfollowtheproceduresinthemanual
●Norepairable partsintheprojectorand do notopencoversformaintenancebyyourself.
●Don’t look straightly into the lightsourcesespeciallyforepileptics, otherwiseeyeswillbeburned.
●Donotconnecta projectortoanytypeofdimmerpack.
●Ifthelamp,lensandscreenprotective cover oftheaprojectorhaveobviousdamage,i.e.,totheextentthatit
hurtstheperformancelikecrackingordeformation.Please stopusingitandreplace them withtheoriginalparts,
otherwise itsperformancewillbe compromised.
●For the installation location of a projector, it shouldn’t be seen in the distance of less than 4 metersforalong
time.
●Before operation, please confirm that all covers(housing) are on and screws tightened. It’s forbidden to use a
projectorwhilecovers(housing)areoff
●Keepthelampcleananddo not touchit withbarehands.
●Whileoperatingit,wearprotectiveitems.

4
●Anyelectricalconnectionmustbecarriedoutbyaqualifiedperson.
●Beforeinstallation,pleaseconfirmthevoltagesupplied matcheswhatisrequired forthe projector
●Eachprojectormustbeproperlyearthedandinstalledasperrelatedelectrical standards.
●Donotusepower cord withitsinsulatordamagedand connectthepowercord withother cables.
●If the projector is not used or under cleaning,, please hold the plug and unplug it. Do not unplug it forcefully or
bypullingthepowercable.
●Allpowercordsmust conform to relatedsafetyandregulations
●Whilebeingoperated,theprojectorshouldnotbeunderrainsor inhumidity.
●Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other
electrical parts’ life will be shortened .
●There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety cord
supplied throughthesafetycordholesfor safetysupport.
●Before any installation, maintenance and cleaning work, please ensure the projector is disconnected frompower
mains.
●.Afterstableoperationundernormalsituation, its temperatureis80℃.
●While the lamp is stricken for the first time, there will be smoke and strange smell. It’s normal and does not
mean theprojectorhassomedefects.
●While it running, don’t touch the metal housing to avoid being burned!
●Donotmounttheprojectordirectlyoninflammablesurface.
●Do not project the beam straightly on combustible items and the minimum distance between the projector and
illuminateditemsis8m.
●Aprojectorshould be installed with good ventilation and the minimum distance between the projector and walls
is50cm.Atthesametime,pleaseensurethefansandairinletsandoutletsareworkable.
●Donotletthefrontlensundersunlightorotherstronglightsourcesatanyangle,otherwisethedanger
offirecanbecaused bythe focused beambythelensinsideaprojector.
●TheproductmeetsTheGeneralTechnicalRequirementsandStandardsforRecycleand UseOfExpired
ApplianceandElectronic Products.
●Whentheproductmeets disposal standardsand needs tobedisposed,aclient needstodisposeandrecycle it.
2. INSTRUCTIONS
●CLEANINGANDMAINTENANCE
Keeping a projector is necessary and thedust, oil and smoke should not accumulate onor in it, otherwise its light output will be greatly
compromised. Regularcleaningwill ensure light output at maximum and reliable running duringits wholelife span. It’s advised to use
softcloth with good qualitydetergent.Under whatever circumstances,itshouldnot usealcoholorother solvent.
Forthe accumulationofoiland smoke onthe front lens, thussharpdecrease in light output, the front lensshouldbe cleaned once every
week. Cooling fans cleaned once every month. Internal items inside the projector should be cleaned once every year using vacuum or
blower.Colorfilters,rotators andinternalmirrorsshould becleanedonceevery month.
Regular inspection of air filters and clean them before they fully blocked. Clean air filters at the bottom of the base. Please vacuum or
compressedairtocleanandputthembackaftercleaning.
●Beforeanymaintenanceandcleaning,please ensuretheprojectisoff thepower
●Onlyqualifiedpersonisallowedtodomaintenance
●During maintenanceandbefore maintenance, theprojectormustbeoffpower.
●To avoid internal damage, sun light or other light mustn’t penetrate into the projector via front lens whether it runs
ornot
●Donotusealcoholorotherorganic solvent tocleanthehousingtoavoiddamag
●Donotuseanysolventwithchemicalelementstocleancolor filtersor hotmirror.
.Hotmirrorshouldbecleanedevery3 daysandcoated with

5
●LUBRICATION
To ensure smooth movement of gobos and zoom and focus lens, it’s advised rotators’ bearings and 2 sliding bars for zoom and focus
lensbelubricated every2 months.Highqualityandhightemperaturelubricant/grease is advised..
●TROUBLESHOOTING
PROBLEM
ACTION
The projector doesn’t switch on
Checkthe fuseonthepower socket.
Checkthelamp.
Thelampisonbuttheprojectordoesn’t respond
to thecontroller
Makesurethatthe fixture’s start address is right
ReplaceorrepairtheXLRsignalcable.
Theprojector functions intermittently
Makesurethefanisworkingwellorfansandtheirshieldsarenotblocked
Beamappearsdim, Lowinbrightness
Make sure the lamp is withinitslifespan
Removedustor grease fromthelenses.
Theprojectimageappearstohavea halo
Carefullycleanthelamp,opticallensesandothercomponents.
HeavilyDefectiveBeam
Checkif lensareingoodcondition(notcracked)
Cleandustorgreaseonthelens.
3. APPEARANCE
4. INSTALLATION
Aprojector can be placed on the stage floordirectlyor mounted on a truss at any direction without impacting itsperformance. Please
use a safety cord, which can support 10 times the weight of the projector, while mounting it on the truss. The safety cord should be
used with magazine witha lock. Just as the figuresbelow, please run the safety cord through the holes at the bottomof the base and
aroundthetruss.
● RIGGING
1. Use M12 bolt to fix the clamp(1) into the omega holder (3), run the bolt through the holder’s holes
2. Push2quick-lockfasteners(4) intoholesatthebottomofthebase,fixthemandtighten themclockwise
3.Run safetycord(2) throughholes at thebottomofthebase and aroundthetruss(6)
Head
Arm
Base

6
Usethespanner suppliedwitha projectorto help installation.
WARNING:
●TheprojectorMUSTbeliftedorcarriedbytheHANDLESinsteadofclamps.
●.For safety the safety cord should afford 10 times the Projector’s weight.

7
It must use secondary safety accessory like appropriate net. The structures of the secondary accessory must ensure that while
malfunction happens, the installed parts won’t fall to the ground.
While rigging, mounting or maintaining, theprojector mustn’t be placed in the areas listed hereinafter: the bridge, high work areas
or otherdangerous areas.
Theoperatorof the projector orits related safety items must be accepted by safetyexperts before first launching or re-running after
anyreplacementsorrepairing.
The operator must ensure a test before acceptance every 4 years and the related safety measures and installation accepted by
experts.
The operator must ensure the related safety measures and its installation must be approved by the technicians every year. The
projector may be installed in places under which people may walk by or sit. Important! Installations in high places requires wide
experience, including but not limited to load limit calculation, the installing materials needed and regular inspection of installing
materials and the projectors. If lacking the qualifications, please don’t try installation by yourself, but seek help from professionals
using designated liftinggears.Abnormal installationmaycausebodyharmorpropertydamages.
The projectors must be installed in places where people can’t reach. If they are removed from ceiling or high places, professional
truss mustbe used.Itisforbiddentoletanyprojector movefreelyinaroomafterinstallation.
Note: Device falling down can cause heavy body harm! If you have any questions about its safety, don’t install any projector!
Beforeinstallation, please ensuremounting areascan endure 10times the weightof aproject atleast.
●POWERCONNECTION
Connectthepowercordasfollows:
L(live)=brown
E(earth)=yellow/green
N(neutral) =blue
Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each
projectorbeconnectedwithpower separatelyso that they maybeindividually switched onandoff.
●The earth wire(yellow/green)mustbe connected to the ground. And electrical connection
mustbeinaccordancewiththestandardsconcerned.
●If any questions about the electrical installation, do not continue but consult a qualified
electrician.
●DMXCONTROLCONNECTION
Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each
wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector)
or5pin XLR plugsand sockets.The XLR's are connectedasshown in the figure above.
Note: care should be takento ensure that none ofthe pinstouch the metallic bodyof the plug or eachother. XLR plugs and sockets mustn’t
be connected in any way other than mentioned in the above figure. The XR330BWS accepts digital control signals in protocol DMX512
(1990).
Connect the controller’s DMX output to the first fixture’s DMX input, and connect the first fixture’s DMX output to the second fixture’s
DMX input and connect the rest fixtures in the same way. Eventually connect the last fixture’s DMX output to a DMX terminator asshown
inthefigurebelow.

8
●DMXTERMINATOR
In the Controller mode, atthe last fixture in the chain, the DMX output hasto be connected witha DMXterminator. This prevents electrical
noisefromdisturbingandcorruptingtheDMXcontrolsignals.
The DMX terminator is simply an XLR connector with a 120(ohm) resistor connected across pins 2 and 3, which is then plugged into
theoutputsocketonthelastprojectorinthechain.Theconnectionsareillustratedbelow.
● ALIGNMENT/INSTALLATION/REPLACEMENTOFALAMP
1. Loosen and remove screws B,C and D .Loosen screw A which can only be loosened but can’t be removed, for details please see the
figureontheright.Thenthelamp anditssupporting framescanbe seen.
2. Loosen screws E and F and push the lamp supporting frames downward to expose the lamp’s side, and remove the lamp after
pushingit downward. After unplugging the lamp, remove it. Plug a newlamp with lamp wires after it is in place, push the supporting
frames upward and tighten the screws to fix the new lamp. Tighten the screws after the lamp chamber cover is on. At last restore the
projector’s originalappearancebasedonthe opposite sequencesofdismantling.
DMX512 OUTPUT INPUT DMX
terminator
OFF
ON
FUSE 250V 8A
POWER IN POW ER OUT DMX IN DMX OUT
OFF
ON
FUSE 250V 8A
POWER IN POWER OUT DMX IN DMX OUT
OFF
ON
FUSE 250V 8A
POWER IN POW ER OUT DMX IN DMX OUT
OUTPUT INPUT
21
3
120
DMX TERMINATOR
CONNECTION
Connect a 120 (OHM) resistor
across pins 2 and 3 in an XLR plug
and insert into the DMX out socket
on the last unit in the chain. PIN 3
PIN 2
A B
C
D
E
F

9
5. SETUPAND CONFIGURATION
●FRONT PANEL OPERATION
To browse through or view a projector’s function settings, push any key to activate the screen after power-on.. After screen
unlocked, push both key and to enter into menus. Each main menu has its sub-menus with different special functions, for
detailspleasesee the5th pointhereinafterOPERATION MENU.
1、Under menupageforfunctionsettings，push or toselectfunctiondesired.
2、During menuoperation ，keyis toescape，keymeansENTER，push keytosavesettingsorenter into
submenus，push or keyto changevalues（plusorminus）.
Push keytogo backtouppermenu.Ifnot,thescreen willgoback toinitialdisplayautomatically.
●DMXSTARTADDRESS
Pushanykeytoenter into options interface.
If multiple projectors are controlled by DMXcontroller, each projector must have its own DMXaddressto receive DMX signals fromthe
controller and respond to them. The projector has 2 DMX modes. There are short mode and standard mode. For example standard mode
has 16 channels, so set the No. 1 projector’s address 001, No. 2 projector’s address 017, No. 3 projector’s address 033, No. 4 projector’s
address49 and soon.
Turnona projectorandpushanykey toenterinto options interface
SelectCHANNELMODEiconandpushENTER key .SelectDMXADRESSin2nd level menu tosetstartaddress
PushkeyUP orDOWN tosetvaluedesired.
PushENTERkey toconfirmit.
PushESCAPEkey toenter intoupper level menus.
●STAND-ALONEMODE
Without connecting a projector with a controller via XLR cable, after preset memories under the master mode enabled, it
will run in Stand-Alone mode.
●MASTER/SLAVEMODE
(1)Editthescenedesired
Two ways toeditscene
a. Editmanually
Disconnect a projector from XLR cable and enter into scene editing via control panel. Ascene has 20 steps and select any step via its
sequence No.. Enter into channel control to edit its data. After disconnected from a DMX controller, a projector will respond to data
edited simultaneously.
b. Editwithhelpofa DMXcontroller
Use a DMX controller to control a projector. After the projector is controlled properly in positions, select the sequence No. ofstep to
besavedandclickto storeDMXvalues.
Current DMX data will be automatically saved to its scene’s data and the sequence NO. added 1. And so on, it can save 20-stepscene.
(2) Selectusemodefromscene menu.There are2 modesforselection: single andrecycle.If not used,itcan be closed.

10
6. OPERATIONMENU
Menu interface:1. DMXaddress 2. Config3. Manual control 4. Scene5. Systemsettings 6. Information
1) Explanationsformenu functions.Push anykeytoenterintooptioninterfacewhileatinitial display
Main menu
1st levelmenu
2nd levelmenu
Description
DMX
address
DMXSetting
001-512
Select “DMX address”option
1）AfterENTERkeypushed，thecurrentDMXaddresswill
be shown
2）PushUPorDOWNkeytosetaddress
3）PushENTERkeytosave andexit.PushESCAPEkeyto
exitdirectly
Config
Channel mode
14CH
ShortMode
Select ”Channel mode” option
1）AfterENTER keypushed,currentchannelmodewillbe
shown(16CHforstandardmode,14CH for shortmode)
2）PushUPorDOWNkeytoselecteitheroftheoptions；
3）PushENTERkeytosave the modeselected.PUSH
ESCAPEkeytogobacktotheupperlevelmenu and
cancelthemode selected
16CH
Standardmode
LampStriking
Auto lamp-on
Select “Lamp Striking”Option
1）PushENTERkeytoshowcurrentmode(Autolamp-on,
lamp-on byDMXcontrol).
2）PushUPorDOWNkeytoselecteitheroftheoptions.
3）Push ENTER key to save the mode selected. PUSH
ESCAPE key to go back to the upper level menu and cancel
the mode selected
Lamp-on byDMXcontrol
Pan&Tilt
Pan Invert
Select“Pan and Tilt Invert”option
1）Push ENTER key and the options will be shown on the
display（OpenorClose）
2）PushUPorDOWNkeytoselecteitheroftheoptions.
3）Push ENTER key to save the selected. PUSH ESCAPE
keyto cancelthesetting.
TiltInvert
PanandTiltswap
Select“Pan and Tilt Swap”option
1）Push ENTER key and the options will be shown on the
MASTER SLAVE SLAVE
OFF
ON
FUSE 250V 8A
POWER IN POWER OUT DMX IN DMX OUT
OFF
ON
FUSE 250V 8A
POWER IN POWER OUT DMX IN DMX OUT
OFF
ON
FUSE 250V 8A
POWER IN POWER OUT DMX IN DMX OUT
OUTPUT INPUT OUTPUT INPUT
DMX
terminator

11
display（OpenorClose）
2）PushUPorDOWNkeytoselecteitheroftheoptions.3）
Push ENTER keyto save the selected. PUSH ESCAPE key
tocancelthesetting.
Channel
calibration
（Hidden ）
PushbothUPandDOWN keystoenter intothemenu，
pushDOWNor UPkeyto select,pushENTER keytosave.
Lampcontrol
Open
Select“Lamp Control”option
1）PushENTERkeyand theoptionswillbeshownonthe
display（OpenorClose）
2）PushUPorDOWNkeytoselecteitheroftheoptions.
3）Push ENTER key to save the selected. PUSH ESCAPE
keytocancelthesetting.
Close
Manual
control
Lamppower
Fullpower
Select“Lamp power”option
1）PushENTERkeyand theoptionswillbeshownonthe
display（Fullorhalfpower）
2）PushUPorDOWNkeytoselecteitheroftheoptions.
3）PushENTERkeytosavethe selected.PUSHESCAPE
keyto cancelthesetting.
Halfpower
Systemreset
Headreset
Select“System reset”option
1）PushENTERkeyand the resetoptionswillbeshownon
thedisplay（Headreset,panandtiltresetand totalreset）
2）PushUPorDOWNkeytoselectanyof the options.
3）PushENTERkeytosavethe selected.PUSHESCAPE
keytocancelthesetting.
PanandTiltreset
Totalreset
Scene
Mode
Close
Select“Mode”option
1）PushENTERkeyand theoptionswillbeshownonthe
display（Close, singleand cycle）
2）PushUPorDOWNkeytoselectanyof the options.
3）PushENTERkeytosave the selected.PUSH ESCAPE
keytocancelthesetting.
Single
Cycle
Select“Scene”options
1）PushENTERkeyand theoptionswillbeshownonthe
display（No.,Effectiveandtime）
2）PushUPorDOWNkeytoselectanyof the options.
3）PushENTERkeytosavethe selected.PUSHESCAPE
keytocancelthesetting.
Sequence No
1-20
Effective
Yes
No
Time
3.0
Save DMX
value
Yes
Cancel
Channel
control
DMXChannel
Select“Channel control”options
1）PushENTERkeyand the optionwillbeshownonthe
display（allDMXchannels）
2）PushUPorDOWNkeytoenterinto anyofthe
options(adjustablebetween0and 255).
3）Push ENTER key to save the selected. PUSH ESCAPE

12
keyto cancelthesetting.
System
settings
Languages
Chinese
Select“Language”options
1）PushUPorDOWNkeytoselecteitheroftheoptions.
2）PushENTERkeytosave the selected.PUSH ESCAPE
keyto cancelthesetting.
English
Display
Normal
Select“Display”options
1）Push ENTERkeyand the waythescreendisplayed will
be shown
2）PushUPorDOWNkeytoselecteitheroftheoptions.
3）PushENTERkeytosave the selected.PUSH ESCAPE
keyto cancelthesetting.
Invert
Backlight
Auto
Select“Backlight”options
1）PushUPorDOWNkeytoselecteitherofthe options.
2）PushENTERkeytosave the selected.PUSH ESCAPE
keyto cancelthesetting.
On
Factorysettings
Yes
Select“Factory settings”options
1）PushUPorDOWNkeytoselecteitheroftheoptions.
2）PushENTERkeytosave the selected.PUSH ESCAPE
keyto cancelthesetting.
Cancel
Information
1. Totalhours （H）
2. Lamptime（min）
3. TheNo.Lamp
replacements
4. replace Lamp
5. Fanvoltage
6. Errormessages
7. About
Select“Information”options
1）PushENTERkeyand theinformationwillbeshown
2）PushUPorDOWNkeytoselectanyof the options.
3）PushENTERkeytosave the selected.PUSH ESCAPE
keyto cancelthesetting.
7. DMX PROTOCOL
PR-9604 Beamlight DMX chart
DMX channel
Value
Function
Short Mode
Standard
Mode
1
1
Pan
0-255
0-100%
2
Pan Fine
0-255
0-100%
2
3
Tilt
0-255
0-100%
4
Tilt Fine
0-255
0-100%
3
5
Pan andTilt speed
0-255
Fast->Slow

13
4
6
Strobe
0-3
Close
4-103
Strobe:Slow->Fast
104-107
Open
108-207
Pulse strobe:Slow->Fast
208-212
Open
213-225
Strobeatrandom:slowspeed
226-238
Strobeatrandom:mediumspeed
239-251
Strobeatrandom:fastspeed
252-255
Open
5
7
Dimmer
0-255
0-100%
6
8
Colors
0-4
Open
5-8
Open+ Color1
9-12
Color1
13-17
Color1+Color2
18-21
Color2
22-25
Color2+Color3
26-29
Color3
30-34
Color3+ Color4
35-38
Color4
39-42
Color4+ Color5
43-46
Color5
47-51
Color5+ Color6
52-55
Color6
56-59
Color6+Color7
60-63
Color7
64-68
Color7+ Color8
69-72
Color8
73-76
Color8+ Color9
77-81
Color9
82-85
Color9+ Color10
86-89
Color10
90-93
Color10+Color11
94-98
Color11
99-102
Color11+Color12
103-106
Color12
107-110
Color12+Color13
111-115
Color13
116-119
Color13+Color14
120-123
Color14
124-127
Color14+Open
128-255
Rotation:slow->fast

14
7
9
Fixed gobowheel
0-3
Open
4-7
GOBO1
8-11
GOBO2
12-15
GOBO3
16-19
GOBO4
20-23
GOBO5
24-27
GOBO6
28-31
GOBO7
32-35
GOBO8
36-39
GOBO9
40-43
GOBO10
44-47
GOBO11
48-51
GOBO12
52-55
GOBO13
56-59
GOBO14
60-63
GOBO15
64-67
GOBO16
68-71
GOBO17
72-78
GOBO1 SHAKE:Slow->Fast
79-85
GOBO2 SHAKE:Slow->Fast
86-92
GOBO3 SHAKE:Slow->Fast
93-99
GOBO4 SHAKE:Slow->Fast
100-106
GOBO5 SHAKE:Slow->Fast
107-113
GOBO6 SHAKE:Slow->Fast
114-120
GOBO7 SHAKE:Slow->Fast
121-127
GOBO8 SHAKE:Slow->Fast
128-134
GOBO9 SHAKE:Slow->Fast
135-141
GOBO10SHAKE:Slow->Fast
142-148
GOBO11SHAKE:Slow->Fast
149-155
GOBO12SHAKE:Slow->Fast
156-162
GOBO13SHAKE:Slow->Fast
163-169
GOBO14SHAKE:Slow->Fast
170-176
GOBO15SHAKE:Slow->Fast
177-183
GOBO16SHAKE:Slow->Fast
184-190
GOBO17SHAKE:Slow->Fast
191-222
Clockwiserotation:Fast->Slow
223-255
Anti-clockwiserotation:slow->fast
8
10
Prism1
0-63
Open
64-255
Prism 1in
9
11
16facet prism rotation
Prism2
0-63
Open

15
8. ERRORMESSAGE
Name
Type
Correction
Pan
Optical sensorerror:Pan
Checkifwiring, optical sensor and motorsare normal
Tilt
Optical sensor error:Tilt
Checkifwiring, optical sensor and motorsare normal
Pan&Tilt driverboard
Communicationerror:module1
Checkifwiring, hall sensorandmotorsarenormal
Motordriverboard
Communicationerror:module2
Checkifwiring, hallsensorandmotorsarenormal
Focus
Hall error: Focus
Checkifwiring, hallsensorandmotorsarenormal
Colorwheel
Hall error:Color wheel
Checkifwiring, hallsensorandmotorsarenormal
Fixed gobowheel
Hall error:Fixedgobowheel
Checkifwiring, hallsensorandmotorsarenormal
Lampstriking
Lampstrikingerror
Check if wiring and igniter are normal and if the voltage of
theigniterisnormal
9. TECHNICALDATA
ELECTRICPARAMETERS
Inputvoltage200V~240VAC，50/60Hz
Inputpower600W@230V
Power factor PF>0.90
THESPECIFICATIONSOFTHELIGHTSOURCE
Lamp MSDPlatinum300SFlex
Color temperature 7800K
rated life 6000hrs
64-255
Prism 2in
10
12
Prism rotation
0-127
0-360°
128-190
Clockwiserotation:Fast->Slow
191-192
Stop
192-255
Anti-clockwiserotation:slow->fast
11
13
Frost
0-255
0-100%
12
14
Focus
0-255
0-100%
13
15
Reset
0-25
NO
26-76
Headreset
77-127
Pan &Tilt reset
128-255
Total reset
14
16
Lampcontrol
0-25
No
26-100
Lampoff
101-255
Lampon

16
COLORS
1colorwheel: 14colors+Open
FIXEDGOBOWHEEL
1fixedgobowheel:17gobos+open,gobodiameter=6mm,itsthickness=0.8mm
PRISM/FROST
1 8-facetprismand1 16-facetprism, bi-directionalrotation fromslow tofast,bothcanbeoverlapped
FOCUS
DMX linear focus
DIMMER /STROBE
Strobeat variablespeeds(15 F.P.Satmaximum)
0-100%lineardimmer
HEADMOVEMENT

17
Pan540º,Tilt 270ºwith 16bitcontrol
BEAMANGLE
0°～2°
CONTROL
InternationalstandardDMX512 protocol,5-pininterface
14channelsinshortmodeand16channelsinstandardmode
HOUSING
Hightemperatureandanti-UVABSandaluminum,IP20
NETWEIGHT
17Kg
OPERATIONTEMPERATURE
Ambienttemperatureatmaximum：45°C
SIZES
LIGHTOUTPUT
609
382
347
393
515
299
0.87
10 20
0.28 0.58
470500 115000
30
50660
2°
Diameter (m)
Distance (m)
lux

18
10. CIRCUITDIAGRAM

19
11. COMPONENTORDER CODES
Name
CodeNo.
Qty
Remarks
PanMotor
50300-00096
1
TiltMotor
50300-00097
1
Colorwheel
50502-00157
1
14colors,eachcode no.standsfor
onecolor,colorsstart fromredand
so on
50502-00158
1
50502-00159
1
50502-00160
1
50502-00161
1
50502-00162
1
50502-00163
1
50502-00164
1
50502-00165
1
50502-00166
1
50502-00167
1
50502-00168
1
50502-00169
1
50502-00170
1
Fixed gobowheel
70502-00015
70502-00011
1
Switchingpowersupply
50400-00008
1
Lamp
50203-00019
1
MSD Platinum300SFlex
Ballast
50406-00018
1

20
APPENDIX:SOMEITEMS REQUIRINGATTENTIONAS FORTHEUSE OF DISCHARGELAMP
For the effective extension of the lifespan of discharge lamp, some factors impacting its lifespan are specially listed
below, based on manufacturing technology and working mechanism of discharge lamps., physical attributions of the
lamps including lamp striking theory( ignited by focused high voltage---highly pressurized air broken down and
burning---lamp on at high temperature with thermal protection--- stable running) and lamp off theory( lamp off power
---lamp off at high temperature and thermal protection-highly pressurized air vaporizing evenly----completion of lamp
off.
1. Thesequenceoflamp striking:Poweron→lamp striking bycontroller(advised nottostrikelamp viapoweron),the
sequence of lamp off: lamp off by controller→mains power shut off (advised not to turn off lamp by shutting off
mainspower)
2. Within 1 min after lamp striking, it shouldn’t re-strike it frequently. ONLY more than 10 min after the projector is
cooledafter lampoff,can thelampbere-strickenagain.
3. Within5min afterlampstriking,itcan’tbe turnedoff.Duringthe lampstriking process,it’s forbidden to turnoff lamp
via shutting off mains power, but via controller. More than 5 min after the projector is cooled after lamp off, can the
mainspowerbeshutoff.
4. Theprojector isadvisednotto point to the samepointfor longtime,i.e.,it shouldn’tbe usedforlongtime ata fixed
angle.
5. Theprojectorisadvisednottousedoublecolorsforlongtime,i.e.,itshouldn’tuse2ormorecolors forlongtime.
6. Theprojectorisadvisednottokeepshuttersclosed whilelamponforlongtime,i.e.,itshouldbelessthan1hrafter
shuttersclosedafter lampon.
Itisadvisednot to use lamphalfpower function forlongtime.
