Theusermanualcontainsimportantinformationaboutthesafeinstallationanduseofaprojector.Pleaseread
and followtheseinstructions carefullyand keep themanualinasafeplaceforfuturereference.
PR LIGHTING LTD.
http://www.pr-lighting.com

2/28
INDEX
1. SAFETYANDWARNINGS
2. INSTRUCTIONS
CLEANINGAND MAINTENANCE
LUBRICATION
TROUBLESHOOTING
3.APPEARANCE
4. INSTALLATION
RIGGING
POWER CONNECTIONS
DMXCONTROLCONNECTIONS
DMXTERMINATOR
ALIGNMENT/INSTALLATION/REPLACEMENTOFALAMP
GOBO/COLORFILTERREPLACEMENT
5.SETUPANDCONFIGURATION
FRONTPANELOPERATION
DMXSTARTADDRESS
DMXWIRELESSCONTROL
STAND-ALONE MODE
MASTER/SLAVE MODE
FIRMWAREUPGRADEVIAUSBINTERFACE
6.OPERATION MENU
7.DMX PROTOCOL
8. ICONSOFTHETOUCHSCREEN
9. ERRORMESSAGES
10.TECHNICALDATA
11.CIRCUITDIAGRAMANDPCBCONNECTIONS
CIRCUITDIAGRAM
12.COMPONENTORDERCODES
3
4
4
4
4
5
5
5
5
6
6
7
8
8
8
9
9
9
9
8
10
12
21
21
23
27
27
28
ACCESSORIES
Thefollowing itemsaresuppliedwiththe projector andpleasecheck:
Name Quantity Unit Remark
Gclamps 2 Pcs
XLRconnector 1 Set Maleandfemale
Safetycord 2 Pcs
Sparegobos 4 Pcs
User manual 1 Pc
Ωclamps 2 Pcs Optional
Pleasenotethat aspartof ourongoingcommitmentto continuousproductdevelopment,specificationsare
subjectto changewithoutnotice.Whilsteverycareistakeninthe preparationof themanualwereservethe
rightto changespecificationsinthe courseof productimprovement.Thepublisherscannot be heldresponsible
fortheaccuracyofthe informationherein, oranyconsequencearisingfromthem.
Everyunitistestedcompletelyandpackedproperlybythemanufacturer.Pleasemakesurethepackingand/
ortheunitisingoodconditionbeforeinstallationand use.Should therebeanydamagecausedby
transportation,consultyourdealeranddonot usetheunit.Anydamagecaused byimproperusewill not be
assumedbythe manufacturerand /ordealer.
Anyfuturetechnicalchanges intheusermanualwon tbewith anyfurthernotice.
Note:FortheproductsmadebyGuangzhouPRlightingLtd,thewarranty forthewholeproductisoneyearstartingfrom
thedeliverydatebut thelightsource isnot within the warranty.

3/28
1. SAFETYANDWARNINGS
NOTE
Before a projector sinstallation, power-on, operation and maintenance, pleasecarefully read
thesafetyinformation hereinafter!
The following safety signsare used in theusermanual.
Warning
User
Manual
Electrical
shock
Goggles
Protective
Gloves
Flames
High
Temperature
Whenunpacking,checkifthereistransportationdamagebeforeusingtheprojector.Should therebeany
damagecausedbytransportation, consult yourdealerand donot useit.
Themanufactureisnotresponsibleforlosscausedbytheusernotfollowing themanualorchangingtheprojector
ashe/she likes.
Pleasebenotedthatthe damage causedbychangingthe projector atwillisnotwarranted.
Donothesitatetocontactthe dealer or the manufacturer if anyquestionsoradvice.
The projector isfor indoor use only, IP20.
Useonlyindrylocations.Keepthisunitawayfromrainandmoisture, excessiveheat,humidityanddust.Donot
allowcontactwithwater or anyotherliquids.
Theprojector shouldbekeptawayfromhigh temperature, fire, electricalsurge,vibrationandstronglightwhile
beingoperated.
Theprojectorisonlyintendedfor installation,operation andmaintenancebyqualifiedpersonnel.And the
operationmuststrictlyfollowthe proceduresinthemanual.
Norepairable partsintheprojector anddo notopencoversfor maintenancebyyourself.
Don’tlook straightlyintothe lightsourcesespeciallyfor epileptics,otherwiseeyeswill be burned..
Donotconnectthisdevicetoanytype ofdimmerpack.
Afterlampswitchedon,theminimumdistance betweenthe projector andilluminatedsurface is10m.
lensandother opticalpartsshall bereplacedimmediatelyif theyhavedeformedorbeendamaged, otherwisethe
lightoutputwillbe compromised.
Beforeoperation,pleaseconfirmthatallcovers(housing)areonandscrewstightened.It’sforbiddentousea
projector while covers(housing)are off .
Keepthe lampcleananddo nottouchit withbarehands.
While operatingit,wear protectiveitems.
Anyelectricalconnectionmustbecarriedoutbya qualifiedperson.
Beforeinstallation, please confirmthevoltagesuppliedmatcheswhatisrequiredfor theprojector.
Eachprojector mustbe properlyearthedandinstalledasperrelatedelectricalstandards.
Donotuse powercord withitsinsulator damagedandconnectthe power cord withother cables.
Iftheprojectorisnotusedor undercleaning,, pleaseholdtheplugandunplugit.Donotunplug itforcefully
or bypullingthe powercable.
All power cordsmustconformtorelatedsafetyandregulations.
While being operated,the projector shouldnotbeunder rainsor inhumidity.
Donotswitchonandofftheprojector constantlyinveryshortintervals,otherwisethelightsource’sandother
electricalparts’lifewillbeshortened.
Therearesafetycord holesatthebottomofthebaseofaprojector.Inviewofsafety,pleaserunthesafety

4/28
cord suppliedthroughthe safetycord holesfor safetysupport.
Beforeanyinstallation,maintenanceandcleaningwork,pleaseensuretheprojector isdisconnectedfrom
powermains.
Afterrunningfor 5minutes,thetemperatureofthehousing oftheprojector is 80 .Afterstableoperation,
itstemperatureis 170 .
While the lampisstrickenfor thefirsttime, therewillbesmokeandstrange smell. It’snormalanddoesnot
meanthe projector hassomedefects.
Donotmountthe projector directlyoninflammablesurface.
Donotprojectthe beamstraightlyoncombustibleitemsandtheminimumdistance betweenthe projector
andilluminateditemsis10m.
Aprojector shouldbeinstalledwithgood ventilationandtheminimumdistance betweentheprojector and
wallsis50cm.At thesametime, please ensurethefansandair inletsandoutletsareworkable.
2. INSTRUCTIONS
CLEANINGAND MAINTENANCE
Ifaprojector can’tstart.Pleasecheckifthefuseisblownup.Ifit does,replace it withanewfusewithsameratings.Andthe
projectorhasover-temperatureprotectivedevice.Ifthetemperatureistoo high,theprotectivedevicewill betriggeredtoshutthe
projector off. Whenithappens,pleasecheckifthefansrunnormallyor fanshieldisblockedbydust.Aftertheissueissolved,
restartthe projector.
Theaccumulationofoil,smokeanddustonthelenswill compromisethelightoutput.Cleaningaprojector isverynecessaryto
ensureareliableuseofit.Coolingfansneedtobecleanedevery15days.Internallens,reflector andhotmirror needtobecleaned
periodicallytooptimizelightoutput.
Cleaningfrequencyistobedecidedbyoperationsanditsenvironment.Usesoftclothandnormaldetergentfor glassfor cleaning
work. It’sadvisedexternalopticalsystembe cleanedevery20daysand internalopticalsystemsevery30/60days.Keeplensclean
anddo nottouchopticalpartswithbare hands.
Before anymaintenance andcleaning, pleaseensure the projectisoff the power.
Onlyqualifiedpersonisallowedtodo maintenance.
Duringmaintenance andbeforemaintenance, the projector mustbe off power.
Toavoidinternaldamage, sun lightor otherlightmustn’tpenetrateintotheprojector viafrontlens
whetherit runsor not.
Donotuse alcoholor other organic solventtocleanthehousingtoavoiddamage.
Donotuse anysolventwithchemicalelementstocleancolor filtersor hotmirror.
LUBRICATION
Toensuresmoothmovementofgobosandzoomandfocuslens,it’sadvisedrotators’bearingsand2slidingbarsfor zoomand
focuslensbe lubricatedevery2months.Highqualityandhightemperaturelubricant/grease isadvised..
TROUBLESHOOTING(Detailsvary with differentprojectors)
PROBLEM ACTION
The projector doesn’tswitchon ØCheckthefuse onthe powersocket.
ØCheckthe lamp.
Thelampisonbutthe projector doesn’trespond
tothe controller ØMakesure thatthefixture’sstartaddressisright ØReplace or repairthe XLRsignalcable.
The projector functionsintermittently ØMake surethefanisworking well or fansand theirshieldsarenotblocked
Beamappearsdim, Lowinbrightness ØMakesure thelampiswithinitslifespan
ØRemove dustorgreasefromthe lenses.
The projectimage appearstohave a halo ØCarefullycleanthe lamp, opticallensesandother components.
HeavilyDefective Beam ØCheckiflensare ingood condition(notcracked)
ØCleandustor grease onthe lens.

5/28
3. APPEARANCE
HEAD
ARM
BASE
4. INSTALLATION
RIGGING
Beforemoving aprojector,Pleaselock Pan and Tilt.Beforeitsoperation, please unlock them.It’sforbidden torun a
projectorwith powerwhileit islocked.
CLAMP
HANDEL CONTROL
PANEL
106 256
256
106
HOLES for SAFETY CORDS
WARNING
TOpass 2SAFETYCORDS
through 4 HOLES forsafety
Take2clampsandthesafetycord outfromthe package andmount2clampsontheundersideoffixturewith2retainersattached
toeachclamp.Hang thefixtureonthestructureandfastenthescrewsattachedtoeachclamp.(Seethe WARNING onthe
undersideofthebaseasshownabove) TopasstheSAFETYCORDthroughtheHOLESforsafety! Alwaysensurethatthe
projector isfirmlyanchoredtoavoidvibrationandslippingwhilstfunctioning.Alwaysensure thatthestructurethatyouaregoing
tomounttheprojector toissecure andstrongenoughtosupportthe weightof the projector.
WARNING:
The projector MUSTbeliftedor carriedbythe HANDLESinsteadofclamps.
.For safetythesafetycord shouldafford 10 timesthe Projector’sweight.
POWERCONNECTION
Connectthe powercord asfollows:
L(live) =brown
E (earth) =yellow/green
N(neutral) =blue
Beforepowerconnection,pleaseensurethepowersuppliedmustmatchwhatthenameplatesays.Itisrecommendedthateach
projector beconnectedwithpowerseparatelysothattheymaybe individuallyswitchedonandoff.

6/28
●Theearthwire(yellow/green)mustbeconnectedto theground.Andelectricalconnectionmustbein
accordance withthestandards concerned.
●If anyquestionsabout theelectricalinstallation,donot continuebut consult a qualifiedelectrician.
DMXCONTROLCONNECTION:
Connectionbetweencontrollerandprojector andbetweenoneprojector andanothermustbemadewithatwin-screenedcable, with
eachwirehavingatleasta0.5mmindiameter.Connectiontoandfromtheprojector isviacannon5pin(whichareincludedwiththe
projector) or 5pinXLRplugsandsockets.TheXLR'sareconnectedasshowninthefigure above.
Note:careshouldbetakentoensurethatnoneofthepinstouchthemetallicbodyoftheplugor eachother.XLRplugsandsockets
mustn’tbeconnectedinanywayotherthanmentionedintheabovefigure. Theprojector acceptsdigitalcontrolsignalsinprotocol
DMX512 (1990).
Connectthecontroller’sDMXoutputtothefirstfixture’sDMXinput,andconnectthefirstfixture’sDMXoutputtothesecond
fixture’sDMXinputandconnecttherestfixturesinthesameway.Eventuallyconnectthelastfixture’sDMXoutputtoaDMX
terminator asshowninthefigure below.
DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX TERMINATOR
DMXTERMINATOR
IntheControllermode, atthelastfixtureinthechain,theDMXoutputhastobeconnectedwithaDMXterminator.Thisprevents
electricalnoisefromdisturbingandcorruptingthe DMXcontrolsignals.
TheDMX terminator issimplyanXLRconnector witha120Ω(ohm)resistor connectedacrosspins2and3,whichisthenplugged
intothe outputsocketonthelastprojector inthechain.Theconnectionsare illustratedbelow.

7/28
ALIGNMENT/INSTALLATION/REPLACEMENTOFALAMP
Beforeinstallation/replacement/alignmentofa lamp, disconnectthe unitfromthe powerandletitcoolfirst.
LockTilt inthefigure belowandopenthe lampcover afterits4screwsareloosened.
After removalofthe lampcover, turnthe lampanti-clockwise andtakeit outoftheceramicstand..
Insertanewlamp.Note:whileplacinganewlamp,do nottouchtheburnerofthelampwithbarehands,otherwisethelightoutput
will be compromised.
Fastenthe 4fast-fit screwsafter thelampcover ison
Important:Theunituseshigh voltagedischargelampwithexternaligniter( ).Whileusingthelamp,pleasecarefullyread
“INSTRUCTIONS”packed withthe lamp.
4FAST-FITSCREWS
BACKCOVER LAMP
Don’ttouchtheinternalsurfaceofthereflector andtheburnerofthelampwithbarehandssoasnotto
impairthe beamoutput.While lamp’sinstallation, do notdamage themetalwire aroundthe burner.
Pleaseread"Instructions"enclosedwiththelamp
Dooperatethe projector while adjustingthelamp
21
3
120
DMXTERMINATOR
CONNECTION
Connecta120 (OHM) resistor
across pins2and 3in an XLR plug
and insert intotheDMX out socket
on the last unit in thechain.
PIN3
PIN2

8/28
GOBOREPLACEMENT
FRAMING MODULE
ROTATING GOBO WHEEL 2
EFFECT WHEEL
COLOUR WHEEL
ROTATING GOBO WHEEL 1
Lockthetilt andloosenthe6fast-fitscrewsontheuppercover,Afterremovingthecover,youwillsee thestructuresasthefigure
below.
Before replacinga gobo on thefixedgobo wheel,useyourfingertoremove the springtighteningitandtaketheoldoneoutwithdue
care.At lastputthenewintothewheel.
Toreplace agobo ontherotatinggobo wheel: taketherotator fromthewheel,takethegobo outfromtherotator byremovingthe
tighteningspring.Putthenewgobo backtotherotator,thentightenitwiththespring.Pleaseensurethespringisinthenarrow
locationoftherotator,whichisthe internalringofitandflattenit. Atlast,pullupthe springstripusing proper toolandputthe rotator
backtothewheelwiththe assistancebyanotherhand.
Note:Donottouchtheglassgobowithbarehand. Place cleanandsoftpaper or clothbetweenhandand glassgobos.
Tighten6fast-fitscrewsafterthe coverison. Unlockthetilt.
DANGER!
Beforereplacement of gobos, theprojectormustbe off thepower.
5. SETUPAND CONFIGURATION
FRONTPANELOPERATION
The projector configurationcanbesetconvenientlyvia pushbuttonsandcolor touchscreen.
Tobrowsethroughor changetheprojector ’ssettings,touchthewhiteareaofthetouchscreenor pressOK buttonfor morethan
3s(Onlypoweredbythebattery,pressingtheOKbutton)tounlockthescreen,thenpress ►keytoentertheprojector ’sfunction
menus.Eachmainmenu hasitssub-menus.And eachmenustandsfor specialfunction.For thedetails,pleaseseethefollowing6th
point ”OperationMenu”.:
1. Atthe pagetosetthefixture’sfunctions, press ◄,►,▲,▼keys ortheirrespectiveicons to selectthe functionsdesired.
2. Whileat2nd,3rd and4th levelofmenus,the◄keyisfor ESCAPE, but ►keywon’twork,and OK keyisusedfor ENTER.
Press OK keytosavethechangesor enterintothesubmenus.Press ▲or ▼keystochangethenumbers(minusor plus).

9/28
Ortouchthe optionneededfor change.
Shortcutkeys:AftertheFunctionMenu isenteredinto,therearealloptionsfor thefunctionsonthetop ofthescreen.Onthe
rightthere are 4shortcutkeyslike←,→LampControlandEnglish/Chinese.
DMXSTARTADDRESS
Eachprojector mustbegivenaDMXstartaddresssothatthecorrectprojectorrespondstothecorrectcontrolsignals. ThisDMXstart
addressisthechannelnumberfromwhichtheprojector startsto “listen”tothedigitalcontrolinformationbeingsentoutfromthe
controller.Theprojector has3DMXmodes.Therearestandard mode,shortmodeandextendedmode. For examplestandard mode
has46 channels,sosettheNo.1projector’saddress001,No.2projector’saddress047,No.3projector’saddress093,No.4
projector’saddress 139,andsoon.
SwitchontheProjector .Press OKkeymorethan3secondstounlockpanel,thenpress ►keytoenterintothefixture’soperation
menus.
SelectDMX AddressiconandpressOK keyor touchtheicondirectlyonthedisplayandselectDMX addressatthe2nd levelmenu
for the addresssetting.
Press▲or ▼keysor touch<、>displayedforthe DMXaddressdesired.
Press OKkeyto confirm.
Press the◄keyto go back tothe upperlevelmenu.
.
DMXWIRELESSCONTROL
The projector haswirelesscontrolfunctionwithwirelessreceiver module andantennafor remote control.
Thesetupofitisbelow:
1.PressOKfor morethan3stounlockthecontrolpanel,thenpress ►keytoenterintothe operation menu and select
“Config Settings”.
2. Select “WirelessFirst”or “WirelessOnly”fromthe menu of “SignalSelect”.
Onlyaftertheprojector islinkedwithatransmitter,canitreceivewirelesssignalsentbythetransmitter.Ifunlinkingit,
Press “Enter”for themenuofUn-linkWirelessundertheupperlevelmenuofConfigSettings,thenthefixtureisunlinked
withthewireless transmitter.
STAND-ALONEMODE
Operatetheprojectorwithoutconnecting withacontroller,enablethemastermodethrough theoperationpanel,the
projectorwill runinStand-Alonemodeautomatically.
DMXaddresscanbesetatany numberwithin512.
MASTER/SLAVEMODE
ManyprojectorscanrunsynchronouslyintheMaster/Slavemodebylinkingthemwitheachother.First,
Connectthefirstfixture’sDMX outputtothesecondfixture’sDMX inputusingXLR-XLRcontrolcableandthenconnectthesecond
fixture’sDMXoutputtothethird fixture’sDMXinput,andsoonuntil allprojectorsareconnectedinthisway. Eventuallyconnectthe
lastfixture’sDMX outputtoa DMXterminator.Set 1st projectorasthemasterandothersareSlaves.
StartAddressesofallSlavesare 001;Operationmode ofthe Master canbesetanymodefor a Master’andSlaves’operation mode can
besetaccordingly.
After Poweredon, thegroupwillrun inMaster/SlaveMode

10/28
DMXIN DMX OUT DMX IN DMXOUT DMXIN DMX TERMINATOR
MASTER SLAVE SLAVE
FIRMWAREUPGRADEVIAUSBINTERFACE
Copythe.PRSfilefor upgradingtoUdiskandplugit intoUSBinterface.Theupgradingfilename or itsfilefoldercanbeseenviathe
USBfirmwareupgradinginterface undermenuSERVICE. SelectthedesiredPRSfileandtaptheupgradingmenu,thenthesystem
will showPleaseWaiting…,whichmeansthefileisbeingcopiedintothesystem.Afterthat,theBootloaderinterface willbeentered
intoandthecountdown10sappear.Within10s,ifUPandDOWNkeysarepressedatthesametime, thesystementersintofirmware
upgradeinterface. Duringthisprocess,thepowersupplymustn’tbeinterrupted.Ifnonekeyispressedwithin10s,thefirmware
upgradeinterface won’tbe enteredinto.
6. OPERATIONMENU
1stLEVEL 2ndLEVEL 3rdLEVEL 4thLEVEL 5thLEVEL
Address
DMXAddress 1-512
IP Address Default IPAddress 2.X.X.X/10.X.X.X
CustomIPAddress X.X.X.X
SubNet Mask X.X.X.X
ArtNet Universe 0-255
Reset
TotalReset ReallyReset?
Pan&Tilt Reset ReallyReset?
ColourSystemReset ReallyReset?
Gobo Reset ReallyReset?
Dimmer/Strobereset ReallyReset?
Zo.Fo.Fr.Pr. ResetReallyReset?
OtherReset ReallyReset?
ConfigSettings
DMXChannel Mode
Short Mode
StandardMode
ExtendedMode
ViewSelectedMode
LampControl
LampControl OFF/ ON
OnByPowerOn
OFF/ ON
Control ByDMX
OFF/ ON
LampPower 1500/1700
1500/ 1700
Signal Select
XLROnly
XLRFirst
WirelessOnly
WirelessFirst
WirelessIn/XLROut
ArtNet Only
ArtNet In/ XLROut

11/28
LossofDMX Normal time out
HoldLastValue
DisplayConfig
DisplayMode
OffAfterDelay
OnAlways
DisplayInvert
Invert OFF
Invert ON
InvertAuto
LanguageSetting English
Chinese
TouchCalibration Input Password123
TemperatureUnit CelsiusDegree
Fahrenheit Degree
Un-LinkWireless ReallyUn-Link?
Defaults RestoreDefaults?
Option Settings
Pan/Tilt Settings
PanDMXInvert OFF/ ON
Tilt DMXInvert OFF/ ON
PanTilt Swap OFF/ ON
XYFeedback OFF/ ON
Pan/Tilt mode Speed/Time
Invert Settings
DimmerInvert OFF/ ON
IrisInvert OFF/ ON
ZoomInvert OFF/ ON
CYM Invert OFF/ ON
CTOInvert OFF/ ON
DimmerCurve Linear/ SquareLaw
Defaults RestoreDefaults?
Information
ViewDMXValues
LampHours ResetLampHours
TotalHours
Temperature
DisplayBoardXX /F
DriverBoard1XX /F
DriverBoard2XX /F
DriverBoard3XX /F
DriverBoard4XX /F
DriverBoard5XX /F
Panand Tilt XX /F
HeadSensorXX /F
SoftwareVersion
DisplayBoard System= XXX
Boot =XXX
Panand Tilt System= XXX
Boot =XXX
DriverBoard1 System= XXX
Boot =XXX
DriverBoard2 System= XXX
Boot =XXX
DriverBoard3 System= XXX
Boot =XXX
DriverBoard4 System= XXX
Boot =XXX
DriverBoard5 System= XXX

12/28
Boot =XXX
Panand Tilt System= XXX
Boot =XXX
ElectronicSN ElectronicSN=
************
RDM DeviceLabel RDM DeviceLabel ANSIE1.20 RDM
Version X.X
FanStatus
Service Manual Effect Control
StrobeXXX
DimmerXXX
…
USBUpdateSoftware
FactoryTest
Operation
Mode
DMXMode ChangeOperation Mode?
MasterMode
Preset Memory
ChangeOperation Mode?
UserMemory1
ChangeOperation Mode?
UserMemory2
ChangeOperation Mode?
Stand-AloneMode
Preset Memory
ChangeOperation Mode?
UserMemory1
ChangeOperation Mode?
UserMemory2
ChangeOperation Mode?
StaticScene ChangeOperation Mode?
User
Memories
Edit UserMemory
Edit UserMemory1
/
Edit UserMemory2
SceneXX
（1~200Scenes）
StrobeXXX
DimmerXXX
…
DelayTime XXX
DelayUnit
LinkToStepXXX
Edit StaticScene
StrobeXXX
DimmerXXX
…
Init UserMemory
Reset UserMemory1
Reset UserMemory?
Input Password123
Reset UserMemory2 Reset UserMemory? Input Password123
Reset StaticScene
Reset StaticScene?
Input Password123
7.DMXPROTOCOL
Ba
sic
m
od
e
Standard
mode
Extended
mode FunctionDescription Decimal Low
Decimal
High
1 1 1
Strobe
Close(LampSwitches to1200 wattmodeafterStrobeisclosedfor5
seconds) 0 10
Open 11 25
Strobespeedfromslowtofast 26 225
Macro(Randomstrobespeedslowtofast) 226 246
Open 247 255
2 2 2
Dimmer
Close 0 0
Dimmerfromdarktolight (0-100%) 1 255
3 3 Dimmer Fine

13/28
Finedimmer 0 255
3 4 4 CYMMacro
ThefollowingfunctionscanbeusedafterCMY,CTO, ColorWheel1and ColorWheel2
channelsaredisabled
NoFunction 0 7
ColourMacro18 9
ColourMacro210 11
ColourMacro312 13
ColourMacro4 14 15
ColourMacro516 17
ColourMacro618 19
ColourMacro720 21
ColourMacro822 23
ColourMacro924 25
ColourMacro10 26 27
ColourMacro11 28 29
ColourMacro12 30 31
ColourMacro13 32 33
ColourMacro14 34 35
ColourMacro15 36 37
ColourMacro16 38 39
ColourMacro17 40 41
ColourMacro18 42 43
ColourMacro19 44 45
ColourMacro20 46 47
ColourMacro21 48 49
ColourMacro22 50 51
ColourMacro23 52 53
ColourMacro24 54 55
ColourMacro25 56 57
ColourMacro26 58 59
ColourMacro27 60 61
ColourMacro28 62 63
ColourMacro29 64 65
ColourMacro30 66 67
LEE colourswatches LEE
LEE 4(MediumBastardAmber) 68 69
LEE 10 (MediumYellow)70 71
LEE 19 (Fire)72 73
LEE 26 (BrightRed)74 75
LEE 58 (Lavender) 76 77
LEE 68 (SkyBlue) 78 79
LEE 71 (TokyoBlue) 80 81
LEE 79 (Just Blue)82 83

14/28
LEE 88 (Lime Green)84 85
LEE 90 (DarkYellowGreen) 86 87
LEE 100 (SpringYellow) 88 89
LEE 101 (Yellow) 90 91
LEE 102 (LightAmber) 92 93
LEE 103 (Straw)94 95
Lee104 (DeepAmber) 96 97
LEE 105 (Orange)98 99
LEE 106 (PrimaryRed)100 101
LEE 111 (DarkPink) 102 103
LEE 115 (PeacockBlue)104 105
LEE 116 (MediumBlue-Green) 106 107
LEE 117 (Steel Blue) 108 109
LEE 118 (Light Blue) 110 111
LEE 119 (DarkBlue) 112 113
LEE 120 (DeepBlue) 114 115
LEE 121 (LEEGreen)116 117
LEE 128 (Bright Pink)118 119
LEE 131 (MarineBlue)120 121
LEE 132 (MediumBlue) 122 123
LEE 134 (GoldenAmber) 124 125
LEE 135 (DeepGoldenAmber) 126 127
LEE 136 (PaleLavender)128 129
LEE 137 (SpecialLavender) 130 131
LEE 138 (PaleGreen) 132 133
LEE 139 (PrimaryGreen)134 135
LEE 141 (Bright Blue)136 137
LEE 147 (Apricot) 138 139
LEE 148 (Bright Rose)140 141
LEE 152 (PaleGold)142 143
LEE 154 (PaleRose)144 145
LEE 157 (Pink)146 147
LEE 158 (DeepOrange) 148 149
LEE 162 (BastardAmber)150 151
LEE 164 (FlameRed)152 153
LEE 165 (Daylight Blue)154 155
LEE 169 (Lilac Tint) 156 157
LEE 170 (DeepLavender)158 159
LEE 172 (Lagoon Blue) 160 161
LEE 179 (Chrome Orange)162 163
LEE 180 (DarkLavender) 164 165
LEE 181 (CongoBlue) 166 167
LEE 197 (AliceBlue)168 169
LEE 201 (Full C.T. Blue)170 171

15/28
LEE 202 (HalfC.T. Blue) 172 173
LEE 203 (QuarterC.T. Blue)174 175
LEE 204 (Full C.T.Orange)176 177
LEE 205 (HalfC.T. Orange)178 179
LEE 206 (QuarterC.T.Orange)180 181
LEE 247 (LEE MinusGreen)182 183
LEE 248 (HalfMinusGreen)184 185
LEE 281 (ThreeQuarterC.T.Blue) 186 187
LEE 285 (ThreeQuarterC.T.Orange)188 189
LEE 352 (GlacierBlue)190 191
LEE 353 (LighterBlue)192 193
LEE 715 (CabanaBlue)194 195
LEE 778 (MillenniumGold)196 197
LEE 793 (VanityFair) 198 199
CMYcolourmixingfromslowtofast200 255
4 5 5 Cyan
Cyan(Linear0-100%) 0 255
6 CyanFine
Cyanin16 Bit precision 0 255
5 6 7 Yellow
Yellow(Linear0-100%) 0 255
8 YellowFine
Yellowin16 Bit precision 0 255
6 7 9 Magenta
Magenta(Linear0-100%) 0 255
10 MagentaFine
Magentain16 Bit precision 0 255
7 8 11 CTO
Linearadjustfromhightolow 0 255
12 CTOFine
CTOin16 Bit precision 0 255
8 9 13
ColourWheel 1
Continualpositioning
index0-360°0 63
positioning
White 64 67
White/colour1(Red) 68 71
Colour1(Red) 72 75
Colour1(Red)/colour2(Yellow) 76 79
Colour2(Yellow) 80 83
Colour2(Yellow)/colour3(Blue) 84 87
Colour3(Blue) 88 91
Colour3(Blue)/colour4(Green) 92 95
Colour4(Green) 96 99

16/28
Colour4(Green)/colour5(Pink) 100 103
Colour5(Pink) 104 107
Colour5（Pink））/colour6（Orange）108 111
Colour6(Orange) 112 115
Colour6(Orange)/ Colour7(UV) 116 119
Colour7(UV) 120 123
Colour7(UV)/white 124 127
Rainbowrotation speedfromslowtofast128 191
Rainbowreverserotation speedfromslowtofast192 255
10 14
ColourWheel 1Fine
ColourContinual positioningin16 Bit precision 0 255
9 11 15
Iris
LinearIrisfromsmall tobig0-100% 0 255
16
Irisin16 bit
Irisin16 bit precision 0 255
10 12 17
IrisMacro0 10
IrisMacrodisabled11 74
IrisMacro1:frombigtosmall withspeedfromslowtofast75 138
IrisMacro2:fromsmall tobigwithspeedfromslowtofast 139 202
IrisMacro3: Iriscontractsfromslowtofast203 210
IrisMacro4(Macro1 at random)withspeedfromslowtofast211 218
IrisMacro5(Macro2 at random)withspeedfromslowtofast 219 226
IrisMacro6(Macro3 at random)withspeedfromslowtofast 227 255
Open0 10
11 13 18
Rotatinggobo wheel1
White0 31
Gobo1 32 47
Gobo2 48 63
Gobo3 64 79
Gobo4 80 95
Gobo5 96 111
Gobo6 112 127
Clockwiserotation fromslowtofast128 143
Anti-clockwiserotation fromslowtofast 144 159
Gobo1 shakefromslowtofast160 175

17/28
Gobo2 shakefromslowtofast 176 191
Gobo3 shakefromslowtofast 192 207
Gobo4 shakefromslowtofast 208 223
Gobo5 shakefromslowtofast 224 239
Gobo6 shakefromslowtofast 240 255
12 14 19
Rotatinggobo wheel 1rotation
Indexing0-360°0 127
Stop 128 128
Clockwiserotation fromslowtofast 129 188
Stop 189 195
Anti-clockwiserotation fromslowtofast 196 255
15 20 Rotatinggobo wheel 1rotation in16 bit
Rotatinggobo wheel 1finerotation 0 255
13 16 21
Rotatinggobo wheel2
White0 31
Gobo1 32 47
Gobo2 48 63
Gobo3 64 79
Gobo4 80 95
Gobo5 96 111
Gobo6 112 127
Clockwiserotation fromslowtofast128 143
Anti-clockwiserotation fromslowtofast 144 159
Gobo1 shakefromslowtofast160 175
Gobo2 shakefromslowtofast 176 191
Gobo3 shakefromslowtofast 192 207
Gobo4 shakefromslowtofast 208 223
Gobo5 shakefromslowtofast 224 239
Gobo6 shakefromslowtofast 240 255
14 17 22
Rotatinggobo wheel 2rotation
Indexing0-360°0 127
Stop 128 128
Clockwiserotation fromslowtofast 129 188
Stop 189 195
Anti-clockwiserotation fromslowtofast 196 255
18 23 Rotatinggobo wheel 2rotation in16 bit
Rotatinggobo wheel 1finerotation 0 255
15 19 24 Framingblade1left
Framingblade1left linearlyclosingfrombigtosmall 0 255
25 Framingblade1left in16 bit
Framingblade1left fineadjustment0 255
16 20 26 Framingblade1right
Framingblade1right linearlyclosingfrombigtosmall 0 255
27 Framingblade1right in16 bit

18/28
Framingblade1rightfineadjustment0 255
17 21 28 Framingblade2left
Framingblade2left linearlyclosingfrombigtosmall 0 255
29 Framingblade2left in16 bit
Framingblade2left fineadjustment0 255
18 22 30 Framingblade2right
Framingblade2right linearlyclosingfrombigtosmall 0 255
31 Framingblade2right in16 bit
Framingblade2rightfineadjustment0 255
19 23 32 Framingblade3left
Framingblade3left linearlyclosingfrombigtosmall 0 255
33 Framingblade3left in16 bit
Framingblade3left fineadjustment0 255
20 24 34 Framingblade3right
Framingblade3right linearlyclosingfrombigtosmall 0 255
35 Framingblade3right in16 bit
Framingblade3rightfineadjustment0 255
21 25 36 Framingblade4left
Framingblade4left linearlyclosingfrombigtosmall 0 255
37 Framingblade4left in16 bit
Framingblade4left fineadjustment0 255
22 26 38 Framingblade4right
Framingblade4right linearlyclosingfrombigtosmall 0 255
39 Framingblade4right in16 bit
Framingblade4rightfineadjustment0 255
23 27 40
Framingmodulerotation
Framingmoduleindexing(0-360degrees)
Stop
Framingmoduleclockwiserotation fromslowtofast
Stop
Framingmoduleanti-clockwiserotation fromslowtofast
41 Framingmodulerotation in16 bit
Framingmodulefinerotation
24 28 42
Prism1
Openposition (hole) 0 16
Prism 17 255
25 29 43
Prism1rotation
Prismindex 0 127
Stop rotating 128 128
Rotation speedfromslowtofast129 191
Stop rotating 192 192
Reverse rotation speedfromslowtofast193 255
26 30 44 Prism2
Openposition (hole) 0 16

19/28
Prism 17 255
27 31 45
Prism2rotation
Prismindex 0 127
Stop rotating 128 128
Rotation speedfromslowtofast129 191
Stop rotating 192 192
Reverse rotation speedfromslowtofast193 255
28 32 46
DualEffectWheel
Noeffectwheel 0 19
Proportional indexing 20 127
Shakefromopentofull position withspeedfromslowtofast128 170
Shakefromopentohalfposition withspeedfromslowtofast 171 213
Shake.fromhalfposition tofull position withspeedfromslowtofast 214 255
29 33 47
DualEffectWheel 1rotation
Norotation 0 0
Forwardsrotation fromslowtofast 1 127
Norotation 128 128
Backwardsrotation fromslowtofast 129 255
30 34 48
DualEffectWheel 2rotation
Norotation 0 0
Forwardsrotation fromfast toslow 1 127
Norotation 128 128
Backwardsrotation fromslowtofast 129 255
31 35 49 LightFrost
Light Frostfrom0%to100%0 255
32 36 50 HeavyFrost
HeavyFrostfrom0%to100%0 255
33 37 51
Autofocus(Notrealizedyet)
WhileonlyIris, RotatingGobo Wheel 1and RotatingGobo Wheel 2areinuse, the
projectorhasautomaticfocusfunction at some distance. Use "AutofocusCalibrations"
channel (34/38/52)tofocustheimage. Priority:Gobo Wheel 2>Gobo Wheel 1>IRIS
Thefollowingfunction canberealizedafterthefocuschannel (35/39/53)isdisabled.
AutofocusOff 0 15
Autofocusfor5M16 75
Autofocusfor10M76 135
Autofocusfor15M136 195
Autofocusfor20M196 255
34 38 52
AutofocusCalibrations
focuscalibrationsup 0 127
focuscalibrationsdown128 255
35 39 53 Focus
Linearlyfocusing 0 255
54 FocusFine
Focusin16 precision 0 255

20/28
36 40 55 Zoom
Linearlyzooming 0 255
56 ZoomFine
Zoomin16 Bit precision 0 255
37 41 57 Pan
Panmovement 0 255
42 58 PanFine
Panmovement in16 bit precision 0 255
38 43 59 Tilt
Tilt movement0 255
44 60 Tiltfine
Tilt movement 16 bit precision 0 255
39 45 61
Pan/Tiltspeed
fast SpeedMode 0 1
Pan&Tilt speedfromfast toslow 2 255
40 46 62
Power/Special functions
Nofunction: 0 4
Reserved 5 19
1.Toactivatefollowingfunctions, stayinDMXvalueforatleast 5s
2.Thelampisallowedtobeturnedoff5minutes afterthelampison.And thelampis
allowedtobeturnedon 5minutes afterthelampisoff.
3. Beforethelampon orlampoff, set “control byDMX”/LampControl/ConfigSettingsas
ONviacontrol panel.
GraphicdisplayOn 20 24
GraphicdisplayOff 25 29
Reserved 30 34
Lamppower1500W 35 39
Lamppower1700W 40 44
Reserved 45 89
Pan/Tilt speedmode 90 94
Pan/Tilt time mode 95 99
Reserved 100 129
LampOn 130 139
Pan/Tilt reset 140 149
Coloursystemreset 150 159
Gobo wheelsreset 160 169
Dimmer/Strobereset 170 179
Zoom/focus/frost/prismreset 180 189
Iris/dualeffectwheel reset 190 199
Total reset 200 209
Reserved 210 229
LampOff 230 239
Reserved 240 255
1.Theprojectorcan tbe turnedonwithin1minute after thelamp-off.
