PR Lighting AQUA LED 1700 FRAMING User manual

1
AQUA LED 1700 FRAMING
PR-8179
This product manual contains important information about the safe installation and use of this projector.
Pleaseread and follow theseinstructions carefullyandkeepthis manualin asafeplaceforfuture reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

2
INDEX
1. SAFETYANDWARNINGS. …………………………………………………………………………………
2. INSTRUCTIONS ……………………………………………………………………………………………
●CLEANINGANDMAINTENANCE ………………………………………………………………………
●LUBRICATION………………………………………………………………………………………………
●TROUBLESHOOTING ……………………………………………………………………………………
3.APPEARANCE…………………………………………………………………………………………………
4.INSTALLATION ………………………………………………………………………………………………
●RIGGING……………………………………………………………………………………………………
●POWERCONNECTIONS ………………………………………………………………………………
●DMXCONTROLCONNECTION…………………………………………………………………………
●DMXTERMINATOR………………………………………………………………………………………
●REPLACEMENTOFGOBOS ………………………………………………………………………………
5.SETUPANDCONFIGURATION………………………………………………………………………………
●FRONTPANELOPERATION………………………………………………………………………………
●DMXSTARTADDRESS……………………………………………………………………………………
●DMXWIRELESSCONTROL………………………………………………………………………………
●STAND-ALONEMODE ……………………………………………………………………………………
●MASTER/SLAVE MODE……………………………………………………………………………………
6.OPERATIONMENU …………………………………………………………………………………………
7.DMXPROTOCOL ……………………………………………………………………………………………
8.LOGOS ONTHESCREEN……………………………………………………………………………………
9. ERROR INFORMATION ……………………………………………………………………………………
10.TECHNICALDATA …………………………………………………………………………………………
11.CIRCUITDIAGRAMANDPCB CONNECTIONS……………………………………………………………
●CIRCUITDIAGRAM…………………………………………………………………………………………
●PCBCONNECTIONS…………………………………………………………………………………………
12.COMPONENTORDERCODES………………………………………………………………………………
3
4
4
5
5
5
5
5
6
6
7
7
8
8
8
9
9
9
10
12
19
20
20
24
24
25
28
The following items are suppliedwith the projector andplease check:
Name
Quantity
Unit
Remark
Gclamp
2
Pcs
XLRconnector
1
Set
Maleandfemale
Safetycord
2
Pc
Thismanual
1
Pc
Ω clamp
2
Pcs
Optional
Power Cord
1
Pc
Please note that as part of ourongoing commitment to continuous product development, specificationsare subject to change
without notice. Whilsteverycare istakeninthe preparationof the manual we reservetherightto change specificationsin the
course of productimprovement. The publishers cannot be held responsible for the accuracy of the information herein, or any
consequencearisingfromthem.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are
in good condition before installation anduse. Should there be any damage caused by transportation, consult your dealer and
donotusethe unit.Anydamagecausedby improperusewillnot be assumedbythe manufacturerand/ordealer.
Anyfuturetechnicalchangesarenotsubjecttofurthernotice.
Note: For the products made by Guangzhou PR lighting Ltd, the warranty forthe whole product is one year starting from
thedelivery datebut the light sourceis notwithinthewarranty.

3
1. SAFETYANDWARNINGS
NOTE
Before a projector’s installation, power-on, operation and maintenance, please carefully read
the safety informationhereinafter!
Thefollowingsafetysignsareused intheusermanual.
Warning
User
Manual
Electrical
shock
Goggles
Protective
Gloves
Flames
High
Temperature
● When unpacking , check if there is transportation damage before using the projector. Should there be any
damagecausedbytransportation,consultyourdealeranddonotuse it.
●The manufacture isnotresponsible for loss caused bythe user not following the manual or changing the projector
ashe/shelikes
●Please be noted that thedamage caused bychangingtheprojectorat willis notwarranted.
● Do not hesitate to contact the dealer or the manufacturer if anyquestions or advice.
● Theprojector is forindoorandoutdoor use,IP65.
● Itcanbeusedinhumidanddustyareas.Anditcancontactwaterandother non-corrosiveliquids.
●The projector should be kept away from high temperature, fire, electrical surge, vibration and strong light while
beingoperated
●The projector is only intended for installation, operation and maintenance by qualified personnel. And the
operationmuststrictlyfollowtheproceduresinthe manual
●Norepairablepartsintheprojector anddo notopencovers formaintenancebyyourself.
●Don’t look straightly into the light sources especially for epileptics, otherwise eyes will be burned.
●Donotconnect this deviceto any type ofdimmer pack
●After lamp switched on, the minimum distancebetweentheprojectorand illuminatedsurface is 5m
●If there are visible damages onthe lamp, lens and protective cover for the screen, i.e., to the extent whichaffects
itsperformancelikecrackingordeformation,pleasestopusingitand contactthemanufacturefortheir
replacement withoriginalparts,otherwiseitsperformancewillbe compromised
.
●Before operation, please confirm that all covers(housing) are on and screws tightened. It’s forbidden to use a
projectorwhilecovers(housing)areoff
●Keep thelamp cleananddonot touch itwithbare hands.
●While operating it,wearprotective items.
●Anyelectrical connectionmustbecarriedoutbya qualifiedperson.
●Before installation, please confirmthe voltage supplied matches whatisrequired fortheprojector
●Eachprojector mustbeproperlyearthed and installed asper relatedelectrical standards.
●Donotusepower cord withitsinsulatordamaged andconnectthepower cord withothercables.
●If the projector is not used or under cleaning,, please hold the plug and unplug it. Do not unplug it forcefully
orbypullingthepowercable.
●Allpower cordsmustconformto related safety andregulations
●Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other

4
electrical parts’ life will be shortened .
●TheprojectorisofclassIP65,and notusedinthe environment higherthanit.
●There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety
cord suppliedthroughthesafetycordholes for safetysupport.
●Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from
power mains.
●After running for 5minutes, the temperature of the housing of the projector is45℃.After stable operation ,
itstemperature is80℃.
●While thelampisstrickenforthefirsttime,therewillbesmokeandstrange smell. It’s normal and does not
mean theprojector has some defects.
● Don’t touch the covers of the working projector(They are very hot!)
●Donotmounttheprojectordirectlyoninflammable surface.
●Do not project the beam straightly on combustible items and the minimum distance between the
projectorandilluminateditemsis5m.
●Aprojector should be installed with good ventilationand the minimum distance between the projector
andwallsis50cm.Atthe same time,pleaseensurethefans andairinletsandoutletsareworkable.
2. INSTRUCTIONS
●CLEANINGANDMAINTENANCE
If a projector can’t start. Please check if the fuse is blown up. If it does, replace it with a new fuse with same ratings. And the
projector has over-temperature protective device. Ifthe temperature is too high, the protective device will be triggered to shut the
projector off. When it happens, please check if the fans run normally or fan shield is blocked by dust. After the issue is solved,
restart theprojector.
The accumulation of oil, smoke and dust on the lens will compromise the light output. Cleaning a projector is very necessary to
ensure a reliable use of it. Cooling fans need to be cleaned every 15days.Internal lens, reflector and hot mirror need tobe cleaned
periodicallyto optimize light output.
The cleaning frequency of cooling fans and heatsink is decided by theoperations, environment and climate. It is advised to clean
itevery15daysorless. Userubberor bushorothernon-metallic tools to carry out cleaning. The tools can’t scratch or deformthe
heat sinkand fans.
Cleaning frequencyis to be decided by operations and itsenvironment. Use soft cloth and normal detergent forglass for cleaning
work. It’s advised external optical system be cleaned every 20days and internal optical systems every30/60days. Keep lens clean
and do nottouch opticalparts withbare hands.
Specialnote:
It’s normal phenomena that there will be mild water mist on the lens while the waterproof product is in use.
●Beforeanymaintenanceandcleaning,pleaseensuretheprojectisoffthepower
●Onlyqualifiedpersonisallowedtodo maintenance
●During maintenance andbefore maintenance, the projector mustbeoff power.
●To avoid internal damage, sun light or other light mustn’t penetrate into the projector via front lens
whether itrunsornot
●Donotusealcoholorotherorganicsolvent toclean the housingto avoiddamage.
●Donotuseanysolventwithchemical elementsto cleancolorfiltersorhotmirror.

5
●LUBRICATION
To ensure smooth movement of gobos and focus lens, it’s advised rotators’ bearings and 2 sliding bars for focus lens belubricated
every 2 months. High qualityand high temperaturelubricant/grease is advised..
●TROUBLESHOOTING
PROBLEM
ACTION
Theprojectorcan’t be switched on
Check ifthe fuse is burned
Check ifthe powercord is connected well
Check if the switching power supply is bad or not connected well. A
professionaltechnicianisrequired forthe repair
Check if the control board is connected well. .Aprofessional technician
isrequiredfortherepair
Theprojectorcanbeswitchedon,buttheLED
lamp’s brightness can’t be controlled
Check if the LED driver board is connected well. A professional
technicianisrequired for therepair
Theprojectorcanbeswitchedonnormally,but
notcontrolledbytheDMXcontroller
Make surethatthe fixture’s startaddressisright
Replaceorrepair theXLR signalcable.
Thebeamisnotbright anditsbrightness
decreasessharply
Makesurethefansareworkingwellorfansandtheirshieldsarenotblocked
bydust.
Makesurethattheinternalopticsisclean.
Beam appears dim, Lowin brightness
Make sure the lamp is within itslifespan
Removedustor greasefrom thelenses.
Theprojectimageappears tohaveahalo
CarefullycleantheLEDlamp,opticallensesand othercomponents.
HeavilyDefectiveBeam
Check if lensareingoodcondition(not cracked)
Cleandustor greaseonthelens.
3. APPEARANCE
4. INSTALLATION
●RIGGING
During transportation, please lock the projector well; Before the use of projector please unlock the head. It’s forbidden to run the
projector withoutunlockPanandTilt.
Body
Arm
Base

6
2
1
23
31
3PIN
DMX512
PIN FUNCTION
1 GND
2 DATA-
3 DATA+
DMX INDMX OUT
1
234
5
5
432
1
5PIN
DMX512
PIN FUNCTION
1 GND
2 DATA-
3 DATA+
4 N/C
5 N/C
DMX IN
DMX OUT
Take 2 clamps and 1 safety cords out from the package and mount 2 clamps on the underside of fixture with 4 retainers attached to
each clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the WARNINGon the underside of
the base as shown above) Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning.
Always ensure that the structure that youare going to mount the projector issecure and is strong enough to supportthe weight ofthe
fixture.
WARNING:
●TheprojectorMUSTbeliftedorcarriedbytheHANDLES insteadofclamps.
●.For safety the safety cord should afford 10 times the Projector’s weight.
●.Forsafety,it should notbe hungby itssides.
●POWERCONNECTIONS
Connect thepower cordas follows:
L(live)=brown
E(earth) =yellow/green
N(neutral)=blue
Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended thateach
projectorbeconnected withpower separatelyso thatthey maybeindividuallyswitched onandoff.
●The earth wire(yellow/green) must be connected to the ground. And electrical connection must be in
accordancewiththe standardsconcerned.
●Ifany questionsaboutthe electricalinstallation, donotcontinuebutconsultaqualifiedelectrician.
● The lighting fixture is with waterproof power socket, it should be equipped with same IPrating power
plug.
●DMXCONTROLCONNECTION
Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with
each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the
projector)or5 pinXLRplugs andsockets.The XLR'sareconnectedasshowninthefigureabove.
Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. XLR plugs and sockets
警告
请把保险绳穿过两个保
险绳扣板上以确保安全
!
保险绳扣板
保险绳
吊钩
提手
Warning
pleaserunthe safetycords through2 safety
cord holestoensuresafety
Safetycordholes
Clamp
Safetycord
Handle

7
mustn’t be connected in any way other than mentioned in the above figure. The projector accepts digital control signals in protocol
DMX512(1990).
Connect the controller’s DMX output to the first fixture’s DMX input, and connect the first fixture’s DMX output to the second
fixture’s DMX input and connect the rest fixtures in the same way. Eventually connect the last fixture’s DMX output to a DMX
terminator as showninthe figure below. (Recommended:that themax. number oflightingconnectionsnotexceed 32)
●DMXTERMINATOR
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents
electrical noisefromdisturbingandcorruptingtheDMXcontrol signals.
The DMX terminator is simply an XLR connector with a 120(ohm) resistor connected acrosspins 2 and 3, whichis then plugged
intothe output socketonthe lastprojectorinthe chain.Theconnectionsareillustratedbelow
●REPLACEMENTOFGOBOS
控制器
DMX512
回路插
输入 输出 输入 输出 输入
NO.1 NO.2 NO.n
21
3
120
DMX TERMINATOR
CONNECTION
Connect a 120 (OHM) resistor
across pins 2 and 3 in an XLR plug
and insert into the DMX out socket
on the last unit in the chain. PIN 3
PIN 2
INPUT
DMXTERMINATOR
DMXCONTROLLER
OUTPUT
INPUT
OUTPUT
INPUT
FixedGobo wheel
Colorwheel
RotatedGobo wheel

8
图案片安装 滤色片安装
11
2
2
Locktiltand unfasten 4 screws of the small cover of the head. Open the cover and you’ll see the structure as above.
Rotating gobos. Pull out the rotator as the figure hereinafter and the removal is in the sequence 1→2. Remove spring of the gobo
and take the gobo out. Place a new gobo in the rotator with the spring and ensure the spring is in the narrow groove of the
rotator ,i.e. its inner ring, then flatten it. At last use proper tool to push the tightening plate upward for the spring and use
another hand to help place the rotator in the original place. It is in the reverse sequence of the removal2→1.
Note: Do not touch glass gobos with bare hands. There should be clean and soft paper or cloth between hand and glass. Install the
chamber cover,tighten4 innerhexagon screws and unlockTilt.
DANGER!
BEFORETHEREPLACEMENTOFGOBOANDCOLORFILTER,THEPROJECTORMUSTBEOFF
POWER.
5.SETUPANDCONFIGURATION
●FRONTPANELOPERATION
Projectorconfigurationcanbesetconvenientlyviapushbuttonandcolortouchscreen.
Launch the projector and pressbutton ENTER for more than 5 secondsto unlock the panel, the LCDwill show the function menu of
the projector, each main menu has its submenus and each submenu has a specific function. For details, please see the
“OPERATION MENU” section.
Pressbutton UP or DOWN ifyouwant tobrowsethroughthe variousSetupOptions.
Pressbutton ENTER to save yoursettingsorenterthesubmenu.
Pressbutton UP or DOWN tochangevalues(plusorminus)
Pressbutton FUNC,it willreturnto theupper menu.Ifbutton FUNC notpressed,thedefaultwill showdisplaystatusautomatically.
●DMXSTARTADDRESS
Eachprojector must be givena DMX start address so that the correct projectorrespondsto the correct controlsignals. ThisDMX start
address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the
controller. The projector has 3 DMX modes. There are short mode ,standard mode and extended mode. For example standard mode
has 38 channels, so set the No. 1 projector’s address 001, No. 2 projector’s address 039, No. 3 projector’s address 077, No. 4
projector’s address115,and so on.
DMX
W-DMX
ETHERNET
FUNC
UP
DOWN
ENTER
Gobo Installation

9
Launch theprojector. Press button ENTER more than3secondsto unlock panel.
Pressbutton ENTER to displayDMXaddress;
Pressbutton UP and DOWN,youcansettheaddress;
Pressbutton ENTER to confirm; afterpoweredon nexttime,the default willbelastvalue saved
Pressbutton FUNC, it willreturnto the uppermenu
.
●DMXWIRELESSCONTROL
Theprojector has wirelesscontrol function with wirelessreceivermoduleandantennafor remotecontrol.
Thesetupofitisbelow:
1. Enter into the projector’s menu. Select the menu “Config Settigns” via the bottoms of UP and DOWN
2. Select DMX control Mode---- Wireless First (Note: Do not select XLR ONLY). The DMX wireless control
function is activated.
Only after the projector is linked with a transmitter, can it receive wireless signal sent by the transmitter. If unlinking it, Press
“Enter” for the menu ofUnlinkWireless undertheupperlevelmenuofConfigSettigns.
●STAND-ALONEMODE
Operate the projector without connecting with a controller, enable the master mode through the operation panel, the
projector will run in Stand-Alone mode automatically.
DMX address can be set at any number within 512.
●MASTER/SLAVEMODE
Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First,
connect the first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR controlcable and then connect the second
fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way. Eventually connect the
last fixture’s DMX output to a DMX terminator. Set 1st projector as the master and others are Slaves.
Start Addresses of all Slaves are 001; Operation mode of the Master can be set any mode for a Master’ and Slaves’ operation modecan
besetaccordingly.
After Powered on, the group will run in Master/Slave Mode: (Recommended: that the max. number of lighting connections not
exceed32)

10
6. OPERATIONMENU
1st LEVEL
2ndLEVEL
3rdLEVEL
4thLEVEL
5thLEVEL
Address
DMXAddress
1-474
IP Address
DefaultIPAddress
2.X.X.X/10.X.X.X
CustomIPAddress
X.X.X.X
SubNetMask
X.X.X.X
ArtNet
ArtNetUniverse
0-255
Reset
Total Reset
Really Reset?
Confirm/Cancel
Pan&TiltReset
ReallyReset?
Confirm/Cancel
ColourSystemReset
Really Reset?
Confirm/Cancel
GoboReset
Really Reset?
Confirm/Cancel
Zo.Fo.Fr.Pr.Reset
Really Reset?
Confirm/Cancel
OtherReset
Really Reset?
Confirm/Cancel
ConfigSettings
DMXChannelMode
ShortMode
Standard Mode
ExtendedMode
ViewSelected Mode
Strobe
…..
Signal Select
XLROnly
XLRFirst
WirelessOnly
WirelessFirst
WirelessIn/XLR Out
ArtnetOnly
ArtnetIn/XLR Out
LossofDMX
Normaltimeout
Hold LastValue
DisplayConfig
DisplayMode
OffAfterDelay
OnAlways
DisplayInvert
InvertOFF
InvertON
InvertAuto
LanguageSetting
English
Chinese
TemperatureUnit
CelsiusDegree
FahrenheitDegree
Un-LinkWireless
Really Un-Link?
Confirm/Cancel
Defaults
RestoreDefaults?
Confirm/Cancel
OptionSettings
Pan/Tilt Settings
PanDMXInvert
OFF/ON
TiltDMXInvert
OFF/ON
回路插
输入 输出 输入 输出 输入
主机 从机 从机
DMXTERMINATOR
MASTER
SLAVE
SLAVE
INPUT
OUTPUT
INPUT
OUTPUT
INPUT
INPUT
DMXCONTROLER

11
PanTilt Swap
OFF/ON
XYFeedback
OFF/ON
Pan/Tilt mode
Speed/Time
InvertSettings
IrisInvert
OFF/ON
ZoomInvert
OFF/ON
CYMInvert
OFF/ON
CTOInvert
OFF/ON
Defaults
RestoreDefaults?
Confirm/Cancel
Information
ViewDMXValues
LampHours
ResetLamp Hours
Total Hours
Temperature
DisplayBoardXX℃/F
PanBoardXX℃/F
Tilt BoardXX℃/F
Driver Board1XX℃/F
Driver Board2XX℃/F
Driver Board3XX℃/F
BladeBoardXX℃/F
FanBoardXX℃/F
LEDXX℃/F
LEDSensorXX℃/F
SoftwareVersion
DisplayBoard
System=XXX
Boot=XXX
PanBoard
System=XXX
Boot=XXX
TiltBoard
System=XXX
Boot=XXX
Driver Board 1
System=XXX
Boot=XXX
Driver Board 2
System=XXX
Boot=XXX
Driver Board 3
System=XXX
Boot=XXX
BladeBoard
System=XXX
Boot=XXX
FanBoard
System=XXX
Boot=XXX
ElectronicSN
ElectronicSN=
************
RDMDeviceLabel
RDMDeviceLabel
ANSIE1.20RDM
VersionX.X
FanStatus
HeadFan
Service
ManualEffectControl
StrobeXXX
DimmerXXX
…
FactoryTest
Operation
Mode
DMXMode
ChangeOperationMode?
Confirm/Cancel
MasterMode
PresetMemory
ChangeOperationMode?
Confirm/Cancel
UserMemory1
ChangeOperationMode?
UserMemory2
ChangeOperationMode?
Stand-AloneMode
PresetMemory
ChangeOperationMode?
UserMemory1
ChangeOperationMode?
UserMemory2
ChangeOperationMode?
StaticScene
ChangeOperationMode?

12
User
Memories
EditUserMemory
EditUserMemory1
/
EditUserMemory2
SceneXX
（1~200Scenes）
StrobeXXX
DimmerXXX
…
DelayTimeXXX
DelayUnit
LinkToStepXXX
EditStaticScene
StrobeXXX
DimmerXXX
…
Init UserMemory
ResetUserMemory1
ResetUserMemory?
InputPassword
ResetUserMemory2
ResetUserMemory?
InputPassword
ResetStaticScene
ResetStaticScene?
InputPassword
7.DMXPROTOCOL
Short
mode
Standard
mode
Extended
mode
FunctionDescription
DecimalLow
DecimalHigh
1
1
1
Strobe
Close
0
0
Pulsestrobespeedfromslowto fast
1
127
Strobespeedslowtofast
128
255
2
2
2
Dimmer
Close
0
0
Dimmerfromdarkto light(0-100%)
1
255
3
3
Dimmer Fine
Finedimmer
0
255
3
4
4
CYMMacro
Thefollowingfunctionscan beusedafterCMY,CTO,andColorWheels
channelsaredisabled
NoFunction
0
7
ColourMacro1
8
9
ColourMacro2
10
11
ColourMacro3
12
13
ColourMacro4
14
15
ColourMacro5
16
17
ColourMacro6
18
19
ColourMacro7
20
21
ColourMacro8
22
23
ColourMacro9
24
25
ColourMacro10
26
27
ColourMacro11
28
29
ColourMacro12
30
31
ColourMacro13
32
33
ColourMacro14
34
35
ColourMacro15
36
37
ColourMacro16
38
39
ColourMacro17
40
41
ColourMacro18
42
43

13
ColourMacro19
44
45
ColourMacro20
46
47
ColourMacro21
48
49
ColourMacro22
50
51
ColourMacro23
52
53
ColourMacro24
54
55
ColourMacro25
56
57
ColourMacro26
58
59
ColourMacro27
60
61
ColourMacro28
62
63
ColourMacro29
64
65
ColourMacro30
66
67
ColourMacro31
68
69
ColourMacro32
70
71
ColourMacro33
72
73
ColourMacro34
74
75
ColourMacro35
76
77
ColourMacro36
78
79
ColourMacro37
80
81
ColourMacro38
82
83
ColourMacro39
84
85
ColourMacro40
86
87
ColourMacro41
88
89
ColourMacro42
90
91
ColourMacro43
92
93
ColourMacro44
94
95
ColourMacro45
96
97
ColourMacro46
98
99
ColourMacro47
100
101
ColourMacro48
102
103
ColourMacro49
104
105
ColourMacro50
106
107
ColourMacro51
108
109
ColourMacro52
110
111
ColourMacro53
112
113
ColourMacro54
114
115
ColourMacro55
116
117
ColourMacro56
118
119
ColourMacro57
120
121
ColourMacro58
122
123
ColourMacro59
124
125
ColourMacro60
126
127
ColourMacro61
128
129

14
ColourMacro62
130
131
ColourMacro63
132
133
ColourMacro64
134
135
ColourMacro65
136
137
ColourMacro66
138
139
ColourMacro67
140
141
ColourMacro68
142
143
ColourMacro69
144
145
ColourMacro70
146
147
ColourMacro71
148
149
ColourMacro72
150
151
ColourMacro73
152
153
ColourMacro74
154
155
ColourMacro75
156
157
ColourMacro76
158
159
ColourMacro77
160
161
ColourMacro78
162
163
ColourMacro79
164
165
ColourMacro80
166
167
ColourMacro81
168
169
ColourMacro82
170
171
ColourMacro83
172
173
ColourMacro84
174
175
ColourMacro85
176
177
ColourMacro86
178
179
ColourMacro87
180
181
ColourMacro88
182
183
ColourMacro89
184
185
ColourMacro90
186
187
ColourMacro91
188
189
ColourMacro92
190
191
ColourMacro93
192
193
ColourMacro94
194
195
ColourMacro95
196
197
ColourMacro96
198
199
CMYcolourmixingfromslowto fast
200
255
4
5
5
Cyan
Cyan (Linear0-100%)
0
255
6
CyanFine
Cyanin16Bitprecision
0
255
5
6
7
Yellow
Yellow(Linear0-100%)
0
255
8
Yellow Fine

15
Yellowin 16Bitprecision
0
255
6
7
9
Magenta
Magenta(Linear0-100%)
0
255
10
MagentaFine
Magentain 16Bitprecision
0
255
7
8
11
CTO
Linear adjust fromhightolow
0
255
12
CTOFine
CTOin 16 Bitprecision
0
255
8
9
13
ColourWheel
Continualpositioning
index0-360°
0
63
positioning
White
64
67
White/colour1(Purple)
68
71
Colour1(Purple)
72
75
Colour1(Purple)/colour2(Red)
76
79
Colour2(Red)
80
83
Colour2(Red)/colour3(Pink)
84
87
Colour3(Pink)
88
91
Colour3(Pink)/colour4(Yellow)
92
95
Colour4(Yellow)
96
99
Colour4(Yellow)/colour5(Green)
100
103
Colour5(Grenn)
104
107
Colour5（Green））/colour6（Blue）
108
111
Colour6(Blue)
112
115
Colour6(Blue)/ White
116
119
White
120
127
Clockwiserainboweffectrotationspeed fromslowtofast
128
191
Anti-clockwiserainboweffectrotationspeed fromslowto fast
192
255
10
14
Colour Wheel Fine
ColourContinualpositioningin16Bitprecision
0
255
9
11
15
Iris
LinearIrisfromsmalltobig0-100%
0
255
16
Irisin16 bit
Irisin16bitprecision
0
255
10
12
17
IrisMacro
IrisMacro disabled
0
10
IrisMacro1:frombigtosmallwithspeedfromslowto fast
11
74
IrisMacro2:fromsmalltobigwithspeedfromslowto fast
75
138
IrisMacro3:Iriscontractsfromslowto fast
139
202
IrisMacro4(Macro1atrandom) withspeedfromslowto fast
203
210

16
IrisMacro5(Macro2atrandom)withspeedfromslowto fast
211
218
IrisMacro6(Macro3atrandom)withspeedfromslowto fast
219
226
Open
227
255
11
13
18
Fixedgobowheel
White
0
15
Gobo1
16
31
Gobo2
32
47
Gobo3
48
63
Gobo4
64
79
Gobo5
80
95
Gobo6
96
111
Gobo7
112
127
Clockwiserotation fromslowtofast
128
149
Anti-clockwiserotation fromslowtofast
150
171
Gobo1shakefromslowtofast
172
183
Gobo2shakefromslowtofast
184
195
Gobo3shakefromslowtofast
196
207
Gobo4shakefromslowtofast
208
219
Gobo5shakefromslowtofast
220
231
Gobo6shakefromslowtofast
232
243
Gobo7shakefromslowtofast
244
255
12
14
19
Rotatinggobowheel
White
0
31
Gobo1
32
47
Gobo2
48
63
Gobo3
64
79
Gobo4
80
95
Gobo5
96
111
Gobo6
112
127
Clockwiserotation fromslowtofast
128
143
Anti-clockwiserotation fromslowtofast
144
159
Gobo1shakefromslowtofast
160
175
Gobo2shakefromslowtofast
176
191
Gobo3shakefromslowtofast
192
207
Gobo4shakefromslowtofast
208
223
Gobo5shakefromslowtofast
224
239
Gobo6shakefromslowtofast
240
255
13
15
20
Rotating gobowheelrotation
Indexing0-360°
0
128
Clockwiserotation fromslowtofast
129
188
Stop
189
195
Anti-clockwiserotation fromslowtofast
196
255
16
21
Rotatinggobowheel rotationin16bit

17
Rotatinggobo wheel finerotation
0
255
14
17
22
Framing blade1left
Framingblade1leftlinearlyclosingfrombigtosmall
0
255
23
Framingblade1leftin16bit
Framingblade1left fineadjustment
0
255
15
18
24
Framingblade1 right
Framingblade1rightlinearlyclosingfrombigtosmall
0
255
25
Framingblade1 rightin16bit
Framingblade1right fineadjustment
0
255
16
19
26
Framingblade2left
Framingblade2leftlinearlyclosingfrombigtosmall
0
255
27
Framingblade2leftin16bit
Framingblade2left fine adjustment
0
255
17
20
28
Framingblade2 right
Framingblade2rightlinearlyclosingfrombigtosmall
0
255
29
Framingblade2 rightin16bit
Framingblade2right fineadjustment
0
255
18
21
30
Framingblade3left
Framingblade3leftlinearlyclosingfrombigtosmall
0
255
31
Framingblade3leftin16bit
Framingblade3left fineadjustment
0
255
19
22
32
Framingblade3 right
Framingblade3rightlinearlyclosingfrombigtosmall
0
255
33
Framingblade3rightin16bit
Framingblade3rightfineadjustment
0
255
20
23
34
Framingblade4left
Framingblade4leftlinearlyclosingfrombigtosmall
0
255
35
Framingblade4leftin16bit
Framingblade4left fineadjustment
0
255
21
22
36
Framingblade4 right
Framingblade4rightlinearlyclosingfrombigtosmall
0
255
37
Framingblade4rightin16bit
Framingblade4rightfineadjustment
0
255
22
25
38
Framingmodulerotation
Framingmoduleindexing(0-360degrees)
0
127
Stop
128
Framingmoduleclockwiserotation fromslowtofast
129
188
Stop
189
195
Framingmoduleanti-clockwiserotation fromslowtofast
196
255
39
Framingmodulerotationin16bit
Framingmodulefinerotation
0
255
23
26
40
Prism
No Prism
0
16

18
Prism
17
255
24
27
41
Prismrotation
Prismindex
0
127
Prismstops
128
Rotationspeed fromslowtofast
129
191
Stoprotating
192
Reverserotationspeed fromslowto fast
193
255
25
28
42
EffectWheel
No effect wheel
0
19
Effectwheelin
20
255
26
29
43
EffectWheelRotation
Forwardsrotationfromslowto fast
0
127
Reverserotationfromslowtofast
128
255
27
30
44
Frost
LightFrost from0%to100%
0
255
28
31
45
Focus
Linearly focusing
0
255
46
FocusFine
Focusin16precision
0
255
29
32
47
Zoom
Linearly zooming
0
255
48
ZoomFine
Zoomin16Bitprecision
0
255
30
33
49
Pan
Panmovement
0
255
31
34
50
PanFine
Panmovementin16bitprecision
0
255
32
35
51
Tilt
Tiltmovement
0
255
33
36
52
Tiltfine
Tilt movement16bitprecision
0
255
34
37
53
Pan/Tiltspeed
Fast SpeedMode
0
1
Pan &Tilt speed fromfasttoslow
2
255
35
38
54
Power/Specialfunctions
No function:
0
4
Reserved
5
19
To activatefollowing functions, stayinDMXvalueforatleast5s
GraphicdisplayOn
20
24
GraphicdisplayOff
25
29
Reserved
30
89
Pan/Tiltspeed mode
90
94
Pan/Tilttimemode
95
99

19
Reserved
100
139
Pan/Tiltreset
140
149
Coloursystemreset
150
159
Gobowheelsreset
160
169
Reserved
170
179
Zoom/focus/frost/prismreset
180
189
Others(Iris/effectwheel/Framingmodule)reset
190
199
Totalreset
200
209
Reserved
210
229
Reserved
240
255
Note:
1）Fanerror can automaticallyturnthe LED lampoff.
2）Note:"SpeedMode" meansPan andTiltwill move fromPointAtoPointB attheirrespective maximumspeeds."TimeMode"
meansbothPanandTilt willarrive atdesignatedpointatthe sametime. It'sadvisedTimeModebeusedifthe projectorrunscirclesor
inoblique lines.
3）Channelpriority: CYM> Cyan,Yellowand Magenta;Prism> Frost
8. LOGOSONTHETOUCHSCREEN
Config Settings
Option Settings
Information
ErrorMessages
Service
Address
OperationMode
Reset
UserMemories
9. ERRORINFORMATION
Thesystemcandetectsome errorsduringthereset,if displayed,touch the logo to viewthe error.
Theerror messages areasfollows:
Name
Type
Correction
Pan
Timeout/magnetSensor/Encoder
Check ifwiring,positioningpartsandmotors arenormal
Tilt
Timeout/magnetSensor/Encoder
Check ifwiring,positioningpartsandmotors are normal
Cyan
Timeout
Check ifwiring,positioningpartsandmotors arenormal
Yellow
Timeout
Check ifwiring,positioning parts and motors are normal
Magenta
Timeout
Check ifwiring,positioningpartsandmotors arenormal
CTO
Timeout
Check ifwiring,positioningpartsandmotors arenormal
ColorWheel
Timeout
Check ifwiring,positioningpartsandmotors arenormal
Fixedgobo wheel
Timeout
Check ifwiring,positioning parts and motors are normal
Rot.GoboWheel
Timeout
Check ifwiring,positioningpartsandmotors arenormal

20
Rot.Gobo1Rotation
Timeout
Check ifwiring,positioning parts and motors are normal
Dimmer
Timeout
Check ifwiring,positioningpartsandmotors arenormal
Prism
Timeout
Check ifwiring,positioning parts and motors are normal
Prism Rotation
Timeout
Check ifwiring,positioningpartsandmotors arenormal
Focus
Timeout
Check ifwiring,positioning parts and motors are normal
Zoom
Timeout
Check ifwiring,positioningpartsandmotors are normal
Effectwheel
Timeout
Check ifwiring,positioning parts and motors are normal
EffectwheelRotation
Timeout
Check ifwiring,positioningpartsandmotors arenormal
PanBoard
Error
Checksignalwire
TiltBoard
Error
Checksignalwire
DriverBoard1
Error
Checksignalwire
DriverBoard2
Error
Checksignalwire
DriverBoard3
Error
Checksignalwire
BladeBoard
Error
Checksignalwire
FanBoard
Error
Checksignalwire
Lampon
Timeout
Check ifhelamp is damaged
Lamp Life
Timeout /Warning
LampOff[Fan Error]
Error
Check ifallfans arenormal
TimeIC
Error
10. TECHNICALDATA
ELECTRICALPARAMETERS
Inputvoltage:100V-240VAC，50/60Hz
Inputpower:1100W@230V
Maximumcurrent: 13.4A
Power factor:PF>0.9
SPECIFICATIONSOFLIGHTSOURCE
Lamp 730WLEDEngine
MSDPlatinum11R
ColourTemperature 8000K
7800°K
ManufacturersRated Lamp Life 20000hrs
2000hrs
COLORS
CMYlinearcoloringmixingsystem withmacros
1ColorWheel
6exchangeablecolor +white(Option:5exchangeable color+white+1 HighCRI filter)
Bi-directionalrainboweffectwithvariablespeedsand halfcoloreffect
Linear /steppingcolorchanging
