PR Lighting LS 90 Logo User manual

1/16
LS 90 Logo
PR-6830
The user manual contains important information about the safe installation and use of a projector. Please read
and followthese instructionscarefullyandkeep themanualinasafe placeforfuturereference.
PR LIGHTING LTD.
http://www.pr-lighting.com
INDEX

2/16
1.SAFETYANDWARNINGS
2. INSTUCTIONS
●CLEANINGANDMAINTENANCE
●TROUBLESHOOTING
3.APPEARANCE
4.INSTALLATION
●RIGGING
●PLACEAUNITONAFLATSURFACE
●TRANSPORTATION
●POWERCONNECTIONS
●DMXCONTROLCONNECTION
●DMXTERMINATOR
5.SETUPANDCONFIGURATION
●FRONTPANELOPERATION
●DMXSTARTADDRESS
●STAND-ALONEMODE
●MASTER/SLAVEMODE
6.OPERATIONMENU
7.DMXPROTOCOL
8.TECHNICALDATA
9.CIRCUITDIAGRAMANDPCBCONNECTIONS
●CIRCUITDIAGRAM
●PCB CONNECTIONS
10.COMPONENTORDERCODES
3
4
4
4
5
5
6
6
6
6
6
7
7
8
8
8
8
9
10
11
13
13
14
15
ACCESSORIES
The followingitemsaresupplied withtheprojector and pleasecheck:
Name
Quantity
Unit
Remark
clamp
1
Pc
Powercord
1
Pc
XLR connector
1
Set
Maleand female
Safetycord
1
Pc
User manual
1
Pc
Transparent Cover+seal+ screws×6
1
Set
Optional
Please note that as part of our ongoing commitment to continuous product development, specifications are subject tochange without notice.
Whilst every care is taken in the preparation of the manual we reserve the right to change specifications in the course of product
improvement.Thepublisherscannotbeheldresponsiblefortheaccuracyoftheinformationherein,oranyconsequencearising fromthem.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in good
conditionbeforeinstallationand use.Should there be any damage caused bytransportation,consultyourdealeranddonot usetheunit. Any
damagecausedbyimproperusewillnotbeassumedbythemanufacturerand/ordealer.
Any future technical change in the user manual won’t be with any further notice.
Note: Forthe productsmadeby GuangzhouPRlighting Ltd,the warranty for the whole product is oneyearstartingfrom the delivery date
butthelightsourceisnotwithinthewarranty.
1. SAFETYANDWARNINGS

3/16
.
NOTE
Before a projector’s installation, power-on,operationandmaintenance,pleasecarefullyread
thesafetyinformationhereinafter!
Thefollowingsafetysignsareusedintheusermanual.
Warning
User
Manual
Electrical
shock
Goggles
Protective
Gloves
Flames
High
Temperature
● When unpacking , check if there is transportation damage before using the projector. Should there be
anydamagecausedbytransportation,consultyourdealeranddonotuseit.
●The manufacture is not responsible for loss caused by the user not following the manual or changing the
projectorashe/shelikes
●Please be noted that the damage caused by changing the projector at will isnotwarranted.
●Do not hesitate to contactthedealerorthe manufacturer ifanyquestionsor advice.
●The unit can be used indoors and outdoors and forits IP rating .please refer to Technical Data section of this user
manual.
● Useonlyindry locations.Keep thisunit awayfromrainandmoisture,excessiveheat, humidityanddust. Donot
allowcontactwithwateror anyother liquids.
●It’s forbidden to make the unit withlowerprotectionleveldirectlyorindirectlycontactwaterorother liquids.
●The projector should be kept away from high temperature, fire, electrical surge, vibration and strong light while
beingoperated
●The projector is only intended for installation, operation and maintenance by qualified personnel. And the
operationmust strictlyfollowtheprocedures inthe manual
●No repairable parts in the projector anddo notopencoversformaintenancebyyourself.
●Don’t look straightly into thelightsources especiallyforepileptics, otherwiseeyeswill beburned.
●Do not connect this device to any typeofdimmer pack
●After lamp switched on, the minimumdistancebetweentheprojector and illuminatedsurfaceis1.5m
●lens and other optical parts shall be replaced immediatelyif they have deformed or beendamaged, otherwise the
lightoutput willbe compromised.
●Before operation, please confirm that all covers(housing) are on and screws tightened. It’s forbidden to use a
projectorwhilecovers(housing)areoff
●Keep the lamp clean and do not touch it with bare hands.
●While operating it, wear protective items.
●Any electrical connection must be carried out by a qualified person .
●Before installation, please confirm the voltage supplied matcheswhatisrequired fortheprojector
●Each projector must be properlyearthed and installedasper relatedelectrical standards.
●Do not use power cord with its insulator damaged and connect the power cord with other cables.
●If the projector is not used or under cleaning,, please hold the plug and unplug it. Do not unplug it forcefullyor
bypullingthepower cable.
●All power cords must conform to related safety and regulations
●While beingoperated,theprojectorshould notbe underrainsorinhumidity.
●Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other
electricalparts’ life willbe shortened.
●There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safetycord
supplied throughthe safetycordholes for safety support.

4/16
●Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from power
mains.
●Under normal temperature, the temperature of the housing will be 55℃; after being stable, the unit’s
surface temperaturewillbe70℃
●While the lamp is stricken for the first time,there will be smoke andstrange smell. It’s normal and does not
meantheprojectorhassome defects.
●While operated, do not touch the metallic housing. It is very hot during operation.
●Do not mount the projector directly on inflammable surface.
●Do not project the beam straightly on combustible items and the minimum distance between the projector
and illuminateditems is10m.
●A projector should be installed with good ventilation and the minimum distance between the projector and
wallsis50cm.Atthe sametime,pleaseensure thefansandairinletsandoutletsareworkable.
2. INSTRUCTIONS
●CLEANINGANDMAINTENANCE
For the units with optical lens, because of the accumulation of the smoke, oil and dust on lens, the light output will be
compromised. For the reliable use of the unit, it is very necessary to keep it clean. The unit is IP65 rating waterproof device.
Unless approval by some professional technician for necessary internal component replacement, it’s forbidden to dismantle the
unit.
Cleaning frequencyisto be decided byoperations and its environment. Use soft cloth and normaldetergent for glass for cleaning
work. It’s advised external optical system be cleaned every 20days. Keep lens clean and do not touch optical parts with bare
hands.
●Before any maintenanceandcleaning,pleaseensuretheprojectisoffthepower
●Onlyqualified personisallowedtodo maintenance
●Duringmaintenanceandbeforemaintenance,theprojectormustbeoffpower.
●To avoid internal damage, sun light or other light mustn’t penetrate into the projector via front lens whether
itrunsornot
●Do not use alcohol or other organic solvent to clean the housing to avoid damage.
●Do not use any solvent with chemical elements to clean color filters or hot mirror.
●TROUBLESHOOTING
PROBLEM
ACTION
The projector doesn’t switch on
Check thepowercordconnection
Power Switch fails or is not connected well, call a professional
technicianforrepairingandchecking
Control board is not connected normally, call a professional technician
forrepairingandchecking,
The projectcanbe turnedon,buttheLEDlamps
can’t be on
LED lamp board is not connected well, call a professional technician for
repairing and checking
The LEDlamps canbeon,butnotcontrolled
byDMX
CheckifDMXStartAddressisproperlyset
CheckifXLRcablefailsornot
Thebrightnessdecreasesobviously
Ambient temperature is too hot which makes the projector too hot,
pleasetakeappropriate ventilationmeasures
3. APPEARANCE

5/16
灯体 body 吊臂 arm
4. INSTALLATION
吊臂 Arm 保险绳 safety cord 吊钩： clamp 警告 warning 为确保安全，请将保险绳连接在安全扣并确认锁
紧For safety,pleaserunthe safetycordthroughthe safetycordholeandensureitistightened
●RIGGING
灯体
吊臂
吊臂
保险绳
警告
为确保
安全，请
将保险绳
连接在安
全扣并确
认锁紧。

6/16
Take 1 clamp and 1 safety cord out from the package and tighten the clamp with the arm, and then mount the whole uniton the truss,
tighten the clamp’s retainers to keep the unit stable. (See the WARNING onthe underside of the base as shown above) To pass the
SAFETYCORDthroughthe ARM forsafety!Always ensurethattheunit is firmly anchoredto avoid vibrationand slippingwhilst
functioning. Always ensure that the structure that you aregoing to mount the unit to is secureand strong enoughto support the weight
oftheunit Loosen thebig knob and adjust the head’s angle for theeffectdesiredandthe tightenit.The installationiscompleted.
(ifthe unitiswitwirelesscontrol, whilebeinghung,theantennashouldfacedown)
●PLACEAUNITONAFLATSURFACE
Before placing a unit on a flat surface, loosen the small knob with the support and make the angle between the arm and the support
60degrees.Tightenthesmallknob.Loosenhebig knobandadjustthe anglebetweenthearmandunitasdesiredandthen tightenit.
.(If the unitis withwireless control,after the unit is placed ona flat surfacethe antenna should face up)
●TRANSPORTATION
Before transportation,tightenboth knobsafter thearmand supportareoverlapped.
WARNING:
●TheprojectorMUSTbelifted orcarriedbythe HANDLESinsteadofclamps.
●.Forsafety the safety cord should afford 10 times the Projector’s weight.
●POWERCONNECTION
Connect thepower cordasfollows:
L(live)=brown
E(earth) =yellow/green
N(neutral)=blue
Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each
projectorbe connected withpowerseparatelyso thattheymaybeindividuallyswitched onandoff.
Note: If projectors are connected in series, please connect POWERIN port of the 1st projector with the Power Mains, then
connectitsPOWEROUTwithPOWERINof the2nd projector,andsoontillallfixturesareconnected.Ifthevoltagesupplied
is 200V-240V, the maximum projectors connected is 8pcs, if it is 100V-120V, the maximum is 4pcs. The diameter ofthe cores
ofthewiresforthePowerin/outcablesmustbeequalorbiggerthan2.5mm2.
●Theearthwire(yellow/green) mustbeconnectedto theground.And electricalconnectionmust bein
accordancewiththestandardsconcerned.
●If any questionsaboutthe electricalinstallation, donotcontinuebutconsulta qualifiedelectrician.
●DMXCONTROLCONNECTION:
Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with
each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon5 pin (which are included with the
projector)or5pinXLRplugsand sockets.The XLR'sareconnected asshowninthefigureabove.

7/16
Note: care should be taken to ensure that none of the pins touch the metallic bodyof the plug or each other. XLR plugs and sockets
mustn’t be connected in any way other than mentioned in the above figure. The unit accepts digital control signals in protocol
DMX512(1990).
Connect the controller’s DMX output to the first fixture’s DMX input, and connect the first fixture’s DMX output to the second
fixture’s DMX input and connect the rest fixtures in the same way. Eventually connect the last fixture’s DMX output to a DMX
terminatorasshowninthefigurebelow.
接回路插 DMXterminator 接控制器 DMX Controller 接电源 Power
●DMXTERMINATOR
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents
electricalnoise fromdisturbingand corruptingtheDMXcontrolsignals.
The DMX terminator is simply an XLR connector with a 120(ohm) resistor connected across pins 2 and 3, which is thenplugged
intotheoutput socketonthe lastprojector inthe chain.The connectionsareillustratedbelow.
5. SETUPANDCONFIGURATION
●FRONTPANELOPERATION
To browse through or modify the projector’s functions, press key ENTER for more than 3 seconds to unlock the control panel and
接电源
接控制器
DMX OUT
POWER OUTPOWER IN
DMX OUTDMX IN
POWER OUTPOWER IN
接回路插
21
3
120
DMX TERMINATOR
CONNECTION
Connect a 120 (OHM) resistor
across pins 2 and 3 in an XLR plug
and insert into the DMX out socket
on the last unit in the chain. PIN 3
PIN 2

8/16
enter the menus. To set or browse through the projector’s functions, press key UP or DOWN. Press the key ENTER to enter the
submenus andthecurrentparameterswillbe displayedwhileflashing.Press key UP or DOWN tochange values(plusor minus)
Press key ENTER tosave yourchangesandenter into theupperlevelmenu while flashings stop;
Press key FUNC,itwill returntothe uppermenu(parametersnotsaved)or browse through1st levelmenus;
Press key FUNC for1 second ornonekeyis pushedfor 1minute, the menu willbeescapedand currentoperationmodedisplayed.
IfDMXsignalisavailable, LEDindicationison.Otherwiseitisoff.
●DMXSTARTADDRESS
Each Projectormustbe givenaDMX startaddressso that thecorrectprojector respondstothecorrectcontrolsignals. ThisDMX start
address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the
controller.The Unithas1 DMXmode.Ithas6channels, so set the No. 1 projector’s address 001, No. 2 projector’s address 007,No.3
projector’s address 013, No. 4 projector’s address019,andsoon.
Launchtheprojector.Pressbutton ENTER more than2secondsto unlock panel.
Pressbutton ENTER to displayDMXaddress;
Pressbutton UP and DOWN, youcansettheaddress;
Pressbutton ENTER to confirm;after poweredonnexttime,the defaultwillbelastvalue saved
Pressbutton FUNC,it willreturnto theupper menu
.
●STAND-ALONEMODE
Operate the projector without connecting with a controller, enable the master mode through the operation panel, the
projector will run in Stand-Alone mode automatically.
DMX address can be set at any number within 512.
●MASTER/SLAVEMODE
Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First,
connect the first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR controlcable and then connect the second
fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way. Eventually connect the
last fixture’s DMX output to a DMX terminator. Set 1st projector as the master and others are Slaves.
StartAddressesofallSlavesare001;Operationmodeof the Master can be set any mode for a Master’ and Slaves’ operation mode can
besetaccordingly
AfterPoweredon,thegroup willrunin Master/SlaveMode
接回路插 DMXterminator 接控制器 DMX Controller 接电源 Power 从机 slave 主机 master
6. OPERATIONMENU
1stlevel menu
2ndlevel menu
3rdlevelmenu
4thlevelmenu
接电源
接控制器
DMX OUT
POWER OUTPOWER IN
DMX OUTDMX IN
POWER OUTPOWER IN
接回路插
从机 从机 主机

9/16
Address
001 -512
DMXAddress
ConfigSetup
MasterSlave
Slave
DefaultSlave
Master
LanguageSetup
English
Default：English
Chinese
Lcd LightSetup
On
Backlightwillbeoff
3minutesafternone
buttonispushed
Off
DisplayInvert
Yes
No
FactorySetting
Yes
PRMTransmit
Yes
cleanProgra
Yes
Motooffset
Color
Focus
-128-127
-128-127
MotoReset
Yes/No
Information
LEDTemperature
XX
FixtureuseTime
XXXX
SoftwareVersion
X.X.X
TestMode
AutoTest
Dimmer
000 -255
LEDbrightness
Color
000 -255
Motorposition
Focus
000 -255
Motorposition
OperationMode
DMX Mode
Yes
UserMemory
Yes
UserProgra Edit
（ET01~ET16）
Dimmer
000 -255
Strobe
000 -255
Color
000 -255
Focus
000 -255
KeepTime
000 –200(0-20S)
7. DMXPROTOCOL
ChannelNo.
Function
DMXValue
Description

10/16
8. TECHNICALDATA
1
Dimmer
000-255
2
DimmerFine
000-255
Dimmerin16bit
3
Strobe
000-007
No
008-255
Strobespeedfromslowto fast
4
Color wheel
000-009
White
010-019
White -Magenta
020-029
Magenta
030-039
Magenta–Orange
040-049
Orange
050-059
Orange -Yellow
060-069
Yellow
070-079
Yellow-Blue
080-089
Blue
090-099
Blue–Cyan
100-109
Cyan
110-119
Cyan-White
120-127
White
128-191
Clockwiserotationfromslowtofast
192-255
Anti-clockwiserotationfromslowto fast
5
Focus
000-255
Motorposition
6
Function
000-199
No
200-209
Motor reset
210-255
No

11/16
ELECTRIC SPECIFICATIONS
Inputvoltage:100V~240VAC，50/60Hz
Inputpower:100W@230V
Maximumcurrent:AC0.55A
Powerfactor：PF>90%
LIGHTSOURCESPECIFICATIONS
Qty 1pc
Power Consumption 90WLEDWhite
ManufacturersRated Lamp Life 50000hours
Colortemperature: 7500K
COLORS
1pccolorwheel(5colors+Open),continualrotation,magnetsensorpositioning
Function
1customized gobo
DIMMER
Linear Dimmer from0-100%
STROBE
ElectronicStrobe0-25FP.S.withpresetstrobepulse effect
BEAMANGLE
Beamangle:30°,motorized focus
CONTROL
Internationalstandard DMX512signalcontrolprotocol
DMX5123pin(Optional5pin)interfaces
Master/Slave synchronizedMode
Standalone mode,presetmode,selftest mode andstaticscene mode
3operationmodes(DMXmode,user memory,presetmemory)
OTHERFUNCTIONS
LCDscreen
DMX 512port for firmware upgrade,aconvenient andquickwayforfirmware upgradeviaDMXcable
Overtemperatureprotection
BuiltinNTCtemperaturedetecting function,IfLEDlampisoverheat, itspower willbedecreased intelligently
Fixturetime,DMX512channel valueand softwareversionwillbedisplayed
Displaycanbeinverted
HOUSING
Hightensile castAluminumalloy,IP65
NETWEIGHT
7.5Kg

12/16
OPERATIONTEMPERATURE:
Maximum ambient temperature 45℃
SIZES:
LIGHTOUTPUT:
投射距离 Distance 光斑直径 Diameter 光照度：Luminuousflux
9. CIRCUITDIAGRAMANDPCBCONNECTIONS
●CIRCUITDIAGRAM
DISTANCE (m)
2m
2m
0m 1m
1m
3m
3m
0 2.5 5 7.5 10 12.5
4791 1198 532 299 192 0
4m 5m
6m 7m
4m 5m
6m 7m
DIAMETER (m) 1.35 2.71 4.06 5.41 6.76
0

13/16
●PCBCONNECTIONS
No
Name

14/16
MasterBoard
Diverboard
10.COMPONENTORDERCODES
1
Thermal Sensor
2
Reserved
3
PWM signal
interface
4
Reserved
5
Power
6
Fan
7
Reserved
8
485 signalinterface
9
DMX signal
interface
10
Reserved
No
Name
1
Power
2
LED Driver

15/16
No.
Name
CodeNo.
Qty
Remarks
1
POWER SWITCH
6190000004
1
K18S-UP200S2424V/8.3A
200W,Kaihuibrand
2
LED 100 WWHITE LIGHT
SOURCE
6150000005
1
TX-3636W90FC120-NUVENG-
A01,Tianxin
3
STEPPINGMOTOR
6030040000
1
24BYJ48-51
4
STEPPING MOTOR
030040235A
1
25PM30005-04N 42×37×73
4coils,length 500mm,Ruibao
5
LED CONSTANTCURRENT
SUPPLYOFPR-6820
6230000010
1

16/16
PR LIGHTING LTD.
1582 XingyeAvenue,NancunPanyu
Guangzhou,511442 China
TEL:[phone]
PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified ifnecessary. Patented Products.
CounterfeitingWillbeProsecuted! P/N:
Version:
