Premier Mounts LPFM5080 User manual

INSTALLATION INSTRUCTIONS
LPFM5080
Universal Low Profile Flat Mount for 50” to 80” Flat Panels
NORTH AMERICA
3130 East Miraloma Avenue
Anaheim, CA 92806 USA
USA and Canada –
Phone: [phone]
Fax: [phone]
EUROPE
Swallow House,
Shilton Industrial Estate,
Shilton, Coventry, England CV79JY
Phone: [phone]
Fax: [phone]
Other Locations – Phone: [phone]; Fax: [phone]
©Premier Mounts 2009
9531-204-001-01

Page 2 Installation Instructions
Table of Contents
Warning Statements
LPFM5080
PRIOR TO THE INSTALLATION OF THIS PRODUCT, THE INSTALLATION INSTRUCTIONS SHOULD BE READ AND
COMPLETELY UNDERSTOOD. THE INSTALLATION INSTRUCTIONS MUST BE READ TO PREVENT PERSONAL INJURY AND
PROPERTY DAMAGE. KEEP THESE INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE LOCATION FOR FUTURE
REFERENCE.
PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS
PRODUCT FOR PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY UNAUTHORIZED
ATTACHMENTS OR MODIFICATIONS, AND IS NOT RESPONSIBLE FOR ANY DAMAGES, CLAIMS, DEMANDS, SUITS,
ACTIONS OR CAUSES OF ACTION OF WHATEVER KIND RESULTING FROM, ARISING OUT OF OR IN ANY MANNER
RELATING TO ANY SUCH USE, ATTACHMENTS OR MODIFICATIONS.
THE SURFACE MUST BE CAPABLE OF SUPPORTING AT LEAST FIVE TIMES THE WEIGHT OF THE FLAT PANEL. IF NOT, THE
MOUNTING STRUCTURE MUST BE REINFORCED. THE MAXIMUM WEIGHT THAT CAN BE USED WITH THIS PRODUCT
IS 300LBS. PROPER INSTALLATION PROCEDURE BY A QUALIFIED SERVICE TECHNICIAN, AS OUTLINED IN THE
INSTALLATION INSTRUCTIONS, MUST BE ADHERED TO. FAILURE TO DO SO COULD RESULT IN SERIOUS PERSONAL
INJURY, OR EVEN DEATH.
SAFETY MEASURES MUST BE PRACTICED AT ALL TIMES DURING THE ASSEMBLY OF THIS PRODUCT. USE PROPER SAFETY
GEAR AND TOOLS FOR THE ASSEMBLY PROCEDURE TO PREVENT PERSONAL INJURY.
Contact Premier Mounts with any questions
[phone]
[email protected]
At least two qualified people should perform the assembly procedure. Injury and/or damage can result from dropping or mishandling the
flat panel.
If mounting to studs, make sure that the mounting screws are anchored into the center of the studs. Use of an edge-to-edge stud finder is
recommended.
Be aware of the mounting environment. If drilling and/or cutting into the mounting surface, always make sure that there are no electrical wires
in wall. Cutting/drilling into an electrical line may cause serious injury.
Make sure there are no water lines inside the wall where the mount is to be located. Cutting/drilling into a water line may cause severe water
damage to the mounting surface.
This product is intended for indoor use only. Use of this product outdoors could lead to product failure and personal injury.
Do not install near sources of high heat. Do not install on a structure that is prone to vibration, movement or chance of impact.
Warning Statements 2
Parts List 3
Installation Tools 3
Hardware Pack 4
Features 5
Wood Stud Installation 6
Concrete Surface Installation 7
Determining the Mounting Hardware 9
Universal Spacer Installation 9
Universal Washer Installation 10
Mounting Bracket Installation 11
Attaching the Display to the Wall Plate 12
Securing the Flat Panel 12
Technical Specifications 13
Warranty 14

Installation Instructions Page 3
Parts List Congratulations on the purchase of your new Premier Mounts LPFM5080 flat panel mount. This mount
is shipped with all proper installation hardware and components. Make sure that none of these parts are
missing and/or damaged before beginning installation. If there are parts missing and/or damaged, please stop the
installation and contact Premier Mounts [phone].
Installation Tools (not supplied)
Wall Plate (Qty 1) Safety Security Screws (Qty 2)
Mounting Brackets (Qty 2)
LPFM5080
Universal Washer (Qty 6)
5/16” x 3” Lag Bolts (Qty 6) Flat Washers (Qty 6)
Universal Spacers (Qty 24)
Phillips Screwdriver 1/4” Drill Bit Electronic Stud Finder Drill Level
1/2” Socket and Socket
Wrench
Wood/Steel
Thread Depth Indicator
(Supplied)

Page 4 Installation Instructions
LPFM5080
Hardware Pack
Mounting Screws
M4 x 25mm (Qty 6)
M4 x 30mm (Qty 6)
M4 x 16mm (Qty 6)
M6 x 45mm (Qty 6)
M6 x 30mm (Qty 6)
M6 x 25mm (Qty 6)
M6 x 16mm (Qty 6)
M5 x 30mm (Qty 6)
M5 x 25mm (Qty 6)
M5 x 16mm (Qty 6)
M8 x 70mm (Qty 4)
M8 x 45mm (Qty 6)
M8 x 30mm (Qty 6)
M8 x 25mm (Qty 6)
M8 x 16mm (Qty 6)
M10 x 30mm (Qty 6)
If your unit requires alternative mounting hardware, use commercially available hardware or contact Premier Mounts [phone].

Installation Instructions Page 5
LPFM5080
Features
Visual Centering Diamond-
This will help in determining
the exact center of your flat
panel on the wall.
Low Profile Design -
Holds the flat panel less than
1” from the wall.
Cable/Electrical Cut Out -
Large cut outs on the wall
plate allow for easy cable
access and power
distribution.
Universal Spacers -
Uniquely designed spacers
that fit multiple screw sizes.
Mounting Slots -
Allow for a variety of stud
configurations and lateral
shift adjustments when
mounting your flat panel.

Page 6 Installation Instructions
LPFM5080
Wood Stud Installation
Step 1. The visual centering diamond will help
you visualize the center of your flat
panel. Place the wall plate against the
wall in the desired viewing location and
mark the center of the visual centering
diamond.
Step 2. If the location is acceptable, use a stud
finder to determine the exact center of
each stud.
Step 3. Once all of the studs have been located,
adjust the wall plate to match the closest
location of the center diamond mark
while hitting at least two found stud
positions with the mount. Use a pencil to
mark these mounting locations.
Stud Electronic
Studfinder
Mark
Step 4. Using a 1/4” drill bit, drill a pilot hole at
the first aligned and marked location.
Step 5. Insert one (1) 5/16” x 3” lag bolt and
washer into the mounting hole and
tighten (see WARNING: below) using a
1/2” socket.
1/2” Socket
Wrench
1/4” Drill
Bit
Wall Plate
5/16” Lag Bolt
and Flat Washer
It is recommended that two people perform the installation. One person should hold the mount while the other person
installs the wall plate.
Visual Centering Diamond - The visual centering diamond will guide you in determing the screen placement on the wall.
Do NOT over-tighten lag bolts when
attaching the mount to the wall.
Improper installation may result
in personal injury or damage to
property.
Only use 1/4” drill bit when drilling
the pilot holes.
IT IS STRONGLY RECOMMENDED TO SECURE THE WALL PLATE TO THREE WALL STUDS USING THE
PROVIDED SIX (6) LAG BOLTS AND SIX (6) FLAT WASHERS.

Installation Instructions Page 7
LPFM5080
Concrete Surface Installation
Step 6. With the help of an assistant, place a
level on the center of the mounting rail
and level the mount. Mark and drill the
second mounting hole.
Step 7. Insert one (1) 5/16” x 3” lag bolt and
washer into the mounting hole and
tighten. Repeat for the remaining mounting
points.
Level
Step 1. Place the wall plate into position against the
wall, keeping it level.
Step 2. Mark off six holes to be used for securing the
mount and place the wall plate aside.
Level
Mark
Concrete anchors are not supplied. Please
use commercially available hardware.
Follow the installation instructions as
provided with the hardware.
Do NOT over-tighten lag bolts when
attaching the mount to the wall. Improper
installation may result in personal injury
or damage to property.
You must secure the wall plate with a
minimum of four (4) lag bolts (2 for each
stud found).

Page 8 Installation Instructions
LPFM5080
Step 3. Next, drill holes using an electric drill
and masonry bit. The drill bit size that is
used will depend on the size of the
hardware used.
Step 4. Insert a concrete anchor into each hole.
Step 5. Use a hammer to lightly tap each anchor
into place so that they are flush with the
wall.
Drill
Step 6. Once all of the anchors are in place, move
the wall plate back into position.
Step 7. Attach nuts and washers to the threaded
shafts that are protruding from the wall.
Level the mount one more time and then
tighten the nuts. Do not overtighten the
wedge anchors.
Threaded Shaft
Mounting Hardware
Wall Plate
Socket Wrench
Solid SurfaceCinder Block

Installation Instructions Page 9
LPFM5080
Universal Spacers Installation
Determining the Mounting Hardware
Step 1. Insert the thread depth indicator (supplied) through the thread inserts found on the back of the flat panel.
Step 2. Using a pencil, mark the depth of the thread insert on the thread depth indicator (Figure 2).
Step 3. Compare and verify the depth of the remaining thread inserts.
Step 4. Locate the correct diameter screw for the thread insert.
Step 5. Compare your thread depth indicator marking to the screw length.
Figure 1
Figure 2 Figure 3
Inverted Flat
Panel Display
Marking the
Depth
Thread Insert
Thread Depth
Indicator
Thread Depth
Indicator
Marking
Screw
Marking
Screw
Thread Depth
Indicator
When using the universal spacers in
the installation, make sure to account
for the appropriate spacing depth
when measuring with the thread depth
indicator. Using the universal spacers
will change the overall length of the
hardware used.
If your selected screw is longer than
the marking on the thread depth
indicator, do not use this screw. The
screw length must not bypass the
marking. If so, select another screw
size (Figure 2 and 3) until you find the
screw the comes closest to your mark
without going past the marking.
You may not need to use any spacers for your particular flat panel.
The universal spacer may be stacked six (6) high, for a total stacking height of 1-1/2”. The universal spacers must be stacked in the
direction shown above. The universal spacers must be placed between the mounting bracket and the flat panel.
The universal spacer can fit M4, M5, M6 and M8 screws sizes.

Page 10 Installation Instructions
LPFM5080
M4
,
M5 M6
M8
The universal washer will fit M4, M5 M6 and M8 hole patterns that your flat panel requires.
EXAMPLE: If your flat panel uses M8 screws, use the M8 mounting points.
Universal Washer Installation
Pre-install the mounting screws, spacers and washers. Once mounted, push down to eliminate movement from the bracket. Then
proceed to tighten the rest of the hardware. Repeat this process for the installation of the remaining mounting bracket.

Installation Instructions Page 11
LPFM5080
To ensure optimal installation, this kit includes various screws of different diameters and lengths.
Mounting Bracket Installation
The number of mounting points will vary between manufacturers.
Select the spacer that is closest in depth to the recess to keep your bracket as close to the flat panel as possible.
Do NOT overtighten the screws.
Mounting Hardware
Universal Washer
Universal Spacer
Mounting Bracket
Mounting Point
Flat Panel
Step 1. Place your flat panel screen-side down on a soft, flat surface, and identify the threaded mounting points that are located on the
back of the flat panel.
Step 2. Determine the correct screw length by carefully inserting a straw or toothpick and mark the depth of the mounting point.
Step 3. If your flat panel has a curved back or a recessed mounting point, a universal spacer must be used.
Step 4. If needed, place the universal spacer between the mounting bracket and the flat panel.
Step 5. Please use a universal washer with each screw for added stability (see Universal Washer Installation, below).
Step 6. Attach each bracket to the flat panel by aligning the holes on each bracket with the threaded inserts on the back of your
flat panel. Secure the bracket to the flat panel by inserting a minimum of two (2) screws per bracket.
Do not overtighten the screws.

Page 12 Installation Instructions
LPFM5080
Step 1. Raise the flat panel (two people required) past the top and bottom mounting rails and slide the flat panel down slowly, keeping
it close to the wall, and engage the mounting brackets to the rails of the wall plate.
Solid Surface Cinder Block
Upper Rail
Lower Rail
Flat Panel
Side View
Top Rail
Bottom Rail
To ensure optimal installation, this kit includes various screws of different diameters and lengths.
Attaching the Display to the Wall Plate
The number of mounting points will vary between manufacturers.
Select the spacer that is closest in depth to the recess to keep your bracket as close to the flat panel as possible.
Do NOT overtighten the screws.
MAKE SURE THE LOCKING SECURITY BRACKET SCREW IS FLUSH WITH THE SECURITY SCREW TAB
BEFORE INSTALLATION (see Securing the Flat Panel, page 13).
Do not release the flat panel until the top and bottom hooks of the arms are resting fully on the upper and lower mounting
rails.

Technical Specifications
All measurements are in inches[mm].
Installation Instructions Page 13
LPFM5080
Solid SurfaceCinder Block
Securing the Flat Panel
Step 1. Insert and tighten the safety security screws with a Phillips head screw driver (please see inset to the right).
Safety Security Screw
SecurityScrew
Tab
Do not release the flat panel until the top and bottom hooks
of the arms are resting fully on the upper and lower mount-
ing rails.
MAKE SURE THE LOCKING SECURITY BRACKET
SCREW IS FLUSH WITH THE SECURITY SCREW
TAB BEFORE INSTALLATION.

PREMIER MOUNTS
LIMITED LIFETIME WARRANTY
What and Who is Covered by this Limited Warranty and for How Long
Premier Mounts warrants this product to be free from defects in material and workmanship for the lifetime of
the original owner of this product. The limited warranty is valid only for the original purchaser of the product.
What Premier Mounts Will Do
At the sole option of Premier Mounts, Premier Mounts will repair or replace any product or product part that is
defective. If Premier Mounts chooses to replace a defective product or part, a replacement product or part will
be shipped to you at no charge, but you must pay any labor costs.
What is Not Covered; Limitations
PREMIER MOUNTS DISCLAIMS ANY LIABILITY FOR DAMAGE TO MOUNTS, ADAPTERS, DIS-
PLAYS, PROJECTORS, OTHER PROPERTY, OR PERSONAL INJURY RESULTING, IN WHOLE OR IN
PART, FROM IMPROPER INSTALLATION, MODIFICATION, USE OR MISUSE OF ITS PRODUCTS.
PREMIER MOUNTS DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. PREMIER
MOUNTS IS NOT RESPONSIBLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUD-
ING BUT NOT LIMITED TO, INABILITY TO USE ITS PRODUCTS OR LABOR COSTS FOR REMOV-
ING AND REPLACING DEFECTIVE PRODUCTS OR PARTS. SOME STATES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
What Customers Must Do for Limited Warranty Service
If you discover a problem that you think may be covered by the warranty you MUST REPORT it in writing to
the address below within thirty (30) days. Proof of purchase (an original sales receipt) from the original con-
sumer purchaser must accompany all warranty claims. Warranty claims must also include a description of the
problem, the purchaser’s name, address, and telephone number. General inquiries can be addressed to Premier
Mounts Customer Service at 1-800-368-9700 Warranty claims will not be accepted over the phone or by fax.
Premier Mounts
Attn: Warranty Claim
3130 East Miraloma Ave.
Anaheim, CA 92806
How State Law Applies
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS WHICH VARY FROM STATE TO STATE.
Warranty
LPFM5080
Page 14 Installation Instructions
