Premio RCO-6000-CFL Series User manual

USER’S
MANUAL
RCO-6000-CFL Series
AI Edge Inference Computer

RCO-6000-CFL l User’s Manual
Table of Contents
2
Prefaces ……………………………………………………………………………………………….. 04
Revision ………………………………………………………..……………………………..……………….……….. 04
Disclaimer ……………………………………………………….…….……………….………………….………….. 04
Copyright Notice …………………………………….…….….………………………………….………………… 04
Trademarks Acknowledgment …………..………….………………………………………................... 04
Environmental Protection Announcement ……………………………………..……..……………….. 04
Safety Precautions ……………………………………………………………………………………….….…….. 05
Technical Support and Assistance ………………………………...……………………..…….…….……. 06
Conventions Used in this Manual …………………………………..……………………......….……….. 06
Package Contents ……………………………………………………………………..…..…………………….… 07
Ordering Information …………………………..……………………………………..………..….….………… 07
Optional Accessory …………...……………………………………................................................. 08
Chapter 1 Product Introductions ……………………………………………………..… 09
1.1 Overview ………………….………………………………..………….…………..……………….. 10
1.1.1 Key Feature ………….…………………..…………….……….…..…..…………....... 11
1.2 Hardware Specification ….………..………….....…………….……..……..……………… 12
1.3 System I/O ………..……………..……………………..……………………..…………………… 15
1.3.1 RCO-6000-CFL ………………………………………………………………...……....…. 15
1.3.2 RCO-6000-CFL-2 ..........................................................………………..… 17
1.3.3 RCO-6000-CFL-2-2PWR ..................................................……………..… 19
1.3.4 RCO-6000-CFL-2060S .....................................................……………..… 21
1.3.5 Universal I/O Bracket .....................................................……………..… 23
1.4 Mechanical Dimension ……………………..………………………..…..………….……….. 24
1.4.1 RCO-6000-CFL ………….…………………………………………………………………... 24
1.4.2 RCO-6000-CFL-2 ..........................................................………………..… 25
1.4.3 RCO-6000-CFL-2-2PWR ..................................................……………..… 26
1.4.4 RCO-6000-CFL-2060S .....................................................……………..… 27
Chapter 2 Switches and Connectors …………….……………………………………. 28
2.1 Switch and connector Locations ………………………………………..…….….…….... 29
2.1.1 Top View ………………………………………………………………………..…..……… 29
2.1.2 Bottom View ……………………………………………………………..……..……….. 30
2.2 Connector / Switch Definition ……………………………….……….…….……............. 31
2.3 I/O Interface Descriptions ........................................................................... 32
2.3.1 LPC Debug Con.................................................................................... 32
2.3.2 Power Con .......................................................................................... 33
2.3.3 DC IN/IGN IN (+9V ~ +48V) ................................................................. 34
2.3.4 COM Con ............................................................................................. 35
2.3.5 SF100 SPI Con ..................................................................................... 37
Chapter 3 System Setup …………………………..…………………………….…………… 67
3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and
unscrewing .……………………………………………………………………………………………. 68
3.2 Disconnecting expansion module from computing module ………............... 68
3.3 Removing chassis top cover …….………………………….…..….…….…..….…………... 70
3.4 Install HDD/SSD on the internal SATA bay ………..…………….….………………...... 71
3.5 Installing HDD on removable SATA HDD/SSD bay ………………………............... 73

RCO-6000-CFL l User’s Manual
3
3.7 Installing CPU ……………………...………………………………….….……………………...... 75
3.8 Installing Mini PCIe card ………..................................................................... 80
3.9 Installing M.2 2280 NVMe SSD ................................................................... 81
3.10 Installing WiFi Module ..………...…….………………….……………………..…………...... 82
3.11 Installing Mini PCIe card / 4GLTE………..…………………………………………………... 85
3.12 Installing Antenna ………………...…….………………….……………………..…………...... 86
3.13 Installing PCIe/PCI expansion Card(RCO-6000-CFL-2) ……………..…………...... 88
3.14 Installing graphic Card (RCO-6000-CFL-2060S) .….…………………..….………..... 90
3.15 Installing wall mount kit …………………………………….……………………..………...... 94
3.16 AC Adapter with 3P terminal block ….……....………………..……..……….……...... 96
3.17 AC Adapter with 4P terminal block ….……....………………..……..……….……...... 97
Chapter 4 BIOS Setup …………………………………………..……………..……………… 98
4.1 BIOS Introduction …….……….……………………………………….…….…..….…………... 99
4.2 Main Setup ……..……….………………….…………………………..….….………………...... 100
4.3 Advanced Setup …………………………………………..………………………………………… 101
4.3.1 Connectivity Configuration ..…………..…………………………..………….……. 102
4.3.2 CPU Configuration ……..………………………………..………..……………..……... 103
4.3.3 PCH-FW Configuration ………………..……………….………….……………..….... 104
4.3.4 SATA and RST Configuration …………………………………………..………….... 105
4.3.5 RST (UEFI RAID) Configuration ……………………………………….………….... 106
4.3.6 Trusted Computing ……………………………..……………….………………..….... 108
4.3.7 ACPI Settings ……………………………………………………….………………..….... 109
4.3.8 Super IO Configuration……………………….………………..…………………….... 110
4.3.9 Hardware Monitor………………………………………......………………..……..... 117
4.3.10 Serial Port Console Redirection ……………..………….………….….…….…....119
4.3.11 Network Stack Configuration ……………..…………………………..…………....120
4.3.12 CSM Configuration ……………………………..……………..……..…………………. 121
4.3.13 USB Configuration …………………………..………………………….………..…….. 122
4.4 Chipset ………..………………….…..….…..…………………………………………………..….... 123
4.4.1 System Agent (SA) Configuration ………….…………………..………………….. 123
4.4.2 PCH-IO Configuration ………….……………………….………………..…………….. 127
4.5 Security …………...….………………….…..….………………………………………..…………... 132
4.6 Boot …………...……….….………………….…..………………………..…………..……………... 135
4.7 Save & Exit …...……….….………………….…..….…..………………………………………..... 136
Appendix WDT & GPIO …………………………………………………………………………… 137
WDT Sample Code …….……………………….……………….……………..….…….…….…………... 138
GPIO Sample Code ………………………………………………………..…………………………………. 139
3.6 Installing SODIMM ……………...…………………………..….……………………………...... 74

RCO-6000-CFL l User’s Manual
4
Revision
Disclaimer
All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio
Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The
information in this document is subject to change without notice and does not represent a commitment on
the part of Premio Inc.
Premio Inc. disclaims all warranties, express or implied, including, without limitation, those of
merchantability, fitness for a particular purpose with respect to contents of this User’s Manual. Users must
take full responsibility for the application of the product.
Copyright Notice
All rights reserved. No part of this manual may be reproduced or transmitted in any form or by any means,
electronic or mechanical, including photocopying, recording, or information storage and retrieval systems,
without the prior written permission of Premio Inc. Copyright © Premio Inc.
Trademarks Acknowledgment
Intel®, Celeron® and Pentium® are trademarks of Intel Corporation.
Windows® is registered trademark of Microsoft Corporation.
AMI is trademark of American Megatrend Inc.
IBM, XT, AT, PS/2 and Personal System/2 are trademarks of International Business Machines Corporation
All other products and trademarks mentioned in this manual are trademarks of their respective owners.
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. Please recycle to minimize pollution
and ensure environment protection.
Prefaces
Revision
Description
Date
1.0
Manual Released
2020/11/01

RCO-6000-CFL l User’s Manual
5
Safety Precautions
Before installing and using the equipment, please read the following precautions:
Put this equipment on a reliable surface during installation. Dropping it or letting it fall could
cause damage.
The power outlet shall be installed near the equipment and shall be easily accessible.
Turn off the system power and disconnect the power cord from its source before making any
installation. Be sure both the system and the external devices are turned OFF. Sudden surge
of power could ruin sensitive components. Make sure the equipment is properly grounded.
When the power is connected, never open the equipment. The equipment should be opened
only by qualified service personnel.
Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
Disconnect this equipment from the power before cleaning. Use a damp cloth. Do not use
liquid or spray detergents for cleaning.
Avoid the dusty, humidity and temperature extremes.
Do not place heavy objects on the equipment.
If the equipment is not used for long time, disconnect it from the power to avoid being
damaged by transient over-voltage.
The storage temperature shall be above -30°C and below 85°C.
The computer is provided with a battery-powered real-time clock circuit. There is a danger of
explosion if incorrectly replaced. Replace only with the same or equivalent type
recommended by the manufacturer.
If one of the following situation arises, get the equipment checked be service personnel:
•The power cord or plug is damaged.
•Liquid has penetrated into the equipment.
•The equipment has been exposed to moisture.
•The equipment does not work well or it cannot work according the user’s manual.
•The equipment has been dropped and damaged.
•The equipment has obvious signs of breakage.
Preface

RCO-6000-CFL l User’s Manual
6
Preface
This indication alerts operators to an operation that, if not strictly observed,
may result in severe injury.
WARNING
This indication alerts operators to an operation that, if not strictly observed,
may result in safety hazards to personnel or damage to equipment.
CAUTION
This indication provides additional information to complete a task easily.
NOTE
Technical Support and Assistance
1. Visit the Premio Inc website at https://premioinc.com where you can find the latest information
about the product.
2. Contact your distributor, our technical support team or sales representative for technical support if
you need additional assistance. Please have following information ready before you call:
Model name and serial number
Description of your peripheral attachments
Description of your software (operating system, version, application software, etc.)
A complete description of the problem
The exact wording of any error messages
Conventions Used in this Manual

RCO-6000-CFL l User’s Manual
7
Package Contents
Before installation, please ensure all the items listed in the following table are included in the package.
Preface
Item
Description
Q’ty
1
RCO
-6000-CFL Series AI Edge Inference Computer 1
2
Wall Mount Kit
1
3
Accessory Kit
1
4
DVI to VGA Adapter
1
Ordering Information
Model No. Product Description
RCO-6000-CFL Industrial Computer with LGA 1151 for Intel® 8th/9th Gen CPU & Q370 PCH, 2x LAN
RCO-6000-CFL-2 Industrial Computer with LGA 1151 for Intel® 8th/9th
Gen CPU & Q370 PCH, 2x LAN,
2x PCI/PCIe
RCO-6000-CFL-2-2PWR Industrial Computer with LGA 1151 for Intel® 8th/9th
Gen CPU & Q370 PCH, 2x LAN,
Dual Power Input
Available Module：
•4L：4x LAN Ports
•4P：4x LAN PoE Ports
•D10G：2x 10Gb Ports
•4U3：4x USB 3.2 Gen 1 Ports
•5G：2x 5G SIM Slots
•4LM12：4x M12 LAN Ports
•4PM12：4x M12 LAN PoE Ports
Available Module：
•4L：4x LAN Ports
•4P：4x LAN PoE Ports
•D10G：2x 10Gb Ports
•4U3：4x USB 3.2 Gen 1 Ports
•5G：2x 5G SIM Slots
•4LM12：4x M12 LAN Ports
•4PM12：4x M12 LAN PoE Ports
Available Expansion：
•2C：1x PCIe x16 and 1x PCI •2E：2x PCIe x8 •2I：2x PCI
Available Module：
•4L：4x LAN Ports
•4P：4x LAN PoE Ports
•D10G：2x 10Gb Ports
•4U3：4x USB 3.2 Gen 1 Ports
•5G：2x 5G SIM Slots
•4LM12：4x M12 LAN Ports
•4PM12：4x M12 LAN PoE Ports

RCO-6000-CFL l User’s Manual
8
Preface
Model No. Product Description
RCO-6000-CFL-2060S Industrial Computer with LGA 1151 for Intel® 8th/9th
Gen CPU & Q370 PCH, 2x LAN,
RTX 2060 Super Integrated
Available Module：
•4L：4x LAN Ports
•4P：4x LAN PoE Ports
•D10G：2x 10Gb Ports
•4U3：4x USB 3.2 Gen 1 Ports
•5G：2x 5G SIM Slots
•4LM12：4x M12 LAN Ports
•4PM12：4x M12 LAN PoE Ports
Optional Accessories
Model No. Product Description
1
-E09A22801
Adapter AC/DC 24V/11.67A 280W with 3pin Terminal Block Plug
5.0mm Pitch
1
-E09A22102
Adapter AC/DC 24V 9.2A 220W with 3pin Terminal Block Plug
5.0mm Pitch, GST220A24
-CT1
SFICBL022
Power Cord, 3
-pin US Type, 180cm
1
-TPCD00002
Power Cord, European Type, 180cm
1
-TPCD00001
Power Cord, 3
-pin UK Type, 180cm

Chapter 1
Product Introductions

RCO-6000-CFL l User’s Manual
10
1.1 Overview
Based on 9th Gen. Intel® Core™ i7-9700E (4.4GHz, 8 Cores) / i5-9500E (4.2GHz, 6 Cores) / i3-9100E
(3.7GHz, 4 Core) / i7-9700TE (3.8GHz, 8 Cores) / i5-9500TE (3.6GHz, 6 Cores) / i3-9100TE (3.2GHz,
4 Core) or 8th Gen. Intel® Core™ i7-8700T (4.0GHz, 6 Cores) / i5-8500T (3.5GHz, 6 Cores) / i3-8100T
(3.1GHz, 4 Cores) or Pentium® G5400T (3.1GHz, Dual Core) / Celeron® G4900T (2.9GHz, Dual Core)
Desktop processor, RCO-6000-CFL series is an extreme features integration, outstanding system
performance, versatile I/O connections, and rugged reliability fanless embedded systems. It offers
dramatically enhanced CPU and graphics performance, wide power and feature scalability, and
advanced features, modularize expansion I/O, rich connectivity interfaces, wide range (9~48V) DC
power input, and high reliability even operating in temperature extremes (-25 ° C~70 ° C).
Featuring with completely cable-less designed, high functional, one-piece housing design, and anti-
vibration, RCO-6000-CFL series are ruggedized systems that can operate in harsh environments and easy
to install and maintain. A build in over voltage protection (OVP), over current protection (OCP), reverse
protection, and wide range DC power input makes RCO-6000-CFL series are safety system for all
industrial applications.
Chapter 1: Product Introductions
Model No. Rear Panel Front Panel
RCO-6000-CFL
RCO-6000-CFL-2
(2x PCI/PCIe)
RCO-6000-CFL-2-2PWR
(Dual Power Input)
RCO-6000-CFL-2060S
(RTX 2060 Super integrated)

RCO-6000-CFL l User’s Manual
11
Chapter 1: Product Introductions
1.1.1 Key Features
LGA 1151 socket for 8th/9th Gen. Intel® CFL-R S Processor Pentium® / Celeron® Desktop Processor
Intel® Q370 chipset
2x DDR4 2400/2666Hz SODIMM. Max. up to 64GB
Triple Independent Display by 1x DVI-I and 2x DisplayPort
2x Intel® GbE supporting Wake-on-LAN and PXE
2x Full-size mini PCIe for communication or expansion modules, 2x SIM socket
4x 2.5” SATA HDD Bay and 1x mSATA with RAID 0, 1, 5, 10 support
1x M.2 (M Key, PCIe x4, 2280, Support NVMe), 1x M.2 (E Key, PCIe x2, 2230, USB 2.0, Support CNVi)
6x RS-232/422/485 (w/ 2x internal), 4x USB 3.2 Gen 2, 5x USB 3.2 Gen 1
8x DI + 8x DO with isolation
9 to 48VDC Wide Range Power Input Supporting AT/ATX Mode
Wide Operating Temperature -25°C to 70°C (35W CPU); -25°C to 60°C (65W CPU)
TPM 2.0 Supported
Power ignition management

RCO-6000-CFL l User’s Manual
12
1.2 Hardware Specification
Chapter 1: Product Introductions
System
Processor
Support 8th/9th Gen Intel® CFL-R S Processor (LGA 1151, 65W/35W
TDP)
•Inte® lCore™ i7-9700E, 8 Cores, 12MB cache, up to 4.4 GHz
•Intel® Core™ i5-9500E, 6 Cores, 9MB Cache, up to 4.2 GHz
•Intel® Core™ i3-9100E, 4 Core, 6MB Cache, 3.7 GHz
•Intel® Core™ i7-9700TE, 8 Cores, 12MB cache, up to 3.8 GHz
•Intel® Core™ i5-9500TE, 6 Cores, 9MB Cache, up to 3.6 GHz
•Intel® Core™ i3-9100TE, 4 Core, 6MB Cache, 3.2 GHz
•Intel® Core™ i7-8700T, 6 Cores, 12MB cache, up to 4.0 GHz
•Intel® Core™ i5-8500T, 6 Cores, 9MB Cache, up to 3.5 GHz
•Intel® Core™ i3-8100T, 4 Cores, 6MB Cache, 3.1 GHz
•Intel® Pentium® G5400T, 2 Cores, 4MB Cache, up to 3.1 GHz
•Intel® Celeron® G4900T, 2 Cores, 2MB Cache, up to 2.9 GHz
System Chipset Intel® Q370 Express Chipset
LAN Chipset GbE1: Intel I219LM (Support Wake-on-LAN
and PXE)
GbE2: Intel I210-AT (Support Wake-on-LAN
and PXE)
GbE3~GbE6: Intel I350-AM4 (Optional)
10 GbE1~GbE2: Intel X710-AT2 (Optional)
Audio Codec Realtek ALC888S
System
Memory
2x 260-Pin DDR4 2400/2666MHz SODIMM.
Max. up to 64GB (Un-buffered and Non-
ECC)
Graphics Intel® UHD Graphics 610/630
RCO-6000-CFL-2060S only：
NVIDIA GeForce ® RTX 2060 Super
BIOS AMI 256Mbit SPI BIOS
Watchdog Software Programmable Supports 1~255
sec. System Reset
TPM TPM 2.0
Display
DisplayPort 2x DisplayPort, support resolution 4096 x 2304
DVI 1x DVI-I, support resolution 1920 x 1200
Multiple Display Triple Display
VGA Yes (by optional split cable)
Display (RCO-6000-CFL-2060S Only)
DisplayPort 3x DisplayPort
DVI 1x DVI-I, 1x DVI-D
HDMI 1x HDMI
Multiple Display 6 Display interfaces
Storage
SSD/HDD 2x Internal 2.5" SATA HDD Bay (support H=9mm)
2x Removable 2.5" SATA HDD Bay (support H=7mm, hot-swappable) Support RAID 0, 1, 5, 10
mSATA 1x mSATA (Shared by 1x Mini PCI Express)
M.2 1x M.2 (M Key, PCIe x4, 2280, Support NVMe),
1x M.2 (E Key, PCIe x2, 2230, USB 2.0, Support CNVi)
SIM Socket 2x External SIM socket
Expansion
Mini PCI Express 2x Full-size Mini PCIe
PCIe 1x PCIe x16 for GPU Card
Expansion Modules
Occupied One Universal I/O Slot:
•LAN/PoE or M12 LAN/PoE Module：
4-port GbE module with Intel® I350 Chipset, RJ-45 or M12 connector (PoE optional)
•D10G Module：
2-Port RJ45 10GbE with Intel X710 Chipset
•USB Module：
4-Port USB with Renesas uPD720201K8 host controller (share PCIe Gen2 x1 bandwidth)
•5G Module：
1x M.2 for 5G (B Key, PCIe x1, USB 3.0, 3042/3052), Including 2x SIM socket,
1x SIM switch (1x Universal Slot Only)

RCO-6000-CFL l User’s Manual
13
Chapter 1: Product Introductions
Operating System
Windows Windows 10
Linux Linux kernel 5.X
Power
Power Adapter
Optional AC/DC 24V/9.2A, 220W
Optional AC/DC 24V/11.67A, 280W
RCO-6000-CFL-2060S：
Optional AC/DC 24V, 220W/280W
Optional AC/DC 24V, 220W for GPU
Power Mode AT, ATX
Power Ignition Sensing Power Ignition Management
Power Supply Voltage
9~48VDC
RCO-6000-CFL-2060S：
2x Power Input：
9~48VDC, 12~48VDC for GPU
Power Connector
3-pin Terminal Block
RCO-6000-CFL-2060S：
3-pin Terminal Block
4-pin Terminal Block for GPU
(12V requires 4-pin terminal block)
Power Protection
OVP (Over Voltage Protection);
OCP (Over Current Protection)
Reserve Protection
I/O
Audio 1x Mic-in, 1x Line-out
COM 4x RS-232/422/485, 2x RS-232/422/485 (internal)
DIO 8 in / 8 out (Isolated)
LAN 2x RJ45
Universal I/O Bracket 1x Universal I/O Bracket (By mini PCIe interface)
USB 4x USB 3.2 Gen 2 (10 Gbps)
5x USB 3.2 Gen 1 (5 Gbps)
1x USB 3.2 Gen 1 header (5 Gbps, internal)
Others 5x WiFi Antenna Holes
1x Power Switch, 1x AT/ATX Switch,
1x Remote Power On/Off
1x PC/Car Mode Switch
1x Delay Time Switch
1x Removable CMOS Battery

RCO-6000-CFL l User’s Manual
14
Chapter 1: Product Introductions
Environment
Operating Temp. -25°C to 70°C (35W CPU) ; -25°C to 60°C (65W CPU)
RCO-6000-CFL-2060S：
-25°C to 60°C (35W/65W CPU)
Storage Temp. -30°C to 85°C
Relative Humidity 10% to 95% (non-condensing)
Standards / Certification CE, FCC Class A,
E-Mark, EMC Conformity with EN 50155, EN 50121-3-2
Vibration With SSD: 3 Grms, 5 - 500 Hz, 0.5 hr/axis
With HDD: 1 Grms, 5 - 500 Hz, 0.5 hr/axis
Shock With SSD: 50G, half sine, 11ms
RCO-6000-CFL-2060S：
With SSD: 20G, half sine, 11ms
Physical
Construction Extruded Aluminum with Heavy Duty Metal
Dimension •RCO-6000-CFL：
240 (W) x 261 (D) x 79.2 (H) mm
•RCO-6000-CFL-2, RCO-6000-CFL-2-2PWR, RCO-6000-CFL-2060S：
240 (W) x 261 (D) x 127.2 (H) mm
Weight •RCO-6000-CFL：7.5 ~ 8.25 kg
•RCO-6000-CFL-2：8.25 ~ 9.3 kg
•RCO-6000-CFL-2-2PWR：8.25 ~ 9.3 kg
•RCO-6000-CFL-2060S：9.5 ~ 10.4 kg
Mounting Wall Mounting
* For 10th Gen Intel CPUs configured to run at 65W, operating temperatures will be limited to 70°C. (RCO-6000-CFL-2060S 60°C)
** 65W CPUS may experience thermal throttling depending on extreme application workloads; this is also due to an increase in the physical
CPU cores from the Intel silicon (up to 10 cores). Please note, this does not indicate system malfunction or problems in the fanless design.
Please consult our embedded engineers for the best configuration to match your application requirements.
*** All specifications and photos are subject to change without notice.

RCO-6000-CFL l User’s Manual
15
Chapter 1: Product Introductions
1.3 System I/O
1.3.1 RCO-6000-CFL
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.2 Gen 2 port (10 Gbps)
Used to connect USB 3.2 device
USB 3.2 Gen 1 port (5 Gbps)
Used to connect USB 3.2 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM4
support RS232/422/485 serial device
Line-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Universal I/O Bracket
Used to customized I/O output
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional
Mini-PCIe WiFi module
LAN Port
Used to connect the system to a local area
network
PoE Port
Used to connect the system to a local area
network with power over Ethernet
SSD/HDD port
Removable 2.5" SATA HDD Bay
(support H=7mm,hot-swappable,
Support RAID 0,1,5,10
Internal 2.5" SATA HDD Bay(support H=9mm)
Front Panel

RCO-6000-CFL l User’s Manual
16
Chapter 1: Product Introductions
DC IN
Used to plug a DC power input with terminal
block
Digital I/O Terminal Block
The Digital I/O terminal block supports 8 digital
input and 8 digital output
COM port
COM1 ~ COM2 support
RS232/422/485 serial device
DVI-I port
Used to connect a DVI monitor or connect
optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.2 Gen 2 port (10 Gbps)
Used to connect USB 3.2 device
LAN port
Used to connect the system to a local area
network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal
block
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module
RCO-6000-CFL Rear Panel

RCO-6000-CFL l User’s Manual
17
Chapter 1: Product Introductions
1.3.2 RCO-6000-CFL-2
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.2 Gen 2 port (10 Gbps)
Used to connect USB 3.2 device
USB 3.2 Gen 1 port (5 Gbps)
Used to connect USB 3.2 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM4
support RS232/422/485 serial device
Line-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Universal I/O Bracket
Used to customized I/O output
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional
Mini-PCIe WiFi module
LAN Port
Used to connect the system to a local area
network
PoE Port
Used to connect the system to a local area
network with power over Ethernet
SSD/HDD port
Removable 2.5" SATA HDD Bay
(support H=7mm,hot-swappable,
Support RAID 0,1,5,10
Internal 2.5" SATA HDD Bay(support H=9mm)
Front Panel
Top Module (Industrial Fanless PC on Top)

RCO-6000-CFL l User’s Manual
18
Chapter 1: Product Introductions
DC IN
Used to plug a DC power input with terminal
block
Digital I/O Terminal Block
The Digital I/O terminal block supports 8 digital
input and 8 digital output
COM port
COM1 ~ COM2 support
RS232/422/485 serial device
DVI-I port
Used to connect a DVI monitor or connect
optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.2 Gen 2 port (10 Gbps)
Used to connect USB 3.2 device
LAN port
Used to connect the system to a local area
network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal
block
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module
RCO-6000-CFL-2 Rear Panel
Top Module (Industrial Fanless PC on Top)
Expansion
PCIe & PCI Slot
Bottom Module (Flexible and Dedicated “EDGEboost Nodes” on Bottom)

RCO-6000-CFL l User’s Manual
19
Chapter 1: Product Introductions
1.3.3 RCO-6000-CFL-2-2PWR
ATX power on/off switch
Press to power-on or power-off the system
Reset switch
Press to reset the system
USB 3.2 Gen 2 port (10 Gbps)
Used to connect USB 3.2 device
USB 3.2 Gen 1 port (5 Gbps)
Used to connect USB 3.2 device
AT/ATX mode select switch
Used to select AT or ATX power mode
Clear CMOS
Used to clear CMOS
SIM card
Used to insert SIM card
COM port
COM1 ~ COM4
support RS232/422/485 serial device
Line-out
Used to connect a speaker
Mic-in
Used to connect a microphone
Universal I/O Bracket
Used to customized I/O output
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Watchdog LED
Indicates the status of the watchdog active
GPIO LED
Indicates the status of the customer define
Ethernet LEDs
Indicates the status of the LAN active
Antenna hole
Used to connect an antenna for optional
Mini-PCIe WiFi module
LAN Port
Used to connect the system to a local area
network
PoE Port
Used to connect the system to a local area
network with power over Ethernet
SSD/HDD port
Removable 2.5" SATA HDD Bay
(support H=7mm,hot-swappable,
Support RAID 0,1,5,10
Internal 2.5" SATA HDD Bay(support H=9mm)
Front Panel
Top Module (Industrial Fanless PC on Top)
Fan
Hot-Swappable Fan Exhaust design for
easy maintenance
Bottom Module
(Flexible and Dedicated
“EDGEboost Nodes” on Bottom)

RCO-6000-CFL l User’s Manual
20
Chapter 1: Product Introductions
DC IN
Used to plug a DC power input with terminal
block
Digital I/O Terminal Block
The Digital I/O terminal block supports 8 digital
input and 8 digital output
COM port
COM1 ~ COM2 support
RS232/422/485 serial device
DVI-I port
Used to connect a DVI monitor or connect
optional split cable for dual display mode
DisplayPort
Used to connect a DisplayPort monitor
USB 3.2 Gen 2 port (10 Gbps)
Used to connect USB 3.2 device
LAN port
Used to connect the system to a local area
network
Remote Power on/off Terminal Block
Used to plug a remote power on/off terminal
block
Antenna hole
Used to connect an antenna for optional Mini-
PCIe WiFi module
RCO-6000-CFL-2-2PWR Rear Panel
Top Module (Industrial Fanless PC on Top)
DC IN
12~48VDC for GPU/Card Expansion
Bottom Module (Flexible and Dedicated “EDGEboost Nodes” on Bottom)
