Presentation Switchers PS110 Manual

Programmers Guide
PS110
August, 2014 • PN: DOC-000024-00a
Presentation
Switchers
digital presentation systems

Page 2 Presentation Switchers, Inc.
Trademark Informaon
Trademark Informaon
Presentaon Switchers®, the “PS Box” logo or icon, and the names and marks associated with Presentaon
Switchers’ products are trademarks and/or service marks of Presentaon Switchers, Inc., and are registered
and/or common-law marks in the United States and various other countries.
All other trademarks are the property of their respecve owners.
Patent Informaon
Patent Informaon
The accompanying product is protected by one or more U.S. and foreign patents and/or pending patent
applicaons held by Presentaon Switchers, Inc.
Customer Feedback
Customer Feedback
We are constantly working to improve the quality of our documentaon, and we would appreciate your
feedback. Please send email to sales@PSwitchers.com.
© 2014 Presentaon Switchers, Inc. All rights reserved.
Presentaon Switchers, Inc.
2324 Cheney-Spokane Road
Cheney, WA 99004 USA
No part of this document may be reproduced or transmied in any form or by any means, electronic or
mechanical, for any purpose, without the express wrien permission of Presentaon Switchers, Inc.
Under the law, reproducing includes translang into another language or format. As between the pares,
Presentaon Switchers, Inc., retains tle to and ownership of all proprietary rights with respect to the so-
ware contained within its products. The soware is protected by United States copyright laws and interna-
onal treaty provision. Therefore, you must treat the soware like any other copyrighted material (e.g., a
book or sound recording).
Every effort has been made to ensure that the informaon in this manual is accurate. Presentaon Switch-
ers, Inc., is not responsible for prinng or clerical errors.
Informaon in this document is subject to change without noce.

Page 3PS110 Programmers Guide
Contents
Contents ............................................................................................3
Introduction .......................................................................................4
Auto-Sense, Auto-Switching ........................................................................... 4
Controlling the PS110 using Infra-Red (IR) ................................................... 4
Front View ....................................................................................................... 4
Manual Control .................................................................................5
Selecting a New Source Device to Display ................................................... 5
Selecting a New Source Device to Display
(Using IR Remote) ............................................................................................ 5
IR Control Codes ..............................................................................6
IR Control Codes ............................................................................................. 6

Page 4 Presentation Switchers, Inc.
Auto-Sense, Auto-Switching
Auto-Sense, Auto-Switching
In many situaons a control system is oen unnecessary, complicated, costly, and confusing.
With the PS110, when a new device is connected to the system that device is immediately
switched to the display. This feature is especially useful in board room and collaborave
presentaon systems.
Controlling the PS110 using Infra-Red (IR)
Controlling the PS110 using Infra-Red (IR)
The PS110 Presentaon Switcher can be controlled externally by using Infra-Red (IR) control
methods. This means that the third party controller will generate IR pulses with direct line-of-
sight to the IR Sensor on the PS110. Many programmers will place an IR emier directly on
the PS110’s IR Sensor to ensure no other device (or person) interferes with the control of the
switcher.
Getting to Know the PS110
Getting to Know the PS110
The graphic below points out key control elements of the PS110 enclosure.
Front View
Front View
Introduction
IR (Infra-Red) Sensor
Source Selector Active Source Indicator
Connect Sources Devices Here

Page 5PS110 Programmers Guide
Manual Control
Note: Selecng an input for a source that is not physcially connected will cause the output
display to indicate that the signal has been lost or disconnected.
Selecting a New Source Device to Display
Selecting a New Source Device to Display
To display a new source, press the Source Selector buon on the Front of the PS110 repeatedly
unl the LED on the Acve Source Indicator corresponds to the desired Source Port Selecon.
That image should now be visible on the Display Output and can be heard on the Stereo Audio
Output connectors.
Selecting a New Source Device to Display
Selecting a New Source Device to Display
(Using IR Remote)
(Using IR Remote)
From the IR Remote controller, shown below, select the Right or Lebuons unl the desired
Source is selected. Right advances to the next higher Source Device port. If the front panel is
viewable, you will see the Acve Source Indicator change when each buon is pressed.

Page 6 Presentation Switchers, Inc.
IR Control Codes
IR Control Codes
IR Control Codes
Some programmers depend on “learning” a remote to obtain the IR control codes. This will
work fine; however, Presentaon Switchers provides a list of IR codes for those without learners
or for programmers that don’t want to rely on inexact analog listening devices to acquire these
codes. Below is a list of these IR control codes. Many of you will cut and paste this list into your
programming soware.
Button Press IR Code
Right 0000 006D 0022 0002 0155 00AA 0015 0015 0015 0040 0015 0015
0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0040
0015 0015 0015 0040 0015 0040 0015 0040 0015 0040 0015 0040
0015 0040 0015 0015 0015 0040 0015 0015 0015 0040 0015 0015
0015 0015 0015 0015 0015 0015 0015 0040 0015 0015 0015 0040
0015 0015 0015 0040 0015 0040 0015 0040 0015 0040 0015 05ED
0155 0055 0015 0E47
Left 0000 006D 0022 0002 0155 00AA 0015 0015 0015 0040 0015 0015
0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0040
0015 0015 0015 0040 0015 0040 0015 0040 0015 0040 0015 0040
0015 0040 0015 0015 0015 0015 0015 0015 0015 0040 0015 0015
0015 0015 0015 0015 0015 0015 0015 0040 0015 0040 0015 0040
0015 0015 0015 0040 0015 0040 0015 0040 0015 0040 0015 05ED
0155 0055 0015 0E47
