5. If no key is pressed, the unit exits MENU after 10 seconds. disappears from
the display.
Note: UP/DN keys (14) on the microphone have the same effect as the
rotation of the rotary CH knob (3). PTT switch (13) validates the last setting
and exists MENU. disappears.
1) COLOR
This function allows to choose the backlight color of the LCD.
Press the Fkey (9) to enter MENU. is displayed.
1. Turn the rotary CH knob (3) or use UP/DN keys (14) on the microphone to
select the COLOR function.
2. Press the Fkey (9) to validate. The current COLOR blinks on LCD.
3. Turn the rotary CH knob (3) or use UP/DN keys (14) on the microphone to
select the color. 7 available colors over and over :
4. New press on the Fkey (9) to validate the chosen color. The parameter
stops blinking. a) Go to point 1to adjust another function or b) Press the
PTT switch (13) to validate and exit MENU. disappears from the display.
5. If no key is pressed, the unit exits MENU after 10 seconds, disappears from
the display.
Default COLOR is (orange).
2) DIM
The DIM function (dimmer) allows to adjust the brightness (from1to 9) of
the backlight or OF (no backlight).
Press the Fkey (9) to enter MENU. is displayed.
1. Turn the rotary CH knob (3) or use UP/DN keys (14) on the microphone to
select the DIM function.
2. Press the Fkey (9) to validate. The current value blinks on LCD.
3. Turn the rotary CH knob (3) or use UP/DN keys (14) on the microphone to
select a new value.
4. New press on the Fkey (9) to validate. The parameter stops blinking. a)
Go to point 1to adjust another function or b) Press the PTT switch (13) to
validate and exit MENU. disappears.
5. If no key is pressed, the unit exits MENU after 10 seconds, disappears from
the display.
Default DIMMER value is 9.
3) KEY BEEP
When the function is activated, a beep sounds when a key is pressed, by
changing the channel etc. “BP” appears on the display when the function
is active.
Press the Fkey (9) to enter MENU. is displayed.
1. Turn the rotary CH knob (3) or use UP/DN keys (14) on the microphone to
select the KEyBP function.
2. Press the Fkey (9) to validate. The current status blinks on LCD.
3. Turn the rotary CH knob (3) or use UP/DN keys (14) on the microphone to
activate On / deactivate Of the function.
4. New press on the Fkey (9) to validate. The parameter stops blinking. a)
Go to point 1to adjust another function or b) Press the PTT switch (13) to
validate and exit MENU. disappears.
5. If no key is pressed, the unit exits MENU after 10 seconds, disappears from
the display.
Default KEY BEEP is On.
4) ROGER BEEP
When the function is active, the icon appears on the display.
The Roger Beep sounds when the PTT switch (13) on the microphone is re-
leased in order to let your correspondent speak. Historically as transceiver
is a “simplex” communication mode, it is not possible to speak and to listen
at the same time (as it is the case with a telephone). Once someone had
finished talking, he said “Roger” in order to prevent his correspondent that
it was his turn to talk. The word “Roger” has been replaced by a significant
beep. There comes “Roger beep” from.
Press the Fkey (9) to enter MENU. is displayed.
1. Turn the rotary CH knob (3) or use UP/DN keys (14) on the microphone to
select the RG BP function.
2. Press the Fkey (9) to validate. The current status blinks on LCD.
3. Turn the rotary CH knob (3) or use UP/DN keys (14) on the microphone to
activate On / deactivate Of the function.
4. New press on the Fkey (9) to validate. The parameter stops blinking. a)
Go to point 1to adjust another function or b) Press the PTT switch (13) to
validate and exit MENU. disappears.
5. If no key is pressed, the unit exits MENU after 10 seconds, disappears from
the display.
Default ROGER BEEP is Of.
5) SWR ADJUSTMENT
This function allows to adjust the SWR (Standing Wave Ratio) by beep tones.
Press the Fkey (9) to enter MENU. is displayed.
