Prestige PE2RELCDZ User manual

12019 Voxx Electronics Corporation. All rights reserved.
Owner’s Guide
For Models:
PE2RELCDZ
IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is
applicable to most vehicles. However, due to the conguration of some vehicles, some functions AND/OR
SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.
FLRS / FLCAN(RS)
RF Upgrade Kit

2FLRS_FLCAN(RS)_PE2RELCDZ Owners REV . 0
Table of Contents
Using Your Remote Control.................................................................... 3
Locking the Doors ............................................................................. 3
Unlocking the Doors .......................................................................... 3
Two Stage Door Unlock (optional)..................................................... 3
Activating Trunk Release (optional)................................................... 3
Activating AUX Output (optional)....................................................... 3
Using the Personal Protection Alarm................................................. 3
Using Your Remote Vehicle Starter ....................................................... 4
Remote Starting Your Vehicle............................................................ 4
Remote Start Shutdown .................................................................... 4
Entering Your Vehicle while it is Running via Remote Start .............. 4
Preheating or Precooling the Vehicle’s Interior ................................. 4
Remote Start Safety Features........................................................... 4
Using the “Quick-Stop” Feature......................................................... 5
Status LED, Light Flashes and Siren/Horn Indications ....................... 5
Additional 2-Way LCD Remote Control Functions............................... 6
Programming Remote Controls ............................................................. 7
Replacing Remote Control Batteries..................................................... 7
Warranty Information .............................................................................. 8

32019 Voxx Electronics Corporation. All rights reserved.
Two Stage Door Unlock (Optional)
If this feature is enabled on your system, pressing the button one time will unlock
only the driver’s door. Press again within three seconds to unlock the remaining
doors.
Activating the Trunk Release Feature (Optional)
If this feature is enabled on your system, pressing and holding the button for three
(3) seconds will open the vehicle’s trunk or hatch.
Door Lock
To lock the vehicle doors press and release the button.
NOTE: The system is equipped with a feature called Silent Choice. If enabled, the
system requires a second press of the button to activate an audible arming response
from the vehicle.
Door Unlock
To unlock the vehicle doors press and release the button.
NOTE: The system is equipped with a feature called Silent Choice. If enabled, the
system requires a second press of the button to activate an audible arming response
from the vehicle.
Activating the AUX Ch. 1 / 2 Output (Optional)
AUX channel output is an optional feature and programming is required at the time of
installation. Please consult your dealer for more information.
Using the Personal Protection Alarm (Panic)
Press and hold the or button for three (3) seconds to activate the personal
protection alarm. During panic mode, the normal function of the transmitter buttons will
be suspended. The transmitter’s and buttons can be used to lock and unlock the
door (if the option is installed). To stop the alarm, press and hold the or button on
the transmitter again for 3 seconds. The system will automatically stop after thirty (30)
seconds.
*Throughout this manual, ‘press’ refers to pressing for less than 1 second; ‘press and hold’ refers to pressing for more
than 3 seconds.
Using Your Remote Control

4FLRS_FLCAN(RS)_PE2RELCDZ Owners REV . 0
Using Your Remote Starter
Remote Starting Your Vehicle
To activate the remote start function, press and release the button two (2) times
within two (2) seconds. The system will sound, the parking lights will ash one (1)
time and the system will check the vehicle to ensure it is safe to start. If all safety
parameters are correct, the vehicle will start. The vehicle’s parking lights will turn on
(or ash depending on system settings) as a visual indication that the vehicle has
started and is running.
If your vehicle stalls or does not start, the system will pause ve (5) seconds, then try
two (2) more times to start the vehicle (a total of three (3) attempts). The system will
pause ve (5) seconds between each start attempt.
Entering the Vehicle while it is Running via Remote Vehicle Start (Optional)
1. Unlock the vehicle’s doors.
2. Enter the vehicle. DO NOT PRESS THE BRAKE PEDAL!
3. Insert the key into the ignition switch and turn to the ON or RUN position.
4. Press the brake pedal.
The remote vehicle starter will disengage and the vehicle will operate normally.
Preheating or Precooling the Vehicle’s interior
Before exiting the vehicle, set the temperature controls to the desired setting and
operation. After the system starts the vehicle, the heater or air conditioner will activate
and heat or cool the vehicle’s interior to your setting.
Remote Start Safety Features
For safety and security reasons, the system will shutdown or prevent the remote
vehicle starter from activating if any of the following occur:
• The vehicle’s hood is open.
• The brake pedal is pressed prior to turning the ignition key to the ON
position.
• The engine is over-revved (tach checking only).
• Valet Mode is active. Refer to the Valet Mode section of this manual on page 5.
• Remote Start Ready Mode is not set. Manual transmission vehicle’s only.
Remote Start Shutdown
Press and release the button two (2) times to turn the vehicle o󰀨.

52019 Voxx Electronics Corporation. All rights reserved.
Using the “Quick-stop” Feature (Optional)
If you want to make a short stop and keep your vehicle running (to keep the interior
warm or cool), the quick-stop feature allows you to do this while keeping your vehicle
secure and your keys with you.
To engage Quick Stop:
1. Stop the vehicle and place the transmission in PARK.
2. With your foot o󰀨 the brake pedal, press and release the button two (2)
times within two (2) seconds. The parking lights will turn on to conrm quick
stop is entered.
3. Remove the keys from the ignition and exit the vehicle. Press the button to
lock the vehicle’s doors if desired.
Status LED, Light Flashes, and Siren/Horn Indications
Status LED Flash Indications
LED Flashes Function
OFF Disarmed
Slow Flash Armed
Fast Flash Passive Arming Countdown
ON (Solid) Valet Mode
Siren/Horn Chirp Indications
Chirps Function
1 Arm
2 Disarm
Parking Light Flash Indications
Flashes Function
1 Arm
2 Disarm
ON (Solid or Slow Flash) Remote Started

6FLRS_FLCAN(RS)_PE2RELCDZ Owners REV . 0
Additional 2-Way LCD Remote Control Functions
Parking Meter Countdown
The parking meter countdown timer has 6 preset times, to access the preset times
and begin countdown press and hold
F
then press and release
OPT
, each additional
press of
OPT
will increase the countdown time.
Stopping LCD Trigger Melody
To stop the alarm trigger melody if the system has been triggered WITHOUT
disarming the system, press button one time only, this will send a lock command to
the vehicle at this time and the alarm will silence.
Battery Save Mode
While in POWER SAVE MODE the 2-Way LCD transmitter will NOT look for any
incoming signals from the main unit until a button is pressed. The LCD screen will
display SAVE ON to indicate that power save mode is ON. To enter power save mode
press and hold
F
then press .
Melody / Vibration Mode
To have the remote control vibrate or play a melody tone each time it receives a
response from the vehicle press and hold
F
then press and release .
Display Illumination
Press and hold the
F
button for one (1) second. The display will illuminate for ve (5)
seconds.
Adjusting the Clock and Timer Settings
The clock, alarm clock and programmable countdown timer are accessed through the
Function Menu. Press and hold
F
for 5 seconds to access the function menu, once
you have accessed the feature menu press and release
F
to scroll through each
feature and follow the steps below to adjust the settings for each. Press and hold
F
for 5 seconds to exit the menu.
Clock Hour Press to increase or
OPT
to decrease
Clock Minute Press to increase or
OPT
to decrease
Alarm Clock Hour Press to increase or
OPT
to decrease
Alarm Clock Minute Press to increase or
OPT
to decrease
Alarm Clock Alert Tone Press or
OPT
to change tone
Alarm Clock ON / OFF Press to turn ON or
OPT
to turn OFF
Countdown Timer Hour Press to increase or
OPT
to decrease
Countdown Timer Minute Press to increase or
OPT
to decrease
Shutdown Alert Tone Press or
OPT
to change tone
Countdown Timer ON / OFF Press to turn ON or
OPT
to turn OFF
Remote Start Alert Tone Press or
OPT
to change tone

72019 Voxx Electronics Corporation. All rights reserved.
Replacing Remote Control Batteries
5 Button Remote Control - Model 185SP
The CR2032 battery inside each remote control should last approximately 1 year
under normal use. When the batteries become weak you will notice the remote control
range (the distance from the vehicle the remote control will work) deteriorate and the
small LED on the remote control will dim. To replace the remote control batteries:
1. Using a coin, disassemble the halves of the remote control.
2. Remove the old battery, observing the +/- symbols on the batteries and replace
with a new battery.
3. Reassemble the halves of the remote control.
4. Test operation of the remote control.
2 Way LCD Remote Control - Model 18RELCD
The battery inside the 2-way LCD remote control is rechargeable and should last
approximately 30-60 days under normal use. When the battery becomes weak you
will notice the remote control range (the distance from the vehicle the remote control
will work) deteriorate and the battery icon on the LCD remote control will show 1 bar
or less.
To recharge the remote control.
1. On the back of the remote; Pull tab with USB symbol up and way from the back
case.
2. Rotate USB tab from right to left to slide out the remote charging port.
3. Press USB tab into place. The lock will engage.
Repeat the process above in reverse to stow the charging port.
Programming Remote Controls
To Program The Remote Controls
1. Cycle the vehicle's ignition switch to the ON position ve (5) times. The LED on
the antenna will turn on solid to indicate the system is ready for remote control
programming.
2. Press the button on the remote control. The LED on the antenna with ash
one (1) time to conrm the remote has been programmed.
3. Repeat step 2 above for each additional remote control.

8FLRS_FLCAN(RS)_PE2RELCDZ Owners REV . 0
LIMITED LIFETIME WARRANTY
Applies to Prestige Series Control Modules, Sirens, Sensors, and Relays.
Voxx Electronics Corporation (the Company) warrants to the original purchaser of
this product that should this product or any part thereof, (other than transmitters)
under normal use and conditions, be proven defective in material or workmanship
during the lifetime of the vehicle, in which it was originally installed from the date of
original purchase such defect(s) will be repaired or replaced with new or reconditioned
product, (at the Company’s option) without charge for parts or repair labor. A
transmitter is warranted for 12 months from the date of original purchase.
To obtain repair or replacement within the terms of this Warranty, the product is to
be delivered with proof of warranty coverage (e.g. dated bill of sale), specication of
defect(s), transportation prepaid, to an approved warranty station. This Warranty is not
transferable.
This Warranty does not cover damage to the vehicle’s electrical system or costs
incurred for removal or reinstallation of the product. This Warranty does not cover
batteries, broken LCD or OLED display screens, nor apply to any product or part
thereof which, in the opinion of the Company, has su󰀨ered or been damaged through
alteration, improper installation, mishandling, misuse, abuse, neglect, accident, or by
removal or defacement of the factory serial number/bar code label(s).
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED
WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY,
SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. IN
NO CASE SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY. No
person or representative is authorized to assume for the Company any liability other
than expressed herein in connection with the sale of this product.
The company does not warrant that this product cannot be compromised or
circumvented. THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS
WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED
ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S LIABILITY EXCEED THE
PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT WITHOUT COST
OF INSTALLATION.
Some states do not allow limitations on how long an implied warranty lasts or the
exclusion or limitation of incidental or consequential damage so the above limitations
or exclusions may not apply to you. This Warranty gives you specic legal rights and
you may also have other rights which vary from state to state.
Voxx Electronics Corporation, 2351 J. Lawson Blvd., Orlando, FL 32824 / 1-800-645-4994

92019 Voxx Electronics Corporation. All rights reserved.
Voxx Electronics Corporation.
Customer Service 1-800-225-6074
WWW.VOXXELECTRONICS.COM
FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of
Industry Canada. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including any interference that
may cause undesired operation.
Warning!
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
PATENTED: www.voxxintl.com/company/patents
