Owner’s Guide
For Models:
PE5BZ
IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is
applicable to most vehicles. However, due to the conguration of some vehicles, some functions AND/OR
SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.
APSRS
RF Upgrade Kit

2APSRS PE5BZ Owners revB
Table of Contents
Using Your Remote Control.................................................................... 3
Locking the Vehicle Doors................................................................. 3
Arming the Security System .............................................................. 3
Unlocking the Vehicle Doors ............................................................. 3
Disarming the Security System ......................................................... 3
Two Stage Door Unlock (optional)..................................................... 3
Activating Trunk Release (optional)................................................... 3
Activating AUX Output (optional)....................................................... 3
Using the Personal Protection Alarm................................................. 4
User Selectable Notication Chirps................................................... 4
User Selectable LED ......................................................................... 4
Programmed Transmitter Notication................................................ 4
Valet Mode ........................................................................................ 5
Manually Overriding the Security System ......................................... 5
Using Your Remote Vehicle Starter ....................................................... 6
Remote Starting Your Vehicle............................................................ 6
Remote Start Shutdown .................................................................... 6
Entering Your Vehicle while it is Running via Remote Start .............. 6
Preheating or Precooling the Vehicle’s Interior ................................. 6
Remote Start Safety Features........................................................... 6
Remote Start Ready Mode................................................................ 7
Enter & Exiting the Vehicle - Remote Start Ready Mode .................. 7
Cancelling Remote Start Ready Mode .............................................. 7
Using the “Quick-Stop” Feature......................................................... 8
Turbo Timer Mode (optional) ............................................................. 8
Operating the 2 / 4 Hour Start Up Timer Mode.................................. 9
Status LED, Light Flashes and Siren/Horn Indications ..................... 10
Replacing Remote Control Batteries................................................... 12
Warranty Information ............................................................................ 13

32019 Voxx Electronics Corporation. All rights reserved.
Arming the Security System (Optional)
To arm the system, exit the vehicle, close all doors, then press the button. The
parking lights will ash 1 time indicating the system is armed, has locked the doors (if
equipped and connected) and activated the starter disable feature. The LED status
indicator will blink steadily, once per second.
NOTE: This feature requires additional programming and installation. Contact your
dealer for more information
*Throughout this manual, ‘press’ refers to pressing for less than 1 second; ‘press and hold’ refers to pressing for more
than 3 seconds.
Using Your Remote Control
Two Stage Door Unlock (Optional)
If this feature is enabled on your system, pressing the button one time will unlock
only the driver’s door. Press again within three seconds to unlock the remaining
doors.
Disarming the Security System
To disarm the system press the button. The parking lights will ash 1 time, indicating
the system is disarmed and has unlocked the doors (if equipped and connected).
NOTE: This feature requires additional programming and installation. Contact your
dealer for more information.
Activating the Trunk Release Feature (Optional)
If this feature is enabled on your system, pressing and holding the button for 3
seconds will open the vehicle’s trunk or hatch.
Door Lock
To lock the vehicle doors press and release the button.
NOTE: The system is equipped with a feature called Silent Choice. If enabled, the
system requires a second press of the button to activate an audible arming response
from the vehicle.
Door Unlock
To unlock the vehicle doors press and release the button.
NOTE: The system is equipped with a feature called Silent Choice. If enabled, the
system requires a second press of the button to activate an audible arming response
from the vehicle.

4APSRS PE5BZ Owners revB
Programmed Transmitter Notication
As a security precaution each time the vehicle’s ignition is turn on the status LED
light with ash the number of transmitters programmed into the system. This helps
to identify unauthorized transmitters from accessing your vehicle. If you believe an
unauthorized transmitter has been programmed to your system, contact your installing
dealer for assistance.
User Selectable Notication Chirps
System ARM/DISARM chirps can be toggled ON or OFF without entering the
programming feature banks.
1. Turn the ignition ON then OFF.
2. Press and release the valet/programming button 3 times. The system
will respond with 1 chirp for ON or 2 chirps for OFF.
User Selectable LED
This feature will control whether the LED is ON or OFF when the system is Armed/
Locked and can be toggled ON or OFF without entering the programming feature
banks.
1. Turn the ignition ON, OFF, ON, OFF.
2. Press and hold the valet/programming button for 5 seconds. The system
LED will respond with 1 ash for ON or 2 ashes for OFF.
Activating the AUX Ch. 4-7 Output (Optional)
AUX channel output is an optional feature and programming is required at the time of
installation. Please consult your dealer for more information.
Using the Personal Protection Alarm (Panic)
Press and hold the or button for 3 seconds to activate the personal protection
alarm. During panic mode, the normal function of the transmitter buttons will be
suspended. The transmitter’s and buttons can be used to lock and unlock the door
(if the option is installed). To stop the alarm, press and hold the or button on the
transmitter again for 3 seconds. The system will automatically stop after 30 seconds.

52019 Voxx Electronics Corporation. All rights reserved.
Valet Mode (Optional)
When valet mode is activated the status LED will light solid, and all security and
remote start functions will be disabled. To enter or exit valet mode simply follow the
steps outlined below:
1. Turn the vehicle’s ignition ON.
2. Push and hold the programming/valet button.
3. The LED will turn on solid when valet mode is active
4. Release the programming/valet button.
Manually Overriding the Security System
Your system can be disarmed without the use of the transmitter. This is necessary to
operate your vehicle if the transmitter is lost or its battery fails. To by-pass the alarm
system;
1. Open the vehicle door. The alarm will sound.
2. Turn the ignition key to the ON position.
3. Within 10 seconds, press and release the valet push button switch.
The alarm system will stop sounding and enter the (by-passed) mode. You can now
start and operate the vehicle normally.

6APSRS PE5BZ Owners revB
Using Your Remote Starter
Remote Starting Your Vehicle
To activate the remote start function, press and release the button 2 times within
2 seconds. The system will sound, the parking lights will ash 1 time and the system
will check the vehicle to ensure it is safe to start. If all safety parameters are correct,
the vehicle will start. The vehicle’s parking lights will turn on (or ash depending on
system settings) as a visual indication that the vehicle has started and is running.
If your vehicle stalls or does not start, the system will pause 5 seconds, then try
3 more times to start the vehicle (a total of 4 attempts). The system will pause 5
seconds between each start attempt.
Remote Start Shutdown
Press and release the button 2 times to turn the vehicle o󰀨.
Entering the Vehicle while it is Running via Remote Vehicle Start (Optional)
1. Unlock the vehicle’s doors.
2. Enter the vehicle. DO NOT PRESS THE BRAKE PEDAL!
3. Insert the key into the ignition switch and turn to the ON or RUN
position.
4. Press the brake pedal. The remote vehicle starter will disengage and
the vehicle will operate normally.
Preheating or Precooling the Vehicle’s interior
Before exiting the vehicle, set the temperature controls to the desired setting and
operation. After the system starts the vehicle, the heater or air conditioner will
activate and heat or cool the vehicle’s interior to your setting.
Remote Start Safety Features
For safety and security reasons, the system will shutdown or prevent the remote
vehicle starter from activating if any of the following occur:
1. The vehicle’s hood is open.
2. The brake pedal is pressed prior to turning the ignition key to the ON
position.
3. The engine is over-revved (tach checking only).
4. Valet Mode is active. Refer to the Valet Mode section of this manual on
page 5.
5. Remote Start Ready Mode is not set. Manual transmission vehicle’s only.

72019 Voxx Electronics Corporation. All rights reserved.
To Enter & Exit the Vehicle while (Manual Transmission) Remote Start Ready
Mode is already active without cancelling Remote Start Ready Mode.
If ready mode has already been activated and you need to enter the vehicle, possibly
to retrieve an item, and will exit the vehicle without driving it, you can keep ready
mode active by following the steps below.
1. With Ready Mode already previously set, activate the remote start.
2. While under control of the remote start open vehicle door to retrieve
items.
3. Exit the vehicle and close all doors.
4. Press the button, the unit waits 3 seconds and then shuts down,
the system will verify all doors have been closed then will emit the 2
short/1 long tone and light ash pattern indicating Manual Transmission
Ready Mode is active.
Note: If the 2 short/1 long tone is not heard then Ready Mode has not been
set.
Remote Start Ready Mode - Manual Transmission Vehicles Only
To activate the remote start function, the system must rst be in Remote Start Ready
Mode. Follow the steps below to enter remote start ready mode.
1. While the engine is running by the ignition key;
a. Place the transmission in neutral.
b. Set the parking brake
2. With your foot o󰀨 the brake pedal, press and release the button to
activate the remote start. The remote will beep 4 times and the parkinglights
will turn on to conrm the system has remote started.
3. Remove the keys from the ignition, the vehicle will remain running.
4. Exit the vehicle and close all vehicle doors.
5. Within 1 minute of step 1, press the button to lock the vehicle’s doors.
The vehicle will shutdown and sound 2 short chirps then 1 long chirp to conrm
ready mode is set.
Remote Start Ready Mode must be enabled if your vehicle is equipped with a
manual transmission.
Cancelling Remote Start Ready Mode - Manual Transmission Vehicles Only
The system will exit remote start ready mode if any of the following occur:
Open any door
Open the hood or trunk (if connected)
Press the brake
Release the parking brake
Turn the ignition ON

8APSRS PE5BZ Owners revB
Using the “Quick-stop” Feature (Optional)
If you want to make a short stop and keep your vehicle running (to keep the interior
warm or cool), the quick-stop feature allows you to do this while keeping your vehicle
secure and your keys with you.
To engage Quick Stop:
1. Stop the vehicle and place the transmission in PARK.
2. With your foot o󰀨 the brake pedal, press and release the button 2
times within 2 seconds. The LED will ash 3 times to conrm quick
stop is entered.
3. Remove the keys from the ignition and exit the vehicle. Press the
button to lock the vehicle’s doors if desired.
To engage Quick Stop - Manual Transmission Vehicles:
1. With the vehicle running, foot o󰀨 the brake, parking brake set ON.
2. Press and release the button to activate remote start.
3. Exit the vehicle close all doors (Door Open/All Doors Close)
4. Press and release the button.
5. Within 3 seconds press the button:
The unit enters Quick Stop Mode and will remain running
until remote start time-out and then shut down. (Remote Start Ready
Mode is NOT active)
Note: Do not leave children or animals unattended in the vehicle when using the
quick-stop feature.
Turbo Timer (Optional)
This option will keep the engine running to allow the vehicle’s turbo to properly cool
down before shutting the engine o󰀨.
To engage the Turbo Timer feature:
1. With the vehicle running via the ignition key and your foot o󰀨 of the
brake pedal.
2. Engage the vehicle’s parking brake.
3. The vehicle’s parking lights will turn on to verify the Turbo Timer
feature has been activated.
4. Turn the ignition key OFF, the vehicle will continue to run until the pre-
programmed time has elapsed (1, 3, or 5 minutes)
To disengage the turbo timer feature, press the vehicle’s brake pedal.

92019 Voxx Electronics Corporation. All rights reserved.
Operating the 2 / 4 Hour Start Up Timer Mode
The system has the ability to start the vehicle every 2 or 4 hours for a 48 hour period.
This feature is especially useful in cold climates where the only means to keep the
engine and engine uids warm is to periodically start the engine. The default setting
is 4 hours.
WARNING!
Be certain that the vehicle is outdoors before using this or any remote starting
device. A running engine produces dangerous carbon monoxide fumes which can be
harmful or fatal if prolonged exposure occurs. DO NOT remote start the vehicle if it is
garaged.
To congure 2 / 4 hour start timer mode:
1. Press and hold the valet button.
2. Cycle the vehicle’s Ignition ON/OFF 1 time.
a. To set for 2 Hour (default) - Press the valet button 2 times.
The Parking lights will ash 2 times for conrmation.
b. To set for 4 Hour (default) - Press the valet button 4 times.
The Parking lights will ash 4 times for conrmation.
To activate the 2 / 4 hour start up timer mode:
1. Start the vehicle and let it run for more than 15 seconds.
2. Cycle the vehicle’s Ignition to the OFF position.
3. Press and release the button on the remote 4 times.
The vehicle’s parking lights will ash 2 or 4 times to conrm the timer
mode is activated.
To exit the 2 / 4 hour start up timer mode:
1. Remote start the vehicle using the remote control.
OR
2. Start the vehicle normally using the Ignition key.

10 APSRS PE5BZ Owners revB
Status LED, Light Flashes, and Siren/Horn Indications
Status LED Flash Indications
LED Flashes Function
OFF Unlocked / Disarmed
Slow Flash Locked / Armed
ON (Solid) Valet Mode
1 Flash / Disarmed Zone 1 Trigger, Shock Sensor
2 Flashes / Disarmed Zone 2 Trigger, Trunk / Hood
3 Flashes / Disarmed Zone 3 Trigger, Door
Siren/Horn Chirp Indications
Chirps Function
1 Lock / Arm
2 Unlock / Disarm
3 Door Ajar Upon Locking /Arming
4 Disarm / Triggered
Parking Light Flash Indications
Flashes Function
1 Lock / Arm
2 Unlock / Disarm
3 Disarm / Triggered
ON (Solid or Slow Flash) Remote Started
Remote Start Shutdown Diagnostics
Parking Light Flashes Shutdown Zone
1 Flash Runtime Expired
2 Flashes Remote Shutdown
3 Flashes Brake ON
4 Flashes Manual Transmission Ready Mode
5 Flashes Hood Open
6 Flashes Low Tach Signal
7 Flashes Tach / Crank Average not learned
8 Flashes High Tach Signal

112019 Voxx Electronics Corporation. All rights reserved.
Replacing Remote Control Batteries
5 Button Remote Control - Model 185SP
The CR2032 battery inside each remote control should last approximately 1 year under
normal use. When the batteries become weak you will notice the remote control range
(the distance from the vehicle the remote control will work) deteriorate and the small LED
on the remote control will dim. To replace the remote control batteries:
1. Using a coin, disassemble the halves of the remote
control.
2. Remove the old battery, observing the +/- symbols on the
batteries and replace with a new battery.
3. Reassemble the halves of the remote control
4. Test operation of the remote control.
Remote Control Programming
1. Cycle vehicle’s ignition to ON.
2. Press and release the vale/programming button 3 times.
2. Press button of each transmitter you wish to program, the system will
beep to conrm each transmitter.
3. Turn the ignition OFF.
NOTE: This system has 1 button programming which programs all channels of the
system.
NOTE: The system will hold up to 4 transmitters in memory, programming a 5th
transmitter will erase the oldest transmitter in memory.

12 APSRS PE5BZ Owners revB
LIMITED LIFETIME WARRANTY
Applies to Prestige Series Control Modules, Sirens, Sensors, and Relays.
Voxx Electronics Corporation (the Company) warrants to the original purchaser of this
product that should this product or any part thereof, (other than transmitters) under nor-
mal use and conditions, be proven defective in material or workmanship during the life-
time of the vehicle, in which it was originally installed from the date of original purchase
such defect(s) will be repaired or replaced with new or reconditioned product, (at the
Company’s option) without charge for parts or repair labor. A transmitter is warranted for
12 months from the date of original purchase.
To obtain repair or replacement within the terms of this Warranty, the product is to
be delivered with proof of warranty coverage (e.g. dated bill of sale), specication of
defect(s), transportation prepaid, to an approved warranty station. This Warranty is not
transferable.
This Warranty does not cover damage to the vehicle’s electrical system or costs
incurred for removal or reinstallation of the product. This Warranty does not cover bat-
teries, broken LCD or OLED display screens, nor apply to any product or part thereof
which, in the opinion of the Company, has su󰀨ered or been damaged through alteration,
improper installation, mishandling, misuse, abuse, neglect, accident, or by removal or
defacement of the factory serial number/bar code label(s).
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WAR-
RANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, SHALL
BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. IN NO CASE
SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY. No person or rep-
resentative is authorized to assume for the Company any liability other than expressed
herein in connection with the sale of this product.
The company does not warrant that this product cannot be compromised or circum-
vented. THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY
IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO
EVENT, SHALL THE COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE PAID
BY PURCHASER FOR THE PRODUCT WITHOUT COST OF INSTALLATION.
Some states do not allow limitations on how long an implied warranty lasts or the
exclusion or limitation of incidental or consequential damage so the above limitations or
exclusions may not apply to you. This Warranty gives you specic legal rights and you
may also have other rights which vary from state to state.
Voxx Electronics Corporation, 180 Marcus Blvd., Hauppauge, New York 11788 / 1-800-645-4994

132019 Voxx Electronics Corporation. All rights reserved.
Voxx Electronics Corporation.
Customer Service 1-800-225-6074
WWW.VOXXELECTRONICS.COM
FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of
Industry Canada. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including any interference that
may cause undesired operation.
Warning!
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
PATENTED: www.voxxintl.com/company/patents
