Prestigio GeoVision 5055 iGO User manual

EN-1
EN
CAUTION
1. To reduce the risk of electric shock, do not remove the cover (or back). No
user-serviceable parts inside. Refer servicing to qualified service personnel.
2. The manufacturer should not hold responsibility for the damage caused by any
substitutions and modifications of the product without authorization from the
manufacturer or authorized unit.
WARNING
The device should not be exposed to dripping or splashing and no objects filled with liquids
should be placed on the device.
To prevent the GPS from being damaged, be sure to keep the GPS out of direct
sunlight or heat. Maintain well-ventilated conditions around the unit to avoid
overheating.
Accessories List
ITEM NAME QTY
Car Charger 1
Mounting Cradle 1
USB Cable 1
Stylus Pen 1
Driver/Documentation CD 1
User Manual 1
Warranty Card
Accessories
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
Important Safety
Instructions
1

EN-2
EN
Front and Side View
1. LCD Touch Screen
Tap the screen with a finger to select commands or use the included stylus.
2. Battery Status Indicator
The indicator glows in bright amber color when battery is fully charged and in red color
when charging.
3. microSD Slot
Insert the SD card into the slot. Used for Mapping Data or user’s music, photo or video.
4. Mini-USB Port
Connects to USB Cable for data access or battery charging
5. Headphone Port
Connect an earphone for private listening. When an earphone jack is plugged in,
the speaker will be turned off automatically.
6. Reset Button
Used to reset the device.
7. Power Button
Press to power ON/OFF device.
8. Speaker
Emits sound, voice or music.
9. Stylus Pen
Used for writing on the LCD Touch Screen.
Inserting microSD Card
To insert a microSD card, place
connector towards device and card
label towards the front side of the
device.
To remove a microSD card, gently
press the edge of the card to release
the safety lock and pull the card out
of the slot.
NOTE:
Please always make sure that no application is accessing the microSD
card before extraction.
Charging
1. Connecting to External USB Device
Flip open the protective rubber cover towards the front of the device.
Insert USB connector into the appropriate USB port.
Insert the other USB connector into USB port on PC to start charging.
View of Main Unit Device Connection
1
2
4
5
3
6
8
9
7

EN-3
EN
2. Connecting to Car Charger
Flip open the protective rubber cover towards the left side of the device.
Insert USB connector into the appropriate USB port.
Insert car charger connector into vehicle 12V accessory/cigarette socket to start
charging.
NOTE:
Please connect the car charger to vehicle 12V accessory/cigarette socket after
vehicle engine is started to protect the device from sudden surges in current.
Connecting to Earphones
Flip open the protective rubber cover towards the front of the device.
Insert earphone plug (not included) into the appropriate earphone port to switch
audio output from device speaker to earphone.
NOTE:
Excessively loud volume is potentially detrimental to hearing. Please turn
down the volume before connecting the earphone and gradually turn up
the volume to a comfortable level.
About Rechargeable Battery
The device is equipped with a built-in rechargeable battery. Please fully charge the battery
(for at least 8 hours) before initial use. The battery status indicator glows in red color when
charging and turns bright amber color when charging is complete. Charging time is
approximately 2 hours.
Working conditions and precautions for the rechargeable battery
Device with new battery should be fully charged before initial use.
It is not necessary to start charging the device before the battery is fully discharged.
Cautions on Battery
Char
g
in
g
Device Connection

EN-4
EN
Device Mounting Procedures
The device can be securely mounted on vehicle dashboard or windshield with the mounting
cradle included. Please follow procedures below to operate mounting cradle:
1. Select an appropriate location on windshield or dashboard where the device and
mounting cradle will not obstruct driver field of vision.
2. Please also make sure that the device has a clear view of sky to attain best GPS
reception.
Place device on the bracket with
bottom positioned on the appropriate
socket.
Push on the top edge to securely
install device onto the cradle.
Lift the suction cup lever and press
the suction cup at desired location.
Press down the suction cup lever to
secure the mounting cradle on the
surface.
Rotate the knob to adjust device to
desired viewing angle.
To Dismount Device
1. Push the tap on top of the mounting cradle to release the device.
2. Lift the suction cup lever to easily remove the suction cup from windshield or
dashboard.
1. Press and hold Power Button
to turn on device.
2. Shortly after the startup screen
is shown, the main menu will be
displayed.
3. Tap the corresponding buttons
with touch pen included to
navigate various functions.
4. Press and hold Power Button
to turn off the device or to allow
device to enter sleep mode.
Using Mounting Getting Started

EN-5
EN
When Prestigio GeoVision is started the first time, you need to select whether to start the
program in Simple mode or in Advanced mode.
The two operating modes of Prestigio GeoVision mainly differ in the menu structure and
the number of available features. The controls and screen layouts are the same.
Simple mode: you have easy access to the most important navigation functions and
the basic settings only. The rest of the settings are set to values that are optimal for
typical use.
Advanced mode: you have access to the full functionality of Prestigio GeoVision.
This Guide covers actions in Simple mode. See the User Manual for detailed instructions on
both modes.
Later you can switch between the two operating modes:
To switch from Simple mode to Advanced mode: on the startup screen (Navigation
Menu), tap , .
To switch from Advanced mode to Simple mode: on the startup screen (Navigation
Menu), tap , .
After selecting Simple mode, the Navigation menu appears. From here you can reach all
parts of Prestigio GeoVision.
The Navigation menu contains the following options:
Tap to specify an address as your destination.
Tap for the list of recent destinations.
Tap to select one of the stored Points of Interest.
Tap for the list of your favourite destinations.
Tap to navigate or to browse the map.
Tap to customise the way Prestigio GeoVision works.
Tap to stop navigation, and exit Prestigio GeoVision.
Navigation MenuGPS

EN-6
EN
In the Navigation menu, tap
By default, Prestigio GeoVision proposes the country/state and settlement where you are.
If needed, tap the button with the name of the country/state, and select a different one from
the list.If needed, change the settlement:
To select the settlement from the list of recently used ones, tap the
button.
To enter a new settlement:
1. Tap the button with the name of the settlement, or if you have changed the
country/state, tap .
2. Start entering the settlement name on the keyboard.
3. Get to the list of search results:
After entering a couple of characters, the names that match the string appear in a list.
Tap to open the list of results before it appears automatically.
4. Pick the settlement from the list.
Enter the street name:
1. Tap .
2. Start entering the street name on the keyboard.
3. Get to the list of results:
After entering a couple of characters, the names that match the string appear
in a list.
Tap to open the list of results before it appears automatically.
4. Pick the street from the list.
Enter the house number:
1. Tap .
2. Enter the house number on the keyboard.
3. Tap to finish entering the address.
The map appears with the selected point in the middle. Tap from the Cursor
menu. The route is then automatically calculated, and you can start navigating.
Navigation Navigation

EN-7
EN
On the Map screen, tap to return to the Navigation menu.
In the Navigation menu, tap .
Select the area around which the POI should be searched:
: The POI will be searched around a given address.
: The POI will be searched around the Cursor.
: The POI will be searched around the current GPS position.
: The POI will be searched around the destination of the active route.
: The POI will be searched not around a given point but by the size of the
detour it means from the active route. This can be useful if you search for a later
stopover that causes only a minimal detour. For example upcoming petrol stations or
restaurants.After this, the list of POI categories appear.
You can narrow the search with the following:
Select the POI group (e.g. Accommodation), and after that, if needed, select the POI
subgroup (e.g. Hotel or Motel).
To find the POI by its name, tap , and use the keyboard to enter a part of
the name.
To list all POIs in a given POI group, press , and then
without entering any letters of its name.
[optional] When finally the list of results appear, you can change the list order with the
or button.
Tap the desired POI in the list.
The map appears with the selected point in the middle. Tap from the Cursor
menu. The route is then automatically calculated, and you can start navigating.
NavigationNavigation

EN-8
EN
The most important and most often used screen of Prestigio GeoVision is the Map screen.
The map looks similar to a conventional road-map. The blue arrow represents your current
position, and the green line shows the recommended route.
There are several screen buttons and data fields on the screen to help you navigate. Their
functions are explained in detail in the User Manual.
During navigation, the screen shows route information and trip data (left screenshot), but
when you tap the map, additional buttons and controls appear for a few seconds (right
screenshot). Most parts of the screen behave as buttons.
or : Switches between 2D (classic top-down view) and 3D (perspective view
for navigation) map modes.
: Opens the Navigation menu.
If you have moved the map, a button appears. Tap this button
to move the
map back to the current GPS position.
Take steps described in the tables below to solve simple problems before contacting
customer service.
NOTE:
Immediately turn off the device and disconnect the power adapter if the
device is not working properly. Never try to repair the unit without
authorized professionals for it may damage the unit.
Map Screen Troubleshooting
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
There is no
sound.
The volume may be turned
down or mute.
Turn up the volume or turn
on the sound output.
Users can’t turn
on the unit.
The adaptor doesn’t
connect well.
Connect the adaptor
correctly.
The built-in rechargeable
battery is weak.
Use the adaptor to supply
power or charge the
battery.
There is no
picture. The brightness may be
turned down.
Adjust the brightness of the
LCD.
The unit can’t
receive satellite
signals or can’t
orient.
The unit may be obstructed
by buildings or metal block.
Make sure to use the unit
out of room; if in the
vehicle, you can use the
external GPS antenna to
solve this problem.

EN-9
EN
To establish connection with PC for data access and synchronization, please execute
setup file included in the Driver/Documentation CD or download the file from Microsoft
website to install:
Microsoft Active Sync® software for operating system Microsoft XP or earlier
versions
(http://www.microsoft.com/windowsmobile/en-us/downloads/microsoft/activesync-dow
nload.mspx)
and/or
Microsoft Mobile Device Center® software for operating system Microsoft Vista
(http://www.microsoft.com/windowsmobile/en-us/downloads/microsoft/device-center-d
ownload.mspx).
Please refer to its user manual for more detailed instructions.
PC ConnectionTroubleshooting
The unit can
receive signals
now but can’t
then; signals
received are not
stable.
The built-in rechargeable
battery is weak.
Use the adaptor to supply
power or charge the
battery.
The unit may be obstructed
by veil, such as heat
insulation paper.
Remove the veil.
Swing of the unit is too
great.
Avoid great swing of the
unit.
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION

EN-10
EN
Model GV5055
GPS Receiver MSR2320
Processor MSB2531A Cortex A7, 800 MHz
RAM 128MB DDR2
Display 5” touch LCD
Resolution 480*272
Storage Capacity 4GB flash memory, Memory card slot supports micro SD
card up to 16GB
Interface Mini USB
Battery 1050mAh Li-Polymer battery
Dimensions 137.5*88.5*12.5mm (L*H*W)
Weight 170g
Storage Temperature -25℃~+70℃
Operating Temperature -20℃~+60℃
Operating Relative
Humidity 90%
Storage Relative
Humidity 95%
As the Prestigio products are constantly updated and improved, your
device’s software and hardware may have a slightly different appearance
or modified functionality than presented in this Quick Start Guide.
Prestigio hereby states that this GPS Navigator complies to basic requirements and another
relevant regulations given by the EU directive1999/5/ES. Full version of the declaration of
conformity is available on www.prestigio.com/certificates.
Technical specifications Disclaimer
