Prestigio GV4500 User manual

1. Important safety instructions ………………….…………………...
2. Accessories ……………………………………………………………
3. View of main unit …………………….……………….......................
4. Device connections ……………………….…………......................
5. Cautions on battery charging ………….…………………………..
6. Getting started ………………………………………………………..
7. Bluetooth Function …………………………………………………..
8. FM Function …………………………………………………………...
9. TMC Function ……………………………………………………….
10. Device Settings……………………………...………………………...
11. Initialization and Software Activation …………………................
12. Navigation...........……………………………………………………...
13. Map Screen……………………………………………………………..
14. More Menu……………………………………………………………...
15. Settings…………………………………………………………………
16. Troubleshooting ………………………………………………………
17. PC Connection…………………………………………………………
1
2
2
3
4
5
6
8
8
8
9
10
13
14
14
15
16
Contents

CAUTION
1. To reduce the risk of electric shock, do not remove the cover (or back). No
user-serviceable parts inside. Refer servicing to qualified service personnel.
2. The manufacturer should not hold responsibility for the damage caused by any
substitutions and modifications of the product without authorization from the
manufacturer or authorized unit.
WARNING
The device should not be exposed to dripping or splashing and no objects filled with
liquids should be placed on the device.
Important Safety
Instructions
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
EN
EN – 1

Accessories List
ITEM NAME QTY
Car Charger 1
USB Cable 1
Stylus Pen 1
Stylish Carry Case
(GV5500BT only) 1
User Manual 1
Warranty Card
Driver/Document CD 1
Accessories
1
EN
EN - 2

Front and Side View
1. LCD Touch Screen
Tap the screen with touch pen or finger to select menu commands or to enter
information.
2. Battery Status Indicator
The indicator glows in bright green colour when battery is fully charged and in red
color when charging.
3. Earphone Jack
Connects to earphones or headsets.
4. MicroSD Slot
Receiving microSD memory card for data access or memory expansion.
5. USB Port
Connection to USB Cable for data access or battery charging
6. Microphone
Records sound.
View of Main Unit
1
4
3
5
6
2

Rear and Top View
1. Speaker
Emits sound, voice or music.
2. Reset Button
Press to reboot the device.
3. Light Sensor
Adjust the brightness of touch screen
4. Power Button
Press to power the device ON/OFF.
View of Main Unit
1
4
2
3

Inserting microSD Card
To insert a microSD card, place the
connector towards the device and the
card label towards the front side of
the device.
To remove a microSD card, gently
press the edge of the card to release
the safety lock and pull the card out
of the slot.
NOTE:
Please always make sure that no application is accessing the microSD
card before extraction.
Connecting to External USB Device (Charging)
Insert the USB connector into the
appropriate USB port.
Insert the other USB connector into
the USB port on PC to start charging.
Device Connections
EN
EN - 3

Connecting to Car Charger
Insert the USB connector into the
appropriate USB port.
Insert car charger connector into
vehicle 12V accessory/cigarette
socket to start charging.
NOTE:
Please connect the car charger to vehicle 12V accessory/cigarette
socket after the vehicle engine is started to protect the device from
sudden surges in current.
Device Connections
EN
EN -4

About Rechargeable Battery
The device is equipped with a built-in rechargeable battery. Please fully charge the
battery (for at least 5 hours) before initial use. The battery status indicator glows in red
colour when charging and turns bright green colour when charging is complete. Charging
time is approximately 4 hours.
Working conditions and precautions for the rechargeable battery
Devices with new batteries should be fully charged before initial use.
It is not necessary to start charging the device before the battery is fully
discharged.
Cautions on Battery
Charging

1. Press and hold Power Button to turn
on the device.
2. Shortly after the greeting screen is
shown, the main menu will be
displayed.
3. Tap the corresponding buttons with
touch pen included to navigate
through various functions.
4. Press and hold Power Button to turn
the device off or to allow the device to
enter sleep mode.
5. Tap Sleep icon to put the device to
sleep mode or Power Off icon to turn
the device off.
Getting Started
EN - 5
EN

1. Tap on Bluetooth icon on the main
menu to start using Bluetooth
function.
2. The link status is shown at the
bottom of the interface.
3. Tap on to exit the current
function.
4. Tap on in Bluetooth interface to
start pairing with mobile phone
device with GPRS function.
5. Please make sure Bluetooth function
on mobile phone is detectable by
other devices.
6. “Connection established” will be
displayed upon the successful
pairing.
7. Tap on in Bluetooth interface to
enter the Phone Keyboard.
8. Tap on digit buttons and tap on
/ / to start Dialing,
Backspace, and enter Dial Record.
Bluetooth Function
(GeoVision 4500BTFM/5500BTFM/5500BTFMHD)
EN
EN - 6

9. Tap on / to adjust the
volume. Tap on to end call.
10. Tap on to enter call record. Tap
on to enter keypad. Tap on
to switch the call to mobile phone or
switch it back to device.
11. The call fails to connect as
illustrated.
12. Tap on to return to Phone
Keyboard interface.
13. Calling number will be displayed
upon the Incoming Call.
Bluetooth Function
(GeoVision 4500BTFM/5500BTFM/5500BTFMHD)

14. Tap on on Bluetooth interface
to enter Dial Record.
15. Tap on / / to view Dialed Call
list, Received Call list, and Missed
Call list. Tap on to start dialing.
16. To delete a desired phone number
on the list, select the number and tap
on . Tap on to delete all
numbers on the list.
17. Tap on in the Bluetooth
interface to redial the last dialed
number.
18. Tap on in the Bluetooth
interface to enter Settingfunction.
19. Tap on to reset a new PIN
code. Tap on / to select a
ring tone.
20. Tap on to enable/disable the
Bluetooth function. Tap on to
enable/disable automatic HFP
connection.
Bluetooth Function
(GeoVision 4500BTFM/5500BTFM/5500BTFMHD)

21. Tap on in Bluetooth interface
to enter Paired Device List function.
22. Tap on to delete mobile phone
name from the list. Tap on to
disconnect the PND (Personal
Navigation Device) from the mobile
phone. Select mobile phone name
from Paired Device List and tap on
to enter Profile list.
23. Tap on to re-connect from
previously connected mobile phone.
Tap on to disconnect the PND
(Personal Navigation Device) from
the mobile phone.
24. Tap on in Bluetooth interface to
start searching process.
25. Mobile phone name desired for
connection will be displayed on the
list when search is completed.
26. Tap on the mobile phone name and
tap on to pair. Tap on to
enter Paired Device List.
Bluetooth Function
(GeoVision 4500BTFM/5500BTFM/5500BTFMHD)
EN
EN - 7

27. Tap on enter Phonebook.
28. Tap on to download the phone
numbers of the mobile phone to the
PND (Personal Navigation Device).
29. Tap on to dial the phone
number.
30. Tap on to delete mobile phone
name from the list.
NOTE:
Bluetooth Function is available for GeoVision 4500BTFM/5500BTFM/5500BTFMHD.
1. Tap on Function icon on the main
menu.
2. Tap on FM icon to start using FM
function.
3. Tap on / or drag the cursor to
tune FM frequency down/up.
4. Tap on to save current FM
frequency.
5. Tap on to enable the FM
function.
6. Tap on to exit.
NOTE:
*Make sure the device is properly
connected to the car charger before using
FM function.
NOTE:
FM function is available for GeoVision 4500BTFM/5500BTFM/5500BTFMHD.
FM Function
(GeoVision 4500BTFM/5500BTFM/5500BTFMHD)
Bluetooth Function
(GeoVision 4500BTFM/5500BTFM/5500BTFMHD)
EN
EN - 8

TMC is a specific application of the FM Radio Data System (RDS) used for broadcasting
real-time traffic and weather information. Route calculation can avoid road blocks or
unexpected traffic jams caused by an accident.
NOTE:
This feature is available only if your hardware supports TMC, and if it’s in your country.
Prestigio GeoVision receiver will automatically search the FM radio stations for TMC
data, and the decoded information will immediately be used in route planning. The
moment Prestigio GeoVision receives traffic information that may affect your route, the
program will warn you that it is recalculating the route, and navigation will continue with a
new route that is optimal considering the most up-to-date traffic conditions.
To fine-tune this recalculation, you can set the minimum delay that can trigger a route
recalculation, or you can instruct Prestigio GeoVision to have you confirm the new
recommended route before it takes effect. You can do these in Traffic settings.
A special icon is displayed on the Map screen to show you whether traffic events are
received. The icon shows the status of the traffic receiver when there are no traffic
events on your route; otherwise it shows the type of the next traffic event on your route.
Road segments affected by traffic events are displayed with an alternate colour on the
map, and small symbols above the road show the nature of the event:
1. Tap to open the Traffic
Summary screen.
2.
Tap to open the list of
traffic events.
TMC Function
(GeoVision 4500TMC/5500TMC/5500TMCHD)

3. Now tap any of the list items to see its
details, and to display the affected
road segment in its full length on the
map.
NOTE:
If there are traffic events on the recommended route that the application has not
bypassed, the icon will open the list of significant traffic events to let you quickly
check them.
TMC Function
(GeoVision 4500TMC/5500TMC/5500TMCHD)

In the main menu, tap on to
enter the device settings.
Tap to display other settings.
Volume
Adjust sound volume, mute device, or enable warning messages.
Backlight Adjust the brightness of touch screen.
Language
Select desired language.
DateTime Set up Time Zone/Date/Time.
Calibration
Calibrate the screen when position deviation occurs.
USB Set the data transmission mode between the navigator and
computer.
Factory Reset
Restore all system settings to factory default values.
Device Settings

When using the navigation software for the first time, an initial setup process starts
automatically. Do as follows:
Select the program language. If your preferred language does not appear on the
screen, tap / or drag the list up or down with your finger to view all available
languages. Tap to select your preferred language. Tap to
confirm your selection, and proceed to the next page.
Read the Software and Database End User Licence Agreement, and tap
if you agree with the terms of use.
The Configuration wizard starts in the selected language. Tap to
continue.
Select the voice guidance language profile. If your preferred language does not
appear on the screen, scroll the list for other available profiles. Tap any item in the list for
a short voice sample. Tap to confirm your selection, and proceed to the
next page.
Initialization and
Software Activation

Set your preferred time format and units. Tap to confirm your
preferences.
Set your preferred route planning options. Tap to confirm your
preferences.
You are offered to watch the tutorial that leads you through the basic steps of
navigation. Tap if you would like to get an instant understanding of the
functions of your software. You can run it later if you choose .
You are now asked whether you allow the software to collect usage information and
GPS logs that may be used for improving the application and the quality and coverage of
maps. Tap to allow the anonymous statistics or to disable this
function.
The initial setup is now complete. The application starts.
Initialization and
Software Activation
EN
EN - 9

Introduction
After the initial setup, and whenever the software is started, the Navigation menu
appears. You have the following options:
•Tap to select your destination by entering an address or selecting
a place of interest, a location on the map or one of your Favourite destinations.
You can also look up your recent destinations from the Smart History, enter a
coordinate or use the location saved in a photo.
•Tap to display the route parameters. You can view the route in its
full length on the map. You can also perform route-related actions such as
editing or cancelling your route, setting a start point for the route, picking route
alternatives, avoiding parts of the route, simulating navigation or adding the
destination to your Favourites.
•Tap to customize the way the navigation software works, watch the
Tutorial, simulate demo routes, or to run some additional applications.
•Tap to start navigating on the map.
•Tap to stop navigation and exit the software.
Navigation
EN
EN - 10
