Prestigio GV4700BT User manual

EN-1
CAUTION
1. To reduce the risk of electric shock, do not remove the cover (or back). No
user-serviceable parts inside. Refer servicing to qualified service personnel.
2. The manufacturer should not hold responsibility for the damage caused by any
substitutions and modifications of the product without authorization from the
manufacturer or authorized unit.
WARNING
The device should not be exposed to dripping or splashing and no objects filled with
liquids should be placed on the device.
To prevent the GPS from being damaged, be sure to keep the GPS out of direct
sunlight or heat. Maintain well-ventilated conditions around the unit to avoid
overheating.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
Important Safety
Instructions
EN

EN-2
Accessories List
ITEM NAME QTY
Car Charger 1
Pouch
（for GV5700/5700BT）
1
USB Cable 1
Stylus Pen 1
Driver/Documentation CD 1
User Manual 1
Warranty Card
Smart Mount
Userguide
(for smart mount)
Accessories
1
EN
1
1

EN-3
Front and Side View
1. LCD Touch Screen
Tap the screen with touch pen or finger to select menu commands or to enter
information.
2. Light sensor
3. Headphone Port
Connects to stereo headphones or headsets.
4. microSD Slot
Receives microSD memory card for data access or memory expansion.
5. Reset Button
Press to reset the device
6. Speaker
Emits sound, voice or music.
View of Main Unit
1
23
4
6
EN
5

EN-4
Top and Bottom View
1. Power Button
Press to power ON/OFF device.
2. Mini-USB Port
Connect to USB Cable for data access or battery charging
View of Main Unit
1
EN
2

EN-5
Inserting microSD Card
zTo insert a microSD card, place
connector towards device and card
label towards the front side of the
device.
zTo remove a microSD card, gently
press the edge of the card to release
the safety lock and pull the card out of
the slot.
NOTE:
Please always make sure that no application is accessing the microSD
card before extraction.
Connecting to External USB Device (Charging)
zInsert the mini USB connector into the
appropriate mini USB port.
zInsert the other USB connector into the
USB port on PC to start charging.
Device Connections
EN

EN-6
Connecting to Earphones
zInsert earphone jack (earphones not
included) into the appropriate
earphone port to switch audio output
from device speaker to earphone.
NOTE:
High volume level is a potential risk to your hearing. Please turn down
the volume before connecting the earphone and gradually turn up the
volume to a comfortable level.
Connecting to Car Charger
zInsert USB connector into the appropriate
USB port.
zInsert car charger connector into vehicle
12V accessory/cigarette socket to start
charging.
NOTE:
Please connect the car charger to vehicle 12V accessory/cigarette
socket after vehicle engine is started to protect the device from sudden
surges in current.
Device Connections
EN

EN-7
About Rechargeable Battery
The device is equipped with a built-in rechargeable battery. Please fully charge the
battery (for at least 8 hours) before initial use. The battery status indicator glows in red
color when charging, and turns green color when the battery is full. Charging time is
approximately 2 hours.
Working conditions and precautions for the rechargeable battery
zDevice with new batteries should be fully charged before initial use.
zBattery should only be used and charged when temperatures are between 0°~
37°C.
zIt is not necessary to start charging the device before the battery is fully
discharged.
NOTE:
Please connect the car charger to vehicle 12V accessory/cigarette
socket after vehicle engine is started to protect the device from sudden
surges in current.
Cautions on Battery
Charging
EN

EN-8
1. Press and hold Power Button to turn
on the device.
2. Shortly after the loading screen is
shown, the main menu will be
displayed.
3. Tap the corresponding buttons with
touch pen included to navigate
various functions.
4. Press and hold Power Button to turn
off the device or to allow the device to
enter sleep mode.
5. Tap Sleep icon to enter sleeping
mode or OFF icon to complete turn
off the device.
Getting Started
Sleep OFF
EN

EN-9
Bluetooth function (optional)
The following is shown how to select, switch on/off the Bluetooth function
1. Tap on Function icon on the main
menu.
2. Tap on Bluetooth icon to start using
Bluetooth function.
3. Tap on ON/OFF icon to enable/
disable Bluetooth function.
4. Tap Info icon to review Bluetooth
information.
5. Tap on to reset a new PIN code.
The default setting is 1234.
Bluetooth Function
Main Menu
EN

EN-10
How to operate the Bluetooth function.
1. Tap on DUN icon or HF icon on the
main menu.
2. Tap on Paired List icon to start
pairing with mobile phone device with
GPRS function.
3. Please make sure Bluetooth function
on mobile phone is detectable by
other devices.
4. Tap on to start searching
process.
5. Mobile phone name desired for
connection will be displayed on the
list when search is completed.
6. Tap on the mobile phone name and
tap on to establish connection.
7. Enter PIN code 1234 when PIN
number is required on mobile phone
device.
8. Tap on to disconnect current
Bluetooth connection.
9. Select mobile phone name from
Paired List and tap on to
re-connect from previously connected
mobile phone.
10. Select mobile phone name from
Paired List and tap on to remove
it from the list.
Bluetooth Connection
EN

EN-11
1. Tap on HF icon on the main menu.
NOTE:
Please refer to Bluetooth Connection
section before connecting by Hands Free
function.
2. Tap on Dial icon to make phone calls.
3. Tap on digit buttons and tap on
to start dialing.
4. Tap on to answer a call if it is on
standby.
5. Tap on to end call.
6. Tap on to switch the call to
mobile phone or switch it back to
device.
7. Tap on to show dialing keypad
to dial more numbers.
8. Tap on Phone Book icon to view
phonebook entries.
9. Tap on to browse phonebook
entries stored in SIM card.
10. Tap /to scroll pages up/down.
11. Select a phonebook entry and tap
to make the call.
12. Select a phonebook entry and tap
to delete it.
Hands Free Function
EN

EN-12
13. Tap on Calls List icon to review call
history.
14. Tap to view Dialed Call list,
Received Call list, and Missed Call
list.
15. Tap /to scroll pages up/down.
16. Select a phonebook entry and tap
to make the call.
17. Select a phonebook entry and tap
to delete it.
Hands Free Function
EN

EN-13
FM function (optional)
1. Tap on Function icon on the main
menu.
2. Tap on FM icon to start using
Bluetooth function.
3. Tap on /to tune FM
frequency down/up.
4. Tap on to open the selected
frequency for broadcast.
5. Tap on to save current FM
station.
6. Tap on to cancel settings and
exit.
FM Function
EN

EN-14
1. Tap /and language option to
select system language.
2. Tap to confirm selection
3. Carefully read through Software and
Database End User License
Agreement. Tap to agree with
the terms of use.
4. The configuration wizard will be
displayed in the selected language.
Tap to continue.
5. Tap /to display all available
voice guidance language profile. Tap
on a language for a short voice sample
and tap to confirm selection.
6. Select desired time format and units
and tap to confirm selection.
7. Select desired route navigation option
and tap to confirm selection.
8. The initialization is now complete. Tap
to continue.
9. Tap to start tutorial that
review the basic steps of navigation.
Tap to skip introduction.
10. Tap to activate navigation
software right away.
NOTE:
Device must be connected to an active Internet connection to start
activation process.
Initialization and
Software Activation
EN

EN-15
Introduction
Tap on Navigation icon to start navigation software. The options are displayed as
below:
Tap Destination icon to start navigation function by entering an
address or selecting a Place Of Interest (POI), a location on the
map, or one of Favorite destinations. Recent destinations can
also be displayed from the Smart History.
Tap My Route icon to display routing parameters including
cancelling current route, selecting route alternatives, simulating
navigation, and adding destination to Favorites.
NOTE:
The button remains inactive when no destination is selected.
Tap More… icon to adjust software settings, go through Demo &
Tutorial, execute additional applications, or received extra content
from www.naviextras.com
Tap Show Map icon to start navigating on the map.
Tap Exit icon to stop navigation and exit the software.
Navigation
EN

EN-16
Destination Menu
In the navigation menu, tap on Destination icon to start navigation function.
Enter an address as routing destination.
Select a POI as routing destination.
Select a location on the map to navigate to.
Select a routing destination from favorite list.
Navigate to the latest destination as displayed.
Select one of latest destinations from history list.
Navigation
EN

EN-17
Navigating to An Address
1. In the navigation menu, tap Destination icon and then Find Address icon.
2. Current country/state/town (location attributes) is set as default location.
3. Tap Select Street to continue or Back to return.
4. Tap location attributes desired to change its values.
5. After tapping a few characters, the device automatically matches character strings
with names of location in database.
6. Tap to confirm selection or to correct entry.
7. Tap to browse a list of location names matching input. Tap an item to
select.
8. Tap and enter a few characters of desired street name.
9. Tap to select street name automatically generated or tap to browse a
list of all street names matching input. Tap an item to select.
10. Tap to enter house number.
11. Tap to complete address entry.
12. Tap to start navigation after system calculation of best desired route.
Navigation
EN

EN-18
Navigating to a Place Of Interest (POI)
In the navigation menu, tap Destination icon and then Find Places icon.
Displays a list of petrol stations along the route, around current
position, or last known location
Displays a list of restaurants along the route, around current
position, or last known location.
Displays a list of parking lots near destination.
Displays a list of accommodations near destination.
Displays all available POI near the following locations:
Near current position.
In a desired city/town.
Near destination of active route
Along the active route.
Navigation
EN

EN-19
The Map screen displays a virtual view of current position and various other
information such as Vehimarker represent current position, orange line showing the
recommended route, buttons and data fields assisting navigating function.
zInformation of current location is displayed at the top of the screen when
destination is not selected. With a confirmed destination, next instruction of
maneuver or next street/road in the route navigation will be displayed.
zTap anywhere on the map to open quick menu with control options.
zTap to explore around the current location. Press directional buttons to
navigate.
zTap to toggle between distance reminders including remaining
distance to destination, estimated time of arrival at destination, and remaining
time of the trip.
zTap to return to navigation menu
Map Screen
EN

EN-20
In the navigation menu, tap More… icon to enter menu. The options are shown as
below:
Tap any of the preinstalled games to start in Demo mode.
Obtain an activation key to play in full version
Download additional games from www.naviextras.com
Tap any of the travel applications to start program.
Start tutorial and demo session that offers basic device function
introduction.
Obtain additional content such as new maps or 3D landmarks.
Configure device settings
Activate the software
NOTE:
Some of the applications may require system activation.
More Menu
prestigio.naviextras.com
EN
