Prestigio GeoVision 4766 User manual

CAUTION
1. To reduce the risk of electric shock, do not remove the cover (or back). No
user-serviceable parts inside. Refer servicing to qualified service personnel.
2. The manufacturer should not hold responsibility for the damage caused by any
substitutions and modifications of the product without authorization from the
manufacturer or authorized unit.
WARNING
The device should not be exposed to dripping or splashing and no objects filled with
liquids should be placed on the device.
To prevent the GPS from being damaged, be sure to keep the GPS out of direct
sunlight or heat. Maintain well-ventilated conditions around the unit to avoid
overheating.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
Important Safety
Instructions
Accessories List
ITEM NAME QTY
Car Charger 1
Pouch
（for GV5766/5766BT）
1
USB Cable 1
Stylus Pen 1
Driver/Documentation CD 1
User Manual 1
Warranty Card
Smart Mount
Userguide
(for smart mount)
Accessories
1
EN
1
1
EN - 1

Front and Side View
1. LCD Touch Screen
Tap the screen with touch pen or finger to select menu commands or to enter
information.
2. Light sensor
3. Headphone Port
Connects to stereo headphones or headsets.
4. microSD Slot
Receives microSD memory card for data access or memory expansion.
5. Reset Button
Press to reset the device
6. Speaker
Emits sound, voice or music.
View of Main Unit
1
2 3
4
6
EN
5
EN - 2
Top and Bottom View
1. Power Button
Press to power ON/OFF device.
2. Mini-USB Port
Connect to USB Cable for data access or battery charging
View of Main Unit
1
2

Inserting microSD Card
zTo insert a microSD card, place
connector towards device and card
label towards the front side of the
device.
zTo remove a microSD card, gently
press the edge of the card to release
the safety lock and pull the card out of
the slot.
NOTE:
Please always make sure that no application is accessing the microSD
card before extraction.
Connecting to External USB Device (Charging)
zInsert the mini USB connector into the
appropriate mini USB port.
zInsert the other USB connector into the
USB port on PC to start charging.
Device Connections
Connecting to Earphones
zInsert earphone jack (earphones not
included) into the appropriate
earphone port to switch audio output
from device speaker to earphone.
NOTE:
High volume level is a potential risk to your hearing. Please turn down
the volume before connecting the earphone and gradually turn up the
volume to a comfortable level.
Connecting to Car Charger
zInsert USB connector into the appropriate
USB port.
zInsert car charger connector into vehicle
12V accessory/cigarette socket to start
charging.
NOTE:
Please connect the car charger to vehicle 12V accessory/cigarette
socket after vehicle engine is started to protect the device from sudden
surges in current.
Device Connections
EN
EN - 3

About Rechargeable Battery
The device is equipped with a built-in rechargeable battery. Please fully charge the
battery (for at least 8 hours) before initial use. The battery status indicator glows in red
color when charging, and turns green color when the battery is full. Charging time is
approximately 2 hours.
Working conditions and precautions for the rechargeable battery
zDevice with new batteries should be fully charged before initial use.
zBattery should only be used and charged when temperatures are between 0°~
37°C.
zIt is not necessary to start charging the device before the battery is fully
discharged.
NOTE:
Please connect the car charger to vehicle 12V accessory/cigarette
socket after vehicle engine is started to protect the device from sudden
surges in current.
Cautions on Battery
Charging
EN
EN - 4
1. Press and hold Power Button to turn
on the device.
2. Shortly after the loading screen is
shown, the main menu will be
displayed.
3. Tap the corresponding buttons with
touch pen included to navigate
various functions.
4. Press and hold Power Button to turn
off the device or to allow the device to
enter sleep mode.
5. Tap Sleep icon to enter sleeping
mode or OFF icon to complete turn
off the device.
Getting Started
Sleep OFF

Bluetooth function (optional)
The following is shown how to select, switch on/off the Bluetooth function
1. Tap on Function icon on the main
menu.
2. Tap on Bluetooth icon to start using
Bluetooth function.
3. Tap on ON/OFF icon to enable/
disable Bluetooth function.
4. Tap Info icon to review Bluetooth
information.
5. Tap on to reset a new PIN code.
The default setting is 1234.
Bluetooth Function
Main Menu
How to operate the Bluetooth function.
1. Tap on DUN icon or HF icon on the
main menu.
2. Tap on Paired List icon to start
pairing with mobile phone device with
GPRS function.
3. Please make sure Bluetooth function
on mobile phone is detectable by
other devices.
4. Tap on to start searching
process.
5. Mobile phone name desired for
connection will be displayed on the
list when search is completed.
6. Tap on the mobile phone name and
tap on to establish connection.
7. Enter PIN code 1234 when PIN
number is required on mobile phone
device.
8. Tap on to disconnect current
Bluetooth connection.
9. Select mobile phone name from
Paired List and tap on to
re-connect from previously connected
mobile phone.
10. Select mobile phone name from
Paired List and tap on to remove
it from the list.
Bluetooth Connection
EN
EN - 5

1. Tap on HF icon on the main menu.
NOTE:
Please refer to Bluetooth Connection
section before connecting by Hands Free
function.
2. Tap on Dial icon to make phone calls.
3. Tap on digit buttons and tap on
to start dialing.
4. Tap on to answer a call if it is on
standby.
5. Tap on to end call.
6. Tap on to switch the call to
mobile phone or switch it back to
device.
7. Tap on to show dialing keypad
to dial more numbers.
8. Tap on Phone Book icon to view
phonebook entries.
9. Tap on to browse phonebook
entries stored in SIM card.
10. Tap /to scroll pages up/down.
11. Select a phonebook entry and tap
to make the call.
12. Select a phonebook entry and tap
to delete it.
Hands Free Function
EN
EN - 6
13. Tap on Calls List icon to review call
history.
14. Tap to view Dialed Call list,
Received Call list, and Missed Call
list.
15. Tap /to scroll pages up/down.
16. Select a phonebook entry and tap
to make the call.
17. Select a phonebook entry and tap
to delete it.
Hands Free Function

FM function (optional)
1. Tap on Function icon on the main
menu.
2. Tap on FM icon to start using
Bluetooth function.
3. Tap on /to tune FM
frequency down/up.
4. Tap on to open the selected
frequency for broadcast.
5. Tap on to save current FM
station.
6. Tap on to cancel settings and
exit.
FM Function
When using the navigation software for the first time, an initial setup process starts
automatically. Do as follows:
Select the program language. If your preferred language does not appear on the
screen, tap / or drag the list up or down with your finger to view all available
languages. Tap to select your preferred language. Tap to
confirm your selection, and proceed to the next page.
Read the Software and Database End User Licence Agreement, and tap
if you agree with the terms of use.
The Configuration wizard starts in the selected language. Tap to
continue.
Select the voice guidance language profile. If your preferred language does not
appear on the screen, scroll the list for other available profiles. Tap any item in the list for
a short voice sample. Tap to confirm your selection, and proceed to the next
page.
Initialization and
Software Activation
EN
EN - 7

Set your preferred time format and units. Tap to confirm your
preferences.
Set your preferred route planning options. Tap to confirm your
preferences.
You are offered to watch the tutorial that leads you through the basic steps of
navigation. Tap if you would like to get an instant understanding of the
functions of your software. You can run it later if you choose .
You are now asked whether you allow the software to collect usage information and
GPS logs that may be used for improving the application and the quality and coverage of
maps. Tap to allow the anonymous statistics or to disable this
function.
The initial setup is now complete. The application starts.
Initialization and
Software Activation
EN
EN - 8
Introduction
After the initial setup, and whenever the software is started, the Navigation menu
appears. You have the following options:
•Tap to select your destination by entering an address or selecting
a place of interest, a location on the map or one of your Favourite destinations.
You can also look up your recent destinations from the Smart History, enter a
coordinate or use the location saved in a photo.
•Tap to display the route parameters. You can view the route in its
full length on the map. You can also perform route-related actions such as
editing or cancelling your route, setting a start point for the route, picking route
alternatives, avoiding parts of the route, simulating navigation or adding the
destination to your Favourites.
•Tap to customize the way the navigation software works, watch the
Tutorial, simulate demo routes, or to run some additional applications.
•Tap to start navigating on the map.
•Tap to stop navigation and exit the software.
Navigation

Destination Menu
In the Navigation menu, tap . The Find menu provides you with the following
options:
•Tap to specify an address as your destination.
•Tap to select a place of interest as your destination.
•Tap to navigate to a location selected on the map.
•Tap to choose from the list of your favourite destinations.
•Tap or to navigate to the recent destination that is shown on the
button.
•Tap to choose from the list of all recent destinations.
•Tap to navigate to a coordinate or to a location saved in a photo.
Navigation
Navigating to An Address
In the Navigation menu, tap , then tap . By default, the screen
proposes the city or town where you are located.
If needed, change the country. Tap the button showing the name of the country.
1. Use the keyboard to enter the name of the country.
2. After entering a couple of characters, the list of countries that match the entered
string appears. Tap the country of your choice.
If needed, change the city/town. Tap the button showing the name of the city/town,
and use the keyboard to enter a part of its name. As you enter letters, the most likely
city/town name is always shown in the input field. You have the following options:
•Tap to select the city/town that is offered in the input field.
•Tap to correct your entry.
•Tap to browse the list of city/town names matching your input.
Select a city/town from the list.
Navigation
EN
EN - 9

Navigating to An Address
Enter the street name:
1. Tap .
2. Use the keyboard to enter a part of the street name.
3. Tap to select the street that is offered in the input field or tap
to browse the list of all streets matching your input. Select a street from the list.
Enter the house number:
1. Tap .
2. Use the keyboard to enter the house number.
3. Tap to finish entering the address.
The map appears with the selected destination in the middle. Tap another map
location if necessary, then tap to confirm the destination.
After a short summary of the route parameters, the map appears showing the entire
route. Wait for a few seconds or tap and start navigating.
Navigation
EN
EN - 10
Navigating to a Place of Interest (POI)
On the Map screen, tap to return to the Navigation menu. In the Navigation
menu, tap , then tap . You are offered the following preset search
categories:
•Tap to get a list of petrol stations along the route or if it is
not available, around your current position or your last known position.
•Tap to get a list of parking lots near the destination or if it
is not available, around your current position or your last known position.
•Tap to get a list of restaurants along the route, around
your current position or your last known position.
•Tap to get a list of accommodation near the destination,
around your current position or your last known position.
You can also tap and search for a place by entering its name.
Navigation

Navigating to a Place of Interest (POI)
If none of the above is appropriate, tap to find a place of interest at the following
locations:
•Tap to search around the current position or if it is not available,
around the last know position.
•Tap to search for a place within a selected city or town.
•Tap to search for a place around the destination of the active
route.
•Tap to search along the active route, and not around a given point.
This is useful when you search for a later stopover that results in a minimal
detour only, such as searching for upcoming petrol stations or restaurants.
Navigation
Example for Navigating to a Place of Interest
Example: To find a park around your destination, do as follows (starting from the
Navigation menu):
Tap .
Tap .
Tap .
Tap .
The list of place categories appears. Tap or slide your finger to browse the list,
and tap .
Tap to browse the whole category, or tap to narrow
down your search.
Tap any of the list items.
Check the details and the location of the place, and then tap .
After a short summary of the route parameters, the map appears showing the entire
route. Wait for a few seconds or tap and start navigating.
Navigation
EN
EN - 11

The Map screen is the most important and frequently used screen of the software. The
Vehimarker (a blue arrow by default) represents your current position, and the orange
line shows the recommended route. There are screen buttons and data fields on the
screen to help you navigate. During navigation, the screen shows route information.
•At the top of the screen, you see your heading and the house numbers on left and
right if you have not selected a route destination. When navigating a route, you see
the next manoeuvre and the next street/road on your route. Tap either of them to
open the route itinerary.
•Tap to open the Quick menu with a selection of functions that are useful
during navigation.
•Tap the map anywhere to explore the map around your current position. Additional
map control buttons appear.
•Tap to open three data fields on the map. Tap any of them to
suppress the others. The default values (you can change them in Map settings):
•the remaining distance to the destination,
•the estimated time of the arrival at the destination, and
•the remaining time of the trip.
•Tap to return to the Navigation menu.
More Screen
EN
EN -12
The 'More' menu provides you with various options and additional applications. In the
Navigation menu, tap .
•: Fine-tune route planning options, change the look of the Map screen,
turn on or off warnings, or restart the Configuration wizard, etc.
•: Visit www.naviextras.com to get additional content, such as new maps or
3D landmarks and useful applications.
•: Access multimedia applications: the Picture Viewer or the Music Player.
•: Access travel applications: the unit converter, the clothing size converter
or country information.
•: Access other useful applications: the calculator, the fuel and maintenance
monitor, sunrise and sunset information or the trip and track log monitor.
•: Read the Tutorial to get instant understanding of the functions of your
software, or run the Demo to watch sample route simulations to see how
navigation works.
More Menu

In the Navigation menu, tap , then tap . The Settings menu provides
you with the following options (scroll the list to see all):
•: Adjust the different sound volumes, change the voice guidance
profile, or enable and set up warnings.
•: Change the function buttons in the Quick menu of the Map screen.
•: Before selecting one of the Lorry profiles as the Vehicle type used
in route calculation, set up the editable lorry attribute profile with the parameters
of your lorry. These parameters will be used in route calculation.
•: You can turn Smart Routes on or off, select whether to take traffic
events into consideration when calculating the route or you can change the
radio station.
•: Select the type of vehicle you are driving, the road types used in
route planning, and the route planning method.
•: These settings determine how Green routes will be calculated.
Settings
They are also used to display the cost and CO2emission of routes.
•: Adjust map related settings: change the daytime and night colour
schemes, change the default zoom level, switch between 2D and 3D map,
suppress buildings or change the Vehimarker.
•: Change the values of the data fields on the Map screen, show or
suppress junction views and signpost or display a route progress bar on the left
of the map.
•: Turn the menu animations on or off, select a different skin for the
application, adjust the display backlight.
•: Change the program language, the time format and units or the
time zone.
•: Turn the automatic trip or track log saving on or off, check the
current size of the trip database.
•: The application collects usage information and GPS logs that may
be used for improving the application and the quality and coverage of maps.
Here you can enable or disable collecting these logs.
•: Modify the basic software parameters set during the initial setup
process.
•: Delete all saved data and reset all settings to their factory defaults.
Settings
EN
EN - 13

Take steps described in the tables below to solve simple problems before contacting
customer service.
NOTE:
Immediately turn off the device and disconnect the power adapter if the
device is not working properly. Never try to repair the unit without
authorized professionals for it may damage the unit.
Troubleshooting
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
There is no
sound.
The volume may be turned
down or mute.
Turn up the volume or turn
on the sound output.
Users cannot
turn on the unit.
The adaptor is not
connected well.
Connect the adaptor
correctly.
The built-in rechargeable
battery is weak.
Use the adaptor to supply
power or charge the
battery.
There is no
picture. The brightness may be
turned down.
Adjust the brightness of the
LCD.
The unit cannot
receive satellite
signals or cannot
orient.
The unit work may be
obstructed by buildings or
metal blocks.
Make sure to use the unit
outdoors; if in vehicle, you
can use the external GPS
antenna to solve this
problem.
EN
EN - 14
To establish connection with PC for data access and synchronization, please execute
setup file included in the Driver/Documentation CD or download the file from Microsoft
website to install:
Microsoft Active Sync® software for operating system Microsoft XP or earlier
versions
(http://www.microsoft.com/windowsmobile/en-us/downloads/microsoft/activesync-dow
nload.mspx)
and/or
Microsoft Mobile Device Center® software for operating system Microsoft Vista
(http://www.microsoft.com/windowsmobile/en-us/downloads/microsoft/device-center-d
ownload.mspx).
Please refer to its user manual for more detailed instructions.
Troubleshooting
PC Connection
Irregularity or
instability in
signal receiving.
The built-in rechargeable
battery is weak.
Use the adaptor to supply
power or charge the
battery.
The unit may be obstructed
by material, such as heat
insulation paper.
Remove the material.
The movement of the unit is
too strong.
Avoid any movement of the
unit.
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION

MODEL GV4766/4766BT GV5766/5766BT
Navigation Software IGO IGO
GPS Chipset SiRF Atlas V 664MHZ SiRF Atlas V 664MHZ
Channels 64 64
Antenna Internal Internal
Interface USB USB
Display size 4.3" 5"
Resolution 480*270 800*480
Display type TFT Touch screen TFT Touch screen
RAM 128MB, DDR2 128MB, DDR2
Flash 4GB 4GB
Expansion slot
Micro SD-Card slot, max
8GB
Micro SD-Card slot, max
8GB
Battery type/capacity Li-polymer 950mAh Li-polymer 1250mAh
Operating System Microsoft Window CE6.0 Microsoft Window CE6.0
Speaker 1w 8ohm built-in speaker 1w 8ohm built-in speaker
Video formats supported AVI AVI
Audio formats supported MP3 MP3
Earphone jack 2.5mm mini jack 2.5mm mini jack
Operating Temperature 0~ 60ºC 0~ 60ºC
Operating humidity 10% to 90%
non-condensing
10% to 90%
non-condensing
Note: The flash size can be changed
Technical Specifications
As the Prestigio products are constantly updated and improved, your device may have a
slightly different appearance or modified functionality than presented in this Quick start
Guide.
Disclaimer
EN
EN - 15
