Stylish Design and Premium Performance
®
Owner’s Manual

Copyright©2006
Pride Mobility Products Corp.
INFMANU1807/RevJ/Aug 2006
SAFETY GUIDELINES
The symbols below are used throughout this owner's manual and on the power chair to identify warnings and
important information. It is very important for you to read them and understand them completely.
WARNING! Failure to follow designated procedures can cause either personal injury, component
damage, or malfunction (black symbol on yellow triangle with black border).
MANDATORY! These actions should be performed as specified. Failure to perform mandatory
actions can cause injury to personnel and/or damage to equipment (white symbol on blue dot
with white border).
PROHIBITED! These actions are prohibited. These actions should not be performed at any time or
in any circumstances. Performing a prohibited action can cause injury to personnel and/or damage
to equipment (black symbol with red circle and red slash).
www.pridemobility.com Jet 7

Jet 7 www.pridemobility.com 3
CONTENTS
I. INTRODUCTION..................................................................................................................................... 4
II. SAFETY..................................................................................................................................................... 6
III. YOUR POWER CHAIR........................................................................................................................14
IV. ASSEMBLY.............................................................................................................................................19
V. DISASSEMBLY..................................................................................................................................... 20
VI. COMFORT ADJUSTMENTS............................................................................................................23
VII. OPERATION........................................................................................................................................... 27
VIII.BATTERIES AND CHARGING ........................................................................................................31
IX. CARE AND MAINTENANCE ............................................................................................................35
X. WARRANTY............................................................................................................................................40
Thisowner’smanualiscompiledfromthelatestspecificationsandproductinformationavailableatthetimeofpublication.
Wereservetheright tomakechanges astheybecome necessary.Anychangesto ourproductsmay causeslightvariations
betweentheillustrationsandexplanationsinthis manualandthe productyouhave purchased.

4 www.pridemobility.com Jet 7
I. INTRODUCTION
SAFETY
WELCOMEtoPride Mobility Products Corporation (Pride). The power chairyouhavepurchasedcombines state-of-
the-artcomponentswithsafety,comfort,andstyling inmind.Weareconfident thatthesedesignfeatureswillprovideyou
with the conveniencesyou expect duringyour daily activities.Once you understand howto safelyoperateandcarefor
yourpower chair,it should giveyouyearsof trouble free operationandservice.
Readandfollowallinstructions, warnings,andnotesinthis manualbeforeattemptingtooperate yourpowerchairforthe
firsttime. In addition, your safety dependsuponyou,as well as your provider, caretaker, or healthcareprofessionalin
usinggoodjudgement.
Ifthere isanyinformation inthismanualwhich youdonot understand, orifyou requireadditionalassistancefor setupor
operation,pleasecontactyourauthorized Pride Provider.Failuretofollowtheinstructionsinthismanual and those
locatedon yourpowerchaircanleadtopersonal injuryand/ordamagetothepowerchair,includingvoidingthe
warranty.
PURCHASER’S AGREEMENT
Byacceptingdelivery of this product, you promisethatyouwill not change, alter,or modify this productor removeor
renderinoperableorunsafeanyguards,shields,orothersafetyfeaturesofthisproduct;fail,refuse,orneglecttoinstallany
retrofitkitsfrom time to time provided by Pride to enhance or preserve the safe useofthisproduct.
INFORMATION EXCHANGE
Wewanttohearyourquestions,comments,andsuggestionsaboutthismanual.Wewouldalsoliketohearaboutthesafety
andreliability of yournewpower chair,and abouttheserviceyou received fromyourauthorizedPride Provider.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new
products,andnew options that can increase your ability to use andenjoyyourpowerchair.Please feel free to contact us
attheaddressbelow:
PrideMobility ProductsCorporation
Attn:Customer CareDepartment
182SusquehannaAvenue
Exeter, PA18643-2694
[e-mail]
800-424-8205
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and
we will be glad to send you a new one immediately.

Jet 7 www.pridemobility.com 5
MyAuthorized Pride Provideris:
Name:_____________________________________________________________________________________
Address:____________________________________________________________________________________
PhoneNumber:_______________________________________________________________________________
PurchaseDate:________________________________________________________________________________
PRIDE OWNERS CLUB
Asan owner of a Pride product,youareinvitedtoregister your product’swarranty and enroll in thePrideOwnersClub.
You may do so by filling out and returning your enclosed product registration card or by visiting Pride's web site at
www.pridemobility.com.Asaregistered member,eachtimeyouvisitoursite,youwillhave accesstothemostinteractive
andhonesteducationalvenueavailabletoday forpeople withmobilityneeds,theirfamilies,andfriends.
Fromour home page,select“Owners Club” toenterapage dedicated tocurrentandpotential Prideproductowners.You
willgain accesstointerviews, stories,recreationideas, dailylivingtips, productandfunding information,andinteractive
messageboards. Thesemessageboardsinvite youtocommunicatewith otherPridecustomers as wellasPride represen-
tativeswho are availabletoassistyou with anyquestionsorconcerns you mayhave.
I. INTRODUCTION

6 www.pridemobility.com Jet 7
II. SAFETY
SAFETY
MANDATORY! Do not operate your new power chair for the first time without completely reading
and understanding this owner’s manual.
Your powerchairisa state-of-the-artlife-enhancementdevicedesignedtoincreasemobility.Prideprovidesanextensive
varietyof products tobest fit the individualneeds of the powerchair user. Please be aware that thefinal selection and
purchasing decision regarding the type of power chair to be used is the responsibility of the power chair user, who is
capableof makingsuchadecision, andhis/herhealthcareprofessional (i.e.,medicaldoctor, physicaltherapist,etc.).
Thecontents ofthismanualare basedontheexpectation thatamobilitydevice experthasproperlyfitted the powerchair
tothe userandhas assisted theprescribinghealthcare professionaland/ortheauthorized PrideProviderinthe instruction
processfor the use of theproduct.
Therearecertainsituations,includingsomemedicalconditions,wherethepowerchairuserwillneedto practiceoperating
the power chair in the presence of a trained attendant.Atrained attendant can be defined as a family member or care
professionalspeciallytrainedinassistingapowerchairuserinvariousdailylivingactivities.
Asyoubeginusingyourpowerchair duringdaily activities,youwillprobablyencountersituationsinwhichyouwillneed
somepractice.Simplytakeyourtimeandyouwillsoonbeinfullandconfidentcontrolasyoumaneuverthroughdoorways,
onandoffofelevators, up and down ramps, and over moderate terrain.
Belowaresomeprecautions,tips,andothersafetyconsiderationsthatwill helpyou becomeaccustomed tooperating your
powerchairsafely.
Modifications
Pridehasdesigned andengineeredyourpowerchairtoprovidemaximummobilityandutility.Awiderangeofaccessories
isavailablefromyourauthorized Pride Provider to further customize your power chair tobetter suityour needs and/or
preferences.However,under no circumstancesshouldyoumodify,add,remove,ordisableany feature, part,orfunction
ofyour power chair.
WARNING! Do not modify your power chair in any way not authorized by Pride. Unauthorized
modifications may result in personal injury and/or damage to your power chair.
Pre-Ride Safety Check
Gettoknowthefeelofyourpowerchairanditscapabilities.Priderecommendsthatyouperformasafetycheckbefore
eachusetomakesureyourpowerchairoperatessmoothlyand safely.SeeIX.“Careand Maintenance.”
Performthefollowinginspectionspriortousingyourpowerchair:
!Checkfor proper tireinflation.Maintain35psi(2.4bar)ineachtire if equippedwithpneumatictires.
!Checkallelectrical connections. Make sure they are tight and not corroded.
!Checkallcontroller connections to the electronics tray.Makesuretheyaresecuredproperly.
!Checkthe brakes. See IX. “CareandMaintenance.”
!Checkbattery charge. See VIII. “Batteries and Charging.”
NOTE: If you discover a problem, contact your authorized Pride Provider for assistance.

Jet 7 www.pridemobility.com 7
II. SAFETY
Weight Limitations
Yourpowerchairis ratedforamaximum weightcapacity.Pleaserefertothe specificationstablefor thislimit.
WARNING! Exceeding the weight capacity voids your warranty and may result in personal injury
and/or damage to your power chair. Pride will not be held responsible for injuries and/or property
damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may result in personal injury and/or property damage.
Tire Inflation
Ifyour powerchairis equippedwithpneumatic tires,youshould checkorhave theairpressure checkedregularly.Proper
inflationpressures willprolongthe lifeofyour tiresandhelp ensurethesmooth operationofyour powerchair.
WARNING! It is important that 35 psi (2.4 bar) tire pressure be maintained in pneumatic tires at all
times. Do not underinflate or overinflate your tires. Low pressure may result in loss of control, and
overinflated tires may burst. Failure to maintain 35 psi (2.4 bar) tire pressure in pneumatic tires at
all times may result in tire and/or wheel failure, causing serious personal injury and/or damage to
your power chair.
WARNING! Inflate your power chair drive tires from a regulated air source with an available pressure
gauge. Inflating your tires from an unregulated air source could overinflate them, resulting in a
burst tire and/or personal injury.
Incline Information
Moreandmorebuildingshaverampswithspecifieddegreesof inclination,designedforeasyandsafeaccess.Someramps
mayhave turning switchbacks(180-degreeturns)that require youtohavegood cornering skillsonyourpower chair.
!Proceedwithextremecaution as you approach the downgrade of a ramp or other incline.
!Takewideswingswithyourpowerchair’sfrontwheelsaroundany tightcorners.Ifyoudo that,thepowerchair’srear
wheelswill follow a widearc,notcutthe corner short,andnotbumpinto or get hunguponanyrailing corners.
!When driving down a ramp, keep the power chair’s speed adjustment set to the slowest speed setting to ensure a
safelycontrolled descent. SeeVII.“Operation.”
!Avoidsudden stops and starts.
Whenclimbinganincline,try tokeepyourpowerchairmoving.Ifyoumuststop,startupagainslowlyandthenaccelerate
cautiously.Whendrivingdownanincline,setyourpowerchairtothe slowest setting and drive in the forward direction
only. If your power chair starts to move down the incline faster than you anticipated or desired, allow it to come to a
completestop byreleasingthejoystick, then pushthejoystick forward slightlytoensurea safelycontrolleddescent.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline.
Drive your power chair straight up the incline. This greatly reduces the possibility of a tip or a fall.
Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered
with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the power chair in freewheel
mode while seated on it or standing next to it. Doing so may result in personal injury and/or
damage to your power chair.
WARNING! Never travel down an incline backwards. This may result in personal injury.
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated

8 www.pridemobility.com Jet 7
II. SAFETY
in figure 1, do not, under any circumstances, exceed the incline guidelines or any other
specifications presented in this manual. Doing so could cause instability in your power chair,
resulting in personal injury and/or damage to your power chair.
Incompliance with theAmericanswith DisabilitiesActof1990,allhandicappublic access ramps arerequiredtohavea
maximumslope of 5° (8.7%). Therefore,Priderecommendsthat the maximum slope ofaninclineyouattempt to safely
ascend or descend on your power chair does not exceed 5° (8.7%). See figure 1.
WARNING! Any attempt to climb or descend a slope steeper than 5° (8.7%) may put your power
chair in an unstable position and cause it to tip, resulting in personal injury.
Figure 1. Maximum Safe Angle (Ascending and Descending)
Braking Information
Yourpowerchairisequippedwith two powerfulbrakesystems:
1. Regenerative—uses electricitytorapidlyslow thevehiclewhenthe joystickreturnsto the center/stopposition.
2. DiscParkBrake—activates mechanicallyafterregenerativebrakingslowsthevehicle tonear stop,orwhenpoweris
removedfrom the systemforanyreason.
Cornering Information
Whileyour power chairisequippedwithrear caster wheelsandfrontanti-tip wheels, excessively highcorneringspeeds
canstill create the possibilityof tipping. Factors whichaffect the possibility oftipping include, but arenot limited to:
corneringspeed,steering angle(howsharplyyouareturning),unevenroadsurfaces,inclinedroadsurfaces,ridingfroman
area of low traction to an area of high traction (such as passing from a grassy area to a paved area – especially at high
speedwhileturning),andabruptdirectional changes. High cornering speeds are not recommended. If you feel that you
maytipoverin acorner, reduceyourspeedandsteering angle(i.e.,lessenthesharpness oftheturn)toprevent yourpower
chairfromtipping.
WARNING! When cornering sharply, reduce your speed. This greatly reduces the possibility of a
tip or fall. To avoid personal injury and/or property damage, always exercise common sense when
cornering.
Outdoor Driving Surfaces
Yourpowerchairisdesignedtoprovideoptimumstabilityundernormaldrivingconditions—dry,levelsurfacescomposed
ofconcrete,blacktop,orasphalt. However,Priderecognizesthattherewill betimes whenyouwillencounterothersurface
types.Forthisreason,yourpowerchairisdesignedtoperformadmirablyonpackedsoil,grass,andgravel.Feelfreeto
useyourpowerchairsafelyonlawnsandinparkareas.
!Reduceyour power chair’sspeedwhendrivingon uneven terrain and/orsoftsurfaces.
!Avoid tallgrassthatcanentangletherunning gear.
!Avoid looselypackedgravelandsand.
!Ifyou feelunsureabout adrivingsurface,avoid thatsurface.

Jet 7 www.pridemobility.com 9
Freewheel Mode
Your powerchairisequipped with amanualfreewheel lever toallowformanual maneuverability byatrainedattendant.
Formore information abouthowtoplace your powerchairintoand out offreewheelmode,see III. “YourPowerChair.”
WARNING! Do not use your power chair in freewheel mode without an attendant present. Personal
injury may result.
WARNING! Do not attempt to personally place your power chair in freewheel mode while seated
on it. Personal injury may result. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline. The chair could
roll uncontrollably on its own, causing personal injury.
Stationary Obstacles (Steps, Curbs, etc.)
Proceedwithextremecaution when driving near raised surfaces, unprotectedledges and/ordrop-offs (curbs,porches,
stairs,etc.). The correct methodforapproachinga curb is illustratedinfigure2.
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than two inches unless you have the assistance of an attendant.
WARNING! Do not attempt to have your power chair proceed backward down any step, curb, or
other obstacle. This may cause the power chair to tip and cause personal injury.
II. SAFETY
Figure 2. Correct Curb Approach Figure 3. Incorrect Curb Approach
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware
that it may be difficult for traffic to see you when you are seated on your power chair. Obey all
local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with extreme
caution.
Stairs and Escalators
Powerchairsarenotdesigned to travel up or down stairs or escalators.Always usean elevator.
WARNING! Never use your power chair to negotiate steps or escalators. You may cause injury to
yourself and to others and/or damage your power chair.

10 www.pridemobility.com Jet 7
II. SAFETY
Doors
!Determineifthe door opens toward or away from you.
!Driveyourpowerchairgentlyandslowlyforwardtopush thedooropen.Ordriveyourpowerchairgentlyandslowly
backwardto pull the door open.
Elevators
Modernelevatorshaveadooredgesafetymechanismthat,whenpushed, reopens the elevator door(s).
!Ifyouare in the doorway ofanelevatorwhen the door(s) begin to close,pushonthe rubber door edge orallowthe
rubberdoor edge to contact thepowerchair and the door willreopen.
!Usecare that pocketbooks, packages,orpower chair accessories donot become caught in elevatordoors.
Lift/Elevation Products
Ifyouwillbetravelingwithyourpowerchair,youmayfinditnecessarytousealift/elevationproducttoaidintransportation.
Priderecommendsthatyoucloselyreviewtheinstructions,specifications,andsafetyinformationsetforthbythemanufacturer
ofthelift/elevationproduct beforeusingthat product.
WARNING! Never sit on your power chair when it is being used in connection with any type of lift/
elevation product. Your power chair was not designed with such use in mind and any damage or
injury incurred from such use is not the responsibility of Pride.
Figure 4.IdealTransfer Position
Transfers
Transferringontoandoffofyourpowerchairrequiresagoodsense
ofbalance.Alwayshave an attendant or healthcare professional
presentwhilelearningtoproperlytransferyourself.
Toeliminatethepossibilityofinjury,Priderecommendsthatyouor
atrainedattendantperformthefollowingtasksbeforeattemptinga
transfer:
!Turnoffthepowertothecontroller.SeeVII. “Operation.”
!Ensure your power chair is not in freewheel mode. See III.
“YourPowerChair.”
!Turn both caster wheels toward the transfer destination to
improvepowerchairstabilityduringtransfer.
!Makesure both armrestsareflipped up orremovedfromyour
powerchair.
!Flipupthe foot platform, or move the leg rests aside; thiswill
helpto keep yourfeetfrom getting caughtonthefoot riggings
duringthetransfer.
!Reducethedistancebetweenyourpowerchairandtheobject
youaretransferringonto.
WARNING! Before transferring, position yourself as far back as possible in the power chair seat
to prevent the power chair from tipping forward during transfer and causing injury.
WARNING! Avoid using your armrests for weight bearing purposes. Such use may cause the power
chair to tip and cause personal injury.
WARNING! Avoid putting all of your weight on the footrest. Such use may cause the power chair
to tip and cause personal injury.

Jet 7 www.pridemobility.com 11
II. SAFETY
Motor Vehicle Transport
Priderecommends thatyoudo notremainseatedin yourpowerchair whiletravelingina motorvehicle.The powerchair
shouldbestowed in the trunk ofacaror in the back of atruckorvan with the batteries removedandproperlysecured.
WARNING! Do not sit on your power chair while it is in a moving vehicle. Personal injury and/or
property damage may result.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Failure to do so may result in personal injury and/or damage to your power chair.
Positioning Belts
Your authorizedPrideProvider, therapist(s), andotherhealthcareprofessionalsare responsible fordeterminingyourre-
quirementfor a positioningbeltinorder to operateyourpowerchair safely.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely. Serious personal injury may result if you fall from the power chair.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is
your power chair suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be
properly belted into seats approved by the vehicle manufacturer.
Inclement Weather Precautions
Exposureof yourpowerchair to inclementweatherconditions shouldbeavoidedwhenever possible.Ifsuddenlycaught
up in rain, snow, severe cold or heat while operating your power chair proceed to shelter at the earliest opportunity.
Thoroughlydry yourpowerchair before storing,charging,oroperating yourpowerchair.
WARNING! Operating in rain, snow, salt, mist/spray conditions, and on icy/slippery surfaces can
cause personal injury and/or damage to the power chair and electrical system. Maintain and store
your power chair in a dry and clean condition.
Reaching and Bending
Neverreach,lean,or bendwhiledriving yourpowerchair.Ifitis absolutelynecessaryto reach,lean,orbendwhile seated
onyour power chair,it is important tomaintaina stable center of gravityandkeep the power chair from tipping.Pride
recommendsthatthe power chair user determine his/her personallimitationsandpracticebending and reaching in the
presenceofaqualified healthcareprofessional.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the floor by
reaching down between your knees. Movements such as these may change your center of gravity
and the weight distribution of the power chair. This may cause your power chair to tip, possibly
resulting in personal injury.
WARNING!Preventpersonalinjury!Keepyourhands awayfromthetires when driving.Be awarethatloose
fitting clothing can become caught in drive tires.

12 www.pridemobility.com Jet 7
Batteries
Inaddition to following thewarnings below,be suretocomply with all otherbattery handling information. For more
informationabout yourpowerchair’sbatteries,seeVIII. “BatteriesandCharging.”
WARNING! Power chair batteries are heavy. Refer to the specifications table. If you are unable to
lift that much weight, be sure to get help. Lifting beyond your capacity can result in personal
injury.
WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds.
Wash hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery. Charging
a frozen battery may result in personal injury and/or damage to the battery.
Preventing Unintended Movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time,
turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This
will also eliminate the possibility of unintended chair movement from electromagnetic (EMI)
sources. Failure to do so may result in personal injury.
Prescription Drugs/Physical Limitations
Usersmustexercisecareandcommonsensewhenoperatingapowerchair.Thisincludesawarenessofsafetyissueswhen
takingprescribed orover-the-counterdrugs orwhentheuser hasspecificphysical limitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or
if you have certain physical limitations. Some medications and limitations may impair your ability
to operate your power chair in a safe manner.
Alcohol
Thepowerchairuser mustexercisecareandcommon sensewhenoperatinghis/herpower chair.Thisincludesawareness
ofsafetyissues whileundertheinfluenceofalcohol.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this
may impair your ability to operate your power chair in a safe manner.
Removable Parts
WARNING! Do not attempt to lift or move a power chair by any of its removable parts. Personal
injury and/or damage to the power chair may result.
II. SAFETY

Jet 7 www.pridemobility.com 13
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can
have an adverse affect on the performance of electrically-powered mobility vehicles.
Electromagneticand Radio FrequencyInterference can come fromsources such as cellularphones, mobile two-way
radios(such as walkie-talkies), radio stations, TVstations,amateurradio(HAM)transmitters, wireless computer links,
microwavesignals,pagingtransmitters, and medium-range mobile transceivers used by emergencyvehicles. Insome
cases,thesewavescancauseunintendedmovement ordamage tothecontrolsystem.Everyelectrically-poweredmobility
vehiclehasanimmunity(orresistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainstEMI.This
producthasbeentestedand has passed at an immunity level of 20 V/m.
WARNING! Be aware that cell phones, two-way radios, laptops, and other types of radio transmitters
may cause unintended movement of your electrically-powered mobility vehicle due to EMI.
Exercise caution when using any of these items while operating your mobility vehicle and avoid
coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered mobility vehicle
can increase the susceptibility of the vehicle to EMI. Do not modify your power chair in any way
not authorized by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance of other
electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, go to the Resource Center on www.pridemobility.com. If unintended
motion or brake release occurs, turn your power chair off as soon as it is safe to do so. Call Pride at 800-424-8205
to report the incident.
II. SAFETY

14 www.pridemobility.com Jet 7
III. YOUR POWER CHAIR
YOUR POWER CHAIR
Your power chair has two main assemblies: the seat and the power base. See figure 5. Typically, the seating system
includesthearmrests,theseatback,theseatbase,andthe controller.Thepowerbaseassemblyincludes twodrivewheels,
twoanti-tip wheels, two rear casterwheels,fourframeassemblies, two battery boxes, andtheelectricalconnectors.See
figures 5, 6, and7.
SEATBACK
ANTI-TIP WHEELS
ARMRESTS
FOOTRIGGING
(FOOT PLATFORM SHOWN)
CASTERWHEEL
DRIVEWHEEL
CONTROLLER
SEATBASE
BODY SHROUD
SEAT ASSEMBLY
Figure 5. The Jet 7
POWERBASE
ASSEMBLY

Jet 7 www.pridemobility.com 15
III. YOUR POWER CHAIR
BATTERY
CONNECTORS
FRONT TRAPEZE BAR
MOTOR CONNECTOR
Figure 6. Jet 7 Power Base
REARTRAPEZEBAR
MANUAL FREEWHEELLEVER
MOTOR CONNECTOR
MANUAL FREEWHEELLEVER

16 www.pridemobility.com Jet 7
III. YOUR POWER CHAIR
Specifications
Suspension: Limited
DriveWheels: 10 in. solid tires, center-mounted (pneumatictires areoptional)
CasterWheels: 8in.,solid,rear-articulating
Anti-tipWheels: 6in.,solid, front-mounted
MaximumSpeed:¹ Up to 4 mph
GroundClearance:² 2.0 in.
OverallSize:² Length:32.5in.
Width:23in.
TurningRadius:² 17 in.
SeatingOptions: Medium-back(standard)
High-backwithheadrest(optional)
SpecialtySeat(optional)
Drivetrain: Two motor,mid-wheel
Battery:³ 12-volt, U-1 (2)
BatteryCharger: 4-amp onboard
Range:¹ Up to 25 miles
Electronics: 50-ampPGDrives VSI Controller
WeightCapacity: 300 lbs.
ComponentWeights: SeatWeight:36.5 lbs.
FootPlatformWeight:8.5lbs.
Front/RearBatteryBoxWeight:26 lbs.(batteryincluded)
BatteryWeight:24.5lbs.each
BatteryWellFrameWeight:13 lbs.
FrontFrameWeight:2.5lbs.
RightFrameAssemblyWeight:33lbs.
LeftFrameAssemblyWeight:33lbs.
¹Varieswith userweight,terraintype, batteryamphour rating (AH),batterycharge,battery condition,andtire condition.
²Duetomanufacturingtolerances and continued product improvement, this specificationcan besubject tovarianceof
(+ or – ) 3%.
³AGMorGel-Cell type recommended.
NOTE: All specifications subject to change without notice.

Jet 7 www.pridemobility.com 17
III. YOUR POWER CHAIR
Electrical Components
Theelectrical componentsarelocatedon thepowerbase. The batteryconnectorsand motorconnectorsarelocated atthe
rearofthepowerbase.Seefigure6.Theammeter,maincircuitbreaker,controllerconnector,chargerpowercordreceptacle,
andthe charger inhibit connector are located ontheelectronicstray. See figure7.
BatteryConnectors: These are where the battery boxes connect to the power base.
MotorConnectors: These arewhere the motors connectto the power base.
Ammeter:Theammeterdisplays the charger’scurrentoutput in amps.SeeVIII.“Batteries and Charging.”
MainCircuitBreaker:Themaincircuitbreakerisasafetyfeature builtinto yourpower chair.Whenthebatteriesandthe
motorsareheavilystrained(e.g.,fromexcessiveloads),themain circuitbreaker tripstopreventdamagetothemotorsand
theelectronics. Ifthecircuittrips, allowthepowerchair to “rest”forapproximately one minute.Then,push in thecircuit
breakerbutton,turnonthecontroller,andcontinuenormaloperation.Ifthemaincircuitbreakercontinuestotriprepeatedly,
contactyour authorizedPrideProvider.
ControllerConnector:This is where the controller connectstothebatteries,motors,andmotorbrakes.
Charger Power Cord Receptacle: This is where the onboard battery charger cord plugs into the onboard battery
charger. SeeVIII.“BatteriesandCharging.”
ChargerInhibitConnector: This iswherethecharger connects tothecontroller.This connectoriscodedwith colored
dots.Makesure that you align the two colored dots before making the connection.
WARNING! Failure to properly align the connectors can result in damage to the controller, the
charger, and the connectors.
CONTROLLER CONNECTOR
AMMETER
MAIN CIRCUIT
BREAKER
Figure 7. Electronics Tray
CHARGERPOWER
CORDRECEPTACLE
CHARGERINHIBIT
CONNECTOR

18 www.pridemobility.com Jet 7
III. YOUR POWER CHAIR
Figure 8. Drive Mode Figure 9. Freewheel Mode
Manual Freewheel Levers
Foryourconvenience,your power chair is equipped with two manual freewheellevers. The leversare locatedon each
motor.See figures 8 and 9. These levers allow you to disengage the drive motors from the gearboxes and maneuver the
chairmanually.Thisiscalledfreewheelmode.
WARNING! Do not use your power chair while the drive motors are disengaged unless you are in
the presence of an attendant! Do not disengage the drive motors when your power chair is on an
incline. The chair could roll down on its own and cause injury!
WARNING! In freewheel mode, the braking system is disengaged. Only engage the freewheel
mode when on a level surface. Failure to comply could result in injury and/or damage to your
product.
To engage or disengage the drive motors:
1. Rotatethemanual freewheelleversinward toengagethe drivemotorsand placeyourpower chairindrive mode.See
figure8.
2. Rotatethemanual freewheel levers outward to disengage the drive motors and placeyourpowerchairinfreewheel
mode.Seefigure9.
NOTE: If a lever is difficult to move in either direction, rock your power chair back and forth slightly. The
lever should then move to the desired position.
MANUALFREEWHEELLEVERS MANUALFREEWHEELLEVERS

Jet 7 www.pridemobility.com 19
IV. ASSEMBLY
INITIAL ASSEMBLY
Yourpowerchairmayrequiresomeassemblyeitherbeforeinitialuseoraftertransportation.Itmayalsorequiredisassembly
tomake some comfortadjustments.
NOTE: Any nylon insert lock nut removed during the disassembly or adjustment of the power chair must be
replaced with a new nut. Nylon insert lock nuts should not be reused as it may cause damage to the nylon
insert, resulting in a less secure fit. Replacement nylon insert lock nuts are available at local hardware stores
or through your authorized Pride Provider.
Seat Installation
Itmay benecessaryto installtheseat eitherpriortoinitial operationorafter transportingyourpower chair.Mostseatsare
attachedtothepowerbasewith theUniversalMountingSystem(UMS). TheUMSconsistsofuniversalpartsthat maybe
attachedto any medium-back orhigh-backseat, regardless of seatwidth or seat depth. Thetwo main components are
aluminumextrusionsmountedtothe seat base. These extrusions attach to a pair of trapezebars thatare mounted tothe
power base.
WARNING! Do not pick up the seat frame by the armrests. They are free to pivot, and you may lose
control of the seat if they do so, resulting in personal injury or damage to the chair.
To install the seat:
1. Setthetrapezebarstothedesiredheight.Tochange the trapeze bar height, see VI. “ComfortAdjustments.”
2. Tilttheseat back, and slide the rear extrusion onto the reartrapeze bar.See figure 10.
3. Lowerthefrontextrusion onto the front trapezebaruntiltheseat locks into place.
4. Flipthe seat latch safety down. See figure11.
WARNING! Make sure the seat latch safety is flipped down before using your power chair.
5. Installthecontroller into oneofthearmrests. SeeVI.“ComfortAdjustments.”
6. Routethecontrollercableso thatitcannotbepinchedintheseathinge andplugthecableintothecontroller connector
onthe electronics tray.
7. Securethecontrollercable to the armrest receiver with one or more wire ties.
SEAT LATCH SAFETY
REAR
TRAPEZEBAR
Figure 11. Seat Latch Safety
Figure 10. Universal Mounting System
FRONT TRAPEZE BAR FRONT EXTRUSION
REAR EXTRUSION

20 www.pridemobility.com Jet 7
DISASSEMBLY
Yourpowerchairdisassemblesinto eighteasilytransportablecomponentassemblieswithnotoolsrequired.Seefigure12.
Place the power chair in an area where there is ample space to work and move around the unit—three or more feet of
clearanceon all sides. Makesuretheunit is powered offbeforedisassemblingthe chair.
WARNING! Even though no tools are required to disassemble or assemble your power chair, you
should take care not to place your hands or fingers on the areas of the component assemblies
where they may be pinched, as the assemblies “snap” together or “snap” apart.
WARNING! Some power chair components are heavy. You may need assistance to lift or carry
them. Please refer to the specifications table for specific component weights before you
disassemble the power chair.
NOTE: During both the disassembly and the assembly of your power chair, you may find it helpful to engage
the drive motors to secure the unit from rolling. See III. “Your Power Chair.”
FOOTREST
SEAT
BATTERY BOXES
BATTERYWELLFRAME
FRONTFRAME
Figure 12. The Jet 7 Component Assemblies
RIGHTPOWERBASE
FRAMEASSEMBLY LEFT POWER BASE
FRAMEASSEMBLY
V. DISASSEMBLY
TRAPEZEBARS
