Pride Mobility Jet 10 Ultra User manual

Pride
Exeter, PA
1-800-800-8586
St. Catherines, ON
1-888-570-1113

2 www.pridemobility.com Jet 10 Ultra/RevA/Apr04
SAFETY GUIDELINES
Copyright © 2004
Pride obility Products Corp.
INF ANU2731
The symbols below are used throughout this owner's manual and on the power chair to identify warnings and important
information. It is very important for you to read them and understand them completely.
WARNING! Failure to follow designated procedures can cause either personal injury, component
damage, or malfunction ( lack sym ol on yellow triangle with lack order).
MANDATORY! These actions should e performed as specified. Failure to perform mandatory
actions can cause injury to personnel and/or damage to equipment (white sym ol on lue dot
with white order).
PROHIBITED! These actions should e prohi ited. These actions should not e performed at any
time or in any circumstances. Performing a prohi ited action can cause injury to personnel and/
or damage to equipment ( lack sym ol with red circle and red slash).
NOTE: Supplemental information that may e helpful to operate the equipment.

Jet 10 Ultra/RevA/Apr04 www.pridemobility.com 3
I. INTRODUCTION ................................................................................................................................. 4
II. SAFETY ................................................................................................................................................. 6
III. EMI/RFI ................................................................................................................................................ 15
IV. THE JET 10 ULTRA ....................................................................................................................... 16
V. ASSEMBLY......................................................................................................................................... 21
VI. COMFORT ADJUSTMENTS........................................................................................................ 22
VII. BATTERIES AND CHARGING .................................................................................................... 2
VIII. OPERATION ....................................................................................................................................... 31
IX. CARE AND MAINTENANCE ........................................................................................................ 35
X. WARRANTY ........................................................................................................................................ 40
CONTENTS
This owners manual is compiled from the latest specifications and product information available at the
time of publication. We reserve the right to make changes as they become necessary. Any changes to our
products may cause slight variations between the illustrations and explanations in this manual and the
product you have purchased.

4 www.pridemobility.com Jet 10 Ultra/RevA/Apr04
I. INTRODUCTION
SAFETY
WELCOME to Pride Mobility Products Corporation (Pride). The power chair you have purchased combines state-of-
the-art components with safety, comfort, and styling in mind. We are confident that these design features will provide you
with the conveniences you expect during your daily activities. Once you understand how to safely operate and care for
your power chair, it should give you years of trouble free operation and service.
Read and follow all instructions, warnings, and notes in this manual before attempting to operate your power chair for the
first time. In addition, your safety depends upon you, as well as your provider, caretaker, or healthcare professional in
using good judgement.
If there is any information in this manual which you do not understand, or if you require additional assistance for setup or
operation, please contact your authorized Pride Provider. Failure to follow the instructions in this manual and those
located on your power chair can lead to personal injury and/or damage to the power chair, including voiding the
warranty.
PURCHASERS AGREEMENT
By accepting delivery of this product, you promise that you will not change, alter, or modify this product or remove or
render inoperable or unsafe any guards, shields, or other safety features of this product; fail, refuse, or neglect to install any
retrofit kits from time to time provided by Pride to enhance or preserve the safe use of this product.
INFORMATION EXCHANGE
We want to hear your questions, comments, and suggestions about this manual. We would also like to hear about the safety
and reliability of your new power chair, and about the service you received from your authorized Pride Provider.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new
products, and new options that can increase your ability to use and enjoy your power chair. Please feel free to contact us
at the address below:
Pride Mobility Products Corporation
Attn: Customer Care Department
182 Susquehanna Avenue
Exeter, PA 18643-2694
[e-mail]
800-424-8205

Jet 10 Ultra/RevA/Apr04 www.pridemobility.com 5
I. INTRODUCTION
PRIDE OWNERS CLUB
As an owner of a Pride product, you are invited to register your product's warranty and enroll in the Pride Owners Club.
You may do so by filling out and returning your enclosed product registration card or by visiting Pride's web site at
www.pridemobility.com. As a registered member, each time you visit our site, you will have access to the most interactive
and honest educational venue available today for people with mobility needs, their families, and friends.
From our home page, select "Owners Club" to enter a page dedicated to current and potential Pride product owners. You
will gain access to interviews, stories, recreation ideas, daily living tips, product and funding information, and interactive
message boards. These message boards invite you to communicate with other Pride customers as well as Pride represen-
tatives who are available to assist you with any questions or concerns you may have.
My authorized Pride Provider:
Name:_____________________________________________________________________________________
Address:____________________________________________________________________________________
Phone Number:______________________________________________________________________________
Purchase Date:_______________________________________________________________________________
NOTE: If you ever lose or misplace your product registration card or your copy of this manual,
contact us and we will e glad to send you a new one immediately.

6 www.pridemobility.com Jet 10 Ultra/RevA/Apr04
II. SAFETY
Corrosive chemicals contained in attery. Use only AGM or Gel-Cell atteries to
reduce the risk of leakage or explosive conditions.
This product has een tested and passed at an immunity level of 20 V/m.
Read and follow the information in the owners manual.
Maximum seating weight.
Locked and in drive mode.
Place unit on level ground and stand ehind or to one side when changing from
drive mode to freewheel mode or freewheel mode to drive mode.
Unlocked and in freewheel mode.
Battery Configuration:
T = Terminal Post
Connect Red wire to T with +
Connect Black wire to T with 
PRODUCT SAFETY SYMBOLS
The symbols below are used on the power chair to identify warnings, mandatory actions, and prohibited actions. It is very
important for you to read and understand them completely.

Jet 10 Ultra/RevA/Apr04 www.pridemobility.com 7
II. SAFETY
Do not remove anti-tip wheels.
Do not use a cell phone, walkie/talkie, laptop, or other radio transmitter while
operating.
Avoid exposure to rain, snow, ice, salt, or standing water whenever possi le.
Maintain and store in a clean and dry condition.
Removal of grounding prong can create electrical hazard. If necessary, properly
install an approved 3-pronged adapter to an electrical outlet having 2-pronged
plug access. Failure to heed could result in personal injury and/or property
damage.
Prevent personal injury and equipment damage. Do not connect an extension
cord to the AC/DC converter or the attery charger.

8 www.pridemobility.com Jet 10 Ultra/RevA/Apr04
II. SAFETY
SAFETY
MANDATORY! Do not operate your new power chair for the first time without completely reading
and understanding this owners manual.
Your power chair is a state-of-the-art life-enhancement device designed to increase mobility. Pride provides an extensive
variety of products to best fit the individual needs of the power chair user. Please be aware that the final selection and
purchasing decision regarding the type of power chair to be used is the responsibility of the power chair user, who is
capable of making such a decision, and his/her healthcare professional (i.e., medical doctor, physical therapist, etc.).
The contents of this manual are based on the expectation that a mobility device expert has properly fitted the power chair
to the user and has assisted the prescribing healthcare professional and/or the authorized Pride Provider in the instruction
process for the use of the product.
There are certain situations, including some medical conditions, where the power chair user will need to practice operating
the power chair in the presence of a trained attendant. A trained attendant can be defined as a family member or care
professional specially trained in assisting a power chair user in various daily living activities.
As you begin using your power chair during daily activities, you will probably encounter situations in which you will need
some practice. Simply take your time and you will soon be in full and confident control as you maneuver through doorways,
on and off of elevators, up and down ramps, and over moderate terrain.
Below are some precautions, tips, and other safety considerations that will help the user become accustomed to operating
the power chair safely.
Modifications
Pride has designed and engineered your power chair to provide maximum mobility and utility. A wide range of accessories
is available from your authorized Pride Provider to further customize your power chair to better suit your needs and/or
preferences. However, under no circumstances should you modify, add, remove, or disable any feature, part, or function
of your power chair.
WARNING! Do not modify your power chair in any way not authorized y Pride. Unauthorized
modifications may result in personal injury and/or damage to your power chair.
Pre-Ride Safety Check
Get to know the feel of your power chair and its capabilities. Pride recommends that you perform a safety check before
each use to make sure your power chair operates smoothly and safely.
Perform the following inspections prior to using your power chair:
nCheck for proper tire inflation. Maintain but do not exceed 35 psi in each tire (if equipped with pneumatic tires).
nCheck all electrical connections. Make sure they are tight and not corroded.
nCheck all controller connections to the power pod. Make sure they are secured properly.
nCheck the brakes. See IX. Care and Maintenance.
nCheck battery charge. See VII. Batteries and Charging.

Jet 10 Ultra/RevA/Apr04 www.pridemobility.com 9
II. SAFETY
NOTE: If you discover a pro lem, contact your authorized Pride Provider for assistance.
Weight Limitations
Your power chair is rated for a maximum weight capacity. Please refer to the specifications table for this limit.
WARNING! Exceeding the weight capacity voids your warranty and may result in personal injury
and/or damage to your power chair. Pride will not e held responsi le for injuries and/or property
damage resulting from failure to o serve weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may result in personal injury and/or property damage.
Tire Inflation
If your power chair is equipped with pneumatic tires, you should check or have the air pressure checked regularly. Proper
inflation pressures will prolong the life of your tires and help ensure the smooth operation of your power chair.
WARNING! It is important that 35 psi tire pressure e maintained in pneumatic tires at all times.
Do not underinflate or overinflate your tires. Low pressure may result in loss of control, and
overinflated tires may urst. Failure to maintain 35 psi tire pressure in pneumatic tires at all times
may result in tire and/or wheel failure, causing serious personal injury and/or damage to your
power chair.
WARNING! Inflate your power chair drive tires from a regulated air source with an availa le pressure
gauge. Inflating your tires from an unregulated air source could overinflate them, resulting in a
urst tire and/or personal injury.
Incline Information
More and more buildings have ramps with specified degrees of inclination, designed for easy and safe access. Some ramps
may have turning switchbacks (180-degree turns) that require you to have good cornering skills on your power chair.
nProceed with extreme caution as you approach the downgrade of a ramp or other incline.
nTake wide swings with your power chairs front wheels around any tight corners. If you do that, the power chairs rear
wheels will follow a wide arc, not cut the corner short, and not bump into or get hung up on any railing corners.
nWhen driving down a ramp, keep the power chairs speed adjustment set to the slowest speed setting to ensure a
safely controlled descent. See VIII. Operation.
nAvoid sudden stops and starts.
When climbing an incline, try to keep your power chair moving. If you must stop, start up again slowly and then accelerate
cautiously. When driving down an incline, set your power chair to the slowest setting and drive in the forward direction
only. If your power chair starts to move down the incline faster than you anticipated or desired, allow it to come to a
complete stop by releasing the joystick, then push the joystick forward slightly to ensure a safely controlled descent.

10 www.pridemobility.com Jet 10 Ultra/RevA/Apr04
II. SAFETY
Figure 1. Maximum Safe Slope (Ascending and Descending)
WARNING! When clim ing an incline, do not zigzag or drive at an angle up the face of the incline.
Drive your power chair straight up the incline. This greatly reduces the possi ility of a tip or a fall.
Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered
with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the power chair in freewheel
mode while seated on it or standing next to it. Doing so may result in personal injury and/or
damage to your power chair.
WARNING! Never travel down an incline ackwards. This may result in personal injury.
WARNING! Even though your power chair is capa le of clim ing slopes greater than those illustrated in
figure 1, do not, under any circumstances, exceed the incline guidelines or any other specifications
presented in this manual. Doing so could cause insta ility in your power chair, resulting in personal injury
and/or damage to your power chair.
In compliance with the Americans with Disabilities Act of 1990, all handicap public access ramps are required to have a
maximum slope of 5°. Therefore, Pride recommends that the maximum slope of an incline you attempt to safely ascend or
descend on your power chair does not exceed 5°. See figure 1.
WARNING! Any attempt to clim or descend a slope steeper than 5° may put your power chair in
an unsta le position and cause it to tip, resulting in personal injury.
Braking Information
Your power chair is equipped with two powerful brake systems:
1. Regenerative  uses electricity to rapidly slow the vehicle when the joystick returns to the center/stop position.
2. Disc Park Brake  activates mechanically after regenerative braking slows the vehicle to near stop, or when power is
removed from the system for any reason.
Cornering Information
While your power chair is equipped with caster wheels and anti-tip wheels, excessively high cornering speeds can still
create the possibility of tipping. Factors which affect the possibility of tipping include, but are not limited to: cornering
speed, steering angle (how sharply you are turning), uneven road surfaces, inclined road surfaces, riding from an area of
low traction to an area of high traction (such as passing from a grassy area to a paved area  especially at high speed while
turning), and abrupt directional changes. High cornering speeds are not recommended. If you feel that you may tip over in
a corner, reduce your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your power chair
from tipping.
WARNING! When cornering sharply, reduce your speed. This greatly reduces the possi ility of a
tip or fall. To avoid personal injury and/or property damage, always exercise common sense when
cornering.

Jet 10 Ultra/RevA/Apr04 www.pridemobility.com 11
II. SAFETY
Outdoor riving Surfaces
Your power chair is designed to provide optimum stability under normal driving conditionsdry, level surfaces composed
of concrete, blacktop, or asphalt. However, Pride recognizes that there will be times when you will encounter other surface
types. For this reason, your power chair is designed to perform admirably on packed soil, grass, and gravel. Feel free to
use your power chair safely on lawns and in park areas.
nReduce your power chairs speed when driving on uneven terrain and/or soft surfaces.
nAvoid tall grass that can entangle the running gear.
nAvoid loosely packed gravel and sand.
nIf you feel unsure about a driving surface, avoid that surface.
Freewheel Mode
Your power chair is equipped with two manual freewheel levers to allow for manual maneuverability by a trained attendant.
For more information about how to place your power chair into and out of freewheel mode, see IV. The Jet 10 Ultra.
WARNING! Do not use your power chair in freewheel mode without an attendant present. Personal
injury may result.
WARNING! Do not attempt to personally place your power chair in freewheel mode while seated
on it. Personal injury may result. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline. The chair could
roll uncontrolla ly on its own, causing personal injury.
Stationary Obstacles (Steps, Curbs, etc.)
Proceed with extreme caution when driving near raised surfaces, unprotected ledges and/or drop-offs (curbs, porches,
stairs, etc.). The correct method for approaching a curb is illustrated in figures 2 and 3.
WARNING! Do not attempt to have your power chair clim or descend an o stacle that is higher
than 2 inches unless you have the assistance of an attendant.
WARNING! Do not attempt to have your power chair proceed ackward down any step, cur , or
other o stacle. This may cause the power chair to tip and cause personal injury.
Figure 2. Correct Curb Approach Figure 3. Incorrect Curb Approach

12 www.pridemobility.com Jet 10 Ultra/RevA/Apr04
II. SAFETY
Public Streets and Roadways
WARNING! You should not operate your power chair on pu lic streets and roadways. Be aware
that it may e difficult for traffic to see you when you are seated on your power chair. O ey all
local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with extreme
caution.
Stairs and Escalators
Power chairs are not designed to travel up or down stairs or escalators. Always use an elevator.
WARNING! Never use your power chair to negotiate steps or escalators. You may cause injury to
yourself and to others and/or damage your power chair.
oors
nDetermine if the door opens toward or away from you.
nDrive your power chair gently and slowly forward to push the door open. Or drive your power chair gently and slowly
backward to pull the door open.
Elevators
Modern elevators have a door edge safety mechanism that, when pushed, reopens the elevator door(s).
nIf you are in the doorway of an elevator when the door(s) begin to close, push on the rubber door edge or allow the
rubber door edge to contact the power chair and the door will reopen.
nUse care that pocketbooks, packages, or power chair accessories do not become caught in elevator doors.
EMI & RFI
Laboratory tests performed by the Food and Drug Administration (FDA) have shown that radio waves can cause unin-
tended motion of electric mobility vehicles. Radio waves are a form of electromagnetic energy (EM). When EM adversely
affects the operation of an electronic device, it is called Electromagnetic Interference (EMI) or Radio Frequency Interfer-
ence (RFI). For more information, see III. EMI/RFI.
Lift/Elevation Products
If you will be traveling with your power chair, you may find it necessary to use a lift/elevation product to aid in transporta-
tion. Pride recommends that you closely review the instructions, specifications, and safety information set forth by the
manufacturer of the lift/elevation product before using that product.
Motor Vehicle Transport
Currently, there are no standards approved for tie-down systems in a moving vehicle of any type to transport a person
while seated in a power chair.
Transfers
Transferring onto and off of your power chair requires a good sense of balance. Always have an attendant or healthcare
professional present while learning to properly transfer yourself.

Jet 10 Ultra/RevA/Apr04 www.pridemobility.com 13
II. SAFETY
To eliminate the possibility of injury, Pride recommends that you or a trained attendant perform the following tasks before
attempting a transfer:
nTurn the power off. See VIII. Operation.
nEnsure your power chair is not in freewheel mode. See IV. The Jet 10 Ultra.
nTurn both caster wheels toward the transfer destination to improve power chair stability during transfer.
nMake sure both armrests are flipped up or removed from your power chair.
nFlip up the foot platform or move the leg rests aside; this will help to keep your feet from getting caught on the foot
rigging during the transfer.
nReduce the distance between your power chair and the object you are transferring onto.
WARNING! Before transferring, position yourself as far ack as possi le in the power chair seat
to prevent the power chair from tipping forward during transfer and causing injury.
WARNING! Avoid using your armrests for weight earing purposes. Such use may cause the power
chair to tip and cause personal injury.
WARNING! Avoid putting all of your weight on the foot riggings. Such use may cause the power
chair to tip and cause personal injury.
Positioning Belts
Your authorized Pride Provider, therapist(s), and other healthcare professionals are responsible for determining your re-
quirement for a positioning belt in order to operate your power chair safely.
WARNING! If you require a positioning elt to safely operate your power chair, make sure it is
fastened securely. Serious personal injury may result if you fall from the power chair.
WARNING! The positioning elt is not designed for use as a seat elt in a motor vehicle. Nor is
your power chair suita le for use as a seat in any vehicle. Anyone traveling in a vehicle should e
properly elted into seats approved y the vehicle manufacturer.
WARNING! Do not sit on your power chair while it is in a moving vehicle. Personal injury and/or
property damage may result.
WARNING! Always e sure your power chair and its atteries are properly secured when it is eing
transported. Failure to do so may result in personal injury and/or damage to your power chair.
Inclement Weather Precautions
WARNING! Pride recommends that you do not operate your power chair in icy or slippery conditions
or on salted surfaces (i.e., walks or roads). Such use may adversely affect the performance and
safety of your power chair, resulting in an accident and personal injury.
WARNING! Avoid exposing your power chair to any type of moisture at any time (rain, snow, mist,
or wash). Such exposure can damage your power chair. Never operate or charge your power chair
if it has een exposed to moisture until it has dried thoroughly.

14 www.pridemobility.com Jet 10 Ultra/RevA/Apr04
II. SAFETY
Reaching and Bending
Never reach, lean, or bend while driving your power chair. If it is absolutely necessary to reach, lean, or bend while seated
on your power chair, it is important to maintain a stable center of gravity and keep the power chair from tipping. Pride
recommends that the power chair user determine his/her personal limitations and practice bending and reaching in the
presence of a qualified healthcare professional.
WARNING! Do not end, lean, or reach for o jects if you have to pick them up from the floor y
reaching down etween your knees. Movements such as these may change your center of gravity
and the weight distri ution of the power chair. This may cause your power chair to tip, possi ly
resulting in personal injury. Keep your hands away from the tires when driving.
Batteries
In addition to following the warnings below, be sure to comply with all other battery handling information. For more
information about your power chairs batteries, see VII. Batteries and Charging.
WARNING! Power chair atteries are heavy. See specifications ta le. If you are una le to lift that
much weight, e sure to get help. Lifting eyond your capacity can result in personal injury.
WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds.
Wash hands after handling.
WARNING! Always protect the atteries from freezing and never charge a frozen attery. Charging
a frozen attery may result in personal injury and/or damage to the attery.
Preventing Unintended Movement
WARNING! If you anticipate eing seated in a stationary position for an extended period of time,
turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This
will also eliminate the possi ility of unintended chair movement from electromagnetic (EM) sources.
Failure to do so may result in personal injury.
Prescription rugs/Physical Limitations
Users must exercise care and common sense when operating a power chair. This includes awareness of safety issues when
taking prescribed or over-the-counter drugs or when the user has specific physical limitations.
WARNING! Consult your physician if you are taking prescri ed or over-the-counter medication or
if you have certain physical limitations. Some medications and limitations may impair your a ility
to operate your power chair in a safe manner.
Alcohol
The power chair user must exercise care and common sense when operating his/her power chair. This includes awareness
of safety issues while under the influence of alcohol.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this
may impair your a ility to operate your power chair in a safe manner.
Removable Parts
WARNING! Do not attempt to lift or move a power chair y any of its remova le parts. Personal
injury and/or damage to the power chair may result.

Jet 10 Ultra/RevA/Apr04 www.pridemobility.com 15
III. EMI/RFI
Electromagnetic and Radio Frequency Interference (EMI/RFI)
Laboratory tests have shown that electromagnetic and radio frequency waves can have an adverse affect on the perfor-
mance of electrically-powered mobility vehicles. The interference can come from sources such as cellular phones, mobile
two-way radios (such as walkie-talkies), radio stations, TV stations, amateur radio (HAM) transmitters, wireless com-
puter links, microwave signals, and paging transmitters. In some cases, these waves can cause unintended movement.
This product has een tested and has passed at an immunity level of 20 V/m.
PROHIBITED! To prevent unintended movement, turn off the power to the electrically-powered
mo ility vehicle efore using a cell phone, two-way radio, lap-top, or any other type of radio
transmitter.
WARNING! The electrically-powered mo ility vehicle itself can distur the performance of other
electrical devices located near y, such as alarm systems.
NOTE: For further information on EMI/RFI, go to www.pridemo ility.com. If unintended motion or
rake release occurs, turn the power chair off as soon as it is safe to do so. Call Pride at 800-424-
8205 to report the incident.

16 www.pridemobility.com Jet 10 Ultra/RevA/Apr04
IV. THE JET 10 ULTRA
THE JET 10 ULTRA
The Jet 10 Ultra has two main assemblies: the seat and the power base. See figures 4 and 5. Typically, the seat assembly
includes the armrests, seatback, and seat base. The seat may also have some optional accessories attached to it, such as
a rear basket, a cane and crutch holder, or a cup holder.
The power base assembly includes two motor/brake assemblies, two drive wheels, two anti-tip wheels, two caster wheels,
two batteries, and the electrical components.
SEATBACK
CONTROLLER
(VSI SHOWN)
REAR
SHROUD
ANTI-TIP WHEEL
DRIVE WHEEL
CASTER WHEEL
Figure 4. The Jet 10 Ultra
POWER BASE
ASSEMBLY
SEAT ASSEMBLY JOYSTICK
FOOT RIGGING
(FOOT PLATFORM SHOWN)
SEAT BASE
ARMRESTS

Jet 10 Ultra/RevA/Apr04 www.pridemobility.com 17
IV. THE JET 10 ULTRA
JET 10 ULTRA SPECIFICATIONS
Suspension: Active Trac
Drive Wheels: 10 in., solid, (10 in., pneumatic are optional)
Caster Wheels: 8 in., solid, rear-mounted
Anti-tip Wheels: 5 in., solid, ront-mounted
Maximum Speed: Up to 4 mph*
Brakes: Intelligent Braking electronic regenerative, disc park brake
Ground Clearance: 2.5 in.
Turning Radius: 18.5 in. (w/o foot riggings)
Turning Diameter 33 in. (w/o foot riggings)
Overall Size: Length: 35.5 in. (w/o foot riggings)
Length: 38.5 in. (w/ swing-away footrests)
Width: 23 in.
Seating Options: Medium-Back Seat (standard)
Limited Recline High-Back Seat (optional)
Full Recline High-Back Seat (optional)
Drivetrain: Two motor, mid-wheel drive
Batteries: Two 12-volt, U-1 batteries
Range: Up to 25 miles*
Battery Charger: 4-amp, on-board
Electronics: 50-amp PG Drives VSI Controller
Weight Capacity: 300 lbs.
Component Weights: Base: 97 lbs.
Medium-Back Seat: 33 lbs.
Batteries: 24.5 lbs. each
*Depending on user weight and terrain.

18 www.pridemobility.com Jet 10 Ultra/RevA/Apr04
IV. THE JET 10 ULTRA
REAR TRAPEZE BAR
FRONT TRAPEZE BAR
Figure 5. The Jet 10 Ultra Power Base
FREEWHEEL LEVER
MOTOR/BRAKE ASSEMBLY
ARTICULATING BEAM
REAR SHROUD FASTENERS
RETAINING CLIPS
RETAINING CLIPS

Jet 10 Ultra/RevA/Apr04 www.pridemobility.com 19
IV. THE JET 10 ULTRA
ELECTRICAL COMPONENTS
The electrical components are located on the power base. The ammeter and the onboard AC power cord receptacle are
located on the right side of the power base. The main circuit breaker is located on the front of the battery tray. The
controller connector and the motor connectors are located on the power pod, inside the power base. See figure 6.
Ammeter: The ammeter displays the chargers current output in amps. See VII. Batteries and Charging.
nboard AC Power Cord Receptacle: This is where the AC power cord plugs into the onboard charger. See VII
Batteries and Charging.
Main Circuit Breaker: The main circuit breaker is a safety feature built into your power chair. See figure 26. When the
batteries and the motors are heavily strained (e.g., from excessive loads), the main circuit breaker trips to prevent damage
to the motors and the electronics. If the circuit trips, allow your power chair to rest for approximately one minute. Next,
push in the circuit breaker button, turn on the controller, and continue normal operation. If the main circuit breaker contin-
ues to trip repeatedly, contact your authorized Pride Provider.
Motor Connectors: This is where the controller connects to the motors. The motor connectors are color-coded with red
and yellow labels. The label color on the motor connector corresponds with the label color on the power pod.
Battery Connector: This is where the controller connects to the batteries. See figures 6 and 26.
Charger Inhibit Connector: The charger inhibit enables the onboard charger to disable the controller during charging.
See VIII. Operation.
BATTERY CONNECTOR
MOTOR CONNECTOR
CHARGER INHIBIT
CONNECTOR
AMMETER
ONBOARD AC POWER
CORD RECEPTACLE
ONBOARD BATTERY CHARGER
CHARGER CIRCUIT FUSE
Figure 6. Jet 10 Ultra Electrical Components
MOTOR CONNECTOR

20 www.pridemobility.com Jet 10 Ultra/RevA/Apr04
MANUAL FREEWHEEL LEVERS
The Jet 10 Ultra has a manual freewheel lever on each motor. Manual freewheel levers enable you to disengage the drive
motors from the gearboxes and maneuver the chair manually.
WARNING! Do not use the power chair while the drive motors are disengaged! Do not disengage
the drive motors when the power chair is on an incline, as the unit could roll on its own, causing
injury!
To engage or disengage the drive motors:
1. Locate the lever on top of each motor.
2. Push the two levers inward to engage the drive motors. See figure .
3. Pull the two levers outward to disengage the drive motors. See figure 8.
If a lever is difficult to move in either direction, slightly rock the power chair back and forth. The lever should then move
to the desired position.
WARNING! It is important to remem er that when your power chair is in freewheel mode, the
raking system is disengaged.
IV. THE JET 10 ULTRA
Figure 8. Freewheel Mode (Drive Disengaged)Figure 7. Drive Mode (Drive Engaged)
MANUAL FREEWHEEL LEVER
