Jazzy®1113 ATS
shown in Candy Apple Red
The Jazzy®1113 ATS offers everything you need—all of the
“big chair” options and accessories, even rehab capabilities—
on the most compact frame available. You’ll take on tight
spaces and narrow hallways without sacrificing a strong outdoor
performance never before seen in a chair of this size. For
sharp ramp transitions as well as a smooth and stable ride
even over exceptionally rough and uneven terrain, the Jazzy
1113 ATS is equipped with Active-Trac®Suspension.

300 lbs.
Up to 4 mph
2.5”
20.5”
36”
23”
10”
6” solid
8” solid
Active-Trac®Suspension
Two-motor, Mid-Wheel Drive
Intelligent braking
(electronic, regenerative disc brakes)
50 amp, PG VSI controller
Yes
On-board, 4 amp (standard)
Up to 15 miles
(2) 12 volt, deep cycle
U-1
24.5 lbs. each
77 lbs.
37 lbs. (medium-back)
20” x 20”
Lifetime limited warranty on frame;
2-year limited warranty on electronics;
18-month limited warranty on drive motors
The information contained herein is correct at the time of publication; we reserve the right to alter
specifications without prior notice. Speed and range vary with user weight, terrain type, battery charge,
battery condition and tire pressure. Due to manufacturing tolerances and continual product improvement,
length, width, turning radius and ground clearance can be subject to variance of + or – 3 %.
JZ1113ATS-5-19-08
SPECIFICATIONS
Weight capacity
Maximum speed
Ground clearance
Turning radius
Overall length
Overall width
Drive Wheels
Front anti-tips
Rear casters
Suspension
Drive train
Braking system
Standard electronics
Specialty controls
Battery charger
Per-charge range
Battery requirements
Battery size
Battery weight
Base weight
Standard seat weight
Max. seat dimensions
Warranty
Candy Apple
Red
Viper Blue
§Powerful two-motor, mid-wheel drive
design offers outstanding maneuverability
§Low center of gravity design delivers a very
smooth and stable ride
§10” knobby drive wheels and optimum
weight distribution provide superior traction
§On-board battery charger
§Fully programmable controller
OPTIONS
FEATURES
Jazzy 1113 ATS 2SP-C
Jazzy 1113 ATS 2SP-SS
MODELS
RECOMMENDED LIFTS
(US) 800-800-8586 § (Canada) 888-570-1113
Visit us on the web: www.pridemobility.com
§Backpacker®Plus
§Backpacker®MV
§Full platform
§Silver Boom 300
* Special order seats or non-standard
dimensions will not be fold-flat and
depth adjustable.
§TRU-Balance®
Power Tilt
1
§Synergy®seating
system
§Solid seat pan
§Cup holder
§Weather cover
§Rear basket
§Oxygen tank holder
§TRU-Balance®
Power Recline
1
§Swing-away joystick
mount
§Cane/crutch holder
§Walker holder
§Safety flag
§Off-board charger
§Solid seat pan
COLOR CHOICES
Onyx Black Champagne
1) 200 lbs. weight capacity with TRU-Balance® 2 Systems
