Pride Jazzy 610 2SP User manual

Including Models: Jazzy 610 2S, Jazzy 610 2SP
1-800-800-8586 (US) 1-888-570-1113 (Canada)
JAZZY 610
SERIES
How a Power Chair should FEEL!™

2 www.pridemobility.com Jazzy 610 Series
SAFETY GUIDELINES
Copyright©2006
PrideMobilityProductsCorp.
INFMANU2897/RevD/December2006
AuthorizedPride Provider:_____________________________________________________________________
Address:________________________________________________________________________________
Phone Number:___________________________________________________________________________
PurchaseDate:____________________________________________________________________________
NOTE: This owner’s manual is compiled from the latest specifications and product information available
at the time of publication. We reserve the right to make changes as they become necessary. Any changes to
our products may cause slight variations between the illustrations and explanations in this manual and the
product you have purchased.
Thesymbolsbelow areusedthroughout thisowner'smanual andonthe powerchairto identifywarningsand important
information.It isvery importantfor youto readthem andunderstandthemcompletely.
WARNING! Indicates a potentially hazardous condition/situation. Failure to follow designated
procedures can cause either personal injury, component damage, or malfunction. On the product,
this icon is represented as a black symbol on a yellow triangle with a black border.
MANDATORY! These actions should be performed as specified. Failure to perform mandatory
actions can cause personal injury and/or equipment damage. On the product, this icon is
represented as a white symbol on a blue dot with a white border.
PROHIBITED! These actions are prohibited. These actions should not be performed at any time or
in any circumstances. Performing a prohibited action can cause personal injury and/or equipment
damage. On the product, this icon is represented as a black symbol with a red circle and red
slash.
Quick Reference Information
088 609 661

Jazzy 610 Series www.pridemobility.com 3
I. INTRODUCTION..................................................................................................................................... 4
II. SAFETY..................................................................................................................................................... 6
III. YOUR POWER CHAIR........................................................................................................................ 16
IV. ASSEMBLY............................................................................................................................................. 21
V. COMFORT ADJUSTMENTS............................................................................................................ 23
VI. BATTERIES AND CHARGING ........................................................................................................ 30
VII. CARE AND MAINTENANCE ............................................................................................................ 34
VIII.WARRANTY............................................................................................................................................ 40
CONTENTS

4 www.pridemobility.com Jazzy 610 Series
I. INTRODUCTION
SAFETY
WELCOMEtoPride Mobility Products Corporation(Pride).The power chairyouhavepurchased combines state-of-
the-artcomponentswithsafety,comfort,andstylinginmind.Weare confidentthatthesedesignfeatureswillprovideyou
withtheconveniences you expectduringyour daily activities.Onceyou understand howtosafelyoperate and carefor
yourpowerchair,itshouldgiveyou yearsoftrouble freeoperationandservice.
Readand followallinstructions,warnings, andnotesinthismanualbeforeattemptingtooperateyourpower chairforthe
first time. Inaddition, your safetydependsuponyou, as well asyourprovider, caretaker, or healthcare professionalin
usinggoodjudgement.
Ifthereis any informationinthis manual whichyoudonot understand,orifyou require additionalassistancefor setup
or operation, please contact your authorized Pride Provider. Failuretofollowtheinstructionsinthismanualand
those located on your powerchair can lead to personal injury and/or damage to the powerchair, including
voidingthewarranty.
PURCHASER’S AGREEMENT
Byacceptingdeliveryof this product,youpromisethat you willnotchange,alter, or modifythisproductor remove or
renderinoperableorunsafeanyguards,shields,orothersafetyfeaturesofthisproduct;fail,refuse,orneglecttoinstallany
retrofitkitsfrom timetotime providedbyPride to enhanceorpreserve thesafeuse ofthisproduct.
SHIPPING AND DELIVERY
Beforeusing yourpowerchair,makesureyourdelivery iscomplete assome componentsmaybeindividuallypackaged.
Ifyou donot receivea completedelivery,pleasecontactyourauthorizedPrideProviderimmediately.Wheredamagehas
occurredduringtransport,eitherto thepackagingor content,please contactthedelivery companyresponsible.
INFORMATION EXCHANGE
Wewanttohearyourquestions,comments, andsuggestionsaboutthismanual.Wewouldalsoliketohearaboutthe safety
andreliability ofyournewpowerchair,andabout theserviceyoureceivedfrom yourauthorized PrideProvider.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new
products,andnew optionsthatcan increaseyourability touseand enjoyyourpower chair. Pleasefeelfree tocontactus
attheaddress below:
USA: Canada:
PrideMobility ProductsCorporation Pride MobilityProductsCompany
Attn.:Customer CareDepartment 380VansickleRoadUnit350
182SusquehannaAvenue St.Catharines,Ontario L2R 6P7
Exeter, PA18643-2694 1-888-570-1113
[e-mail]
800-424-8205
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and
we will be glad to send you a new one immediately.

Jazzy 610 Series www.pridemobility.com 5
I. INTRODUCTION
PRIDE OWNERS CLUB
As an owner of a Pride product, you are encouraged to enroll in the Pride Owners Club. Complete and return your
enclosedproduct registrationcardorvisitPride’s websiteatwww.pridemobility.com.
Fromour homepage,select“OwnersClub” toenterapagededicated tocurrent andpotentialPrideproductowners.You
willgain accessto interviews,stories,recreationideas,dailylivingtips,productandfundinginformation,andinteractive
messageboards. Thesemessageboardsinviteyoutocommunicate withotherPridecustomersaswellas Priderepresen-
tativeswhoareavailableto assistyouwithanyquestions orconcernsyoumayhave.

6 www.pridemobility.com Jazzy 610 Series
II. SAFETY
PRODUCT SAFETY SYMBOLS
Thesymbols belowareusedonthepowerchairtoidentifywarnings,mandatoryactions,andprohibitedactions.Itisvery
importantfor youtoreadandunderstand themcompletely.
Corrosive chemicals contained in battery. Use only AGM or Gel-Cell batteries to reduce
the risk of leakage or explosive conditions.
This product has been tested and passed at an immunity level of 20 V/m.
Read and follow the information in the owner’s manual.
Maximum seating weight.
Locked and in drive mode.
Place unit on level ground and stand behind or to one side when changing from drive
mode to freewheel mode or freewheel mode to drive mode.
Unlocked and in freewheel mode.
Battery Set Configuration:
++
++
+ = Positive (Red) Terminal Post
- = Negative (Black) Terminal Post
Connect Red wires to Red Positive (+) Terminal Posts
Connect Black wires to Black Negative (––
––
–) Terminal Posts

Jazzy 610 Series www.pridemobility.com 7
II. SAFETY
Keep your hands away from the tires when driving. Be aware that loose fitting clothing
can become caught in drive tires.
Disposal and recycling - Contact your authorized Pride Provider for information on proper
disposal and recycling of your Pride product and its packaging.
Do not use a cell phone, walkie/talkie, laptop, or other radio transmitter while operating.
Avoid exposure to rain, snow, ice, salt, or standing water whenever possible. Maintain and
store in a clean and dry condition.
Removal of grounding prong can create electrical hazard. If necessary, properly install an
approved 3-pronged adapter to an electrical outlet having 2-pronged plug access.
Do not connect an extension cord to the AC/DC converter or the battery charger.

8 www.pridemobility.com Jazzy 610 Series
II. SAFETY
GENERAL GUIDELINES
MANDATORY! Do not operate your new power chair for the first time without completely reading
and understanding this owner’s manual.
Your powerchairisastate-of-the-artlife-enhancementdevicedesignedtoincreasemobility.Prideprovidesanextensive
varietyofproductstobestfitthe individual needs of the power chair user. Pleasebeawarethatthefinal selection and
purchasing decision regarding the type of power chair to be used is the responsibility of the power chair user, who is
capableof makingsuchadecision,and his/herhealthcare professional(i.e.,medicaldoctor,physicaltherapist, etc.).
Thecontents ofthismanualarebased onthe expectationthatamobilitydeviceexperthas properlyfittedthepowerchair
tothe userandhasassistedtheprescribinghealthcare professionaland/or theauthorized PrideProviderintheinstruction
processfortheuse of the product.
Therearecertainsituations,includingsomemedicalconditions,wherethepowerchairuser willneedtopracticeoperating
the power chair in the presence of a trained attendant.Atrained attendant can be defined as a family member or care
professionalspeciallytrainedinassistingapowerchairuserinvariousdailylivingactivities.
Asyoubeginusingyour powerchairduringdailyactivities, youwillprobablyencountersituationsinwhichyouwillneed
somepractice.Simplytakeyourtimeandyouwillsoonbeinfullandconfidentcontrolasyoumaneuverthroughdoorways,
onandoff of elevators,upanddown ramps,andovermoderate terrain.
Belowaresomeprecautions,tips,andothersafetyconsiderationsthatwillhelpyoubecomeaccustomedtooperatingyour
powerchair safely.
Modifications
Pridehasdesignedandengineeredyourpowerchairtoprovidemaximummobilityandutility.Awiderangeofaccessories
isavailablefrom your authorizedPrideProviderto further customizeyourpower chair tobettersuityour needs and/or
preferences.However,undernocircumstancesshould youmodify,add,remove, ordisable anyfeature,part, orfunction
ofyourpower chair.
WARNING! Do not modify your power chair in any way not authorized by Pride. Do not use
accessories if they have not been tested or approved for Pride products.
Pre-Ride Safety Check
Gettoknow thefeelofyour powerchairand its capabilities.Priderecommends that youperforma safetycheckbefore
eachuseto makesureyour power chairoperatessmoothly andsafely.
Performthefollowinginspectionspriorto usingyourpowerchair:
!Checkforproper tire inflation.Maintainbut do notexceed35psi(2.4bar)in each tireifequipped with pneumatic
tires.
!Checkallelectrical connections.Makesure theyaretight andnotcorroded.
!Checkallcontroller connections tothepowerbase. Make suretheyare secured properly.
!Checkthebrakes.See VII. “Care andMaintenance.”
!Checkbatterycharge. SeeVI.“Batteries andCharging.”
NOTE: If you discover a problem, contact your authorized Pride Provider for assistance.

Jazzy 610 Series www.pridemobility.com 9
II. SAFETY
Weight Limitations
Yourpowerchairisratedforamaximumweightcapacity.Please refertothespecificationstableforthislimit.
WARNING! Stay within the specified weight capacity of your power chair. Exceeding the weight
capacity voids your warranty. Pride will not be held responsible for injuries and/or property damage
resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may affect the center of gravity, resulting in a tip or a fall.
Tire Inflation
Ifyour powerchair isequipped withpneumatictires,youshouldcheckorhavetheairpressurecheckedregularly.Proper
inflationpressures willprolong thelife ofyourtiresandhelpensurethesmoothoperationofyourpowerchair.
WARNING! It is important that 35 psi (2.4 bar) tire pressure be maintained in pneumatic tires at all
times. Do not underinflate or overinflate your tires. Low pressure may result in loss of control, and
overinflated tires may burst. Failure to maintain 35 psi (2.4 bar) tire pressure in pneumatic tires at
all times may result in tire and/or wheel failure.
WARNING! Inflate your power chair drive tires from a regulated air source with an available pressure
gauge. Inflating your tires from an unregulated air source could overinflate them, resulting in a
burst tire.
Incline Information
Moreandmorebuildingshaverampswithspecifieddegreesofinclination,designedforeasyandsafeaccess.Someramps
mayhaveturningswitchbacks(180-degree turns)that requireyouto havegood corneringskillson yourpower chair.
!Proceedwithextreme cautionasyou approachthedowngradeof arampor otherincline.
!Take wideswings withyourpowerchair’sfrontwheelsaroundanytightcorners.If youdothat,thepowerchair’srear
wheelswillfollowawide arc,notcut thecornershort,andnot bumpintoor gethunguponany railingcorners.
!When driving down a ramp, keep the power chair’s speed adjustment set to the slowest speed setting to ensure a
safelycontrolleddescent.
!Avoid suddenstopsand starts.
Whenclimbinganincline,trytokeepyourpowerchairmoving.Ifyoumuststop,startupagain slowlyandthenaccelerate
cautiously.When driving down an incline, set your power chair to the slowest speed setting and drive in the forward
directiononly. Ifyourpowerchairstartstomove downthe inclinefasterthanyouanticipatedordesired, allowit tocome
toacompletestopby releasingthejoystick,thenpush thejoystickforwardslightlyto ensureasafelycontrolleddescent.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline.
Drive your power chair straight up the incline. This greatly reduces the possibility of a tip or a fall.
Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered
with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the power chair in freewheel
mode while seated on it or standing next to it.
WARNING! Never travel down an incline backward. Doing so may cause the power chair to tip.
WARNING! If your power chair is equipped with a reclining seatback, do not attempt to negotiate
inclines with the seat in a reclined position. Do not attempt to negotiate obstacles with the seat
in a reclined position unless an attendant is present to help stabilize the chair. Failure to heed
may result in the power chair tipping over.

10 www.pridemobility.com Jazzy 610 Series
II. SAFETY
Figure 1. Maximum Safe Slope (Ascending and Descending)
5 (8.7%)
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated
in figure 1, do not, under any circumstances, exceed the incline guidelines or any other
specifications presented in this manual. Doing so could cause instability in your power chair.
IncompliancewiththeAmericanswith DisabilitiesActof 1990,allhandicap publicaccessramps arerequiredtohavea
maximumslopeof5°(8.7%). Therefore,Priderecommends thatthemaximum slopeofan inclineyou attempttosafely
ascend or descend on your power chair does not exceed 5° (8.7%). See figure 1.
WARNING! Any attempt to climb or descend a slope steeper than 5° (8.7%) may put your power
chair in an unstable position and cause it to tip.
Freewheel Mode
Yourpowerchairisequippedwithtwomanualfreewheelleverstoallowformanualmaneuverabilitybyatrainedattendant.
Formoreinformationabouthow toplaceyourpowerchair intoandoutoffreewheel mode,seeIII.“YourPower Chair.”
WARNING! Do not use your power chair in freewheel mode without an attendant present.
WARNING! Do not attempt to personally place your power chair in freewheel mode while seated
on it. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline. This could cause
the chair to roll uncontrollably on its own.
Braking Information
Yourpowerchairis equippedwith twopowerfulbrake systems:
!Regenerative— useselectricitytorapidlyslowthevehicle whenthe joystickreturnstothecenter/stopposition.
!DiscParkBrake—activatesmechanicallyafterregenerativebraking slowsthevehicletonearstop,orwhenpoweris
removedfrom thesystemforanyreason.
Cornering Information
Whileyourpowerchairisequippedwithfrontandrearcasterwheels,excessivelyhighcorneringspeedscanstillcreatethe
possibilityoftipping.Factorswhichaffectthepossibilityoftippinginclude,butarenotlimitedto:corneringspeed,steering
angle(howsharplyyouareturning),unevenroadsurfaces,inclinedroadsurfaces, ridingfromanareaoflowtractiontoan
areaofhightraction(such as passing from a grassy areatoapavedarea – especially at high speedwhileturning),and
abruptdirectionalchanges.High cornering speeds arenotrecommended.If you feel thatyoumaytip over in acorner,
reduceyourspeed andsteeringangle(i.e.,lessen thesharpnessof theturn)to preventyourpower chairfromtipping.
WARNING! When cornering sharply, reduce your speed and maintain a stable center of gravity.
This greatly reduces the possibility of a tip or fall.

Jazzy 610 Series www.pridemobility.com 11
II. SAFETY
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware
that it may be difficult for traffic to see you when you are seated on your power chair. Obey all
local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with
extreme caution.
Outdoor Driving Surfaces
Yourpowerchairisdesignedtoprovideoptimumstabilityundernormaldrivingconditions—dry,levelsurfacescomposed
ofconcrete,blacktop,orasphalt.However,Priderecognizesthattherewillbetimeswhenyouwillencounter othersurface
types.Forthis reason,yourpowerchair isdesignedto perform admirablyonpacked soil,grass,and gravel. Feelfreeto
useyourpower chairsafelyonlawns andinpark areas.
!Reduceyourpowerchair’sspeed whendrivingonuneventerrain and/orsoftsurfaces.
!Avoidtallgrassthatcanentangle therunninggear.
!Avoid looselypackedgravel andsand.
!Ifyou feelunsureaboutadrivingsurface,avoidthatsurface.
Inclement Weather Precautions
Exposureof yourpowerchairtoinclementweatherconditions shouldbe avoidedwheneverpossible.Ifsuddenlycaught
up in rain, snow, severe cold or heat while operating your power chair, proceed to shelter at the earliest opportunity.
Thoroughlydry yourpowerchairbeforestoring,charging,oroperatingyourpowerchair.
WARNING! Operating in rain, snow, salt, mist/spray conditions, and on icy/slippery surfaces can
have an adverse affect on the electrical system. Maintain and store your power chair in a dry and
clean condition.
WARNING! Prolonged exposure to hot or cold conditions may affect the temperature of upholstered
and non-upholstered items on the power chair, possibly resulting in skin irritation. Exercise caution
when using your power chair in extremely hot or cold conditions or when exposing your power
chair to direct sunlight for prolonged periods of time.
Stationary Obstacles (Steps, Curbs, etc.)
Proceedwithextremecaution when drivingnearraised surfaces, unprotected ledgesand/ordrop-offs (curbs, porches,
stairs,etc.).Be sureyourpower chairistraveling perpendiculartoany curbyouare requiredtonavigate. Seefigure2.
Figure 2. Correct Curb Approach Figure 3. Incorrect Curb Approach

12 www.pridemobility.com Jazzy 610 Series
II. SAFETY
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than 2 in. (5 cm) unless you have the assistance of an attendant.
WARNING! Do not attempt to have your power chair proceed backward down any step, curb, or
other obstacle. This may cause the power chair to tip.
Stairs and Escalators
Powerchairsare not designed totravelup or downstairsorescalators. Always use anelevator.
WARNING! Never use your power chair to negotiate steps or escalators.
Doors
!Determineifthe dooropenstoward orawayfrom you.
!Driveyourpowerchairgentlyandslowly forwardtopushthedooropen.Ordriveyourpowerchairgentlyandslowly
backwardtopullthedoor open.
Elevators
Modernelevatorshave adooredge safety mechanismthat,when pushed,reopensthe elevator door(s).
!Ifyouarein the doorway ofanelevatorwhen the door(s) begintoclose, push on therubberdooredge or allow the
rubberdooredgeto contact the power chairandthedoor will reopen.
!Usecarethatpocketbooks,packages, or power chair accessoriesdonotbecomecaught in elevator doors.
Lift/Elevation Products
Ifyouwillbetravelingwithyourpowerchair,youmayfinditnecessary tousealift/elevationproducttoaidintransporta-
tion.Priderecommends that youcloselyreviewthe instructions,specifications,andsafety information setforthby the
manufacturerofthelift/elevationproductbeforeusing thatproduct.
WARNING! Never sit on your power chair when it is being used in connection with any type of lift/
elevation product. Your power chair was not designed with such use in mind and any damage or
injury incurred from such use is not the responsibility of Pride.
Motor Vehicle Transport
Priderecommends thatyoudonotremainseatedinyourpower chairwhile travelingin amotorvehicle.Thepowerchair
shouldbestowedin the trunk ofacar or in thebackofa truck or vanwithbatteriesremoved and properlysecured.
WARNING! Do not sit on your power chair while it is in a moving vehicle.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Batteries should be secured in an upright position and protective caps should be
installed on the battery terminals. Batteries should not be transported with any flammable or
combustible items.
Positioning Belts
YourauthorizedPrideProvider,therapist(s),andother healthcareprofessionalsareresponsiblefor determiningyourre-
quirementforapositioningbelt inordertooperateyour powerchairsafely.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely in order to reduce the possibility of a fall from the power chair.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is
your power chair suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be
properly belted into seats approved by the vehicle manufacturer.

Jazzy 610 Series www.pridemobility.com 13
II. SAFETY
Batteries
In addition to following the warnings below, be sure to comply with all other battery handling information. For more
informationabout yourpowerchair’sbatteries,seeVI.“BatteriesandCharging.”
WARNING! Power chair batteries are heavy. See specifications table. If you are unable to lift that
much weight, be sure to get help. Use proper lifting techniques and avoid lifting beyond your
capacity.
WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds.
Wash hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery. Charging
a frozen battery may result in damage to the battery.
WARNING! Connect your battery harnesses in the proper manner. RED (+) cables must be connected
to positive (+) battery terminals/posts. BLACK (-) cables must be connected to negative (-) battery
terminals/posts. Protective caps should be installed over all battery terminals. REPLACE cables
immediately if damaged.
Removable Parts
WARNING! Do not attempt to lift or move a power chair by any of its removable parts, including the
armrests, seat, foot riggings, controller, and shrouds.
Preventing Unintended Movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time,
turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This
will also eliminate the possibility of unintended chair movement from electromagnetic (EM) sources.
Reaching and Bending
Neverreach, lean,orbendwhiledrivingyourpowerchair.Ifitisabsolutelynecessarytoreach,lean,orbendwhileseated
onyourpowerchair, it is importanttomaintaina stable center ofgravityandkeepthe power chair fromtipping.Pride
recommendsthatthepower chair userdeterminehis/herpersonal limitations andpracticebendingand reaching inthe
presenceof aqualifiedhealthcareprofessional.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the floor by
reaching down between your knees or if you have to reach over the back of the seat. Movements
such as these may change your center of gravity and the weight distribution of the power chair,
possibly causing your power chair to tip.
WARNING! Keep your hands away from the tires when driving. Be aware that loose fitting clothing
can become caught in drive tires.

14 www.pridemobility.com Jazzy 610 Series
II. SAFETY
Figure 4.IdealTransfer Position
Transfers
Transferring onto and off of your power chair requires a
goodsenseofbalance.Alwayshaveanattendantorhealth-
careprofessionalpresentwhilelearningtoproperlytransfer
yourself.
Toeliminatethepossibilityofinjury,Priderecommendsthat
youora trainedattendantperform thefollowingtasksbe-
foreattemptingatransfer:
!Turnoffthepowertothe controller.
!Ensureyour powerchairisnotinfreewheelmode.See
III.“YourPowerChair.”
!Turnthecaster wheelstowardthe transferdestination
toimprovepowerchairstabilityduringtransfer.
!Make sure both armrests are flipped up or removed
fromyour powerchair.
!Flip up the foot platform or move the leg rests aside;
thiswillhelp tokeepyour feetfromgetting caught on
thefootriggingduringthetransfer.
!Reducethe distancebetween yourpowerchairandthe
objectyouaretransferringonto.
WARNING! Before transferring, position yourself as far back as possible in the power chair seat
to prevent the power chair from tipping forward during transfer.
WARNING! Avoid putting all of your weight on the power chair armrests and do not use the armrests
for weight bearing purposes, such as transfers. Such use may cause the power chair to tip, resulting
in a fall from the power chair.
WARNING! Avoid putting all of your weight on the foot riggings. Such use may cause the power
chair to tip.
Prescription Drugs/Physical Limitations
Usersmustexercisecareandcommonsensewhenoperatingapowerchair.Thisincludesawarenessofsafetyissueswhen
takingprescribed orover-the-counterdrugsorwhentheuserhasspecificphysicallimitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or
if you have certain physical limitations. Some medications and limitations may impair your ability
to operate your power chair in a safe manner.
Alcohol/Smoking
Thepower chairusermustexercisecareandcommonsensewhenoperatinghis/herpowerchair.Thisincludesawareness
ofsafetyissueswhileundertheinfluenceof alcoholorwhilesmoking.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this
may impair your ability to operate your power chair in a safe manner.

Jazzy 610 Series www.pridemobility.com 15
WARNING! Although the power chair seat has passed the necessary testing requirements for
cigarette smoke, Pride recommends that you adhere to the following safety guidelines:
!Do not leave lit cigarettes unattended.
!Keep ashtrays a safe distance from the seat cushions.
!Always make sure cigarettes are completely extinguished before disposal.
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can
have an adverse affect on the performance of electrically-powered mobility vehicles.
ElectromagneticandRadioFrequencyInterferencecancome from sources such as cellular phones, mobile two-way
radios(suchas walkie-talkies),radiostations, TVstations,amateurradio(HAM) transmitters,wirelesscomputer links,
microwavesignals,paging transmitters, and medium-rangemobiletransceivers used byemergencyvehicles.In some
cases,thesewavescancause unintendedmovementordamageto thecontrolsystem.Everyelectrically-poweredmobility
vehiclehasanimmunity(orresistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainstEMI.This
producthasbeen testedandhas passed atanimmunity levelof20 V/m.
WARNING! Be aware that cell phones, two-way radios, laptops, and other types of radio transmitters
may cause unintended movement of your electrically-powered mobility vehicle due to EMI.
Exercise caution when using any of these items while operating your mobility vehicle and avoid
coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered mobility vehicle
can increase the susceptibility of the vehicle to EMI. Do not modify your power chair in any way
not authorized by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance of other
electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, go to the Resource Center on www.pridemobility.com. If
unintended motion or brake release occurs, turn your power chair off as soon as it is safe to do so. Call Pride
at 800-424-8205 to report the incident.
II. SAFETY

16 www.pridemobility.com Jazzy 610 Series
III. YOUR POWER CHAIR
THE JAZZY 610 SERIES POWER CHAIR
Yourpower chairhastwo main assemblies:theseat assemblyandthe powerbaseassembly.Seefigure 5.Typically,the
seatassembly includesthe armrests,seatback,andseatbase.Thepowerbaseassemblyincludestwo motor/brakeassem-
blies,twodrive wheels,fourcaster wheels, twobatteries,and wiringharnesses.See figure 5,6,and 7.
SEATBACK
REAR
SHROUD
DRIVE WHEEL
CASTER WHEEL
Figure 5.The Jazzy 610 Series Power Chair
POWERBASE
ASSEMBLY
SEAT ASSEMBLY
JOYSTICK
FOOTRIGGING
(FOOT PLATFORM SHOWN)
SEATBASE
ARMRESTS
CONTROLLER
CASTER WHEEL

Jazzy 610 Series www.pridemobility.com 17
III. YOUR POWER CHAIR
SPECIFICATIONS
Suspension: ATXSuspension(Active-Tracwithextrastability)
DriveWheels: 10in.(25.4cm),pneumaticorsolidavailable
FrontCasterWheels: 5in.(12.7cm),solid
RearCasterWheels: 6 in.(15.24cm),solid
MaximumSpeed:¹ Upto4mph(6.43km/h)
Range:1Variableupto10miles(16km)
Brakes: “IntelligentBraking”electronicregenerative,discparkbrake
GroundClearance:² 2.5in.(6.35cm)
TurningRadius:² 21.25in.(54cm)
OverallSize:² Length:34.75in.(88.26cm)withoutfootriggings
Width:23.25in.(59cm)
Drivetrain: Twomotor, mid-wheeldrive
Batteries:³ Two12-volt,deep-cycleU-1batteries
BatteryCharger: 4-amp,onboard(standard)
4-amponboard/5-ampoff-boardcombo
WeightCapacity: 300lbs.(136kg)
250lbs.(113kg)withTRU-Balance2PowerTilt
ComponentWeights: Base:109lbs.(49.44kg)withoutseatandbatteries
Batteries:24.5lbs.(11.11kg)each
¹ Varies with base model, user weight, terrain type, battery amp hour rating (AH), battery charge, battery condition, motors, controller
type, tire type, and tire condition.
² Due to manufacturing tolerances and continued product improvement, this specification can be subject to a variance of (+ or – ) 3%.
³ AGMorGel-Celltype recommended.
NOTE: All specifications subject to change without notice.

18 www.pridemobility.com Jazzy 610 Series
III. YOUR POWER CHAIR
ELECTRICAL COMPONENTS
Theelectricalcomponentsarelocated inside the power base. Theammeterandthecharger power cord receptacle are
located on the right side of the power base. The main circuit breaker is located on the front of the battery tray. The
controllerconnector(s)are locatedinsidethepower base.Seefigure 7.
Ammeter:Theammeterdisplays thecharger’scurrent outputinamps. SeeVI.“Batteries andCharging.”
ChargerPowerCordReceptacle:Thisiswherethechargerpowercordplugsintotheonboard batterycharger. SeeVI.
“BatteriesandCharging.”
MotorConnectors:This iswherethe controllerconnectsto the motors.
BatteryConnector:This iswherethe controller connectstothe batteries.
Figure 6.The Jazzy 610 Series Power Base
MOTOR/BRAKEASSEMBLY
REARSHROUDFASTENERS
TRAPEZEBARS
FRONT COVER

Jazzy 610 Series www.pridemobility.com 19
III. YOUR POWER CHAIR
ControllerConnector:This iswherethe controllerconnectsto thepowerbase. Eachcontrollerusesadifferent typeof
cable.Regardlessof which typeofcontroller is used,thecable must besecuredto the seatassemblyand not allowedto
dragonthe floor.
MainCircuitBreaker:Themaincircuitbreakerisasafetyfeaturebuiltintoyourpowerchair.Whenthebatteriesandthe
motorsareheavilystrained(e.g.,fromexcessive loads),themaincircuitbreakertripsto preventdamagetothemotorsand
theelectronics. Ifthecircuittrips,allowyourpowerchairto“rest”for approximatelyone minute.Next,pushinthecircuit
breakerbutton,turnonthe controller, andcontinuenormaloperation.If themaincircuitbreakercontinues totriprepeat-
edly, contactyourauthorizedPrideProvider.
Figure 7. Jazzy 610 Series Electrical Components
BATTERY
CONNECTOR
CHARGERPOWER
CORDRECEPTACLE
CHARGERCIRCUITFUSE
ONBOARD BATTERY
CHARGER
MAINCIRCUITBREAKER
AMMETER
POWERMODULE
MOTOR
CONNECTORS
CHARGERINHIBITCONNECTOR
BATTERY
CONNECTOR
VSI CONTROLLER
CONTROLLER CONNECTOR
MOTOR
CONNECTORS

20 www.pridemobility.com Jazzy 610 Series
MANUAL FREEWHEEL LEVERS
TheJazzy610 hasamanual freewheel leveroneach motor.Manualfreewheellevers enableyouto disengagethedrive
motorsfromthegearboxesandmaneuverthechairmanually.
WARNING! Do not use the power chair while the drive motors are disengaged! Do not disengage
the drive motors when the power chair is on an incline, as the unit could roll on its own! Only
engage the freewheel mode when on a level surface.
WARNING! It is important to remember that when your power chair is in freewheel mode, the
braking system is disengaged.
To engage or disengage the drive motors:
1. Locate theleverontop of each motor.
2. Push thetwolevers inwardtoengage thedrivemotors. Seefigure8.
3. Pull thetwolevers outwardtodisengage thedrivemotors.Seefigure 9.
Ifaleverisdifficulttomoveineitherdirection,slightlyrockthe powerchairbackandforth.Thelevershouldthenmoveto
thedesired position.
WARNING! Do not use the freewheel lever handles as tie-down points to secure this product.
III. YOUR POWER CHAIR
Figure 9. Freewheel Mode (Drive Disengaged)
Figure 8. Drive Mode (Drive Engaged)
