Princess 01.368020.02.001 User manual

EN Instruction manual
Smart Dehumidifier
01.368020.02.001

PARTS DESCRIPTION
1
7
6
4
5
2
3

Instruction manual
3
SAFETY
• Please read this user’s manual carefully to
ensure proper use, maintenance and
installation.
• By ignoring the safety instructions the
manufacturer cannot be held responsible for
the damage.
• The appliance is for indoor use only.
• Do not use the unit on a socket under
repairs or not installed properly.
• Do not use the unit:
• near a source of fire.
• in an area where oil is likely to splash.
• in an area exposed to direct sunlight.
• in an area where water is likely to splash.
• near a bath, a shower or a swimming pool.
• Never insert your fingers or any other object
into the air outlet. Take special care to warn
children of these dangers.
• Keep the unit upward while transport and
storage.
• Before cleaning or moving the unit, always
turn off or disconnect the power supply.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard.
• Never move the appliance by pulling the
cord and make sure the cord cannot
become entangled.
• The appliance must be placed on a stable,
level surface.
• This appliance is only to be used for
household purposes and only for the
purpose it is made for.
• The appliance shall be installed in
accordance with national wiring regulations.
• Notes:
• Contact the dealer or a designated repair
shop if any parts are damaged;
• In case of any damage, please turn off the
unit, disconnect the power supply and
contact the dealer or a designated repair
shop.
• In any case, the power cord shall be firmly
grounded.
• This appliance shall not be used by children
aged less than 8 years. This appliance can
be used by children aged from 8 years and
above and persons with reduced physical,
EN

Instruction manual
4
sensory or mental capabilities or lack of
experience and knowledge if they have been
given supervision or instruction concerning use
of the appliance in a safe way and understand
the hazards involved. Children shall not play
with the appliance. Keep the appliance and its
cord out of reach of children aged less than 8
years. Cleaning and user maintenance shall not
be made by children unless older than 8 and
supervised.
Warning
• To protect yourself against an electric shock, do
not immerse the cord, plug or appliance in the
water or any other liquid.
• The appliance shall be stored in a room without
continuously operating ignition sources (for
example: open flames , an operating gas
appliance or an operating electric heater).
• Do not pierce or burn.
• Be aware that refrigerants may not contain an
odor.
• Contact authorized service technician for repair
or maintenance of this unit.
• Do not pull , deform or modify the power supply
cord , or immerse it in water . Pulling or misuse
of the power supply cord can result in damage
to the unit and cause electrical shock.
• Compliance with national gas regulations shall
be observed.
• Keep ventilation openings clear of obstructions.
• Any person who is involved with working on or
opening a refrigerant circuit should hold a
current valid certificate from an industry
accredited assessment authority which
authorizes their competence to handle
refrigerants safely in accordance with an
industry recognized assessment specification.
• Servicing should only be performed as
recommended by the equipment manufacturer.
Maintenance and repair requiring the assistance
of other skilled personnel should be carried out
under the supervision of a person(s) competent
in the use of flammable refrigerants.
• Do not stop the unit by pulling out the power
plug whilst in operation as this may cause an
electric shock or fire due to heat generation
unless strange sounds are heard or if strange
smells or smoke appear from the unit.
• Unplug the unit if strange sounds, smell, or
smoke comes from it.

Instruction manual
5
Caution
• Please make sure the product ventilates all
the time, make sure the inlet and outlet
ventilation are not blocked in any way.
• Operate this unit on a horizontal surface to
avoid water leakage.
• Do not operate this unit in an explosive or
corrosive atmosphere.
• Operate this unit in an ambient of 35 degree
centigrade or less.
• When the unit is shut off, please wait at least
3.5 minutes before restarting. This to
prevent the compressor from being
damaged.
• To avoid the household electricity block out,
please do not use any extension cord for
this unit.
Refrigerant
Specific information regarding appliances with R 290 refrigerant gas.
• Thoroughly read all of the warnings.
• When defrosting and cleaning the
appliance , do not use any tools other than
those recommended by the manufacturing
company.
• The appliance must be placed in an area
without any continuously sources of ignition
(for example: open flames , gas or electrical
appliances in operation).
• Do not puncture and do not burn.
• This appliance contains Y g (see rating label
back of unit ) of R290 refrigerant gas.
• R290 is a refrigerant gas that complies with
the European directives on the environment.
Do not puncture any part of the refrigerant
circuit.
• If the appliance is installed, operated or
stored in a non-ventilated area, the room
must be designed to prevent to the
accumulation of refrigerant leaks that could
result in a fire risk or explosion due to
ignition of the refrigerant caused by electric
heaters, stoves, or other sources of ignition.
• The appliance must be stored in such a way
as to prevent mechanical failure.
• Individuals who operate or work on the
refrigerant circuit must have the appropriate
certification issued by an accredited
EN

Instruction manual
6
organization that ensures competence in
handling refrigerants according to a specific
evaluation recognized by associations in the
industry.
• Repairs must be performed based on the
recommendation from the manufacturing
company. Maintenance and repairs that require
the assistance of other qualified personnel must
be performed under the supervision of an
individual specified in the use of flammable
refrigerants.
(CE) N 842/2006: This unit contains the refrigerant R290. The amount of
refrigerant is less than 1kg, and is in a closed cooling circuit. The coolant
does have zero ozone depletion potential, but is a so-called greenhouse
gases under the Kyoto Protocol and may thus contribute to global
warming, if it is released to the atmosphere. Therefore only trained
technicians with refrigerant certificate make a filling or emptying. Your
appliance does not have be refilled with refrigerant if used properly and
has an undamaged coolant circuit. GWP: R290: 3
• WARNING: In order to avoid overheating,
do not cover the heater.
PARTS DESCRIPTION
1. Supply cord
2. Tank
3. Filter
4. Back
5. Air outlet
6. Display
7. Front
BEFORE THE FIRST USE

Instruction manual
7
• Place the unit in the correct upright position before unpacking.
• Take the appliance andaccessoriesoutthebox.Removethe
stickers,protective foilorplasticfrom thedevice.
• Before using your appliance for the first time, wipe off all
removable parts with a damp cloth. Never use abrasive products.
• Please ensure the unit is not placed against objects which will
obstruct air intake e.g. furniture or curtains as this will affect its
performance dramatically.
• Please don’t place or operate the unit in a narrow place
• Do not place the unit in full sun as it might shut down due to
overheat and the color of the unit may soon fade out.
• Do not place the unit in a humid place.
• A distance of 20cm minimum must be kept between the unit and
the wall or any other obstacles.
• Putthepower cable intothe socket.(Note: Make surethe
voltagewhich is indicated on the devicematchesthe
localvoltage beforeconnecting the device.Voltage220V-240V
50Hz).
FUNCTIONS OF CONTROL PANEL
• Power button: Press to turn the unit ON or OFF. When
powered on, the current humidity level will be shown. The unit will
begin in "CO" (Continuous) mode as default.
• Mode: Use to switch between the different modes.
– Dehumidify (Auto or Manual operation)
– Fan (Fan mode only)
– Laundry (Full power mode)
EN

Instruction manual
8
• Up-Down: Set the required humidity
level: "CO" (continuous), 30 to 90% and “AU” (Automatic). The default
mode is “CO”. Note: Press up and down at the same time to convert
the display from Humidity to Temperature. The display will go back to
Humidity after 5 seconds.
• Speed: Fan speed can be switched between high or low.
Note: In comfortable mode ("AU") with a room temperature above 27
degree and in Laundry mode the fan speed is fixed and cannot be
adjusted.
• Timer (Regular time range 01-24 hours):
– In the power on state press timer to set the timer for scheduled
shutdown.
– In the power off state press Timer to set the timer for scheduled
start of the dehumidifier.
• Swing: Swing function on/off, pressing the button when the
dehumidifier is on will let the louver swing continuously, press the
button again to let the louver stop moving. When stopped the Louver
will be fully open to maximise airflow.
• Child lock: Hold for 5 seconds to activate the child lock
function, all other functions will not work when activated, to disable the
child lock hold the same button again for 5 seconds.
• Wi-Fi: To set the dehumidifier in pair mode, press and hold
the Wi-Fi button until the indicator starts to flash, it could take about 6
seconds, then follow the steps in the Princess Home app.
DEHUMIDIFY MODE SETTINGS
Manual humidity set operation:
In this mode you can set a custom humidity level from 30 to 90%. The
dehumidifier will work to reduce the humidity providing the room humidity
level is above the set level.
Once the humidity is reduced the compressor will automatically turn off
and the fan will continue to run. If the humidity level rises again then the
compressor will begin again.
CO (Continuous operation):
In this mode the dehumidifier will continuously run regardless of the room
humidity. The fan speed can be adjusted.
AU (Automatic) operation:
In this mode the dehumidifier will operate automatically to the below levels:
Room temperature 5c to 20c = 60% humidity.
Room temperature 20c to 27c = 55% humidity.

Instruction manual
9
Room temperature above 27c = 50% humidity.
Laundry mode:
In this mode the dehumidifier is in full power operation and will
continue to operate regardless of the humidity level. The fan speed is
locked on high and cannot be adjusted.
Fan mode:
In this mode the dehumidifier will only operate for air circulation and
the compressor will not run. The humidity will not be reduced in this
mode.
Water full:
If the water tank is full the full indicator will show red and an alarm will
sound. Empty and replace the water tank and the dehumidifier will
automatically resume its set operation.
NOTE: The compressor will not begin until 3 minutes has passed.
Automatic Defrost:
It is possible that the dehumidifier can produce internal frost. This is
normal and the dehumidifier will automatically go into defrost mode
when frost is detected to reduce this.
The compressor will turn off and the fan will continue, once the
defrost has finished the compressor will start and normal operation
will continue.
USING THE DEHUMIDIFIER WITH PRINCESS
HOME APP
• The dehumidifier can be used manually with its built-in controls or
you can use a smart phone or smart speaker to control it. Before
you begin, ensure the Princess Home app is downloaded. The
Princess Home app is available on Android and iOS.
• Download the correct version of the Princess Home app via our
website princesshome.eu/nl-nl/princess-home-app or use the QR
code:
Pair your dehumidifier to Princess Home app
• Make sure your dehumidifier is powered on and that the unit is in
pair mode by pressing and holding the Wi-Fi button until the
indicator starts to flash, it could take about 6 seconds.
EN

Instruction manual
10
• Open the Princess Home app.
• Select your country code, enter the cell phone number and tap “Get” to
get a message containing the verification code.
• Enter the verification code in the message and tap “Log in” to log in to
the App.
• Click "Add Device" to add a new device.
• Select the device you wanted to connect.
• Follow the instructions on the app to connect the dehumidifier.
• To control your device with voice using a smart speaker please refer to
the manufacturer's instructions on how to enable a skill through your
device.
EMPTY THE WATER TANK
• When the drainage tank is full, the tank full indicator light will turn on,
the operation will stop automatically and the buzzer will beep 15 times.
• Gently press on the sides of the tank and pull the tank out with both
hands.
• Empty the water tank above a sink.
• Do not remove the float from the water tank, otherwise the water
sensor cannot detect the water level, causing the unit to malfunction.
• If the tank is dirty, use water for cleaning. Do not use gasoline or other
chemicals, because it may damage the water tank and cause water
leakage.
• Press the tank tightly with both hands to put it into place.
• If the water tank is not positioned correctly, the full water sensor will
remain active and the dehumidifier will not work.
CONTINUOUS WATER DRAINAGE
• The unit features a continuous drainage port. Using a plastic pipe (with
an inner diameter of 10mm). Take out the water tank and put the
drainpipe over the water outlet of the unit. Put the water tank back in
place and guide the drainpipe through the hole of the water tank. The
water in the drainage tank can be continuously drained out from the
continuous port on the unit.
FILTER CLEANING
• Take the filter out of the unit.

Instruction manual
11
• Clean the filter using a vacuum cleaner to gently absorb dust on
the filter screen surface.
• Use some warm water and a mild detergent if it is very dirty.
Make sure the filter is completely dry before you put it back.
• Push the two hooks to put the filter back into the unit.
CLEANING MAINTENANCE
• Before cleaning, be sure to disconnect the unit from any electric
supply outlet.
• First clean the surface with a neutral detergent and wet cloth, and
then wipe it with a dry cloth.
• Do not use gasoline or other chemicals to clean the unit.
STORAGE
• Empty the water in the tank.
• Roll up the power cord.
• Clean the filter.
• Store the unit in a cool and dry place.
EN

Instruction manual
12
TROUBLESHOOTING
Problem Possible causes Suggested solution
The machine
doesn't work.
Is the power line properly
connected?
Connect the plug into the
socket.
Full water indicator light
is on (water tank full or
not in the right place).
Drain the water in the tank
and put it in place.
The room temperature is
above 35 degrees or
under 5 degrees.
The protection is started and
the machine will not work.
Is the lock on? If the lock is on, please
unlock by press and hold the
lock button for 5 seconds.
Dehumidificatio
n function
cannot start.
Is the filter blocked? Clean the filter (screen)
according to the cleaning
instructions.
Is the air inlet or outlet
blocked?
Remove the obstruction from
the air inlet or outlet.
The machine
makes noise.
Is the machine tilted? Move the machine to a flat,
horizontal surface.
Is the filter blocked? Clean the filter (screen)
according to the cleaning
instructions.
E1 Code Coil sensor short circuit
or open circuit
Check if the line is loose or
replace the coil sensor.
THE PRODUCT OR EQUIPMENT CONTAINS
FLUORINATED GREENHOUSE GAS.
Art.nr. 368020
Coolant: R290
Quantity in kg: 0.05
Global Warming Potential: 3
CO2 Equivalent in tonnes: 0.00015
DECLARATION OF CONFORMITY
• Hereby, Smartwares Europe declares that the radio equipment type
368020 is in compliance with Directive 2014/53/EU
• The full text of the EU declaration of conformity is available at the
following internet address: www.princesshome.eu/doc
ENVIRONMENT
This appliance should not be put into the domestic garbage at the
end of its durability, but must be offered at a central point for the recycling
of electric and electronic domestic appliances. This symbol on the
appliance, instruction manual and packaging puts your attention to this
important issue. The materials used in this appliance can be recycled. By
recycling of used domestic appliances you contribute an important push to
the protection of our environment. Ask your local authorities for information
regarding the point of recollection.
Support

Instruction manual
13
You can find all available information and spare parts at
www.princesshome.eu!
EN
