Princess 368020 User manual

EN Instruction manual
NL Gebruiksaanwijzing
FR Mode d’emploi
DE Bedienungsanleitung
ES Manual de usuario
PT Manual de utilizador
IT Manuale utente
SV Bruksanvisning
CS Návod na použití
PL Instrukcja obsługi
SK Návod na použitie
Smart Dehumidifier
01.368020.01.001
FI Ohjekirja
DK Brugervejledning
NO Bruksanvisningen

1
7
6
4
5
2
3
PARTS DESCRIPTION / ONDERDELENBESCHRIJVING / DESCRIPTION DES PIÈCES
/ TEILEBESCHREIBUNG / DESCRIPCIÓN DE LAS PIEZAS / DESCRIÇÃO DOS
COMPONENTES / DESCRIZIONE DELLE PARTI / BESKRIVNING AV DELAR / OPIS
CZĘŚCI / POPIS SOUČÁSTÍ / POPIS SÚČASTÍ / BESKRIVELSE AF BESTANDDELE /
OSIEN KUVAUKSET / BESKRIVELSE AV DELER

Instruction manual
3
SAFETY
• Please read this user’s manual carefully to
ensure proper use, maintenance and
installation.
• By ignoring the safety instructions the
manufacturer cannot be held responsible for
the damage.
• The appliance is for indoor use only.
• Do not use the unit on a socket under
repairs or not installed properly.
• Do not use the unit:
• near a source of fire.
• in an area where oil is likely to splash.
• in an area exposed to direct sunlight.
• in an area where water is likely to splash.
• near a bath, a shower or a swimming pool.
• Never insert your fingers or any other object
into the air outlet. Take special care to warn
children of these dangers.
• Keep the unit upward while transport and
storage.
• Before cleaning or moving the unit, always
turn off or disconnect the power supply.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard.
• Never move the appliance by pulling the
cord and make sure the cord cannot
become entangled.
• The appliance must be placed on a stable,
level surface.
• This appliance is only to be used for
household purposes and only for the
purpose it is made for.
• The appliance shall be installed in
accordance with national wiring regulations.
• Notes:
• Contact the dealer or a designated repair
shop if any parts are damaged;
• In case of any damage, please turn off the
unit, disconnect the power supply and
contact the dealer or a designated repair
shop.
• In any case, the power cord shall be firmly
grounded.
• This appliance shall not be used by children
aged less than 8 years. This appliance can
be used by children aged from 8 years and
above and persons with reduced physical,
EN

Instruction manual
4
sensory or mental capabilities or lack of
experience and knowledge if they have been
given supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved. Children
shall not play with the appliance. Keep the
appliance and its cord out of reach of
children aged less than 8 years. Cleaning
and user maintenance shall not be made by
children unless older than 8 and supervised.
Warning
• To protect yourself against an electric shock,
do not immerse the cord, plug or appliance
in the water or any other liquid.
• The appliance shall be stored in a room
without continuously operating ignition
sources (for example: open flames , an
operating gas appliance or an operating
electric heater).
• Do not pierce or burn.
• Be aware that refrigerants may not contain
an odor.
• Contact authorized service technician for
repair or maintenance of this unit.
• Do not pull , deform or modify the power
supply cord , or immerse it in water . Pulling
or misuse of the power supply cord can
result in damage to the unit and cause
electrical shock.
• Compliance with national gas regulations
shall be observed.
• Keep ventilation openings clear of
obstructions.
• Any person who is involved with working on
or opening a refrigerant circuit should hold a
current valid certificate from an industry
accredited assessment authority which
authorizes their competence to handle
refrigerants safely in accordance with an
industry recognized assessment
specification.
• Servicing should only be performed as
recommended by the equipment
manufacturer. Maintenance and repair
requiring the assistance of other skilled
personnel should be carried out under the
supervision of a person(s) competent in the
use of flammable refrigerants.
• Do not stop the unit by pulling out the power
plug whilst in operation as this may cause an
electric shock or fire due to heat generation

Instruction manual
5
unless strange sounds are heard or if
strange smells or smoke appear from the
unit.
• Unplug the unit if strange sounds, smell, or
smoke comes from it.
Caution
• Please make sure the product ventilates all
the time, make sure the inlet and outlet
ventilation are not blocked in any way.
• Operate this unit on a horizontal surface to
avoid water leakage.
• Do not operate this unit in an explosive or
corrosive atmosphere.
• Operate this unit in an ambient of 35 degree
centigrade or less.
• When the unit is shut off, please wait at least
3.5 minutes before restarting. This to
prevent the compressor from being
damaged.
• To avoid the household electricity block out,
please do not use any extension cord for
this unit.
Refrigerant
Specific information regarding appliances with R 290 refrigerant gas.
• Thoroughly read all of the warnings.
• When defrosting and cleaning the
appliance , do not use any tools other than
those recommended by the manufacturing
company.
• The appliance must be placed in an area
without any continuously sources of ignition
(for example: open flames , gas or electrical
appliances in operation).
• Do not puncture and do not burn.
• This appliance contains Y g (see rating label
back of unit ) of R290 refrigerant gas.
• R290 is a refrigerant gas that complies with
the European directives on the environment.
Do not puncture any part of the refrigerant
circuit.
• If the appliance is installed, operated or
stored in a non-ventilated area, the room
must be designed to prevent to the
accumulation of refrigerant leaks that could
EN

Instruction manual
6
result in a fire risk or explosion due to
ignition of the refrigerant caused by electric
heaters, stoves, or other sources of ignition.
• The appliance must be stored in such a way
as to prevent mechanical failure.
• Individuals who operate or work on the
refrigerant circuit must have the appropriate
certification issued by an accredited
organization that ensures competence in
handling refrigerants according to a specific
evaluation recognized by associations in the
industry.
• Repairs must be performed based on the
recommendation from the manufacturing
company. Maintenance and repairs that
require the assistance of other qualified
personnel must be performed under the
supervision of an individual specified in the
use of flammable refrigerants.
(CE) N 842/2006: This unit contains the refrigerant R290. The amount
of refrigerant is less than 1kg, and is in a closed cooling circuit. The
coolant does have zero ozone depletion potential, but is a so-called
greenhouse gases under the Kyoto Protocol and may thus contribute
to global warming, if it is released to the atmosphere. Therefore only
trained technicians with refrigerant certificate make a filling or
emptying. Your appliance does not have be refilled with refrigerant if
used properly and has an undamaged coolant circuit. GWP: R290: 3
• WARNING: In order to avoid
overheating, do not cover the heater.
PARTS DESCRIPTION
1. Supply cord
2. Tank
3. Filter
4. Back
5. Air outlet
6. Display
7. Front
BEFORE THE FIRST USE
• Place the unit in the correct upright position before unpacking.
• Take the appliance andaccessoriesoutthebox.Removethe
stickers,protective foilorplasticfrom thedevice.
• Before using your appliance for the first time, wipe off all
removable parts with a damp cloth. Never use abrasive products.
• Please ensure the unit is not placed against objects which will
obstruct air intake e.g. furniture or curtains as this will affect its
performance dramatically.
• Please don’t place or operate the unit in a narrow place
• Do not place the unit in full sun as it might shut down due to
overheat and the color of the unit may soon fade out.
• Do not place the unit in a humid place.

Instruction manual
7
• A distance of 20cm minimum must be kept between the unit and
the wall or any other obstacles.
• Putthepower cable intothe socket.(Note: Make surethe
voltagewhich is indicated on the devicematchesthe
localvoltage beforeconnecting the device.Voltage220V-240V
50Hz).
FUNCTIONS OF CONTROL PANEL
•Power button: Press to turn ON/OFF the unit. When
powered on the current humidity level will be shown. The unit will
begin in "CO" (Continuous) mode as default.
•Mode: use to switch between the different modes.
– Dehumidify (Auto or Manual operation)
– Fan (Fan mode only)
– Laundry (Full power mode)
•Up-Down: Set the required
humidity: "CO" (continuous), 30 to 90% and “AU” (Automatic).
The default mode is “CO”. Note: Press up and down at the same
time to convert the display from Humidity to Temperature. The
display will go back to Humidity after 5 seconds.
•Speed: Fan speed can be switched between high or
low. Note: In comfortable mode ("AU") with a room temperature
above 27 degree and in Laundry mode the fan speed is fixed and
cannot be adjusted.
•Timer (Regular time range 01-24 hours):
EN

Instruction manual
8
– In the power on state press timer to set the timer for
scheduled shutdown.
– In the off state press timer to set the timer for scheduled start
of the dehumidifier.
•Swing: Swing function on/off, pressing the button when
the dehumidifier is on will let the louver swing continuously, press
the button again to let the louver stop moving. When stopped the
Louver will be fully open to maximise airflow.
•Child lock: Hold for 5 seconds to activate the child lock
function, all other functions will not work when activated, to
disable the child lock hold the same button again for 5 seconds.
•Wi-Fi: To set the dehumidifier in pair mode, press and
hold the Wi-Fi button until the indicator starts to flash, it could take
about 6 seconds, then follow the steps in the Princess Home app.
DEHUMIDIFY MODE SETTINGS
Manual humidity set operation:
In this mode you can set a custom humidity level from 30 to 90%. The
dehumidifier will work to reduce the humidity providing the room
humidity level is above the set level.
Once the humidity is reduced the compressor will automatically turn
off and the fan will continue to run. If the humidity level rises again
then the compressor will begin again.
CO (Continuous) operation:
In this mode the dehumidifier will continuously run regardless of the
room humidity. The fan speed can be adjusted.
AU (Automatic) operation:
In this mode the dehumidifier will operate automatically to the below
levels:
Room temperature 5c to 20c = 60% humidity.
Room temperature 20c to 27c = 55% humidity.
Room temperature above 27c = 50% humidity.
Laundry mode:
In this mode the dehumidifier is in full power operation and will
continue to operate regardless of the humidity level. The fan speed is
locked on high and cannot be adjusted.
Fan mode:
In this mode the dehumidifier will only operate for air circulation and
the compressor will not run. The humidity will not be reduced in this
mode.

Instruction manual
9
Water full:
If the water tank is full the full indicator will show red and an alarm will
sound. Empty and replace the water tank and the dehumidifier will
automatically resume its set operation.
NOTE: The compressor will not begin until 3 minutes has passed.
Automatic Defrost:
It is possible that the dehumidifier can produce internal frost. This is
normal and the dehumidifier will automatically go into defrost mode
when frost is detected to reduce this.
The compressor will turn off and the fan will continue, once the
defrost has finished the compressor will start and normal operation
will continue.
USING THE DEHUMIDIFIER WITH PRINCESS
HOME APP
• The dehumidifier can be used manually with its built-in controls or
you can use a smart phone or smart speaker to control it. Before
you begin, ensure the Princess Home app is downloaded. The
Princess Home app is available on Android and iOS.
• Download the correct version of the Princess Home app via our
website princesshome.eu/nl-nl/princess-home-app or use QR:
Pair your dehumidifier to Princess Home app
• Make sure your dehumidifier is powered and that the unit in pair
mode by pressing and holding the Wi-Fi button, it could take
about 6 seconds.
• Open the Princess Home app.
EN

Instruction manual
10
• Select your country code, enter the cell phone number and tap
“Get” to get a message containing the verification code.
• Enter the verification code in the message and tap “Log in” to log
in to the App.
• Click "Add Device" to add a new device.
• Select the device you wanted to connect.
• Follow the instructions on the app to connect the dehumidifier.
• To control your device with voice using a smart speaker please
refer to the manufacturer's instructions on how to enable a skill
through your device.
EMPTY THE WATER TANK
• When the drainage tank is full, the tank full indicator light will turn
on, the operation will stop automatically and the buzzer will beep
15 times.
• Gently press on the sides of the tank and pull the tank out with
both hands.
• Empty the water tank above a sink.
• Do not remove the float from the water tank, otherwise the water
sensor cannot detect the water level, causing the unit to
malfunction.
• If the tank is dirty, use water for cleaning. Do not use gasoline or
other chemicals, because it may damage the water tank and
cause water leakage.
• Press the tank tightly with both hands to put it into place.
• If the water tank is not positioned correctly, the full water sensor
will remain active and the dehumidifier will not work.
CONTINUOUS WATER DRAINAGE
• The unit features a continuous drainage port. Using a plastic pipe
(with an inner diameter of 10mm). Take out the water tank and
put the drainpipe over the water outlet of the unit. Put the water
tank back in place and guide the drainpipe through the hole of the
water tank. The water in the drainage tank can be continuously
drained out from the continuous port on the unit.

Instruction manual
11
FILTER CLEANING
• Take the filter out of the unit.
• Clean the filter using a vacuum cleaner to gently absorb dust on
the filter screen surface.
• Use some warm water and a mild detergent if it is very dirty.
Make sure the filter is completely dry before you put it back.
• Push the two hooks to put the filter back into the unit.
CLEANING MAINTENANCE
• Before cleaning, be sure to disconnect the unit from any electric
supply outlet.
• First clean the surface with a neutral detergent and wet cloth, and
then wipe it with a dry cloth.
• Do not use gasoline or other chemicals to clean the unit.
STORAGE
• Empty the water in the tank.
• Roll up the power cord.
• Clean the filter.
• Store the unit in a cool and dry place.
TROUBLESHOOTING
Problem Possible causes Suggested solution
The machine
doesn't work.
Is the power line properly
connected?
Connect the plug into the
socket.
Full water indicator light is
on (water tank full or not in
the right place).
Drain the water in the tank and
put it in place.
The room temperature is
above 35 degrees or under
5 degrees.
The protection is started and
the machine will not work.
Is the lock on? If the lock is on, please unlock
by press and hold the lock
button for 5 seconds.
EN

Instruction manual
12
Dehumidification
function cannot
start.
Is the filter blocked? Clean the filter (screen)
according to the cleaning
instructions.
Is the air inlet or outlet
blocked?
Remove the obstruction from
the air inlet or outlet.
The machine
makes noise.
Is the machine tilted? Move the machine to a flat,
horizontal surface.
Is the filter blocked? Clean the filter (screen)
according to the cleaning
instructions.
E1 Code Coil sensor short circuit or
open circuit
Check if the line is loose or
replace the coil sensor.
THE PRODUCT OR EQUIPMENT CONTAINS
FLUORINATED GREENHOUSE GAS.
Art.nr. 368020
Coolant: R290
Quantity in kg: 0.05
Global Warming Potential: 3
CO2 Equivalent in tonnes: 0.00015
DECLARATION OF CONFORMITY
• Hereby, Smartwares Europe declares that the radio equipment
type 368020 is in compliance with Directive 2014/53/EU
• The full text of the EU declaration of conformity is available at the
following internet address: www.princesshome.eu/doc
ENVIRONMENT
This appliance should not be put into the domestic garbage at
the end of its durability, but must be offered at a central point for the
recycling of electric and electronic domestic appliances. This symbol
on the appliance, instruction manual and packaging puts your
attention to this important issue. The materials used in this appliance
can be recycled. By recycling of used domestic appliances you
contribute an important push to the protection of our environment. Ask
your local authorities for information regarding the point of
recollection.
Support
You can find all available information and spare parts at
www.princesshome.eu!

© Copyright 2022
Wireless technology: Wi-Fi
Operating frequency: 2.400~2.484GHz
Max. radio-frequency power: 17.5dBm
